Photophysics of Platinum
−Acetylide Substituted
Hexa-peri-hexabenzocoronenes
Kye-Young Kim, Shengxia Liu, Muhammet E. Ko1se, and Kirk S. Schanze*
Department of Chemistry, UniVersity of Florida, P.O. Box 117200,
GainesVille, Florida 32611-7200
Received October 16, 2005
This manuscript reports the synthesis and photophysical investigation of two hexa-peri-hexabenzocoronenes (HBCs)
that are functionalized with platinum(II) acetylide units of the type trans-(Ar )2Pt(PBu3)2. In one complex, the
platinum is directly linked to the HBC chromophore by an ethynyl spacer, whereas in the second, the platinum is
separated from the HBC via a 1,4-phenylene ethynylene spacer. The Pt acetylide units introduce strong spin
−CtC−
−
−
orbit coupling into the HBC chromophore, giving rise to high yields of the triplet excited state along with moderately
intense phosphorescence at ambient temperature. On the basis of emission spectroscopy, the triplet state of the
HBC chromophore is located at 2.14 eV and the S
−T splitting is 0.6 eV. The triplet
−triplet absorption and radical
cation absorption spectra of the Pt HBCs are determined by laser flash photolysis. Aggregation of the Pt
−
−HBCs
in a poor solvent such as hexane leads to quenching of the triplet state, but spectroscopy provides no evidence
for the formation of a triplet excimer, even under conditions where the molecules are strongly aggregated.
Introduction
HBCs that are substituted on the periphery with solubi-
lizing alkyl groups aggregate into discotic liquid crystalline
phases due to their disk shape and large-area planar π
systems.7-9 A number of investigations have been carried
out to characterize the properties of all-organic HBC-based
materials.10,11 These studies have demonstrated that in the
solid state the materials display very high charge carrier
mobility, an effect which is believed to be due to strong π-π
interactions between adjacent molecules in columnar stacks.12
Several investigations have also demonstrated that the
absorption and fluorescence properties of the HBC chro-
mophore are influenced by aggregation, and the effects are
attributed to interchromophore interactions, e.g., π-stacking
and singlet excimer formation in the excited state.9
Large polycyclic aromatic hydrocarbons have been the
focus of considerable research interest during the past several
years. When substituted with alkyl or alkyloxy groups, the
structures are soluble in typical organic solvents, and due to
the planar, disk shape of the aromatic core the molecules
have a strong tendency to aggregate.1,2 Of particular recent
interest is the family of substituted hexa-peri-hexabenzo-
coronenes (HBCs), which have been studied intensively by
Mu¨llen and co-workers.3,4 Although there are early reports
concerning the properties of the unsubstituted parent HBC,5,6
work in this field has been fueled by the development of
synthetic approaches that allow relatively large-scale syn-
thesis of a variety of functionalized HBC derivatives.3,7
Introduction of a transition metal that is strongly coupled
to the HBC can provide a means to tune the optical and
electronic properties of the chromophore without sacrificing
its propensity to self-assemble into aggregates and liquid
* To whom correspondence should be addressed. Tel: 352-392-9133.
Fax: 352-392-2395. E-mail: kschanze@chem.ufl.edu.
(1) Gallivan, J. P.; Schuster, G. B. J. Org. Chem. 1995, 60, 2423-2429.
(2) Nuckolls, C.; Katz, T. J.; Castellanos, L. J. Am. Chem. Soc. 1996,
118, 3767-3768.
(3) Ito, S.; Wehmeier, M.; Brand, J. D.; Kubel, C.; Epsch, R.; Rabe, J.
P.; Mu¨llen, K. Chem.-Eur. J. 2000, 6, 4327-4342.
(4) Simpson, C. D.; Wu, J. S.; Watson, M. D.; Mu¨llen, K. J. Mater. Chem.
2004, 14, 494-504.
(5) Clar, E.; Ironside, C. T.; Zander, M. J. Chem. Soc. 1959, 142-147.
(6) Clar, E. Polycyclic Hydrocarbons; Academic Press: London, New
York, 1964; Vol. 2.
(8) Pisula, W.; Kastler, M.; Wasserfallen, D.; Pakula, T.; Mu¨llen, K. J.
Am. Chem. Soc. 2004, 126, 8074-8075.
(9) Kastler, M.; Pisula, W.; Wasserfallen, D.; Pakula, T.; Mu¨llen, K. J.
Am. Chem. Soc. 2005, 127, 4286-4296.
(10) Wu, J. H.; Watson, M. D.; Mu¨llen, K. Angew. Chem., Int. Ed. 2003,
42, 5329-5333.
(11) Wu, J. S.; Watson, M. D.; Zhang, L.; Wang, Z. H.; Mu¨llen, K. J. Am.
Chem. Soc. 2004, 126, 177-186.
(7) Fechtenkotter, A.; Tchebotareva, N.; Watson, M.; Mu¨llen, K. Tetra-
hedron 2001, 57, 3769-3783.
(12) van de Craats, A. M.; Warman, J. M.; Fechtenkotter, A.; Brand, J.
D.; Harbison, M. A.; Mu¨llen, K. AdV. Mater. 1999, 11, 1469-1472.
10.1021/ic051788v CCC: $33.50
Published on Web 02/11/2006
© 2006 American Chemical Society
Inorganic Chemistry, Vol. 45, No. 6, 2006 2509

Kim et al.
Chart 1
provides clear evidence that aggregation of the Pt-HBCs
suppresses the triplet yield and lifetime. By contrast,
spectroscopic studies show that the electronic structure of
the triplet state in the Pt-HBCs is not strongly affected by
aggregation, suggesting that triplet state remains localized
on a single HBC chromophore despite the existence of
intermolecular π-π interactions in the aggregates.
Experimental Section
crystalline phases. Although a number of investigations have
explored the properties of all-organic HBCs, to date only
two metal-organic HBC complexes have been reported.13,14
This previous investigation examined the optical and elec-
trochemical properties of an N-heterocyclic HBC derivative
coordinated to -Ru(bpy)22+ or Pd(η3‚C3H5)+ units.13,14 The
Ru-HBC complex displayed a near-infrared photolumines-
cence arising from a Ru f HBC metal-to-ligand charge-
transfer excited state.
The present manuscript reports the synthesis and photo-
physical investigation of two HBCs that are functionalized
with platinum(II) acetylide units of the type trans-(Ar-Ct
C-)2Pt(PBu3)2 (structures 1 and 2, Chart 1). The Pt-
acetylide units are of interest because they introduce strong
spin-orbit coupling into the HBC chromophore, giving rise
to high yields of the triplet excited state along with
moderately efficient phosphorescence at ambient temper-
ature.15-20 The Pt-substituted HBCs are soluble in typical
organic solvents, and like the all-organic HBCs, they exhibit
a strong tendency to aggregate, even in dilute solution.
Because the platinum center enhances intersystem crossing
and phosphorescence, it is possible to probe the effect of
aggregation of the HBC chromophore on the properties of
the triplet excited state in this system. The work presented
herein is unique because most previous studies concerning
the effects of aggregation on the optical properties of
π-conjugated materials have focused on the singlet state.21-26
This is in part because the singlet state is more easily probed
spectroscopically compared to the triplet. The present work
General Methods. All starting materials were used without
