PAPER
One-electron oxidized product of difluoroiron(III) porphyrin: is it iron(IV)
porphyrin or iron(III) porphyrin p-cation radical?†
Akira Ikezaki,a,b Masashi Takahashic and Mikio Nakamura*a,b,d
Received 1st April 2011, Accepted 28th June 2011
DOI: 10.1039/c1dt10561b
The electronic structure of [Fe(TMP)F2], which is formally a one-electron oxidation equivalent above
[FeIII(TMP)F2]-, has been examined in solution by 1H NMR, UV-Vis, and Mo¨ssbauer spectroscopy. In
CD2Cl2–CD3OD solution at 193 K, the pyrrole-H and m-H signals appeared at 128.2 and 116.7 ppm,
respectively. The UV-Vis spectrum showed broad absorption bands at 560–680 nm. The Mo¨ssbauer
spectrum taken in frozen toluene–methanol solution exhibited a very broad single line from which the
IS and QS values were determined by computer simulation to be 0.50 and 0.14 mm s-1, respectively. On
the basis of these results, it was concluded that the one-electron oxidized product of [Fe(TMP)F2]-
should be formulated as the iron(III) radical cation [FeIII(TMP∑)F2], not as iron(IV) porphyrin
[FeIV(TMP)F2] as previously suggested.
electron oxidized species was unsuccessful due to the instability
Introduction
of the product.21,22 Density functional studies also predicted the
formation of [FeIV(TPP)F2] rather than [FeIII(TPP∑)F2].23 Recently,
High-valent iron porphyrin complexes are key reactive intermedi-
ates in heme enzymes such as Cytochrome P450 and peroxidase.1–3
Ghosh and Taylor reported the opposite result on the basis
Revealing the nature of the reactive intermediates has been an
of the more accurate and sophisticated CASPT2 calculations;
[FeIII(TPP∑)F2] is 0.31 eV more stable than [FeIV(TPP)F2].24 More
issue of great interest. Thus, extensive studies have been done
on the formation and characterization of various one- and two-
recently, Panchmatia et al. reached the same conclusion by using
electron oxidized products of iron(III) porphyrins.4,5 In principle,
one-electron oxidation of iron(III) porphyrin produces either
iron(IV) porphyrin or the iron(III) porphyrin radical cation.6–12
Actually however, iron(IV) porphyrins are rarely obtained except
for the complexes having an FeIV O unit.11,12 A unique example
is [FeIV(TMP)(OMe)2] reported by Groves et al. in 1985.13,14
The factors affecting the iron(IV) states have been discussed
theoretically by Ghosh et al.15,16 Finding another example of
an iron(IV) complex is quite important to reveal the general
conditions that stabilize the iron(IV) porphyrin relative to the
iron(III) porphyrin radical cation.17–19 Among various axial ligands,
fluoride should be the most plausible candidate because it is
classified as a strong field ligand as methoxide.20 In fact, the
oxidation potential of [FeIII(TPP)F2]- is quite unusual because the
first oxidation wave is observed at +0.68 V, which is ca. 0.4 V less
anodic than that of a large number of high-spin five-coordinate
[FeIII(TPP)X] compounds.21 However, the isolation of the one-
DFT+U and UB3LYP techniques.25 In this paper, we will describe
the electronic structure of [Fe(Por)F2], which corresponds to the
one-electron oxidized product of [FeIII(Por)F2]-, not only to answer
the controversial issue but also to seek for the general conditions
to obtain iron(IV) porphyrin complexes.
Results and discussion
1H NMR spectroscopy
To obtain the complex that is the one-electron oxidation equivalent
above [FeIII(TMP)F2]-, the methanol-d4 (CD3OD) solution of
tetrabutylammonium fluoride(Bu4NF) was added at 193 K to the
CD2Cl2 solution of [Fe(TMP∑)(ClO4)2] in an NMR sample tube as
shown in Scheme 1. The starting complex, [FeIII(TMP∑)(ClO4)2],
aDepartment of Chemistry, School of Medicine, Toho University, Ota-ku,
Tokyo, 143-8540, Japan. E-mail: mnakamu@med.toho-u.ac.jp
bResearch Centre for Materials with Integrated Properties, Toho University,
Funabashi, 274-8510, Japan
cDepartment of Chemistry, Faculty of Science, Toho University, Funabashi,
274-8510, Japan
dDivision of Chemistry, Graduate School of Science, Toho University,
Funabashi, 274-8510, Japan
† Electronic supplementary information (ESI) available. See DOI:
10.1039/c1dt10561b
Scheme 1 Formation of the complex that is the one-electron oxidation
equivalent above [FeIII(TMP)F2]-.
This journal is
The Royal Society of Chemistry 2011
Dalton Trans., 2011, 40, 9163–9168 | 9163
©

View Article Online
should be partially converted to [FeIII(TMP∑)(CD3OD)2](ClO4)2
and/or [FeIII(TMP∑)(ClO4)(CD3OD)](ClO4) in CD2Cl2–CD3OD
solution. In fact, the pyrrole-H signal appeared at ca. 100 ppm at
195 K, which clearly indicates that the complex adopts the S = 5/2
spin state; [FeIII(TMP∑)(ClO4)2] shows the pyrrole-H signal at -22.5
ppm since the complex adopts the mixed S = 3/2, 5/2 spin state.6,13
The o-CH3, m-H, and p-CH3 signals were observed extremely
downfield at 41, 121, and 27 ppm, respectively, in CD2Cl2–CD3OD
solution, suggesting that the porphyrin has a half-occupied a2u
orbital.13
Fig. 1 shows the 1H NMR spectra taken after the addition of (a)
1.0, (b) 1.5, and (c) 2.0 equiv of Bu4NF. When 1.0 equiv of Bu4NF
was added, the starting complex was completely converted to the
new complex signified as A as shown in Fig. 1(a). The signal at
112.8 ppm was assigned to the pyrrole-H of A by the spectral
comparison with the pyrrole-d8 complex shown in Fig. 1(a-1).
The presence of the downfield shifted pyrrole-H signal indicates
that A adopts the high-spin (S = 5/2) state. The mesityl signals
shifted upfield but they still appeared at extremely downfield
positions; the o-CH3, m-H, and p-CH3 signals were observed at
31.4 (average), 89.3 (average), and 18.7 ppm, respectively. Thus,
the radical cationic state is maintained even after the addition of
1.0 equiv of Bu4NF. Close inspection of the spectrum revealed
that the o-CH3 gave two very broad signals as shown in Fig. 1(a-
2). The results suggest that A is the mono-F complex formulated
either by five-coordinate [FeIII(TMP∑)F]ClO4 or by six-coordinate
[FeIII(TMP∑)F(CH3OH)]ClO4 and/or [FeIII(TMP∑)F(ClO4)]. By
the further addition of Bu4NF, the signals of A were gradually
replaced by those of the new complex signified as B as shown in
Fig. 1(b). When 2.0 equiv of Bu4NF was added, the signals of A
were almost completely replaced by those of B as shown in Fig.
1(c). The broad signal at 129.0 ppm was assigned to the pyrrole-
H on the basis of the spectral comparison with the pyrrole-d8
complex as shown in Fig. 1(c-1). Thus, the high-spin state of the
iron(III) ion is maintained during the addition of Bu4NF. The large
downfield shifts of the o-CH3, m-H, and p-CH3 together with the
single signals for the o-CH3 and m-H indicate that B should be best
formulated as high-spin (S = 5/2) six-coordinate [FeIII(TMP∑)F2]
where the radical spin is in the porphyrin a2u orbital.
The same reaction was carried out in CD2Cl2 solution con-
taining no CD3OD. By the addition of 1.0 equiv of Bu4NF, the
1H NMR spectrum completely changed to show the formation
of a new complex signified as A¢ as given in Fig. S1(a) of
the ESI.† Although the pyrrole signal of A¢ was observed at a
downfield position, i.e. 114.6 ppm, as in the case of A formed in
CD2Cl2–CD3OD solution, all the other signals appeared in the
opposite direction. For example, the o-CH3 signals were observed
at -8.6 and -11.7 ppm, m-H signals at -34.9, -37.8 ppm, and
1
the p-CH3 signal at -5.7 ppm. Thus, the H NMR spectrum of
A¢ resembles that of five-coordinate [FeIII(TPP∑)Cl]SbCl6,7 and
should be expressed as [FeIII(TMP∑)F]ClO4. The large upfield shift
of the m-H signals can then be explained in terms of the anti-
ferromagnetic coupling between the unpaired electrons in the a2u
and dz orbitals;7,26,27 this interaction is symmetry allowed in five-
2
coordinate complexes where the iron(III) ion is placed out of the
porphyrin plane.28,29 The result, in turn, indicates that the mono-F
complex A formed in CD2Cl2–CD3OD solution should be for-
mulated as high-spin six-coordinate [FeIII(TMP∑)F(CD3OD)]ClO4
and/or [FeIII(TMP∑)F(ClO4)] rather than [Fe(TMP∑)F]ClO4.
When 2.0 equiv of Bu4NF was added, [Fe(TMP∑)F]ClO4 was
completely converted to the new complex signified as B¢. Since
1
the H NMR spectrum of B¢ shown in Fig. S1(b)† is essentially
the same as that of B formed in CD2Cl2–CD3OD solution, B¢
should be formulated as [FeIII(TMP∑)F2]. We have noticed that
B is much more stable than B¢. That is, while the reduction of
1
B¢ took place during the H NMR measurement at 223 K, no
reduction was observed in the case of B even at 298 K. The result
suggests that methanol is playing an important role in stabilizing
[FeIII(TMP∑)F2]. Presumably, the hydrogen bonding with methanol
weakens the field strength of fluoride, which in turn weakens the
reducing ability of the coordinating fluoride ions. Table 1 lists
the chemical shifts of these complexes together with those of
analogous oxidized complexes.
In order to confirm if B is really the one-electron oxidation
equivalent above [FeIII(TMP)F2]-, the titration experiment was
carried out using Bu4NI as a reducing agent. As shown in Fig.
2(a) and (b), the addition of 0.5 equiv of Bu4NI converted
50% of B to high-spin [FeIII(TMP)F]. Complete conversion to
[FeIII(TMP)F] was achieved by the addition of 1.1 equiv of
Bu4NI as shown in Fig. 2(c). Thus, the titration result clearly
indicates that B is one-electron oxidation equivalent above the
iron(III) porphyrin. It should be noted that the one-electron re-
duction of [FeIII(TMP∑)F2] (B) produces [FeIII(TMP)F] rather than
Fig. 1 1H NMR spectral changes of [FeIII(TMP∑)(ClO4)2] observed when
(a) 1.0, (b) 1.5, and (c) 2.0 equiv. of (Bu4N)F was added at 193 K. (a-1) and
(c-1) are the downfield region of the pyrrole-d8 complex. Symbols o1, m1,
p1, and py1 correspond to the o-CH3, m-H, p-CH3, and pyrrole-H signals
of mono-F complex (A). Similarly, the symbols o2, m2, etc. correspond to
those of bis-F complex (B).
9164 | Dalton Trans., 2011, 40, 9163–9168
This journal is
