Poly(ethylene glycol) stabilized Co nanoparticles as highly active and
selective catalysts for the Pauson–Khand reaction{
Jean-Luc Muller,a Ju¨rgen Klankermayera and Walter Leitner*ab
Received (in Cambridge, UK) 14th February 2007, Accepted 22nd March 2007
First published as an Advance Article on the web 11th April 2007
DOI: 10.1039/b702330h
PEG-stabilized cobalt nanoparticles were prepared by thermal
decomoposition of [Co2(CO)8] in PEG and were shown to be
highly active and selective catalysts, for intra- and intermole-
cular Pauson–Khand reactions (PKR), in organic solvents or
aqueous media.
The [2 + 2 + 1] cycloaddition of alkynes with alkenes and carbon
monoxide (CO) to form cyclopentenones is known as Pauson–
Khand reaction (PKR).1 The original reaction setup2 required a
Fig. 1 PEG-stabilized Co-nanoparticles.
stoichiometric application of cobalt complexes derived from
[Co2(CO)8], but catalytic versions were developed more recently.3,4
carbonyl absorptions, indicating a complete decomposition of the
metal carbonyl. In a first set of experiments the intramolecular
PKR (Scheme 1) catalyzed by the PEG-stabilized cobalt
nanoparticles was investigated. Under optimized reaction condi-
tions conversions of 1 were almost quantitative using catalyst
loadings of only 3.3 mol% (Table 1). By using higher catalyst
loadings a significant decrease of the pressure under otherwise
identical conditions was possible (Entry 3–4, Table 1).
Nevertheless the practical utility of this synthetic method is still
limited by problems of catalyst separation and the volatile and
toxic nature of cobalt carbonyls.1
Our group recently demonstrated that commercially available
Raney cobalt acts as active and recyclable catalyst for inter- and
intramolecular PKR.5 Raney cobalt can be efficiently separated
and reused by filtration and/or exploiting its ferromagnetic
properties. Chung and co-workers deposited cobalt particles by
thermal decomposition of [Co2(CO)8] onto various supports and
demonstrated the catalytic activities of the resulting materials for
the PKR.6,7 Colloidal cobalt nanoparticles in supported or
unsupported form were also used as reusable catalysts for this
reaction.8,9 Cobalt nanoparticles, for the intramolecular PKR in
aqueous solution, stabilized by sodiumdodecylsulfate (SDS) were
reported.10 All these nanoparticle catalysed systems require very
high catalyst loadings approaching stoichiometric ratios in many
cases. So far only heterobimetallic Co/M (M = Rh,11 Ru12)
nanoparticles on charcoal lead to active catalytic systems that
operate at loadings of a few mol%.
The scope of this new protocol was tested in a variety of
different intra- and intermolecular PKRs. Representative results
obtained under standard conditions are given in Table 2. Almost
quantitative conversions were achieved with both catalysts for
the malonate derived enynes 1 and 3 as well as for the diol 5. The
PEG-stabilized cobalt nanoparticles were also active for the
intramolecular PKR in water, giving high yields of cyclic products
(Scheme 2). Interestingly the decarboxylated compound 16 was
formed to a large extent under these conditions. In contrast, the
literature reported hydrogenation of the double bond in water, was
not observed.10,13
The intermolecular PKR of norbonene 7 with different alkynes
occurs also smoothly with both catalysts, also a higher catalyst
loading and and increased CO pressure was required. Again, protic
functional groups were tolerated (Table 2, entry 3, 5) and excellent
conversions and selectivities were obtained in all cases. The
performance of the two different types of nanoparticles was largely
identical for the various substrates.
Here we report that poly(ethylene glycol) PEG-stabilized cobalt
nanoparticles serve as readily available, highly active and partly
recyclable catalysts for the PKR. The catalysts are compatible with
organic solvents and aqueous solutions as reaction media. PEG-
stabilized cobalt nanoparticles were prepared by thermal decom-
position of [Co2(CO)8] in molten PEG at 80–100 uC. PEG of
molecular weight 1000 and 5000 was used. Transmission electron
microscopic (TEM) pictures confirmed that the particles stabilized
either with PEG1000 or PEG5000 were smaller than 1.6 nm and well
dispersed (Fig. 1). The IR spectra of the catalysts showed no
The workup of the reaction mixture is particularly straight
forward with the PEG5000-stabilized Co-nanoparticles. These
materials are readily separated from the reaction mixture using
aInstitut fu¨r Technische und Makromolekulare Chemie, RWTH Aachen,
Worringerweg 1, 52074, Aachen, Germany
bMax Planck Institut fu¨r Kohlenforschung, Kaiser-Wilhelm-Platz 1,
45470, Mu¨lheim an der Ruhr, Germany
{ Electronic supplementary information (ESI) available: An experimental
section for the synthesis and characterisation of the PEG-stab. cobalt
nanoparticles and the catalysis and characterisation of the products. See
DOI: 10.1039/b702330h
Scheme 1 Intramolecular PKR reaction with PEG-stabilized
Co-nanoparticles.
This journal is ß The Royal Society of Chemistry 2007
Chem. Commun., 2007, 1939–1941 | 1939

View Article Online
Table 1 Pressure dependence of the PKR catalysed by the PEG-
stabilized Co-nanoparticles
Conversion
[%]
Selectivity
for 2 [%]
Entry
Co [mol%]
Pressure/bara
1
2
3
4
a
3
3
50
50
23
10
10
5
¢99.0
35.1
97.4
98.0
89.8
98.2
91.8
84.5
Pressure in the autoclave at 130 uC. Reaction conditions: All
reactions were performed in 4 mL THF, in a 10 mL window
equipped steel autoclave. Reaction time 16 h. Catalyst: PEG5000
stabilized Co-nanoparticles.
Scheme 2 Intramolecular PKR in water.
-
