Scutellarin derivatives as apoptosis inducers: design, synthesis and
biological evaluation
a
a
a
a
b,*
c
a,*
3
4
Tong Han , Jia Li , Jingjing Xue , He Li , Fanxing Xu , Keguang Cheng , Dahong Li , Zhanlin
a
d
a,∗
Li , Ming Gao and Huiming Hua
a
5
6
7
8
9
0
1
Key Laboratory of Structure-Based Drug Design & Discovery, Ministry of Education, and School of Traditional
Chinese Materia Medica, Shenyang Pharmaceutical University, 103 Wenhua Road, Shenyang 110016, China
b
Wuya College of Innovation, Shenyang Pharmaceutical University, 103 Wenhua Road, Shenyang 110016, China
c
State Key Laboratory for the Chemistry and Molecular Engineering of Medicinal Resources, and School of
Chemistry and Pharmacy, Guangxi Normal University, 15 Yucai Road, Guilin 541004, China
d
1
1
School of Pharmaceutical Sciences, Mukogawa Women’s University, 11-68 Koshien, Nishinomiya 663-8179,
Japan
12
13
14
15
16
17
18
19
20
21
∗
Corresponding authors. Tel.: +86-24-23986465; Fax: +86-24-23986465.
E-mail address: huimhua@163.com (H. Hua); lidahong0203@163.com (D. Li); fanxing0011@163.com (F. Xu).
1

ACCEPTED MANUSCRIPT
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
Abstract:
To explore novel antitumor agents with high efficiency and low toxicity, a series of
NO-donating scutellarin derivatives (14−17) were synthesized and the antiproliferative activities
against MCF-7, HCT-116, PC-3 and HepG2 cancer cell lines were assessed. Among them,
compound 14b was the strongest with IC50 values of 2.96 µM, 7.25 µM, 0.09 µM and 0.50 µM,
respectively, and displayed low toxicity against normal human liver L-O2 cells with an IC50 of
47.96 µM, showing good selectivity between normal and malignant liver cells. Moreover, NO
releasing ability of the derivatives has been studied. Mechanism studies of the most promising
compounds 14b and 15a were carried out. The results indicated that 14b and could induce
apoptosis, cell cycle arrest at the S phase and led to mitochondrial dysfunction in the HepG2 and
PC-3 cell lines, respectively. Furthermore, Human Apoptosis Protein Array kit assay demonstrated
that 14b could induce apoptosis through down-regulating the levels of procaspase-3 and inhibiting
the expression of survivin, c-IAP1, HSP27, HSP60, HSP70, HO-1/HMOX1/HSP32 and
HO-2/HMOX2 in HepG2 cell line. These results guaranteed compound 14b to be a drug candidate
against liver cancer for further investigation.
1
1
1
1
1
1
1
1
Key words: scutellarin, antiproliferative activity, selectivity, NO, apoptosis.
18
19
20
21
22
23
24
25
2

ACCEPTED MANUSCRIPT
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
1. Introduction
Natural products have been the major sources of chemical diversity for lead compounds,
inspiring for the research and development of new drugs [1,2]. According to the statistics, there
are nearly 51% of currently marketed drugs owing their origins to natural compounds [3].
Flavonoids, as a large class of natural products, are widely distributed in the plant kingdom as
secondary metabolites [4]. They show various biological activities, especially for the treatment of
cancer [5], cardiovascular diseases [6] and neurodegenerative disorders [7]. Moreover, flavonoids
are considered to exhibit positive impact on human health without significant side effects, since
they are also existed in fruits and vegetables which we consume inadvertently in our daily diet
[8,9].
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
Scutellarin, an extract from traditional Chinese herb Erigeron breviscapus (vant.) Hand-Mazz,
is the main effective flavonoid component of breviscapine [10]. It has been widely reported for the
treatment of cardiovascular diseases, such as hypertension [11], myocardial fibrosis [12,13] and
cardiomyocyte ischemia/reperfusion injury [14,15]. Recently, scutellarin was found to show
anticancer activity [16,17], which could suppress proliferation, migration and invasion of human
hepatocellular carcinoma cells via inhibiting the STAT3/Girdin/Akt activity [18,19]. There were
also accumulating evidences suggesting that scutellarin could significantly inhibit the growth,
adhesion and migration of human tongue squamous carcinoma cells by reducing the expression of
MMP-2, MMP-9 and integrin α β [20,21,22]. All these results demonstrated that scutellarin
v
6
possessed potent antitumor activities with great therapeutic potentials. However, some perceived
disadvantages of scutellarin limited its further application, mainly including low stability and poor
oral bioavailability [23]. In order to overcome these disadvantages, methyl and benzyl as
protective groups were introduced to 6-OH and 4′-OH in order to avoid oxidation, and the
antitumor activities of the modified derivatives could also be further improved since methyl and
benzyl groups were benefit to the antitumor activity of flavonoid derivatives according to the
literatures [24,25].
Nitric oxide (NO) is a low molecular weight signaling molecule and plays pivotal roles in
3

ACCEPTED MANUSCRIPT
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
diverse physiological and pathophysiological processes [26]. Over the past decade, NO has
aroused great interest as a potential antitumor agent [27]. The molecular mechanisms involved in
NO-mediated cell death are multiple. In general, high concentration of NO can induce apoptosis,
inhibit metastasis of tumor cells, and sensitize tumor cells to chemotherapy, radiation and
immunotherapy [28,29]. Some kinds of NO donors can produce high levels of NO with a wide
range of half-lives in vitro and in vivo, and have been widely used in drug research, especially the
types of furoxan and nitrate [29-31]. Furoxans are an important class of thermodynamically stable
NO donors. A variety of active compounds or natural products including bifendate, coumarin and
oleanolic acid have been hybrided with furoxan (Figure 1) and displayed potent antitumor
