Tuning Photophysical and Electrochemical Properties of Cationic
Iridium(III) Complex Salts with Imidazolyl Substituents by Proton
and Anions
Qiang Zhao,† Shujuan Liu,‡ Mei Shi,† Fuyou Li,*,† Hao Jing,† Tao Yi,† and
Chunhui Huang*,†
Department of Chemistry and Laboratory of AdVanced Materials, Fudan UniVersity, Shanghai, 200433,
People’s Republic of China, and Institute of AdVanced Materials (IAM), Nanjing UniVersity of Posts and
Telecommunications, 66 XinMoFan Road, Nanjing 210003, People’s Republic of China
ReceiVed June 22, 2007
A series of cationic iridium(III) complex salts, 1-5, were synthesized containing different phenanthroline
derivatives. Their photophysical and electrochemical properties were investigated. The influences of anions
and proton on the photophysical and electrochemical properties were also studied in detail. Upon addition
of CF3COOH, the emission wavelength was significantly red-shifted and the emission color changed
-
from yellow to red. In addition, the addition of F-, CH3COO-, and H2PO4 can also cause significant
-
variations in UV-vis absorption and emission spectra. Upon addition of F-, CH3COO-, and H2PO4 ,
the solution colors of 1-3 changed from yellow-green to brown and the emission of 1-3 was quenched
completely, which can be observed by the naked eye.
oxygen concentration,8 and metal ions.5c However, as the best
phosphorescent dyes,9 the applications of iridium(III) complexes
in chemosensors were mainly limited to recognizing oxygen10
and the Hg2+ cation.11
Introduction
Phosphorescent heavy-metal complexes have been explored
for a multitude of photonic applications including organic light-
emitting diodes,1 photovoltaic cells,2 biological labeling re-
agents,3 and hydrogen production via photoreduction of water.4
Recently, phosphorescent heavy-metal complexes have also
attracted considerable interest as sensors,5 because of their
significant Stokes shifts for easy separation of excitation and
emission and relatively long lifetimes compared with purely
organic luminophores.6 Many phosphorescent heavy-metal
complexes, such as platinum(II), rhenium(I), and ruthenium-
(II) complexes, have been explored as chemosensors for anions,7
On the other hand, anion recognition and sensing have been
of most interest in recent years because of their important roles
in biological processes and environmental assays.12 Various
types of pure organic dyes have been used as receptors for
anionic species.12,13 Up to now, only one example of iridium-
(III) complex salts has been reported to recognize chloride
anions with low sensitivity (Ksv-1 ) 34 mmol L-1).14
In our previous report, the imidazolyl group of imidazo[4,5-
f][1,10]phenanthroline can interact with a proton, and the
NH group can also be deprotonated by addition of a strong
alkali.15 Sensitivity to proton and alkali might be expected for
iridium(III) complexes incorporating an imidazo[4,5-f][1,10]-
phenanthroline unit. Herein, three cationic iridium(III) complex
* To whom correspondence should be addressed. Fax: 86-21-55664621.
Tel: 86-21-55664185. E-mail: fyli@fudan.edu.cn (F.Y.L.); chhuang@
pku.edu.cn (C.H.H.).
† Fudan University.
‡ Nanjing University of Posts and Telecommunications.
(1) (a) Tsuboyama, A.; Iwawaki, H.; Fururori, M.; Mukaide, T.;
Kamatani, J.; Igawa, S.; Moriyama, T.; Miura, S.; Takiguchi, T.; Okada,
S.; Hoshino, M.; Ueno, K. J. Am. Chem. Soc. 2003, 125, 12971-12979.
(b) Adachi, C.; Baldo, M. A.; Thompson, M. E.; Forrest, S. R. J. Appl.
Phys. 2001, 90, 5048-5051.
(2) (a) Wong, H. L.; Lam, L. S. M.; Cheng, K. W.; Man, K. Y. K.;
Chan, W. K.; Kwong, C. Y.; Djurisˇic´, A. B. Appl. Phys. Lett. 2004, 84,
2557-2559. (b) Hara, K.; Nishikawa, T.; Kurashige, M.; Kawauchi, H.;
Kashima, T.; Sayama, K.; Aika, K.; Arakawa, H. Solar Energy Mater. Solar
Cells 2005, 85, 21-30.
(3) Lo, K. K. W.; Ng, D. C. M.; Chung, C. K. Organometallics 2001,
20, 4999-5001.
(4) (a) Goldsmith, J. I.; Hudson, W. R.; Lowry, M. S.; Anderson, T. H.;
Bernhard, S. J. Am. Chem. Soc. 2005, 127, 7502-7510. (b) Kirch, M.;
Lehn, J. M.; Sauvage, J. P. HelV. Chim. Acta 1979, 62, 1345-1384. (c)
Krishnan, C. V.; Brunschwig, B. S.; Creutz, C.; Sutin, N. J. Am. Chem.
Soc. 1985, 107, 2005-2015.
(5) (a) de Silva, A. P.; Gunaratne, H. Q. N.; Gunnlaugsson, T.; Huxley,
A. J. M.; McCoy, C. P.; Rademacher, J. T.; Rice, T. E. Chem. ReV. 1997,
97, 1515-1566. (b) Demas, J. N.; DeGraff, B. A. Coord. Chem. ReV. 2001,
211, 317-351. (c) Tang, W. S.; Lu, X. X.; Wong, K. M. C.; Yam, V. W.
W. J. Mater. Chem. 2005, 15, 2714-2720.
salts [Ir(ppy)2(N∧N)]+PF6 (1-3) (see Chart 1) based on
-
different phenanthroline derivatives (N∧N ligands) were syn-
thesized, and the tuning of the photophysical and electrochemical
(8) Brinas, R. P.; Troxler, T.; Hochstrasser, R. M.; Vinogradov, S. A. J.
Am. Chem. Soc. 2005, 127, 11851-11862.
(9) (a) Neve, F.; Deda, M. L.; Crispini, A.; Bellusci, A.; Puntoriero, F.;
Campagna, S. Organometallics 2004, 23, 5856-5863. (b) Liu, S. J.; Zhao,
Q.; Chen, R. F.; Deng, Y.; Fan, Q. L.; Li, F. Y.; Wang, L. H.; Huang, C.
H.; Huang, W. Chem.-Eur. J. 2006, 12, 4351-4361. (c) Didier, P.;
Ortmans, L.; Kirsch-De Mesmaeker, A.; Watte, R. Inorg. Chem. 1993, 32,
5239-5245. (d) Zhao, Q.; Liu, S. J.; Shi, M.; Wang, C. M.; Yu, M. X.; Li,
L.; Li, F. Y.; Yi, T.; Huang, C. H. Inorg. Chem. 2006, 45, 6152-6160.
(10) (a) Gao, R.; Ho, D. G.; Hernandez, B.; Selke, M.; Murphy, D.;
Djurovich, P. I.; Thompson, M. E. J. Am. Chem. Soc. 2002, 124, 14828-
14829. (b) Huynh, L.; Wang, Z.; Yang, J.; Stoeva, V.; Lough, A.; Manners,
I.; Winnik, M. A. Chem. Mater. 2005, 17, 4765-4773. (c) Di Marco, G.;
Lanza, M.; Mamo, A.; Stefio, I.; Di Pietro, C.; Romeo, G.; Campagna, S.
Anal. Chem. 1998, 70, 5019-5023.
(11) Zhao, Q,; Cao, T.Y.; Li, F. Y,; Li, X.H.; Jing, H.; Yi, T.; Huang C.
H. Organometallics 2007, 26, 2077-2081.
(12) (a) Beer, P. D.; Gale, P. A. Angew. Chem., Int. Ed. 2001, 40, 486-
516. (b) Coord. Chem. ReV. 2003, 240, issues 1 and 2 (Special Issues on
anion receptors). (c) Mart´ınez-Ma´n˜ez, R.; Sanceno´n, F. Chem. ReV. 2003,
103, 4419-4476. (d) Suksai, C.; Tuntulani, T. Chem. Soc. ReV. 2003, 32,
192-202.
(6) Carraway, E. R.; Demas, J. N.; DeGraff, B. A.; Bacon, J. R. Anal.
Chem. 1991, 63, 337-342.
(7) Lin, Z. H.; Zhao, Y. G.; Duan, C. Y.; Zhang, B. G.; Bai, Z. P. Dalton
Trans. 2006, 3678-3684.
10.1021/om700623j CCC: $37.00 © 2007 American Chemical Society
Publication on Web 10/24/2007

Cationic Iridium(III) Complex Salts
Organometallics, Vol. 26, No. 24, 2007 5923
Chart 1. Chemical Structures of the Complex Salts 1-5
further purification. 2-Phenylpyridine and N-ethyl-3-carbazolecar-
boxaldehyde were obtained from Acros and used without further
purification.
Synthesis of the Phenanthroline Derivatives. The phenanthro-
line derivatives were synthesized according to a previous report.16
Synthesis of the Iridium(III) Complex Salts. All iridium(III)
-
complex salts [Ir(ppy)2(N∧N)]+PF6 were prepared by the same
procedure. Herein, only the synthesis of complex salt [Ir(ppy)2-
-
(phen)]+PF6 (1) is described in detail.
Complex Salt 1. The cyclometalated iridium(III) chlorobridged
dimer [Ir(ppy)2Cl]2 was prepared according to literature methods.17
A solution of [Ir(ppy)2Cl]2 (0.079 mmol) and 2-phenylimidazo-
[4,5-f][1,10]phenanthroline (0.158 mmol) in CH2Cl2-MeOH
(30 mL, 2:1 v/v) was heated to reflux. After 4 h, the yellow solution
was cooled to room temperature, and then a 10-fold excess of
potassium hexafluorophosphate was added. The suspension was
stirred for 2 h and then was filtered to remove insoluble inorganic
salts. The solution was evaporated to dryness under reduced
pressure. The crude product was applied to a silica gel column and
eluted with CH2Cl2-acetone (15:1) to afford a yellow solid in 63%
yield. 1H NMR (400 MHz, d6-DMSO), δ(ppm): 9.15 (d, 2H, J )
8.0), 8.26 (t, 4H, J ) 8.0), 8.15 (d, 2H, J ) 4.0), 8.03-8.07 (m,
2H), 7.95 (d, 2H, J ) 7.6), 7.86 (t, 2H, J ) 7.6), 7.63 (t, 2H, J )
7.2), 7.56 (t, 1H, J ) 7.2), 7.51 (d, 2H, J ) 5.6), 7.05 (d, 2H, J )
7.2), 6.92-6.99 (m, 4H), 6.30 (d, 2H, J ) 7.2). 13C NMR
(100 MHz, d6-DMSO), δ(ppm): 167.5, 153.4, 151.0, 149.8, 149.1,
144.8, 144.7, 139.3, 132.9, 131.9, 130.9, 129.9, 127.7, 127.2, 125.7,
124.5, 123.1, 120.6. Anal. Calcd for IrC41H28N6F6P: C, 52.28; H,
3.00; N, 8.92. Found: C, 52.42; H, 3.32; N, 8.67. MS(LDI-TOF):
m/e 797.3 (M - PF6).
properties of 1-3 by anions and proton was investigated. For
comparison, two other cationic iridium(III) complex salts,
[Ir(ppy)2(L2)]+PF6 (4) and [Ir(ppy)2(L3)]+PF6 (5), without
the N-H group were also studied.
-
-
