that can host active materials. SEM images of the electrochemical
CuxSny compound on CP in Fig. 1c,d show the CP fibers homoge-
neously covered with CuxSny . The covering appears to be particles
and aggregates of different sizes ͑the smallest are Ͻ1 m͒, the big-
gest having a leaf shape. Figure 1e,f displays the SEM images of
mechanochemical Cu6Sn5 on CP and mechanochemical Cu6Sn5
powder. Here the Cu6Sn5 deposited on CP by permeation is more
localized where the fibers criss-cross, but it is present in the whole
volume of CP ͑as per SEM images, not shown, of the back side of
the Cu6Sn5 /CP electrodes͒. Most of the carbon fibers remained
bare, and the aggregates of different sizes are made of nanometric
particles. Figure 2 displays the ‘‘particle’’ size distribution of the
mechanochemical Cu6Sn5 . The abscissa is the particle or, as in our
case, the agglomerate size, which can be viewed as an ‘‘equivalent
diameter,’’ i.e., the diameter of a sphere which exhibits the same
physical properties as the measured, irregular particle or agglomer-
ate. The ordinate is the oversize cumulative distribution indicating
the total quantity of all agglomerates with equivalent diameter
smaller than or equal to the abscissa value. The size of 90% of the
agglomerates is Ͻ20 m.
M H2SO4 degassed solution at room temperature. Adhesive tape
was used to prevent deposition on the back of the electrode and to
limit the exposed area to 1 cm2. Ultrapure water ͑Milli-Q, 18.6 M⍀
cm, Simplicity Water System, Millipore Co.͒ was employed for so-
lutions and rinsing. Electrodes with different amounts of Cu-Sn in-
termetallic compound ͑2-6 mg cmϪ2͒ were prepared at constant cur-
rent ͑Ϫ12 mA cmϪ2͒. As the efficiency of the electrodeposition was
low, alloy mass loading was evaluated by weighing. The potential
during galvanostatic electrodeposition was ca. Ϫ0.5 V vs. saturated
calomel electrode. The electrodes were dried under vacuum at 60°C
for 16 h before use. Nanometric -Cu Sn ͑Sn 45.5, Cu 54.5 atom
Ј
6
5
%͒ prepared mechanochemically was also used to prepare electrodes
by permeation of a suspension of Cu6Sn5 ͑96 wt %͒, poly͑vi-
nylidene fluoride͒ ͑4 wt %͒, and acetone through CP sheets. These
electrodes, with a Cu6Sn5 mass loading of 3-14 mg cmϪ2, were
dried 1 h at 70°C under vacuum at room temperature before use.
All the electrodes were characterized by X-ray diffraction ͑XRD͒
analysis with a Philips PW1050/81 powder diffractometer ͑Cu K␣
radiation, 40 mA, 40 kV͒. Scanning electron microscopy ͑SEM͒
analyses were performed with a Philips 515 SEM microscope
equipped with an EDAX PV9900 energy dispersion detector for
X-ray energy-dispersive spectroscopy ͑EDS͒. For secondary elec-
tron imaging and for EDS, 20 and 25 keV electrons were used. The
particle/aggregate dimensions were measured with a Fritsch Analy-
sette 22 Compact laser particle sizer in the range 0.3-300 m ͑62
channels͒ with 5 scans/measurement.
Figure 3 shows the XRD patterns of different electrodes: bare
CP,
electrochemical
CuxSny /CP,
and
mechanochemical
Cu6Sn5 /CP; the pattern of Sn electrodeposited on CP is also re-
ported for comparison. The figure also indicates the main reflections
of the different materials ͑stars for the Cu6Sn5 and circles for the Sn
main peaks͒. The electrochemical CuxSny , unlike the pattern of
mechanochemical Cu6Sn5 , shows the coexistence of two phases,
All the electrodes were electrochemically characterized by gal-
vanostatic charge/discharge cycles at T ϭ 30 Ϯ 1°C in a T-shaped
cell sealed in a dry box ͑Mbraun Labmaster 130, O2 and
Cu Sn and Sn. While the reflections attributable to tin oxides or
Ј
6
5
Ͻ
H2O
1 ppm͒. The working electrodes were cut with a hollow
copper oxides are absent in both the ͑b͒ and ͑c͒ spectra, the reflec-
tions of CP are recognizable in all the spectra. From the EDS analy-
sis of several portions of an electrochemical CuxSny /CP, we esti-
mated a mean value for the Cu/Sn atomic ratio of 1.19 Ϯ 0.11, and
we considered it reasonable to take the electrodeposited material as
Cu6Sn5 .
brass punch. Due to the resharpening of the punch’s rim, the area
was 0.68 Ϯ 0.02 cm2. Given the inhomogeneous density of the CP
sheets, the masses of the CP current collectors, evaluated by weigh-
ing, are reported in all the figures related to electrochemical mea-
surements. The counter electrode was metallic Li in excess, and the
reference electrode for monitoring the electrode potentials was a Li
foil. The separator, a Whatman GF/D glass fiber disk, was imbibed
with the electrolyte solution ethylene carbonate:dimethyl carbonate
(EC:DMC2:1)-1 M LiPF6 ͑LP31 Merck, battery grade͒. The gal-
vanostatic cycles were carried out at 0.500 mA, i.e., 0.74
Ϯ 0.02 mA cmϪ2. The terms ‘‘charge’’ and ‘‘discharge’’ refer to the
alloy electrode being used as the anode in lithium-ion batteries, i.e.,
to lithiation and delithiation, respectively. The discharges were po-
tential limited ͑2.000 V vs. Li͒, and the charges were time limited
͑while maintaining a safe voltage cutoff of 0.005 V vs. Li͒ to insert
defined amounts of lithium per atom of tin. The amount of lithium to
be inserted ͑estimated as the product of current and time͒ was cal-
culated, in relation to the Li/Sn atomic ratio to be reached, on the
basis of the mass of the Cu6Sn5 loaded on the electrode. The specific
capacity of Cu6Sn5 was calculated by assuming that all the lithiation
charge involved the Cu6Sn5 . The cells with electrodes having high
alloy mass loading were disassembled and reassembled to change
the Li metal counter electrode ͑and in some cases even the separa-
tor͒ after a certain number of cycles, i.e., when the sum of their
charges was ca. 400 C cmϪ2, to prevent the Li metal deposition/
dissolution at the counter electrode from interfering with the cycling
stability of the Cu6Sn5 . The electrochemical deposition and charac-
terization were performed with a VMP multichannel potentiostat and
a PAR 273A potentiostat/galvanostat.
Cu6Sn5 was electrodeposited on both Cu and CP. As the effi-
ciency of the electrodeposition process was low, we considered the
increase of the electrode weight instead of the charge involved in the
electrodeposition to evaluate alloy mass loading. We first tested
electrodes with a Cu6Sn5 mass loading of ca. 4-6 mg cmϪ2. The
coulombic efficiency of the first galvanostatic cycle of Cu6Sn5 both
on Cu and CP ranged from 60 to 75%, being affected, just like the
carbonaceous materials, by irreversible capacity due to side reac-
tions at the electrode/electrolyte interface. Figure 4 reports the volt-
age profiles of repeated galvanostatic charge/discharge cycles of
Cu6Sn5 on copper, where the charge process was time limited to
insert lithium up to 1.88 Li/Sn atomic ratio. However, after the first
three cycles, in which the lithiation plateau at 0.4 V progressively
disappeared, the potential of the Cu6Sn5 /Cu electrode reached the
charge cutoff voltage ͑5 mV͒, and the amount of Li inserted ͑and
deinserted͒ became lower and lower than the 1.88 atom per Sn.
Figure 5 displays the discharge capacity from galvanostatic cycles of
two Cu6Sn5 /Cu electrodes of the same area with initial charges
further limited to 1.10 Li/Sn and 0.59 Li/Sn. In these cases, too, the
alloy electrode’s stability was low, as well as its coulombic effi-
ciency. The reason for this decay can be found in the formation of
cracks, as also reported in the literature.13 The Cu foil cannot sup-
port the stress of the Cu-Sn alloy during the lithiation/delithiation,
which results in pulverizing and delaminating from the Cu foil of
the material, with cracks up to 20 m wide, as we observed by SEM
of the electrodes after 100 cycles. The low coulombic efficiency
may also lead to electrode material pulverization, which produces
new surface area able to react with the electrolyte, in addition to
interparticle contact loss.16
Results and Discussion
We started with the electrochemical synthesis of Cu6Sn5 on both
CP and Cu current collectors. Given that the copper electrodeposi-
tion potential is less negative than that of tin, a solution with a
concentration of tin higher than that of copper was selected for the
galvanostatic electrodeposition of the Cu-Sn intermetallic com-
pound. The SEM photographs at different magnification of CP in
Fig. 1a,b show an open and fibrous structure ͑fiber diam ca. 10 m͒
Figure 5 also reports the capacity data from galvanostatic cycles
of a Cu6Sn5 /CP electrode, which indicate that the use of the CP
current collector is successful when compared to that of Cu. The
