Title: Bifunctional Pincer Catalysts for Chemoselective Transfer
Hydrogenation and Related Reactions
Authors: Shirel Cohen, Alexey N Bilyachenko, and Dmitri Gelman
This manuscript has been accepted after peer review and appears as an
Accepted Article online prior to editing, proofing, and formal publication
of the final Version of Record (VoR). This work is currently citable by
using the Digital Object Identifier (DOI) given below. The VoR will be
published online in Early View as soon as possible and may be different
to this Accepted Article as a result of editing. Readers should obtain
the VoR from the journal website shown below when it is published
to ensure accuracy of information. The authors are responsible for the
content of this Accepted Article.
To be cited as: Eur. J. Inorg. Chem. 10.1002/ejic.201801486
Link to VoR: http://dx.doi.org/10.1002/ejic.201801486

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Bifunctional Pincer Catalysts for
Chemoselective Transfer Hydrogenation and
Related Reactions
a
b,c
a,b
Shirel Cohen, Alexey N. Bilyachenko and Dmitri Gelman *
aInstitute of Chemistry, Edmond J. Safra Campus, The Hebrew University of Jerusalem,
b
Jerusalem, 91904 Israel. Peoples’ Friendship University of Russia (RUDN University), Miklukho-
c
Maklay St., 6, 117198 Moscow, Russia. A.N. Nesmeyanov Institute of Organoelement Compounds,
Russian Academy of Sciences, Vavilov Street 28, 119991 Moscow, Russia.
RECEIVED DATE
*
To whom correspondence should be addressed. E-mail: dmitri.gelman@mail.huji.ac.il. Fax
No. +972-2-6585279. https://scholars.huji.ac.il/dmitrigelman/home
Keywords: pincer complexes, transfer hydrogenation, formic acid.
ABSTRACT
A comparative study on the chemoselective transfer hydrogenation of nitroarenes to anilines
and related processes using FA as the hydrogen source is described; these processes are catalyzed by
a series of pincer catalysts equipped with different functional groups in the secondary coordination
sphere. Some new (4 and 5) as well as previously reported (1-3) catalysts belonging to the family of
3
bifunctional PC(sp )P pincer complexes were employed in this study The reported compounds
exhibited remarkably different catalytic activity behavior, depending on the nature of the functional
groups. Transfer hydrogenation of nitrobenzene with FA as a hydrogen source was probed using
1
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
iridium complexes 3 or 4 as a catalyst. Under the same conditions, the analogous palladium complex
was found to be useful for the selective amidation of aniline with light carboxylic acids.
2
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Introduction
It was previously demonstrated that artificial enzyme-mimicking catalysts, designed to possess
attractive interactions between the secondary coordination environment and the substrate, often
improve the chemo- and stereo-control of the catalyzed reaction. For example, a series of hydroxylated
ligands, developed independently by Bӧrner, Kagan, and others have shown that interactions between
the pendant hydroxyl group and functional groups of the substrates may govern enantioselectivity in
[
1]
hydrogenation reactions. More recently, Brudvig, and Crabtree described a bis-magnesium oxidation
catalyst possessing a Kemp's triacid-based ligand that anchors substrates via hydrogen bonding and
[2]
inverts selectivity in their oxidation. Another interesting example of regioselective C–H
functionalization controlled by the hydrogen bonds between an urea-based ligand and substrates was
[3]
proposed by Kanai and Kuninobu. The hydrogen-bonding ability of a guanidine-modified phosphine
ligand was employed by Breit and co-workers to improve the selectivity in the hydroformylation of
functional alkenes.[4] Exploiting electrostatic substrate-ligand attractions, Reek and co-workers
demonstrated excellent regioselectivity in the same and related transformations.[5] Nevertheless, the
number of systems exploiting this approach continues to grow.[6]
3
Recently, our group found an amine-functionalized pincer Ir(III)-PC(sp )P complex 1 (Scheme
1
) that proved to be a clean and efficient catalyst for FA hydrogenation. This catalyst displayed
superior performance over existing catalytic systems in neat formic acid because the key
decarboxylation step was facilitated by secondary ligand-substrate interactions between the
positively charged remote functionality and the negatively charged formate (Scheme 1) [
.
7]
3
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Scheme 1. Secondary ligand-substrate-attracting interactions stabilize the H-bound transition
state.
3
This catalyst belongs to a family of 3-dimensional PC(sp )P pincer complexes based on the
[
8]
dibenzobarrelene scaffold developed by our group . They are easily accessible via complementary
synthetic approaches, allowing structural diversity and facile synthesis of libraries of the functionalized
ligands and of their corresponding transition metal complexes (Scheme 2).[8a-f]
Scheme 2. Divergent synthesis allowing facile shuffling of functional groups in the primary and
secondary coordination spheres.
Here, we wish to determine the applicability of these catalytic systems to laboratory processes
and, in particular, to the chemoselective hydrogenation of nitroarenes to anilines and related processes
using FA as the hydrogen source; these processes are catalyzed by catalysts equipped with different
functional groups in the secondary coordination sphere.
4
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Results and discussions
Synthesis. In this study we decided to compare the reactivity of some previously reported (1-
) and new (4-5) bifunctional catalysts (Figure 1).
3
Figure 1. Catalysts used in this study.
Synthesis of complexes 1-3 was carried out as reported by us previously.[7, 9] For the synthesis
3
of 4-5, the PC(sp )P scaffold was modified according to Scheme 3 via sequential Diels-Alder
cycloaddition between 1,8-dibromooanthracene and diethyl fumarate, the LAH-promoted reduction of
the ester groups, methylation, and BuLi-mediated electrophilic phosphination. The methoxy-capped
ligand (L1) was prepared in >80% overall yield.
5
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Scheme 3. Synthesis of the new ligand and complexes 4-5.
3
1
1
The new ligand, L1, exhibits two doublet signals at -18.67 and -20.78 ppm in the P[ H] NMR
spectrum assigned to two slightly different phosphine groups (Jp-p = 40 Hz) and a phosphine-coupled
1
multiplet signal (at 6.84 ppm) in the H NMR spectrum corresponding to the methine proton spanned
by phosphine groups. The through-space H-P splitting[10] suggests that the phosphine groups point at
the front methine hydrogen.[11] A singlet assigned to the back methine hydrogen is found at 6.75 ppm.
Reacting L1 with a half equivalent of [Ir(COE)
2
Cl]
2
(COE =cyclooctene) at room temperature for 12
1
h in chloroform led to the formation of carbometalated species 4. It can be concluded from H NMR
that metalation occurs because of the disappearance of the characteristic signal assigned to the front
1
methine proton. The appearance of the typical Ir-hydride triplet was observed in the H NMR spectrum
3
1
1
at -19.92 ppm (JH-P = 9 Hz). The P[ H] NMR spectrum, however, displayed an expected low-field
shift in signals up to 25.64ppm.
6
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Scheme 4. Formation of 4. Selected bond lengths [Å] and angles [deg.]: C1–Ir1 (2.052(5)),
Ir1–P1 (2.221(15)), Ir1–P2 (2.263(15)), Ir1–O1 (2.206(4)); P1-Ir1-Cl1 (85.39(5)), C1-Ir1-P1
(83.45(15)), O1-Ir1-P1 (158.87(12)), P2-Ir1-O1 (88.97(12)), P2-Ir1-P1 (100.68(5)), and C1-Ir1-
Cl1(92.06(15)).
Single crystals of 4 were grown by diffusing n-hexane into a saturated chloroform solution
Scheme 3, right). The solid-state molecular structure analysis confirmed metalation of the ligand,
(
displaying an almost perfect octahedral geometry around the iridium center with a cis- and trans-
positioned chloride ligands: an Cl(1)-Ir(1)-Cl(2) angle of 86.47(5), an P(1)−Ir−P(2) angle of
1
00.68(5)°, an O(1)-Ir-Cl(2) angle of 92.36(11), and a C(1)−Ir−Cl(2) angle of 171.15(15)°. The
Ir−O(1) distance of 2.206(4) Å is a characteristic of coordinating oxygen.[12] The remaining distances
3
are within the usual range for iridium PC(sp )P pincer complexes of this type, which were
characterized by us in the past.[13] Fast hydride-chloride exchange upon exposure to chloroform
explains the absence of the expected hydride ligand (see the supporting information).
Coordination of methoxy-functionalized ligand L1 to PdCl
2
(CH
3
CN) in 1:1 ratio in
2
chloroform led to the 9:1 mixture of products that were separated by crystallization (Scheme 5). Thus,
the desired 5 was unequivocally identified by NMR, showing a characteristic disappearance of the
7
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
central methine hydrogen by H-NMR and a characteristic position of a pair of doublets at 44.93 and
4
9.04 ppm by P NMR. The minor product was identified as a quasi-closed halogen-bridged
3
1
dipalladium complex (6) possessing a nonplanar Pd
2
Cl site. The P-NMR spectrum of the new
4
product displayed two sharp singlets with a resonance frequency of 25.93 and 27.32 ppm, respectively,
showing no communication between the new phosphines. Indeed, the x-ray analysis of 6 revealed that
o
....
the Pd
2
Cl
4
core is bent (ca. 119 ) and that the corresponding Pd Pd distance is as short as 2.9607 Å.
On the other hand, incorporating the Pd
2
Cl unit between the phosphine donors results in a significant
4
.
...
increase in P P distance (5.497Å), leading to the absence of P-P splitting. We have observed the
formation of such complexes previously; it can be controlled by limiting the concentration of the
starting materials – as we described previously, high-dilution conditions avoid or reduce their
appearance.[14]
Scheme 5. Formation of 5 and 6. ORTEP drawing of 6 (50% probability ellipsoids). Hydrogen atoms
and solvent molecules are omitted for clarity. Selected bond lengths (Å) and angles (deg.): Cl(1)-Pd(1)
2
2
2
.3380(9), Cl(1)-Pd(2) 2.3205(9), Cl(2)-Pd(2) 2.4203(9), Cl(2)-Pd(1) 2.4223(10), Cl(3)-Pd(1)
.2698(10), Cl(4)-Pd(2) 2.2844(10), P(1)-Pd(1) 2.2289(10), P(2)-Pd(2) 2.2224(10), Pd(1)-Pd(2)
.9607(5), P(1)-Pd(1)-Cl(3) 87.71(4), P(1)-Pd(1)-Cl(2) 95.43(4), Cl(3)-Pd(1)-Cl(2) 176.84(3), P(1)-
Pd(1)-Cl(1) 174.31(4), Cl(3)-Pd(1)-Cl(1) 91.90(4), Cl(2)-Pd(1)-Cl(1) 84.94(3), P(1)-Pd(1)-Pd(2)
24.02(3), Cl(3)-Pd(1)-Pd(2) 127.44(3), Cl(2)-Pd(1)-Pd(2) 50.28(2), Cl(1)-Pd(1)-Pd(2) 52.34(2),
1
P(2)-Pd(2)-Cl(4) 87.75(4), P(2)-Pd(2)-Cl(2) 94.76(3), Cl(4)-Pd(2)-Cl(2) 177.48(3), P(2)-Pd(2)-Cl(1)
8
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
1
76.65(3), Cl(4)-Pd(2)-Cl(1) 92.22(3), Cl(2)-Pd(2)-Cl(1) 85.27(2), P(2)-Pd(2)-Pd(1) 125.45(2), Cl(4)-
Pd(2)-Pd(1) 127.54(3), Cl(2)-Pd(2)-Pd(1) 50.80(2), and Cl(1)-Pd(2)-Pd(1) 52.28(2).
Catalysis. Based on the efficient decomposition of formic acid by some of our complexes, we
decided to focus on some generic transformations utilizing formic acid as a hydrogen source, such as
the transfer hydrogenation of nitroarenes. Anilines are very common intermediates for the synthesis of
fine chemicals including biologically active molecules, natural products, dyes, agrochemicals, and raw
chemicals.[15] Various more or less laborious methods for their preparation are available; however, the
reduction of nitroarenes (which, in turn, can be readily obtained from very cheap precursors) is the
most straightforward method both in laboratory and industrial settings. The reduction can be cleanly
performed catalytically using molecular hydrogen as a reductant.[16] However, owing to the difficulty
of handling hazardous hydrogen gas and the need for a special infrastructure, these methods are not
feasible on a large scale. In contrast, catalytic or non-catalytic reduction systems utilizing
(over)stoichiometric reducing agents such as metallic zinc, metallic iron, sulfides, metal hydrides, or
hydrazines are routinely employed. Although safer, these stoichiometric systems are environmentally
expensive, since the reducing agents themselves and their wastes, which are used, are hazardous and
are difficult to dispose of.[17] Consequently, a great deal of research has been dedicated to developing
practical and operationally simple protocols that use environmentally friendly reductants. For example,
heterogeneously or homogeneously catalyzed transfer hydrogenation, which employs cheap, safe, and
sustainable isopropanol or formic acid as hydrogen surrogates, were tested.[17k, 18] Some promising
examples of homogeneous transfer hydrogenation of nitroarenes using iron[19], ruthenium,[20] cobalt,[21]
and molybdenum[22] catalysts are paving the way to the development of an environmentally benign,
sustainable, and waste-economical industry. Despite this progress, the efficiency of homogeneous
transfer hydrogenation of nitro groups needs to be improved, especially in terms of chemoselectivity
because the desired reduction of nitroarenes to amines is often accompanied by incomplete reductions
9
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
to hydroxylamines or azocompounds, as well as a competitive reduction of vulnerable functional
groups such as halides, carbonyls, or nitriles.[23]
Our initial experiments included attempts to accomplish hydrogenation of nitrobenzene using
different hydrogen sources in the presence of 1 mol% of iridium-based complexes bearing ligands with
different pendant groups: an acidic CO
2
H- and OH-containing (1 and 2, respectively), a basic NH -
2
containing 3 and a neutral MeO-containing 4 (Table 1). Upon examination of various
solvent/temperature/base/hydrogen source combinations, a general trend was realized: catalysts 1 and
2
were the least active in the presence of both neat formic acid and formic acid/TEA azeotrope (entries
1
-2 and 5-6). On the other hand, the amino- functionalized complex 3 displayed moderate conversion,
although excellent selectivity when two equivalents of formic acid were used as the hydrogen source.
Noteworthy, the lower conversions, observed in the presence of 3, are because the HCOOH
decomposition rate catalyzed by this complex is significantly higher than the rate of the successive
hydrogenation; however, complete conversions could be achieved only with a large excess of FA.[24]
On the other hand, only moderate selectivity was observed in the reaction catalyzed by 4 under the
same conditions. However, significantly better results were obtained when HCOOH/NEt
replaced formic acid. Under these conditions, complete conversion of the model nitrobenzene into
aniline with excellent selectivity was achieved using only 2 equivalents of HCOOH/NEt and 3 as a
catalyst, whereas the MeO-modified 4 drove the reaction aniline at a more modest conversion rate
68%) but with still excellent selectivity, spotting 3 and 4 as suitable catalysts for this reaction.
3
azeotrope
3
(
Replacing FA by IPA leads to much lower conversion (Table 1, entries 9-10). Furthermore, we found
that our catalytic system is very stable in air and that the reaction can be performed without rigorous
exclusion of oxygen. Only slightly reduced yields were observed when air- and nitrogen-filled
reactions were run side by side.
1
0
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Table 1. Representative optimization experiments.
N
Conditionsa
Conversionb Selectivity to anilineb
1
2
3
4
5
6
1, FA, DME
23%
50%
56%
86%
24%
39%
N/D
N/D
99%
82%
N/D
N/D
2, FA, DME
3, FA, DME
4, FA, DME
1, FA/TEA, DME
2, FA/TEA, DME
7
8
9
3, FA/TEA, DME
4, FA/TEA, DME
99%
68%
9%
99%
99%
N/D
N/D
3, IPA/K
4, IPA/K
2
2
CO
3
3
, DME
, DME
1
0
CO
<1
a
Reaction conditions: 1 mmol of the catalyst 1-4, 2 eq of FA/0.25 eq. of the additive, 2 ml of DME.
°
b
Sealed outoclave.60-80 C. Based on NMR with an internal standard.
Next, we investigated the general applicability of our catalyst system. To explore the functional
group tolerance in more detail, we started to investigate the reactions of different substituted
nitroarenes (Table 2). Thus, electron-neutral nitrobenzenes were fully converted to the corresponding
anilines (Table 2, entries a-b) in a clean and efficient fashion. Similarly, electron-rich p-nitroaniline
was hydrogenated in 92% yield and excellent selectivity to p-diaminobenzene without side reactions
such as polymerization or condensation between the nitro and amine groups, which form azo
compounds (Table 2, entry d). Nitrobenzenes bearing electron-deficient substituents such as o- and p-
nitrochlorobenene led to excellent yields of the corresponding anilines as well (Table 2, entries i-j). In
contrast, cyano-, amide-, ester-, or keto-substituted nitrobenzenes displayed generally good to
excellent conversions but moderate chemoselectivity owing to partial reduction of the vulnerable
1
1
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
functional groups. Fortunately, employing catalyst 4 in place of the more reactive 3 greatly improved
the chemoselectivity (Table 2, entries e-h). Finally, an attempted hydrogenation of 2-nitrostyrene
revealed a relatively poor chemoselectivity and was accompanied by a partially hydrogenated double
bond.
Table 2. Representative hydrogenation and hydrogenation-alkylation of nitroarenes using FA/TEA
and catalyzed by 3 and 4.
a
b
Isolated yield, % (selectivity, %). Using catalyst 3. Using catalyst 4. General reaction conditions: 6
mg of 3/4 added to 5 mmol of the nitro compound, 10 mmol of FA/TEA and 2 ml of DME.
1
2
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Based on the more chemoselective transfer hydrogenation of nitroarenes possessing carbonyl
functions, using 4 as a catalyst, we attempted a one-pot transfer hydrogenation-reductive amination of
ketones, which is considered as one of the straightforward and convenient methods to prepare alkylated
amines.[25] Traditional methods largely rely on stoichiometric amounts of boron-,[26] tin-,[27] and silane-
[
28]
based reductants; however, they are costly and usually give rise to over-alkylation or the formation
of toxic wastes. Some reductive amination methodologies were also reported by using a gas reductant
, but mostly under very harsh conditions.[29]
such as CO and H
2
Initially, we tested a reaction of nitrobenzene in the presence of a 1.1 equivalent of
o
acetophenone, 3 equivalents of FA/TEA, and 0.1 mol% of 4 as a catalyst in DME at 90 C. We were
happy to realize that under these conditions, the one-pot three-step reaction goes to completion and the
desired product k was isolated in 96% yield. The reactions proceeded very well to afford the desired
products in excellent yields using nitrobenzene-fluorenone (Table 2, l), and the substituted
nitrobenzene-acetone mixtures (Table 2, m-n).
It was previously speculated that reactivity in such a bifunctional catalyst possessing additional
coordination spheres is rather ligand-centered, whereas the identity of the metal at the catalytic site
plays a secondary role. Thus, we tested the new palladium pincer complex 5 as a catalyst in these
reactions, seeking to observe similar behavior. Thus, in the first experiment we attempted transfer
hydrogenation of nitrobenzene with FA/TEA azeotrope under the previously described conditions
(Scheme 6, top). However, the conversion of the starting material was rather low, and the only product
identified from this reaction was formanilide, which resulted from a partial transfer hydrogenation of
nitrobenzene and subsequently, direct amide formation with excessive formic acid (Scheme 5, top).
The amide bond is very common in both naturally occurring and synthetic compounds. It is
increasingly important in pharmaceutical chemistry, being present in many of the available drugs;
1
3
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
therefore, amidation reactions are among the most important reactions in medicinal chemistry,
especially those allowing direct amidation of carboxylic acids.[30] Therefore, in the next experiment
o
we exposed aniline to pure formic acid and FA/TEA azeotrope (2 equiv.) in DME at 80 C in the
presence of 0.1 mol% of 5. The reaction resulted in the quantitative formation of the amide product
after 12 hours in both cases. A similar experiment with acetic acid resulted in the formation of the
corresponding acetanilide in a quantitative yield. The scope and limitation as well as mechanistic
studies of the reaction are currently underway and will be reported soon.
Scheme 6. Direct amidation reaction catalyzed by 5. General reaction conditions: 6 mg of 5 added to
7
mmol of the nitro/amine compound, 14 mmol of FA/TEA or acetic acid and 2 ml of DME.
3
In conclusion, we synthesized and characterized a series of new PC(sp )P pincer ligands
bearing different functional groups in the secondary coordination sphere. Their coordination chemistry
1
4
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
and the catalytic properties of the corresponding iridium and palladium complexes were studied. The
new compounds exhibited remarkably different catalytic activity behavior, depending on the nature of
the functional groups. Transfer hydrogenation of nitrobenzene with FA as a hydrogen source was
probed using iridium complexes 3 or 4 as a catalyst. Under the same conditions, the parallel palladium
complex was found to be useful for the selective amidation of aniline with light carboxylic acids.
Experimental Section
General Considerations. All manipulations were performed using standard Schlenk techniques under
dry N or Ar. All reagents were purchased from the usual suppliers and used without further
2
purification. All reagents were weighed and handled in air. Flash column chromatography was
performed with Merck ultra pure silica gel (230-400 mesh). All catalytic reactions were carried out
under N
2
. Yields refer to isolated compounds greater than 95% purity as determined proton Nuclear
1
Magnetic Resonance spectroscopy ( H-NMR) analysis. The CAS numbers of the known compound
were listed. Spectroscopy data of the known compounds matches with the data reported in the
1
13
31
corresponding reference. H-, C- and P-NMR spectra were recorded on a Bruker 400 or 500 MHz
instruments with chemical shifts reported in ppm relative to the residual deuterated solvent or the
internal standard tetramethylsilane.
Synthesis of the ligand L1: 1,8-bis-dibromoanthracene (2.35 g, 7 mmol) and diethyl fumarate (1.4
mL, 8.4 mmol) in 25 mL of xylene were heated under reflux overnight. The solvent was evaporated,
and methanol was added to precipitate the crude product. The white solid was filtered, washed with
methanol and dried on vacuum affording 2.45 g (69%) of the desired diester adduct.
1H-NMR (CDCl
),δ: 1.22 (t, 3H, J = 8 Hz), 1.31 (t, 3H, J = 8 Hz), 3.41 (dd, 1H, J =15 Hz, J =3 Hz),3.41
3
(dd, 1H, J =25 Hz, J =3 Hz), 4.02 (m, 4H), 4.75 (d, 1H, J =3Hz), 5.72 (d, 1H , J =3 Hz), 6.95 (m, 2H),
1
5
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
7
.18(d, 1H, J =8 Hz), 7.28(m, 3H). Anal. Calcd. For C22
H, 3.93.
The solution of the diester obtained in the previous step (0.53 g, 1 mmol) and LiAlH
H
20Br
2
O
4
: C, 51.99; H, 3.97. Found: C, 52.06;
4
(0.23g, 6 mmol)
in 20 ml of dry ether was stirred for 12 hours under Ar. Then 1M solution of HCl was added carefully.
The aqueous phase was extracted 3 times with ethyl acetate. The combined organic phases were dried
over sodium sulfate, filtered and evaporated. The product was rinsed with methanol and dried affording
0
.3 g (56%) of the diol intermediate as a white solid.
1H-NMR (DMSO-d
), δ: 1.24(br, 1H), 1.34 (br, 1H), 2.67 (m, 1H), 2.87 (m, 1H), 3.05 (m, 1H), 3.15(m,
6
1
H), 4.5 (d, 1H, J = 2 Hz), 4.69 (t, 1H, J = 4 Hz), 4.77 (t, 1H, J = 4 Hz), 5.18 (d, 1H, J = 2 Hz), 7.08
(t, 2H, J = 8 Hz), 7.16-7.32 (m, 4H).
The diol prepared in the previous step (1.65 gr, 2.6 mmol) was stirred in 20 ml of dry THF with the
addition of NaH (60% dispersion in silicon oil, 0.26 gr, 6.5 mmol) for 30 min. After the color changes
to brown, MeI (0.8 ml, 13 mmol) was slowly added to the solution. The mixture was stirred for 24 h.
After washings with aqueous HCl and evaporation of the solvent, a brown oily liquid obtained. The
product was crystallized from MeOH to give 0.68 gr of the methylated derivative (54% yield).
1H-NMR (CDCl
), δ: 1.53 (m, 1H), 1.59 (m, 1H), 2.68 (t, 1H, J = 9), 2.98 (t, 1H, J = 9), 3.05 (dd, 1H,
3
J = 9 Hz, J = 6Hz), 3.18 (dd, 1H, J = 10 Hz, J = 5Hz), 3.31 (s, 3H) 3.33 (s, 3H), 4.4 (d, 1H, J = 2 Hz),
5
5
.32 (d, 1H, J = 2 Hz), 6.99 (m, 2H), 7.22 (m, 2H) ,7.35 (m, 2H). Anal. Calcd. For C20
H20Br
2
2
O : C,
3.12; H, 4.46. Found: C, 53.07; H, 4.50.
1
ml (2.6 mmol) of BuLi (2.5 M in hexane) was slowly added to the THF solution of the methylated
derivative prepared in the previous step (0.82 gr, 1.2 mmol) at -78 C. After 20 min of stirring, ClPPh
2
(0.6 ml, 2.6 mmol) was added to the solution. The mixture was stirred for 2 hours. After washings with
1
6
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
saturated solution of sodium bicarbonate and evaporation of the solvent, an oily liquid was obtained.
The product was crystallized from MeOH to give 0.3 gr of the desired L1 (40% yield).
1H-NMR (CDCl
), δ: 2.446 (dd, 1H, J = 9Hz), 2.56 (dd, 1H, J = 9Hz), 2.73 (dd, 1H, J = Hz, J = 6Hz),
3
2
.81 (s, 3H), 3.17 (m, 1H), 3.32 (s, 3H), 4.45(m, 1H), 6.01 (m, 1H), 6.75(qd, 1H, J = 4Hz, J = 3Hz, J
3
1
=
1Hz), 6.84 (dq, 1H, J = 4Hz, J = 3Hz, J = 1Hz), 7.0-7.07 (m, 4H), 7.12-7.39 (m, 22H). PNMR
+
(CDCl
3
), δ: -18.67 (d, J = 40 Hz), -20.78 (d, J = 40 Hz). HRMS (ESI) Calcd for [M+H] 662.7347,
found 662.7349.
Synthesis of the complexes 4 and 5. A solution of the L1 (50 mg, 0.075 mmol) and IrCl(COE) (33.8
2
mg, 0.075 mmol) or PdCl
2
(CH
3
CN) (19.6 mg, 0.075 mmol) in toluene was stirred for 12 hr at room
2
temperature under Ar. Evaporation of the solvent the complex as a white solid (90%).
1H-NMR (DMSO-d
6
), δ: -19.92 (t, 1H, JP-H = 9 Hz), 0.22 (m, 1H), 1.20 (t, 1H, J = 8Hz), 1.28 (m,
1
H),1.39 (t, 1H, J = 8Hz), 2.23 (s, 3H), 2.3 (s, 1H), 2.4 (dd, 1H, J = 7 Hz, J = 3Hz), 2.93(s, 3H), 3.04
3
1
(
dd, 1H, J = 7 Hz, J = 3Hz), 4.37(s, 1H), 7.07-7.6 (m, 20H), 7.79 (s, 1H), 8.12 (s, 1H). PNMR (DMSO-
), δ: 25.64 (dd, J = 66 Hz, J = 25Hz). Anal. Calcd. For C44 IrO : C, 57.14; H, 4.25. Found:
C, 57.21; H, 4.29.
d
6
H39Cl
2
P
2 2
Supporting Information: Supporting Information: (see footnote on the first page of this article): NMR
spectra, crystallographic spectral data concerning organic reactions are given in the Supporting
Information
1
7
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Acknowledgments
This research was supported by ISF (Israel Science Foundation) Grant Nos. 917/15 and
384/13. We wish to thank Dr. Benny Boguslavsky for solving the X-ray structures (CCDC 1888575
1
and CCDC 1888576). The authors declare no competing financial interests.
References
[
1]
a) J. Holz, R. Sturmer, U. Schmidt, H.-J. Drexler, D. Heller, H.-P. Krimmer, A. Borner, Eur.
J. Org. Chem. 2001, 4615-4624; b) A. Borner, Eur. J. Inorg. Chem. 2001, 327-337.
S. Das, C. D. Incarvito, R. H. Crabtree, G. W. Brudvig, Science 2006, 312, 1941-1943.
Y. Kuninobu, H. Ida, M. Nishi, M. Kanai, Nat. Chem. 2015, 7, 712.
[
[
[
2]
3]
4]
a) T. Smejkal, D. Gribkov, J. Geier, M. Keller, B. Breit, Chem. - Eur. J. 2010, 16, 2470-2478;
b) D. Fuchs, G. Rousseau, L. Diab, U. Gellrich, B. Breit, Angew. Chem., Int. Ed. 2012, 51,
2
178-2182.
[
[
5]
6]
S. S. Nurttila, P. R. Linnebank, T. Krachko, J. N. H. Reek, ACS Catalysis 2018, 8, 3469-3488.
a) B. Zhao, Z. Han, K. Ding, Angew. Chem., Int. Ed. 2013, 52, 4744-4788; b) Q. Zhao, S. Li,
K. Huang, R. Wang, X. Zhang, Org. Lett. 2013, 15, 4014-4017; c) F. Voss, E. Herdtweck, T.
Bach, Chem. Commun. 2011, 47, 2137-2139; d) K.-N. T. Tseng, J. W. Kampf, N. K. Szymczak,
ACS Catal. 2015, 5, 5468-5485; e) C. Chen, Z. Zhang, S. Jin, X. Fan, M. Geng, Y. Zhou, S.
Wen, X. Wang, L. W. Chung, X.-Q. Dong, X. Zhang, Angew. Chem., Int. Ed. 2017, 56, 6808-
6
812; f) V. S. Koshti, A. Sen, D. Shinde, S. H. Chikkali, Dalton Trans. 2017, 46, 13966-13973.
S. Cohen, V. Borin, I. Schapiro, S. Musa, S. De-Botton, N. V. Belkova, D. Gelman, ACS Catal.
017, 7, 8139-8146.
[
[
7]
8]
2
a) C. Azerraf, D. Gelman, Chem. - Eur. J. 2008, 14, 10364-10368; b) C. Azerraf, D. Gelman,
Organometallics 2009, 28, 6578-6584; c) C. Azerraf, A. Shpruhman, D. Gelman, Chem.
1
8
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Commun. 2009, 466-468; d) D. Gelman, S. Musa, ACS Catal. 2012, 2, 2456-2466; e) D.
Gelman, R. Romm, Top. Organomet. Chem. 2013, 40, 289-318; f) O. Cohen, O. Grossman, L.
Vaccaro, D. Gelman, J. Organomet. Chem. 2014, 750, 13-16; g) C. Azerraf, O. Grossman, D.
Gelman, J. Organomet. Chem. 2007, 692, 761-767; h) L. Kaganovsky, K.-B. Cho, D. Gelman,
Organometallics 2008, 27, 5139-5145; i) R. Levy, C. Azerraf, D. Gelman, K. Rueck-Braun, P.
N. Kapoor, Catal. Commun. 2009, 11, 298-301.
[
[
9]
S. Musa, I. Shaposhnikov, S. Cohen, D. Gelman, Angew.Chem., Int. Ed. 2011, 50, 3533-3537.
10] a) J.-C. Hierso, A. Fihri, V. V. Ivanov, B. Hanquet, N. Pirio, B. Donnadieu, B. Rebière, R.
Amardeil, P. Meunier, J. Am. Chem. Soc. 2004, 126, 11077-11087; b) M. W. Haenel, H.
Fieseler, D. Jakubik, B. Gabor, R. Goddard, C. Krüger, Tetrahedron Lett. 1993, 34, 2107-2110;
c) J. Blum, D. Gelman, Z. Aizenshtat, S. Wernik, H. Schumann, Tetrahedron Lett. 1998, 39,
5
611-5614; d) N. Jaber, D. Gelman, H. Schumann, S. Dechert, J. Blum, Eur. J. Org. Chem.
002, 1628-1633.
2
[
11] The spatial interaction with the phosphines lone pairs similarly affects the bridghead carbon
1
3
showing a triplet signal around 43 ppm with a wide coupling constant of about 21 Hz by C
NMR.
[
[
12] D. C. Babbini, V. M. Iluc, Organometallics 2015, 34, 3141-3151.
13] a) H. Schumann, O. Stenzel, S. Dechert, F. Girgsdies, J. Blum, D. Gelman, R. L. Halterman,
Eur. J. Inorg. Chem. 2002, 211-219; b) G. A. Silantyev, O. A. Filippov, S. Musa, D. Gelman,
N. V. Belkova, K. Weisz, L. M. Epstein, E. S. Shubina, Organometallics 2014, 33, 5964-5973;
c) S. De-Botton, R. Romm, G. Bensoussan, M. Hitrik, S. Musa, D. Gelman, Dalton Trans.
2
016, 45, 16040-16046.
[
14] a) C. Azerraf, S. Cohen, D. Gelman, Inorg. Chem. 2006, 45, 7010-7017; b) O. Grossman, C.
Azerraf, D. Gelman, Organometallics 2006, 25, 375-381.
1
9
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
[
[
15] a) The Nitro Group in Org anic Synthesis (Ed.: N. Ono), Wiley-VCH, NewYork, 2001; b) R.
S. Downing, P. J. Kunkeler, H. van Bekkum , Catal. Today 1997, 37, 121-136;
16] a) S. Cai, H. Duan, H. Rong, D. Wang, L. Li, W. He, Y. Li, ACS Catal. 2013, 3, 608-612; b)
G. N. Bondarenko, I. P. Beletskaya, Mendeleev Commun. 2015, 25, 443-445; c) X. Yang, H.
Zhao, S. Gao, Ind. Eng. Chem. Res. 2017, 56, 3429-3435; d) T.-N. Ye, Y. Lu, J. Li, T. Nakao,
H. Yang, T. Tada, M. Kitano, H. Hosono, J. Am. Chem. Soc. 2017, 139, 17089-17097.
17] a) H. Mahdavi, B. Tamami, Synth. Commun. 2005, 35, 1121-1127; b) Q. Shi, R. Lu, K. Jin, Z.
Zhang, D. Zhao, Green Chem. 2006, 8, 868-870; c) U. Sharma, P. Kumar, N. Kumar, V.
Kumar, B. Singh, Adv. Synth. Catal. 2010, 352, 1834-1840; d) S. Kim, E. Kim, B. M. Kim,
Chem.- Asian J. 2011, 6, 1921-1925; e) V. Macho, L. Vojček, M. Schmidtová, M. Haruštiak,
J. Mol. Catal. 1994, 88, 177-184; f) H. S. Wilkinson, G. J. Tanoury, S. A. Wald, C. H.
Senanayake, Tetrahedron Lett. 2001, 42, 167-170; g) K. Layek, M. L. Kantam, M. Shirai, D.
Nishio-Hamane, T. Sasaki, H. Maheswaran, Green Chem. 2012, 14, 3164-3174; h) H.-S. Shin,
S. Huh, ACS Appl. Mater. Interfaces 2012, 4, 6324-6331; i) W. Du, G. Chen, R. Nie, Y. Li, Z.
Hou, Catal. Commun. 2013, 41, 56-59; j) M. M. Dell'Anna, S. Intini, G. Romanazzi, A. Rizzuti,
C. Leonelli, F. Piccinni, P. Mastrorilli, J. Mol. Catal. A: Chem. 2014, 395, 307-314; k) S.
Fountoulaki, V. Daikopoulou, P. L. Gkizis, I. Tamiolakis, G. S. Armatas, I. N. Lykakis, ACS
Catal. 2014, 4, 3504-3511; l) S. Ganji, S. S. Enumula, R. K. Marella, K. S. R. Rao, D. R. Burri,
Catal. Sci. Technol. 2014, 4, 1813-1819; m) W.-G. Jia, H. Zhang, T. Zhang, S. Ling, Inorg.
Chem. Commun. 2016, 66, 15-18; n) Y. Liu, Y. Lu, M. Prashad, O. Repič, J. Blacklock Thomas,
Adv. Synth. Catal. 2005, 347, 217-219.
[
[
18] a) I. Sorribes, G. Wienhofer, C. Vicent, K. Junge, R. Llusar, M. Beller, Angew. Chem., Int. Ed.
2
012, 51, 7794-7798; b) H. Wei, X. Liu, A. Wang, L. Zhang, B. Qiao, X. Yang, Y. Huang, S.
Miao, J. Liu, T. Zhang, Nat. Commun. 2014, 5, 5634; c) S. Dayan, F. Arslan, N. Kalaycioglu
Ozpozan, Appl. Catal., B 2015, 164, 305-315; d) R. V. Jagadeesh, K. Natte, H. Junge, M.
2
0
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
Beller, ACS Catal. 2015, 5, 1526-1529; e) C. Jiang, Z. Shang, X. Liang, ACS Catal. 2015, 5,
814-4818; f) K. J. Datta, A. K. Rathi, M. B. Gawande, V. Ranc, G. Zoppellaro, R. S. Varma,
4
R. Zboril, ChemCatChem 2016, 8, 2298; g) N. M. Patil, T. Sasaki, B. M. Bhanage, ACS Sus.
Chem. Eng. 2016, 4, 429-436; h) X. Cui, Y. Long, X. Zhou, G. Yu, J. Yang, M. Yuan, J. Ma,
Z. Dong, Green Chem. 2018, 20, 1121-1130; i) X. Liu, C. Wang, S. Cheng, N. Shang, S. Gao,
C. Feng, C. Wang, Y. Qiao, Z. Wang, Catal. Commun. 2018, 108, 103-107; j) Y. Zhu, S. Yang,
C. Cao, W. Song, L.-J. Wan, Inorg. Chem. Front. 2018,5, 1094-1099; k) M. B. Gawande, A.
K. Rathi, P. S. Branco, I. D. Nogueira, A. Velhinho, J. J. Shrikhande, U. U. Indulkar, R. V.
Jayaram, C. A. A. Ghumman, N. Bundaleski, O. M. N. D. Teodoro, Chem. - Eur. J. 2012, 18,
1
2628-12632; l) P. Lara, K. Philippot, Catal. Sci. Technol. 2014, 4, 2445-2465; m) K.-i.
Shimizu, Catal. Sci. Technol. 2015, 5, 1412-1427; n) G. Vile, D. Albani, N. Almora-Barrios,
N. Lopez, J. Perez-Ramirez, ChemCatChem 2016, 8, 21-33.
[
19] G. Wienhoefer, I. Sorribes, A. Boddien, F. Westerhaus, K. Junge, H. Junge, R. Llusar, M.
Beller, J. Am. Chem. Soc. 2011, 133, 12875-12879.
[
[
20] W.-G. Jia, S. Ling, H.-N. Zhang, E.-H. Sheng, R. Lee, Organometallics 2018, 37, 40-47.
21] B. Sahoo, D. Formenti, C. Topf, S. Bachmann, M. Scalone, K. Junge, M. Beller,
ChemSusChem 2017, 10, 3035-3039.
[
[
22] R. Rubio-Presa, M. R. Pedrosa, M. A. Fernandez-Rodriguez, F. J. Arnaiz, R. Sanz, Org. Lett.
2
017, 19, 5470-5473.
23] a) I. Sorribes, G. Wienhoefer, C. Vicent, K. Junge, R. Llusar, M. Beller, Angew. Chem., Int.
Ed. 2012, 51, 7794-7798; b) E. Pedrajas, I. Sorribes, A. L. Gushchin, Y. A. Laricheva, K.
Junge, M. Beller, R. Llusar, ChemCatChem 2017, 9, 1128-1134; c) A. Corma, C. González-
Arellano, M. Iglesias, F. Sánchez, App. Catal. A: General 2009, 356, 99-102; d) V. R.
Choudhary, M. G. Sane, J. Chem. Tech. Biotech. 1998, 73, 336-340.
2
1
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
[
[
24] The manuscript describing detailed studies of the formic acid dehydrogenation is under
preparation.
25] a) A. F. Abdel-Magid and S. J. Mehrman, Org. Process Res. Dev., 2006, 10, 971–1031; b) T.
Gross, A. M. Seayad, M. Ahmad and M. Beller, Org. Lett., 2002, 4, 2055–2058; c) M. Zhang,
H. Yang, Y. Zhang, C. Zhu, W. Li, Y. Cheng and H. Hu, Chem. Commun., 2011, 47, 6605–
6
2
607; d) D. Talwar, N. P. Salguero, C. M. Robertson and J. Xiao, Chem. – Eur. J., 2014, 20,
45–252; e) S. Werkmeister, K. Junge and M. Beller, Green Chem., 2012, 14, 2371–2374; f)
D. Menche, J. Hassfeld, J. Li, G. Menche, A. Ritter and S. Rudolph, Org. Lett., 2006, 8, 741–
44; g) K. Saito andT. Akiyama, Chem. Commun., 2012, 48, 4573–4575
7
[
26] a) M. Horn, H. Mayr, E. Lacôte, E. Merling, J. Deaner, S. Wells, T. McFadden and D. P.
Curran, Org. Lett., 2012, 14, 82–85; b) W. Liao, Y. Chen, Y. Liu, H. Duan, J. L. Petersen and
X. Shi, Chem. Commun., 2009, 6436–6438; c) E. M. Dangerfield, C. H. Plunkett, A. L. Win-
Mason, B. L. Stocker and M. S. M. Timmer, J. Org. Chem., 2010, 75, 5470–5477.
[
[
27] a) P. D. Pham, P. Bertus and S. Legoupy, Chem. Commun., 2009, 6207–6209; b) H. Kato, I.
Shibata, Y. Yasaka, S. Tsunoi, M. Yasuda and A. Baba, Chem. Commun., 2006, 4189–4191.
28] a) O.-Y. Lee, K.-L. Law, C.-Y. Ho and D. Yang, J. Org. Chem., 2008, 73, 8829–8837; b) T.
Mizuta, S. Sakaguchi and Y. Ishii, J. Org. Chem., 2005, 70, 2195–2199; c) O.-Y. Lee, K.-L.
Law and D. Yang, Org. Lett., 2009, 11, 3302–3305.
[
29] a) J. W. Park and Y. K. Chung, ACS Catal., 2015, 5, 4846–4850; b) D. Chusov and B. List,
Angew. Chem., Int. Ed., 2014, 53, 5199–5201; c) M. Chang, S. Liu, K. Huang and X. Zhang,
Org. Lett., 2013, 15, 4354–4357; d) A. Pagnoux-Ozherelyeva, N. Pannetier, M. D. Mbaye, S.
Gaillard and J.-L. Renaud, Angew. Chem., Int. Ed., 2012, 51, 4976–4980; e) S. Fleischer, S.
Zhou, K. Junge and M. Beller, Chem. – Asian J., 2011, 6, 2240–2245; f) D. B. Bagal, R. A.
Watile, M. V. Khedkar, K. P. Dhake and B. M. Bhanage, Catal. Sci. Technol., 2012, 2, 354–
2
2
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
3
58; g) A. S. Touchy, S. M. A. Hakim Siddiki, K. Kon and K.-i. Shimizu, ACS Catal., 2014,
, 3045–3050.
4
[
30] a) Carey, J. S.; Laffan, D.; Thomson, C.; Williams, M. T. Org. Biomol. Chem. 2006, 4,
337−2347. b) Amarnath, L.; Andrews, I.; Bandichhor, R.; Bhattacharya, A.; Dunn, P.; Hayler,
2
J.; Hinkley, W.; Holub, N.; Hughes, D.; Humphreys, L.; Kaptein, B.; Krishnen, H.; Lorenz, K.;
Mathew, S.; Nagaraju, G.; Rammeloo, T.; Richardson, P.; Wang, L.; Wells, A.; White, T. Org.
Process Res. Dev. 2012, 16, 535−544.
2
3
This article is protected by copyright. All rights reserved.

European Journal of Inorganic Chemistry
10.1002/ejic.201801486
A comparative study on the transfer hydrogenation of nitroarenes with formic acid catalyzed by a
series of pincer catalysts equipped with different functional groups in the secondary coordination
sphere is presented.
2
4
This article is protected by copyright. All rights reserved.
