Another advantage of the SnO2/RGO nanocomposite is the
robust reusability, which is a prerequisite for practical applications.
After the reaction, the solid catalyst was separated from the
reaction mixture conveniently by simple filtration. The recyclability
was then tested under the identical conditions through the
epoxidation of cyclohexene. The results in Fig. 4 demonstrated that
the heterogeneous catalyst was fairly stable for ten cycles without
observing significant decrease in catalytic activity. Both conversion
and selectivity were still higher than 90% throughout ten runs. The
robust recyclability of SnO2/RGO nanocomposite may originate
from the strong interactions between graphene and metal oxide.
Evidence for the stability of our catalyst can be seen in further
tests. The XRD patterns of the fresh and the reused one (after 10
recycles) are shown in Fig. S6. Obviously, there is no discriminable
difference between the fresh catalyst and the spent one, indicating
that the characteristic peaks of tetragonal SnO2 still exist. The TEM
image of the recovered catalyst (Fig. S7) further confirmed that the
size of SnO2 is still around 3nm intuitively after ten recycles,
suggesting that graphene prevent the aggregation problem
efficiently. The result of ICP-AES analysis showed no trace of Sn in
the filtrate, which is also confirmed by the TG curves (Fig. S8), as the
amount of active spieces remained at 77% in consecutive cycles.
These results infer that the nanocomposite is truly heterogeneous
with no active spieces leaching.
Notes and references
1
Q. H. Xia, H. Q. Ge, C. P. Ye, Z. M. Liu and K. X. Su, Chem.
Rev., 2005, 105, 1603-1662.
P. J. Cordeiro and T. D. Tilley, ACS Catal., 2011, 1, 455-467.
L. Wang, H. Wang, P. Hapala, L. Zhu, L. Ren, X. Meng, J. P.
Lewis and F. S. Xiao, J. Catal., 2011, 281, 30-39.
S. A. Hauser, M. Cokoja and F. E. Kühn, Catal. Sci. Technol.,
2
3
4
5
2013,
D. Banerjee, R. V. Jagadeesh, K. Junge, M. M. Pohl, J. Radnik,
3, 552-561.
A. Brückner and M. Beller, Angew. Chem. Int. Ed., 2014, 53
4359-4363.
,
6
7
8
9
M. Masteri-Farahani, F. Farzaneh and M. Ghandi, J. Mol.
Catal. A: Chem., 2006, 248, 53-60.
E. Angelescu, O. Pavel, R. Bîrjega, M. Florea and R. Zăvoianu,
Appl. Catal. A, 2008, 341, 50-57.
B. Qi, X. H. Lu, D. Zhou, Q. H. Xia, Z. R. Tang, S. Y. Fang, T.
Pang and Y. L. Dong, J. Mol. Catal. A: Chem., 2010, 322, 73-79.
V. R. Choudhary, R. Jha and P. Jana, Green Chem., 2006, 8,
689-690.
10 K. Kamata, K. Yonehara, Y. Sumida, K. Yamaguchi, S. Hikichi
and N. Mizuno, Science, 2003, 300, 964-966.
11 G. Grigoropoulou, J. Clark and J. Elings, Green Chem., 2003,
5
, 1-7.
12 A. Russo, C. De Fusco and A. Lattanzi, ChemCatChem, 2012,
, 901-916.
4
13 K. Yamaguchi, K. Ebitani and K. Kaneda, J. Org. Chem., 1999,
64, 2966-2968.
14 U. R. Pillai, E. Sahle-Demessie and R. S. Varma, Tetrahedron
Lett., 2002, 43, 2909-2911.
15 M. Romero, J. Calles, M. Ocana and J. Gomez, Microporous
Mesoporous Mater., 2008, 111, 243-253.
16 E. Yoo, T. Okata, T. Akita, M. Kohyama, J. Nakamura and I.
Honma, Nano Lett., 2009, 9, 2255-2259.
17 X. Chen, G. Wu, J. Chen, X. Chen, Z. Xie and X. Wang, J. Am.
Chem. Soc., 2011, 133, 3693-3695.
Furthermore, the generality of this catalytic system was then
investigated under the optimized reaction conditions. As shown in
Table 2, styrene showed a conversion of 93.4% and selectivity of
81.4% (entry 1) and the epoxidation was also successfully carried
out on norbornene (entry 4). Anethole and allyl alcohol showed
relatively high conversion with lower selectivity (entries 2 and 5).
The conversion of isophorone and 1-octene were significantly lower
than other alkenes (entries 6 and 7), which possibly because weaker
electrophilic cycloaddition would occur in the epoxidation of
electron-deficient alkenes.
18 J. Li, C. y. Liu and Y. Liu, J. Mater. Chem., 2012, 22, 8426-
8430.
19 G. Williams, B. Seger and P. V. Kamat, ACS nano, 2008, 2,
1487-1491.
20 R. Nie, J. Shi, W. Du, W. Ning, Z. Hou and F. S. Xiao, J. Mater.
Chem. A, 2013, , 9037-9045.
21 S. M. Paek, E. Yoo and I. Honma, Nano Lett., 2008,
1
9
, 72-75.
22 B. Weng, J. Wu, N. Zhang and Y. J. Xu, Langmuir, 2014.
23 G. Zhou, D. W. Wang, L. C. Yin, N. Li, F. Li and H. M. Cheng,
Conclusions
In conclusion, we have demonstrated for the first time that
SnO2/RGO nanocomposite can be used as an excellent catalyst in
the epoxidation of alkenes with a combined oxidant of H2O2 (30
wt%) and acetonitrile. The catalyst is recyclable and stable, which
can be reused for at least ten times with no appreciable loss in its
catalytic activity. Furthermore, the XRD and TEM analyses of the
reused catalyst disclosed that the nanoparticles still dispersed
homogeneously on graphene sheets without any aggregation,
indicating the unique layered structure of graphene minimized the
aggregation problem effectively. Additionally, the use of H2O2 with
only 1.2 molar equivalents is another attractive advantage. Other
chemical reactions in this catalytic system are under investigation in
our laboratory.
Acs Nano, 2012,
24 B. Sun, Z. Jiang, D. Fang, K. Xu, Y. Pei, S. Yan, M. Qiao, K. Fan
and B. Zong, ChemCatChem, 2013, , 714-719.
25 H. Song, L. Zhang, C. He, Y. Qu, Y. Tian and Y. Lv, J. Mater.
Chem., 2011, 21, 5972-5977.
26 S. Gilje, S. Han, M. Wang, K. L. Wang and R. B. Kaner, Nano
Lett., 2007, 7, 3394-3398.
27 Y. Wang, I. Djerdj, B. Smarsly and M. Antonietti, Chem.
Mater., 2009, 21, 3202-3209.
28 Y. Li, X. Lv, J. Lu and J. Li, J. Phys. Chem. C, 2010, 114, 21770-
21774.
29 G. B. Payne, P. H. DEMING and P. H. WILLIAMS, J. Org.
Chem., 1961, 26, 659-663.
30 W. C. Frank, Tetrahedron: Asymmetry, 1998, 9, 3745-3749.
31 S. Ueno, K. Yoshida, K. Ebitani and K. Kaneda, Chem.
Commun., 1998, 295-296.
32 I. Kirm, F. Medina, X. Rodrıguez, Y. Cesteros, P. Salagre and J.
́
6, 3214-3223.
5
Sueiras, Appl. Catal., A, 2004, 272, 175-185.
33 W. Zheng, R. Tan, L. Zhao, Y. Chen, C. Xiong and D. Yin, RSC
Acknowledgements
Adv., 2014,
4, 11732-11739.
This work was supported by the NSFC (No: 21176213), and Zhejiang
Key Innovation Team of Green Pharmaceutical Technology (No:
2010R50043).
