6052
D. D. Long et al. / Bioorg. Med. Chem. Lett. 22 (2012) 6048–6052
and 50 mg, qd).17 Velusetrag also improved stool consistency,
Vehicle
and reduced both straining and the use of laxatives. In both the
Phase 1 and Phase 2 studies velusetrag was well tolerated.
Following on from our previous efforts utilizing our multivalent
approach to drug discovery towards 5-HT4 receptor agonists we fo-
cused on identification of neutral secondary binding groups. Com-
bination of a quinolone–tropane primary binding group with a
chiral 2-propanol linker to a neutral N-methyl-methylsulfonamide
secondary binding group afforded velusetrag (TD-5108), which
was selected as a development candidate. Velusetrag is a potent
and highly selective 5-HT4 receptor agonist in vitro with robust
in vivo GI activity and an attractive oral pharmacokinetic profile.
In human subjects, velusetrag has achieved proof-of-concept in pa-
tients with chronic idiopathic constipation and shown clinical evi-
dence for potential utility in the treatment of both upper and lower
GI disorders. Velusetrag has been well tolerated in all clinical trials
to date and is currently under active development.
Compound 15 (0.003mg/kg)
Compound 15 (0.03mg/kg)
Compound 15 (0.3mg/kg)
Compound 15 (3mg/kg)
400
300
200
100
0
*
Figure 5. Guinea pig colonic transit following subcutaneous dosing of compound
15.
of carmine red dye relative to vehicle treated animals. Following
subcutaneous administration, prokinetic activity was evident
when the distance traveled by the dye was measured 60 min later
(data not shown), or when the time for excretion of the first fecal
pellet containing the marker was recorded, Figure 5. In this assay,
15 appeared to have superior potency to tegaserod, although tegas-
erod did not achieve a statistically significant increase in colonic
transit at the doses tested.
Acknowledgments
The authors would like to thank Dr. Jeff Finer from Theravance,
Inc. for his assistance in reviewing this article, Dr. Robert Chao for
work related to crystal structure determination and Shanti
Amagasu for electrophysiology work.
References and notes
Additional profiling of 15 included demonstration of good oral
bioavailability and GI motility in dogs.9,13 The effects of 15 on
1. Camilleri, M.; Kerstens, R.; Rykx, A.; Vandeplassche, L. N. Engl. J. Med. 2008, 358,
2344.
secretion of soluble amyloid precursor protein alpha (sAPPa from
HEK293 cells-stably transfected with human 5-HT4(d) receptor
and human APP695 in an in vivo model of cognition (rat Morris
water maze) were also examined.2 The results obtained support a
potential role for potent and efficacious 5-HT4 receptor agonists
in providing symptomatic and disease-modifying benefit in the
treatment of Alzheimer’s disease.
Subsequently compound 15 was nominated as a development
candidate, velusetrag (TD-5108) and advanced to human clinical
trials. Accordingly an alternate, optimized synthesis of velusetrag
was devised to support IND-enabling studies and clinical manufac-
ture, Scheme 3.14 The key chiral NMe-sulfonamide substituted
epoxide 17 was prepared in a single step by reaction of MeNHSO2Me
16 with (S)-epichlorohydrin under basic aqueous conditions. It is
believed that opening of the epoxide occurs first with subsequent
base mediated closure of the hydroxy chloro intermediate to yield
17. Reaction of this functionalized epoxide 17 with the quinolone
tropane 6 and subsequent freebasing and crystallization as the
hydrochloride salt afforded velusetrag.
In healthy human subjects, dose-related prokinetic activity,
including increases in stool production, were observed with single
doses of velusetrag up to 70 mg and repeated daily doses of up to
50 mg for 14 days.15 The pharmacokinetics of velusetrag over the
single dose-range demonstrated dose-dependent increases in sys-
temic exposure and was supportive of once daily dosing (elimina-
tion half-life of 12–14 h). These pharmacokinetic findings were
similar in patients with chronic constipation from a separate study
in which velusetrag was shown to increase gastric emptying as
well as intestinal and colonic transit in healthy volunteers, sug-
gesting utility in both upper and lower GI disorders.16 In a large
(n = 401), proof-of-concept, Phase 2 trial (ACCORD) in patients with
chronic idiopathic constipation velusetrag showed statistically and
clinically significant increases relative to placebo in both weekly
spontaneous bowel movement frequency and the weekly fre-
quency of complete SBM at all three doses tested (15 mg, 30 mg
2. Shen, F.; Smith, J. A. M.; Chang, R.; Bourdet, D. L.; Tsuruda, P. R.; Obedencio, G.
P.; Beattie, D. T. Neuropharmacol 2011, 61, 69.
3. Megerian, J. T. International Conference on Alzheimer’s Disease. 2008, HT-01-07.
4. Long, D. D.; Armstrong, S. R.; Beattie, D. T.; Choi, S.-K.; Fatheree, P. R.; Gendron,
R. A. L.; Goldblum, A. A.; Humphrey, P. P.; Marquess, D. G.; Shaw, J. P.; Smith, J.
A. M.; Turner, S. D.; Vickery, R. G. Bioorg. Med. Chem. Lett. 2012, 22, 4849.
5. (a) Long, D. D.; Aggen, J. B.; Christensen, B. G.; Judice, J. K.; Hegde, S. S.; Kaniga,
K.; Krause, K. M.; Linsell, M. S.; Moran, E. J.; Pace, J. L. J. Antibiot. 2008, 61, 595;
(b) Choi, S.-K.; Green, D.; Ho, A.; Klein, U.; Marquess, D.; Taylor, R.; Turner, S. D.
J. Med. Chem. 2008, 51, 3609; (c) Hughes, A. D.; Chin, K. H.; Dunham, S. L.;
Jasper, J. R.; King, K. E.; Lee, T.-W.; Mammen, M.; Martin, J.; Steinfeld, T. Bioorg.
Med. Chem. Lett. 2011, 21, 1354; (d) Jacobsen, J. R.; Choi, S.-K.; Combs, J.;
Fournier, E. J. L.; Klein, U.; Pfeiffer, J. W.; Thomas, R.; Yu, C.; Moran, E. J. Bioorg.
Med. Chem. Lett. 2012, 221, 1213.
6. McKinnell, R. M.; Armstrong, S. R.; Beattie, D. T.; Choi, S.-K.; Fatheree, P. R.;
Gendron, R. A. L.; Goldblum, A.; Humphrey, P. P.; Long, D. D.; Marquess, D. G.;
Shaw, J. P.; Smith, J. A. M.; Turner, S. D.; Vickery, R. G. J. Med. Chem. 2009, 52,
5330.
7. In the case of compound 15 with the NMeSO2Me secondary binding group the
(R)-OH-designation corresponds to the same relative configuration as the (S)-
OH-designation of THRX-194556 (5) with the piperazine–sulfonamide
secondary binding group.
8. Smith, J. A. M.; Beattie, D. T.; Marquess, D.; Shaw, J.-P.; Vickery, R. G.;
Humphrey, P. P. A. Naunyn Schmiedebergs Arch. Pharmacol. 2008, 378, 12.
9. Beattie, D. T.; Armstrong, S. R.; Shaw, J. P.; Marquess, D.; Sandlund, C.; Smith, J.
A.; Taylor, J. A.; Humphrey, P. P. Naunyn Schmiedebergs Arch. Pharmacol. 2008,
378, 139.
10. Briejer, M. R.; Bosmans, J. P.; Van Daele, P.; Jurzak, M.; Heylen, L.; Leysen, J. E.;
Prins, N. H.; Schuurkes, J. A. Eur. J. Pharmacol. 2001, 423, 71.
11. Wardle, K. A.; Sanger, G. J. Br. J. Pharmacol. 1993, 110, 1593.
12. Armstrong, S. R.; McCullough, J. L.; Beattie, D. T. J. Pharmacol. Toxicol. Methods
2006, 53, 198.
13. Shaw, J.-P.; Deattie, D.; Cheong, J.; Choi, S.-K.; Kern, R.; Marquess, D.;
Obedencio, G.; Smith, J.; Humphrey, P. AAPS Ann. Meet. Expos. 2007, 9, 2422.
14. Complete synthesis of velusetrag is described in Marquess, D.; Fatheree, P. R.;
Turner, S. D.; Long, D. D.; Choi, S.-K.; Goldblum, A. A.; Genov, D. U.S. Patent
2008, 114, 7375.
15. Goldberg, M. R.; Wong, S. L.; Ganju, J.; Li, Y.-P.; Ballow, C. H.; Kitt, M. M.
Gastroenterology 2007, 132, 322.
16. Manini, M. L.; Camilleri, M.; Goldberg, M.; Sweetser, S.; McKinzie, S.; Burton,
D.; Wong, S.; Kitt, M. M.; Li, Y.-P.; Zinsmeister, A. R. Neurogastroenterology
2010, 22, 42.
17. Goldberg, M.; Li, Y.-P.; Johanson, J. F.; Mangel, A. W.; Kitt, M.; Beattie, D. T.;
Kersey, K.; Daniels, O. Aliment. Pharmacol. Ther. 2010, 32, 1102.
