Scientific Programming 10 (2002) 91–100
IOS Press
91
Mobile objects in Java
Luc Moreaua and Daniel Ribbensb
aElectronics and Computer Science, University of Southampton, SO17 1BJ Southampton, UK
Tel.: + 44 23 8059 4487; Fax: + 44 23 8059 2865; E-mail: L.Moreau@ecs.soton.ac.uk
bService d’Informatique, University of Lie`ge, 4000 Lie`ge, Belgium
Tel.: +32 4366 2640; Fax: +32 4366 2984; E-mail: ribbens@montefiore.ulg.ac.be
Abstract: Mobile Objects in Java provides support for object mobility in Java. Similarly to the RMI technique, a notion of
client-side stub, called startpoint, is used to communicate transparently with a server-side stub, called endpoint. Objects and
associated endpoints are allowed to migrate. Our approach takes care of routing method calls using an algorithm that we studied
in [22]. The purpose of this paper is to present and evaluate the implementation of this algorithm in Java. In particular, two
different strategies for routing method invocations are investigated, namely call forwarding and referrals. The result of our
experimentation shows that the latter can be more efficient by up to 19%.
1. Introduction
Successive paradigms such as remote procedure calls
(RPC) [3], method invocation in Network Objects [4]
and remote method invocation (RMI) in Java [12],
amongst others, abstract away from the reality of dis-
tribution. They successively provided programmers
with new and more sophisticated abstractions. RPC
provides homogeneity, by its marshalling and unmar-
shalling of data structures using data representation
suitable for heterogeneousplatforms. Network Objects
offers memory uniformity because remote method in-
vocations are syntactically identical to local ones and
garbage collection takes care of local and distributed
objects. Java RMI provides code propagation because
the programmer no longer needs to replicate code to
remote machines, but instead Java RMI is able to load
code dynamically.
The next logical step is to hide the location and
movement of objects. A similar approach has also been
adopted by the network community, which devised the
next generation of the IP protocol (IPv6) with support
for mobile addresses [14].
There exists an incremental approach to introduce
mobility into an infrastructurethat is unaware of mobil-
ity [7,16]. It consists of associating each mobile entity
with a stationary home agent, which acts as an inter-
mediary for all communications. While this approach
preserves compatibility with an existing infrastructure,
introducing an indirection to a home agent for every
Over the last few years, mobile agents have emerged
as a powerful paradigm to structure complex distributed
applications. Intuitively, a mobile agent can be seen
as a running software that may decide to suspend its
executionon a host and transfer its state to another host,
where it can resume its activity. Cardelli [5] argues
that mobile agents are the right abstraction to develop
applications distributed across “network barriers”, e.g.
in the presence of firewalls or when connectivity is in-
termittent. In Telescript [17], software migration is
presented as an alternative to communications over a
wide-area network, in which clients move to servers to
perform computations. Lange [16] sees mobile agents
as an evolution of the client-server paradigm, and enu-
merates several reasons for using software mobility.
It is a challenge to design and implement mobile
agent applications because numerous problems such
as security, resource discovery and communications,
need to be addressed. Therefore, we introduce Mobile
Objects in Java, a middleware that helps implement
mobile agent systems by providing a concept of mobile
object. Its specific contribution is a communication
mechanism consisting of the invocation of methods on
objects that may be mobile.
Our motivation has been driven by developments in
distributed computing over the last couple of decades.
ISSN 1058-9244/02/$8.00 2002 – IOS Press. All rights reserved

92
L. Moreau and D. Ribbens / Mobile objects in Java
communicationputs a burden on the infrastructure; this
may hamper the scalability of the approach, in particu-
lar, in massively distributed systems, such as the amor-
phous computer [27] or the ubiquitous/pervasive com-
puting environment [1]. Free from any compatibility
constraint, we adopted an algorithm to route messages
to mobile agents that does not require any static loca-
tion: the theoretical definition of this algorithm based
on forwarding pointers and the proof of its correctness
have been investigated in a previous publication [22].
The purpose of this paper is to present Mobile Ob-
jects in Java, an implementation of the algorithm,
which offers transparent method invocation and dis-
tributed garbage collection for mobile objects. By
transparent, we mean that mobile and non-mobile ob-
jects present a same interface, which is independent of
the object location and its migratory status. Distributed
garbage collection ensures that an object, whether mo-
bile or not, can be reclaimed once it is no longer ref-
erenced. While implementing our algorithm, it be-
came clear that two strategies could be adopted, which
we named call forwarding and referrals; we present
these strategies and evaluate their performance through
a benchmark.
extend a Web-based client-server architecture with mo-
bile agents that perform tasks on behalf of users and that
are able to migrate to a predefined itinerary of hosts.
After being dispatched,agents migrate securely,with
data, code and state to an itinerary of servers that may
have relevant data and services. Agents become inde-
pendent of the user who created them: they can survive
intermittent or unreliable network connections. Mobile
agents are beneficial for several reasons.
(i) They avoid the delivery of large volume of sci-
entific data required for data mining of images;
(ii) They help maintain confidentiality and own-
ership of data, by being run through security
checks, ensuring that they have the rights to
access the data;
(iii) They are allowed specific queries on the li-
brary according to the “securitylevel” theywere
granted.
This paper is organised as follows. First, we provide
more motivation for mobile agents by presenting two
promising application domains in Section 2. Then, in
Section 3, we summarise the algorithm we have inves-
tigated in [22]. In Section 4, we describe its imple-
mentation in Java, providing a transparent interface to
mobile objects. We then discuss two different methods
for routingmethod invocations, namely forwardingand
referrals, in Section 5. In order to compare these tech-
niques, we devise a synthetic benchmark, and analyse
results in Section 6. Finally, we compare our approach
with related work in Section 7.
Fig. 1. Architecture.
Mobile users
The context of the Magnitude project [24] is the
“ubiquitous computing environment” [27] where em-
bedded devices and artifacts abound in buildings and
homes, and have the ability to sense and interact with
devices carried by peoplein their vicinity. Applications
running on mobile devices interact with the infrastruc-
ture, and find and exploit services to fulfill the user’s
needs.
However, communications between mobile devices
and the infrastructure have somelimitations,in the form
of intermittent connectivity and low bandwidth. Fur-
thermore, processing power and memory capacity of
compact mobile devices remain relatively small. As
a result, such an environment would prevent the large
scale deployment of advanced services that are com-
munication and computation intensive.
2. Motivation
In this Section, we provide further motivation for
mobile agents. We describe two promising applications
where mobile agents act semi-autonomously on behalf
of users. The reasons for doing so, however, differ
substantially in the two applications.
Digital library
Yan and Rana [30] present a high-level service for
a digital library of radar images of the Earth. The li-
brary is composed of a set of confidential images and
associated annotations with attached ownership. They
We adopt mobile agents as proxies for mobiles users.
As illustrated by Fig. 1, we utilise mobile agents, as

L. Moreau and D. Ribbens / Mobile objects in Java
93
semi-autonomousentities, which can migrate from mo-
bile devices to infrastructure locations to take advan-
tage of the resources their specific tasks require; mobile
agents perform their tasks on the infrastructure, possi-
bly involving further migration, and then return results
back to mobile users.
aimed at the object; as soon as the acknowledgement
arrives, delayed messages may be forwarded.
Timestamps are used to guarantee that sites always
update their knowledgeabout mobile objects with more
recent information than the one they currently have.
If a site receives information with a timestamp that is
smaller than the timestamp in its table, the received
information is discarded. Such a timestamp mechanism
is mandatory to avoid cyclic routing of messages [22].
In the algorithm described so far, a mobile object
leaves a trail of forwarding pointers during its migra-
tion. In order to reduce the length of the chain of for-
warding pointers, routing information and associated
timestamp may be propagated by any site to any site;
timestamps are again used to guarantee that the most
recent information is stored in routing tables. In the
rest of the paper, we discuss an implementation of this
abstract algorithm.
Summary
Both scenarios use the idea of mobile agent, as a
semi-autonomous proxy for a user. If granted the right
to do so, mobile agents may migrate to new locations,
where they can take advantage of local resources.
3. Message routing algorithm
In this section, we summarise the message routing
algorithm for mobile agents that we formalised in [22].
We consider a set of mobile objects and a set of sites (in
our case JVMs) taking part into a computation. Each
mobile object is associated with a timestamp, which is
a counter incremented every time the object changes
location. Each site keeps a record of the location where
every mobile object known to the site is thought to
be, and of the timestamp the object had at the time.
Therefore, in a system composed of several sites, sites
may have different information about a same mobile
object (depending on how fast location information is
propagated between sites).
The algorithm proceeds as follows. When a mobile
object decides to migrate from a site A to another site
B, it informs A of its intention of migrating; a trans-
portation service is used to transport the object to B.
When the mobile object arrives at B, its safe arrival
is acknowledged by informing its previous site A of
its new location and of its new timestamp; site A can
then update its local table with the mobile object’s new
position and timestamp.
4. Implementation in Java
In Java RMI [12], an object whose methods can be
invoked from another JVM is implemented by a remote
object. Such a remote object is described by one or
more remote interfaces. Remote method invocation is
the action of invoking a method of a remote interface
on a remote object. In practice, a stub acts as a client’s
local representative or proxy for a remote object. The
stub of a remote object implements the same interface
as the remote object: when a method is called on the
stub, arguments are serialised and communicatedto the
remote object,1 where the method can be called; its
result is transmitted back to the stub and becomes the
method call result. A very desirable feature of this
approach is that local and remote method invocation
share an identical syntax.
Now, we present an approach in which remote ob-
jects are allowed to be mobile, but clients still use the
same stub-based method invocation mechanism, mak-
ing them unaware of the location and movement of the
mobile object.
Mobile objects delegate to sites the task of send-
ing messages to other objects. When a site receives
a request for sending a message to a mobile object, it
searches its table in order to find the object location.
If the object is local, the message is passed onto the
object. If the object is not local, but known to be at a re-
mote location, the message is forwarded to the remote
location.
4.1. Startpoints and endpoints
Figure 2 displays the different entities of our imple-
mentation. The right-hand side of the picture repre-
As migrationis not atomic, a mobile object may have
left a site, but the acknowledgement of its safe arrival
may not have been received by the site yet. In such
a case, the site temporarily has to enqueue messages
1Before Java 1.2, there was a notion of skeleton, which was a
server-side representative of the object, responsible for deserialising
the arguments.

94
L. Moreau and D. Ribbens / Mobile objects in Java
Fig. 2. Startpoint and endpoint.
sents the “server-side” on JVM2, composed of a mo-
bile object; the left-hand side is concerned with the
“client-side” on JVM1.
of method invocation, but also to make the system more
resilient to failures. In Fig. 3, when JVM2 has to for-
ward a call to JVM3, JVM2 knows that information
on JVM1 is out of date. Therefore, when the result is
returned to JVM1, we can also return updated informa-
tion about the mobile object location. To this end, we
made the remote interface implemented by endpoints
different from the interface implemented by mobile ob-
jects: we return not only the “usual result”, but also the
new object location.
Returning updated location information at the same
time as returningresults may not propagateinformation
soon enough, because processing on the server may be
long. Therefore, independently, we might like to in-
form previous JVMs in the chain about the location of
the mobile object. Since regular remote method invo-
cation does not give any information about the method
caller, we provide, as extra arguments, the stubs point-
ing to the JVMs involved in the chain.
In summary, a startpoint implements the same inter-
face as a mobile object. An endpoint has a derived in-
terface passing extra routing information, both during
the forward call and during the return of a result. The
RMI-stub encapsulatedin the startpoint implements the
same interface as the endpoint.
For the sake of illustration,let us consider the method
talk specified in the interface Talker implemented
by a mobile object.
We adopt Nexus terminology [8], and we respec-
tively name startpoint and endpoint the client-side and
server-side representatives of a remote object. A mo-
bile object is specified by an interface, which must also
be implemented by its startpoints. Startpoints contain
an RMI stub representing the current location of a mo-
bile object, and permit direct communication with the
endpoint; the endpoint passes messages to the mobile
object. Additionally, the startpoint contains the mobile
object’s timestamp t. (The endpoint also has the same
timestamp t.)
Figure 3 displays the new configuration after the
mobile object has migrated to JVM3. There exists a
new endpoint acting as a server-side representative at
the new location. Its timestamp is t + 1 following its
increase after migration. The endpoint is referred to by
a startpoint with timestamp t+1, which is sent to JVM2
as an acknowledgement to the safe arrival at JVM3.
This startpoint is used by the endpoint on JVM2 as a
forwarding pointer to the new object location. When
a method is activated on the startpoint on JVM1, the
call is still transmitted to JVM2, where the endpoint is
aware that the object has moved to JVM3 and uses the
same mechanism to forward the call.
As opposed to simple message passing, a remote
method invocation is expected to return a result.2 In
a first instance, our implementation is based on call
forwarding and the result is propagated back along the
chain to the initial startpoint where the method call was
initiated.
interface Talker {
int talk(int v, String s);
}
A startpoint associated with such a mobile ob-
ject also implements the interface Talker. The
endpoint of such a mobile object implements the
Endpoint TalkerI interface containing a method
talk:
In such an algorithm, it is important to reduce any
chain of forwarding pointers in order to reduce the cost
2In the particular case of a procedure returning a type void, no
result is returned, but the method invocation terminates after the call
has been completed remotely; for the sake of presentation, we will
no longer distinguish this case from normal return of values.
interface _Endpoint_TalkerI {
_int_Result talk (List from,

L. Moreau and D. Ribbens / Mobile objects in Java
95
Fig. 3. Mobile object migration.
int _v, String _s);
executing in parallel, and, if necessary, to save their
}
state in a serializable field of the object.
Mobile Objects in Java also introduce the concept of
“platform”, a JVM that runs mobile objects securely. A
platform is a RMI UnicastRemoteObject which
advertises its presence by binding itself with a RMI-
style URL (specified at construction time) in a RMI-
registry. This is such a URL which is expected as
a first argument by migrate. Hooks are provided
to perform security checks before executing objects in
their sandbox [20].
The extra argumentfrom is a list of RMI stubs to the
JVMs that were involved in the passing of the current
method call. The type int Result encapsulates an
int as well as new routing information. We have im-
plemented a stub compiler which takes care of gener-
ating such interfaces. It also creates the definitions of
the startpoint and endpoint classes.
4.2. Object migration
4.3. Startpoint deserialisation
WeprovideanewabstractclassUnicastMobile-
Object, which encapsulates the behaviourcommonto
all mobile objects. A mobile object must be defined as
a subclass of UnicastMobileObject, from which
two methods can be inherited:
In our system, on a given platform, there is at most
one instance of a startpoint that refers to a given mobile
object. In orderto preservethis invariant, each platform
maintains a table of all the startpoints it knows, which
is updated when startpoints are deserialised. (We use
the Java method doReadResolve [13] to override
the object returned from the stream.)
protected void migrate(String url,
Serializable state)
protected void install(Object state)
A desirable consequence of this implementation is
that all objects using a specific startpoint share the ben-
efit of the most recent routing information for that start-
point. The table of startpoints is a hash table, using a
unique name given to mobile objects as a hashing key.
This table uses weak references [11] to guarantee that
startpoints do not remain accessible longer than neces-
sary. As a result, we ensure that mobile objects may be
properly garbage collected.
A mobile object can initiate its migration to another
JVM, identified by a RMI-style URL, using the method
migrate. The current object content will be serial-
ized in conjunction with an extra argument. Upon an
object’s arrival, the method install is activated with
the state argument passed to migrate. Both methods
are defined as “protected” to guarantee that they are
invoked only under the object’s control.
The Java object model does not make any guaran-
tee regarding which thread executes remote methods.
Therefore, for a single object, there may be several
threads executing in parallel when a request for mi-
grating is issued by one of them. As Java does not
support thread migration, it is not possible to suspend
the execution of all threads in order to resume them at
the destination. Instead, we allow an object to migrate
when there is only one thread executing a method of
this object. It is therefore the programmer’s respon-
sibility to synchronize and terminate threads currently
4.4. Clearing routing information
Routing information has to be cleared when it is no
longer needed. Indeed, platforms run for a long period
of time and host many visiting mobile objects, which
leave forwarding pointers as they migrate to their next
destination. We need to ensure that routingtables do not
become filled with unnecessary routing information.
We have observed [22] that the task of clearing rout-
ing tables is equivalent to the distributed termination

96
L. Moreau and D. Ribbens / Mobile objects in Java
problem [25]. A forwarding endpoint is allowed to
be cleared if it can be proved that no other platform
will ever forward method calls to it. This may be im-
plemented using a distributed reference counting algo-
rithm [23,25]. In particular, RMI provides a method
Unreferenced for remote objects which is called
when there is no remote reference to this object [12].
When this method is called on an endpoint, it may be
unexported, and the reference to the next startpoint in
the chain may be lost. Note that this mechanism can
only work if tables of startpoints contain weak refer-
ences to these. Otherwise, if startpoints remain live,
the RMI-stubs they contain will also remain live, which
will prevent the call of the Unreferenced method
on the associated endpoints.
6. Benchmark
The scientific programming community has a tra-
dition of adopting benchmarks to evaluate the perfor-
mance of computers; for instance, the Linpack Bench-
mark is a numerically intensive test used to measure
floating point performance. Unfortunately, we lack
benchmarks specifically suited to evaluate routing al-
gorithms for mobile objects. This may be explained
by the relative novelty of the concept of mobile ob-
ject, and the inexistence of widely accepted applica-
tions for mobile agents. In a previous paper [23], we
observed that there was no recognised benchmark for
evaluating distributed garbage collectors; therefore, we
designed some synthetic benchmarks for such a type of
distributed algorithms. We propose to adopt a similar
approach here.
A synthetic benchmark is an abstraction of a real
program, where routing of messages may have an im-
pact on the performance of the computation. In our
benchmark, we measure the cost of invoking a method
on a mobile object that has changed location since the
last time the method was invoked on it. In the con-
text of the Magnitude architecture of Section 2, such a
benchmark is reminiscent of the communications one
may have with a mobile agent visiting several locations
to perform a task.
Figure 4 summarises the “Itinerary Benchmark”. An
Itinerary consists of N platforms P0, . . . , PN−1 to be
visited by a mobile object. A platform P, not part of
the itinerary, is used to initiate invocations of a method
m on the remote mobile object. Every method invoca-
tion takes as argument a list of J platform identifiers
that the mobile object has successively to migrate to; an
itinerary is completed when the mobile object returns
to the first platform P0. As method m is invoked on the
mobile object, it spawns a thread responsible for mi-
grating the mobile object to J platforms, while method
m terminates in parallel. On platform P, we measure
the time taken to perform all method calls necessary to
complete an itinerary.
Figure 5 illustrates the execution of the Itinerary
benchmark over 10 platforms (5 rather heavily loaded
workstations/servers each running 2 JVMs), connected
by a local area network. Each method call forced the
object to migrate to one new location. We ran the same
benchmark using both the call forwarding and the re-
ferrals techniques. We can see that in this specific in-
stance, referrals are on average 9% faster than call for-
warding, over 200 itineraries. We should observe the
abnormal duration of the first itinerary in Fig. 5: in-
5. Forwarding vs referrals
In our theoretical algorithm [22], messages are
routed individually; a reply would be regarded as a sep-
arate message to be routed independently. The view
that we have adopted for Mobile Objects in Java differs
slightly because it is based on the remote method invo-
cation paradigm: methods are invoked and are expected
to produce a result. In the previous section, we showed
that the result could be propagated backwards along the
chain of forwarding pointers left by the mobile object.
Long chains of remote method invocations offer too
little resilience to failures of intermediary nodes. In-
stead of forwarding a method call, an endpoint could
throw an exception indicating that the mobile object
has migrated. The exception could contain the new
startpoint pointing at the mobile object location.
The approach consisting of throwing an exception
containing a new startpoint, instead of forwarding a
call, is similar to the referral mechanism [9] used in
distributed search systems such as Whois++ [26] and
LDAP [28]. It then puts the onus on the method in-
voker to re-try the invocation with the next location of
the object; once the object has been reached, the result
may then be returned to the caller directly. In our im-
plementation, the startpoint is in charge of re-trying a
method invocation until it becomes successful. There-
fore, from the programmer’sviewpoint, there is no syn-
tactic difference between the two approaches. An op-
tion passed as argument to the stub compiler specifies
whether code has to be generated for referrals or for
call forwarding. In the rest of the paper, we compare
the performance of the two approaches.

L. Moreau and D. Ribbens / Mobile objects in Java
97
Fig. 4. Itinerary Benchmark.
deed, it can be up to an order of magnitude slower than
the others since it forces object byte-code to be loaded
dynamically as the mobile object visits each platform
for the first time.
In Fig. 6,we summarise our results,which we discuss
now. Several variants of the Itinerary benchmark were
considered.
location only (Notation: One Acknowledge-
ment).
In order to reduce some of the non-deterministic na-
ture of the benchmark, we have introduced a delay be-
tween each method call to the mobile object, which
gave time to the object to migrate to its location. Such
a delay is not included in the results.
In the first table of Fig. 6, eager acknowledgement
of object migration resulted in methods calls to be for-
warded at most once. This is confirmed by the aver-
age duration of a method call, which does not incur
any significant variation as J, the number of migra-
tions associated with a method call, increases. We also
observe that there is no significant difference between
sequential and random itineraries. Finally, the referrals
technique appears to be marginally more efficient than
call forwarding.
In the second table of Fig. 6, acknowledgements of
object position is back-propagated to the object’s pre-
vious location only. Therefore, as we increase J, the
number of platforms that the mobile object has to mi-
grate to for each method call, we observe that method
calls have to be forwarded further. Again, we do not
observe any significant difference between sequential
and random itineraries. However, the referrals tech-
nique becomes significantly more efficient than call for-
warding: its efficiency is in the range [11%–19%] for a
LAN, whereas its in the range [6%–11%] for a cluster.
Instrumenting the Itinerary benchmark turned out to
be more difficult than anticipated. Indeed, many ele-
(i) We always ran the Itinerary benchmark on 10
platforms. In one case, the platforms executed
on 5 rather heavily loaded workstations/servers
each running 2 JVMs) connected by a 100Mb
local area network (Notation: LAN). In the
other case, the platforms executed on 5 nodes
of a cluster (Linux 2.2, 450 Mhz) with dedi-
cated 100Mb network, with each node running
2 JVMs (Notation: Cluster).
(ii) The partitioning of the platforms may be de-
terministic or non-determinisic. In the former
case, the object systematically visits platforms
in the same order (Notation: Sequential). In the
latter case, the orderof platformsis decidedran-
domly for each itinerary (Notation: Random).
(iii) We ran the Itinerary benchmark using both the
call forwarding (Notation: CF) and the referrals
techniques (Notation: Ref).
(iv) When a mobile object migrates to successive lo-
cations, its new position can be acknowledged
to all its previous locations (Notation: Eager
Acknowledgement), or to its directly previous

98
L. Moreau and D. Ribbens / Mobile objects in Java
Comparison of Call forwarding and Referrals [sequential (eager ack) 200 1]
8192
4096
2048
Call Fowarding ( Itinerary Average: 2657.99, Method Average: 265.799)
Referral Style ( Itinerary Average: 2431.27, Method Average: 243.127)
0
20
40
60
80
100
120
140
160
180
200
Number of itineraries
Fig. 5. An illustration of call forwarding vs referrals (LAN).
Fig. 6. Average duration of a method call to a mobile object.
ments, not in our control, interact with our implemen-
tation. In particular, platform to platform communi-
cations were implemented with Java RMI, which uses
Birrel’s distributed garbage collector [4]. Such a dis-
tributed GC introduces synchronisations every time a
stub is communicated by a remote method invocation;
in particular, such synchronisations occur in the bench-
mark when an object migration is acknowledged, or
when stubs are piggybacked. An alternative would be
to use another algorithm [23] which does not introduce
such synchronisations. Our rationale for comparing
sequential and random itineraries was to test whether a
cost was incurred because new connections needed to
be opened. Java RMI hides the implementation details
in a totally opaque manner, and we have no control over
the management of these resources in our implementa-
tion.
Discussion
Call forwarding requires two interventions of each
intermediary platform for forwarding the call and the
result, whereas referrals require only one such inter-
vention. We believe that this element is the principal
explanation for the superior performance of referrals
in the presence of heavily loaded platforms (as in our
LAN). We anticipate that such a configurationis similar
to the environment in which mobile agents are likely to
be deployed (cf. Section 2).
At the beginning of our investigation, we debated
whether referrals would be penalised by having to open
new connections between the benchmark platform and
itinerary platforms. In all likelihood, such connections
had to be opened for distributed GC purpose in both
variants of the algorithm, and therefore no significant
change of performance could be attributed to this as-
pect. Tools to instrument resources used within the
JVM would be extremely valuable in this context.

L. Moreau and D. Ribbens / Mobile objects in Java
99
7. Related work and conclusion
(ii) The absence of widely recognised benchmarks
does not ease comparison with other authors.
(iii) In mobile computing, social human behaviours
dictate the patterns of physical mobility; these
can be extensively used in simulations. Because
we lack widely accepted applications of mobile
agents, we also lack accepted models of their
mobility.
We have presented Mobile Objects in Java a library
able to route method invocations to mobile objects. We
have discussed two ways of forwarding calls, namely
call forwarding and referrals; the latter turned out to
be more efficient in our benchmark. There is a third
method where the caller explicitly passes a reference
to itself, which is used by the callee to return the re-
sult. Such a method discussed in [8,21] allows the
result to “short-cut” the chain of forwarding calls. A
more extensive study is required to investigate the per-
formance of these three methods (as well as the home
agent approach) in various scenarios.
Mobile Objects in Java is an integral part of a mobile
agent system that we use to support mobile users in
the Magnitude project [24]. From a software engineer-
ing viewpoint, such a library provides a separation of
concern between higher-level interactions and message
routing. We are adopting such a communication model
in three different circumstances.
It is this specific problem that Huet [10] addresses
by looking at a formal modelisation of routing algo-
rithms as stochastic processes. In particular, he com-
pares a centralised forwarder with distributed forward-
ing pointers. From the slides that were accessible to us,
we were enable to establish the patterns of mobility he
adopted, and whether call forwarding or referrals were
considered. A challenging issue is to define simula-
tions that are refined enough to take into account other
activities such as distributed garbage collection, which
itself also lacks recognised benchmarks.
In the future, we wish to investigate strategies for
propagating information about object’s locations inde-
pendently of remote method invocation. Such a study
will have to consider new benchmarks, ideally derived
from real applications, and should also include alter-
native routing algorithms. Furthermore, other require-
ments and their implications on performance need to
be investigated, such as security and robustness of di-
rectory services.
(i) User-driven communication to their mobile
agents;
(ii) Return of results from a mobile agent to a mo-
bile personal digital assistant;
(iii) Communications between mobile agents.
There are a number of other systems that support
mobile computations, but they adopt a different philos-
ophy. Emerald [15] supports migration of an object, in-
cluding threads runningin parallel. In Kali Scheme [6],
continuations may be migrated between address spaces.
None of them provides the transparent routing of mes-
sages, as described in this paper. Other approaches rely
on a stationary entity to support communications be-
tween mobile objects, including Aglets [16], Nomadic
Pict [29], April [18] and the InterAgent Communica-
tion Library [19]. Jumping Beans [2] is a commercial
product offering support for mobile applications, but
requires a server to be visited by mobile agents dur-
ing each agent migration. Stationary and central loca-
tions put an extra burden on the infrastructure which
we wanted to avoid in our implementation.
Acknowledgements
David De Roure pointed out an analogy between the
directory service described in this paper and the notion
of referrals used in distributed search systems and in
“query routing”. Thanks to Omer Rana for discussions
on their agent-based Digital Library system, and to
Danius Michaelides for his comments on the paper.
This research is funded in part by EPSRC and QuinetiQ
project “Magnitude” reference (GR/N35816).
Our investigation has highlighted a number of dif-
ficulties concerning the evaluation of algorithms for
mobile agents.
References
[1] S. Adams and D. DeRoure, A Simulator for an Amorphous
Computer, in: Proceedings of the 12th European Simulation
Multiconference (ESM’98), Manchester, UK, June 1998.
[2] Ad Astra, Jumping beans, Technical report, White Paper,
1999, http://www.JumpingBeans.com/.
[3] A.D. Birrell and B.J. Nelson, Implementing Remote Procedure
Calls, ACM Transactions on Computer Systems 2(1) (February
1984), 39–59.
(i) In high-level implementations such as ours, in
particular above Java RMI, the lack of tools
to instrument low-level resources (connections,
distributed garbage collection) makes it some-
what difficult to explain observed behaviours.

100
L. Moreau and D. Ribbens / Mobile objects in Java
[4] A. Birrell, G. Nelson, S. Owicki and E. Wobber, Network Ob-
[19] F.H. McCabe, InterAgent Communications Reference manual,
Technical report, Fujitsu Laboratories of America, 1999.
[20] G. McGraw and E.W. Felten, Securing Java, Wiley, 1999.
[21] D. Michaelides, L. Moreau and D. DeRoure, A Uniform Ap-
proach to Programming the World Wide Web, Computer Sys-
tems Science and Engineering 14(2) (1999), 69–91.
[22] L. Moreau, Distributed Directory Service and Message Router
for Mobile Agents, Science of Computer Programming 39(2–
3) (2001), 249–272.
[23] L. Moreau, Tree Rerooting in Distributed Garbage Collection:
Implementation and Performance Evaluation, Higher-Order
and Symbolic Computation, To appear.
[24] L. Moreau, D. De Roure, W. Hall and N. Jennings, MAG-
NITUDE: Mobile AGents Negotiating for ITinerant Users in
the Distributed Enterprise, http://www.ecs.soton.ac.uk/˜lavm/
magnitude/, 2001.
[25] G. Tel and F. Mattern, The Derivation of Distributed Termina-
tion Detection Algorithms from Garbage Collection Schemes,
ACM Transactions on Programming Languages and Systems
15(1) (January 1993), 1–35.
[26] C. Weider, J. Fullton and S. Spero, Architecture of Whois++
Index Service, Request for comments 1913, Internet Engineer-
ing Task Force, 1996.
[27] M. Weiser, Some Computer Science Problems in Ubiquitous
Computing, Communications of the ACM 36(7) (July 1993),
74–84.
jects, Technical Report 115, Digital Systems Research Center,
February 1994.
[5] L. Cardelli, Abstractions for Mobile Computation, in: Secure
Internet Programming: Security Issues for Distributed and
Mobile Objects, J. Vitek and C. Jensen, eds, Vol. 1603 of
Lecture Notes in Computer Science, 1999.
[6] H. Cejtin, S. Jagannathan and R. Kelsey, Higher-order dis-
tributed objects, ACM Transactions on Programming Lan-
guages and Systems 17(5) (September 1995), 704–739.
[7] J. Dale and F.G. McCabe, Agent Management Support for
Mobility, Fipa’98 draft specification, Fujitsu Laboratories of
America, 1998.
[8] I. Foster, C. Kesselman and S. Tuecke, The Nexus Approach
to Integrating Multithreading and Communication, Journal of
Parallel and Distributed Computing 37 (1996), 70–82.
[9] N. Gibbins and W. Hall, Scalability issues for query routing
service discovery. in: Proceedings of the Second Workshop on
Infrastructure for Agents, MAS and Scalable MAS, May 2001.
[10] F. Huet, Distribution and localisation, http://www.irit.fr/
ACTIVITES/PLASMA/PRO-Toulouse2001/LesPropositions
/LesTransparents/pro-huet.pdf.
[11] Java Reference Objects, http://java.sun.com/j2se/1.3/docs/
guide/refobs/.
[12] Java Remote Method Invocation Specification, November
1996.
[13] Java Object Serialization Specification, November 1998.
[14] D.B. Johnson and C. Perkins, Mobility Support in IPv6, In-
ternet draft, IETF Mobile IP Working Group, 1999. draft-ietf-
mobileip-ipv6-09.txt.
[15] E. Jul, Migration of light-weight processes in Emerald, Op-
erating Systems Technical Committee Newsletter 3(1) (1989),
25–30.
[16] D.B. Lange and M. Ishima, Programming and Deploying Java
Mobile Agents with Aglets, Addison-Wesley, 1998.
[17] General Magic, Telescript Technology: Mobile Agents, 1996.
[18] F.G. McCabe and K.L. Clark, APRIL – Agent Process Interac-
tion Language, in: Proc. of ECAI’94 Workshop on Agent The-
ories, Architectures and Languages, Springer-Verlag, 1995.
[28] M. Whalh, T. Howes and S. Kille, Light Weight Directory
Access Protocol (v3), Request for comments 2251, Internet
Engineering Task Force, 1997.
[29] P. Wojciechowski and P. Sewell, Nomadic Pict: Language and
Infrastructure Design for Mobile Agents, in: First Interna-
tional Symposium on Agent Systems and Applications/Third
International Symposium on Mobile Agents (ASA/MA’99), Oc-
tober 1999.
[30] Y. Yang, O.F. Rana, C. Georgousopoulos, D.W. Walker and
R.D. Williams, Mobile agents and the sara digital library,
in: Proceedings of IEEE Advances in Digital Libraries 2000,
Washington, DC, May 2000, pp. 71–77.

Journal of
Industrial Engineering
Advances in
Multimedia
Applied
Computational
Intelligence and Soft
Computing
International Journal of
Distributed
The Scientific
World Journal
Sensor Networks
Hindawi Publishing Corporation
Hindawi Publishing Corporation
Hindawi Publishing Corporation
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
http://www.hindawi.com
http://www.hindawi.com
Volume 2014
http://www.hindawi.com
Volume 2014
Volume 2014
Volume 2014
http://www.hindawi.com
Volume 2014
AFduvanzcezs iyn
Systems
Modelling &
Simulation
in Engineering
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
http://www.hindawi.com
Volume 2014
Volume 2014
Submit your manuscripts at
http://www.hindawi.com
Journal of
Computer Networks
and Communications
ꢀAdvancesꢀinꢀ
Artificial
Intelligence
Hindawi Publishing Corporation
http://www.hindawi.com
HindawiꢀPublishingꢀCorporation
http://www.hindawi.com
Volume 2014
Volumeꢀ2014
International Journal of
Advances in
Biomedical Imaging
Artificial
Neural Systems
International Journal of
Computer Games
Technology
Advances in
Advances in
Computer Engineering
Software Engineering
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
Hindawi Publishing Corporation
Volume 2014
Volume 2014
Volume 2014
http://www.hindawi.com
Volume 2014
http://www.hindawi.com
Volume 2014
International Journal of
Reconfigurable
Computing
Computational
Intelligence and
Neuroscience
Advances in
Journal of
Journal of
Human-Computer
Electrical and Computer
Robotics
Interaction
Engineering
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
http://www.hindawi.com
Hindawi Publishing Corporation
Volume 2014
Volume 2014
Volume 2014
Volume 2014
http://www.hindawi.com
Volume 2014
