Cationic ruthenium complex of the formula [RuCl(2,6-diacetylpyridine)
(
PPh ) ]BArF and its catalytic activity in the formation of enol esters
3
2
Matthew J. Stark , Douglas T. Tang , Nigam P. Rath a,b, Eike B. Bauer a,
a
a
⇑
a
University of Missouri – St. Louis, Department of Chemistry and Biochemistry, One University Boulevard, St. Louis, MO 63121, USA
Center for Nanoscience, University of Missouri – St. Louis, St. Louis, MO 63121, USA
b
a r t i c l e i n f o
a b s t r a c t
Article history:
A new ruthenium 2,6-diacetylpyridine complex was synthesized and applied in the atom-economic syn-
thesis of enol esters through Markovnikov-directed addition of carboxylic acids to terminal alkynes. The
ruthenium complex [RuCl(dap)(PPh ) ] BArF was synthesized from [RuCl (PPh ) ] and the correspond-
3 2 2 3 2
ing ligand 2,6-diacetylpyridine (dap). The complex was characterized structurally. The new ruthenium
complex was utilized under ambient conditions as a catalyst in the Markovnikov addition of carboxylic
acids to terminal alkynes to afford the corresponding enol esters in 93% to 52% isolated yields (85 °C, 16 h
reaction time, 1 mol% catalyst loading).
Received 2 December 2017
Revised 8 January 2018
Accepted 10 January 2018
Available online xxxx
+
À
Keywords:
Ruthenium complexes
Homogeneous catalysis
Vinyl esters
Ó 2018 Elsevier Ltd. All rights reserved.
Transition metal Lewis acids
Introduction
Several methods to access enol esters are known; among them
are Bayer-Villiger-type oxidation of
the cross coupling of alkenyltrifluoroborate salts with carboxylic
a
,b-unsaturated ketones13 or
Alkynes are valuable starting materials in organic synthesis, and
their transformations can produce a variety of compound classes.
Many of these transformations are transition-metal catalyzed,
and the palladium-catalyzed Sonogashira coupling between termi-
1
4
acids. The addition of carboxylic acids to terminal alkynes is
attractive because these starting materials are readily available
and the method is atom-economical.
1
nal alkynes and aryl- or vinyl halides is a prominent example. The
Well-characterized ruthenium complexes play a prominent role
in organometallic catalysis; they can be thoroughly characterized
using conventional analytical techniques and tend to be configura-
addition of carboxylic acids to terminal alkynes is an atom-eco-
nomical reaction to afford enol esters, and the reaction requires
promotion by a catalyst.2 The reaction can generate different
regioisomers; Markovnikov addition provides the corresponding
geminal enol esters A, whereas anti-Markovnikov addition leads
to the corresponding (E) and (Z) enol esters B (Scheme 1). Control
of the regioselectivity is, thus, crucial for the reaction to be syn-
thetically useful. Ruthenium catalysts are widely employed for
15
tionally stable. Cationic ruthenium complexes can serve as mild
Lewis acids in solution, and are consequently able to exhibit cat-
alytic activity in cases where Lewis acids are the catalytically active
1
6
species.
As part of our continuing research program centered around
1
7
ruthenium complexes, we are in continuous search for well-
defined ruthenium complexes to be applied as catalysts. The
majority of the ruthenium catalysts for the title reaction are based
on fairly uncomplicated and/or commercial ruthenium complexes
3
the reaction since the pioneering work of Shvo. There are catalyst
systems known that produce primarily the Markovnikov enol
4
esters A, and others that give mainly the anti-Markovnikov prod-
ucts B.5 Basic additives,6 the solvent7 or the architecture and the
3,4a,5a
4a,b,5a,6,9b
bearing
a
carbonyl
monodentate phosphine,
8
7
4c
electronic nature of the ruthenium catalyst may have an influence
on the regioselectivity. The addition of carboxylic acids to internal
alkynes is less common but it has been reported as well.
hydrido, or carboxylate ligands. It has been demonstrated that
the ligand structure and its electronic properties can have an
influence on the selectivity of the reaction. However, systematic
9
6
The resulting enol esters themselves are valuable starting mate-
investigations of the metal complex structure on the selectivity
of the title reactions are scarce. The reaction requires elevated tem-
peratures to proceed and catalyst stability at higher temperatures
is not very well investigated.
10
rials for example in polymerization reactions, in acylation reac-
tions,1 and in a number of other organic transformations.
1
12
Based on these considerations, we were searching for a new
ruthenium complex architecture for the title reaction, that would
⇑
Corresponding author.
E-mail address: bauere@umsl.edu (E.B. Bauer).
https://doi.org/10.1016/j.tetlet.2018.01.029
040-4039/Ó 2018 Elsevier Ltd. All rights reserved.
0
Please cite this article in press as: Stark M.J., et al. Tetrahedron Lett. (2018), https://doi.org/10.1016/j.tetlet.2018.01.029

2
M.J. Stark et al. / Tetrahedron Letters xxx (2018) xxx–xxx
Fig. 1. Molecular structure of [RuCl(dap)(PPh
3 2
) ]BArF depicted with 50% probabil-
ity ellipsoids; H atoms and the counter ion are omitted for clarity. Key bond lengths
(
(
Å) and angles (°): Ru(1)–N(1), 1.990(4); Ru(1)–O(1), 2.141(3); Ru(1)–O(2), 2.082
3); Ru(1)–P(1), 2.3220(13); Ru(1)–P(2) 2.3855(13); Ru(1)–Cl(1) 2.4210(12); N(1)–
Ru(1)–P(1), 92.54(12); N(1)–Ru(1)–P(2), 169.54(12); P(1)–Ru(1)–P(2), 97.54(5); N
(1)–Ru(1)–Cl(1), 83.38(11); P(1)–Ru(1)–Cl(1), 173.19(4); P(2)–Ru(1)–Cl(1), 86.84
Scheme 1. Enol ester synthesis.
(
4); O(1)–Ru–O(2), 154.01(14).
be tunable and that would show high promise of thermal stability.
As mentioned, mainly monodentate ligands have been employed
previously. We were wondering whether ruthenium complexes
bearing tridentate ligands can be employed as catalysts in the for-
mation of enol esters. We envisaged 2,6-diacetylpyridines as a tun-
able ligand platform, and set out to investigate its ruthenium
complex as catalyst for the title reaction. Herein, we present the
synthesis and structural characterization of a 2,6-diacetylpyridine
ruthenium complex and its application as catalyst for the regiose-
lective addition of carboxylic acids to terminal alkynes. To the best
of our knowledge, it is the first ruthenium catalyst bearing a tri-
dentate ligand that promotes this reaction.
reveals that the 2,6-diacetylpyridine ligand is coordinated to the
ruthenium center through the nitrogen and the two oxygen atoms
in a tridentate fashion. The O(1)–Ru–O(2) ‘‘bite” angle of the 2,6-
diacetylpyridine ligand is 154°. This angle is smaller than the
1
80° angle in an ideal octahedral complex, which is believed to
be responsible for the fact that the complex is somewhat distorted.
The two PPh ligands take a cis position to each other, which is in
3
3
1
1
accordance with the P{ H} NMR spectrum of the complex. The
bond lengths are comparable to other, neutral ruthenium chloro
1
7a,17b
PPh
3
complexes,
and it appears that the positive charge has
no profound impact on the bond lengths around the ruthenium
center.
Syntheses of the ruthenium complex
Catalytic investigations with the ruthenium complex [RuCl
(
dap)(PPh
3 2
) ]BArF
To the best of our knowledge, ruthenium complexes bearing a
tridentate 2,6-diacetylpyridine ligand are unknown. Accordingly,
The new complex was subsequently investigated as catalyst for
when the known complex [RuCl
dap) and NaBArF (sodium tetrakis[3,5-bis(trifluoromethyl)phe-
nyl]borate) were stirred at room temperature for one hour in CH
2 3 3
(PPh ) ], 2,6-diacetylpyridine
the title reaction, and initial screening efforts for a test reaction
between phenyl acetylene and benzoic acid are compiled in Table 1.
As can be seen, the reaction is dependent on the reaction temper-
ature, the solvent, potential additives, and the reaction time.
Toluene was found to be the solvent of choice (Table 1, entry 1).
Lower reaction times and temperatures resulted in lower yields
or no conversion (entries 2–4), and 18 h at 85 °C gave the highest
yield. It has been reported that bases as additive can improve the
(
2
-
+
À
Cl
isolated from the reaction mixture in 92% yield (Scheme 2), which
will be referred to subsequently as [RuCl(dap)(PPh ]BArF. The
new complex was characterized by multinuclear NMR, IR, MS
2 3 2
, the deep purple complex [RuCl(dap)(PPh ) ] BArF could be
3 2
)
3
1
1
and microanalysis. The P{ H} NMR spectrum showed two mutu-
ally coupled doublets, demonstrating the presence of two magnet-
6
yield and/or the selectivity of the enol ester formation. However,
for our catalyst, it appeared that bases such as DBU, Et N, Na CO
3 2 3
3
ically inequivalent PPh ligands.
In order to unequivocally establish the structure of the complex,
its X-ray structure was determined. The molecular structure is
depicted in Fig. 1, and key bond lengths and angles are given in
the Figure caption. Additional details for the structure determina-
tion are given in the Supplementary data.
or NaHCO completely shut down the reaction (entries 6–9), which
we tentatively ascribed to deactivation of the cationic catalyst by
3
the bases. Solvents other than toluene gave significantly lower
yields (entries 10–14). As expected, without catalyst no reaction
took place (entry 5). For optimum results, the alkyne was
employed in a twofold excess over the carboxylic acid substrate.
Catalyst loadings as low as 1% were found to be sufficient. In all
cases, the Markovnikov product was the major or the only product.
Under the optimized reaction conditions, we employed the cat-
alyst in the synthesis of a number of enol esters and the results are
compiled in Table 2. As can be seen, both aromatic and aliphatic
carboxylic acids as well as both aromatic and aliphatic alkynes
can be employed in the reaction in any combination. The reaction
also proceeds when hydroxy acids were employed as substrates
(entries 6 and 7). The products were isolated chromatographically
As can be seen from the bond angles Fig. 1, the complex
assumes a distorted octahedral architecture. The X-ray structure
Scheme 2. Synthesis of the ruthenium complex.
Please cite this article in press as: Stark M.J., et al. Tetrahedron Lett. (2018), https://doi.org/10.1016/j.tetlet.2018.01.029

M.J. Stark et al. / Tetrahedron Letters xxx (2018) xxx–xxx
3
Table 1
