Hexose Rearrangements upon Fragmentation of
N-Glycopeptides and Reductively Aminated
N-Glycans
Manfred Wuhrer,* Carolien A. M. Koeleman, and Andre´ M. Deelder
Leiden University Medical Center, Biomolecular Mass Spectrometry Unit, Department of Parasitology,
P.O. Box 9600, 2300 RC Leiden, The Netherlands
Tandem mass spectrometry of glycans and glycoconju-
gates in protonated form is known to result in rearrange-
ment reactions leading to internal residue loss. Here we
studied the occurrence of hexose rearrangements in
tandem mass spectrometry of N-glycopeptides and reduc-
tively aminated N-glycans by MALDI-TOF/TOF-MS/MS
and ESI-ion trap-MS/MS. Fragmentation of proton ad-
ducts of oligomannosidic N-glycans of ribonuclease B that
were labeled with 2-aminobenzamide and 2-aminobenzoic
acid resulted in transfer of one to five hexose residues to
the fluorescently tagged innermost N-acetylglucosamine.
Glycopeptides from various biological sources with oli-
gomannosidic glycans were likewise shown to undergo
hexose rearrangement reactions, resulting in chitobiose
cleavage products that have acquired one or two hexose
moieties. Tryptic immunoglobulin G Fc-glycopeptides with
biantennary N-glycans likewise showed hexose rearrange-
ments resulting in hexose transfer to the peptide moiety
retaining the innermost N-acetylglucosamine. Thus, as a
general phenomenon, tandem mass spectrometry of re-
ductively aminated glycans as well as glycopeptides may
result in hexose rearrangements. This characteristic of
glycopeptide MS/MS has to be considered when develop-
ing tools for de novo glycopeptide structural analysis.
