R E S E A R C H A R T I C L E
Efficient global monitoring statistics for high-dimensional
data
Jun Li
Department of Statistics, University of
California, Riverside, California
Abstract
Global monitoring statistics play an important role in developing efficient mon-
itoring schemes for high-dimensional data. A number of global monitoring
statistics have been proposed in the literature. However, most of them only
work for certain types of abnormal scenarios under specific model assumptions.
How to develop global monitoring statistics that are powerful for any abnor-
mal scenarios under flexible model assumptions is a long-standing problem in
the statistical process monitoring field. To provide a potential solution to this
problem, we propose a novel class of global monitoring statistics. Our proposed
global monitoring statistics are easy to calculate and can work under flexible
model assumptions since they can be built on any local monitoring statistic that
is suitable for monitoring a single data stream. Our simulation studies show that
the proposed global monitoring statistics perform well across a broad range of
settings and compare favorably with existing methods.
Correspondence
Jun Li, Department of Statistics,
University of California, Riverside,
Riverside, CA 92521, U.S.A.
Email: jun.li@ucr.edu
KEYWORDS
CUSUM, process change detection, quantile vs quantile, statistical process control
1
INTRODUCTION
Advanced manufacturing and data acquisition technologies have made the gathering of high-dimensional data possible
in many fields. The demand for efficient online monitoring tools for such data has never been greater. Depending on the
purpose, two types of monitoring schemes are needed.
The first type is for applications in which changes in any of data streams indicate the same abnormality in the whole
system and require a single, uniform corrective action. As a result, those applications do not require the identification
of abnormal data streams. For example, in the environmental monitoring application, hundreds or thousands of sensors
are usually deployed to monitor certain environmental factors. The abnormality of data from any of those sensors will
indicate a general abnormality in those environmental factors. In many cases, it is not of interest to identify which sensors
have caused the alarm. Since it is not required to identify abnormal data streams for this type of monitoring scheme, a
popular approach for developing monitoring schemes of this type is to use a single global monitoring statistic to track all
data streams jointly. As a result, a global monitoring statistic that is powerful for detecting any abnormal scenario is the
key for developing any efficient monitoring scheme of this type.
The second type of monitoring scheme is for applications in which changes in different data streams indicate different
problems in the system, requiring unique corrective actions. As a result, this type of monitoring scheme needs to identify
which data stream is experiencing abnormal activities. For example, in the network traffic surveillance application, the
network traffic data from different data streams are associated with different IP addresses. When some abnormality in
the data occurs, identifying which data stream or IP address has caused the problem is very important, as doing so helps
Qual Reliab Engng Int. 2019;1–15.
wileyonlinelibrary.com/journal/qre
© 2019 John Wiley & Sons, Ltd.
1

2
LI
pinpoint the cause and guides future corrective actions. As pointed out in Li,1 the following two-stage strategy can be
very effective to develop this type of monitoring scheme. In the first stage, a global monitoring statistic is used to decide
whether there is any abnormal data stream. If this is the case, the second stage is activated, and a local monitoring statistic
is used to decide which data streams are abnormal. As shown in Li,1 this two-stage strategy has better performance than
the one-stage strategy. On the basis of this two-stage strategy, it is evident that what global monitoring statistic to use in
the first stage becomes critical, since it will ultimately affect the effectiveness of the resulting monitoring scheme in terms
of how quickly it will raise an alarm when some of the data streams start experiencing abnormal activities.
From the above discussions, it is clear that an efficient global monitoring statistic is important for developing effi-
cient monitoring schemes of both types. How to construct efficient global monitoring statistics for high-dimensional
data streams has been an active research topic in the statistical process monitoring field. A number of global monitoring
statistics have been proposed. However, most of them only work for certain types of abnormal scenarios under specific
model assumptions. For example, under the assumption that each data stream follows a normal distribution and using the
cumulative sum (CUSUM) statistic as the local monitoring statistic for each data stream, Tartakovsky et al2 and Mei3 pro-
posed using the maximum and sum of those CUSUM statistics, respectively, as the global monitoring statistic. It has been
shown that the sum of those CUSUM statistics is more effective than the maximum when a moderate or large number of
data streams are abnormal and vice versa when only a few data streams are abnormal. In practice, it is usually unknown
in advance how many data streams will be abnormal. Therefore, neither the maximum or the sum of those CUSUM
statistics as the global monitoring statistic guarantees robust performance. Xie and Siegmund4 recognized this limita-
tion and proposed a global monitoring statistic derived from the likelihood function of a normal-mixture model. Besides
being computationally intensive, their approach also needs to pre-specify the percentage of abnormal data streams. If the
percentage is misspecified, their approach will sacrifice some power. Zou et al5 proposed some alternative way to com-
bine the CUSUM statistics from all data streams to produce a single global monitoring statistic. This approach does not
require prior knowledge about how many data streams are abnormal and performs well compared with the aforemen-
tioned methods across different abnormal scenarios. However, it is not clear how to extend their approach to develop some
computationally efficient global monitoring statistics for situations where the local monitoring statistics are not CUSUM
statistics. Recently, Liu et al6 proposed several global monitoring statistics via the so-called SUM-shrinkage technique.
The SUM-shrinkage technique they use is essentially a thresholding method. Instead of taking the sum of all the local
monitoring statistics as proposed in Mei,3 their new global monitoring statistics take the sum of only those that exceed
some pre-specified threshold. As expected, the detection power of their monitoring schemes depends on the pre-specified
threshold. In their paper, they studied several choices of threshold. However, each one works well only for certain types
of abnormal scenarios. Similar to other thresholding-based methods, it is impossible to find a single threshold in their
proposed global monitoring statistics that will work well for different types of abnormal scenarios.
In addition to the limitations described above, most of the existing approaches were developed under the normality
assumption. When this normality assumption does not hold, none of the above approaches will perform as expected.
So all this indicates the need to develop flexible global monitoring statistics that can work with any type of data and
be effective for different types of abnormal scenarios. To meet this need, we propose a novel class of global monitoring
statistics by making use of the order statistics of the local monitoring statistics. The unique use of the order statistics
makes our proposed monitoring statistics efficient for different abnormal scenarios, as shown in our simulation studies.
Our proposed global monitoring statistics are easy to calculate and can work under flexible model assumptions since they
can be built on any local monitoring statistic that is suitable for monitoring a single data stream. There is vast literature
on how to monitor a single data stream. Therefore, the proposed class of global monitoring statistics can easily benefit
from this rich literature.
The rest of the paper is organized as follows. In Section 2, we propose a general class of global monitoring statistics and
show that the global monitoring statistic studied in Zou et al5 can be considered as a special case of our proposed global
monitoring statistic. In Section 3, we give three examples of our proposed global monitoring statistic from the general class
and evaluate their performance through simulation studies. Finally, we provide some concluding remarks in Section 4.
2
METHODOLOGY
2.1 Notation
The setup for our high-dimensional data monitoring problem is the following. There are m data streams in the system. We
denote the observation from the ith data stream at time t by Xi,t, i = 1, … , m, t = 1, 2, … . Since a time series model can

LI
3
be used to decorrelate the temporal correlation within each data stream and a spatial model can be used to decorrelate
the spatial correlation between data streams before applying monitoring schemes, following most papers on the topic,
we assume that the Xi,t are independent both within and between data streams. When the system is in control (IC), the
underlying distribution of {Xi,1, Xi,2, … } (i = 1, … , m) is called the IC distribution, denoted by F0,i. Following this setup,
at a given time t, we observe Xi,1, Xi,2, … , Xi,t, i = 1, … , m. The task of our online monitoring scheme at time t is to
determine if the distribution of Xi,1, Xi,2, … , Xi,t is the same as F0,i for all i = 1, 2, … , m.
The above task can be carried out by tracking a global monitoring statistic Gt, which contains information collected
from all data streams up to time t. If Gt is within the preset control limit, we will declare that all data streams are IC and
continue monitoring. If Gt exceeds the control limit, we will raise an alarm suggesting that some of the data streams are
out of control (OC). In the following, we propose a novel class of global monitoring statistics that can work with any type
of data and be effective for different types of OC scenarios.
2.2 Proposed global monitoring statistics
Because the change point can happen at different times for different data streams, a popular approach in the literature
for developing the global monitoring statistic Gt is to first choose an appropriate local monitoring statistic for tracking
each data stream and then combine those local monitoring statistics in a way that produces a single global monitoring
statistic. We will follow this approach. More specifically, let Wi,t be the local monitoring statistic for the ith data stream at
time t that summarizes the evidence regarding a possible local change based on the observations, Xi,1, … , Xi,t. Without
loss of generality, we assume that a larger Wi,t indicates a higher probability of the ith data stream being OC. Although
our proposed global monitoring statistic Gt can work with any choice of Wi,t, in order for Gt to be efficient for detecting
changes in any data stream, the Wi,t should be chosen to be efficient for detecting local changes. Since choosing a good
local monitoring statistic Wi,t is equivalent to choosing an appropriate monitoring statistic for the univariate data stream,
there is rich literature on this topic (see, for example, Qiu7), and we can easily find the appropriate monitoring statistic
from the literature as Wi,t for any particular application in mind. Therefore, in the following, we assume that the Wi,t have
been constructed, and our focus is how to combine these local monitoring statistics Wi,t into a powerful global monitoring
statistic.
Note that at any time t, we have calculated W1,t, … , Wm,t. Without loss of generality, we assume that the Wi,t are
independent and identically distributed when the system is IC. As mentioned in Section 1, Liu et al6 recently proposed
an SUM-shrinkage approach to construct the global monitoring statistic based on W1,t, … , Wm,t. In their approach,
W1,t, … , Wm,t are compared with some pre-specified threshold, and only those that exceed the threshold are used to con-
struct the global test statistic. However, similar to all the other thresholding methods, it is impossible to choose a threshold
in advance that works well for all OC scenarios.
Instead of comparing W1,t, … , Wm,t with some pre-specified threshold, we propose to compare their order statistics
with their respective expected values when the system is IC. More specifically, let W(1),t ≤ W(2),t ≤ … ≤ W(m),t be the
order statistics of W1,t, … , Wm,t. Note that W(i),t can be also considered as the observed (i − 3∕4)∕(m − 1∕2) quantile of the
underlying distribution of the Wi,t. Here, (i − 3∕4)∕(m − 1∕2) is the common continuity correction of i∕m. Let q(i),t denote
the expected (i − 3∕4)∕(m − 1∕2) quantile of the IC distribution of the Wi,t. Then, q(i),t can be considered as the expected
value of W(i),t. A natural statistic that summarizes the differences between W(i),t and their respective expected values q(i),t
∑
m
is simply i=1(W(i),t − q(i),t)2. Since a larger Wi,t indicates a higher probability of the ith data stream being OC, only when
W(i),t is larger than its expected value q(i),t, it may indicate abnormality in the system. Therefore, we only include the
difference when W(i),t is larger than its expected value q(i),t in our global monitoring statistic, and the new class of global
monitoring statistics we propose is
m
∑
(
)
2
Gt =
W
(i),t − q(i),t I{W
,
}
(1)
(i),t>q(i),t
i=1
where I{A} is the indicator function and takes 1 if A is true and 0 otherwise. Then, our proposed monitoring scheme is
to plot Gt over the time t, and it raises an alarm if Gt > h, where h is the control limit predetermined by the desired IC
average run length (denoted by ARL0).
At first glance, our proposed global monitoring statistic Gt is the sum-type statistic, so it is expected to be effective when
a moderate or large number of data streams are abnormal. As shown in our simulation studies in Section 3, our global
monitoring statistic Gt is efficient not only for a large number of abnormal data streams but also for a few abnormal data
streams. The reason why Gt can be efficient when a few data streams are abnormal is the following. In general, the extreme
order statistics W(i),t with small i or large i have larger variabilities than the order statistics in the middle. Therefore,

4
LI
although the expression in (1) is in the form of an unweighted sum of squares, if we take into account the variabilities of
different order statistics W(i),t, Gt is actually a weighted sum of squares, with the more extreme order statistics receiving
larger weight. This weighting scheme makes Gt also sensitive for a few abnormal data streams, since those abnormal
data streams will most likely drive up the extreme order statistics first. Therefore, despite its simple form, our proposed
global monitoring statistic Gt has a build-in adaptive mechanism that is capable of adapting to different types of abnormal
scenarios.
As seen above, the proposed new class of global monitoring statistics is very general and can work with any local moni-
toring statistic Wi,t that is suitable for the particular application in mind. Therefore, it can find wide-ranging applications
in the real world and offer promising solutions to various statistical process monitoring problems. As shown in our sim-
ulation studies reported in Section 3, this class of global monitoring statistics performs very well across different OC
scenarios under different model assumptions.
To calculate the above Gt, the expected quantiles q(i),t (i = 1, … , m) of the IC distribution of the Wi,t are needed. When
the IC distribution of the Wi,t is from some well-known distribution family, the q(i),t can be easily obtained from that dis-
tribution family. When the IC distribution of the Wi,t is not from any well-known distribution family, which is most often
the case, we can first simulate a random sample from the IC distribution of the Wi,t and then use the sample quantiles of
this random sample to approximate the corresponding q(i),t. We will give several examples on how to obtain those approx-
imations in the next section. It should be noted that obtaining approximations of the q(i),t will be carried out offline before
the online monitoring starts and the values will be stored beforehand. As a result, the total online computational effort
∑
m
in calculating Gt is the same as calculating i=1(W(i),t − ai)2I{W >a } with all the ai given. Therefore, it is computationally
(i),t
i
simple to implement the proposed method online for monitoring high-dimensional data streams.
2.3 A special case: The global monitoring statistic proposed by Zou et al5
Assume that all the IC distributions F0,i are the normal distribution with mean 0 and variance 1 (denoted by N(0, 1)) and
the OC distribution of the ith data stream (i = 1, … , m) is also some normal distribution with mean ꢀi and variance 1
(denoted by N(ꢀi, 1)). Under those assumptions, an optimal local monitoring statistic for each data stream is the CUSUM
statistic. To detect a positive mean shift, the CUSUM statistic for the ith data stream is defined as
{
Si+,0 = 0,
(2)
1
2
Si+,t = max(0, Si+,t−1 + ꢀi(Xi,t − ꢀi)), for t ≥ 1.
Let Hi,t(·) denote the cumulative distribution function of S+ when the ith data stream is IC. Then, define Ui,t = Hi,t(S+ ),
i,t
i = 1, … , m, and their order statistics are U(1),t ≤ … ≤ U(mi),,tt. Utilizing one of the goodness-of-fit test statistics developed
by Zhang,8 Zou et al5 proposed the following global monitoring statistic:
{
[
]}2
U(−i)1,t − 1
m
∑
GZt =
log
I{U
.
(3)
(i),t>(i−3∕4)∕(m−1∕2)}
(m − 1∕2)∕(i − 3∕4) − 1
i=1
In the following, we show that GZt can be considered as a special case of our proposed global monitoring statistic Gt
in (1). To see this, note that Q(p) = − log(p−1 − 1) is the quantile function of the standard logistic distribution. If we
assume that the OC means ꢀi, i = 1, … , m, are all equal, then − log(U−1 − 1) can be considered as the observed (i −
(i),t
3∕4)∕(m − 1∕2) quantile of the underlying distribution of Si+,t on the scale of the standard logistic distribution. Similarly,
[
]
−1
− log( (i − 3∕4)∕(m − 1∕2) − 1) is the expected (i − 3∕4)∕(m − 1∕2) quantile of the underlying distribution of Si+,t on the
scale of the standard logistic distribution. As a result, if we choose Wi,t to be − log(U−1 − 1) with W(i),t = − log(U−1 − 1)
i,t
(i),t
[
]
−1
and q(i),t = − log( (i − 3∕4)∕(m − 1∕2) − 1), our proposed global monitoring statistic Gt in (1) reduces to GZt in (3).
The above shows that GZt is a special case of our proposed global monitoring statistic Gt. Therefore, GtZ can be also
considered as the sum of the squared differences between the observed quantiles and expected quantiles. Theoretically, GtZ
can be modified using local monitoring statistics other than the above CUSUM statistics Si+,t. However, the quantiles used
in GZt are on the scale of the standard logistic distribution. To obtain those quantiles, the local monitoring statistics have
to be transformed to Ui,t based on their underlying IC distribution. For many commonly used local monitoring statistics,
there is no analytical form available for this transformation, and it has to be approximated through the Markov chain

LI
5
method or Monte Carlo simulation, which can be time-consuming, especially for high-dimensional data monitoring. This
greatly restricts the applicability of GZt to other settings. Therefore, in Zou et al,5 all the analysis was limited to using S+
i,t
in (2) as the local monitoring statistic, since a closed-form formula to approximate Ui,t is available in this setting thanks
to Grigg and Spiegelhalter.9 In contrast, the quantiles used in our proposed Gt can be directly determined by any local
monitoring statistics Wi,t, which makes our Gt more versatile and more computationally efficient than GZt for monitoring
high-dimensional data.
3
EXAMPLES
In Section 2, we propose a general class of global monitoring statistics, which can be built on any local monitoring statistic.
In this section, we provide three examples of our proposed global monitoring statistic from this general class and compare
their performance with that of other existing global monitoring statistics.
3.1 Known prechange and postchange distributions
In our first example, we assume that the distributions before and after the change are N(0, 1) and N(ꢀ, 1), respectively,
for all the data streams, where ꢀ is the postchange mean and is completely specified. Under this setting, we can use the
CUSUM statistic Si+,t defined in (2) with ꢀi = ꢀ as the local monitoring statistic.
On the basis of this local monitoring statistic, the global monitoring statistic GZt defined in (3) can be used to monitor
the m data streams jointly. As mentioned earlier, to implement GZt , it is important that Ui,t can be calculated quickly.
Grigg and Spiegelhalter9 developed an empirical approximation to the IC steady-state distribution of the CUSUM statisitc
S+ . Their result can be used to obtain a closed-form formula to calculate Ui,t. Since this formula only works when S+
i,t
i,t
reaches its steady state, to make use of this formula, we modify the definition of the CUSUM statistic a little. Instead of
starting the CUSUM statistic at 0, ie, Si+,0 = 0 as in (2), we start the CUSUM statistic at some value randomly drawn from
the IC steady-state distribution of Si+,t. More specifically, we first generate 105 independent sequences of {Xk,1, … , Xk,2000
}
105
(k = 1, … , 105), each of which is independently drawn from N(0, 1), and calculate Sk+,2000 as in (2). Then, {Sk+,2000
}
k=1 can
serve as a random sample from the IC steady-state distribution of Si+,t. Our modified CUSUM statistic is then defined as
follows. For i = 1, … , m,
{
+∗
S
S
= Vi
i,0
,
(4)
1
2
= max(0, Si+,t∗−1 + ꢀ(Xi,t − ꢀ)), for t ≥ 1
+∗
i,t
105
where Vi is randomly drawn with replacement from {S+
}
. The global monitoring statistic GZt in (3) is then calcu-
k,2000 k=1
lated using Ui,t = H∗(Si+,t∗), where H∗(·) is the IC distribution of S+∗. Since S+∗ starts from the steady state, H∗(·) at any
i,t
i,t
time t follows the IC steady-state distribution. As a result, we can utilize the closed-form formula provided in Grigg and
Spiegelhalter9 to calculate the above Ui,t quickly.
+∗
Similarly, we also use the above-modified CUSUM statistic S as Wi,t in our proposed global monitoring statistic Gt
i,t
105
in (1). Because of this modification, the underlying distribution of Wi,t for any time t is the same as that of {S+
}
obtained above. Then, its expected quantiles q(i1),0t5also remain the same for any time t and can be well approximatedkb=y1
k,2000
the corresponding sample quantiles of {Sk+,2000
statistic Gt in this particular setting is
}
k=1, which we denote by q(i). Therefore, our proposed global monitoring
s
̂
m
(
)
∑
2
+∗
(i),t
s
+∗
s
̂
Gt =
S
− q(i) I{S
,
(i),t>q(i)}
̂
i=1
+∗
(1),t
+∗
(m),t
+∗
+∗
where S
≤ … ≤ S
are the order statistics of S , … , S
.
1,t
m,t
In Liu et al,6 several global monitoring statistics based on hard thresholding, soft thresholding and order thresholding
were proposed. From their simulations, the soft-thresholding method seems to work the best. Therefore, we only include
their soft-thresholding-based global monitoring statistic in the following simulation study for performance comparison.
To be consistent with the above GZt and Gt, we also calculate their global monitoring statistic based on the above-modified
+∗
CUSUM statistic S , which is defined as
i,t
m
∑
GLt =
max{Si+,t∗ − b, 0},
i=1
where b is the thresholding constant. Following Liu et al,6 three choices of b are considered: (a) b1 = 1∕2; (b) b2
log(10) = 2.3026; and (c) b3 = log(100) = 4.6052.
=

6
LI
• Simulation study
In the following, we report a simulation study to compare the performance of Gt, GZt , and GtL. The general simulation
settings are the following. Among the m data streams, m0 data streams are from the IC distribution N(0, 1), and the
remaining m1 = m − m0 data streams are from the OC distribution N(0.5, 1). We consider two choices of m: m = 100 and
1000, and Table 2 lists the corresponding choices of m1 for these two choices of m.
In our simulation study, we construct the monitoring scheme by tracking Gt, GZt , and GtL, respectively. If Gt, GtZ, or GLt
exceed its respective control limit h, the corresponding monitoring scheme will stop the monitoring and raise an alarm.
The control limit h for Gt, GZt , and GtL can be obtained through Monte Carlo simulation to satisfy the ARL0 requirement.
The desired ARL0 for all the monitoring schemes is set at 1000. The control limits h for Gt, GZt , and GtL for different values
of m are listed in Table 1.
Using those control limits, the monitoring schemes based on Gt, GZt , and GtL are then used to monitor the above m data
streams with m1 of them being OC. Since those OC data streams have changed from their IC distributions from the very
beginning, the detection power of the monitoring schemes based on Gt, GZt , and GtL can be compared with the average
time for the monitoring scheme to raise an alarm, ie, the average run length (denoted by ARL1). Table 2 reports the ARL1
of the monitoring schemes based on Gt, GZ, and GtL for different settings from 2500 simulations. The standard deviations
of the run lengths from the 2500 simulatitons are also included in parentheses, and the standard errors of the ARL1 are
simply those standard deviations divided by 50.
TABLE 1 The control limits of the
monitoring schemes based on Gt, GZt ,
and GLt when ARL0 = 1000
m = 100
m = 1000
Gt
GtZ
GtL
b1
GtL
b1
Gt
GtZ
b2
b3
b2
b3
h
20.798 28.570 69.496 19.303 5.513 25.041 32.593 526.599 108.212 19.413
GtL
b1
TABLE 2 The ARL1 of the
monitoring schemes based on Gt, GZt ,
and GLt from 2500 simulations
m
m1
1
3
5
Gt
GtZ
b2
b3
64.44 (32.88) 68.04 (33.15) 110.26 (55.02)
36.20 (14.95) 38.17 (15.01) 48.44 (21.88)
27.08 (10.53) 28.75 (10.96) 32.55 (14.35)
81.22 (40.72)
38.23 (15.92)
27.26 (10.53)
19.67 (7.06)
17.01 (5.93)
11.25 (3.52)
6.52 (1.97)
4.99 (1.54)
4.32 (1.34)
62.71 (31.84)
35.74 (13.62)
28.65 (9.89)
23.04 (7.53)
21.08 (6.52)
16.12 (4.56)
11.23 (3.33)
9.48 (2.81)
8.56 (2.63)
8
20.33 (7.26)
17.42 (6.11)
10.64 (3.67)
4.88 (1.57)
3.25 (0.97)
2.72 (0.77)
20.77 (7.76)
17.63 (6.64)
10.04 (3.84)
3.91 (1.43)
2.37 (0.82)
1.89 (0.59)
21.19 (8.94)
17.33 (7.21)
9.43 (3.61)
4.15 (1.40)
2.81 (0.93)
2.37 (0.74)
100
10
20
50
80
100
1
81.56 (37.40) 86.87 (38.64) 214.47 (113.31) 148.94 (74.62) 98.34 (44.36)
3
51.83 (18.91) 53.97 (19.81) 106.37 (49.85)
41.89 (13.58) 43.36 (14.39) 73.63 (32.83)
33.90 (10.30) 35.47 (11.02) 52.97 (21.97)
73.70 (31.93)
52.33 (20.96)
38.89 (14.17)
33.02 (11.62)
20.88 (6.69)
11.88 (3.30)
8.94 (2.43)
7.85 (2.07)
6.16 (1.65)
5.19 (1.45)
4.14 (1.13)
3.46 (0.96)
3.04 (0.86)
2.71 (0.80)
2.47 (0.72)
2.27 (0.68)
2.11 (0.62)
1.97 (0.59)
53.60 (20.03)
41.54 (13.64)
33.70 (9.99)
30.07 (8.80)
22.54 (5.85)
15.82 (3.70)
13.09 (3.09)
12.14 (2.71)
10.34 (2.46)
9.16 (2.23)
7.80 (2.00)
6.86 (1.82)
6.18 (1.68)
5.65 (1.57)
5.22 (1.50)
4.92 (1.40)
4.60 (1.32)
4.31 (1.32)
5
8
10
20
50
80
100
30.19 (8.96)
21.04 (6.24)
11.95 (3.67)
8.47 (2.54)
7.05 (2.13)
5.04 (1.43)
3.96 (1.13)
2.78 (0.80)
2.21 (0.60)
1.88 (0.46)
1.67 (0.48)
1.46 (0.50)
1.26 (0.44)
1.09 (0.29)
31.58 (9.63)
21.60 (6.60)
11.50 (3.88)
7.65 (2.69)
6.16 (2.19)
4.08 (1.45)
3.05 (1.06)
2.07 (0.64)
1.61 (0.53)
1.30 (0.46)
1.08 (0.28)
1.02 (0.13)
1.00 (0.03)
1.00 (0.00)
1.00 (0.00)
43.87 (17.80)
24.74 (9.58)
11.01 (4.03)
7.18 (2.55)
5.83 (2.01)
4.09 (1.36)
3.20 (1.04)
2.35 (0.71)
1.92 (0.57)
1.65 (0.51)
1.45 (0.50)
1.28 (0.45)
1.16 (0.37)
1.07 (0.25)
1.03 (0.17)
1000 150
200
300
400
500
600
700
800
900
1000 1.03 (0.17)
Note. The standard deviations of the run lengths from the 2500 simulations are reported in parentheses.

LI
7
For the monitoring schemes based on GLt , the bold number in each row of Table 2 represents the smallest ARL1 among
the three choices of b for that particular OC scenario. As the table shows, the detection power of GLt depends on the choice
of b. If b is too small, GLt is not powerful when only a few data streams are OC, since many IC data streams may exceed b
and the signal in GLt will be diluted by including those IC data streams. Similarly, if b is too large, GLt is not powerful when
many data streams are OC, since many of them may not exceed b and hence do not contribute to GLt . This is consistent
with what is known for any thresholding-based method. However, in practice, it is rarely known in advance how many
data streams will be OC, which makes it extremely difficult to come up with an appropriate b for GLt in real applications.
In contrast, both Gt and GtZ do not depend on any sort of tuning parameter, and they perform well across different OC
scenarios with detection delays being always close to those of GLt with the best choice of b.
When further comparing Gt with GZt , we notice that our Gt is better when a small number of data streams are OC,
while GZt is better when a large number of data streams are OC. This can be explained by the following. As described
in Section 2, both of the global monitoring statistics can be viewed as the sum of the squared differences between the
observed quantiles and expected quantiles. GZt is based on the quantiles from the standard logistic distribution, while our
Gt is based on the quantiles from the distribution of the CUSUM statistic S+∗ in (4). As shown in Grigg and Spiegelhalter,9
i,t
+∗
the tail of the IC distribution of S resembles that of an exponential distribution, which implies that the IC distribution
i,t
+∗
of S has a heavier tail than the standard logistic distribution. As a result, the extreme quantiles contribute more in Gt
i,t
than in GZ. This explains why Gt performs better than GZt when a small number of data streams are OC and vice versa
when a latrge number of data streams are OC.
3.2 Known prechange distribution but unknown postchange distribution
In the previous example, in order to use the CUSUM statistic as the local monitoring statistic, the distribution after the
change needs to be completely specified. In some real-world applications, prior knowledge of the postchange distribution
may not be available. In our second example, we consider the setting where the postchange distribution is unknown. More
specifically, we assume that the OC distribution of the ith data stream is N(ꢀi, 1) with ꢀi unknown and the IC distributions
of all data streams are still N(0, 1). To obtain the specific form of our proposed global monitoring statistic Gt, the key
is to find the appropriate local monitoring statistic Wi,t in this setting. There exist a few options for such a statistic in
the statistical process monitoring literature. For example, Sparks10 proposed an adaptive CUSUM statistic, and Han and
Tsung11 developed a reference-free cumulative score statistic. In both of the two methods, instead of using the specified
ꢀi in the CUSUM statistic defined in (2), an estimate of ꢀi is plugged in. In Sparks,10 an exponentially weighted moving
average (EWMA) of all the past observations is used to estimate ꢀi, while, in Han and Tsung,11 the absolute value of the
current observation, |Xi,t|, is used as the estimate of ꢀi. Following the same idea, Lorden and Pollak12 proposed another
estimate of ꢀi to replace ꢀi in the CUSUM statistic in (2) and proved the asymptotic optimality of the resulting monitoring
statistic. Since the CUSUM statistic in (2) is only for detecting positive mean shifts, the monitoring statistic developed in
Lorden and Pollak12 is also only for positive mean shifts. Recently, Liu et al6 extended Lorden and Pollak's monitoring
statistic to detect both positive and negative mean shifts. In the following, we use this two-sided monitoring statistic in
Liu et al6 as our local monitoring statistic Wi,t.
More specifically, define, for t ≥ 1,
(
(
(
))
))
1
Xi,t − ꢀ̂
2
(1)
i,t
(1)
i,t
(1)
i,t
C
= max 0, Ci(,1t−) 1 + ꢀ̂
,
,
(
1
Xi,t − ꢀ̂
2
(2)
i,t
(2)
i,t
(2)
i,t
C
= max 0, Ci(,2t−) 1 + ꢀ̂
(1)
(2)
i,t
where ꢀ̂ and ꢀ̂ are the estimates of ꢀi for the positive mean shift and negative mean shift, respectively, and they are
i,t
given by
(
)
(
)
(1)
i,t
(1)
(2)
i,t
(2)
i,t
s + S
t + T
−s + S
(1)
(2)
i,t
ꢀ̂ = max ꢁ,
> 0, ꢀ̂ = min −ꢁ,
< 0.
i,t
t + T
i,t
In the above estimates, ꢁ is the pre-specified smallest mean shift that is meaningful, and s and t are also pre-specified
nonnegative constants and can be considered as a prior so that the above estimates can be treated as the Bayes-type
estimates. In our simulation studies, we choose ꢁ = 0.25, s = 1, and t = 4 as in Liu et al.6 For j = 1, 2, the sequences

8
LI
( ꢂ)
( ꢂ)
(S , T ) are calculated recursively.
i,t
i,t
{
( ꢂ)
S
+ Xi,t−1, if C( ꢂ) > 0,
( ꢂ)
i,t
i,t−1
i,t−1
S
=
( ꢂ)
0,
if C
= 0,
i,t−1
{
Ti(,tꢂ−) 1 + 1, if C( ꢂ) > 0,
( ꢂ)
i,t
i,t−1
T
=
( ꢂ)
0,
if C
= 0.
i,t−1
Finally, our local monitoring statistic Ci,t is simply
(1)
(2)
Ci,t = max(C , C ).
i,t
i,t
In Liu et al,6 the above monitoring statistic Ci,t starts from the following initial values:
(1)
i,0
(2)
(1)
(2)
(1)
(2)
S
= S = T = T = C = C = Xi,0 = 0.
i,0 i,0 i,0 i,0 i,0
Using those initial values, the IC distribution of the Ci,t will change over the time before it reaches its steady
state. Recall that, to implement our proposed global monitoring statistic Gt, the expected quantiles q(i),t of the IC
distribution of the Cim,t are needed. If the IC distribution of the Ci,t changes over the time, then we need to calcu-
late and store {q(i),t
}
for each t. To simplify our procedure, similarly to how we modified the original CUSUM
i=1
statistic in the previous section, we propose to set the initial values, (S(1), S(2), Ti(,10), Ti(,20), Ci(,10), C(2), Xi,0), at some value
i,0
(2)
i,t
i,0
(1)
i,t
i,0
(1) (2)
i,t
(1)
i,t
(2)
i,t
randomly drawn from the IC steady-state distribution of (S , Si,t , T , T , C , C , Xi,t). To obtain such initial val-
ues, we generate 105 independent sequences of {Xk,1, … , Xk,2000} (k = 1, … , 105), each of which is independently
drawn from N(0, 1), and calculate (Sk(1,2)000, Sk(2,2)000, Tk(1,2)000, Tk(2,2)000, Ck(1,2)000, Ck(2,2)000, Xk,2000), using the initial value 0. Then,
5
{(Sk(1,2)000, Sk(2,2)000, Tk(1,2)000, Tk(2,2)000, Ck(1,2)000, C(2) , Xk,2000)}10 can be used to approximate the IC steady-state distribution of
k,2000
k=1
(S(1), S(2), T(1), T(2), C(1), C(2), Xi,t). The initial values to calculate our modified Ci∗,t are then defined as
i,t
i,t
i,t
i,t
i,t
i,t
(S(1), S(2), Ti(,10), Ti(,20), Ci(,10), C(2), Xi,0) = Vi,
i,0
i,0
i,0
5
where Vi is randomly drawn from {(Sk(1,2)000, Sk(2,2)000, Tk(1,2)000, Tk(2,2)000, Ck(1,2)000, C(2) , Xk,2000)}10 with replacement. Since
k,2000
k=1
(S(1), S(2), T(1), T(2), C(1), C(2), Xi,t) starts from the steady state, C∗ at any time t follows the IC steady-state distribution when
i,t
i,t
i,t
i,t
i,t
i,t
i,t
105
the system is IC, and its expected quantiles q(i),t also remain the same for any time t. Then, {max(Ck(1,2)000, Ck(2,2)000)} can be
k=1
used to approximate the IC steady-state distribution of C∗ , and the expected quantiles q(i),t of C∗ can be approximated by
i,t
i,t
105
c
the corresponding sample quantiles of {max(Ck(1,2)000, Ck(2,2)000)} , which we denote by q(i). Therefore, our proposed global
̂
k=1
monitoring statistic Gt in this particular setting is
m
(
)
∑
2
c
∗
c
̂
Gt =
C(∗i),t − q(i) I{C
,
(i),t>q(i)}
̂
i=1
where C(∗1),t ≤ … ≤ C(∗m),t are the order statistics of C1∗,t, … , Cm∗ ,t
.
• Simulation study
Using the above modified local monitoring statistics Ci∗,t, theoretically, it is possible to define the global monitoring
statistic GZt proposed by Zou et al5 in this setting accordingly. To implement this GZt , it is important to have a closed-form
formula for the cumulative distribution function of Ci∗,t. However, it is not easy to develop such a formula for the above Ci∗,t.
Because of this computational difficulty of GZt , in our simulation study, we only compare our global monitoring statistic
Gt defined above with the one proposed in Liu et al.6 Their global monitoring statistic based on soft thresholding in this
particular setting is defined as
m
∑
GLt =
max{Ci∗,t − b, 0}.
i=1

LI
9
TABLE 3 The control limits of the monitoring
schemes based on Gt and GLt when ARL0 = 1000
m = 100
m = 1000
GtL
b1
GtL
b1
Gt
b2
b3
Gt
b2
b3
h
19.717 78.452 19.977 5.644 24.096 617.353 114.857 19.787
Again, following Liu et al,6 three choices of b are considered: (a) b1 = 1∕2; (b) b2 = log(10) = 2.3026; and (c) b3
log(100) = 4.6052.
=
The specific simulation settings are similar to those in Section 3.1. Among the m data streams, m0 data streams are
from the IC distribution N(0, 1), and the remaining m1 = m − m0 data streams are from the OC distribution N(ꢀi, 1),
i = 1, … , m1, where ꢀi is randomly drawn from {−0.5, 0.5}. We consider two choices of m: m = 100 and 1000, and Table 4
lists the corresponding choices of m1 for these two choices of m.
Similar to the first simulation study reported in Section 3.1, the performance of Gt and GLt is compared based on the
ARL1 of their corresponding monitoring schemes. The desired ARL0 for the Gt- and GLt -based monitoring schemes is set
at 1000. The control limits h for those monitoring schemes, which are obtained through Monte Carlo simulation, are
listed in Table 3.
On the basis of those control limits, the ARL1 of the Gt- and GLt -based monitoring schemes are obtained from 2500
simulations, which are reported in Table 4. The standard deviations of the run lengths from the 2500 simulations are
also included in parentheses. Again, for the GLt -based monitoring schemes, the bold number in each row represents the
smallest ARL1 among the three choices of b for that particular OC scenario. As we can see from the table, the ARL1 of GtL
depends on the choice of b. GLt with a small b does not perform well when a small number of data streams are OC, while
GLt with a large b does not perform well when a large number of data streams are OC. The explanation is similar to that
we give in Section 3.1. Since it is rarely known in advance how many data streams will be OC in practice, it is extremely
difficult to come up with an appropriate b for GLt in real applications. In contrast, despite the fact that there is no tuning
parameter involved, our Gt performs well across different OC scenarios, and its detection delays are always close to those
of GLt with the best choice of b. This makes our Gt particularly appealing in many real-world applications.
3.3 Unknown prechange and postchange distributions
In the previous two examples, the prechange distributions for all data streams are assumed to be completely known
and are specified by some particular parametric distribution. In some applications, it might not be easy to identify the
appropriate distributions for all data streams. Therefore, in this example, we consider the setting where both the prechange
and postchange distributions are unknown. Again, to obtain the specific form of our proposed global monitoring statistic
Gt in this setting, we need to find the appropriate local monitoring statistic Wi,t. To deal with the unknown prechange
distribution, a nonparametric monitoring statistic should be used. To deal with the unknown postchange distribution,
we need a nonparametric monitoring statistic that can detect any arbitrary distributional changes. In the literature, to
deal with the unknown prechange distribution, many nonparametric monitoring statistics assume that a large amount
of IC reference data generated by the prechange distribution is available so that certain characteristics of the prechange
distribution can be well estimated. However, in order for the effect of using estimates instead of the true values on the
ARL0 to be negligible, it usually requires a substantial amount of IC reference data. In many real-world applications, it can
be very challenging to have such data. Therefore, to find a good candidate for our Wi,t, we only focus on the nonparametric
monitoring statistics that have the self-starting feature.
There are a few nonparametric self-starting monitoring statistics that can detect any arbitrary distributional changes
in the literature. For example, Zou and Tsung13 proposed an EWMA statistic based on a powerful goodness-of-fit test.
However, according to the simulation studies conducted in Ross and Adams,14 this EWMA statistic is only sensitive in
detecting scale increases and is not as powerful as its competitors in detecting other types of distributional changes includ-
ing location shifts. Ross and Adams14 further proposed two monitoring statistics based on the change-point detection
(CPD) framework. Their proposed CPD statistics are shown to have better overall performance than Zou and Tsung's
EWMA statistics for detecting different distributional changes. However, like most CPD statistics, the computation of their
proposed statistics is very intensive, which makes them very challenging to implement for monitoring high-dimensional
data. Recently, Li15 proposed a nonparametric self-starting CUSUM statistic that can detect any arbitrary distributional
changes. On the basis of the simulation studies in Li,15 the proposed monitoring statistic not only is computationally
more efficient than Ross and Adams's CPD statistics but also has better overall detection power than those CPD statistics.
Therefore, in the following, we use the CUSUM statistic proposed in Li15 as our local monitoring statistic Wi,t.

10
LI
GtL
b1
TABLE 4 The ARL1 comparison of the monitoring
schemes based on Gt and GtL
m
m1
1
Gt
b2
b3
71.05 (37.20) 120.08 (62.31)
41.05 (17.58) 55.64 (25.85)
31.37 (12.67) 37.93 (16.37)
88.54 (45.55)
44.01 (19.25)
31.89 (13.03)
24.25 (9.15)
21.10 (7.84)
14.25 (4.62)
8.59 (2.44)
6.85 (1.81)
6.16 (1.53)
70.94 (36.97)
40.89 (17.21)
32.13 (12.57)
26.24 (9.69)
23.86 (8.73)
18.02 (5.83)
12.41 (3.60)
10.39 (2.87)
9.52 (2.53)
3
5
8
10
20
50
80
100
24.51 (9.27)
21.54 (8.08)
14.43 (4.77)
8.17 (2.26)
6.17 (1.58)
5.40 (1.26)
26.89 (10.98)
22.86 (9.24)
13.49 (4.85)
6.98 (2.13)
5.20 (1.40)
4.51 (1.14)
100
1
91.72 (43.42) 229.39 (126.38) 161.70 (83.56) 106.88 (51.26)
3
56.75 (22.74) 114.71 (56.63)
46.40 (17.00) 82.56 (37.59)
37.48 (13.18) 59.71 (25.92)
34.05 (11.68) 50.09 (20.84)
80.57 (35.88)
59.86 (24.22)
44.29 (16.67)
38.23 (13.94)
25.26 (8.34)
14.81 (4.08)
11.36 (2.96)
10.15 (2.65)
8.19 (1.98)
7.12 (1.68)
5.90 (1.33)
5.20 (1.12)
4.72 (1.00)
4.33 (0.91)
4.09 (0.84)
3.85 (0.84)
3.70 (0.75)
3.54 (0.74)
59.57 (23.93)
47.45 (16.85)
37.83 (12.81)
33.98 (11.23)
25.19 (7.62)
17.24 (4.50)
14.35 (3.55)
13.17 (3.30)
11.26 (2.61)
10.14 (2.31)
8.74 (2.00)
7.91 (1.75)
7.28 (1.59)
6.77 (1.48)
6.45 (1.38)
6.13 (1.34)
5.90 (1.25)
5.67 (1.25)
5
8
10
20
50
80
100
24.57 (7.74)
15.36 (4.15)
11.77 (3.06)
10.42 (2.67)
8.15 (1.96)
6.94 (1.60)
5.49 (1.18)
4.70 (0.97)
4.19 (0.84)
3.78 (0.76)
3.50 (0.68)
3.28 (0.66)
3.10 (0.58)
30.05 (11.50)
15.04 (4.95)
10.55 (3.30)
9.15 (2.78)
6.86 (1.94)
5.74 (1.53)
4.48 (1.08)
3.83 (0.89)
3.43 (0.75)
3.12 (0.69)
2.88 (0.60)
2.71 (0.59)
2.61 (0.55)
2.47 (0.54)
1000 150
200
300
400
500
600
700
800
900
1000 2.95 (0.52)
Note. The standard deviations of the run lengths from the 2500 simulations are reported in
parentheses.
Assume that, for each data stream, there are n IC reference data, denoted by Xi,−n+1, … , Xi,0, i = 1, … , m. At time
t ≥ 1, for the ith data stream, we partition the real line into the following d left-to-right regions:
(1)
(1)
(1)
(1)
(1)
(1)
(1)
̂
̂
̂
̂
̂
̂
̂
Ai,t,1 = (−∞, qi,t,1], Ai,t,2 = (qi,t,1, qi,t,2], … , Ai,t,d = (qi,t,d−1, ∞),
and the following d center-outward regions:
(2)
(2)
(2)
̂
̂
̂
Ai,t,1 = (qi,t,d−1, qi,t,d+1],
(2)
(2)
(2)
(2)
(2)
̂
̂
̂
̂
̂
Ai,t,2 = (qi,t,d−2, qi,t,d−1] ∪ (qi,t,d+1, qi,t,d+2],
… …
(2)
(2)
(2)
̂
̂
̂
Ai,t,d = (−∞, qi,t,1] ∪ (qi,t,2d−1, ∞),
(1)
(2)
̂
̂
where qi,t,ꢂ (j = 1, … , d − 1) and qi,t,k (k = 1, … , 2d − 1) are the (j∕d)th and (k∕(2d))th sample quantiles, respectively,
from Xi,−n+1, … , Xi,0, Xi,1, … , Xi,t−1. For j = 1, … , d, define
(1)
(1)
(2)
(2)
̂
̂
̂
̂
Yi,t,ꢂ = I(Xi,t ∈ Ai,t,ꢂ),
Yi,t,ꢂ = I(Xi,t ∈ Ai,t,ꢂ),
and
ꢂ
ꢂ
∑
∑
(1)
(1)
(2)
(2)
̂
̂
̂
̂
Zi,t,ꢂ
=
Yi,t,l
,
Zi,t,ꢂ
=
Yi,t,l.
l=1
l=1

LI
11
For k1, k2 = 1, 2, we calculate
ꢂ
∑
⎛
⎜
⎜
⎧
⎪
⎪
⎨
⎛
⎜
⎜
⎜
⎞
⎟
⎟
⎟
(k1,k2)
̂
pi,t,l
d−1
d2
l=1
∑
1
d
(k1,k2)
(k1,k2)
̂
t−1
(k ) log
1
̂
̂
Si,t
= max 0, S
+
Z
⎜
i,t,ꢂ
ꢂ=1 ꢂ(d − ꢂ)
ꢂ∕d
⎜
⎪
⎜
⎟
⎜
⎪
⎩
⎜
⎝
⎟
⎠
⎝
ꢂ
∑
⎛
⎞⎫⎞
(k1,k2)
̂
pi,t,l
1 −
⎜
⎜
⎜
⎟⎪⎟
⎟⎪⎟
⎟⎬⎟
l=1
+(1 − Zi(,kt,ꢂ)) log
,
1
̂
1 − ꢂ∕d
⎜
⎟⎪⎟
⎜
⎝
⎟⎪⎟
⎠⎭⎠
where p(i,kt,l,k ) is defined by
1
2
̂
(k1,k2)
i,t,l
ꢃl(k ) + N
2
(k1,k2)
̂
pi,t,l
=
,
d
∑
(k1,k2)
i,t
ꢃꢂ(k ) + N
2
ꢂ=1
and both Ni(,kt ,k ) and Ni(,kt,l,k ) are calculated recursively by
1
2
1
2
{
(k1,k2)
N
(k1,k2)
̂
̂
+ 1, if Si,t−1 > 0,
(k1,k2)
i,t
i,t−1
N
N
=
=
(k1,k2)
0,
if Si,t−1 = 0,
{
(k1,k2)
(k1)
(k1,k2)
̂
̂
N
+ Yi,t−1,l, if Si,t−1 > 0,
(k1,k2)
i,t,l
i,t−1,l
(k1,k2)
̂
0,
if Si,t−1 = 0.
The constants {ꢃ1(k ), … , ꢃd(k )} (k2 = 1, 2) serve as the parameters of a prior distribution and are chosen as suggested in
2
2
(1)
(1,1)
(1,1)
Li.15 In particular, when using ꢃꢂ in Si,t , the prior indicates a positive location shift; therefore, Si,t is more powerful
̂
̂
for detecting positive location shifts. When using ꢃꢂ(2) in Si,t , the prior indicates a negative location shift, so Si(,1t,2) is more
(1,2)
̂
̂
powerful for detecting negative location shifts. Similarly, when using ꢃꢂ(1) in Si(,2t,1), the prior indicates a scale increase, so
̂
Si(,2t,1) is more powerful for detecting scale increases. When using ꢃꢂ(2) in Si,t , the prior indicates a scale decrease, so Si,t
is more powerful for detecting scale decreases. If we do not have any prior information about what type of changes the
process might encounter, our local monitoring statistic is simply
(2,2)
(2,2)
̂
̂
̂
(1,1) (1,2) (2,1)
Si,t = max(Si,t , Si,t , Si,t , Si(,2t,2)),
(5)
̂
̂
̂
̂
̂
which is efficient to detect any type of distributional changes. Li15 shows that the above monitoring statistic is asymptotic
distribution free. Following the suggestion in Li,15 we choose d = 20 and n = 40.
(k1,k2)
i,0,l
In Li,15 the initial values (Si(,k0 ,k ), N(k1,k2), N
, Yi(,k0,l)), k1, k2 = 1, 2, l = 1, … , d, and i = 1, … , m, for the above mon-
1
2
1
̂
̂
i,0
̂
itoring statistic Si,t are all set at 0. To simplify the calculation of our proposed global monitoring statistic Gt, similarly
to how we modified the local monitoring statistics in the previous two examples, we propose to set the initial values
(k1,k2)
i,0,l
(k1)
(Si(,k0 ,k ), N(k1,k2), N
, Yi,0,l ) at some values randomly drawn from their IC steady-state distributions. More specifically,
1
2
̂
̂
i,0
5
̂
using the distribution-free property of Si,t, we generate 10 independent sequences of {Xk,−39, … , Xk,0, Xk,1, … , Xk,2000
(k = 1, … , 105), each of which is independently drawn from N(0, 1), and calculate
}
5
{(
)}10
(k1,k2)
(k1)
Sk,2000, Nk(k,20,k00), N(k ,k )
k,2000,l, Yk,2000,l
,
1
2
1
2
̂
̂
k=1

12
LI
1
2
1
2
105
(k1,k2)
(k1)
using the initial value 0. Then, {(Sk,2000, Nk(k,20,k00), Nk(k,20,k00),l, Yk,2000,l)}
can be used to approximate the IC steady-state
̂
̂
k=1
(k1,k2)
i,t,l
(k1)
distribution of (Si(,kt ,k ), N(k1,k2), N
, Yi,t,l ). The initial values to calculate our modified Si,t are then defined as
1
2
∗
̂
̂
̂
i,t
(k1,k2)
i,0,l
(Si(,k0 ,k ), N(k1,k2), N
, Yi(,k0,l)) = Vi,
1
2
1
̂
̂
i,0
1
2
1
2
105
(k1,k2)
(k1)
where Vi is randomly drawn from {(Sk,2000, Nk(k,20,k00), Nk(k,20,k00),l, Yk,2000,l)}
with replacement. The expected quantiles q(i),t
̂
̂
k=1
∗
105
(1,1)
(1,2)
(2,1)
(2,2)
̂
̂
̂
̂
̂
of Si,t can then be well approximated by the corresponding sample quantiles of {max(Sk,2000, Sk,2000, Sk,2000, Sk,2000)}k=1
which we denote by q(i). Therefore, our proposed global monitoring statistic Gt is
,
̂
s
̂
m
(
)
∑
2
̂
s
∗
̂
S
̂
Gt =
(i),t − q(i) I{S
,
(i),t>q(i)}
̂
s
∗
̂
̂
i=1
∗
∗
∗
∗
̂
̂
̂
̂
where S(1),t ≤ … ≤ S(m),t are the order statistics of S1,t, … , Sm,t
.
• Simulation study
∗
̂
Using the above modified local monitoring statistics Si,t, again, it is difficult to implement the global monitoring statistic
Z
5
∗
̂
Gt proposed by Zou et al, since no closed-form formula for the cumulative distribution function of Si,t is available. We
can use the thresholding method proposed in Liu et al6 to come up with some alternative global monitoring statistics.
However, it is not clear how to choose a sensible threshold. Therefore, in our simulation study, we only compare our global
∑
m
monitoring statistic Gt defined above with two other natural competitors Gmt ax = maxi=1, … ,mS and Gstum
=
i=1 Si,t.
∗
∗
̂
̂
i,t
∗
̂
Again, in our simulation study, we consider monitoring m data streams. Since Si,t is distribution free, among the m data
streams, we randomly select half of the data streams to have N(0, 1) as their IC distributions, one fifth of the data streams
to have the t distribution with 2.5 degrees of freedom as their IC distributions, and the remaining data streams to have
the lognormal distribution with parameters ꢀ = 1 and ꢄ = 0.5 as their IC distributions. For the data generated from the t
or lognormal distribution, we also standardize the data so that their IC distributions have mean 0 and standard deviation
1. Among the m data streams, the first m0 data streams follow their IC distributions all the time, and the remaining
m1 = m − m0 data streams will experience certain distributional changes from their IC distributions at the change-point
t = 100. Since Si,t is capable of detecting any type of distributional changes, starting from the change-point t = 100, for
∗
̂
the m1 data streams that will experience distributional changes, we add 0.5 to the observations from the first ⌈m1∕2⌉
data streams to introduce the location change and multiply 1.5 to the observations from the remaining m1 − ⌈m1∕2⌉
data streams to introduce the scale change. Here, ⌈b⌉ is the smallest integer not less than b. Similar to the previous two
examples, we consider two choices of m: m = 100 and 1000, and Table 6 lists the corresponding choices of m1 for these
two choices of m. The desired ARL0 for the Gt-, Gtmax- and Gstum-based monitoring schemes is set at 1000. The control
limits h for those monitoring schemes, which are obtained through Monte Carlo simulation, are listed in Table 5.
On the basis of those control limits, the ARL1 (after the change point) of the Gt-, Gmt ax-, and Gtsum-based monitoring
schemes from 2500 simulations is reported in Table 6. The standard deviations of the run lengths from the 2500 simula-
tions are also included in parentheses. Again, the bold number in each row represents the smaller ARL1 between Gtmax
and Gtsum for that particular OC scenario. As we can see from the table, Gtmax works best when only a few data streams are
OC but does not perform well when a large number of data streams are OC. On the other hand, Gstum has the best per-
formance when a large number of data streams are OC but has the worst performance when only a few data streams are
OC. In contrast, our Gt performs well across different OC scenarios, and if its detection delay is not the best among all the
three monitoring statistics, it is always very close to the best. This provides another example of the robust performance of
our proposed global monitoring statistic Gt for detecting different OC scenarios.
TABLE 5 The control limits of the monitoring schemes based on Gt,
Gmt ax, and Gtsum when ARL0 = 1000
m = 100
m = 1000
Gt
Gmt ax
Gstum
Gt
Gmt ax
Gstum
h
144.016 26.908 524.492 171.697 33.492 4720.355

LI
13
TABLE 6 The ARL1 comparison of the monitoring schemes based
on Gt, Gtmax, and Gtsum
m
m1
1
Gt
Gmt ax
Gstum
85.89 (52.00)
53.43 (25.14)
43.92 (16.91)
27.70 (9.55)
25.17 (8.44)
17.24 (4.99)
10.42 (2.65)
7.73 (1.87)
6.63 (1.54)
80.51 (51.40)
57.68 (27.62)
51.91 (19.98)
35.90 (13.36)
34.07 (12.50)
28.52 (9.47)
23.45 (6.99)
20.61 (6.14)
19.31 (5.63)
181.85 (136.38)
86.00 (49.69)
59.84 (29.17)
32.82 (14.25)
28.33 (11.58)
16.35 (5.64)
8.74 (2.55)
6.30 (1.77)
5.35 (1.45)
3
5
8
10
20
50
80
100
100
1
123.93 (118.56) 111.90 (98.57) 452.76 (430.52)
3
75.18 (32.13)
64.98 (25.32)
55.19 (20.56)
50.35 (17.97)
31.34 (9.16)
20.66 (5.10)
15.76 (3.69)
13.33 (3.01)
10.47 (2.30)
8.78 (1.90)
6.83 (1.41)
5.67 (1.20)
4.90 (0.99)
4.45 (0.92)
4.03 (0.82)
3.66 (0.75)
3.37 (0.72)
76.72 (32.95)
70.05 (28.96)
64.05 (25.55)
61.10 (23.28)
42.46 (14.31)
34.72 (10.35)
30.78 (8.23)
28.14 (7.46)
25.59 (6.49)
24.14 (6.04)
22.23 (5.40)
21.00 (4.90)
19.87 (4.92)
19.30 (4.78)
18.81 (4.60)
18.23 (4.44)
17.70 (4.33)
17.32 (4.26)
215.51 (161.58)
157.96 (104.68)
112.17 (66.04)
95.71 (53.16)
44.15 (19.04)
21.51 (7.33)
14.60 (4.50)
11.82 (3.47)
8.84 (2.48)
5
8
10
20
50
80
100
1000 150
200
7.14 (1.95)
300
5.37 (1.41)
400
4.39 (1.17)
500
3.79 (0.98)
600
3.40 (0.91)
700
3.06 (0.80)
800
2.76 (0.75)
900
2.53 (0.71)
1000 3.12 (0.66)
2.35 (0.67)
Note. The standard deviations of the run lengths from the 2500 simulations
are reported in parentheses.
GtL
b1
TABLE 7 The computational times (in minutes) of the monitoring schemes based on Gt,
GZt and GLt in calculating their ARL1s for different choices of m1 in the simulation study from
Section 3.1
m
100
Gt
0.24 2.34
GtZ
b2
b3
0.21 0.20 0.19
1000 2.51 33.27 2.71 2.11 1.89
4
CONCLUDING REMARKS
In this paper, we introduce a general class of global monitoring statistics for high-dimensional data streams. Our pro-
posed global monitoring statistics are easy to calculate, which makes them suitable for monitoring high-dimensional data
streams. To show the computational efficiency of our proposed global monitoring statistics, we report in Table 7 the com-
putational times of the five monitoring schemes in calculating their ARL1s for different choices of m1 in the simulation
study from Section 3.1 on a Dell computer with Intel Core i7-6700HQ Processor. As we can see from Table 7, the mon-
itoring schemes from the thresholding-based GLt are the most efficient in terms of computation, since GLt only requires
the comparison of the local monitoring statistics Wi,t with some pre-specified threshold. For our proposed monitoring
scheme, after we obtain the estimates of the q(i),t offline beforehand, the total online computational effort in calculating
∑
m
our proposed Gt is the same as calculating
(W(i),t − ai)2I{W >a } with all the ai given. Therefore, our Gt only needs to
i=1
(i),t
i
order the Wi,t, which requires O(m log m) computations. Although this is more time-consuming than simply comparing
Wi,t to a threshold, from Table 7, we can see that the computational times of our Gt-based monitoring scheme are compa-
rable with those from the GtL-based monitoring schemes. In contrast, the computational times of the monitoring scheme
based on GZt are almost 10 times the computational times of our proposed monitoring scheme. This is due to the extra
computation needed to convert Wi,t to Ui,t in calculating GZt .
In our simulation studies reported in Section 3, we use the sample quantiles from a random sample of size 100 000 from
the IC distribution of the Wi,t to approximate the q(i),t. In the following, we report new results for the simulation study

14
LI
from Section 3.1 when we use random samples of smaller sizes to estimate the q(i),t. The size of the random IC Wi,t sample
used to estimate the q(i),t is represented by B in Table 8. As mentioned earlier, our proposed global monitoring statistic is
∑
m
equivalent to
(W(i),t − ai)2I{W
with ai being given by the estimate of q(i),t, which we obtain offline beforehand.
(i),t>ai}
i=1
The control limit h of our proposed monitoring scheme is then determined based on those given ai values. With different
IC Wi,t sample sizes, the values of the ai specified in the above monitoring statistic will be different, so is the control limit
h of our proposed monitoring scheme. The h value corresponding to a specific B value in Table 8 is the control limit we
obtain for ARL0 = 1000 when the ai is given by the estimates of the q(i),t from a random IC Wi,t sample of size B. In
Table 8, the ARL when m1 = 0 indicates the simulated ARL0. Therefore, as shown in the table, the simulated ARL0s of
our proposed monitoring schemes with different IC Wi,t sample sizes are all close to the nominal level ARL0 = 1000. As
we can also see from the table, for m1 ≠ 0, the reported ARL1s for our proposed monitoring schemes with different IC
Wi,t sample sizes are also very similar. From those results, we can see that the size of the random IC Wi,t sample used to
estimate the q(i),t has no significant impact on the performance of our proposed monitoring scheme.
As mentioned in Section 1, there are two types of monitoring schemes. For the second type of monitoring scheme, after
our proposed monitoring scheme based on Gt triggers an alarm, we also need to identify which data stream is experiencing
abnormal activities. For this purpose, we can use the local monitoring statistics Wi,t to determine which data streams are
OC as follows: If Wi,t is larger than some control limit, say ch, we conclude that the ith data stream is OC; otherwise,
we conclude that the ith data stream is IC. We refer to Li1 for more details on how to choose the control limit ch in this
situation.
Although we only consider three types of local monitoring statistics as examples in the paper, our proposed global mon-
itoring statistic can work with any local monitoring statistic that is efficient for monitoring a single data stream. This
TABLE 8 The ARL results of our
proposed monitoring scheme based on
Gt when the q(i),t are estimated by the
sample quantiles from random samples
of different sizes
B = 100000
h = 20.798
1008.94 (1014.88) 994.45 (1021.60)
64.44 (32.88)
36.20 (14.95)
27.08 (10.53)
20.33 (7.26)
17.42 (6.11)
10.64 (3.67)
4.88 (1.57)
3.25 (0.97)
2.72 (0.77)
B = 100000
h = 25.041
B = 10000
h = 19.812
B = 5000
h = 20.341
1007.48 (1010.02) 1003.80 (993.95)
B = 1000
h = 27.496
m
m1
0
1
3
5
8
10
20
50
80
100
65.28 (32.54)
36.43 (14.64)
27.16 (10.24)
20.29 (7.16)
17.14 (6.30)
10.46 (3.58)
4.82 (1.60)
3.23 (0.96)
2.65 (0.76)
B = 50000
66.57 (33.63)
36.65 (14.49)
26.72 (10.14)
20.04 (7.45)
17.38 (6.29)
10.24 (3.64)
4.72 (1.49)
3.16 (0.96)
2.62 (0.77)
B = 10000
62.58 (31.44)
36.20 (14.64)
27.26 (10.28)
21.01 (7.22)
18.54 (6.36)
11.54 (3.72)
5.54 (1.73)
3.70 (1.09)
3.07 (0.86)
B = 5000
h = 30.055
996.05 (1005.91)
79.94 (36.80)
51.60 (18.31)
41.59 (13.95)
34.72 (10.47)
30.88 (9.51)
22.04 (6.37)
12.25 (3.61)
8.61 (2.58)
7.17 (2.13)
5.14 (1.54)
3.97 (1.12)
2.79 (0.76)
2.21 (0.60)
1.86 (0.46)
1.67 (0.48)
1.47 (0.50)
1.26 (0.44)
1.11 (0.31)
1.03 (0.16)
100
m
m1
0
1
3
5
8
10
20
50
80
100
h = 24.608
h = 22.512
1006.42 (1044.24) 1004.02 (1008.25) 994.39 (1024.27)
81.56 (37.40)
51.83 (18.91)
41.89 (13.58)
33.90 (10.30)
30.19 (8.96)
21.04 (6.24)
11.95 (3.67)
8.47 (2.54)
7.05 (2.13)
5.04 (1.43)
3.96 (1.13)
2.78 (0.80)
2.21 (0.60)
1.88 (0.46)
1.67 (0.48)
1.46 (0.50)
1.26 (0.44)
1.09 (0.29)
86.50 (39.92)
53.07 (19.28)
42.15 (13.88)
33.40 (10.55)
30.18 (9.44)
21.08 (6.32)
11.57 (3.47)
8.19 (2.59)
6.93 (2.06)
4.97 (1.47)
3.84 (1.13)
2.75 (0.78)
2.15 (0.58)
1.82 (0.48)
1.61 (0.49)
1.41 (0.49)
1.20 (0.40)
1.09 (0.29)
1.02 (0.14)
81.69 (37.52)
51.59 (18.65)
42.27 (13.91)
33.75 (10.26)
30.25 (9.45)
20.97 (6.10)
11.88 (3.53)
8.37 (2.47)
7.00 (2.10)
5.02 (1.48)
3.92 (1.10)
2.76 (0.77)
2.18 (0.59)
1.83 (0.46)
1.64 (0.49)
1.43 (0.50)
1.22 (0.42)
1.07 (0.26)
1.02 (0.14)
1000 150
200
300
400
500
600
700
800
900
1000 1.03 (0.17)

LI
15
flexibility makes our proposed global monitoring statistics suitable for many different real-world applications. The simu-
lation studies in the three examples we consider further show that our proposed global monitoring statistic performs well
under a variety of OC scenarios and has the best overall detection power comparing with other existing global monitoring
statistics.
ACKNOWLEDGEMENTS
The author thanks the editor and two anonymous referees for their constructive comments and suggestions, which greatly
improved the quality of the paper.
ORCID
Jun Li
https://orcid.org/0000-0002-0323-8255
REFERENCES
1. Li J. A two-stage online monitoring procedure for high-dimensional data streams. J Qual Technol. 2018. https://doi.org/10.1080/00224065.
2018.1507562
2. Tartakovsky AG, Rozovskia BL, Blazeka RB, Kim H. Detection of intrusions in information systems by sequential change-point methods
(with discussion). Stat Method. 2006;3:252-340.
3. Mei Y. Efficient scalable schemes for monitoring a large number of data streams. Biometrika. 2010;97:419-433.
4. Xie Y, Siegmund D. Sequential multi-sensor change-point detection. Ann Stat. 2013;41:670-692.
5. Zou C, Jiang W, Wang Z, Zi X.. An efficient on-line monitoring method for high-dimensional data streams. Technometrics. 2015;57:374-387.
6. Liu K, Zhang R, Mei Y.. Scalable SUM-shrinkage schemes for distributed monitoring large-scale data streams. Stat Sin. 2019;29:1-22.
7. Qiu P. Introduction to Statistical Process Control. Boca Raton: FL: Chapman & Hall/CRC; 2014.
8. Zhang J. Powerful goodness-of-fit tests based on the likelihood ratio. J R Stat Soc Ser B. 2002;64:281-294.
9. Grigg OA, Spiegelhalter DJ. An empirical approximation to the null unbounded steady-state distribution of the cumulative sum statistic.
Technometrics. 2008;50:501-511.
10. Sparks RS. CUSUM charts for signalling varying location shifts. J Qual Technol. 2000;32:157-171.
11. Han D, Tsung F.. A reference-free cuscore chart for dynamic mean change detection and a unified framework for charting performance
comparison. J Am Stat Assoc. 2006;101:368-386.
12. Lorden G, Pollak M. Sequential change-point detection procedures that are nearly optimal and computationally simple. Seq Anal.
2008;27:476-512.
13. Zou C, Tsung F. Likelihood ratio-based distribution-free EWMA control charts. J Qual Technol. 2010;42:174-196.
14. Ross GJ, Adams NM. Two nonparametric control charts for detecting arbitrary distribution changes. J Qual Technol. 2012;44:102-116.
15. Li J. Nonparametric adaptive CUSUM chart for detecting arbitrary distributional changes. Submitted. 2017. (arXiv:1712.05072).
AUTHOR BIOGRAPHY
Jun Li received her PhD in Statistics from the Department of Statistics and Biostatistics at Rutgers University
in 2006. Since then, she has been with the Department of Statistics at the University of California, Riverside, as
an assistant professor (2006-2012) and an associate professor (2012 to present). She is a lifetime member of the
American Statistical Association and the Institute of Mathematical Statistics. Her current research interests include
statistical process control and nonparametric multivariate analysis.
How to cite this article: Li J. Efficient global monitoring statistics for high-dimensional data. Qual Reliab Engng
Int. 2019; 1–15. https://doi.org/10.1002/qre.2557
