Light-Induced Regiospecific Bromination of meso-Tetra(3,5-
Di-tert-butylphenyl)Porphyrin on 2,12 beta-Pyrrolic Positions
Gabriele Di Carlo, Alessio Orbelli Biroli, Francesca Tessore, Silvia
Rizzato, Alessandra Forni, Giulia Magnano, and Maddalena Pizzotti
J. Org. Chem., Just Accepted Manuscript • Publication Date (Web): 20 Apr 2015
Downloaded from http://pubs.acs.org on April 25, 2015
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
The Journal of Organic Chemistry is published by the American Chemical Society.
1155 Sixteenth Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 22
The Journal of Organic Chemistry
1
2
3
4
5
LightꢀInduced Regiospecific Bromination of mesoꢀ
6
7
8
9
Tetra(3,5ꢀDiꢀtertꢀbutylphenyl)Porphyrin on 2,12
βꢀ
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Pyrrolic Positions
Gabriele Di Carlo,*,† Alessio Orbelli Biroli,‡ Francesca Tessore,† Silvia Rizzato,† Alessandra
Forni,†,‡ Giulia Magnano† and Maddalena Pizzotti†
† Department of Chemistry, University of Milan, Via C. Golgi 19, 20133 Milano, Italy
‡ Institute of Molecular Sciences and Technologies of CNR (ISTMꢀCNR), Via Golgi 33, Iꢀ20133
Milano, Italy
Eꢀmail: gabriele.dicarlo@unimi.it
GRAPHICAL ABSTRACT
