Improved Methodology for the Synthesis of a Cathepsin B Cleavable Dipeptide Linker, Widely Used in Antibody-Drug Conjugate Research

Article abstract of DOI:10.1016/j.tetlet.2018.08.021

Antibody-drug conjugates (ADCs) represent an emerging class of biopharmaceutical agents that deliver highly potent anticancer agents (payloads) selectively to tumors or components associated with the tumor microenvironment. The linker, responsible for the connection between the antibody and payload, is a crucial component of ADCs. In certain examples the linker is composed of a cleavable short peptide which imparts an additional aspect of selectivity. Especially prevalent is the cathepsin B cleavable Mc-Val-Cit-PABOH linker utilized in many pre-clinical ADC candidates, as well as the FDA approved ADC ADCETRIS (brentuximab vedotin). An alternative route for the synthesis of the cathepsin B cleavable Mc-Val-Cit-PABOH linker is reported herein that involved six steps from l-Citrulline and proceeded with a 50% overall yield. In this modified route, the spacer (a para-aminobenzyl alcohol moiety) was incorporated via HATU coupling followed by dipeptide formation. Importantly, this route avoided undesirable epimerization and proceeded with improved overall yield. Utilizing this methodology, a drug-linker construct incorporating a potent small-molecule inhibitor of tubulin polymerization (referred to as KGP05), was synthesized as a representative example.

Full text of DOI:10.1016/j.tetlet.2018.08.021

Accepted Manuscript
Improved Methodology for the Synthesis of a Cathepsin B Cleavable Dipeptide
Linker, Widely Used in Antibody-Drug Conjugate Research
Deboprosad Mondal, Jacob Ford, Kevin G. Pinney
PII:
S0040-4039(18)31002-5
https://doi.org/10.1016/j.tetlet.2018.08.021
TETL 50196
DOI:
Reference:
Tetrahedron Letters
To appear in:
Received Date:
Accepted Date:
27 July 2018
12 August 2018
Please cite this article as: Mondal, D., Ford, J., Pinney, K.G., Improved Methodology for the Synthesis of a Cathepsin
B Cleavable Dipeptide Linker, Widely Used in Antibody-Drug Conjugate Research, Tetrahedron Letters (2018),
doi: https://doi.org/10.1016/j.tetlet.2018.08.021
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to our customers
we are providing this early version of the manuscript. The manuscript will undergo copyediting, typesetting, and
review of the resulting proof before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.

Improved Methodology for the Synthesis of a Cathepsin B Cleavable Dipeptide Linker,
Widely Used in Antibody-Drug Conjugate Research
Deboprosad Mondal1, Jacob Ford1, Kevin G. Pinney1*
1 Department of Chemistry and Biochemistry, Baylor University, One Bear Place # 97348, Waco,
Texas 76798-7438, United States
*Corresponding author: Tel.: +1 254 710 4117
E-mail address: Kevin_Pinney@baylor.edu
ABSTRACT
Antibody-drug conjugates (ADCs) represent an emerging class of biopharmaceutical agents that
deliver highly potent anticancer agents (payloads) selectively to tumors or components associated
with the tumor microenvironment. The linker, responsible for the connection between the antibody
and payload, is a crucial component of ADCs. In certain examples the linker is composed of a
cleavable short peptide which imparts an additional aspect of selectivity. Especially prevalent is
the cathepsin B cleavable Mc-Val-Cit-PABOH linker utilized in many pre-clinical ADC
candidates, as well as the FDA approved ADC ADCETRIS® (brentuximab vedotin). An alternative
route for the synthesis of the cathepsin B cleavable Mc-Val-Cit-PABOH linker is reported herein
that involved six steps from l-Citrulline and proceeded with a 50% overall yield. In this modified
route, the spacer (a para-aminobenzyl alcohol moiety) was incorporated via HATU coupling
followed by dipeptide formation. Importantly, this route avoided undesirable epimerization and
proceeded with improved overall yield. Utilizing this methodology, a drug-linker construct
incorporating a potent small-molecule inhibitor of tubulin polymerization (referred to as KGP05),
was synthesized as a representative example.
1

Keywords:
Dipeptide synthesis; Drug-linker construct; Cleavable linker; Epimerization
2

Antibody-drug conjugates (ADCs) represent a leading strategy for the targeted delivery of
anticancer agents (payloads), and are one of the fastest growing classes of oncological therapeutics
with over 60 conjugates in various stages of clinical trials.1 ADCs are typically comprised of a
monoclonal antibody (mAb) to which an anticancer therapeutic agent (payload) is conjugated
through an appropriate cleavable or non-cleavable linker (Fig. 1). The use of a monoclonal
antibody allows for a high degree of antigen selectivity, thereby potentially decreasing off-target
effects often observed in standard chemotherapy.2–5
The linker plays a critical role in the stability of the ADC in systemic circulation, and is
key for efficient and selective release of the payload at the tumor site. Linkers can be classified
within two broad categories, cleavable and non-cleavable, based on the mechanism of drug
release.6,7 Cleavable linkers are designed to be sensitive to specific physiological conditions such
as high glutathione concentration,8–10 low pH,11 or cleavage by protease enzymes highly expressed
in cancer cells and/or the tumor microenvironment.12,13 ADCs that contain non-cleavable linkers
depend on lysosomal degradation of the monoclonal antibody in the targeted tumor cell for drug
release.6 Cleavable linkers can be broadly categorized into two types, chemically labile and
enzymatically labile linkers. Chemically labile hydrazone and disulfide linkers are stable at the
3

neutral pH of blood.14 Hydrazone linkers are cleaved in the acidic environment of endosomes (5.0-
6.5) and lysosomes (4.5-5.0) associated with tumor cells, whereas disulfide linkages are cleaved
by glutathione that is more highly concentrated (up to 1000 fold higher) in tumor cells versus
normal tissue.15 Chemically labile linkers often suffer from limited plasma stability.6,13,16
Alternatively, peptide based linkers are designed as specific substrates for proteases that are highly
expressed in cancer cells or the tumor microenvironment.17 In Brentuximab vedotin (ADCETRIS®,
Seattle Genetics), one of four FDA approved ADCs currently on the market, a cathepsin B
cleavable maleimido-containing valine-citrulline based dipeptide linker (Mc-Val-Cit-PABOH) is
utilized (Fig. 2).18 The monomethylauristatin-E (MMAE)16,19,20 payload (inspired by the natural
product dolastatin 10,21–24 representing a seminal contribution by Pettit and co-workers) is bonded
through a self-immolative para-aminobenzyl alcohol spacer,12,25–29 eloquently first advanced by
Katzenellenbogen and co-workers.30 Upon cleavage of the dipeptide by cathepsin B, the spacer
undergoes a spontaneous 1,6-elimination resulting in release of the payload. The Mc-Val-Cit-
PABOH linker (1, Fig. 2) displays high plasma stability (half-lives in mice and monkey of 6.0 and
9.6 days, respectively), and has been found to be superior over chemically labile linkers.7,16
The Val-Cit dipeptide linker is commercially available, however it commands a high price
(approximately $2,500/g).31–34 This inspired us to undertake the synthesis of this linker to support
our various drug-linker construct applications,35 which utilize potent small-molecule inhibitors of
tubulin polymerization as payloads.36–41 While the Mc-Val-Cit-PABOH linker is certainly well-
described in the literature,42–45 we are aware of only two publications that provide a detailed
experimental procedure for the synthesis of this specific linker.13,46 The original contribution was
provided by Dubowchick and co-workers,13 however following that methodology (in our hands)
4

often led to fairly low overall yields along with unanticipated epimerization resulting in
diastereomeric mixtures that proved difficult to separate. Therefore, we modified the methodology
to provide a synthetic route with improved yield and no observable epimerization.35 Subsequent
to our patent publication on this methodology,35 and during the late stages of manuscript
preparation, we were encouraged to see that Wei and co-workers at Genentech reported a modified
route to this Val-Cit dipeptide linker 1 utilizing similar, although not exactly identical,
methodology.46 Neri and co-workers have described related methodology, but for the synthesis of
other short peptide constructs.47
The original reported synthesis by Dubowchick and co-workers (outlined in scheme 1)13
was initially followed in our laboratory. The synthesis of Fmoc-Val-Cit 5 proceeded smoothly
starting from commercially available Fmoc-Val-OSu 2. The EEDQ coupling reaction used for
amide bond formation between compound 5 and para-aminobenzyl alcohol in the next step was
not only complicated by the formation of several side-products, but also suffered from low yields
(average between 20-25%). Of most concern, compound 8 was always obtained as a mixture of
diastereomers 8 and 8a in variable ratios of 3:1 to 8:1 due to epimerization of the citrulline
stereogentic center of compound 5 during the coupling reaction. In an effort to improve the yield
and possibly reduce the rate of epimerization, EEDQ was replaced with HATU in the coupling
reaction between compound 5 and 4-aminobenzyl alcohol. The yield was slightly improved, but
the problem of epimerization persisted. It was then realized that the low yield and complicacy of
this particular step was most likely due to Fmoc deprotection under basic reaction conditions.
Therefore, to improve the yield, Fmoc was replaced with Boc and Cbz protecting groups which
are stable under basic conditions (6 and 7). Both compounds 6 and 7 underwent HATU mediated
coupling reactions with 4-aminobenzyl alcohol to generate the corresponding para-aminobenzyl
alcohols 9 and 10 in good yield (70-80%). Unfortunately, even though a better yield was obtained,
epimerization of the desired product still occurred resulting in a nearly 1:1 mixture of
diastereomers for both compounds 9 and 10.
5

After exploring different protecting groups and coupling reagents (EEDQ and HATU) it
was postulated that the reaction conditions were most likely not contributors to epimerization, but
rather that the epimerization was due to the nature of the substrate used in the coupling step (step
b, scheme 1). It is well known that coupling reactions between the carboxylic acid moiety of a
peptide (di to polypeptide) and a nucleophile, such as an amine group of an amino acid, can be
problematic due to epimerization of the α-chiral center with respect to the carboxylic acid group.
A generalized example of such epimerization is detailed in scheme 2.48–50 When the terminal
carboxylic acid of a peptide is activated 11, oxazolone 12a can be formed as the leading
intermediate. Under mildly basic conditions the oxazolone undergoes racemization via the
formation of conjugate anionic intermediate 13. The resulting oxazolone mixture of intermediates
12a and 12b then reacts with the nucleophile to generate products 14a and 14b, thus explaining
epimerization of the stereogenic center. Therefore, peptides are usually grown at the N-terminus
under mild activation conditions.48–50 In this later approach, the carboxylic acid group is activated
6

on an N-protected α-amino acid and then reacted with a nucleophile such as C-protected amino
acid or amine, thus avoiding oxazolone formation.48,49
Oxazolone formation offers a rational explanation that accounts for compounds 8, 9, and 10 being
obtained as a mixture of diastereomers. In order to avoid possible oxazolone formation a new route
to compound 1 was developed (Scheme 3).
7

Our modified procedure (Scheme 3) worked well with both Fmoc and Cbz as protecting
groups. Fmoc or Cbz protected l-citrullines 15 and 16 were synthesized through reaction of l-
citrulline with Fmoc-Cl or Cbz-OSu in quantitative yield. Subsequent amide bond formation
between the protected citrulline 15 or 16 and 4-aminobenzyl alcohol using HATU as the coupling
reagent afforded Fmoc-Cit-PABOH 17 or Cbz-Cit-PABOH 18 in good yield (60-65% for 17 and
70-80% for 18). In the case of Fmoc protected l-citrulline 15, the reaction was carried out in the
8

presence of 1.0 equivalent of N,N-diisopropylethylamine (DIPEA) as significant Fmoc
deprotection occurred in the presence of excess base thus resulting in a low yield. The synthesis
of dipeptide 8 started with Fmoc deprotection of compound 17 using excess triethylamine (20
equivalents) in DMF at room temperature followed by the reaction of the generated Cit-PABOH
with commercially available Fmoc-Val-OSu. Fmoc-Val-Cit-PABOH 8 was obtained in very good
yield (85-95%) as a single diastereomer. Cbz-Val-Cit-PABOH 10 was also obtained in a similar
manner in excellent yield (90-95%) as a single diastereomer. The Cbz deprotection was performed
by Pd catalyzed hydrogenolysis. To obtain the final target compound 1 (from 8), Fmoc
deprotection (triethylamine in DMF) of compound 8 afforded the free amine (Val-Cit-PABOH)
which was subsequently reacted with the activated 6-maleimidohexanoic acid (Mc-OSu, 20).
Compound 1 was obtained in an excellent yield (up to 96%) as a single diastereomer. This final
step was further optimized by generating the o-succinimide activated compound 20 in situ. In this
modified procedure, 6-maleimidohexanoic acid was activated (in situ) by treatment with N,N'-
disuccinimidyl carbonate in DMF and then reacted with the previously generated Val-Cit-PABOH
compound 19. Intermediate 10 was also converted to compound 1 in excellent yield (up to 98%)
as a single diastereomer under similar conditions. Over 1 g of compound 1 has been synthesized
in a single batch with an overall yield of 50% and intermediates 8 and 10 have been prepared in 3
g batches, with an overall yield of 55% and 65% respectively. Similar yields have been obtained
through repeated syntheses (x10).
A new drug-linker construct (Scheme 4) incorporating the Mc-Val-Cit-PABOH linker 1
was synthesized, which utilized a promising aniline-based dihydronaphthalene inhibitor of tubulin
9

polymerization (colchicine binding site) as the payload (referred to as KGP05).51,52 This unique
payload demonstrates dual-mechanism of action functioning as both an antiproliferative agent
(cytotoxin) and as a potent vascular disrupting agent (VDA). Small-molecule VDAs impart
selective and irreversible damage to tumor-associated vasculature and are mechanistically distinct
from the generally well-described angiogenesis inhibiting agents (AIAs).53–56 Treatment of KGP05
with triphosgene generated the corresponding isocyanate intermediate 21. The desired drug-linker
construct 22 was obtained in a relatively high yield through the reaction of compound 1 with the
generated isocyanate in the presence of dibutyltin dilaurate.
In conclusion, a modified route has been developed for the synthesis of the cathepsin B
cleavable Val-Cit dipeptide linker 1 widely used in ADCs. The method proved to be straight-
forward, consistent, and scalable. Above all, the methodology afforded the Val-Cit dipeptide linker
1 with exclusive diastereoselectivity, eliminating the potential problem of racemization associated
with the citrulline stereogenic center.
10

References
1. Beck A, Goetsch L, Dumontet C, Corvaïa N. Nat Rev Drug Discov. 2017; 16: 315–337.
2. Chari RVJ, Miller ML, Widdison WC. Angew Chem Int Ed. 2014; 53: 3796–3827.
3. Schrama D, Reisfeld RA, Becker JC. Nat Rev Drug Discov. 2006; 5: 147–159.
4. Schwartz RS. N Engl J Med. 2004; 350: 1079–1080.
5. Perez HL, Cardarelli PM, Deshpande S, Gangwar S, Schroeder GM, Vite GD, Borzilleri RM. Drug
Discov Today. 2014; 19: 869–881.
6. Lu J, Jiang F, Lu A, Zhang G. Int J Mol Sci. 2016; 17: 561.
7. Ducry L, Stump B. Bioconjug Chem. 2010; 21: 5–13.
8. Saito G, Swanson JA, Lee K-D. Adv Drug Deliv Rev. 2003; 55: 199–215.
9. Mills BJ, Lang CA. Biochem Pharmacol. 1996; 52: 401–406.
10. Kellogg BA, Garrett L, Kovtun Y, Lai KC, Leece B, Miller M, Payne G, Steeves R, Whiteman KR,
Widdison W, Xie H, Singh R, Chari RVJ, Lambert JM, Lutz RJ. Bioconjug Chem. 2011; 22: 717–727.
11. Ritchie M, Tchistiakova L, Scott N. mAbs. 2013; 5: 13–21.
12. Chakravarty PK, Carl PL, Weber MJ, Katzenellenbogen JA. J Med Chem. 1983; 26: 633–638.
13. Dubowchik GM, Firestone RA, Padilla L, Willner D, Hofstead SJ, Mosure K, Knipe JO, Lasch SJ, Trail
PA. Bioconjug Chem. 2002; 13: 855–869.
14. Bouchard H, Viskov C, Garcia-Echeverria C. Bioorg Med Chem Lett. 2014; 24: 5357–5363.
15. Jain N, Smith SW, Ghone S, Tomczuk B. Pharm Res. 2015; 32: 3526–3540.
16. Doronina SO, Toki BE, Torgov MY, Mendelsohn BA, Cerveny CG, Chace DF, DeBlanc RL, Gearing RP,
Bovee TD, Siegall CB, Francisco JA, Wahl AF, Meyer DL, Senter PD. Nat Biotechnol. 2003; 21: 778–
784.
17. Bakhtiar R. Biotechnol Lett. 2016: 1–10.
18. Senter PD, Sievers EL. Nat Biotechnol. 2012; 30: 631–637.
19. Maderna A, Doroski M, Subramanyam C, Porte A, Leverett CA, Vetelino BC, Chen Z, Risley H, Parris
K, Pandit J, Varghese AH, Shanker S, Song C, Sukuru SCK, Farley KA, Wagenaar MM, Shapiro MJ,
Musto S, Lam M-H, Loganzo F, O’Donnell CJ. J Med Chem. 2014; 57: 10527–10543.
20. Maderna A, Leverett CA. Mol Pharm. 2015; 12: 1798–1812.
21. Pettit GR, Kamano Y, Herald CL, Tuinman AA, Boettner FE, Kizu H, Schmidt JM, Baczynskyj L, Tomer
KB, Bontems RJ. J Am Chem Soc. 1987; 109: 6883–6885.
22. Pettit GR, Singh SB, Hogan F, Lloyd-Williams P, Herald DL, Burkett DD, Clewlow PJ. J Am Chem Soc.
1989; 111: 5463–5465.
23. Aherne GW, Hardcastle A, Valenti M, Bryant A, Rogers P, Pettit GR, Srirangam JK, Kelland LR. Cancer
Chemother Pharmacol. 1996; 38: 225–232.
̄
24. Bai R, Roach MC, Jayaram SK, Barkoczy J, Pettit GR, Luduena RF, Hamel E. Biochem Pharmacol. 1993;
45: 1503–1515.
25. Alouane A, Labruère R, Le Saux T, Schmidt F, Jullien L. Angew Chem Int Ed. 2015; 54: 7492–7509.
26. de Groot FMH, de Bart ACW, Verheijen JH, Scheeren HW. J Med Chem. 1999; 42: 5277–5283.
27. Greenwald RB, Pendri A, Conover CD, Zhao H, Choe YH, Martinez A, Shum K, Guan S. J Med Chem.
1999; 42: 3657–3667.
28. de Groot FMH, Busscher GF, Aben RWM, Scheeren HW. Bioorg Med Chem Lett. 2002; 12: 2371–
2376.
29. Doronina SO, Mendelsohn BA, Bovee TD, Cerveny CG, Alley SC, Meyer DL, Oflazoglu E, Toki BE,
Sanderson RJ, Zabinski RF, Wahl AF, Senter PD. Bioconjug Chem. 2006; 17: 114–124.
30. Carl PL, Chakravarty PK, Katzenellenbogen JA. J Med Chem. 1981; 24: 479–480.
31. http://www.chemscene.com/159857-80-4.html (accessed July 23, 2018).
11

32. http://www.abovchem.com/pc/en/product_item.aspx?ID=QC5578738 (accessed July 23, 2018).
33. http://www.atkchemical.com/159857-80-4.html (accessed July 23, 2018).
34.https://www.sigmaaldrich.com/catalog/buildingblock/product/combiblocksinc/comh04234da4?lang
=en&region=US (accessed July 23, 2018).
35. Pinney, K., Lin, C., Mondal, D., Ford, J.WO/2017/066668 2017.
36. Herdman CA, Strecker TE, Tanpure RP, Chen Z, Winters A, Gerberich J, Liu L, Hamel E, Mason RP,
Chaplin DJ, Trawick ML, Pinney KG. MedChemComm. 2016; 7: 2418–2427.
37. Herdman CA, Devkota L, Lin C-M, Niu H, Strecker TE, Lopez R, Liu L, George CS, Tanpure RP, Hamel E,
Chaplin DJ, Mason RP, Trawick ML, Pinney KG. Bioorg Med Chem. 2015; 23: 7497–7520.
38. Tanpure RP, George CS, Strecker TE, Devkota L, Tidmore JK, Lin C-M, Herdman CA, MacDonough MT,
Sriram M, Chaplin DJ, Trawick ML, Pinney KG. Bioorg Med Chem. 2013; 21: 8019–8032.
39. Tanpure RP, George CS, Sriram M, Strecker TE, Tidmore JK, Hamel E, Charlton-Sevcik AK, Chaplin DJ,
Trawick ML, Pinney KG. MedChemComm. 2012; 3: 720–724.
40. MacDonough MT, Strecker TE, Hamel E, Hall JJ, Chaplin DJ, Lynn Trawick M, Pinney KG. Bioorg Med
Chem. 2013; 21: 6831–6843.
41. Sriram M, Hall JJ, Grohmann NC, Strecker TE, Wootton T, Franken A, Trawick ML, Pinney KG. Bioorg
Med Chem. 2008; 16: 8161–8171.
42. Zhang D, Le H, Cruz-Chuh J dela, Bobba S, Guo J, Staben L, Zhang C, Ma Y, Kozak KR, Lewis Phillips
GD, Vollmar BS, Sadowsky JD, Vandlen R, Wei B, Su D, Fan P, Dragovich PS, Khojasteh SC, Hop CECA,
Pillow TH. Bioconjug Chem. 2018; 29: 267–274.
43. Dal Corso A, Cazzamalli S, Gébleux R, Mattarella M, Neri D. Bioconjug Chem. 2017.
44. Verma VA, Pillow TH, DePalatis L, Li G, Phillips GL, Polson AG, Raab HE, Spencer S, Zheng B. Bioorg
Med Chem Lett. 2015; 25: 864–868.
45. Burke PJ, Senter PD, Meyer DW, Miyamoto JB, Anderson M, Toki BE, Manikumar G, Wani MC, Kroll
DJ, Jeffrey SC. Bioconjug Chem. 2009; 20: 1242–1250.
46. Wei B, Gunzner-Toste J, Yao H, Wang T, Wang J, Xu Z, Chen J, Wai J, Nonomiya J, Tsai SP, Chuh J,
Kozak KR, Liu Y, Yu S-F, Lau J, Li G, Phillips GD, Leipold D, Kamath A, Su D, Xu K, Eigenbrot C,
Steinbacher S, Ohri R, Raab H, Staben LR, Zhao G, Flygare JA, Pillow TH, Verma V, Masterson LA,
Howard PW, Safina B. J Med Chem. 2018; 61: 989–1000.
47. Cazzamalli S, Dal Corso A, Neri D. J Controlled Release. 2017; 246: 39–45.
48. Montalbetti CAGN, Falque V. Tetrahedron. 2005; 61: 10827–10852.
49. Joullie MM, Lassen KM. Arkivoc. 2010; 2010: 189.
50. Isidro-Llobet A, Álvarez M, Albericio F. Chem Rev. 2009; 109: 2455–2504.
51. Devkota L, Lin C-M, Strecker TE, Wang Y, Tidmore JK, Chen Z, Guddneppanavar R, Jelinek CJ, Lopez
R, Liu L, Hamel E, Mason RP, Chaplin DJ, Trawick ML, Pinney KG. Bioorg Med Chem. 2016; 24: 938–
956.
52. Pinney, K. G., Mocharla, V. P., Chen, Z., Hadimani, M., Kessler, J., Dorsey, J. M., Edvardsen, K.,
Chaplin, D. J., Prezioso, J., Ghatak, A (deceased). United States Patent, US7001926B2 2006.
53. Siemann DW. Cancer Treat Rev. 2011; 37: 63–74.
54. Mason RP, Zhao D, Liu L, Trawick ML, Pinney KG. Integr Biol. 2011; 3: 375.
55. Chase DM, Chaplin DJ, Monk BJ. Gynecol Oncol. 2017; 145: 393–406.
56. Grisham R, Ky B, Tewari KS, Chaplin DJ, Walker J. Gynecol Oncol Res Pract. 2018; 5.
12

13

Incorporation of Self immolative
spacer followed by dipeptide
formation results in higher yields and
no epimerization
O
O
OH
H
O
O
N
FmocHN
N
H
H2N
N
H
OH
O
NH2
L-Citrulline
NH
NH2
O
O
O
O
OH
H
N
N
Mab Conjugation
Site
N
N
H
Payload Attachment
Site
H
O
O
NH
NH2
