Sulfated Zirconia-Catalyzed Synthesis of 3,4-Dihydro-
pyrimidin-2(1H)-ones (DHPMs) Under Solventless Conditions:
Competitive Multicomponent Biginelli vs. Hantzsch Reactions
1
2
2
Deyanira Angeles-Beltrán , Leticia Lomas-Romero , Victor H. Lara-Corona , Eduardo
2
1,
González-Zamora and Guillermo Negrón-Silva *
1
2
Departamento de Ciencias Básicas and Departamento de Química, UAM, Av. San Pablo No 180. C.
P. 02200, México D. F., México; E-mail addresses: D. Angeles-Beltrán: dab@correo.azc.uam.mx,
L. Lomas-Romero: llr@xanum.uam.mx, V. H. Lara-Corona: lacv@xanum.uam.mx, E. González-
Zamora: egz@xanum.uam.mx
*
Author to whom correspondence should be addressed: e-mail: gns@correo.azc.uam.mx
Received: 21 July 2006; in revised form: 27 September 2006 / Accepted: 1 October 2006 / Published:
October 2006
2
2
-
Abstract: The catalytic ability of ZrO
2
/SO
4
to promote solventless three-component
condensation reactions of a diversity of aromatic aldehydes, urea or thoiurea and ethyl
acetoacetate was studied. Products resulting from Hantzsch and/or Biginelli multi-
component reactions are obtained in the presence of solid acid catalysts using the same
reactants but different temperature conditions. The sulfated zirconia catalyst can be
recovered and recycled in subsequent reactions with a gradual decrease of activity.
Keywords: Biginelli reaction, Hantzsch reaction , multicomponent reactions, 1,4-
dihydropyridines, dihydropyrimidinones, solventless reactions.
Introduction
Acid-catalysed transformations are common in bond-making and breaking reactions in Organic
Chemistry. These reactions are most often conducted in solution and involve heating a mixture of
reagents containing a catalytic amount of mineral or classic Lewis acids [1]. The replacement of these
acids has been a focal point of research and development for a long time. The applications of solid

Molecules 2006, 11
732
acids such as natural and modified clay minerals [2], zeolites and zeotype materials [3] as efficient
catalysts in organic transformations have been widely studied. Aside the fact that they have excellent
activity and selectivity, even on industrial scales, and in most cases these substances can be recovered
from reaction mixtures and reused with good results [4], these solid acids are important from an
environmental point of view because they produce less hazardous by-products. In this context, solid
sulfated zirconia [5] have been used, due to their acidic and shape-selective nature, for performing the
synthesis of heterocycles [6,7], acylation of aromatics ketones [8] and stereocontrolled glycosidations
[
9], synthesis of aromatic gem-dihalides [10], acylation of crown ethers [11], and chemoselective
synthesis of acylals from aromatic aldehydes and their deprotections [12]. It is also known that in
many cases organic reactions under solvent free conditions occur more efficiently and more selectively
than do their solutions counterparts [13].
In 1893 Biginelli reported the first synthesis of 3,4-dihydropyrimidin-(1H)-ones by a very simple
one-pot condensation reaction of an aromatic aldehyde, urea and ethyl acetoacetate in ethanolic
solution using a catalytic amount of acid [14]. The dihydropyrimidinone core and its derivatives form
an important class of compounds, as it is present in a large family of natural products with broad
biological activities as antihypertensive, antiviral, antitumor and anti-inflammatory agents and as
calcium channel blockers [15]. Attempts to synthesize these moieties by the Biginelli reaction over
various heterogeneous catalysts such as KSF [16], silica sulfuric acid [17] and more recently, the
Lewis acids cerium (III) and indium(III) chloride [18], CuCl H O/CuSO ·5H O [19] and ferric
2
2
4
2
chloride/tetraethyl orthosilicate system are reported [20]. Recently, sulfated zirconia and sulfated
zirconia modified with metals have been used in organic transformations to obtain 3,4-
dihydropyrimidin-2(1H)-ones, bis-(indoyl)methane derivatives, 2,3-dihydro-1H-1,5-benzodiazepines,
2
diaryl sulfoxides, coumarins, diphenylureas and protected carbonyl compounds and ZrO /pillared clay
has been reported to be an efficient catalyst for solventless synthesis of dihydropyrimidinones [21].
Hantzsch heterocyclic derivatives have been also obtained since the last century. This one pot
reaction occurs in a similar way to Biginelli´s, but it involves the use of ammonia in ethanol under
reflux [22] or solvent-free conditions [23] Hantzsch derivatives as well as Biginelli condensation
products have been studied due to their potent biological activities, but Hantzsch-type
dihydropyridines in particular are used are hypotensive agents for the treatment of cardiovascular
disorders [24].
Some publications have proven the existence of a competition between the obtention of 1,4-
dihydropyridines (DHPs) and 3,4-dihydropyrimidin-2(1H)-ones (DHPMs) under infrared radiation and
solventless conditions [25] or microwave heating [26]. These one pot condensation reactions in the
presence of acid solids have enabled us to achieve a simple green route for the preparation of DHPs; in
connection with our interest in the novel use of sulfated zirconia as a catalyst in solvent free organic
reactions, we report herein the synthesis of DHPMs via a clean, single-step, high yield cyclo-
condensation reaction of aromatic aldehydes, ethyl acetoacetate and urea or thiourea under solvent-
free conditions using sulfated zirconia as catalyst. Products resulting from competitive Biginelli and
Hantzsch pathways are obtained, depending on the reaction temperature. Reusability of the catalyst,
ease of separation of pure products, selectivity and high yields in comparison to the classical Biginelli
reaction are some of the unique features of this process.

Molecules 2006, 11
733
Results and Discussion
The sulfated zirconia catalyst was prepared by the reaction of zirconium isopropoxide with sulfuric
acid in isopropanol. The product, obtained as a viscous solution, was first heated at 80°C to evaporate
excess alcohol and then calcinated in air at 600°C, to give a white solid, identified as the target
compound.
Figure 1 shows the results obtained after X-ray diffraction characterization of sulfated zirconia; the
diffractogram pattern corresponds to sulfated zirconia samples where a tetragonal phase was found in
all the samples given by reflections in 2θ = 30.18° (relative intensity is 100) as well as peaks 34.616°,
3
5.283°, 50.214°, 50.770°, 59.291°, 60.187° and 63.724°. (ICSD collection code: 066787).
Figure 1. Diffraction pattern of sulfated zirconia
2
θ
Figure 2 presents the results obtained by means of adsorption-desorption of nitrogen that gave an
isotherm plot type IV of BET classification (Brunauer Emett and Teller theory); the isotherm
hysteresis loop indicated a uniform pore size distribution.
Figure 2. Nitrogen adsorption-desorption plot of sulfated zirconia
100
90
80
70
60
50
40
30
20
10
0
Adsorption
Desorption
0
0.2
0.4
0.6
0.8
1
P/Po

Molecules 2006, 11
734
The data for BET specific surface-area, pore volume and pore size values are shown in Table 1.
The TPD curve consisted of a wide high temperature desorption peak (at 600 °C) and the number of
-1
3
acid sites was measured by integration of the peak area. The acidity result was 340.72 µmole NH ·g .
Table 1. Sulfated zirconia textural features
2
-1
Surface area
Pore volume
Pore size
105.73 m ·g
-
1
0.12 mL·g
42.79 Å
The basic scheme of the Biginelli reactions using sulfated zirconia as acid catalyst is shown in
Scheme 1.
Scheme 1
R
CO Et
CO Et
2
2
O
X
=
ZrO /SO
HN
2
4
+
+
Solvent-free
R
H
NH2
NH2
O
X
N
H
4
Me
3
1
2
X=O, S
4a R= C6H5, X= O
b R= C6H5, X= S
4
Table 2 shows the different aldehydes used in solvent-free Biginelli reactions at 60°C in the
presence of a catalytic amount of sulfated zirconia during a 4 hr reaction. We report isolated yields.
The product’s characteristics have been reported in the literature [20-22, 25, 27-32]. Some solvents
were also used to test Biginelli reactions over sulfated zirconia at 60°C. No Hantzsch reaction products
were observed.
Table 2
Entry
R
X
4
Yield (%)
94
1
C
6
H
5
O
O
O
O
S
2
3
4
5
6
7
8
9
2-(CH
4-(CH
5-(CH
3
3
3
)C
6
6
H
4
4
80
)C
H
80
)-2-Furyl
83
C
6
H
5
98
2-(CH )C H
S
90
3
6
4
4-(CH
3
)C
6
H
4
S
86
4-(OCH
3
)C
6
H
4
S
98
2-Furyl
S
88
When the solvent free reactions were carried out at 80°C in the presence of sulfated zirconia, only
traces of Hantzsch product were obtained. A temperature increase, however, favored the

Molecules 2006, 11
735
decomposition of urea into ammonia, thus promoting Hantzsch’s reaction and allowing a competitive
reaction leading to Biginelli 4 and Hantzsch 5 condensation products to take place (Scheme 2).
Scheme 2
R
R
CO Et
O
2
O
CO Et CO2Et
CO2Et
Me
2
2
ZrO /SO4=
HN
+
+
+
R
H
NH2
NH2 Solvent-free
4
hr
O
O
N
H
Me
N
H
Me
1
3
2
4
5
5a R= C6H5
Table 3 shows the different aldehydes used in a one-step solvent-free reaction at 100°C and 150°C
in the presence of a catalytic amount of sulfated zirconia during a 4 hr reaction. In all cases urea was
used.
Table 3
Yield (%)
Entry
R
4
5
4
5
100°C
150°C
1
2
3
4
5
6
7
C
6
H
5
84
78
71
50
59
70
57
10
16
6
52
35
42
25
34
22
57
41
16
51
64
63
57
37
2-(CH
4-(CH
5-(CH
3
3
3
)C
6
6
H
4
4
)C
H
)-2-Furyl
32
20
21
5
2-Furyl
2-(OCH
3
3
)C
6
6
H
4
4
4-(OCH
)C
H
*
Isolated yields of products 4 and 5 are reported.
To examine the reuse of the catalyst the sulfated zirconia was recovered by filtration and washed
with acetone prior to drying. Reactivation was performed by heating the product in air at 500 °C. The
XRD pattern of the materials thus recovered and reactivated were typical of sulfated zirconia, with the
exception that there was an increase in the intensity of the peak at 2θ = 28° that is associated with the
presence of the monoclinic phase. Recently, Sticher et al. reported that in a fixed-bed flow reactor at
3
00 °C monoclinic sulfated zirconia showed lesser catalytic activity in n-butane isomerizations as
compared to the tetragonal phase [33]. Our results indicate that as the number of reactivation cycles
increases, so does the presence of the monoclinic phase, which makes the material proportionally less
catalytically active. Our results using benzaldehyde reflected such a decrease of the catalytic activity at
6
0 °C, whereby an 87% yield of the Biginelli condensation product was obtained in the first cycle and
a 52% one in the second.

Molecules 2006, 11
736
Conclusions
Sulfated zirconia proved to be an efficient acid catalyst replacement for common acid substances
in multicomponent reactions under solventless conditions. Advantages of the technique described were
easy recovery of the catalyst and the good yields of Biginelli and obtained, depending on the reaction
temperarture. An increase of the latter typically increased the amounts of the 1,4-dihydropyridines
(
Hantzsch products) in most cases.
Acknowledgements
Deyanira Angeles Beltrán is indebted to CONACyT, for the financial support via the Postgraduate
Scholarship No. 142059 granted.
Experimental
General
The reaction products were analyzed by means of a Hewlett Packard GC/MS system 6890/5973
gas chromatograph equipped with an HP-5 column, 70-280 °C (10 °C/min), inj. 250 ºC, det. 280 °C;
the detector was set in the Chemical Ionization mode using methane as reactive gas. Powder X-ray
diffraction (XRD) patterns were obtained with a Siemens instrument using Cu Kα radiation. Nitrogen
adsorption/desorption isotherms were plotted at -196 °C on a Micromeritics ASAP 2020 equipment.
Temperature programmed desorption (TPD) measurements were acquired on a Micromeritics
TPD/TPR 2900 instrument (sample was activated at 370 °C for 10 min in flowing He (10 mL/min) and
then, saturation of ammonia at 100 °C (20% NH in He) and desorption at 10 °C/min to 600 °C. IR
3
1
13
spectra were recorded on a Perkin-Elmer FT-IR system/GX spectrometer. H- and C-NMR were
measured on a Bruker Avance DMX-500 spectrometer with tetramethylsilane as internal standard.
Procedure for the preparation of sulfated zirconia catalysts.
Sulfuric acid (98 % wt, 1 mL) was mixed with deionized water (3.5 mL). Zirconium isopropoxide
(
70% wt in 1-propanol, 20 mL) was further diluted with 1-propanol (30.5 mL). The acid solution was
dropwise added to the alkoxide solution under vigorous stirring, until a viscous solution was obtained.
The gel was heated at 80°C to evaporate excess alcohol. After, the dry gel was calcinated at 600°C for
7
h in air, leading to a white solid, identified as sulfated zirconia.
General procedure for the synthesis of DHPs (4) and DHMPs (5).
Ethyl acetoacetate (1 mmol), aldehyde (1 mmol) and amine (urea or thiourea, 1.5 mmol) were
placed in a vial equipped with a magnetic stirrer and plastic cap. The mixture was heated at 60, 80, 100
and 150°C in the presence of sulfated zirconia (50 mg) for 4 h without solvent. After the reaction, the
mixture was left at room temperature, then 1:1 methanol-dichloromethane (10 mL) was added and the

Molecules 2006, 11
737
solid was recovered by filtration. The filtrate was evaporated under reduced pressure and products
were purified by silica gel column chromatography. For entry 1, Table 3, ethyl acetoacetate (1 mmol),
benzaldehyde (1 mmol) and urea (1.5 mmol), in this order, were mixed at 100 °C for 4 h with sulfated
zirconia (50 mg). The results are summarized in Tables 2 and 3. All products were identified by
1
comparison of their corresponding melting points, mass spectra data and H-NMR spectra as follows:
Ethyl 6-methyl-2-oxo-4-phenyl-1,2,3,4-tetrahydropyrimidine-5-carboxylate (4a): Yield 84%; m.p.
+
2
05-206 °C (lit. [25] 206-207°C); GC-MSD for C H N O (m.w.: 260 g/mol): [M+1] =261,
1
4
16
2
3
+
+
-
1
[
M+29] = 289, [M+41] =301; IR (cm ): 3238, 3117, 2980, 1722, 1697, 1644, 1462, 1419, 1383,
1
1
367, 1340, 1313, 1289, 1272, 1217, 1180, 1087, 1027, 956, 879, 824, 756, 697, 661; H-NMR (500
MHz, CDCl ): δ (ppm) 7.77 (br, 1H, NH), 7.27-7.32 (m, 5H, Ar-H), 5.62 (br, 1H, NH), 5.41 (s, 1H,
3
1
3
CH-Ph), 4.04-4.11 (m, 2H, -CH -CH ), 2.35 (s, 3H, -CH ), 1.16 (t, 3H, J= 7.1 Hz, -CH -CH ); C-
2
3
3
2
3
NMR (125 MHz, CDCl ): δ (ppm) 165.47, 153.05, 146.96, 144.00, 128.05, 127.14, 126.25, 100.22,
3
5
9.32, 54.66, 17.99, 13.76.
Ethyl 6-methyl-4-phenyl-2-thioxo-1,2,3,4-tetrahydropyrimidine-5-carboxylate (4b). Yield 98%; m.p.
+
2
02-204°C (lit. [32] m.p. 205-206°C); GC-MSD for C14
H
16
N
2
O
2
S (m.w.: 276g/mol): [M+1] =277,
+
+
-
1
[
M+29] = 305, [M+41] =317; IR (cm ): 3324, 3169, 3102, 2981, 2234, 2001, 1666, 1572, 1495,
1
8
1
464, 1449, 1425, 1388, 1344,1326, 1302, 1263, 1192, 1175, 1117, 1027, 1003, 963, 916, 871, 836,
1
22, 781, 758, 722, 692, 651,615; H-NMR (500 MHz, CDCl ): δ (ppm) 9,68 (br, 1H, NH), 9,06 (br,
3
H, NH), 7.27-7.31 (m, 5H, Ar-H), 5.33 (s, 1H, CH-Ph), 4.04-4.09 (m, 2H, -CH -CH ), 2.36 (s, 3H, -
2
3
1
3
CH ), 1.16 (t, 3H, J= 6.97 Hz, -CH -CH ); C-NMR (125 MHz, CDCl ): δ (ppm) 174.09, 164.99,
3
2
3
3
1
43.93, 142.92, 127.82, 127.11, 126.23, 101.11, 59.26, 54.56, 17.14, 13.48.
Diethyl 2,6-dimethyl-4-phenyl-1,4-dihydropyridine-3,5-dicarboxylate (5a): Yield 10%; m.p. 154-155
+
+
°
C (lit. [25] m.p. 156-157 °C); GC-MSD for C19
H23NO
4
(m.w.: 229 g/mol): [M+1] =330, [M+29] =
+
-
1
3
1
7
58, [M+41] =370; IR (cm ): 3340, 3061, 2982, 1725, 1685, 1648, 1621, 1560, 1486, 1474, 1453,
372, 1322, 1299, 1247, 1207, 1167, 1143, 1122, 1091, 1032, 1019, 916, 882, 843, 827, 777, 766, 737,
1
02, 679, 638, 619; H-NMR (500 MHz, CDCl ): δ (ppm) 7.26-7.29 (m, 2H, Ar-H), 7.20 (t, 2H, J= 7.3
3
Hz, Ar-H), 7.11 (tt, 1H, J = 2.0, J = 7.3 Hz, Ar-H), 5.78 (br, 1H, NH), 4.99 (s, 1H, CH-Ph), 4.03-4.13
1
2
(
m, 4H, -CH -CH ), 2.32 (s, 6H, -CH ), 1.22 (t, 6H, J= 7.2 Hz, -CH -CH ); 13C-NMR (125 MHz,
2 3 3 2 3
CDCl ): δ (ppm) 167.66, 147.76, 143.90, 127.70, 127.95, 126.06, 104.02, 59.60, 39.59, 19.45, 14.20.
3
References
1
.
a) Lu, J.; Bai, Y.; Wang, A.; Yang, B.; Ma, H. Tetrahedron Lett. 2000, 18, 9075-9078 ; b) Ma,
Yun.; Qian, C.; Wang, L.; Yang, M. J. Org. Chem. 2000, 62, 3864-3868 ; c) Ranu, B. C.; Hajra,
A.; Jana, U. J. Org. Chem. 2000, 65, 6270-6272.
2
3
4
5
.
.
.
.
Varma, R. S. Tetrahedron 2002, 58, 1235-1255.
Corma, A.; García, H. Chem. Rev, 2003, 103, 4307-4366.
Sen, S. E.; Smith, S. M.; Sullivan, K. A. Tetrahedron 1999, 55, 12657-12698.
Song, X.; Sayari, A. Cat. Rev. Sci. Eng. 1996, 38, 329-412.

Molecules 2006, 11
738
6
7
.
.
Benjaram, M. R.; Pavani, M.S. Tetrahedron Lett. 2003, 44, 4447-4449.
Negrón, G.; Angeles, D.; Lomas, L.; Martínez, A.; Ramírez, M.; Martínez, R. Heterocycles 2004,
3, 367-371.
Deutsch, J.; Trunschke, A.; Muller, D.; Quaschning, V.; Kemnitz, E.; Lieske, H. Catalysis Lett.
003, 88, 9-15.
Toshima, K.; Nagai, H.; Kasumi, K.; Kawahara, K.; Matsumura, S. Tetrahedron 2004, 60, 5331-
339.
6
8
9
.
.
2
5
1
1
1
0. Wolfson, A.; Shokin, O.; Tavor, D. J. Mol. Catal. A. 2005, 226, 69-76.
1. Biró, K.; Figueras, F.; Békássy, S. Appl. Catal. A: Gen. 2002, 229, 235-243.
2. Negrón, G.; Palacios, L.; Angeles, D.; Lomas, L.; Gaviño, R. J. Braz. Chem. Soc. 2005. 16, 490-
4
94.
1
1
1
3. Tanaka, K.; Toda, F. Chem. Rev. 2000, 100, 1025-1074.
4. Biginelli, P. Gazz. Chim. Ital. 1893, 23, 360-416.
5. a) Kappe, O. Tetrahedron 1993, 49, 32, 6937-6963; b) Kappe, O. J. Org. Chem. 1997, 62, 3109-
3
118.
1
1
1
1
2
2
6. Lin, H.; Ding, J.; Chen, X.; Zhang, Z. Molecules 2000, 5, 1240-1243.
7. Salehi, P.; Dabiri, M.; Zolfigol, M. A.; Fard, M. A. B. Heterocycles 2003, 60, 2435-2440.
8. Juaristi, E.; Muñoz-Muñiz, O. ARKIVOC 2003, XI, 16-26.
9. Gohain, M.; Prajapati D ; Sandhu J. S. Synlett., 2004, 2, 235-238.
0. Cepanec, I.; Litvic, M.; Bartolinčić, A.; Lovrić, M. Tetrahedron, 2005, 61, 4275-4280.
1. a) Reddy, B. M.; Sreekanth, P. M.; Reddy, V. R. J. Mol. Catal. A: Chem. 2005
Reddy, B. M.; Sreekanth, P. M.; Lankshmanan, P. J. Mol. Catal. A: Chem. 2005
,
225
,
71-78; b)
,
237
,
93-100; c)
Singh V.; Sapehiyia V.; Srivastava V.; Kaur S. Catal. Commun. 2006, 7, 571-578.
2. Stout, D. M. Chem. Rev. 1982, 82, 223-243.
2
2
2
3. Zolfigol, M. A.; Safaiee, M. Synlett 2004, 5, 827-828.
4. a) Janis, R. A.; Silver, P. J.; Triggle, D. J, Adv. Drug Res. 1987, 16, 309-591; b) Bossert, F.;
Meyer, H.; Wehinger, E. Angew. Chem. Int. Ed. Eng. 1981, 20, 762-769.
5. Osnaya, R.; Arroyo, G. A.; Parada, L.; Delgado, F.; Trujillo, J.; Salmón, M.; Miranda, R.,
ARKIVOC 2003, XI, 112-117.
2
2
2
2
2
3
3
3
6. Legay, J.C.; Vanden, E. J. J.; Bazureau, J. P. Tetrahedron 2005, 61, 12386-12397.
7. Sridhar, R.; Perumal, P. T. Tetrahedron 2005, 61, 2465-2470.
8. Salehi, H.; Guo, P. X. Synth. Commun. 2004, 34, 4349-4357.
9. Yutaka, W.; Kazuhiro, S.; Tomonori, H.; Shoichiro, O. Synthesis 1983, 9, 759-761.
0. Liselotte, O.; Westman, J. Synlett 2001, 8, 1296-1298.
1. Khodabakhsh, N.; Mohammah, Z.; Mehdi, S.; Iraj, M. Heterocycles 2005, 65, 657-660.
2. Zhidovinova, M. S.; Fedorova, O.V.; Rusinov, G.L.; Ivchinnikova, I. G. Rus. Chem. Bull. 2003,
5
2, 2527-2528.
3
3. Stichert, W.; Schüth, F.; Kuba, S.; Knüozinger, H. J. Catal. 2001, 198, 277-285.
Sample Availability: Available from the authors.
2006 by MDPI (http:www.mdpi.org). Reproduction is permitted for non commercial purposes.
©
