Oxide-ion-conducting phases in the Bi2MoO6-Bi 2VO5.5 system

Article abstract of DOI:10.1134/S0020168506110148

In search of new oxide-ion-conducting phases, we have synthesized a series of Bi₂V_1-x Mo _x O_5.5+x/2 ceramic samples, in which the end-members Bi₂VO_5.5 (x = 0) and Bi₂MoO₆ (x = 1) are single-layer Aurivillius phases, possess ferroelectric properties, and offer high oxide-ion conductivity. We have determined the phase composition of the samples and have investigated their electrical properties. The results indicate the formation of narrow ranges of Bi₂VO_5.5-and Bi₂MoO₆-based solid solutions (0 < x ≤ 0.1 and 0.9 ≤ x < 1, respectively). In the composition range 0.2 ≤ x ≤ 0.8, the samples consist of Bi ₂VO_5.5-or Bi₂MoO₆-based solid solutions and compounds isostructural with BiVO₄ and Bi ₆Mo₂O₁₅. Molybdenum doping stabilizes the orthorhombic phase β-Bi₂VO_5.5 to room temperature, but the solid solutions differ little in electric conductivity from Bi ₂VO_5.5. The conductivity of the Bi₂MoO ₆-based solid solutions is higher than that of undoped bismuth molybdate by about a factor of 3.

Full text of DOI:10.1134/S0020168506110148

ISSN 0020-1685, Inorganic Materials, 2006, Vol. 42, No. 11, pp. 1255–1259. © Pleiades Publishing, Inc., 2006.
Original Russian Text © V.I. Voronkova, E.P. Kharitonova, O.G. Rudnitskaya, 2006, published in Neorganicheskie Materialy, 2006, Vol. 42, No. 11, pp. 1374–1378.
Oxide-Ion-Conducting Phases
in the Bi2MoO6–Bi2VO5.5 System
V. I. Voronkova, E. P. Kharitonova, and O. G. Rudnitskaya
Moscow State University, Vorob’evy gory 1, Moscow, 119992 Russia
e-mail: voronk@polly.phys.msu.ru
Received October 24, 2005; in final form, April 27, 2006
Abstract—In search of new oxide-ion-conducting phases, we have synthesized
a series of
Bi2V1 − xMoxO5.5 + x/2 ceramic samples, in which the end-members Bi2VO5.5 (x = 0) and Bi2MoO6 (x = 1) are
single-layer Aurivillius phases, possess ferroelectric properties, and offer high oxide-ion conductivity. We have
determined the phase composition of the samples and have investigated their electrical properties. The results
indicate the formation of narrow ranges of Bi2VO5.5- and Bi2MoO6-based solid solutions (0 < x ≤ 0.1 and
0.9 ≤ x < 1, respectively). In the composition range 0.2 ≤ x ≤ 0.8, the samples consist of Bi2VO5.5- or Bi2MoO6-
based solid solutions and compounds isostructural with BiVO4 and Bi6Mo2O15. Molybdenum doping stabilizes
the orthorhombic phase β-Bi2VO5.5 to room temperature, but the solid solutions differ little in electric conduc-
tivity from Bi2VO5.5. The conductivity of the Bi2MoO6-based solid solutions is higher than that of undoped bis-
muth molybdate by about a factor of 3.
DOI: 10.1134/S0020168506110148
INTRODUCTION
lius phases. Note that studies of oxide-ion-conducting
phases in the similar system Bi2WO6–Bi2VO5.5
revealed limited series of solid solutions which had a
substantially higher conductivity in comparison with
the end-members [9].
The compounds Bi2MoO6 (BM) and Bi2VO5.5 (BV)
belong to the large family of layered bismuth-contain-
ing perovskite-related compounds (Aurivillius phases)
in which the perovskite slab consists of only one octa-
hedral layer. The Aurivillius phases are ferroelectric
superionics with a high oxide-ion conductivity and are
potentially attractive as solid electrolytes for advanced
power sources [1]. Both Bi2MoO6 and Bi2VO5.5 exhibit
complex polymorphism. At 604°C, bismuth molybdate
undergoes an irreversible phase transition from a low-
temperature, polar orthorhombic phase (γ), which has
an Aurivillius structure, to a tetragonal phase (γ'') and
then to a high-temperature, nonpolar monoclinic phase
(γ'), which does not have a layered perovskite-like
structure [2]. Bismuth vanadate has recently attracted a
great deal of attention owing to its high oxide-ion con-
ductivity [3], which attains 0.1 S/cm at 550°C. Bismuth
vanadate undergoes two phase transitions, at 440 and
570°C, associated with a ferroelectric transition from a
monoclinic polar phase (α) to an orthorhombic nonpo-
lar phase (β) and from the β phase to a tetragonal phase
(γ), also nonpolar [4, 5]. The high-temperature, γ phase
offers high conductivity and can be stabilized to room
temperature by doping with transition metals, resulting
in the formation of the large BIMEVOX family of
oxide-ion conductors [6].As shown byVannier et al. [7]
and Thery et al. [8], molybdenum substitution for up to
The objective of this work was to synthesize Auriv-
illius phases in the Bi2MoO6–Bi2VO5.5 system with the
aim of extending the range of oxide-ion conductors and
to investigate their electrical properties.
EXPERIMENTAL
We prepared two batches of ceramic samples with
nominal compositions of Bi2V1 – xMoxO5.5 + x/2 by solid-
state reactions in appropriate mixtures of extrapure-
grade Bi2O3, MoO3, and V2O5 at 800 and 500°C. Two
firing temperatures were used because the Aurivillius
phase of Bi2VO5.5 requires higher synthesis tempera-
tures (on the order of 800°C) than that of Bi2MoO6,
which exists, as mentioned above, only below 604°C.
This restricts the firing temperature of BM-rich compo-
sitions.
In the first batch, x was varied from 0 to 1 in
0.1 steps. The samples were fired first at 600 and then
at 800°C, with intermediate grinding and pressing at
0.1 GPa. After synthesis, the samples were quenched to
room temperature. At 800°C, equilibration took 3 days,
as checked by x-ray diffraction (XRD). To obtain
20% of the vanadium leads to the formation of Aurivil- orthorhombic BM (γ phase) with a layered structure,
1255

1256
VORONKOVA et al.
BiVO4
*
Bi6Mo2O15
x = 0
α
α
x = 0.1
x = 0.2
β
*
*
*
*
x = 0.5
x = 0.8
*
*
*
*
*
*
*
x = 0.9
x = 1.0
10
20
30
40
50
60
2θ, deg
Fig. 1. XRD patterns of Bi V
Mo O
samples synthesized at 800°C (batch I); α and β mark superlattice reflections from
5.5 + x/2
2
1 – x
x
α-BV and β-BV, respectively; also shown are fundamental reflections from additional phases isostructural with BiVO and
4
Bi Mo O .
6
2 15
we prepared a second batch of samples, with x varied
from 0.5 to 1 in 0.1 steps, by firing at 500°C, followed
by quenching. At this temperature, equilibration
required 6 days.
XRD patterns were collected at room temperature
on Rigaku D-max/RC and DRON-2.0 diffractometers
(CuKα radiation). Temperature-dependent electrical
conductivity and dielectric permittivity were measured
INORGANIC MATERIALS Vol. 42 No. 11 2006

OXIDE-ION-CONDUCTING PHASES IN THE Bi2MoO6–Bi2VO5.5 SYSTEM
1257
x = 1.0
x = 0.9
x = 0.8
*
*
*
* *
30
*
20
40
50
60
2θ, deg
Fig. 2. XRD patterns of Bi V
tional phases.
Mo O
samples synthesized at 500°C (batch II); the asterisks mark reflections from addi-
2
1 – x
x
5.5 + x/2
at 1 MHz from 30 to 750°C using a Tesla BM 431E tively) decreases. Solid solutions based on the mono-
bridge and samples with platinum (batch I) or silver clinic phase γ'-Çå exist in the range 0.9 ≤ x < 1. At
(batch II) electrodes.
intermediate Mo contents, 0.2 ≤ x ≤ 0.8, two additional
RESULTS AND DISCUSSION
Figures 1 and 2 show XRD patterns of batch I and II
BM–BV samples, synthesized at 800 and 500°C,
respectively. As seen in Fig. 1, there is a limited series
of BV-based solid solutions in the range 0 < x ≤ 0.1. The
solid-solution range is narrower than that reported ear-
lier [7, 8]. At room temperature, the x = 0.1 solid solu-
tion is isostructural with the orthorhombic phase β-BV,
as evidenced by the presence of the characteristic
superlattice reflection at 2θ = 25° in its XRD pattern
[4, 5]. Increasing the molybdenum content within the
solid-solution range reduces the lattice parameter a of
the solid solutions from 5.597 to 5.594 Å and increases
the c parameter from 15.396 to 15.433 Å. Concurrently,
the orthorhombic distortion (020 + 200, 024 + 204, and
133 + 313 doublets at 2θ ꢀ 32°, 40°, and 55°, respec-
Solid solutions
based on Bi2VO5.5
BiVO4,
Solid solutions
based on Bi2MoO6,
BiVO4, and
,
and Bi6Mo2O15
Bi Mo2O15
6
0
0.2
0.4
0.6
0.8
1.0
Bi2VO5.5
x
Bi2MoO6
Fig. 3. Composition stability ranges of phases in the
Bi V Mo O system.
2
1 − x
x 5.5 + x/2
INORGANIC MATERIALS Vol. 42 No. 11 2006

1258
VORONKOVA et al.
ε
–3.0
300
–3.5
–4.0
–4.5
200
100
2
1
2
–5.0
–5.5
1
10
15
20
25
104/T, K–1
0
200
400
600
800
t, °C
Fig. 5. Arrhenius plots of conductivity for (1) Bi MoO and
Fig. 4. Dielectric permittivity as a function of temperature
2
6
for (1) Bi MoO and (2) Bi V Mo
O
.
(2) Bi V Mo O
.
2
6
2
0.1
0.9 5.95
2
0.1
0.9 5.95
ε
1400
2
1
1200
1000
800
–1
–2
–3
–4
600
400
1
2
200
10
15
20
25
104/T, K–1
0
100
200
300
400
500
t, °C
Fig. 7. Arrhenius plots of conductivity for (1) Bi VO and
Fig. 6. Dielectric permittivity as a function of temperature
for (1) Bi VO and (2) Bi V Mo
2
5.5
O
.
(2) Bi V Mo
O
.
2
5.5
2
0.9
0.1 5.55
2
0.9
0.1 5.55
phases emerge, isostructural with BiVO4 and
Bi6Mo2O15 [10, 11]. Figure 3 shows the composition
stability ranges of the phases present in the samples
synthesized at 800°C (batch I). In the samples with
0.5 ≤ x ≤ 1.0 synthesized at 500°C (batch II), the Auriv-
illius phase based on the orthorhombic phase γ-Çå
exists in the range 0.9 ≤ x ≤ 1. The lattice parameters of
Figures 4 and 5 present the temperature depen-
dences of dielectric permittivity and electrical conduc-
tivity for bismuth molybdate and Bi2V0.1Mo0.9O5.95
,
isostructural with the orthorhombic phase of BM (syn-
thesis at 500°C). At ꢀ600°ë, the curves show strong
anomalies due to the ferroelectric phase transition from
the orthorhombic phase γ-BM to the monoclinic phase
the solid solutions depend very little on vanadium γ'-BM. Vanadium doping reduces the transition temper-
content.
ature by 20°C and increases the conductivity by a factor
INORGANIC MATERIALS Vol. 42 No. 11 2006

OXIDE-ION-CONDUCTING PHASES IN THE Bi2MoO6–Bi2VO5.5 SYSTEM
1259
of about 3 over the entire temperature range studied, up
REFERENCES
to 10–3 S/cm at 550°C. Dielectric permittivity also
1. Kharton, V.V., Marques, F.M.B., and Atkinson, A.,
Transport Properties of Solid Oxide Electrolyte Ceram-
ics: A Brief Review, Solid State Ionics, 2004, vol. 187,
nos. 1–4, pp. 135–149.
increases on doping.
Figure 6 shows the temperature dependence of
dielectric permittivity for bismuth vanadate and the
Bi2V0.9Mo0.1O5.55 solid solution. The introduction of
2. Watanabe, A. and Kodama, H., Polymorphic Transfor-
mation of Bi2MoO6, J. Solid State Chem., 1980, vol. 35,
pp. 240–245.
Mo suppresses the α
β ferroelectric phase transi-
tion, in accordance with XRD data, which demonstrate
that, at room temperature, this solid solution is isostruc-
tural with the paraelectric phase β-BV. The Arrhenius
plots of conductivity for these samples are displayed in
Fig. 7. The plot for undoped BV shows well-defined
jumps in conductivity near 420 and 550°C, due to the
3. Abraham, F., Boivin, J.C., Mairesse, G., and Nowo-
grocki, G., The BIMEVOX Series: A New Family of
High Performances Oxide Ion Conductors, Solid State
Ionics, 1990, vols. 40–41, pp. 934–937.
4. Mairesse, G., Roussel, P., Vannier, R.N., et al., Crystal
Structure Determination of α, β, and γ-Bi4V2O11 Poly-
morphs. Part I: γ and β-Bi4V2O11, Solid State Sci., 2003,
vol. 5, no. 6, pp. 851–859.
α
β and β
γ phase transitions. The plot for the
solid solution shows only one jump, at ꢀ550°ë, due to
the β
γ phase transition. Below 300°C, the conduc-
tivity of Bi2V0.9Mo0.1O5.55 is slightly lower; at higher
temperatures, it approaches the conductivity of the
undoped sample.
5. Mairesse, G., Roussel, P., Vannier, R.N., et al., Crystal
Structure Determination of α-, β-, and γ-Bi4V2O11 Poly-
morphs. Part II: Crystal Structure of α-Bi4V2O11, Solid
State Sci., 2003, vol. 5, no. 6, pp. 861–869.
CONCLUSIONS
6. Boivin, J.C. and Mairesse, G., Recent Material Develop-
ments in Fast Oxide Ion Conductors, Chem. Mater.,
1998, vol. 10, pp. 2870–2888.
The Bi2MoO6–Bi2VO5.5 system contains limited
Bi2V1 – xMoxO5.5 + x/2 solid solutions with Aurivillius
structures, based on BV in the composition range 0 <
x ≤ 0.1 and based on BM in the range 0.9 ≤ x < 1, even
though the end-members are isostructural with one
another. In the composition range 0.2 ≤ x ≤ 0.8, we
identified two additional phases, isostructural with
BiVO4 and Bi6Mo2O15. At room temperature, the
Bi2V0.9Mo0.1O5.55 solid solution is isostructural with the
orthorhombic phase β-BV, which is only stable
between 440 and 570°C. Molybdenum doping has little
effect on the electrical conductivity of the BV-based
solid solutions, whereas the conductivity of the BM-
based solid solutions is higher than that of undoped bis-
muth molybdate by about a factor of 3.
7. Vannier, R.N., Mairesse, G., Abraham, F., and Nowo-
grocki, G., Incommensurate Superlattice in Mo-Substi-
tuted Bi4V2O11, Solid State Chem., 1993, vol. 103,
pp. 441–446.
8. Thery, O., Vannier, R.N., Dion, C., and Abraham, F.,
Preparation, Characterization, and Oxide Ion Conductiv-
ity in U-Substituted Bi4V2O11, Solid State Ionics, 1996,
vol. 90, pp. 105–110.
9. Voronkova, V.I., Yanovskii, V.K., Kharitonova, E.P., and
Rudnitskaya, O.G., Superionic Conductors in the
Bi2WO6–Bi2VO5.5 System, Neorg. Mater., 2005, vol. 41,
no. 7, pp. 866–870 [Inorg. Mater. (Engl. Transl.), vol. 41,
no. 7, pp. 760–765].
10. Powder Diffraction File, Newtown Square: ICDD, 2001,
ACKNOWLEDGMENTS
no. 14-0688.
This work was supported by the Russian Foundation
for Basic Research, grant no. 04-03-32432.
11. Powder Diffraction File, Newtown Square: ICDD, 2001,
no. 26-0216.
INORGANIC MATERIALS Vol. 42 No. 11 2006
