Tetrahedron: Asymmetry 15 (2004) 119–126
Synthesis of novel C2-symmetric chiral bis(oxazoline) ligands
and their application in the enantioselective addition of diethylzinc
to aldehydes
Bin Fu, Da-Ming Du* and Jianbo Wang
Department of Chemical Biology, College of Chemistry and Molecular Engineering, Key Laboratory of Bioorganic Chemistry and
Molecular Engineering of Ministry of Education, Peking University, Beijing 100871, PR China
Received 6 September 2003; revised 25 October 2003; accepted 10 November 2003
Abstract—Novel chiral bis(oxazoline) ligands bearing dibenzo[a,c]cycloheptadiene and a dihydroxy group have been synthesized
and their application in the catalytic asymmetric addition of diethylzinc to aldehydes investigated. The enantioselectivities for the
aromatic aldehydesare generally high and up to 96% ee wasobtained.
ꢀ 2003 Elsevier Ltd. All rights reserved.
1. Introduction
the asymmetric addition of diethylzinc to aldehydes and
high enantioselectivities were obtained. Ligands 4 and 5,
explored by Bolm et al.14 and ligand 6 designed by
Pastor and Adolfsson,15 respectively, also showed good
catalytic activity (Scheme 1). In these ligands, the
oxazoline unit and adjacent hydroxy group function
together to control the catalytic process.
The catalytic enantioselective addition of organozinc
reagent to aldehydes is one of the most widely used
methodologiesin asymmetric carbon–carbon bond for-
mation.1 Asymmetric organozinc addition to aldehydes
provides the synthesis of various chiral alcohols, which
are important structural components of natural pro-
ducts and fine chemicals. Over the past decade, many
chiral ligands and catalysts have been designed and
synthesized, and high enantioselectivities have been
achieved.2 Among the diverse chiral ligand structures,
chiral amino alcoholsare predominant. In recent years,
other types of ligands, such as diols TADDOLs,3 and
BINOLs,4 amino thiols,5 iminyl alcohols,6 carbohydrate
derivatives,7 sulfonamides,8 and phosphoramide,9 have
also been explored for catalyzing this type of reaction.
On the other hand, chiral oxazolines, especially chiral
bis(oxazoline), have been widely applied in many cata-
lytic asymmetric reactions as versatile ligands.10
Recently, oxazoline-based ligands were also found to be
effective for the asymmetric addition of diethylzinc to
aldehydes.11 In particular, the ligand combining the
oxazoline ring and hydroxy group or an amino group
have been reported to show excellent catalytic activity in
the asymmetric addition of diethylzinc to aldehydes.12–15
For example, Ikeda et al.13 developed the ligands 1–3 for
Asa continuation of our ongoing project on the devel-
opment of novel chiral bis(oxazoline) ligands,16;17 we
report herein the synthesis and application of novel
C2-symmetric bis(oxazoline) ligands 11a and 11b with
dibenzo[a,c]cycloheptadiene and a hydroxy group as
substituents on the oxazoline ring. These ligands were
expected to furnish a new chiral environment in asym-
metric catalysis reactions by a combination of a hydroxy
group, oxazoline ring, and dibenzo[a,c]cycloheptadiene.
2. Results and discussion
The ligand 11 was synthesized starting from the cyclic
diethyl dicarboxylate 7.18 The cyclic carboxylate was
converted into the dihydroxy diamide 8 by the following
procedure: (1) hydrolysis in methanol solution of
NaOH; (2) acyl chloride formation with thionyl chlor-
ide; and (3) condensation with amino alcohol in the
presence of excess Et3N. The overall yield of three steps
wasup to 72%. Subsequently, the method explored by
Denmark et al.19 wasselected for cyclization. However,
* Corresponding author. Tel.: +86-10-6275-6568; fax: +86-10-6275-
1708; e-mail: dudm@pku.edu.cn
0957-4166/$ - see front matter ꢀ 2003 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetasy.2003.11.006

120
B. Fu et al. / Tetrahedron: Asymmetry 15 (2004) 119–126
O
O
R
R
N
N
R
HO
O
R
CPh2OH
CPh2OH
Fe
Fe
R
R
N
N
R
N
CPh2OH
OH
O
N
O
R
CPh2OH
O
3a R = Me 3b R = i-Pr
3c R = t-Bu
2a R = i-Pr
2b R = t-Bu
1a R = i-Pr
1b R = t-Bu
O
O
CPh2OH
O
O
HN
HN
N
Ph
O
Ph
N
N
CPh2OH
Fe
N
Fe
O
R
R
5
4
6a R = i-Pr
6b R = Ph
Scheme 1.
the treatment of dihydroxy diamide 8 with mesyl chlo-
ride (2.2 equiv) and Et3N (4.4 equiv) in dichloromethane
led to unexpected product 9. The methanesulfonate is a
good leaving group and with assistance of the adjacent
carboxylate group, the elimination reaction will be
With the ligandsin hand, we proceeded to invetsigate
their efficiency in catalytic asymmetric addition of
diethylzinc to aldehydes. Catalytic asymmetric addition
of diethylzinc to aldehydesisone of mots common
reactionsfor carbon–carbon bond formation. At firts,
we screened the normal reaction conditions for this
typical reaction. Thus, the effect of solvent and reaction
temperature on the catalytic addition of diethylzinc to
benzaldehyde was investigated using 10% mol ligand
11a. The results are summarized in Table 1. With hexane
asthe oslvent, the reaction wascarried at room tem-
perature for 24 h, after work-up and column chroma-
tography, (R)-1-phenyl-1-propanol wasobtained only in
40% yield with 2% ee (Table 1, entry 1). Although it was
reported that hexane isfavorable for high enantio-
selectivity,22a;b it seems not to be the case in our reaction
system. Subsequently, other solvents were tested (Table
1, entries2–4). In a mixed solvent of dichloromethane–
hexane (1:1), the chemical yield islow (38%), but the
enantioselectivity is improved to 65% ee; in THF–hex-
ane (1:1), both chemical yield and ee rise significantly to
68% and 77% ee, respectively. The best solvent system
wasfound to be toluene–hexane (1:1). At room tem-
perature, this solvent system gave 88% chemical yield
and 84% ee (Table 1, entry 4). The reaction at low
temperature was found to give slightly better results
(Table 1, entry 5). However, when the volume ratio of
toluene–hexane waschanged to 5:1, the yield dropped to
32% and the ee value did not change (86% ee) (Table 1,
entry 6). Thisreuslt isdifferent from the previous
observation that dilute toluene solutions give higher
yields and enantioselectivities.23
dominant and thusa more tsable conjugate product
wasformed. We then tried a different dehydration
reagent, diethylaminosulfur trifluoride (DAST),
9
20
according to the work of Williamset al. Thus, treat-
ment of the dihydroxy diamide 8 with a slight excess
(1.1 equiv) of DAST at )78 ꢁC in CH2Cl2, followed by
addition of K2CO3 and warming to room temperature,
afforded the desired bis(oxazoline) biscarboxylate 10 in
high yield (86%). Treatment of compound 10 with
Grignard reagent (11 equiv) in THF ()78 ꢁC to rt) gave
the target bis(oxazoline) ligands 11a,b in good yields(for
11a 75% and 11b 71%) (Scheme 2). For comparison,
ligands 10 and 13, which bear CO2Me and tert-butyl on
the oxazoline ring, respectively, were also synthesized
following the same procedure (Scheme 2). The mono-
oxazoline ligand 17 wasobtained according to the above
similar procedure from mono-acid 14, which can be
obtained by decarbonylation of corresponding diacid
(Scheme 3).18 The structures of these new compounds
were characterized by NMR, MS, IR, and elemental
analysis.
Despite the existence of axial chirality in compound 11,
fast interconversion between (R) and (S) enantiomersof
biphenyl occursat room temperature owing to the low
rotational energy barrier along the 1,10-bond of biphenyl
moiety.21 Consequently, the chirality of 10, 11a,b, 13, 16,
and 17 only derivesfrom the chiral oxazoline.s The
formation of dibenzo[a,c]cycloheptadiene ring from
linking the biphenyl reducesthe difficulty in separating
the diastereoisomers from the double chirality of
biphenyl backbone and oxazoline ring, and makesthe
synthesis procedure convenient.
The chiral ligand 11b wasfound not to be aseffective as
11a. Under the same conditions as entry 5, the ligand
11b gave only 38% yield and 50% ee (Table 1, entry 7).
The electron-rich dimethylhydroxymethyl group in 11a
should increase the Lewis basicity of the alkoxide and

B. Fu et al. / Tetrahedron: Asymmetry 15 (2004) 119–126
121
R
CO2Me
R
OH
O
O
CONHC=CH2
N
N
CONHC=CH2
OH
R
CO2Me
R
9
11a, R = Me
11b, R = Ph
d
f
CO2Me
CH2OH
O
CONHCHCO2Me
CO2Et
CO2Et
N
a, b, c
e
CONHCHCO2Me
N
O
CH2OH
CO2Me
8
7
10
CH2OH
CMe3
O
a, b, c
CONHCHC(Me)3
N
d
CONHCHC(Me)3
CH2OH
N
O
CMe3
12
13
Scheme 2. Reagentsand conditions: (a) NaOH, CH 3OH; (b) SOCl2; (c) aminol alcohol, Et3N, 72%; (d) MsCl, Et3N; (e) DAST, K2CO3, 86%; (f)
