Tackling the Spiro Tetracyclic Skeleton of Cyanogramide:
Incorporation of a Hydantoin Moiety
Marco Monecke and Thomas Lindel*
TU Braunschweig, Institute of Organic Chemistry, Hagenring 30, 38106 Braunschweig, Germany
S
* Supporting Information
ABSTRACT: Wang’s enantioselective thiourea-catalyzed spiro-annulation paved the way
to the first tetracyclic analog of the marine natural product cyanogramide from the
actinobacterium Actinoalloteichus cyanogriseus. The synthesis comprises seven steps starting
from an alkylidene indolinone. Installation of the (E)-styryl side chain faced a
regiochemistry problem, circumvented by prior conversion to the hydantoin and
employing Batey’s conditions. Comparison of the ECD spectra of the spiro indoline
pyrrolo[1,2-c]imidazole and cyanogramide confirmed the absolute configuration of the
natural product.
aminal ester 2. We also included the related tetracyclic
compound 4, where the C2 unit of cyanogramide is replaced by
a carbonyl group. The resulting hydantoin moiety of 4 could
be more stable than ring D of the putative, demethylated
cyanogramide derivative 2. The styryl side chain was to be
introduced by Cu-mediated N−C coupling.
For studies toward 3, we chose racemic 3,3′-thiopyrrolidonyl
spiro-oxindole 5, the ethyl ester analog of which had been
obtained by Jiangtao Sun et al.6 and by Rui Wang et al.7 by
Michael addition/cyclization of α-isothiocyanato imides to 2-
oxoindolin-3-ylidene acetates in the presence of DBU (1,8-
diazabicyclo[5.4.0]undec-7-ene, Scheme 2; see the Supporting
he marine indole alkaloid cyanogramide (1, Scheme 1)
Twas isolated from the marine-derived actinobacterium
Actinoalloteichus cyanogriseus by Weiming Zhu et al. in 2014.1
The molecule features a pyrrolo[1,2-c]imidazole system, which
is spiro-fused to an oxindole. Cyanogramide (1) is the only
natural product exhibiting that tetracyclic partial structure.
Besides, only a few tetracyclic structures are known that share
the tricyclic spiro[indoline-3,3′-pyrrole]dione moiety with
compound 1. In all cases, an oxazolidine ring is annulated
instead of the imidazolinone of cyanogramide (1).2−4 Only
one molecule has been described that contains the double
bond present in ring C of cyanogramide.5 While cyanogramide
(1) showed only weak cytotoxicity against the adriamycin- and
vincristine-resistant cancer cell lines, it reversed their resistance
against adriamycin and vincristine at 5 μM concentration. This
effect was attributed to inhibition of the P-glycoprotein, an
ATP dependent drug efflux pump highly expressed in the
tested cell lines, by cyanogramide (1).1
Scheme 2. Synthesis of Spiro-indolone Pyrrolone 9 from
Spiro-thiolactam 5
Initially, we expected that the pyrrolo[1,2-c]imidazole-1,5-
dione system of cyanogramide (1, rings C and D, Scheme 1)
could be accessed by cyclization of an N-acetylated, pyrrolone
carboxamide-based precursor 3, being in equilibrium with
Scheme 1. Spiro-indolone Alkaloid Cyanogramide (1) from
the Marine-Derived Bacterium Actinoalloteichus
cyanogriseus, Putative Synthetic Precursors
Received: November 5, 2018
© XXXX American Chemical Society
A
DOI: 10.1021/acs.orglett.8b03540
Org. Lett. XXXX, XXX, XXX−XXX

Organic Letters
Letter
Information). It was possible to convert spiro-pyrrolidine-2-
thione 5 to the corresponding lactam 6 by treatment with
H2O2/HCO2H (97%), followed by conversion to carboxylic
acid 7 with TFA (trifluoroacetic acid). For the subsequent
Barton decarboxylation we were inspired by Williams’
synthesis of spirotryprostatin B and derivatives.8 Decarbox-
ylation of 7 by formation of the acid chloride, in situ
conversion to the Barton ester, reaction with BrCCl3 under
irradiation conditions,8 and reaction with DBU afforded the
α,β-unsaturated spiro-indolone pyrrolone 9 in modest yield
(27%), which was difficult to purify. All our attempts to subject
9 to ammonolysis led to decomposition, which led us to
abandon that pathway.
Scheme 4. Synthesis of TMSE-Protected Spiro-
pyrrolidinone Carboxamide 19 via Thiourea-Catalyzed
Michael Addition/Cyclization
As long as the ester moiety was in place, ammonolysis of 6
was facile and afforded pyrrolidinone carboxamide 10 (Scheme
3). Buchwald coupling of 10 with (E)-β-bromostyrene (11)
Scheme 3. Study on the Relative Reactivity of the Lactam
and Primary Amide Nitrogen Atoms towards Buchwald
Coupling, Starting from Spiro-indolone 6
20
The optical rotatory power of 17 ([α]D = −33.6, c = 1.0)
corresponds well to values reported by Wang et al. for similar
compounds. Oxidative hydrolysis of 17 afforded lactam 18,
followed by ammonolysis to TMSE ester 19.
As concluded from the behavior of spiro-pyrrolone
carboxamide 10 (Scheme 3), regioselective N-styrylation
would require protection of the lactam nitrogen, ideally by
acetylation. Thus, we attempted the acetylation of lactam 19
(Scheme 5). Acetylated product 20 was obtained regioselec-
tively in quantitative yield. The constitution of 20 was secured
by an HMBC correlation of the α-hydrogen 5′-H and the
acetyl carbonyl carbon. Heating of 19 under reflux with 10
equiv of Ac2O led to double N-acetylation affording 24 (82%).
However, there was no tendency of 20 or 24 to undergo
cyclization to a 2-hydroxy-2-methylimidazolidin-4-one, which
would correspond to the core structure of cyanogramide (1).
Surprisingly, Buchwald coupling of N-acetylated lactam 20
with bromostyrene 11 did not occur at the free primary amide
moiety. Instead, we isolated compound 21 (Scheme 5), where
the acetyl was replaced by the styryl group. Apparently, the
acetyl group was cleaved off by Cs2CO3 that preceded the N−
C coupling. Even under Batey’s conditions11 employing
potassium styryl trifluoroborate (22)/Cu(OAc)2/O2 we
observed undesired styrylation of the lactam nitrogen.
Differing from 21, the acetyl group had migrated to the
neighboring primary amide resulting in compound 23. All
attempts to install a styryl unit at the diacetylated tricycle 24
under either Buchwald’s or Batey’s conditions failed.
under microwave conditions with elevated amounts of CuI
(1.1 equiv)/DMEDA (N,N′-dimethylethylenediamine, 2.2
equiv), as applied in our synthesis of parazoanthine F,9
resulted in the formation of the undesired N-styryllactam 12
(45%). The primary amide moiety had remained in place. To
check the general availability of the primary amide moiety for
Buchwald coupling, we reacted 12 again and obtained bis-
styryl product 13 in moderate yield (41%). Thus, both
functional groups did react, but not in the desired order, and
the lactam nitrogen had to be functionalized before Buchwald
coupling.
For further experiments, we replaced the tert.-butyl ester by a
TMSE ((trimethylsilyl)ethyl) ester function, because the tert-
butyl group had shown some instability. We also switched to
the optically active series. TMSE ester 14 (Scheme 4) was
obtained by Wittig reaction of N-methylisatin and the
corresponding acetic acid based phosphorane (see the
Supporting Information). Reaction of 14 with isothiocyanato
compound 1510 in the presence of chiral organocatalyst 167
afforded spiro-indolinone 17 in high yield (88%) and perfect ee
(Scheme 4, >98%, as judged by analytical HPLC; see the
Supporting Information). The relative configuration of product
17 was derived from an intense NOESY correlation between
5′-H and 4-H of the indolone.
We concluded that the fourth ring of the cyanogramide
skeleton had to be formed prior to styrylation and, given our
observation with the acetyl group, introduced a C1 instead of a
C2 unit. While treatment of lactam-carboxamide 19 with
B
DOI: 10.1021/acs.orglett.8b03540
Org. Lett. XXXX, XXX, XXX−XXX

Organic Letters
Letter
Scheme 5. Reaction of Mono- or Diacetylated Spiro-indoles
