Enantio- and Regioselective Heck-Type Reaction of Arylboronic
Acids with 2,3-Dihydrofuran
Liza Penn, Alina Shpruhman, and Dmitri Gelman*
Department of Organic Chemistry, The Hebrew UniVersity of Jerusalem, Jerusalem, 91904 Israel
dgelman@chem.ch.huji.ac.il
ReceiVed January 31, 2007
Reported herein is a protocol for the enantioselective Pd(II)-catalyzed Heck-type reaction between
arylboronic acids and 2,3-dihydrofuran. The highest chemical and optical yields were obtained when a
Pd(OAc)2/(R)-MeO(biphenylphosphine) or a Pd(OAc)2/(R)-(2,2′-bis(diphenylphosphino)-1,1′-binaphthyl)
catalyst and a Cu(OAc)2 reoxidant were employed.
Introduction
extremely prolonged reaction times are normally required to
obtain satisfactory results (up to 9 days in some cases).6 Second,
enantioselectivity erosion is often observed when substrates
other than aryl/vinyl trifluoromethansulfonates (triflates) or
iodides are employed;7 when considering that efficient enan-
tiodifferentiation (at the olefin coordination and migratory
insertion steps) apparently requires a simultaneous coordination
of the palladium center to both the chiral diphosphine and the
prochiral olefin, a partial loss of enantioselectivity is the result
of the competition between cationic and neutral reaction
pathways (Scheme 1).8 As a consequence, the scope of
asymmetric MH reactions is mainly limited to aryl/vinyl triflates
and iodides, which tend to react according to the cationic
mechanism.7,9
Nowadays, the asymmetric palladium-catalyzed Mizoroki-
Heck (MH) reaction is a well-established and powerful method
for the construction of tertiary and quaternary chiral centers.1
Although both the intramolecular and intermolecular transfor-
mations are often used as key strategic steps in the syntheses
of complex polycyclic molecules2 and valuable synthetic
intermediates such as dihydrofurans,3 dihydropyrroles,4 and
cycloalkenes,5 there is still room for further improvements. First,
(1) (a) Shibasaki, M.; Miyazaki, F. In Handbook of Organopalladium
Chemistry for Organic Synthesis; Negishi, E.-i. Ed., John Wiley & Sons:
New Jersey, 2002. (b) Palladium in Organic Synthesis; Tsuji, J. Ed.,
Springer: Heidelberg, Germany, 2005; Vol. 14. (c) Shibasaki, M.; Vogl,
E. M. J. Organomet. Chem. 1999, 1. (d) Dounay, A. B.; Overman, L. E.
Chem. ReV. 2003, 103, 2945.
(2) (a) Ashimori, A.; Matsuura, T.; Overman, L. E.; Poon, D. J. J. Org.
Chem. 1993, 58, 6949. (b) Ashimori, A.; Bachand, B.; Overman, L. E.;
Poon, D. J. J. Am. Chem. Soc. 1998, 120, 6477. (c) Mizutani, T.; Honzawa,
S.; Tosaki, S.-Y.; Shibasaki, M. Angew. Chem., Int. Ed. 2002, 41, 4680.
(d) Enders, D.; Lenzen, A.; Backes, M.; Janeck, C.; Catlin, K.; Lannou,
M.-I.; Runsink, J.; Raabe, G. J. Org. Chem. 2005, 70, 10538. (e) Campos,
K. R.; Journet, M.; Lee, S.; Grabowski, E. J. J.; Tillyer, R. D. J. Org. Chem.
2005, 70, 268. (f) Enders, D.; Lenzen, A.; Raabe, G. Angew. Chem., Int.
Ed. 2005, 44, 3766.
(3) (a) Ozawa, F.; Kubo, A.; Hayashi, T. J. Am. Chem. Soc. 1991, 113,
1417. (b) Ozawa, F.; Kubo, A.; Matsumoto, Y.; Hayashi, T. Organometallics
1993, 12, 4188. (c) Hennessy, A. J.; Connolly, D. J.; Malone, Y. M.; Guiry,
P. J. Tetrahedron Lett. 2000, 41, 7757. (d) Nilsson, P.; Gold, H.; Larhed,
M.; Hallberg, A. Synthesis 2002, 1611. (e) Kilroy, T. G.; Hennessy, A. J.;
Connolly, D. J.; Malone, Y. M.; Farrell, A.; Guiry, P. J. J. Mol. Catal. A
2003, 196, 65. (f) Tu, T.; Deng, W.-P.; Hou, X.-L.; Dai, L.-X.; Dong, X.-
C. Chem.sEur. J. 2003, 9, 3073. (g) Mata, Y.; Dieguez, M.; Pamies, O.;
Claver, C. Org. Lett. 2005, 7, 5597.
(5) (a) Sato, Y.; Sodeoka, M.; Shibasaki, M. J. Org. Chem. 1989, 54,
4738. (b) De la Rosa, J. C.; Diaz, N.; Carretero, J. C. Tetrahedron Lett.
2000, 41, 4107. (c) Gilbertson, S. R.; Fu, Z. Org. Lett. 2001, 3, 161. (d)
Gilbertson, S. R.; Xie, D.; Fu, Z. J. Org. Chem. 2001, 66, 7240.
(6) (a) Ozawa, F.; Kubo, A.; Hayashi, T. Tetrahedron Lett. 1992, 33,
1485. (b) Trabesinger, G.; Albinati, A.; Feiken, N.; Kunz, R. W.; Pregosin,
P. S.; Tschoerner, M. J. Am. Chem. Soc. 1997, 119, 6315.
(7) (a) Samsel, E. G.; Norton, J. R. J. Am. Chem. Soc. 1984, 106, 5505.
(b) Ashimori, A.; Overman, L. E. J. Org. Chem. 1992, 57, 4571.
(8) (a) Amatore, C.; Jutand, A. J. Organomet. Chem. 1999, 254. (b)
Beletskaya, I. P.; Cheprakov, A. V. Chem. ReV. 2000, 100, 3009. (c) Only
several asymmetric Heck-type transformations that are catalyzed by
transition metal complexes bearing monodentate ligands are known. See
for example Imbos, R.; Minnaard, A. J.; Feringa B. L. J. Am. Chem. Soc.
2002, 124, 184.
(9) (a) Karabelas, K.; Westerlund, C.; Hallberg, A. J. Org. Chem. 1985,
50, 3896. (b) Grigg, R.; Loganathan, V.; Santhakumar, V.; Sridharan, V.;
Teasdale, A. Tetrahedron Lett. 1991, 32, 687. (c) Brown, J. M.; Perez-
Torrente, J. J.; Alcock, N. W.; Clase, H. J. Organometallics 1995, 14, 207.
(4) Tu T.; Hou X.-L.; Dai L.-X. Org. Lett. 2003, 5, 3651.
10.1021/jo070170v CCC: $37.00 © 2007 American Chemical Society
Published on Web 04/10/2007
J. Org. Chem. 2007, 72, 3875-3879
3875

Penn et al.
from an independent report by Mikami.15 Mikami and co-
workers demonstrated for the first time that an enantioselective
Pd(II)/Chiraphos-catalyzed organoboron-mediated Heck-type
reaction is, indeed, possible. Unfortunately, the reported trans-
formation was limited to 4-trifluorometyl-phenylboronic acid
and alkyl 1-cyclopentene-1-carboxylates.
SCHEME 1. Cationic vs Neutral Pathway in an
