Transition Met Chem (2011) 36:819–827
821
Preparation of complex 1
compositions are [Cu(babb)(pic)2]ꢀH2O, and [Co(babb)2]-
(pic)2. The electrolytic conductivity of complex 2 shows
that it is 1:2 electrolyte in DMF [33]. In theory, complex 1 is
neutral, but the conductivity shows that it is a 1:1 electrolyte
in DMF, which may be attributed to partial ionization of the
discrete [Cu(babb)(pic)2] in the DMF.
To a stirred solution of babb (223.5 mg, 0.25 mmol) in hot
EtOH (10 mL) was added Cu(pic)2 (129.94 mg, 0.50 mmol)
in EtOH (2 mL). A yellow crystalline product formed
rapidly. The precipitate was filtered off, washed with EtOH
and absolute Et2O, and dried under vacuum. The crude
product was dissolved in MeCN to form a yellow solution
into which Et2O was allowed to diffuse at room tempera-
ture. Yellow crystals of 1 suitable for X-ray measurement
were obtained after several weeks. Yield: 160.5 mg (64%).
Found (%): C, 49.9; H, 3.5; N, 15.6. Calcd. (%) for
C41H35CuN11O15: C, 49.7; H, 3.7; N, 15.5. Km(DMF,
297 K): 77.9 S cm2 mol-1. UV–vis (k, nm): 275, 280, 381.
FTIR (KBr m/cm-1): 746, m(o–Ar); 1,269, m(C–N); 1,363,
m(O–N–O); 1,481, m(C=N), 1,635, m(C=C) [30].
The IR spectra of the two complexes are closely related to
that of the free ligand babb. One of the most diagnostic
changes occurs in the region between 1,650 and 1,250 cm-1
.
The spectrum of free babb shows a strong band at
1,462 cm-1 and weak bands at 1,643 and 1,408 cm-1
,
attributable to the m(C=N) and m(C=C) frequencies of the
benzimidazole group [34–37], respectively. The location of
these two bands was slightly shifted for both complexes; the
band at 1,462 cm-1 is shifted to 1,481 and 1,483 cm-1 for
complexes, respectively, which implies direct coordination
of all four imine nitrogen atoms to the central metal atom
[38]. Information regarding the possible bonding modes of
the picrate and benzimidazole rings may also be obtained
from the IR spectra [39].
Preparation of complex 2
Complex 2 was prepared by a similar procedure as for com-
plex 1, using Co(pic)2 instead of Cu(pic)2. Yield: 250.3 mg
(63%). Found (%): C, 70.1; H, 6.2; N, 14.3 Calcd. (%) for C70
H62 Co N16 O14: C, 70.3; H, 6.3; N, 14.1. Km(DMF, 297 K):
133.04 S cm2 mol-1. UV–vis (k, nm): 281, 381. FTIR (KBr m/
cm-1): 746, m(o–Ar); 1,269, m(C–N); 1,366, m(O–N–O);
1,483 cm-1, m(C=N), 1,633 cm-1, m(C=C) [30].
DMF solutions of the ligand and its complexes show,
as expected, almost identical UV spectra. The UV bands
of the free ligand (286, 279 nm) are only marginally red-
shifted (5–6 nm) for complex 1, which is evidence of C=N
coordination to the metal center. These bands are assigned
to p ? p* (imidazole) transitions [12]. Conversely, the
bands are marginally blue-shifted (5–6 nm) for complex 2,
this phenomenon also shows that C=N is involved in
coordination to the metal center [40]. The picrate bands
(observed at 381 nm both complexes) are assigned to
n ? p* and p ? p* transitions [11].
X-ray crystallography
A suitablesingle crystal was mounted on a glass fiber, and the
intensity data were collected on a Bruker Smart CCD dif-
fractometer with graphite-monochromated Mo–Ka radiation
˚
(k = 0.71073 A) at 296 K. Data reduction and cell refine-
X-ray structures of the complexes
ment were performed using the SMART and SAINT pro-
grams [31]. The structure was solved by direct methods and
refined by full-matrix least-squares against F2 of data using
SHELXTL software [32]. All H atoms were found in dif-
ference electron maps and subsequently refined in a riding-
model approximation with C–H distances ranging from 0.93
The crystal structure of complex 1 consists of discrete
[Cu(babb)(pic)2] and solvent water molecules. The solvent
water molecules are present in the crystal lattice, but have
no direct interactions with the [Cu(babb)(pic)2]. The OR-
TEP structure (30% probability ellipsoids) of [Cu(babb)-
(pic)2] with atom numberings is shown in Fig. 1.
˚
to 0.97 A and Uiso(H) = 1.2 Ueq(C). Basic crystal data,
description of the diffraction experiment, and details of the
structure refinement are given in Table 1. Selected bond
distances and angles are presented in Table 2.
The central copper(II) atom is six-coordinate with a
CuN3O3 environment. The ligand acts as a tridentate
N-donor, with the remaining coordination sites occupied by
three O atoms from two picrates. The coordination geom-
etry of the Cu(II) may be best described as distorted
octahedral with (O1, O2, O8, N1) providing the equatorial
plane. The maximum deviation distance (N1) from the
least-squares plane calculated from the four coordination
Results and discussion
Characterization and structures of the complexes
˚
atom atoms is 0.19 A, indicating that those atoms are
The two complexes are soluble in DMF, DMSO, and ace-
tonitrile, but insoluble in water and other organic solvents,
such as methanol, ethanol, petroleum ether, trichlorome-
thane, etc. The elemental analyses show that their
almost in a plane. The average bond length between the
copper and the apical nitrogen atoms (N3, N5) is 1.975(3)
˚
˚
A, which is about 0.247 A shorter than the bond average
length between the copper and the four coordinated
