C−H stretching in the original organic ligands completely
disappeared, and new bands at 2887 and 2947 cm−1
corresponding to C−H stretching in NMF solvent appeared.
These results confirm that long hydrocarbon organic ligands
can be completely replaced by S2− and thus all-inorganic CdS
QDs can be obtained.
Figure 1d shows the ζ-potential of purified CdS/S2− QDs is
−35.7 mV, implying a negative charge on the surface of CdS
QDs. The purified S2− capped CdS QDs were further reacted
with Cd(AC)2 in NMF to get CdS/Cd2+ QDs in NMF. Their
ζ-potential which displays in Figure 1d is +13.2 mV, indicating
that a positive charge on CdS QDs could be realized by
introducing Cd(AC)2. TEM images of CdS QDs with average
size of 3.3 nm in different stages are shown in Figure S1.
Layer-by-layer atomic deposition assembly is a common
method for preparing core/shell CdSe/CdS NPLs. By the
reaction of Cd2+ with CdSe/S2− NPLs, one monolayer of CdS
shells can be formed. After the deposition of several layers of
CdS, core/shell CdSe/CdS NPLs with red emission were
formed and then they were transferred into the hexane phase
by the addition of OA and OLA organic ligands. By the
exchange of organic ligands with S2−, NMF solutions of CdSe/
CdS/S2− NPLs were obtained. Figure 2 compares the
absorption and photoluminescence spectra of CdSe/CdS
NPLs capped with organic ligands in hexane and CdSe/
CdS/S2− NPLs in NMF. Both the absorption and emission
peaks had slight increases after S2− capping. As the initial
CdSe/CdS NPLs had a Cd-rich surface, the initial surface Cd
ions on the CdSe/CdS NPLs could react with S2− to get a thin
CdS layer, resulting in a minor increase of absorption peak and
an enhancement of photoluminescence. After aging for several
days, the quantum yield (QY) of CdSe/CdS/S2− NPLs could
reach 2.8%, which is a great enhancement compared with that
of CdSe/CdS NPLs (QY: 0.6%). When the inorganic-ligand
CdSe/CdS/S2− NPLs met with inorganic-ligand CdS/Cd2+
QDs, a fusion occurred between them, resulting in QDs-inlaid
NPLs called as CdS QD/CdSe/CdS NPLs, which are
illustrated in Scheme 1.
Figure 3. TEM images of CdS QD/CdSe/CdS NPLs in NMF (a)
and in hexane (b). The scale bars are 50 and 20 nm for images a and
b, respectively.
purified by size-selective precipitation to remove free CdS/
Cd2+ QDs. From Figure 3b, CdS/Cd2+ QDs could still be seen
on the CdSe/CdS/S2− NPLs, which further proves the fusion
of CdS/Cd2+ QDs and CdSe/CdS/S2− NPLs. The lateral
dimensions of CdS QD/CdSe/CdS NPLs are 42 nm × 12 nm,
and the thickness is 3.2 nm. It is worth mentioning that fusion
between CdS/Cd2+ QDs and CdSe/S2− NPLs can also be
realized. The corresponding UV−vis spectra, PL spectra and
TEM images can be seen in Figures S4 and S5 in the
In summary, the fusion of semiconductor CdS QDs and
CdSe/CdS NPLs was realized by the reaction of inorganic-
ligand CdS/Cd2+ QDs with inorganic-ligand CdSe/CdS/S2−
NPLs. Different from the organic molecule linker method for
connecting two types of nanomaterials, CdS QDs were fused
with CdSe/CdS NPLs by the reactions of Cd2+ (from CdS/
Cd2+ QDs) and S2− (from CdSe/CdS/S2− NPLs), thus no
insulating ligands exist. Furthermore, this promising fusion also
resulted in great photoluminescence-enhancement of NPLs.
These all-inorganic assemblies open up interesting oppor-
tunities for integrated nanodevices which can be directly used
for electronic and optoelectronic applications.
ASSOCIATED CONTENT
* Supporting Information
The Supporting Information is available free of charge at
■
sı
The fusion between inorganic-ligand CdSe/CdS/S2− NPLs
and CdS/Cd2+ QDs can be proved by the absorption and
emission spectra. As shown in Figure 2A, the absorption peak
of CdSe/CdS/S2− NPLs shifts from 620 to 635 nm after the
mixing with CdS/Cd2+ QDs. CdS QD/CdSe/CdS NPLs could
be formed due to the reactions between Cd2+ on the CdS/
Cd2+ QDs and S2− on the CdSe/CdS/S2− NPLs. The
corresponding photoluminescence peak shifts from 631 to
643 nm shown in Figure 2B also imply the interactions
between CdS/Cd2+ QDs and CdSe/CdS/S2− NPLs. For the
QY, the QY of CdS QD/CdSe/CdS NPLs was 17.8%, which
was greater than that of CdSe/CdS/S2− NPLs due to the
diminishment of S2− PL quenchers by the reaction of S2− and
Cd2+. CdS QD/CdSe/CdS NPLs in NMF phase could be
extracted to hexane phase in the presence of OLA and OA.
After purification, the QY of CdS QD/CdSe/CdS NPLs in
hexane was 15.1%.
TEM images in Figure 3a show the fusion between CdSe/
CdS/S2− NPLs and inorganic-ligand CdS/Cd2+ QDs in NMF
after mixing for 6 h. Small black dots on the NPLs with a size
about 3.3 nm can be assigned to CdS/Cd2+ QDs which have
no remarkable size change before and after fusion with CdSe/
CdS/S2− NPLs. In order to further confirm that CdS/Cd2+
QDs were inlaid on the CdSe/CdS/S2− NPLs, they were
transferred from the NMF phase to the hexane phase and
FT-IR details, TEM images of CdS QDs in different
stages and CdS QD/CdSe NPLs in NMF, XPS spectra,
HR-TEM images and XRD spectra of CdS QD/CdSe/
CdS NPLs, UV−vis and PL spectra of CdSe NPLs,
CdSe/S2− NPLs in NMF and CdS QD/CdSe NPLs in
NMF, and experimental procedures (PDF)
