Measurement and Correlation of Solubility of Benzothiazolium Ionic
Liquids in Ethanol + Ethyl Benzoate
Tian Yao and Kaifeng Du*
Cite This: https://dx.doi.org/10.1021/acs.jced.9b00997
Read Online
sı
*
Metrics & More
Article Recommendations
Supporting Information
ACCESS
ABSTRACT: The solubilities of benzothazolium-based ionic liquids (ILs) [HBth][BF4], [HBth][CH3SO3], and [HBth][p-TSA] in
binary ethanol + ethyl benzoate solvents were measured using the equilibrium method with the temperature range from 233.2 to
293.7 K at atmospheric pressure. Results of these measurements were correlated by both λh equation and the modified Apelblat
equation. It was found that both models gave satisfactory correlation results. In the λh model, the average relative deviations were
0.7145, 0.7845, and 0.8119% for [HBth][BF4], [HBth][CH3SO3], and [HBth][p-TSA], respectively. Interestingly, the parameters of
λ and h for the λh model and A, B, and C for the modified Apelblat model were simultaneously expressed as functions of solvent
composition (xsol) for the first time. Furthermore, solubilities of these three ILs in the binary system were predicted through these
two sets of self-created correlation equations with ideal performances. The total average relative deviations were less than 2.2% for
both models. These successful in-depth correlations and validated prediction results have guaranteed the accuracy of experimental
solubility data and provide us a reliable method for accurate solubility prediction at any temperature with any solvent composition.
This developed calculation method in this report lays a foundation for accurate industrial recovery of ILs and gives us valuable
guidance for the design of the specific purification process to acquire desired purity of the product in industrial production.
Song et al.18 reported the first esterification of aromatic acid with
alcohols catalyzed by “temperature-sensitive” ILs. These
INTRODUCTION
■
Aromatic esters are very important chemical intermediates with
functionalized ILs including [HBth][BF4], [HBth][CH3SO3],
wide applications in the chemical industry and are usually
synthesized through acid-catalyzed esterification reactions1 or
and [HBth][p-TSA] had very large solubility differences with
only small-scale changes of temperature in many alcohols.19
synthesized through enzymatic esterification reactions2−4 with
alcohols and benzoic acids as raw materials. Inorganic acids such
They exhibited excellent catalytic performances and ideal
recoveries. Among them, esterification yield of benzoic acid
could reach up to 97.3% in ethanol with [HBth][CH3SO3] as
the catalyst, which is showing great industrial application
as H3PO4, H2SO4, and so forth, have been widely applied as
catalysts for the esterification.5−9 Although high yields were
acquired, usage of a large amount of organic solvents and
difficulty in the catalyst recovery could result in environmental
potential. Although this temperature-sensitive IL-catalyzed
esterification of benzoic acid in ethanol had excellent perform-
ances, there still exists some amount of ILs dissolved in the
ethanol + ethyl benzoate solution after cooling down to room
temperature at the end of the reaction. Due to the high cost of IL
and high requirement of product purity,20 it is vitally important
contamination. Thus, it is necessary to develop novel environ-
mentally friendly, efficient, and recyclable catalysts.
Ionic liquids (ILs), a class of nonmolecular solvents with low
melting points, negligible volatility, wide liquid range, and good
chemical stability and solubility,10,11 have drawn widespread
attention of researchers. In the field of synthetic chemistry, they
often replace hazardous organic solvents and serve as an
environmentally friendly, nonvolatile, and recyclable reaction
medium.12 Many researchers have already successfully applied
ILs in the esterification with reduced reaction time and
temperature as well as satisfactory recyclability.13−17 Later,
Received: October 18, 2019
Accepted: December 27, 2019
https://dx.doi.org/10.1021/acs.jced.9b00997
J. Chem. Eng. Data XXXX, XXX, XXX−XXX
© XXXX American Chemical Society
A

Journal of Chemical & Engineering Data
pubs.acs.org/jced
Article
Figure 1. Synthetic routes and molecular structures of [HBth][BF4], [HBth][CH3SO3], and [HBth][p-TSA].
Table 1. Provenance and Purity of the Chemicals Used in This Work
chemical name
source
prepared in lab
prepared in lab
initial mole fraction purity
purification method
final mole fraction purity analysis method
[HBth][BF4]
[HBth][CH3SO3]
[HBth][p-TSA]
ethyl benzoate
ethanol
0.95
0.96
0.95
≥0.995
≥0.995
≥0.995
developed in our lab
developed in our lab
developed in our lab
no further purification
no further purification
no further purification
≥0.99
≥0.99
≥0.99
HPLC
HPLC
HPLC
prepared in lab
Kelon Chemical Reagent Co., Ltd.
Kelon Chemical Reagent Co., Ltd.
Kelon Chemical Reagent Co., Ltd.
≥0.995
≥0.995
≥0.995
ethyl acetate
to further crystallize IL out for recycle by cooling the system
down to very low temperature. Therefore, accurate solubility
data of these ILs in this binary system at low temperature is of
vital importance for the guidance of industrial separation.
Herein, we report the solubility data of three ILs ([HBth]-
[BF4], [HBth][CH3SO3], and [HBth][p-TSA]) in the binary
ethanol + ethyl benzoate solvents at low temperature ranging
from 233.2 to 293.7 K at atmospheric pressure. These data were
ideally fitted by the λh equation and the modified Apelblat
equation, respectively. Surprisingly, for the first time, parameters
of λ and h for the λh model and A, B, and C for the modified
Apelblat model were simultaneously expressed as functions of
solvent composition (xsol) with satisfactory correlation co-
efficients (R2). Furthermore, solubilities of these three ILs at any
solvent composition and any temperature could be accurately
predicted through both models.
Corporation, Germany) in DMSO-d6 with tetramethylsilane
(TMS) as an internal standard. 1H NMR spectra were recorded
at 400 MHz, and 13C NMR spectra were recorded at 100 MHz.
The electrospray ionization mass spectrometry (ESI-MS)
spectra were recorded on a ZQ 4000 mass spectrometer
(Waters Corporation, USA). An LC20-AT high-performance
liquid chromatography (HPLC) instrument (Shimadzu Co.,
Japan) consisting of a diode array detector was used for the
analysis and quantitation of targeted IL. A Welchrom C18
column (4.6 × 250 mm, 5 μm) was used as the HPLC analytical
column.
Synthesis and Purification of ILs. The synthesis of ILs was
according to the reported literature.19 Briefly, 0.5 mol accurate
amount of benzothiazole was dissolved in 100 mL of anhydrous
ethanol and placed in a round-bottom flask equipped with a
magnetic stirrer in an ice bath. Equal molar of fluoroboric acid
(methanesulfonic acid or p-toluenesulfonic acid) dissolved in
about 40 mL of ethanol was added dropwise into the round-
bottom flask under adequate stirring for about 1 h. Afterward,
the mixture was continuously stirred for 12 h at room
temperature. Ethanol was removed by evaporation under
vacuum to give the crude product as a white solid. It was then
washed three or four times by ethyl acetate and recrystallized in
anhydrous ethanol to give the final pure product, which was
dried for more than 12 h under vacuum at 343 K. The ILs were
characterized by 1H NMR, 13C NMR, and ESI-MS (the detail is
shown in the Supporting Information). The synthetic route of
ILs is shown in Figure 1. Melting points were determined as 398
K for benzothiazolium tetrafluoroborate ([HBth][BF4]), 378 K
for benzothiazolium methanesulfonate ([HBth][CH3SO3]),
and 393 K for benzothiazolium p-toluene sulfonate ([HBth]-
[p-TSA]).19 All these three purified ILs have mole fraction
purities higher than 99% determined by HPLC. The provenance
of main used chemicals and their purities are given in Table 1.
Solubility Measurement. The solubility of ILs was
measured by a static equilibrium method as presented in Figure
2. The concentration determination of ILs was conducted by the
EXPERIMENTAL SECTION
■
Chemicals and Apparatus. Benzothiazole (CAS number
95-16-9) of analytical grade was supplied by Xilong Chemical
Factory in Shantou City, Guangdong. Tetrafluoroboric acid
(CAS number 16872-11-0), methanesulfonic acid (CAS
number 75-75-2), ethyl benzoate (CAS number 93-89-0), p-
toluenesulfonic acid (CAS number 104-15-4), ethyl acetate
(CAS number 141-78-6), anhydrous ethanol, and so forth, were
purchased from Chengdu Kelon Chemical Reagent Co., Ltd.,
with analytical grade or above. All used water was ultrapure
water obtained from an ultrapure water purification system (0.4
mm filter) manufactured by Millipore Co., Ltd. (Bedford, MA,
USA). A RE-3000B rotary evaporator (Shanghai Yarong
Biochemical Instrument Co., Ltd., China) was applied for
vacuum evaporation. Melting points were measured by an XRC-
1 melting point apparatus (Sichuan University Instrument Co.,
Ltd.). Mass values were measured by an electronic balance
(ESJ200-4A, Longteng Electronics Co., Ltd., Shenyang, China)
1
with an uncertainty of 0.0001 g. H NMR and 13C NMR
spectra were recorded on an AV-400 spectrometer (Bruker
B
https://dx.doi.org/10.1021/acs.jced.9b00997
J. Chem. Eng. Data XXXX, XXX, XXX−XXX

Journal of Chemical & Engineering Data
pubs.acs.org/jced
Article
where MA, M1, and M2 represent the molecular weights of the
solute, ethyl benzoate, and ethanol, respectively. xsol is the molar
fraction of ethyl benzoate in the binary solvent system. x is the
molar fraction solubility of IL.
The solubilities of three benzothiazolium-based ILs were
determined in the temperature range of 233.2 to 293.7 K. First of
all, we determined the solubilities in ethanol and compared these
results with the previous literature19 in the Supporting
Information. Then, the solvent compositions (xsol) were defined
as 0.25, 0.33, 0.50, 0.67, and 1.00 in the main text. As
demonstrated in Tables 2−4, solubility data of these ILs in
different solvent compositions were measured and correlated by
the λh equation and the modified Apelblat equation. The λh
model is a semiempirical equation proposed by Buchowski et
al.21 and is given as eq 4.
Figure 2. Apparatus for determination of solubilities of [HBth][BF4],
[HBth][CH3SO3], and [HBth][p-TSA]. (1) Preprogrammed auto-
matic temperature controller, (2) thermostat with ethanol as medium,
(3) rubber plug, (4) mercury thermometer, (5) sample connection, (6)
crystallizer, and (7) magnetic stirrer.
