W. Bi et al. / Bioorg. Med. Chem. 15 (2007) 6909–6919
6915
(C-9a), 138.78 (C-8a), 149.73, 158.84, 160.24 (Ph),
171.06 (COOH); RP-HPLC-ESI-MS (tR = 15.95 min)
(M+H)+ 369, (M+H-73) 296. trans-1: 1H NMR
(CD3OD + TFA) d 4.72 (m, 1H, H-3), 6.22 (s, 1H, H-
1); 13C NMR (CD3OD + TFA) d 53.60 (C-3), 57.37
(C-1); other signals as cis-1: RP-HPLC-ESI-MS
(tR = 16.8 min) (M+H)+ 369, (M+H-73) 296.
(d), 120.5 (d), 77.7 (s), 65.8 (t), 47.1 (d), 38.4 (t),
28.6 (q), 28.2 (t). Anal. Calcd for C23H29N3O4
(411.22): C, 67.12; H, 7.11; N, 10.22. Found: C,
67.22; H, 7.19; N, 10.24.
4.1.1.5. Fmoc-Aza-b3-Orn(NBoc)-OBn (6a). A mix-
ture of Fmoc-protected ornithine hydrazine (5) (3.7 g,
9 mmol), benzyl 2-bromoacetate (2.66 g, 11.6 mmol),
toluene (20 mL), and dry K2CO3 (870 mg, 0.7 equiv)
was refluxed under stirring for 28 h. After the workup
followed by flash column chromatography (EtOAc/hex-
ane, 1:3), 3.02 g (60%) of the title compound was ob-
tained as a colorless oil that slowly crystallized in
ether: mp 107 ꢂC; 1H NMR (CDCl3) d 1.50 (s, 9H,
CH3), 1.62 (m, 2H, CH2), 2.97 (m, 2H, CH2), 3.24 (m,
2H, CH2), 3.75 (m, 2H, CH2), 4.20 (t, 1H, J = 6.9 Hz,
CH), 4.50 (d, 2H, J = 6.9 Hz, CH2), 5.19 (s, 2H, CH2),
6.88 (br s, 1H, NH), 7.25–7.90 (m, 13H, Ar). 13C
NMR (DMSO) d 171.23 (s), 156.55 (s), 155.50 (s),
144.13, 141.77 (s), 135.54 C (s), 129.13, 129.04, 128.84
(d), 128.14, 127.47, 125.44, 120.40 (d), 79.38 (s), 67.09
(t), 64.47 (t), 57.63 (t), 54.56 (t), 47.67 (d), 38.83 (t),
28.85 (q), 27.83 (t). Anal. Calcd for C32H37N3O6
(559.27): C, 68.66; H, 6.67; N, 7.51. Found: C, 68.59;
H, 6.86; N, 7.28.
4.1.1.2. 1-Boc-amino-3,3-diethoxypropane (2). A mix-
ture of Boc2O (9 g, 40 mmol) in dioxane (40 mL) was
added dropwise to a stirred solution of 1-amino-3,3-
diethoxypropane (5.52 g, 37 mmol) and Et3N (4.04 g,
40 mmol) in dioxane (5 mL) at 0 ꢂC. After 2 h, the mix-
ture was allowed to warm to rt. Stirring was continued
overnight, and the solvent was evaporated. The residual
oil was taken up in water (10 mL), and the mixture was
acidified with an aqueous solution of 1 N HCl (pH 3–4)
and extracted with EtOAc (60 mL · 3). The organic
layer was dried (Na2SO4) and evaporated to give a crude
oil of 1-Boc-amino-3,3-diethoxypropane 8.89 g (90%)
suitable for further work without further purification.
1H NMR (CDCl3) d 1.25 (t, 6H, J = 8.8 Hz, CH3),
1.48 (s, 9H, CH3), 1.85 (q, 2H, J = 6.3 Hz, CH2), 3.26
(q, 2H, J = 6.1 Hz, CH2), 3.22–3.77 (m, 6H, CH2),
4.58 (t, 1H, J = 6.3 Hz, CH), 4.95 (br s, 1H, NH).
4.1.1.3. 3-Boc-aminopropanal (3). A solution of 1-
Boc-amino-3,3-diethoxypropane (8.89 g, 36 mmol) in
AcOH (15 mL) and H2O (4 mL) was stirred at rt for
10 h, neutralized with Na2CO3, taken up in ether, and
washed with brine. The organic phase was evaporated
under vacuum to give a yellow oil used as such in the
next step (6.31 g, 98%). 1H NMR (CDCl3) d l.47 (s,
9H, CH3), 2.75 (t, 2H, CH2), 3.46 (m, 2H, CH2), 4.95
(br s, 1H, NH), 9.85 (s, 1H, CHO).
4.1.1.6. Fmoc-Aza-b3-Arg(Boc)2OBn (7). To a solu-
tion of 6a (1 g, 1.79 mmol) in CH2Cl2 (5 mL), 5 mL of
TFA was added. After stirring at rt overnight, 25 mL
of CH2Cl2 and 10 mL of water were added. The mixture
was neutralized with solid Na2CO3 (pH 8–9), and the or-
ganic layer was washed with brine and dried over
Na2SO4. After concentration, without further purifica-
tion, the crude product 6b was directly subjected to
the next step. 6b was diluted with 10–15 mL of CH2Cl2,
and then NEt3 (1.1 equiv, 251 L) and (BocNH)2C = NTf
(0.9 equiv, 0.64 g) were added. After stirring at rt for
15 h, the solution was sequentially washed with a 2 N
aqueous solution of NaHSO4 (10 mL), Na2CO3
(10 mL), and brine (10 mL). The organic layer was dried
over Na2SO4. After concentration, the crude product
was further purified by flash chromatography (hexane/
EtOAc, 7:3) to afford the title compound 7 (1.00 g,
80%). 1H NMR (CDCl3) d 1.39 (s, 18H, CH3), 1.60
(m, 2H, CH2), 2.80 (m, 2H, CH2), 3.32 (m, 2H, CH2),
3.66 (m, 2H, CH2), 4.24 (t, 1H, J = 7.1 Hz, CH), 4.45
(d, 2H, J = 7.1 Hz, CH2), 5.05 (s, 2H, CH2), 6.95 (br s,
1H, NH), 7.27–7.82 (m, 13H, Ar), 8.28 (br s, 1H,
NH), 11.45 (br s, 1H, NH). 13C NMR (DMSO) d
171.45 (s), 170.80 (s), 163.97 (s), 156.57 (s), 153.59 (s),
144.17 (s), 141.73 (s), 135.67 (d), 129.06, 128.91,
128.78 (d), 128.09, 127.45, 125.47, 120.34 (d), 83.35 (s),
79.48 (s), 66.93 (t), 60.74 (t), 58.04 (t), 53.89 (t), 47.64
(d), 38.83 (t), 28.67 (q), 28.44 (q), 27.45 (t). Anal. Calcd
for C38H47N5O8 (701.34): C, 65.02; H, 6.75; N, 9.98.
Found: C, 65.10; H, 6.83; N, 9.98.
4.1.1.4. Fmoc-protected ornithine hydrazine (5). Fmoc
carbazate (9.24 g, 36.4 mmol) was added to a stirred
solution of 3-Boc-aminopropanal (6.31 g, 36.4 mmol)
in CH2Cl2 (150 mL) at rt The reaction mixture was stir-
red for 12 h and concentrated under vacuum to give a
crude solid that was triturated with petroleum ether to
afford the hydrazone (4) as a white solid (13.2 g, 89%).
1H NMR (CDCl3) d 1.38 (s, 9H, CH3), 2.31 (m, 2H,
CH2), 3.11 (m, 2H, CH2), 4.28 (t, 1H, J = 6.8 Hz,
CH), 4.41 (d, 2 H, J = 6.8 Hz, CH2), 6.91 (br, 1H,
NH), 7.28–7.93 (m, 9H, Ar + CH), 10.84 (s, 1H, NH).
13C NMR (DMSO) d 155.5 (s), 153.2 (s), 146.2 (s),
143.7 (s), 140.72 (s), 127.6 (d), 127.0 (d), 125.1 (d),
120.1 (d), 77.5 (s), 65.4 (t), 46.6 (d), 37.3 (t), 28.8 (t),
28.2 (q).
Fmoc-protected hydrazone (4) (3 g, 7.31 mmol) was
then reduced with sodium cyanoborohydride (0.55 g,
1.2 equiv). The crude solid was triturated with petro-
leum ether to afford a white solid of 5 (2.48 g 82%):
mp 101 ꢂC; 1H NMR (CDCl3) d 1.40 (s, 9H, CH3),
1.50 (m, 2H, CH2), 2.68 (m, 2H, CH2), 2.98 (m,
2H, CH2), 4.24 (t, 1H, J = 6.9 Hz, CH), 4.32 (d,
2H, J = 6.9 Hz, CH2), 4.70–4.85 (br s, 1H, NH),
6.78 (br s, 1H, NH), 6.80 (br s, 1H, NH), 7.25–7.90
(m, 8H, Ar). 13C NMR (DMSO) d 157.2 (s), 155.9
(s), 144.2 (s), 142.9 (s), 128.0 (d), 127.6 (d), 125.6
4.1.1.7. Fmoc-Aza-b3-Arg(Boc)2-OH (8). Catalytic
hydrogenolysis with 10% Pd/C (50 mg) of 7 (0.86 g,
0.5 mmol) afforded 0.72 g (96%) of the title compound
1
8 as a colorless oil. H NMR (CDCl3) d 1.38 (s, 9H,
CH3), 1.39 (s, 9H, CH3), 1.62 (m, 2H, CH2), 2.89 (m,
2H, CH2), 3.38 (m, 2H, CH2), 3.60 (m, 2H, CH2), 4.14
