Enantiopure Synthesis of (R)-Mandelonitrile Using
Hydroxynitrile Lyase of Wild Apricot (Prunus armeniaca L.)
[ParsHNL] in Aqueous/Organic Biphasic System
Mohammad Asif1 · Tek Chand Bhalla1
Received: 9 January 2017 / Accepted: 5 March 2017
© Springer Science+Business Media New York 2017
Abstract Hydroxynitrile lyases (HNLs) are increasingly
finding application in the synthesis of enantiomerically
pure cyanohydrins which are important intermediates in
the production of pharmaceuticals and agrochemicals. Syn-
thesis of enantiopure mandelonitrile was carried out using
HNL of wild apricot (Prunus armeniaca L.) [ParsHNL]
in aqueous/organic biphasic system. The optimum pH and
temperature of the reaction were 4.0 and 15°C respectively,
which are important parameters to suppress the non-enzy-
matic catalysis. ParsHNL catalyses synthesis of (R)-man-
delonitrile in methyl-tbutyl ether (MTBE)/citrate buffer
biphasic system with >99% ee. Synthesis of mandelonitrile
was carried out in batch reaction at 40 ml scale and finally
2.7 mmoles of (R)-mandelonitrile was recovered which
corresponded to 90% molar conversion in 46 h reaction. In
fed batch reaction 6.37 mmoles of (R)-mandelonitrile could
be produced which corresponds to 91% molar conversion in
46 h. In both reactions, enzyme produces (R)-mandeloni-
trile with >99% ee which showed enhanced selectivity
as compared to aqueous reaction (96% ee) by ParsHNL.
The results showed potential of ParsHNL to synthesize
(R)-mandelonitrile in both, batch reaction and fed-batch
reaction and can be effectively used in the synthesis of
(R)-mandelonitrile.
Graphical Abstract
3000
Product Formed (µmole)
3000
2700
2640
2598
Substrate le (µmole)
2500
2088
1948
2000
1500
1000
500
0
1052
912
402
360
300
0
0
3
6
24
28
46
Time (h)
HCN
ParsHNL
(R)-MANDELONITRILE
CHIRAL SYNTHESIS
BENZALDEHYDE
6370
91
6067
5952
85
100
6000
4800
3600
2400
1200
0
4708
64.9
80
86.7
Substrate
Product
60
3000
54.6
2252
2292
40
20
0
% conversion
1948
1908
1052
1048
933
630
0
6
12
18
24
30
36
42
48
Time (h)
Keywords Prunus armeniaca L. · Wild apricot · (R)-
mandelonitrile · Biphasic reaction · Hydroxynitrile lyase ·
ParsHNL · Cyanohydrin · Batch-fed batch reaction
1 Introduction
* Tek Chand Bhalla
bhallatc@rediffmail.com
Hydroxynitrile lyases (HNL, EC 4.1.2.x) are the enzymes
which mediate the release of hydrogen cyanide (HCN) and
1
Department of Biotechnology, Himachal Pradesh University,
Summer Hill, Shimla, Himachal Pradesh 171005, India
Vol.:(0123456789)
1 3

M. Asif, T. C. Bhalla
aldehyde or ketone from their corresponding cyanohydrins
[1] and catalyses enantioselective synthesis of cyanohy-
drins through reverse reaction [2]. The cyanohydrins and
their derivatives are finding wide applications in indus-
tries for production of pharmaceuticals, agrochemicals
and cosmetics, as both functional groups of cyanohydrins,
hydroxyl and cyanide are attached to same carbon atom,
which can be readily converted into other synthetically rel-
evant building blocks like α-hydroxy ketones, α-hydroxy
carboxylic acids and β-amino acids [3].
