Please do not adjust margins
New Journal of Chemistry
Page 6 of 8
DOI: 10.1039/C7NJ01839H
ARTICLE
Journal Name
reaction mixture was evaporated to afford the crude compound
which was purified by silica gel column chromatography (15 %
EtOAc/petroleum ether) to gave the pure compound 5a (5.5 g, 88%)
as white solid. 1H NMR (400 MHz, CDCl3): δ = 8.38 (m, 2H), 7.87 (dd,
2H), 7.76 (t, 1H), 7.57 (m, 2H), 7.48 (m, 3H). MS (EI): m/z 250
(M+1,100).
Conclusions
In summary, we have developed
a facile and versatile
procedure for the synthesis of functionalized novel 2, 5-diphenyl-
5H-chromeno [4, 3-d] pyrimidin-5-ol and (2, 4-diphenylpyrimidin-5-
yl) (2-hydroxyphenyl) methanone. This is the first report of ANRORC
reaction of 3-benzoyl chromone with benzamidines. These findings
will significantly expand the value of chromones in the synthesis of
heterocycles.
2, 4-diphenylpyrimidin-5-yl)(2-hydroxyphenyl)
methanone (8a) & 2, 5-diphenyl-5H-chromeno [4,
3-d] pyrimidin-5-ol (7a): 25 % NaOMe (0.8 ml, 3.6 mmol) in
methanol was taken in methanol under N2 atm, to this compound
6a (0.313 g, 2.00 mmol) was added at RT and stirred for 5 min. Then
compound 5a was added and stirred the reaction mixture at RT for
16 h. The progress of the reaction was monitored by TLC (20% Ethyl
acetate in petroleum ether) showed completion of the reaction.
After completion of the reaction; the reaction mixture evaporated
to afford the crude compound which was purified by silica gel
column chromatography Elution of the column with 10%
EtOAc/petroleum ether to gave the pure compound 7a (0.400 g,
57%) as white solid. M.p. 171-175 °C. 1H NMR (400 MHz, DMSO-d6):
δ = 8.52 (m, 3H), 8.31 (d, 2H), 7.62 (m, 6H), 7.48 (m, 3H), 7.27 (t,
1H), 7.17 (d, 1H). IR (KBr, cm−1): 3469, 3169, 1757, 1598, 1552,
1418, 1048, 957, 753, 692. 13C NMR (100 MHz, CD3COCD3) = 164.8,
156.6, 155.8, 154.5, 142.5, 138.4, 131.7, 131.9, 134.5, 131.9, 129.8,
129.7, 129.5, 129.1, 127.9, 126.2, 125.8, 125.3, 123.2, 121.0, 120.8,
119.1, 99.9. MS (EI): m/z 352 (M+1,100), HRMS: (ESI): Calcd for:
C23H16N2O2 [M+H]: 353.1212; Found: 353.1316.
Elution of the column with 5 % EtOAc/petroleum ether to gave
the pure compound 8a (0.150 g, 21%) as white solid. M.p. 129-133
°C. 1H NMR (400 MHz, CDCl3): δ = 11.90 (s, 1H), 8.87 (s, 1H), 8.64
(m, 2H), 7.76 (dd, 2H), 7.56 (m, 3H), 7.39 (m, 4H), 7.36 (d, 1H), 7.01
(dd, 1H), 6.72 (t, 1H). IR (KBr, cm−1): 3227, 3058, 1971, 1621, 1549,
1419, 1332, 1240, 922, 742, 692. 13C NMR (100 MHz, DMSO-d6) =
196.34, 163.3, 159.3, 156.9, 136.86, 136.80, 136.5, 136.0, 131.4,
130.9, 130.27, 130.2, 129.05, 129.0, 128.8, 128.4, 128.41, 128.14,
128.10, 122.37, 122.3, 119.3, 117.3. MS (EI): m/z 352 (M+1,100),
HRMS: (ESI): Calcd for: C23H16N2O2 [M+H]: 353.1212; Found:
353.1320.
General Experimental Details. Dry solvents were
purchased from chemical suppliers and used without further
purification. Analytical thin-layer chromatography (TLC) was
performed on commercially available Merck TLC Silica gel 60 F254
.
Silica gel column chromatography was performed on silica gel 60
(spherical 100-200 µm). IR spectra were recorded on Perkin-Elmer
FT/IR-4000 using ATR.1H NMR spectra were recorded on Varian-400
(400 MHz) spectrometer. Chemical shifts of 1H NMR spectra were
reported relative to tetra methyl silane. 13C NMR spectra were
recorded on Varian-400 (100 MHz) spectrometer. Chemical shifts of
13C NMR spectra were reported to relative to CDCl3 (77.16) and
DMSO-d6 (39.5). Splitting patterns were reported as s, singlet; d,
doublet; t, triplet; q, quartet; m, multiplet; br, broad.
Experimental Procedure for the Preparation of 2-
acetylphenyl benzoate (3a): To a stirred solution of 2-
hydoxy acetophenone (1a) (2 g, 14.68 mmol) in pyridine (3 ml) was
added benzoyl chloride (2a) (2.9 g, 20.56 mmol) at 0 0C and the
reaction mixture was stirred at RT for 1h. The progress of the
reaction was monitored by TLC (5% Ethyl acetate in petroleum
ether) showed completion of the reaction. After completion of the
reaction; the reaction mixture was poured in to ice cold 1N HCl (70
ml) and stirred at RT for 2 h. The solid was filtered and washed with
water and dried under vacuum to give the crude product. The crude
product was washed with n-pentane to afford the pure compound
1
3a (3 g, 85%) as white solid. H NMR (400 MHz, CDCl3): δ = 8.22 (d,
2H), 7.87 (d, 1H), 7.68 (m, 1H), 7.56 (m, 3H), 7.39 (t, 1H), 7.25 (m,
1H), 2.54 (s, 3H). MS (EI): m/z 240 (M+1,100).
1-(2-hydroxyphenyl)-3-phenylpropane-1, 3-dione
(4a): To a stirred solution of compound 3a (2.7g, 11.25mmol) in
pyridine (10 ml) was added NaOH powder (675 mg, 16.87 mmol) at
50 0C and the reaction mixture was stirred at the same temperature
for 1h. The reaction mixture became thick solid. The progress of the
reaction was monitored by TLC (10% Ethyl acetate in petroleum
ether) showed completion of the reaction. After completion of the
reaction; the reaction mixture was acidified with 20 % acetic acid
solution and stirred at RT for 3 h. The yellow coloured solid was
filtered and washed with water and dried under vacuum to afford
the pure compound 4a (2.4 g, 90%) as yellow solid. 1H NMR (400
MHz, CDCl3): δ = 15.54 (s, 1H), 12.09 (s, 1H), 7.93 (m, 2H), 7.78 (dd,
1H), 7.75 (m, 1H), 7.50 (m, 3H), 7.01 (dd, 1H), 6.90 (t, 1H), 6.85 (s,
1H). MS (EI): m/z 240 (M+1,100).
Acknowledgements
Authors are grateful to GVK Biosciences Pvt. Ltd., for the financial
support and encouragement. Help from the analytical department
for the analytical data is appreciated. We thank Dr. Sudhir Kumar
Singh for his invaluable support and motivation.
Notes and references
1
2
H. Knolker, K. R. Reddy, Chem. Rev. 2002, 102, 4303.
M. D. Watson, A. Fechtenktter, K. Milen, Chem. Rev. 2001,
101, 1267.
3
4
C. Li, F. Zhang, Tetrahedron Lett. 2017, 58, 1572.
G. Lahoud, V. Timoshchuk, A. Lebedev, K. K. Arar, Y. M. Hou,
H. Gamper, Nucleic Acids Res. 2008, 36, 6999.
3-benzoyl-4H- chromen-4-one (5a): To a stirred solution
of compound 4a (6 g, 25.00 mmol) in toluene (60 ml) was added
DMF-DMA (17 ml, 75.00 mmol) at 5 0C and the reaction mixture
was heated to 80 0C for 1h. The progress of the reaction was
monitored by TLC (10% Ethyl acetate in petroleum ether) showed
completion of the reaction. After completion of the reaction; the
5
6
7
8
M. Loeffler, E. Zameitat, Encycl. Biol. Chem. 2004,
W. B. Parker, Chem Rev. 2009, 109, 2880.
E. D. Clercq, Med. Res. Rev. 2003, 23, 253.
3, 600.
S. R. Krungkrai, J. Krungkrai, Asian Pac. J. Trop. Med. 2016, 9,
525.
