Malodorogenic Sensing of Carbon Monoxide

Article abstract of DOI:10.1002/chem.201703726

A thin film of poly-([IrCl(cod)(NHC-onbe)]_n-(propyl-onbe)_m) (onbe=oxanorbornene) coated on filter paper reacts quantitatively with CO to yield 1,5-cyclooctadiene, the unpleasant smell of which can be detected by the human olfactory system with very high sensitivity. Odorless, but toxic CO is thus “translated” into the distinct smell of 1,5-cyclooctadiene. Based on malodorogenic sensing it is possible to smell the presence of CO.

Full text of DOI:10.1002/chem.201703726

A Journal of
Accepted Article
Title: Malodorogenic Sensing of Carbon Monoxide
Authors: Herbert Plenio, Marvin Bergmann, and Meike Egert
This manuscript has been accepted after peer review and appears as an
Accepted Article online prior to editing, proofing, and formal publication
of the final Version of Record (VoR). This work is currently citable by
using the Digital Object Identifier (DOI) given below. The VoR will be
published online in Early View as soon as possible and may be different
to this Accepted Article as a result of editing. Readers should obtain
the VoR from the journal website shown below when it is published
to ensure accuracy of information. The authors are responsible for the
content of this Accepted Article.
To be cited as: Chem. Eur. J. 10.1002/chem.201703726
Link to VoR: http://dx.doi.org/10.1002/chem.201703726
Supported by

Chemistry - A European Journal
10.1002/chem.201703726
Malodorogenic Sensing of Carbon Monoxide
Marvin Bergmann, Meike Egert, and Herbert Plenio*
Organometallic Chemistry, Alarich-Weiss-Str. 12, TU Darmstadt, 64287 Darmstadt, Germany, e-mail:
plenio@tu-darmstadt.de
Both authors M.E. and M.B. contributed equally.
Dedicated to the memory of Dr. K. J. Wannowius
Abstract: A thin film of poly-([IrCl(cod)(NHC-onbe)]
n
-(propyl-onbe) ) (onbe= oxanorbornene) coated
m
on filter paper reacts quantitatively with CO to yield 1,5-cyclooctadiene, whose unpleasant smell can
be detected by the human olfactory system with very high sensitivity. Odorless, but toxic CO is thus
“
translated” into the distinct smell of 1,5-cyclooctadiene. Based on malodorogenic sensing it is
possible to smell the presence of CO.
Carbon monoxide is a colorless, odorless and tasteless gas, liberated upon incomplete combustion of
carbon containing materials.[1] The high toxicity of CO and its facile (accidental) generation in
[
2]
everyday life pose a serious health threat. The risks associated with CO poisoning are aggravated
due to the absence of highly characteristic symptoms.[3] Victims are treated with pure O
to
2
compensate for the reduced oxygen uptake capacity and to displace hemoglobin-bound CO. Based
on its toxicity the threshold limit value of CO during extended exposure (8 h) has been set to 25
[
4]
ppm. Higher levels of around 100 ppm result in headaches within a few hours, whereas prolonged
exposure of up to 500 ppm carbon monoxide leads to severe poisoning, resulting in circulatory
[
5]
failure, brain damage, and finally death. Consequently, a large number of CO-sensitive devices for
the measurement of air quality are known.[6] From a commercial point of view solid state devices
such as metal oxide based semiconductors[7] and electrochemical sensors are by far the most
successful ones.[8] Colorimetric CO-detection is utilized in modern multichannel pulse oximetry and
basically relies on the prominent deoxy-myoglobin assay.[9] More recently molecular probes for the
detection of CO were developed, in which a chemical reaction with CO leads to a change in the color
or the fluorescence signal.[10] The chromogenic rhodium complexes developed by Martinez-Máñez
represented a breakthrough for the simple detection of CO (scheme 1a) in the critical concentration
range of 50-100 ppm. [11] Fluorogenic reactions for CO-detection were also reported, in which the
presence of CO leads to a pronounced increase in the fluorescence level (scheme 1b, 1c).[12] This is
also relevant with a view to the intracellular detection, since CO is an important biogenic signaling
molecule.[13]
1
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
We want to present here an entirely new approach for the detection of CO, which relies on the
chemical translation of this toxic gas into a smellable compound. The well-known reaction of
[
MCl(cod)(NHC)] (M= Rh, Ir; NHC= N-heterocyclic carbene) with two equivalents of CO produces the
carbonyl complex [MCl(CO)
2
(NHC)] in almost quantitative yields.[14] The other product of this
reaction, 1,5-cyclooctadiene, is normally ignored.[15] However, the human nose is extremely sensitive
to the unpleasant smell of 1,5-cyclooctadiene[16] and the odor threshold was determined to be
0
.00087 ppm[17] (triangle odor bag method).[18][19] The reaction of CO with [MCl(cod)(NHC)] can thus
be viewed as a chemical translation of odorless CO into smelly 1,5-cyclooctadiene. Based on this
reaction, the human olfactory system acquires the ability to smell the presence of toxic CO. The
unpleasantness of 1,5-cyclooctadiene smell serves as an additional warning. We propose the term
“
malodorogenic sensing” for this new detection concept. This approach directly addresses our sense
of smell and is quite different from an electronic nose.[20] The concept reported here can be
considered as a special indicator displacement assay.[21]
Scheme 1. Chromogenic and fluorogenic CO-responsive reactions (bdp= bodipy fluorophore).
The observation of 1,5-cyclooctadiene smell depends on the chemical substitution of the cod ligand
with CO and on the physical transfer of the liberated 1,5-cyclooctadiene from the surface into the gas
phase and into the human olfactory system.[22] Malodorogenic reactions should be carried out in the
absence of solvents to facilitate the transfer of 1,5-cyclooctadiene into the gas phase and to prevent
masking the smell of the olefin. For a preliminary test of the malodorogenic concept, the behavior of
several powdered metal complexes containing cod ligands (figure 1) were investigated. Between (0.1
-
6
–
0.9) ·10 mol of the respective complex were physisorbed on a small piece of Linters paper by
2
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
evaporation of a CHCl
3
solution of the respective complex. First the smell of these samples after
exposure to ambient air during 5- 120 min was tested. None of the complexes produced smellable
quantities of 1,5-cyclooctadiene. Obviously, the constituents of ambient air do not lead to false
positives. Next, the samples were exposed to air containing between 800 – 1600 ppm of CO for 5
min. Following this treatment most of the complexes transpire a strong smell of 1,5-cyclooctadiene.
The reaction of dissolved [MCl(cod)(NHC)] complexes with CO is known to be very fast.[12d] In order to
obtain reliable data on the CO uptake, the solid-gas reactions of 13 Rh and Ir complexes with CO
were tested (Figure 1).[23] Powdered sample of the complex were exposed to CO (500 ppm CO in N
2
)
1
and the ratio of the respective [(MCl(cod)(NHC)] and [(MCl(CO)
2
(NHC)] complexes determined by H-
NMR spectroscopy. Significant differences in the reaction rates with CO were observed. In general,
iridium complexes react faster with CO than rhodium complexes, as had been observed before for
the solution reactions.[12d] The nature of the NHC ligand also has a significant influence, notably the
reaction of the CAAC –based NHC Ir complex 2 is very slow.
1
1
1
1
3
2
1
0
9
8
7
6
5
4
3
2
1
[IrCl(cod)(SIMes)]
[IrCl(cod)(IMes-butoxy)]
[IrCl(cod)(IPr)]
[IrCl(cod)(IMes)]
[RhCl(cod)(SIPr)]
[IrCl(cod)(SIPr)]
[RhCl(cod)(IMes)]
[RhI(cod)(NHC)]
RhCl(cod)(NHC)]
[
[RhCl(cod)(IPr)]
[RhCl(cod)(SIMes)]
[IrCl(cod)(CAAC)]
[RhCl(cod)]2
0
10 20 30 40 50 60 70 80 90 100
yield of carbonyl complex / %
Figure 1. Conversions for the solid-gas reactions of [MCl(cod)(NHC)] (M= Rh, Ir) complexes with CO
CO-for-cod substitution) after 4 h to give [MCl(CO) (NHC)] (IPr= 1,3-bis(2,6-diisopropylphenyl)imi-
(
2
dazol-2-ylidene, SIPr= 1,3-bis(2,6-diisopropylphenyl)imidazolidin-2-ylidene, IMes= 1,3-bis(2,4,6-tri-
methylphenyl)imidazol-2-ylidene, SIMes= 1,3-bis(2,6-trimethylphenyl)imidazolidin-2-ylidene, CAAC=
cyclic alkylamino carbene, NHC in complex 5= 1,3-diisopropyl,-4,5-dichloro-imidazol-2-ylidene, NHC
in complex 6= 1,4-diphenyl-1,2,3-triazol-5-ylidene)(for a full list of complexes studied, see supporting
information).
The release of cod from different [MCl(cod)(NHC)] complexes upon exposition to a CO containing
atmosphere of ambient air was monitored via EI-mass spectrometry (figure 2). Filter paper strips
were impregnated with solutions of the respective complex. After evaporation of the solvent, the
paper strips were exposed to a CO-containing atmosphere. Aliquots of the atmosphere close to the
3
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
impregnated paper were periodically transferred into the mass spectrometer via a capillary located
close to the samples. The transfer rate of 1,5-cyclooctadiene into the gas phase shows a significant
spread for the different metal complexes (figure 2). The ordering of the transfer rates for the various
[
MCl(cod)(NHC)] complexes is qualitatively correlated with the ordering of the CO-for-cod
substitution reactions (see figure 1).[24] Based on this observation, it seems that the physical process
of 1,5-cyclooctadiene release from the solid residue following the CO-for-cod substitution reaction
appears to be relatively independent of the nature of the starting complex.
4000
3000
2000
1000
0
#13
#
3
#
8
#11
#
8
#10
#7
#4
0
10
20
30
40
50
60
time / min
Figure 2. Release of 1,5-cyclooctadiene from [MCl(cod)(NHC)] (M= Rh, Ir for complexes 3, 4, 7, 8, 9,
0, 11, 13) into the gas phase as monitored via EI-MS.
1
When trying to directly probe the rate of CO uptake of the organometallic complexes adsorbed on
filter paper using ATR-IR spectroscopy, we experienced reproducibility problems. It seems the
organometallic complexes are easily lost from the paper surface by mechanical abrasion during
handling of the samples. This facile loss of complex from the paper is problematic for the potential
application of malodorogenic sensing, since the accidental intake of transition metal containing
particles while smelling cod must be avoided.
To overcome this problem, analogous polymeric [IrCl(cod)(NHC)] complexes were synthesized. This
approach was based on the expectation, that thin polymer films firmly stick to the paper surface and
are characterized by fast CO penetration and rapid evaporation of 1,5-cyclooctadiene.
The synthesis of the new organometallic polymer[25] was conducted as follows (scheme 2, scheme 3 ):
A polymerizable oxanorbornene unit was covalently attached to an azolium salt containing a
nucleofuge.[26] This NHC precursor was converted into [IrCl(cod)(NHC-onbe)] (onbe = oxanorbornene)
according to standard procedures.[27] The polymerizable Ir-complex is closely related to complex 12
(figure 1), which stood out for fast CO-for-cod substitution reactions. Treatment of the onbe-tagged
complex with a ROMP catalyst[28] provided the respective homopolymer, albeit in modest yields (ca.
4
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
5
0%), which turned out to be unsuitable for film formation. The properties of the polymer and the
polymer yield were significantly improved by synthesizing copolymers of the organometallic mono-
mer and a closely related propyl-terminated monomer (scheme 3). The copolymers are produced in
yields of 73-86% with M = 35.000 g/mol and PDI = 2.3 (for 1:2 polymer). Notably, the ROMP catalyst
n
selectively polymerizes the oxanorbornene unit. The metal bound 1,5-cyclooctadiene does not react.
Scheme 2. Synthesis of polymerizable [IrCl(cod)(NHC-onbe)] complexes for malodorogenic sensing.
Reagents and conditions: a) 3a,4,7,7a-tetrahydro-4,7-epoxyisobenzofuran-1,3-dione, 5-aminopentan-
o
o
1
-ol, neat, 80 C; b) methanesulfonyl chloride, Et
3
N, CH
2
Cl
2
, 0 C and 5-hydroxy-1,3-dimesityl-1H-
o
imidazol-3-ium chloride, KI, K
2
CO
3
, acetone, 60 C; c) [IrCl(cod)]
2
, K CO , acetone reflux.
2
3
Scheme 3. Polymerization of organometallic and organic monomers via ROMP to the organometallic
homopolymer (m= 0, yield: 50%) or statistical copolymers (yield: 73-86%) with n:m= 1:2, 1:5 and
1
:10. Reagents and conditions: a) OPh-Grubbs-Hoveyda complex,[28] CH
2
Cl , r.t., polymer precipitated
2
with MeOH.
A solution of poly-([IrCl(cod)(NHC-onbe)
1
]-(propyl-onbe)
2
) in CHCl was used for spin-coating the
3
polymer onto a quartz disc. Thin films of the metallopolymer with an average thickness of 5-10 m
were produced. The CO-for-cod substitution reaction and the liberation of 1,5-cyclooctadiene was
studied using a quartz crystal microbalance (QCB) (figure 3). The admission of a nitrogen atmosphere
containing 500 ppm of CO at t= 213 s leads to a pronounced increase in the signal due to the uptake
5
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
of CO by the film and the substitution of cod by two molecules of CO. The reaction with CO appears
to be very fast and is followed by the evaporation of 1,5-cyclooctadiene from the polymer film. This
process was accelerated significantly at t= 600 s by allowing a gentle nitrogen flow through the
sample chamber. To prove that this frequency change is due to a CO-for-cod substitution reaction, a
similar experiment using a poly-([IrCl(CO) (NHC-onbe)]-(onbe-propyl)) film was done. In this
2
experiment the admission of CO gas did not result in significant changes in the resonance frequency
of the quartz disc.
evaporation of 1,5-cyclooctadiene
100
gentle nitrogen flow
80
60
40
20
0
CO-admission
0
500 1000 1500 2000 2500 3000
time / s
Figure 3. CO-uptake and release of 1,5-cyclooctadiene by the thin film of poly-([IrCl(cod)(NHC-onbe)]-
onbe-propyl)) monitored by quartz crystal microbalance. Exposure to CO atmosphere (500 ppm) in
(
nitrogen starting at t= 213 s, gentle flow of nitrogen over the sample starting at t= 600 s.
ATR-IR measurements of the polymer film after CO exposure provide additional evidence for the
formation of the iridium carbonyl complex. The typical carbonyl stretching absorbances are observed
at 1974, 2056 cm for CO ligands located cis and trans to the NHC ligand. A large area (ca. 100 cm2)
-
1
[29]
polymer film of similar film thickness was prepared and exposed to CO (500 ppm in N ). An NMR-
2
spectrum of the dissolved film shows that the majority of polymeric Ir(cod) complex in the film was
converted into the respective iridium carbonyl complex. Based on the mass balance of the CO-for-
cod substitution and according to the Sauerbray equation[30] the frequency drop in the QCB
experiments was expected to be more pronounced than observed. The NMR experiments and the
asymptotic curve (figure 3) indicate, that the majority of the liberated 1,5-cyclooctadiene is removed
from the polymer film. We therefore attribute the weaker than expected drop in the QCB frequency
to changes in the film elasticity upon CO-for-cod substitution and inelastic mass oscillation in the soft
polymer film.[30]
Thin films of the organometallic polymer on various substrates (filter paper, aluminum foil, glas)
were prepared to optimize the detection sensitivity for a 100 ppm concentration of CO in ambient
6
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
air. Based on our preliminary experiments, paper supports perform better than the other substrates.
A smellable amount of 1,5-cyclooctadiene is produced within a few seconds after exposure to CO
containing atmosphere when using as little as 0.2 mg of a polymer (iridium content 0.04 mg) is
applied to a 1 cm paper strip.[31]
2
In conclusion, the simple CO-for-cod substitution in complexes [IrCl(cod)(NHC)] leads to the rapid
formation of 1,5-cyclooctadiene, which evaporates into the gas phase. The human nose is extremely
sensitive to the distinct smell of 1,5-cyclooctadiene. The CO-for-cod substitution thus corresponds to
a chemical translation of toxic, but odorless CO into smelly 1,5-cyclooctadiene. This approach is
termed malodorogenic sensing. Thin films of polymeric iridium complexes are very useful for the
highly sensitive indirect detection of CO.[32] With a view to the very small amounts of CO-sensitive
polymer needed, the application of malodorogenous CO sensing appears to be a realistic target. The
concept reported here is simple and cheap, it’s application does not require special expertise or a
sophisticated infrastructure. According to Whitesides simple paper-based analytical devices are
suitable for applications everywhere in the world.[33]
Acknowledgements. This work was supported by the DFG through grant Pl 178/18-1. We wish to
thank Prof. Dr. R. Schäfer for access and support with the QCB, Ms. Sahinalp and Dr. A. Schießer for
the mass spectrometric measurements and Prof. Dr. M. Biesalski for providing samples of Linters
paper and access to a spin coater.
Keywords: carbon monoxide · sensing · iridium · quartz crystal microbalance · 1,5-cyclooctadiene
[
[
1]
2]
M. Goldstein, J. Emerg. Nursing 2008, 34, 538-542.
According to the "Statistisches Bundesamt" in Germany during 2014 at least 594 people were
victims
of
lethal
CO
poisoning:
https://www.destatis.de/DE/Publikationen/Thematisch/Gesundheit/Todesursachen/Todesur
sachenstatistik.html
a) N. Cobb, R. A. Etzel, JAMA 1991, 266, 659-663; b) S. R. Wilcox, J. B. Richards, Respiratory
[
3]
Care 2013, 58, 376-379.
[
[
[
[
4]
5]
6]
7]
American Conference of Governmental Industrial Hygienists (ACGIH) 2005.
Carbon Monoxide Poisoning (ed. D. G. Penney), CRC Press, Boca Raton, 2007.
X. Zhou, S. Lee, Z. Xu, J. Yoon, Chem. Rev. 2015, 115, 7944-8000.
J. Feng-Renn, F. Yean-Kuen, C. Yen-Ting, C. Tse-Heng, I. L. Cheng, L. Cheng-Wei, L. Yan-Wei,
Sens. J., IEEE 2011, 11, 1227-1232.
[
[
8]
9]
S. S. Park, J. Kim, Y. Lee, Anal. Chem. 2012, 84, 1792-1796.
A. J. Atkin, J. M. Lynam, B. E. Moulton, P. Sawle, R. Motterlini, N. M. Boyle, M. T. Pryce, I. J. S.
Fairlamb, Dalton Trans. 2011, 40, 5755-5761.
[
[
10]
11]
C. Marin-Hernandez, A. Toscani, F. Sancenon, J. D. E. T. Wilton-Ely, R. Martın
Commun. 2016, 52, 5902-5911.
́
ez-Máñez, Chem.
a) J. Esteban, J. V. Ros-Lis, R. Martínez-Máñez, M. D. Marcos, M. Moragues, J. Soto, F.
Sancenón, Angew. Chem. Int. Ed. 2010, 49, 4934-4937; b) M. E. Moragues, J. Esteban, J. V.
7
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
Ros-Lis, R. Martínez-Máñez, M. D. Marcos, M. Martinez, J. Soto, F. Sancenón, J. Am. Chem.
Soc. 2011, 133, 15762-15772; c) M. E. Moragues, R. Montes-Robles, J. V. Ros-Lis, M. Alcañíz,
J. Ibañez, T. Pardo, R. Martínez-Máñez, Sens. Actuators, B 2014, 191, 257-263.
a) C. W. Rogers, M. O. Wolf, Angew. Chem., Int. Ed. 2002, 41, 1898-1900; b) B. W. Michel, A.
R. Lippert, C. J. Chang, J. Am. Chem. Soc. 2012, 134, 15668-15671; c) T. Yan, J. Chen, S. Wu, Z.
Mao, Z. Liu, Org. Lett. 2014, 16, 3296-3299; d) P. Kos, H. Plenio, Chem. Eur. J. 2015, 21, 1088-
[
[
12]
13]
1
095; e) O. Halter, I. Fernández, H. Plenio, Chem. Eur. J. 2017, 23, 711-719.
a) L. Yuan, W. Lin, L. Tan, K. Zheng, W. Huang, Angew. Chem. Int. Ed. 2013, 52, 1628-1630; b)
S. H. Heinemann, T. Hoshi, M. Westerhausen, A. Schiller, Chem. Commun. 2014, 50, 3644-
3
660.
[
[
[
14]
15]
16]
a) J. A. S. Howell, P. M. Burkinshaw, Chem. Rev. 1983, 83, 557-599; b) A. R. Chianese, X. Li, M.
C. Janzen, J. W. Faller, R. H. Crabtree, Organometallics 2003, 22, 1663-1667.
Metal-bound 1,5-cyclooctadiene is termed "cod", while for free 1,5-cyclooctadiene the long
name is used.
It is believed that the olfactory receptor is a metalloprotein, since strongly metal
coordinating compounds are characterized by very intense smell. J. Wang, Z. A. Luthey-
Schulten, K. S. Suslick, Proc. Nat. Acad. Sci. 2003, 100, 3035–3039.
[
17]
The threshold limit value of 1,5-cyclooctadiene is at least 40 times lower than that of CO.
(LD50 (Rat) = 1900 mg/kg, LC50= 12 mg/L, Acute inhalation toxicity per 4 h= 1000 ppm, acute
breathing toxicity is category 4 (= lowest category). The odor threshold is more than 1000-
times lower than the lethal dose (based on an 4 h exposure time), in addition the exposure
time for a single sniffing event is approx. 3600 times shorter.
a) Y. Iwasaki, J. Jap. Ass. Odor Envir. 2012, 43, 395-400; b) F. Di, L. Jiemin, Y. Qin, Adv. Mat.
Res. Online 2013, 807-809, 451-455.
[
18]
[
[
[
[
[
19]
20]
21]
22]
23]
Japan Association on Odor Environment: http://orea.or.jp/english.html.
J. R. Askim, M. Mahmoudi, K. S. Suslick, Chem. Soc. Rev. 2013, 42, 8649-8682.
B. T. Nguyen, E. V. Anslyn, Coord. Chem. Rev. 2006, 250, 3118–3127.
1,5-cyclooctadiene: b.p.= 150 C, vapor pressure 6.5 hPa (293 K).
We tried to generate samples with similar particle size to suppress the potential effect of
o
different surface morphology on the reaction rate with CO.
[
24]
All samples were prepared in the same manner, but it cannot be excluded, that different
morphology of the samples has an influence on the cod release.
[
[
25]
26]
W. J. Sommer, M. Weck, Coord. Chem. Rev. 2007, 251, 860.
L. Benhamou, N. Vujkovic, V. César, H. Gornitzka, N. Lugan, G. Lavigne, Organometallics 2010,
2
9, 2616-2630.
[
[
[
[
[
27]
28]
29]
30]
31]
R. Savka, H. Plenio, Dalton Trans. 2015, 44, 891-893.
P. Kos, R. Savka, H. Plenio, Adv. Synth. Catal. 2013, 355, 439-447.
S. Wolf, H. Plenio, J. Organomet. Chem. 2009, 694, 1487-1492.
K. A. Marx, Biomacromolecules 2003, 4, 1099-1120.
Preliminary experiments show, that from a sample size of eight people, all eight were able to
smell the presence of 1,5-cyclooctadiene generated from this amount of polymer film.
The amount of 1,5-cyclooctadiene contained in 0.2 mg of polymer is approximately 0.015
mg. The real intake of this compound while smelling should be significantly smaller. Based on
the toxicity of 1,5-cyclooctadiene, this amount appears to be unproblematic.
a) F. Güder, A. Ainla, J. Redston, B. Mosadegh, A. Glavan, T. J. Martin, G. M. Whitesides,
Angew. Chem. Int. Ed. 2016, 55, 5727-5732; b) A. W. Martinez, S. T. Phillips, G. M.
Whitesides, E. Carrilho, Anal. Chem. 2010, 82, 3-10.
[
[
32]
33]
8
This article is protected by copyright. All rights reserved.

Chemistry - A European Journal
10.1002/chem.201703726
Malodorogenic Sensing of Carbon Monoxide
A rose by any other name would smell as sweet. A chemical reaction involving a thin film of an
organometallic polymer and CO translates odorless, but toxic carbon monoxide into 1,5-
cyclooctadiene. The human olfactory system is able to perceive the unpleasant smell of this olefin at
concentrations below 0.001 ppm. Based on the malodorogenic approach humans are enabled to
smell the presence of carbon monoxide.
9
This article is protected by copyright. All rights reserved.
