4718 Journal of Medicinal Chemistry, 2007, Vol. 50, No. 19
Kitagawa et al.
1
(1H, t, J ) 8.0 Hz), 7.10 (1H, br), 6.82 (1H, d, J ) 13.6 Hz), 6.10
(1H, d, J ) 7.6 Hz), 4.39 (1H, d, J ) 4.8 Hz), 4.16 (2H, s), 2.23
(3H, s). 13C NMR (DMSO-d6): δ 176.4, 160.2, 153.8, 145.6, 144.5,
139.3, 138.39, 138.39, 136.6, 135.0, 134.7, 132.1, 128.6, 128.3,
128.2, 127.1, 125.2, 124.8, 124.3, 114.5, 113.4, 99.7, 37.3, 27.4,
16.7. MS (FAB+): 669 (M + H). HRMS: calcd for C29H23-
BrCl2N6O2S (M + H) 669.0242, found 669.0230. LC-MS: method
72%). H NMR (CD3OD): δ 7.56 (1H, d, J ) 7.6 Hz), 7.52 (2H,
d, J ) 8.0 Hz), 7.28 (1H, brs), 7.22 (2H, d, J ) 8.0 Hz), 7.01 (2H,
d, J ) 7.8 Hz), 6.94 (1H, t, J ) 7.8 Hz), 6.72 (2H, s), 6.30 (1H,
d, J ) 7.6 Hz), 4.51 (2H, s), 4.27-4.23 (4H, m), 2.07 (2H, t, J )
5.2 Hz), 1.87 (3H, s). 13C NMR (CDCl3/CD3OD): δ 177.9, 156.1,
146.5, 145.4, 142.8, 140.5, 137.3, 136.8, 135.9, 134.6, 131.9, 129.3,
128.6, 127.7, 127.6, 125.3, 117.3, 116.3, 115.0, 55.4, 37.3, 36.8,
27.4, 15.9. MS (FAB+): 576 (M + H). HRMS: calcd for C29H27-
Cl2N7O2 (M + H) 576.1682, found 576.1688. LC-MS: method
A, tR ) 9.07 min, 669 (M + H), purity 98.2%; method B, tR
11.14 min, 669 (M + H), purity 97.9%.
)
A, tR ) 7.21 min, 576 (M + H), purity 100%; method B, tR
8.97 min, 576 (M + H), purity 100%.
)
(E)-1-((4-(4-(3-(3-(2,6-Dichlorobenzyl)-2-methyl-4-oxopyridin-
1(4H)-yl)prop-1-enyl)phenyl)-1H-imidazol-2-yl)methyl)-3-(5-
bromothiazol-2-yl)urea (30). The title compound was obtained
from N-(5-bromothiazol-2-yl)-1H-imidazole-1-carboxamide and (4-
(4-(2-(3-(2,6-dichlorobenzyl)-2-methyl-4-oxopyridin-1(4H)-yl)prop-
1-enyl)phenyl)-1H-imidazol-2-yl)methylamine hydrochloride ac-
cording to the similar procedure used to prepare 29 as a white
powder (17 mg, 41%). 1H NMR (CD3OD): δ 7.76 (1H, d, J ) 7.6
Hz), 7.63 (2H, d, J ) 8.4 Hz), 7.36-7.31 (5H, m), 7.25 (1H, s),
7.14 (1H, t, J ) 7.6 Hz), 6.41 (1H, d, J ) 7.6 Hz), 6.34 (1H, dt,
J ) 16 Hz, J ) 4.8 Hz), 6.18 (1H, d, J ) 16 Hz), 4.80-4.77 (2H,
m), 4.51 (2H, s), 4.04 (2H, s), 2.20 (3H, s). 13C NMR (CD3OD):
δ 179.6, 162.5, 156.1, 149.0, 147.5, 143.2, 139.1, 137.9, 136.9,
135.7, 132.9, 129.8, 129.3, 128.7, 127.9, 126.0, 124.4, 115.9, 102.1,
56.9, 38.3, 28.5, 16.5. MS (FAB+): 683 (M + H). HRMS: calcd
for C30H25BrCl2N6O2S (M + H) 683.0398, found 683.0388. Anal.
(C30H25BrCl2N6O2S‚2.46H2O) C, H, N.
1-((4-(4-(2-(3-(2,6-Dichlorobenzyl)-2-methyl-4-oxopyridin-
1(4H)-yl)ethyl)phenyl)-1H-imidazol-2-yl)methyl)-3-(5-(methyl-
sulfonyl)thiazol-2-yl)urea (34). The title compound was obtained
from N-(5-(methylsulfonyl)thiazol-2-yl)-1H-imidazole-1-carboxa-
mide and (4-(4-(2-(3-(2,6-dichlorobenzyl)-2-methyl-4-oxopyridin-
1(4H)-yl)ethyl)phenyl)-1H-imidazol-2-yl)methylamine hydrochlo-
ride (20) according to the similar procedure used to prepare 29 as
1
a white powder (4.3 mg, 50%). H NMR (CD3OD): δ 7.88 (1H,
s), 7.56 (1H, d, J ) 7.6 Hz), 7.52 (1H, d, J ) 8.0 Hz), 7.29 (1H,
s), 7.23 (2H, d, J ) 8.0 Hz), 7.01 (2H, d, J ) 8.2 Hz), 6.94 (1H,
t, J ) 8.2 Hz), 6.29 (1H, d, J ) 7.6 Hz), 4.55 (2H, s), 4.26-4.22
(4H, m), 3.21 (3H, s), 2.99 (2H, t, J ) 6.4 Hz), 1.86 (3H, s). 13C
NMR (DMSO-d6): δ 169.2, 164.8, 154.3, 153.0, 145.9, 144.6,
144.5, 137.3, 135.1, 134.3, 132.3, 129.9, 129.0, 128.8, 128.6, 125.9,
125.2, 124.6, 115.0, 111.2, 56.6, 45.8, 35.6, 35.1, 28.1, 16.4. MS
(ESI+): 671 (M + H). HRMS: calcd for C30H28Cl2N6O4S2 (M +
H) 671.1069, found 671.1072. Anal. (C30H28Cl2N6O4S2) C, H, N.
1-((4-(4-(3-(3-(2,6-Dichlorobenzyl)-2-methyl-4-oxopyridin-
1(4H)-yl)propyl)phenyl)-1H-imidazol-2-yl)methyl)-3-(5-bromothi-
azol-2-yl)urea (31). The title compound was obtained from N-(5-
bromothiazol-2-yl)-1H-imidazole-1-carboxamide and (4-(4-(2-(3-
(2,6-dichlorobenzyl)-2-methyl-4-oxopyridin-1(4H)-yl)propyl)phenyl)-
1H-imidazol-2-yl)methylamine hydrochloride according to the
similar procedure used to prepare 29 as a white powder (19 mg,
Biology. Preparation of His-Tagged FabI. The fabI gene from
E. coli DH5R was amplified by PCR and cloned into pBAD/Myc-
His B vector (Invitrogen). The resulting plasmid was transformed
into E. coli TOP10. The expression of FabI protein fused with a
His-tag was induced with 0.2% arabinose. The cell pellets were
resuspended in lysis buffer (5 mM Tris-HCl, pH 8.0, 0.3 M NaCl,
containing 1 mg/mL of lysozyme) and lysed by sonication. Cell
lysates were applied to a Ni-NTA agarose column (QIAGEN) and
eluted with 250 mM imidazole. The solvent was exchanged to 20
mM Tris-HCl, pH 7.5, 10 mM EDTA, pH 8.0, 1 mM DTT by
dialysis, and the purified protein was stored at -80 °C until use.
Preparation of S. pneumoniae FabK. The fabK genes were
amplified by PCR from S. pneumoniae R6 and cloned into pET-
21b(+) expression vector (Novagen). The resulting plasmid was
transformed into E. coli BL21(DE3). The expression of FabK
protein fused with His-tag at C-terminal was induced by 1 mM
isopropyl â-D-thiogalactoside, and the cells cultivated in LB broth
were grown for a further 4 h before collecting by centrifugation.
Purification of the His-tagged FabK protein was performed as
above. Purified proteins were exchanged into 0.1 M sodium
phosphate buffer, pH 7.0, by dialysis and stored at -80 °C until
use.
Enzyme Inhibition Assay. Enzymatic activity of FabI and FabK
was measured as the reduction of NADH and monitored by the
change in absorbance at 340 nm. Assays were performed in 96-
half-area plates in a final assay volume of 100 µL. For FabI
inhibition assay, the reaction mixture consisted of 100 mM sodium
phosphate (pH 7.4), 0.25 mM crotonoyl-CoA, 0.4 mM NADH, and
50 µg/mL of His-tagged E. coli FabI. For FabK inhibition assay,
the reaction was performed in 100 mM 2-(N-morpholino)ethane-
sulfonic acid (pH 7.0), 100 mM NH4Cl, 0.2 mM crotonoyl-CoA,
0.4 mM NADH, and 2 µg/mL of purified FabK. The reaction was
initiated by addition of the enzyme and measured by absorption at
340 nm for 10 min at room temperature. Concentration giving 50%
reduction in the enzymatic activity was determined as IC50.
1
41%). H NMR (CD3OD): δ 7.90 (1H, s), 7.69 (1H, d, J ) 7.6
Hz), 7.59 (2H, d, J ) 8.4 Hz), 7.33-7.29 (3H, m), 7.25 (1H, s),
7.19-7.15 (3H, m), 6.35 (2H, d, J ) 7.6 Hz), 4.51 (2H, s), 4.32
(2H, s), 3.99 (2H, t, J ) 7.2 Hz), 2.62 (2H, t, J ) 7.2 Hz), 2.08
(3H, s), 2.05-1.97 (2H, m). 13C NMR (CD3OD): δ 179.2, 162.5,
156.0, 148.5, 147.2, 142.8, 140.5, 139.1, 137.8, 136.9, 129.8, 129.7,
129.3, 128.5, 126.1, 115.7, 102.1, 54.7, 38.3, 33.1, 32.9, 28.5, 16.3.
MS (FAB+): 685 (M + H). HRMS: calcd for C30H27BrCl2N6O2S
(M + H) 685.0555, found 685.0556. LC-MS: method A, tR
)
8.72 min, 685 (M + H), purity 100%; method B, tR ) 10.81 min,
685 (M + H), purity 99.7%.
1-((4-(4-(2-(3-(2,6-Dichlorobenzyl)-2-methyl-4-oxopyridin-
1(4H)-yl)ethyl)phenyl)-1H-imidazol-2-yl)methyl)-3-(5-(pyridin-
2-ylthio)thiazol-2-yl)urea (32). The title compound was obtained
from N-(5-(pyridin-2-ylthio)thiazol-2-yl)-1H-imidazole-1-carboxa-
mide and (4-(4-(2-(3-(2,6-dichlorobenzyl)-2-methyl-4-oxopyridin-
1(4H)-yl)ethyl)phenyl)-1H-imidazol-2-yl)methylamine hydrochlo-
ride (20) according to the similar procedure used to prepare 29 as
an off-white powder (13.4 mg, 37%). 1H NMR (CD3OD): δ 8.34-
8.32 (1H, m), 7.64 (1H, ddd, J ) 8.0 Hz, J ) 8.0 Hz, J ) 2.0 Hz),
7.58 (1H, d, J ) 7.4 Hz), 7.55 (1H, s), 7.28 (1H, s), 7.21 (2H, d,
J ) 8.0 Hz), 7.05-6.99 (3H, m), 6.91 (1H, t, J ) 8.0 Hz), 6.31
(1H, d, J ) 7.4 Hz), 4.53 (2H, s), 4.26-4.22 (4H, m), 2.99 (2H, d,
J ) 6.4 Hz), 1.83 (3H, s). 13C NMR (DMSO-d6): δ 175.6, 164.3,
160.0, 153.6, 149.3, 146.8, 145.0, 144.9, 140.9, 139.4, 137.6, 136.7,
134.81, 134.77, 133.0, 129.0, 128.4, 127.9, 125.5, 124.1, 120.6,
119.6, 113.7, 112.9, 112.5, 53.9, 37.2, 35.9, 27.3, 15.3. MS
(FAB+): 702 (M + H). HRMS: calcd for C34H29Cl2N7O2S2 (M
+ H) 702.1279, found 702.1281. LC-MS: method A, tR ) 8.27
min, 702 (M + H), purity 99.6%; method B, tR ) 10.18 min, 702
(M + H), purity 99.7%.
1-((4-(4-(2-(3-(2,6-Dichlorobenzyl)-2-methyl-4-oxopyridin-
1(4H)-yl)ethyl)phenyl)-1H-imidazol-2-yl)methyl)-3-(1H-imida-
zol-2-yl)urea (33). The title compound was obtained from N-(1H-
imidazol-2-y)-1H-imidazole-1-carboxamide and (4-(4-(2-(3-(2,6-
dichlorobenzyl)-2-methyl-4-oxopyridin-1(4H)-yl)ethyl)phenyl)-1H-
imidazol-2-yl)methylamine hydrochloride (20) according to the
similar procedure used to prepare 29 as a white powder (3.6 mg,
MIC Testing. Antibacterial activity was determined by the broth
microdilution method according to the NCCLS document M7-A6.
The minimum inhibitory concentration (MIC) was determined as
the lowest concentration of the test compound that prevented visible
growth. S. aureus ATCC29213, S. pneumoniae KU197 (PRSP), S.
pneumoniae KU197 (A141S) (PRSP, fabk mutant),42 H. influenzae
Rd, H. influenzae Rd∆acrB (efflux mutant), H. influenzae PRC44,
