Brief Articles
Journal of Medicinal Chemistry, 2008, Vol. 51, No. 7 2309
Table 3. Cytotoxicity of Chalcones 6, 13, and 39 against Different Cell
Lines
Chalcone 6, one of the most active chalcones reported by
Bowen and co-workers,12 was prepared and its growth inhibition
against 11 cancer cell lines was compared to chalcones 13 and
39. As shown in Table 3, it is clear that higher antimitotic
activity is correlated to strong antiproliferative effect. The IC50
values observed, in the micromolar range, are in keeping with
those observed in human serum with a number of commercially
active anticancer agents, such as cytarabine, methotrexate, or
cyclophosphamide.
Although additional data, such as clearance studies, are
required, the preliminary toxicity data obtained on chalcone 13
suggest that it is a good candidate for further in vivo development.
The present investigation allowed the identification of active
chalcones with anticancer activities and brings new structural
elements that will aid in the design of more active chalcones.
One of the most active chalcones (chalcone 13) was formulated
and evaluated in vivo for toxicity in healthy animals. The lack
of toxicity makes this compound and probably its analogs
(chalcones 3 and 39) good candidates for in vivo evaluation
for antitumor chemotherapy.
chalcone (IC50, µM)a
cell line
6
13
60
2.2
30
0.25
1.3
0.45
1
0.65
39
52
4
30
0.8
10
1
2.2
1.9
50
MCF7
N2A
75
55
60
10
62
9
10
6
80
40
34
NIH3T3
SW48
HNO150
HCT116
Messa
CEM
K562
RL
L1210
50
0.8
7
0.9
8.5
a IC50 was determined with reference to a standard curve constructed
for control cells and represents the concentration that results in a 50%
decrease in cell growth after 24 h incubation.
importance of methoxylation on the A-ring was previousley
reported and discussed by Ducki and co-workers.10,14 Indeed,
a number of potent anticancer chalcones having three methoxy
groups at 3′,4′,5′-positions were reported (IC50 within the nM
range). The presence of a hydrogen-bond donor such as an NH2
at 4′-position (compound 56) did not affect the cell cycle arrest
showing that this position may tolerate a variety of substituents.
The beneficial effect of a NH2 group at 4′-position has been
recently pointed out by Robinson and co-workers.11 The
enhanced activity of 2′,6′-dimethoxy derivatives indicates that
the conformation of the acyl substituent is an important
parameter for the binding to biological targets because di-ortho-
substitution drives by electrostatic repulsion the dihedral angle
between the A-ring and the carbonyl group to 90°. The issue
related to the conformation of chaclcones versus anticancer
activity has been adressed by Ducki et al.14,20
The hydroxylation at 2′ is generally undesirable (e.g., 41 vs
42 and 3 vs 37). It is conceivable that the negative effect of a
hydroxy group at 2′-position is due to a flat geometry induced
by the intramolecular hydrogen bond between the hydroxyl and
carbonyl groups. This observation is in contrast with the results
reported by Rao and co-workers,13 showing high cytotoxic 2′-
hydroxylated chalcones against Jurkat and U937 cancer cells.
In the case of dimethoxylated chalcones on the A-ring, it is
shown that the most suitable positions for methoxylation are
2′,4′ or 2′,6′ (derivatives 3 and 13 vs 52).
At the B-ring, it is clear that 2-, 4-, and 6-positions are the
most suitable positions for substitution (compounds 3, 6, 13,
39, 41, 52, 56). The substitution pattern can include two or three
methoxy groups at the above positions. For dimethoxylated
derivatives on the B-ring, the methoxy groups should preferably
be linked to carbons 2 and 6 (6 vs 22). However, the topological
requirements for methoxy substitution on the B-ring are less
demanding than those of the A-ring, suggesting that this phenyl
ring is not a strong pharmacophoric element for the pharma-
codynamic behavior of these compounds. Several attempts to
drive 2D or 3D quantitative relationships were performed using
a wide panel of recently developed in silico methods. Unfor-
tunately, no predictive model was obtained with regard to the
low internal predictive power. We believe that, to interfere with
the different phases of the cell cycle, the compounds have to
permeate the cell and the nucleus membranes. Variations of
molecular structure of examined chalcones influence differently
pharmacodynamics and permeation mechanisms, and these
complex mechanisms, quantified by cell growth inhibition
results, are presumably responsible for the lack of global QSAR
models.
Experimental Section
Chemistry. Melting points were measured on a Fisher mi-
cromelting point apparatus and are uncorrected. 1H and 13C NMR
spectra were recorded on Bruker Avance 400. Mass spectra were
obtained on a JEOL HX-110 spectrometer. Elemental analysis were
performed by the Analytical Department of CNRS, Vernaison,
France. Chemicals and reagents were obtained either from Aldrich
or Acros companies. PEG 300 (Lutrol E300) was kindly donated
by BASF (Germany).
Synthesis of Chalcones: Typical Procedure. To a stirred
solution of acetophenone (1 mmol) and a benzladehyde derivative
(1 mmol) in MeOH (10 mL) was added KOH (50% aqueous
solution, 1 mL). The solution was heated at 70 °C for 3-5 h, MeOH
was evaporated, and the residue was dissolved in CH2Cl2/H2O (50
mL, 4:1). The organic layer was washed with brine and evaporated.
After this, column chromatography was carried out over silica gel
(AcOEt/hexane 1:2). In the case of fluorinated chalcones, KOH
(25%) was used.
Formulation of 13 for Animal Experiments. Chalcone 13 was
dissolved in a mixture of 50/50 PEG 300/injectable water (% v/v).
The solution was magnetically stirred at ambient temperature in a
sealed container for 4 h. A volume of 25 mL of the formulated
solution was filtered using sterile 0.22 µm PVDF filtration devices
(Roth Sochiel, Germany) and introduced into 50 mL glass vials,
previously sterilized by autoclaving. The amount of dissolved 13
was assayed spectrophotometrically at 347 nm in absolute ethanol.
Solutions without 13 were similarly prepared as references.
Flow Cytometry Analysis of Cell Cycle. Cells were treated with
the test compound at 10 µM for 24 h. After drug exposure, 106
cells/mL were resuspended in 2 mL of propidium iodide solution
(50 µL/mL), incubated at 4 °C overnight, and then analyzed by
flow cytometry. The G2/M fraction of cells exposed to different
compounds was performed on a FACScalibur (Becton Dickinson,
San Jose, U.S.A.). Cell cycle distribution was calculated after
exclusion of cell doublets and aggregates on a FL2-area/FL2-width
dot plot using Modfit LT 2.0 software (Verity Software Inc.,
Topsham, U.S.A.).
MTT Cytotoxicity Assays. Cell viability was determined on
exponentially growing K562 cells using the MTT assay, as
previously described.21 This assay is based on the conversion by
metabolically active cells of 3-(4,5-dimethylthiazol-2-yl)-2,5-di-
phenyl tetrazolium bromide (MTT) into formazan crystals, which
are then dissolved in an isopropanol solution. Optical density is
measured by spectrometry. Briefly, asynchronously growing cells
were transferred into 96-well cultures plates (Costar, Corning Inc.,
NY) in 100 µL of medium, with a final cell concentration of 3 ×
103 cells/well and incubated in media for 24 h. Corresponding drug
concentrations were then added to each plate. After 72 h of drug
exposure (10 µM), 20 µL of MTT reagent (5 mg/ml) were added
