molecules
Article
Lipase-Catalyzed Synthesis of Sucrose Monolaurate
and Its Antibacterial Property and Mode of Action
against Four Pathogenic Bacteria
Shi-Yin Shao 1,2, Yu-Gang Shi 1,2,*, Yu Wu 1,2, Li-Qing Bian 1,2, Yun-Jie Zhu 1,2
Xin-Ying Huang 1,2, Ying Pan 1,2, Lu-Yao Zeng 1,2 and Run-Run Zhang 1,2
,
1
Zhejiang Provincial Collaborative Innovation Center of Food Safety and Nutrition,
Zhejiang Gongshang University, Hangzhou 310035, China; 16030000214@pop.zjgsu.edu.cn (S.-Y.S.);
wuyu6939@sina.com (Y.W.); 16030000222@pop.zjgsu.edu.cn (L.-Q.B.); 18363851057@163.com (Y.-J.Z.);
elandzhou@163.com (X.-Y.H.); Holalailai@163.com (Y.P.); zengluyao159@163.com (L.-Y.Z.);
m17826852919_1@163.com (R.-R.Z.)
School of Food Science and Biotechnology, Zhejiang Gongshang University, Hangzhou 310035, China
Correspondence: yugangshi@zjgsu.edu.cn; Tel.: +86-0571-2800-8927
2
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 26 April 2018; Accepted: 7 May 2018; Published: 8 May 2018
Abstract: The aim of this work was to evaluate the antibacterial activities and mode of
action of sucrose monolaurate (SML) with a desirable purity, synthesized by Lipozyme TL
IM-mediated transesterification in the novel ionic liquid, against four pathogenic bacteria including
L. monocytogenes, B. subtilis, S. aureus, and E. coli. The antibacterial activity was determined by
minimum inhibitory concentration (MIC), minimum bactericidal concentration (MBC), and the
time–kill assay. SML showed varying antibacterial activity against tested bacteria with MICs and
MBCs of 2.5 and 20 mM for L. monocytogenes, 2.5 and 20 mM for B. subtilis, 10 and 40 mM for
S. aureus, respectively. No dramatic inhibition was observed for E. coli at 80 mM SML. Mechanism of
bacterial inactivation caused by SML was revealed through comprehensive factors including cell
morphology, cellular lysis, membrane permeability, K+ leakage, zeta potential, intracellular enzyme,
and DNA assay. Results demonstrated that bacterial inactivation against Gram-positive bacteria was
primarily induced by the pronounced damage to the cell membrane integrity. SML may interact
with cytoplasmic membrane to disturb the regulation system of peptidoglycan hydrolase activities
to degrade the peptidoglycan layer and form a hole in the layer. Then, the inside cytoplasmic
membrane was blown out due to turgor pressure and the cytoplasmic materials inside leaked out.
Leakage of intracellular enzyme to the supernatants implied that the cell membrane permeability
was compromised. Consequently, the release of K+ from the cytosol lead to the alterations of the zeta
potential of cells, which would disturb the subcellular localization of some proteins, and thereby
causing bacterial inactivation. Moreover, remarkable interaction with DNA was also observed.
SML at sub-MIC inhibited biofilm formation by these bacteria.
Keywords: ionic liquids; lipase; biocatalysis; sucrose monolaurate; antimicrobial activity; biofilm
1. Introduction
Sugar fatty acid esters (SFAE) are diverse compounds consisted of a hydrophilic carbohydrate
moiety and one or more (saturated or unsaturated) fatty acids as lipophilic moieties, which are
widely used as emulsifiers in food industry due to their high biodegradability and safety. SFAE are
synthesized by chemical and enzymatic methods. However, many consumers are concerned about
the potential adverse side effects of synthetic chemicals in food. Thus, it is of vital importance
to develop the novel ways of biotransformation with many advantages (mild reaction conditions,
Molecules 2018, 23, 1118; doi:10.3390/molecules23051118
www.mdpi.com/journal/molecules

Molecules 2018, 23, 1118
2 of 18
exclusive chemo-, region-, and stereoselectivity; high atom economy; and limited waste), compared
to traditional chemical synthesis. However, a major challenge in the enzymatic synthesis of SFAE
is the selection of appropriate solvent system to dissolve substrates with different physical property
(polar sugars and non-polar fatty acid). Some hydrophilic organic solvents (e.g., dimethyl sulfoxide)
are able to dissolve both sugars and fatty acids at relatively high concentration, but the activity of
most enzymes are retarded in these conventional solvents. Ionic liquids (ILs) are considered as an
environmentally friendly alternative to organic solvents and carry numerous intriguing properties
that are suitable for numerous applications in biotransformation [
include increased stability or protective effects for enzymes, adaptable solubility properties, convinced
impact on the specificity of biocatalysts or the shift in equilibrium of the reaction, and recyclability [ ].
In our laboratory, we have been developing new functionalized ILs in parallel with evaluating them as
novel media for biological applications [ ]. Therefore, we pursued to explore whether the new IL is
1]. The benefits of ILs to biocatalysis
2,3
4,5
also suitable for the enzymatic synthesis of SFAE.
Among SFAE, sucrose monolaurate (6-O-lauroylsucrose, SML) is considered the potent inhibitor
of microbial activity and their properties are being actively explored, yet there are conflicting data on
the microbes effected. 500 and 1000
on the surface of raw sliced beef [ ]. 1% SML effectively inhibited the growth of Zygosaccharomyces bailii
and Lactobacillus fructivorans in salad dressings during storage at 27 ◦C [ g mL−1 SML with
]. 1000
600 ]. 200
g mL−1 EDTA caused a 3.0 log reduction of Yersinia enterocolitica on egg shell surface [
mL−1 SML inhibited the growth of E. coli [ ]. SML at 4 mg mL−1 inhibited Bacillus sp. and E. coli [10].
Zhao et al. [11] reported SML showed antibacterial activities against five pathogenic bacteria including
E. coli. However, Conley and Kabara [12] reported that 125
g mL−1 commercial sucrose laurate
(58%, SML) showed no inhibition of E. coli. Monk et al. [ ] observed that the growth of E. coli was
unaffected in TSB containing 1 mg mL−1 SML. Enzymatically synthesized SML (6.25 mg mL−1
µ
g mL−1 SML showed inhibition against Escherichia coli O157:H7
6
7
µ
µ
8
µg
9
µ
6
)
resulted in no decrease in the growth of E. coli during 28 h [13]. Gram-negative bacteria (E. coli
O157:H7, Klebsiella pneumoniae, Salmonella enterica serotype Typhimurium) did not show a change in
growth in SML compared to the controls [14]. Although the antibacterial activities of SFAE have been
extensively studied, the information related to particularly SML, especially with high purity, has not
been well defined. In addition, the sucrose esters preparation that was used normally contained
small amounts of di- and triester forms, so it is hard to evaluate how the ester forms contribute to the
overall antibacterial activity. To the best of our knowledge, little is known about the mode of action or
antibacterial mechanism of SML against pathogenic bacteria.
In the present report, firstly, we had developed the enzymatic synthesis SML by lipozyme TL
IM-mediated transesterification in a novel functionalized ionic liquid. Then, in order to ascertain the
antibacterial efficacy and potential mechanism of SML against four pathogenic bacteria including
Listeria monocytogenes (L. monocytogenes), Bacillus subtilis (B. subtilis), Staphylococcus aureus (S. aureus),
and Escherichia coli (E. coli), the in vitro antibacterial activity of SML with high purity (more than
94%) were evaluated by measuring MIC and MBC values, as well as kill-time assays. Moreover,
the antibacterial mechanisms towards representative bacteria were determined by cell morphology,
cellular lysis, membrane permeability, K+ and
DNA, as well as biofilm inhibition.
β-galactosidase leakage, zeta potential and cellular
2. Materials and Methods
2.1. Materials
Sucrose and vinyl laurate with >98% purity were purchased from Sigma-Aldrich (Shanghai, China).
Sucrose monolaurate ( 97%) was obtained from Sigma-Aldrich (Shanghai, China). Lipozyme TL IM
≥
(T. lanuginosus lipase immobilized on silica gel) was a gift from Novo Nordisk (Copenhagen, Denmark). 3 Å
and 4 Å Molecular sieves were purchased from Sinopham Chemical Reagent Co., Ltd. (Shanghai, China).
Ionic liquid, 3CIM(EO)][NTf2] (1-(2-(2-methoxyethoxy)ethyl)-5,6,7,8-tetrahydroimidazo[1,2-a]pyridin-1-ium

Molecules 2018, 23, 1118
3 of 18
bis(trifluoromethylsulfony)imide) (99%, HPLC) was synthesized and purified in our laboratory. All other
reagents were of analytical grade. All other chemicals of analytical or HPLC grade were purchased from
commercial sources in China. Vinyl laurate and other organic solvents were stored over 4 Å molecular
sieves, at least 24 h prior to use.
2.2. Lipase-Catalyzed Transesterification for SML in Ionic Liquid
2.2.1. Synthesis of [3CIM(EO)][NTf2]
The procedure of synthesis was conducted according to our method [5] with minor modifications.
Methanesulfonyl chloride (36 mmol, in 30 mL DCM) was added to an 50 mL DCM solution of
◦
2-(2-methoxyethoxy) ethanol (22 mmol) and triehylamine (56 mmol) at 0 C. The contents were stirred
in an ice bath for 1 h. Then, the reaction was washed with 0.5 M citric acid (3
×
20 mL) and 1 M sodium
bicarbonate (3 20 mL). The organic layer was dried over anhydrous Na2SO4 and evaporated
×
under reduced pressure to obtain colorless liquid 2-(2-methoxyethoxy) ethyl methanesulfonate.
6,7-Dihydro-5H-pyrrolo[1,2-a] imidazole (10 mmol) was added into a round-bottomed flask containing
2-(2-methoxyethoxy) ethyl methanesulfonate. The reaction was conducted at 80 ◦C overnight.
After cooling to the room temperature, the whole mixture was subsequently washed with ether
(3
×
10 mL) to give a light yellow liquid, methanesulfonate salt, (65–96% yield). To a 150 mL
round-bottomed flask was then added methanesulfonate salt (2.5 g) followed by the addition of
bistrifluoromethanesulfonimide lithium salt (1:1 equiv) and water (5 mL). The reaction was allowed to
proceed the ion exchange for 12 h at room temperature. The reaction was extracted with DCM
(3
×
5 mL) and dried over anhydrous Na2SO4 and concentrated to obtain the colorless liquid
[3CIM(EO)][NTf2] with good isolated yield (70–90%).
2.2.2. General Procedure of the Lipase-Catalyzed Transesterification in the Ionic Liquid
Crystalline sucrose was ground manually to◦powder in a porcelain mortar, sieved through a
mesh with a pore size of 0.2 mm, dried in a 60 C oven generally overnight and then stored in
desiccators. Lipase-catalyzed synthesis of SML with vinyl laurate in the mixtures of ionic liquid-organic
solvent ([3CIM(EO)][NTf2] and 2-methyl-2-butanol (2M2B)) (1.5:1, v/v) was carried out in a glass vial
with Teflon caps to avoid the escape of volatile organic compounds, especially for organic solvents.
Sucrose (45 mM) and vinyl laurate (180 mM) were mixed with the media mentioned above. 50 g/L
of enzyme and 3 Å molecular sieve (10%, w/v) was put into the mixture. The reaction was allowed
◦
to proceed at 60 C for 72 h. After centrifugation, TLC and HPLC technic was used to analyze
the supernatants. The sucrose esters were eluted with ethyl acetate: methanol: H2O (17:2:1 v/v/v).
The purification was monitored by TLC. The fractions containing SML were pooled and the solvent
was evaporated to obtain SML for further study.
Position of the fatty acid in the sucrose and monoacylation were confirmed by NMR spectroscopy.
1H- and 13C-NMR-spectra were recorded on a Bruker Avance 500 spectrometer (Bruker Instruments,
Karlsruhe, Germany).
Sucrose Monolaurate (SML). 6-O-Lauroylsucrose. solid, 1H-NMR (500 MHz, DMSO):
δ 5.18 (d, J = 3.6 Hz,
1H); 4.34–4.10 (m, 2H); 4.02 (dd, J = 11.7, 6.0 Hz, 1H); 3.99–3.81 (m, 2H); 3.71 (ddd, J = 18.6, 13.7, 13.0 Hz,
2H); 3.63–3.44 (m, 6H); 3.44–3.24 (m, 4H); 3.18 (ddd, J = 12.5, 9.9, 3.2 Hz, 2H); 3.06 (d, J = 9.4 Hz, 1H);
2.37–2.12 (m, 2H); 1.63–1.36 (m, 2H), 1.24 (s, 16H); 0.86 (t, J = 6.8 Hz, 3H). 13C-NMR:
δ
173.47 (7–C=O),
104.33 (2’–C), 91.92 (1–C–O), 83.18 (5’–C), 77.39 (3’–C–OH), 74.94 (4’–C), 73.13 (3–C), 71.98 (5–C), 70.61
(2–C), 70.48 (4–C), 64.03 (6–C), 63.07 (6’–C), 62.64 (1’–C), 33.80 (–CH2– Chain), 31.76(–CH2– Chain), 29.47
(–CH2– Chain), 29.39 (–CH2– Chain), 29.18 (–CH2– Chain), 28.97 (–CH2– Chain), 24.88 (–CH2– Chain),
22.56 (–CH2– Chain), 14.43 (18–CH3). ESI-MS: [M + H2O]+ = 542.316.

Molecules 2018, 23, 1118
4 of 18
2.2.3. Analytical Procedure
Reaction were examined by TLC on Silica gel 60 F254 aluminum sheets using chloroform: methanol:
acetic acid: H2O (75:15:5:3 v/v/v/v) as the eluting system. The compounds were colored by spraying a
color agent with p-anisaldehyde–aceticacid–95% ethanol–sulfuric acid (12.5:2.5:225:12.5 v/v/v/v) and
◦
visualized by heating at 105 C for 15 min. HPLC analysis was performed by HPLC using a Waters pump
(Waters 1525, Waters, Sutton, MA, USA) with evaporative light scattering detector (ELSD, Waters 2424).
A Purospher RP-18e column (5
×
250
×
4.6 mm2, Merck, Darmstadt, Germany) was used, and the
mobile phase was a mixture of methanol and water (90:10 v/v) at a flowrate of 1 mL min−1. The yield of
SML was calculated from the HPLC data.
2.3. Bacterial Strains and Growing Conditions
Four common pathogenic bacterial strains were used in the study. The Gram-positive
bacteria, Listeria monocytogenes ATCC 19114 (L. monocytogenes), Bacillus subtilis CMCC(B) 63501
(B. subtilis), and Staphylococcus aureus CMCC(B) 26003 (S. aureus); and the Gram-negative bacteria,
Escherichia coli CMCC(B) 44102 (E. coli) were obtained from National Center For Medical Culture
Collections (Beijing, China), and were grown and maintained in Tryptone Soy broth (TSB) and on
Trypticase Soy agar (TSA) (Hangzhou Microbial Reagent Co. Ltd, Hangzhou, China). Strains were
maintained on TSA slants at 4 ◦C. A 16-h culture in TSB at 37 ◦C was diluted with TSB to achieve an
inoculum of 106 CFU mL−1 approximately. The cells numbers in the suspensions was identified by
duplicate plating from 10-fold serial dilution on TSA and counting the colonies after incubation at
37 ◦C for 24 h.
2.4. Antimicrobial Activity
2.4.1. Minimum Inhibitory Concentration (MIC) and Minimum Bactericide Concentration (MBC)
MIC and MBC were determined by broth macrodilution assay with some modification [15].
Serial two-fold dilutions of SML were prepared in TSB at concentrations of 1.25, 2.5, 5, 10, 20, 40,
and 80 mM. One tube with the same volume of TSB without SML was set as the negative control.
Inocula were added into all the tubes to achieve the initial inoculum of 106 CFU mL−1 approximately.
All tubes were incubated at 37 ◦C for 24 h, a 1 mL portion was removed from 10 mL cell suspensions
in each tube for colony counting by decimal dilution with sodium chloride solution (0.85%, w/v) ,
and plated out onto TSA. Each concentration was assayed in triplicate. The MIC was defined as the
lowest concentration resulting in maintenance or reduction of inoculums viability for all the triplicates
compared to the negative control after 24 h. The minimum bactericidal concentration (MBC) is defined
as the concentration where nearly 99% or more of the initial inoculums are killed after 24 h.
2.4.2. Growth Curve and Time–Kill Kinetics Analysis
◦
Briefly, Indicators were cultured to exponential phase (OD600 = 0.5–0.7) at 37 C and 125
µL of the
culture was transferred into each well on 96-well microtiter plates. SML was dissolved in the cultures
to obtain final concentrations of 1 MIC, 2 MIC, and 4 MIC, and samples without SML were
×
×
×
used as control. Bacteria were further cultured at 37 ◦C, and cell growth was monitored by enzyme
micro-plate reader at 600 nm at 0.5 h intervals, using a multimode plate reader, and lysis was observed.
The time–kill test was performed to determine the killing kinetics of SML against tested
bacteria [16]. Individual bottles containing SML broth dilutions with various concentrations were
−1
◦
cultured with the inoculum with a density of 106 CFU mL at 37 C with shaking at 180 rpm. After 0,
2, 4, 8, 12, 20, 24, and 48 h of incubation, aliquots of 1 mL was removed from each tube for colony
counting by decimal dilution in 0.85% (w/v) sodium chloride solution, and plated out onto TSA at
◦
37 C for 12–18 h, and the number of survivors (CFU mL−1) was determined by counting the colonies.
Time–kill curves were constructed by plotting the Log CFU mL−1 versus time. The theoretical detection
limit was 10 CFU mL−1, corresponding to 1 Log CFU mL−1
.

Molecules 2018, 23, 1118
5 of 18
2.5. Antibacterial Mechanism
2.5.1. Propidium Iodide Uptake Test
The fluorescent dye propidium iodide (PI; alladin, P113815) was used to evaluate cell membrane
damage of bacteria. The PI uptake test was conducted according to the method with some
modifications [17]. For each bacterium, after inoculation, all the solutions were incubated at 37 ◦C
under shaking conditions (180 rpm) for 24 h. A 5 mL portion from each tube was removed and then
centrifuged at 6000
×
g at 4 ◦C for 15 min. The supernatants were discarded and cells were washed
three times with PBS (0.1 mmol L−1, pH 7.2) and then cell pellets were resuspended in 10 mL PBS
(0.1 mmol L−1, pH 7.2) with the final cells concentration of 106 CFU mL−1. SML was added at the final
◦
concentration of 1
×
MIC and then incubated at 37 C under shaking conditions (180 rpm) for 4 h. A PI
stock solution of 1 mg mL−1 was prepared. For evaluation of PI uptake after SML treatment, cells were
incubated with 0.3 mL PI solution in the dark at 37 ◦C for 10 min. Fluorescence was measured at an
excitation wavelength of 495 nm and an emission wavelength of 500–700 nm with a 5-nm slit in a
fluorimeter (RF-5301PC, Shimadzu, Kyoto, Japan). The parallel sample without SML was used as the
negative control. Three independent experiments were performed for each condition tested.
2.5.2. Cell Constituents’ Release
The cell integrity is examined by determining the release of cell constituents into supernatant
according to Diao’s method with some modifications [18]. Cells from the working culture of tested
bacteria were collected by centrifuged for 10 min at 5000
×
g, washed three times with PBS (0.1 M,
pH 7.0), and resuspended in the same buffer. 5 mL of cell suspension were incubated with 1
×
MIC SML
◦
at 37 C under agitation for 6 h. Then, 2 mL of each sample was collected and centrifuged at 10,000
×
g
for 5 min. Negative control groups containing bacterial supernatant without SML treatments were
tested similarly. The concentrations of proteins in supernatants were established by Bradford assay [19].
1 mL of diluted supernatant and 5 mL of Coomassie Brilliant Blue G-250 reagent were carefully
mixed and its absorbance was measured at 595 nm. The protein content was determined by using
a calibration curve prepared with bovine serum albumin. Reducing sugars in supernatants were
determined using the 3,5-dinitrosalicylic acid (DNS) method by taking 1 mL of diluted supernatant
along with 1 mL of DNS reagent. A mixture was heated in boiling water for 10 min. After cooling to
room temperature, 10 mL of distilled water was added. The absorbance of the reaction mixtures was
measured at 540 nm and compared with a glucose calibration curve to obtain the concentration of
reducing sugars. The amounts of DNA and RNA released from the cytoplasm in supernatant were
analyzed by measuring the absorbance at 260 nm. Potassium ion concentration in TSB in supernatants
were determined by the method modified from Zhang’s method [20]. Cultures of bacteria with a
density of 106 CFU mL−1 were exposed to SML with fixed concentrations in TSB and all the solutions
were incubated at 37 ◦C under shaking conditions (180 rpm). After 0, 0.5, 2, 4, 8, 12, 20, and 24 h of
incubation, aliquots of 1 mL was removed from each tube and a cell-free supernatant was harvested
by centrifugation at 8000
(Hydrophilic PTFE needle filter, ANPEL Laboratory Technologies Inc., Shanghai, China) with a 0.45-
×
g for 15 min and the suspension was filtered through a millipore filter
µm
nylon membrane and then 0.1 mL filtrate was diluted with 4.9 mL HNO3 solution (2%) for measuring
the amount of extracellular potassium ions via inductively coupled plasma mass spectrometry (ICP-MS;
Agilent 7700×, Agilent Technologies Japan, Tokyo, Japan).
2.5.3. Cytoplasmic β-Galactosidase Released from Cells after SML Treatment
The bacterial suspensions of L. monocytogenes, S. aureus, and E. coli (1.0
treated with solutions of SML at 20 mM containing 1.0 mM MgCl2 and 10 mM KCl at 37 C with
×
108 CFU mL−◦1) were
orbital shaking for 2 h. Untreated L. monocytogenes, S. aureus, and E. coli were used as negative controls,
respectively. The samples were then centrifuged at a 4000
retrieved for use in the colorimetric assay. The supernatants were diluted ten-fold in PBS solution
×
g for 10 min, then the supernatants were

Molecules 2018, 23, 1118
6 of 18
(950 µL), and then 50 µL of 1.0 mM o-nitrophenol (ONP) was added to the supernatants and allowed
to react at room temperature for 2 h. Then, 200 L of each sample was transferred into a 96-well
µ
flat bottom microplate, and the absorbance of the samples was measured using a monochromatic
microplate spectrophotometer at 420 nm.
2.5.4. Evaluation of Zeta Potential
The zeta potential of the bacterial suspensions was determined as previously reported with some
modifications [21]. Various bacteria were incuba◦ted overnight in TSB at 37 ◦C at 180 rpm agitation.
The cells were centrifuged twice at 5000
The OD640 nm of cell suspensions was set to 0.2
of SML (to a final concentration of 10 mM) and incubated at 30 ◦C and 120 rpm for 1 h. A negative
control was prepared with sterile distilled water. The zeta potential of the bacterial suspensions was
recorded using a Nano Zetasizer (Malvern Instruments), in carefully filled zeta potential cells (DTS1060,
Malvern, UK), at the room temperature (20–25 ◦C).
×
g and 25 C for 10 min and washed with sterile distilled water.
±
0.02. 1.8 mL of this culture was added to 200 µL
2.5.5. Effect of SML on Bacterial DNA
Bacteria genomic DNA was extracted by using TIANamp Bacteria DNA Kit (Tiangen Biotech, Co., Ltd.,
Beijing, China). The purity of the extracted DNA was determined by the optical density method
(OD260/OD280 = 1.978), and the concentration of DNA measurement was conducted by using the
ultraviolet absorbance at 260 nm (UV 2600, Shimadzu, Kyoto, Japan) at the room temperature. The bacteria
DNA and SML were dissolved in 10 mM Tris–HCl buffer (pH 7.2) and then mixed to obtain various
DNA/SML samples with increasing SML concentrations (0, 5, and 10 mM). DNA mixed with ethanol
was used as negative control because SML was dissolved in ethanol. After incubation at 37 ◦C for 10 min,
absorbance of the mixed solutions was measured in the range of wavelengths 230–350 nm (SpectraMax
i3x multi-mode detection platform, Molecular Devices, Wals, Austria). Electrophoresis was performed to
separate and visualize DNA fragment in a 0.8% agarose gel at 130 V for 25 min. DNA was stained with the
GelRed dye.
2.5.6. Biofilm Formation Assay
Biofilm formation was quantified in regular 96-well microtiter plates according to a previously
described method [22] with minor modifications. The overnight-grown cultures were diluted 1:100
in fresh TSB medium containing appropriate concentrations of SML, transferred to sterile 96-well
microtiter plates at 200 µL per well and incubated at 37 ◦C without shaking for 48 h.
2.5.7. Scanning Electron Microscopy (SEM) Analysis
SEM studies were carried out as previously reported with some modifications [23] to determine
the efficacy of the SML and the morphological changes of bacteria strains. Bacteria at approximate
−1
◦
106 CFU mL were treated with 1
×
MIC SML. After 20 h of incubation at 37 C, cells were harvested
by centrifugation at 10,000
×
g for 10 min and washed twice with 0.1 M phosphate buffer saline
(PBS, pH 7.2), and then fixed with 2.5% (v/v) glutaraldehyde in PBS (0.1 M, pH 7.0) overnight at
4 ◦C; washed three times in the PBS (0.1 M, pH 7.0) for 15 min at each step; then postfixed with 1%
OsO4 in phosphate buffer for 1–2 h and washed three times in the PBS (0.1 M, pH 7.0) for 15 min
at each step. After centrifugation, the cells were then dehydrated with an ethanol series (30, 50, 70,
80, 90, 95, and 100%). Cells were dried further by using a Hitachi Model HCP-2 critical point dryer
(Hitachi Koki Co. Ltd., Tokyo, Japan) with liquid CO2. The dehydrated sample was coated with
gold-palladium in Hitachi Model E-1010 ion sputter (Hitachi Koki Co. Ltd., Tokyo, Japan) for 4–5 min
and examined under Hitachi Model TM-1000 SEM (Hitachi Koki Co. Ltd., Tokyo, Japan).

Molecules 2018, 23, 1118
7 of 18
2.6. Statistical Analysis
All of the experiments were performed in triplicate and the mean
were reported. The significant differences between the two groups were examined using t-test.
A p-value < 0.05 denoted the presence of a statistically significant difference.
±
standard deviation values
3. Results and Discussion
3.1. Lipase-Catalyzed Transesterification in Novel Functionalized Ionic Liquid
The yields of the enzymatic synthesis of SML was dependent on many conditions including the
type of acyl donor, enzyme, and solvent [14]. In order to gain greater yield, vinyl ester was chosen
as the acyl donor as the rate of transesterification of sugar and vinyl ester was much faster than
with alkyl esters [24]. Considering both the regioselectivity (6-O) and catalytic activity, it had been
confirmed that lipase from T. lanuginosa (such as Lipozyme TL IM from Novo Nordisk) is the most
efficient enzyme for this reaction [25]. A conversion of 37% to monolaurate in 36 h was achieved
by employing 2M2B as the medium. The resulting monoester was isolated, and the position of
acylation determined by 1H-NMR, demonstrating that hydroxyl 6-OH was mainly selectively acylated.
Furthermore, we found a functionalized ionic liquid ([3CIM(EO)][NTf2]) could give a relatively better
yield of SML compared to [BMIM][BF6] or [BMIM][BF4] which were commonly used in biocatalysis
to ameliorate the performance of enzymes in conventional organic solvents (no data shown). It has
been reported that ILs containing an alkyl ether moiety as a cationic part acted as good media for
enzymatic reactions [26]. It is accordingly envisioned that the novel ionic liquid synthesized with
the combination of both advantages from the structures of double imidazolium ring and alkyl ether
moiety could not only afford a preferred microenvironment for enzymatic reactions with maintaining
the relatively high activity of lipase but also improve the solubility of substrates [5]. The addition of
[3CIM(EO)][NTf2] (50%, v/v) to the medium gave rise to a notable acceleration of the process, resulting
in a 66% conversion to 6-O-lauroylsucrose in 24 h. This enhancement of monoester production and
shorter reaction time could be related to a better solubilization of sucrose in the medium containing
the suitable ionic liquid.
In this work, the lipase-catalyzed transesterification of sucrose with vinyl laurate was successfully
performed in a binary system consisted of [3CIM(EO)][NTf2] and 2M2B (Scheme 1), which proved
to be capable of achieving a high SML yield (72%) under the optimum conditions (VIL:V2M2B = 1.5:1,
◦
sucrose to vinyl laurate molar ratio of 1:3, 60 C, Lipozyme TL IM concentration of 50 g/L, 24 h).
The SML was the main resulting product with small amount of diesters and the purity of SML was
higher than 94% after being purified by silica gel column chromatography (Figure S1a). The identity of
the ester products was confirmed by NMR analysis and its 13C-NMR spectrum showed as Figure S1b,
which was shown to be identical to those reported by Potier et al. [27].
Scheme 1. Lipase-catalyzed synthesis of SML in ionic liquid.

Molecules 2018, 23, 1118
8 of 18
3.2. MICs and MBCs of SML
Most of the previous studies on antimicrobial properties of SFAE used commercial derivative [6,10].
In this context, SML was obtained as described above and purified to 94% via by silica gel column
chromatography. The effect of SML was tested on four different pathogenic bacteria including Gram-positive
bacteria (L. monocytogenes, B. subtilis, and S. aureus) and Gram-negative bacterium (E. coli). The bacterial
were diluted to 106 CFU mL−1 before the addition of SML at final concentrations of 1.25, 2.5, 5, 10, 20, 40,
and even 80 mM. The MICs and MBCs of SML against the tested bacteria are shown in Figure S2.
In general, SML showed a higher activity against Gram-positive bacteria than against
Gram-negative bacteria. The MICs of SML against Gram-positive bacteria, L. monocytogenes, B. subtilis,
as well as S. aureus were 2.5, 2.5, and 10 mM, respectively. Compared with other tested bacteria,
L. monocytogenes appear to be the most susceptible to SML, as it shows a significant growth difference
from the control at a SML concentration of 2.5 mM. B. subtilis, is more sensitive to SML than
that of S. aureus. The similar results were also obtained by Wagh et al. [28], Habulin et al. [13],
and Ferrer et al. [10]. Lactose monolaurate of 2 mM exhibited some growth inhibition against Listeria
but the MBC was between 5.7 and 9.5 mM [28]. Habulin et al. [13] found the similar effect of SML
concentration on the inhibitory of it again B. cereus, namely increasing the concentration of SML up to a
specific value, 23 mM, resulting in 99% inhibition. On the other hand, enzymatically synthesized SML
with the concentration of 7.6 mM could exhibit the maximum percentage of inhibition for B. subtilis
(95%), while the inhibition could not be found as for S. aureus [10]. Moreover, Figure S2 also shows that
L. monocytogenes and B. subtilis has a similar MBC of 20 mM, while S. aureus has an MBC of 40 mM.
As for Gram-negative bacteria, E. coli, the growth of E. coli was slightly less than that of control
at concentrations of 40 mM (regarded as the MIC) and only 3% inhibition was observed in the
concentration of 80 mM (Figure S2d). The results indicated that Gram-negative bacteria were more
resistant to SML than Gram-positive bacteria due to the outer membrane of the Gram-negative bacteria,
which restricted diffusion of SML through their lipopolysaccharide covering [29]. Similar results
were also found by Monk et al. [6] and Habulin et al. [13]. SML showed no inhibition on the growth
of E. coli in broth in the concentration of 2 mM [
6
]. The purified enzymatically synthesized SML
in the concentration of 6.25 mg mL−1 (12 mM), as well as the commercial SML in concentration
of 12.5 mg mL−1 caused no decrease in the growth of E. coli after 28 h [13]. However, the results
are varying in other research groups. Ferrer et al. [10] reported 26% inhibition was obtained at the
concentration of 7.6 mM of enzymatically synthesized SML. Kato and Arima [9] reported chemically
synthesized SML (58.3%, in purity) at concentrations higher than 0.2 mg mL−1 completely inhibited
growth, whereas using the same sample from Kato group, no inhibition of Gram-negative organisms
including E. coli was observed by Conley and Kabara [12]. These discrepancies could be due to the
variation in the procedures of preparation and purification for SML, bacteria strains, as well as analysis
approaches of antimicrobial activity.
3.3. Growth Curve and Time–Kill Analysis
SML lysed exponentially growing cells of L. monocytogenes and B. subtilis (Figure 1a,c).
The addition of SML to the culture with the final concentration of 1
×
MIC caused a 72 or 25%
reduction in the OD600, respectively, after 1 h of incubation. These results suggested that the lysis of
L. monocytogenes and B. subtilis cells induced with SML may be due to the action of autolytic enzymes,
as in the lysis by sucrose hexadecanoate described previously [30].

Molecules 2018, 23, 1118
9 of 18
(a)
(c)
(e)
(b)
(d)
(f)
(g)
(h)
Figure 1. Time–kill curves of SML at the different concentration against various microorganisms.
) L. monocytogenes; ( ) B. subtilis; ( ) S. aureus; ( ) E. coli. The error bars represent the
standard deviations.
(
a,b
c,d
e,f
g,h

Molecules 2018, 23, 1118
10 of 18
Time–kill assays allow to examine the rate at which different concentrations of enzymatically
synthesized SML kill bacteria; the concentration-dependent and time-dependent bactericidal activities
of SML can be investigated by this methodology. The results obtained for the time–kill curves are
summarized in Figure 1. Time–kill curves differ for each species. SML at higher concentrations
led to a more rapid decrease in bacterial number for Gram-positive bacteria. The viability of these
Gram-positive cells decreased significantly to 0 Log CFU mL−1 after 2 or 4 h of incubation with SML
at 1
×
MIC, compared to nearly 8 Log CFU mL−1 of the control. In comparison with the results in
Figure 1a–d, the lytic action of SML to L. monocytogenes and B. subtilis could be ascertained clearly.
In addition, during this treatment a great loss of viability occurred that preceded lysis, indicating that
autolysis is induced by SML. On the other hand, the viable cells numbers were rapidly declined after 2
or 4 h (Figure 1b,d,f). SML may interact with cytoplasmic membrane (CM) to disturb the regulation
system of (a) peptidoglycan (PG) hydrolase(s) activities. Such an enzyme may attack outside PG and
the initial partial degradation of PG layer may form rather hole in the layer.
In the treatments with SML at more than 1
of bacteria were significantly lower than the initial value after 24 h. Above 4
activity promptly was shown in 2 h. Furthermore, the fact that SML at high concentrations showed
×
MIC concentration, the numbers of viable cells
MIC, bactericidal
×
rapidly bactericidal activity, pointed towards a mechanism of action, infiltration of bacterial membrane.
−1
Moreover, when SML concentration was set at 2
×
MIC, there were 5.16, 1.03, and 4.61 Log CFU mL
drops in colony counts after 24 h for L. monocytogenes, B. subtilis and S. aureus, respectively
(Figure 1b,d,f). Noteworthily, for Gram-positive bacteria, killing was first observed after 2 or
4 h and then the surviving cells regrew, which indicate these cells seemed to adapt to SML.
Similar results were also found in bacteria cells treated by other antibacterial compounds, such as
sucrose hexadecanoate [30] and amikacin [31].
For the Gram-negative bacteria, E. coli, to some extent antibacterial activity was observed before
16 h at 1
×
MIC SML and then the regrowth occurred (Figure 1d). However, in terms of the time–kill
curves, we noted these findings are inconsistent with the results recently reported by Zhao et al. [11],
even though the antibacterial agent with similar structure, sucrose monocaprate, was applied to inhibit
the growth of B. cereus, B. subtilis, S. aureus, E. coli, and S. typhimurium.
3.4. Permeability of Cell Membrane
PI uptake, which is intimately related to pore formation in the cell membrane [17]. Cells were
treated with SML at 1
×
MIC for 24 h. Under these conditions PI uptake values varied with type
of bacteria (Figure S3 and Figure 2a). The differences in fluorescence intensity (a.u.) caused by
PI-DNA interaction could quantitate the strength of CM permeabilization following the SML-induced
membrane leakage. Except E. coli, PI uptake values for bacteria pretreated with SML at 1
×
MIC for
24 h were significantly higher than those treated without SML in the present study, which indicate that
pores can form in the cell membrane when SML was applied to these bacteria. It also can be observed
in SEM analysis (Figure 3b,d,f). In addition, pore formation is dependent on SML concentrations, and
a critical concentration is needed for pore formation to lead to membrane destruction (no data shown).
In terms of E. coli cells, the fluorescence intensity of PI showed no increase compared with the control
(p > 0.05), indicating that the integrity of E. coli cells could not be compromised by 1
which also could be directly observed by SEM (Figure 3g,h).
×
MIC SML,
In parallel with the hole formation, the inside CM could be blown out first due to turgor pressure from
the cytoplasm of Gram-positive bacteria to form a bleb. Then, the bleb was broken and inside cytoplasmic
materials leaks out. The turgor force for Bacillus subtilis is considerable, and up to 20 atm [32]. Therefore,
the overall data propose that SML reinforced damage on the bacterial membranes, with remarkable effects
on Gram-positive bacteria. Thus, one can propose that SML may act as the antimicrobial agent that weaken
the outer membrane of the cells, inducing changes on its permeability. To investigate the effect of SML on
cytoplasmic membrane, the permeability of the membranes to intracellular K+ and
assessed. Figure 2b showed K+ efflux from L. monocytogenes treated with SML at 1
β
-galactosidase was also
×
MIC and 4 MIC for
×

Molecules 2018, 23, 1118
11 of 18
different period of time. In the presence of SML, the K+ efflux significantly accelerated for the first 2 h and
then continued to increase for the rest of observation time. As shown in Figure 2c, released cytoplasmic
β-galactosidase from L. monocytogenes, S. aureus, and E. coli exhibits dose dependence with treatment using
SML. Compared to the control, the leakage of cytoplasmic -galactosidase from L. monocytogenes and S. aureus
β
treated with SML increased by 1.9 and 1.5 times, respectively. However, in case of E. coli, no obvious increase
in the leakage of cytoplasmic β-galactosidase was observed, compared to the control.
As a damaged bacterial cell membrane is more permeable, large molecules, such as protein and
genetic nucleotide materials leach out from the cells. Compared to the control, the leakage of proteins from
L. monocytogenes, B. subtilis, S. aureus treated with SML increased by 2.7, 3.1, and 20.7 times, respectively
(Figure 2d). The OD260 of supernatant from L. monocytogenes, B. subtilis, and S. aureus treated with SML were
1.5-, 1.7-, and 2.3-times as high as that of the control (Figure 2e). Similarly, the leakage of reducing sugar from
L. monocytogenes and B. subtilis treated with SML increased by 54.7- and 4.3-times compared to the control,
and S. aureus treated without SML even demonstrated the leakage of reducing sugar below the detection
limit (Figure 2f). The above results indicated that damage to the CM did occur, which led to the losses of cell
constituents and inhibition of cell growth.
(a)
(b)
(c)
(d)
(e)
(f)
Figure 2.
SML on cell constituents’ release of various bacteria; (
suspensions in TSB; ( ) Absorbance of o-nitrophenol (ONP) at 420 nm (Abs420) from the supernatants of
different cells with 20 mM SML treatment; ( ) Protein. The error bars represent the standard deviations,
and the asterisks indicate significant difference between each other; ( ) UV-absorbing substances
leaking (OD260 nm); ( ) Reducing sugar. The error bars represent the standard deviations, and the
asterisks indicate significant difference between each other.
(a
) Uptake of propidium iodide of various microorganisms after SML treatment. Effect of
b) Potassium ion efflux of L. monocytogenes cell
c
d
e
f

Molecules 2018, 23, 1118
12 of 18
(a)
(c)
(e)
(g)
(b)
(d)
(f)
(h)
Figure 3.
after treatment with 1
(magnification, 20,000); (
50,000); ( ) SEM of S. aureus control (magnification,
with 1 MIC SML for 24 h (magnification, 40,000); ( ) SEM of E. coli control (magnification,
) SEM of E. coli after treatment with 1 MIC SML for 24 h (magnification, 25,000). White arrows
indicate the pore-like lesions.
(
a
) SEM of L. monocytogenes control (magnification,
MIC SML for 24 h (magnification,
) SEM of B. subtilis after treatment with 1
20,000); (
×
10,000); (
25,000); (
MIC SML for 24 h (magnification,
) SEM of S. aureus after treatment
20,000);
b
) SEM of L. monocytogenes
×
×
c) SEM of B. subtilis control
×
d
×
×
e
×
f
×
×
g
×
(
h
×
×

Molecules 2018, 23, 1118
13 of 18
3.5. Scanning Electron Microscopy (SEM) Analysis
The morphological changes of L. monocytogenes, B. subtilis, S. aureus, and E. coli were evaluated by
SEM analysis. The scanning electron micrographs of both untreated and SML-treated bacterial cells are
shown in Figure 3. Untreated cells showed regular and typical morphology, with a plump and smooth
surface, and were uniform in size and distribution (Figure 3a,c,e,g). In contrast, L. monocytogenes,
B. subtilis, and S. aureus cells treated with at 1
×
MIC concentration of SML (2.5 mM for L. monocytogenes,
2.5 mM for B. subtilis, and 10 mM for S. aureus) and revealed a severe damaging effect on the
cell morphology, showing an irregularly wrinkled and coarse outer surface, the small leaking hole
(Figure 3b,d,h) or even cell collapse could be observed (Figure 3f). This indicated that SML treatment
may result in damage to the L. monocytogenes, B. subtilis, and S. aureus cell walls and CM. However,
no obvious broken and rupture cells were found in E. coli cells treated with 40 mM SML, and
only more wrinkled, coarse outer surface were observed by SEM at 20 k magnification (Figure 3h).
The concentration for commercially available sugar esters used in foods and cosmetics as emulsifiers is
−1
up to 10 g L
[33], which is nearly twice as high as the MBC determined here for L. monocytogenes [25].
The MBCs for these tested organisms are greater than the critical micelle concentration (CMC) value
for SML (0.2 to 0.8 mM) [34], indicating that SML concentrations greater than the CMC should be
concerned to afford cell growth inhibition. Our results are consistent with other studies that evaluated
the antimicrobial effects of various esters against Gram-positive bacteria. Similarly, it is proposed
that monoglycerides as non-ionic surfactants penetrate and become combined with bacterial plasma
membrane, thereby compromising membrane permeability. Some researchers suggested sucrose esters
exerted their antibacterial effect through affecting the permeability of the cell membrane, resulting in
the leakage of some cellular components such as proteins, reducing sugars [11].
3.6. Effects of SML on the Apparent Zeta Potential of Cells
The surface charge of cells is frequently determined based on their zeta potential, which is
calculated from their electrophoretic motility in the presence of an electric field, under defined pH
and ionic concentrations [35]. The time course of zeta potential measurements with L. monocytogenes
and E. coli in the absence and presence of SML were presented in Figure S4. The alterations in zeta
potential of L. monocytogenes and E. coli exhibited different patterns compared to their own controls.
Bacterial cells normally present a negative surface charge, due to the presence of anionic groups in
their membranes, such as carboxylate and phosphate groups [36]. Changes in the surface charge
of both bacteria to less negative values were obtained after exposure to SML, indicating that cells
treated with SML could to the depolarization of membrane. In addition, the release of K+ from
the cytosol led to the alterations of the zeta potential of cells, which would disturb the subcellular
localization of some proteins, and thereby cause the bacterial inactivation. For L. monocytogenes, where
the effect of SML on the surface charge in zeta potential was more significant than that of E. coli.
In comparison with the native control, less negative values were obtained when cells were exposed
to SML (Figure S4a). In contrast to this, for E. coli, there are inconspicuous variation in zeta potential
during the first 10 h regardless of exposure to SML (Figure S4b). Also, the obvious differences in zeta
potential distribution of cells exist for such two representative bacteria, even though they were treated
with the same conditions. A second peak located at apparent zeta potential of L. monocytogenes with
treatment of SML was observed in Figure 4b, while this peak did not show when L. monocytogenes was
treated without 10 mM SML for 24 h in Figure 4a. However, such a change did not occur in E. coli
(Figure S4c,d). It could be inferred that there might be a different mode of action of SML for these two
different bacteria.

Molecules 2018, 23, 1118
14 of 18
(a)
(b)
(c)
Figure 4. The effect of SML on zeta potential distribution of L. monocytogenes. (
a) L. monocytogenes,
without exposure to SML for 24 h; ( ) L. monocytogenes, with exposure to SML for 24 h. Interaction of
b
DNA of L. monocytogents with increasing amounts of SML; (c) Ultraviolet spectroscopic measurements.
3.7. Effect of SML on DNA of L. monocytogenes
The disruption of DNA, one of the most important genetic materials, could hinder gene expression,
thereby leading to the restriction of normal enzyme and receptor synthesis, and inevitably inducing the
death of bacteria. The interaction between SML and DNA, like the binding of it to DNA, was studied
through ultraviolet and fluorescence spectra. As shown in Figure 4c, the addition of SML illustrated
significant decrease of the maximum absorption intensity and a slight red shift, indicating the
corresponding alternation in structure and conformation of DNA resulting from SML. SML may
bind onto the phosphate group of DNA by hydrogen bonding, which could lead to reduction of the
charge density in main chain and incensement the contraction of DNA structure [11]. The present
study demonstrated that besides the cell wall and membrane, the bacterial genome might be another
antibacterial target of SML, which fertilize the antibacterial mechanism of SML. Since SML showed
binding effect with DNA, agarose gel electrophoresis of genomic DNA and DNA with increasing
amounts of SML were used to evaluate whether it could induce the DNA damage. As shown in
Figure S5, the bands of DNA treated with different concentrations of SML were similar to that of
control, which indicated SML had no ability to cause significant DNA damage. These results are in
accordance with the findings obtained by Zhao et al. [11].
3.8. Effect of SML at Sub-MICs on the Inhibition of Biofilm Formation
SML is completely safe and if it had biofilm inhibitory activity, it would be suitable to be
employed in controlling biofilms in food applications. Microbial biofilms represent a distinct bacterial
physiology characterized by a multicellular phenotype that is fundamentally different from planktonic
bacteria. In this section, we explored the differing effects of SML at sub-MICs on Gram-positive and

Molecules 2018, 23, 1118
15 of 18
Gram-negative bacterial strains. Figure 5 showed that SML exhibits the specific ability for inhibition of
biofilm formation by these bacteria except for S. aureus. SML could significantly inhibit the biofilm
formation by B. subtilis, L. monocytogenes, and E. coli. The degree of inhibition of biofilm formation
resulted from SML was relatively concentration-dependent. Compared to the control, the biofilm
formation from L. monocytogenes, B. subtilis, and E. coli treated with 1/4
×
MIC SML reduced by 1.9-,
6.1-, and 2.6-times, respectively, demonstrating that the efficacy of SML to spoil the biofilm formation
by B. subtilis is the most remarkable among them. We speculated that the physical factors such as
nature of electric charge of the cell surface or physical interaction between cell and solid surface might
be of more importance [35].
In contrast, the biofilm formation by S. aureus was stimulated by SML at sub-MICs, which could be
rationally used to explain why S. aureus is more inherently resistant to SML than other Gram-positive
bacteria in Figure S2. This was also found in recent experiments on biofilm formation, where all the
antibiotics tested were effective in laboratory MIC tests but lost their efficacy against S. aureus biofilms
in sub-MICs [37]. On the other hand, the growth of these four bacteria was mostly unaffected at
sub-MICs (<1/2
×
MIC), which is also in agreement with the results obtained in Figure S2. It is also
speculated that the inhibition of SML to them is related not only to physicochemical properties of cell
surface such as chemical structure and composition or nature of electric charge of the cell surface but
also to chemical interaction between cells/biofilm and antibacterial compounds or physical interaction
between cells and solid surface [35].
(a)
(b)
(c)
(d)
Figure 5. Effect of different concentrations of SML on the biofilm formation of (
) B. subtilis; ( ) S. aureus; ( ) E. coli. The error bars represent the standard deviations, and the asterisks
indicate significant difference between each other.
a) L. monocytogenes;
(b
c
d
4. Conclusions
This work investigated the antibacterial properties of enzymatically synthesized SML against
four pathogenic bacteria including L. monocytogenes, B. subtilis, S. aureus, and E. coli. SML could exhibit
significant antimicrobial activity against tested bacterial and anti-biofilm formation for these bacteria,

Molecules 2018, 23, 1118
16 of 18
especially against Gram-positive bacteria. The potential antibacterial mechanisms of SML were related
to permeability and integrity of cell envelops, resulting in leakage of some cellular components
(proteins, reducing sugars, 260 nm absorbing materials and K+, as well as
β-galactosidase). Similarly,
SML might bind with DNA to hinder DNA replication. Moreover, SML at sub-MIC significantly
inhibited biofilm formation by L. monocytogenes, B. subtilis, and E. coli, especially for B. subtilis,
whereas their inhibitory effect was invalid in the case of S. aureus biofilm formation. More broadly,
we expect this study’s ability to find the use of other biosurfactants on their own or as adjuvants may
represent a potential way forward in tackling foodborne infections and biofilms in food processing
environments in the future.
Supplementary Materials: The supplementary materials are available online.
Author Contributions: Y.-G.S. conceive and designed the experiments; Y.-G.S., S.-Y.S., Y.W., L.-Q.B., Y.-J.Z.,
X.-Y.H., Y.P., L.-Y.Z. and R.-R.Z. performed the experiments; Y.-G.S. analyzed the data; Y.-G.S. wrote the paper.
All authors have approved for the final version of the manuscript.
Funding: This research was funded by National Natural Science Foundation of China (21106131 and 31501452),
Academic Exchanges and Talent Training Program (2017SICR109), Zhejiang Provincial Program for Overseas
High-Level Experts Introduction (Z20170407), as well as Food Science and Engineering the Most Important
Discipline of Zhejiang Province (JYTsp20142101).
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
5.
Rantwijk, F.V.; Lau, R.M.; Sheldon, R.A. Biocatalytic transformations in ionic liquids. Trends Biotechnol. 2003
21, 131–138. [CrossRef]
Moniruzzaman, M.; Nakashima, K.; Kamiya, N.; Goto, M. Recent advances of enzymatic reactions in ionic
liquids. Biochem. Eng. J. 2010, 48, 295–314. [CrossRef]
Quijano, G.; Couvert, A.; Amrane, A. Ionic liquids: Applications and future trends in bioreactor technology.
Bioresour. Technol. 2010, 101, 8923–8930. [CrossRef] [PubMed]
Shi, Y.G.; Liu, Y.L.; Lai, P.Y.; Tseng, M.C.; Tseng, M.J.; Li, Y.D.; Chu, Y.H. Ionic liquids promote PCR
amplification of DNA. Chem. Commun. 2012, 48, 5325–5327. [CrossRef] [PubMed]
Shi, Y.G.; Wu, Y.; Lu, X.Y.; Ren, Y.P.; Wang, Q.; Zhu, C.M.; Yu, D.; Wang, H. Lipase-catalyzed esterification of
ferulic acid with lauryl alcohol in ionic liquids and antibacterial properties in vitro against three food-related
bacteria. Food Chem. 2017, 220, 249–256. [CrossRef] [PubMed]
,
6.
Monk, J.D.; Beuchat, L.R.; Hathcox, A.K. Inhibitory effects of sucrose monolaurate, alone and in combination
with organic acids, on Listeria monocytogenes and Staphylococcus aureus. J. Appl. Bacteriol. 1996, 81, 7–18.
[CrossRef] [PubMed]
7.
8.
Yang, C.M.; Luedecke, L.O.; Swanson, B.G. Inhibition of microorganisms in salad dressing by sucrose and
methylglucose fatty acid monoesters. J. Food Process. Preserv. 2003, 27, 285–298. [CrossRef]
Favier, G.I.; Escudero, M.E.; de Guzmán, A.M. Inhibitory effects of sucrose fatty acid esters on survival of
Yersinia enterocolitica on eggshell surface and use of blue lake as indicator of bacterial penetration into eggs.
J. Appl. Microbiol. 2009, 106, 774–783. [CrossRef] [PubMed]
9.
Kato, A.; Arima, K. Inhibitory effect of sucrose ester of lauric acid on the growth of Escherichia coli.
Biochem. Biophys. Res. Commun. 1971, 42, 596–601. [CrossRef]
10. Ferrer, M.; Soliveri, J.; Plou, F.J.; López-Cortes, N.; Reyes-Duarte, D.; Christensen, M.; Copa-Patino, J.L.;
Ballesteros, A. Synthesis of sugar esters in solvent mixtures by lipases from Thermomyces lanuginosus and
Candida antarctica B, and their antimicrobial properties. Enzym. Microb. Technol. 2005, 36, 391–398. [CrossRef]
11. Zhao, L.; Zhang, H.Y.; Hao, T.Y.; Li, S. In vitro antibacterial activities and mechanism of sugar fatty acid
esters against five food-related bacteria. Food Chem. 2015, 187, 370–377. [CrossRef] [PubMed]
12. Conley, A.J.; Kabara, J.J. Antimicrobial action of esters of polyhydric alcohols. Antimicrob. Agents Chemother.
1973, 4, 501–506. [CrossRef] [PubMed]
13. Habulin, M.; Šabeder, S.; Knez, Ž. Enzymatic synthesis of sugar fatty acid esters in organic solvent and in
supercritical carbon dioxide and their antimicrobial activity. J. Supercrit. Fluids 2008, 45, 338–345. [CrossRef]

Molecules 2018, 23, 1118
17 of 18
14. Walsh, M.K.; Bombyk, R.A.; Wagh, A.; Bingham, A.; Berreau, L.M. Synthesis of lactose monolaurate as
influenced by various lipases and solvents. J. Mol. Catal. B Enzym. 2009, 60, 171–177. [CrossRef]
15. Wilson, B.; Abraham, G.; Manju, V.S.; Mathew, M.; Vimala, B.; Sundaresan, S.; Nambisan, B. Antimicrobial
activity of Curcuma zedoaria and Curcuma malabarica tubers. J. Ethnopharmacol. 2005, 99, 147–151. [CrossRef]
[PubMed]
16. D’Arrigo, M.; Ginestra, G.; Mandalari, G.; Furneri, P.M.; Bisignano, G. Synergism and postantibiotic
effect of tobramycin and Melaleuca alternifolia (tea tree) oil against Staphylococcus aureus and Escherichia coli.
Phytomedicine 2010, 17, 317–322. [CrossRef] [PubMed]
17. Park, I.K.; Kang, D.H. Effect of electropermeabilization by ohmic heating for inactivation of Escherichia coli
O157:H7, Salmonella enterica serovar Typhimurium, and Listeria monocytogenes in buffered peptone water and
apple juice. Appl. Environ. Microb. 2013, 79, 7122–7129. [CrossRef] [PubMed]
18. Diao, W.R.; Hu, Q.P.; Zhang, H.; Xu, J.G. Chemical composition, antibacterial activity and mechanism
of action of essential oil from seeds of fennel (Foeniculum vulgare Mill.). Food Control 2014, 35, 109–116.
[CrossRef]
19. Bradford, M.M. A rapid and sensitive method for the quantitation of microgram quantities of protein
utilizing the principle of protein–dye binding. Anal. Biochem. 1976, 72, 248–254. [CrossRef]
20. Zhang, H.Y.; Kong, B.H. Study on antibacterial mechanism of clove extract. Food Sci. 2009, 30, 88–91.
21. Borges, A.; Ferreira, C.; Saavedra, M.J.; Simões, M. Antibacterial activity and mode of action of ferulic and
gallic acids against pathogenic bacteria. Microb. Drug Resist. 2013, 19, 256–265. [CrossRef] [PubMed]
22. Narisawa, N.; Furukawa, S.; Ogihara, H.; Yamasaki, M. Estimation of the biofilm formation of Escherichia coli
K-12 by the cell number. J. Biosci. Bioeng. 2005, 99, 78–80. [CrossRef] [PubMed]
23. Ma, X.H.; Zheng, J.; Zhang, X.L.; Hu, Q.D.; Qian, R.J. Salicylic acid alleviates the adverse effects of salt stress
on Dianthus superbus (Caryophyllaceae) by activating photosynthesis, protecting morphological structure,
and enhancing the antioxidant system. Front. Plant Sci. 2017, 8, 600. [CrossRef] [PubMed]
24. Wang, Y.F.; Lalonde, J.J.; Momongan, M.; Bergbreiter, D.E.; Wong, C.H. Lipase-catalyzed irreversible
transesterifications using enol esters as acylating reagents: Preparative enantio- and regioselective syntheses
of alcohols, glycerol derivatives, sugars and organometallics. J. Am. Chem. Soc. 1988, 110, 7200–7205.
[CrossRef]
25. Ferrer, M.; Cruces, M.A.; Bernabé, M.; Ballesteros, A.; Plou, F.J. Lipase-Catalyzed Regioselective Acylation of
Sucrose in Two-Solvent Mixtures. Biotechnol. Bioeng. 1999, 65, 10–16. [CrossRef]
26. Zhao, H.; Song, Z.; Olubajo, O. High transesterification activities of immobilized proteases in new
ether-functionalized ionic liquids. Biotechnol. Lett. 2010, 32, 1109–1116. [CrossRef] [PubMed]
27. Potier, P.; Bouchu, A.; Gagnaire, J.; Queneau, Y. Proteinase N-catalysed regioselective esterification of sucrose
and other mono- and disaccharides. Tetrahedron Asymmetry 2001, 12, 2409–2419. [CrossRef]
28. Wagh, A.; Shen, S.; Shen, F.A.; Miller, C.D.; Walsh, M.K. Effect of lactose monolaurate on pathogenic and
nonpathogenic bacteria. Appl. Environ. Microbiol. 2012, 78, 3465–3468. [CrossRef] [PubMed]
29. Jouki, M.; Mortazavi, S.A.; Yazdi, F.T.; Koocheki, A. Optimization of extraction, antioxidant activity and
functional properties of quince seed mucilage by RSM. Int. J. Biol. Macromol. 2014, 66, 113–124. [CrossRef]
[PubMed]
30. Tsuchido, T.; Ahn, Y.H.; Takano, M. Lysis of bacillus subtilis cells by glycerol and sucrose esters of fatty acids.
Appl. Environ. Microbiol. 1987, 53, 505–508. [PubMed]
31. Ferro, B.E.; Van, I.J.; Wattenberg, M.; Van, S.D.; Mouton, J.W. Time–kill kinetics of antibiotics active against
rapidly growing mycobacteria. J. Antimicrob. Chemother. 2015, 70, 811–817. [CrossRef] [PubMed]
32. Osawa, M.; Erickson, H.P. Turgor pressure and possible constriction mechanisms in bacterial division.
Front. Microbiol. 2018, 9, 111. [CrossRef] [PubMed]
33. Devulapalle, K.S.; de Segura, A.G.; Ferrer, M.; Alcalde, M.; Mooser, G.; Plou, F.J. Effect of carbohydrate fatty
acid esters on Streptococcus sobrinus and glucosyltransferase activity. Carbohydr. Res. 2004, 339, 1029–1034.
[CrossRef] [PubMed]
34. Becerra, N.; Nuez, L.R.D.; Zanocco, A.L.; Lemp, E.; Günther, G. Solubilization of dodac small unilamellar
vesicles by sucrose esters: A fluorescence study. Colloids Surf. A Physicochem. Eng. Asp. 2006, 272, 2–7.
[CrossRef]
35. Palmer, J.; Flint, S.; Brooks, J. Bacterial cell attachment, the beginning of a biofilm. J. Ind. Microbiol. Biotechnol.
2007, 34, 577–588. [CrossRef] [PubMed]

Molecules 2018, 23, 1118
18 of 18
36. Ahimou, F.; Denis, F.A.; Touhami, A.A.; Dufrêne, Y.F. Probing microbial cell surface charges by atomic force
microscopy. Langmuir 2002, 18, 9937–9941. [CrossRef]
37. Girard, L.P.; Ceri, H.; Olson, A.P.M.; Sepandj, F. MIC versus MBEC to determine the antibiotic sensitivity of
Staphylococcus aureus in peritoneal dialysis peritonitis. Perit. Dial. Int. 2010, 30, 652–656. [CrossRef] [PubMed]
Sample Availability: Not available.
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
