Molecules 2015, 20, 10866-10872; doi:10.3390/molecules200610866
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Communication
Selenium-Mediated Synthesis of Tetrasubstituted Naphthalenes
through Rearrangement
James Tancock and Thomas Wirth *
School of Chemistry, Cardiff University, Cardiff CF10 3AT, UK; E-Mail: tancockJ@cardiff.ac.uk
* Author to whom correspondence should be addressed; E-Mail: wirth@cf.ac.uk;
Tel./Fax: +44-2920-876968.
Academic Editor: Thomas G. Back
Received: 11 May 2015 / Accepted: 11 June 2015 / Published: 12 June 2015
Abstract: New β-keto ester substituted stilbene derivatives have been synthesized and
cyclized with selenium electrophiles in the presence of Lewis acids. This now allows access
to 1,2,3,4-tetrasubstituted naphthalene derivatives as cyclization and rearrangement products.
Keywords: naphthols; rearrangement; selenium
1. Introduction
Organoselenium chemistry and selenium-containing reagents allow nucleophilic, electrophilic as well
as radical reactions, which have been investigated intensively for the last decades. The formation of
new bonds through the selenium-mediated addition to double bonds has become a key reaction for
electrophilic selenium reagents and we have reported on many facets of these transformations [1,2].
Apart from heteroatom nucleophiles used in selenenylation reactions of alkenes, we have reported
carboselenenylations leading to dihydronaphthalenes and benzofluorene derivatives [3].
2. Results and Discussion
Herein we expand on a recently reported reaction sequence of carboselenenylation and elimination,
which is accompanied with a 1,2-rearrangement of an aryl group under very mild reaction conditions [4].
We had shown that the treatment of -keto esters of type 1 with phenyl selenenylchloride in the presence
of iron(III)chloride leads in high yields to the cyclization products 2, which were the result of a sequence
of carboselenenylation, 1,2-migration of the aryl substituent and elimination (Scheme 1).

Molecules 2015, 20
10867
O
O
OH O
2 equiv PhSeCl
1.1 equiv FeCl3
OEt
OEt
CH2Cl2, –78 ºC
Ar
Ar
1
2
Scheme 1. Synthesis of naphthols 2 from -keto esters 1.
There have been many natural chemicals discovered that contain a naphthalene ring in their structure. In
some instances, these natural products have some biological activity. We were therefore interested to extend
the above mentioned reaction sequence towards the synthesis of 1,2,3,4-tetrasubstituted naphthol derivatives.
Other reactions leading to 1,2,3,4-tetrasubstituted naphthol derivatives have been described recently [5].
In order to use the reaction sequence shown in Scheme 1 for the synthesis of 1,2,3,4-tetrasubstituted
naphthol derivatives, modified starting materials had to be synthesized. This was achieved by the reactions
sequence shown in Scheme 2.
CO2Me
CO2H
Ph
Ph
CO2Me
I
Pd(OAc)2, PPh3
LiOH
84%
69%
Ph
3
4
5
O
O
1. carbonyldiimidazole
2. KO2C-CH2-CO2Et
OEt
59%
Ph
6
Scheme 2. Synthesis of starting material 6.
Firstly, the Mizoroki-Heck cross coupling of methyl 2-iodobenzoate 3 with α-methyl styrene afforded
the stilbene ester 4 in good yields. The palladium-catalyzed reaction produced exclusively only one
geometric isomer, as evidenced by 1H-NMR. The ester 4 was then hydrolyzed into its carboxylic acid
derivative 5 using three equivalents of lithium hydroxide. Typically a hydrolysis of an ester using this
method proceeds almost quantitatively, however in this instance 84% was the greatest yield which could
be achieved. The carboxylic acid 5 was then activated using carbonyldiimidazole (CDI) in order for its
conversion to the β-keto ester. After stirring the carboxylic acid 5 overnight with CDI, the transformation
into stilbene 6 required the addition of potassium ethyl malonate along with MgCl2 and NEt3. After stirring
overnight once more, stilbene ester 6 was isolated in an acceptable yield (59%). NMR investigations of 6
showed it was in equilibrium with its enol tautomer, this equilibrium was shifted towards the keto form.
Different selenium electrophiles have been investigated for the carboselenenylation of 6 to 7. The
different reagents and reaction conditions are shown in Table 1.

Molecules 2015, 20
10868
Table 1. Conditions for cyclization of 6 to 7.
Entry
Reagents
PhSeSePh, FeCl3
PhSeSePh, FeCl3
PhSeOTf
Conditions
−78 °C, 1.5 h
25 °C, 1.5 h
7 Yield
traces
7%
1
2
3
4
5
6
−78 °C, 3 h
10%
40%
61%
96%
PhSeCl, FeCl3
PhSeCl, FeCl3
PhSeCl, FeCl3
−78 °C, 3 h
−78 °C, 12 h
−60  25 °C, 5 h
It is clear from these data that the diphenyl diselenide is not electrophilic enough to add across the
stilbene double bond to any great extent (Table 1, entries 1 and 2). Phenylselenenyl bromide and silver
triflate can be used to form the phenylselenenyl triflate in situ. But even this reagent did not lead to
substantial amounts of the cyclization product. Only the reagent combination of phenylselenenyl
chloride and iron(III) chloride could be optimized successfully and finally provided product 7 in almost
quantitative yield (Table 1, entry 6).
Attempts were also made to isolate dihydronaphthalene 8 by carrying out the carbocyclization
procedure at −78 °C and using only one equivalent of phenylselenenyl chloride. However, an isolation
of 8 via preparative TLC was not successful. The phenylselenenyl and the phenyl substituent in 8 are
trans-oriented due to the E-double bond geometry of 6. We have already established such a relationship
in related reactions where starting materials with a Z-double bond configuration would not react due to
the steric interactions in the cyclization intermediate [6]. As already stated, when carrying out the
carbocyclization of stilbene 6, naphthol derivative 7 was obtained as the only product as shown in
Scheme 3. Compound 12 was not observed. Therefore, the migration of the phenyl ring is the exclusive
process occurring during the reaction. In order to quantify this, the relative energies of carbocations 9,
10, and 11 were calculated. The calculations were performed using the Gaussian 03 software package [7].
Geometries were optimized separately for all structures and the energies were calculated using the
B3LYP/6-31G (d) level of theory. Solvent effects were considered using the PCM solvent model
available through Gaussian. Intermediates 10 and 11 were both more stable than 9, by 17.37 and
18.96 kcal·mol−1, respectively. Intermediate 10 had a net stabilization of 1.59 kcal·mol−1 over 11.
Considering the carbocations 10 and 11 in their protonated ketone resonance forms, the calculations on
those resonance structures led to the same conclusion. The resonance structure of 10 was 1.50 kcal·mol−1
lower in energy that that of 11. These protonated ketone forms may be a better representation of the
intermediates because usual logic would predict 11 being the more stable of the two with the positive
charge located in a benzylic position. The phenyl substituent could also stabilize the positive charge
through the formation of a phenonium intermediate. We had proposed such intermediates in previous
rearrangements [8], but in this case the calculation of a phenonium ion intermediate was unsuccessful.

Molecules 2015, 20
10869
O
OH
Ph
CO2Et
PhSeCl, FeCl3
CO2Et
7
Ph
6
OH
CO2Et
10
11
OH
OH
CO2Et
Ph
CO2Et
Ph
Ph
OH
SePh
CO2Et
Ph
8
9
OH
CO2Et
Ph
12
Scheme 3. Cyclization and rearrangement of -ketoester 6 to naphthol derivative 7.
The structural analysis of 7 was carried out to determine the position of both, the phenyl and methyl
1
13
groups. H- and C-NMR spectra are in agreement with the literature values [5]. High resolution mass
data also support the formation of the cyclic product. However, to unambiguously determine the positions
of the substituents, it was required to analyze the crystals of 7 using single crystal X-ray diffraction. As
it can be seen below (Figure 1), this analysis proved that the phenyl group migrated to the 4 position instead
of the methyl group, in line with the assumption made according to the previous findings.
Figure 1. Single crystal X-ray structure of 7 [9].

Molecules 2015, 20
10870
3. Experimental Section
Methyl (E)-2-(2-phenylprop-1-en-1-yl)benzoate (4) [10]. A mixture of methyl 2-iodobenzoate (15 mmol,
4.0 g), α-methylstyrene (18 mmol, 2.3 mL), triethylamine (32 mmol, 4.4 mL), palladium acetate
(0.48 mmol, 323 mg) and triphenylphosphine (0.96 mmol, 251 mg) were added to a round bottom
flask and heated under reflux at 120 °C for 5 h. After cooling, 10% aq. HCl (100 mL) was added slowly
with stirring. The resulting mixture was extracted with ethyl acetate. The organic layers were collected and
concentrated under vacuum. The crude product was purified by column chromatography (EtOAc:hexane,
1:12) to give the product 4 as yellow oil (2.61 g, 10.35 mmol) in 69% yield. 1H-NMR (300 MHz, CDCl3):
δ = 8.00 (d, J = 7.9 Hz, 2H), 7.81 (dd, J = 7.8, 1.7 Hz, 1H), 7.63–7.58 (m, 2H), 7.40–7.35 (m, 3H),
7.33–7.29 (m, 2H), 3.94 (s, 3H), 2.11 (d, J = 1.3 Hz, 3H) ppm.
(E)-2-(2-Phenylprop-1-en-1-yl)benzoic acid (5) [11]. Stilbene 4 (12.5 mmol, 3.0 g) was dissolved in a
90 mL solution of THF:MeOH:H2O (4:1:1). LiOH was added at room temperature with stirring. The
reaction was heated for 12 hours at 70 °C. The reaction was cooled with ice and neutralized with a 1 M HCl
solution. The solvents were removed under vacuum and the organic products taken up in EtOAc, then washed
with water and brine. The crude product was then recrystallized in ethanol to give the clean product 5 as
colorless crystals in 84% yield (10.5 mmol, 2.49 g). 1H-NMR (300 MHz, CDCl3): δ = 8.06 (d, J = 8.0 Hz,
2H), 8.01 (dd, J = 7.8, 1.6 Hz, 1H), 7.62–7.57 (m, 2H), 7.44–7.37 (m, 3H), 7.32 (d, J = 2.8 Hz, 2H), 2.13
(d, J = 1.3 Hz, 3H) ppm. HRMS (NSI): m/z [M – H] calcd. for C16H13O2: 237.0921; found: 237.0916.
Ethyl (E)-3-oxo-3-(2-(2-phenylprop-1-en-1-yl)phenyl)propanoate (6)
Step A: A solution of stilbene carboxylic acid 5 (4.17 mmol, 994 mg) and 1,1′-carbonyldiimidazole
(6.67 mmol, 1.08 g) in dry THF (15 mL) was stirred at room temperature for 12 h.
Step B: To a suspension of potassium ethyl malonate (8.34 mmol, 1.42 g), dry acetonitrile (25 mL)
and triethylamine (2.1 mL), magnesium chloride (12.5 mmol, 1.19 g) was added while maintaining the
temperature at 20 °C. The reaction mixture was stirred at room temperature for 4 h and then cooled in
an ice bath. The solution from step A was added slowly and the resulting mixture was stirred for 12 h.
The solvent was removed under vacuum, the residue was taken up in toluene (20 mL), cooled in an ice
bath, and aqueous HCl (12%, 10 mL) was slowly added. The mixture was extracted with ethyl acetate.
The combined organic layers were washed with aqueous NaHCO3, brine, dried over MgSO4, filtered and
then the solvent was removed under vacuum. The crude product was purified by column chromatography
(EtOAc:hexane, 1:12) to give product 6 as an orange oil in 59% yield (2.46 mmol, 760 mg). 1H-NMR
(250 MHz, CDCl3): δ = 8.00–7.30 (m, 10H), 7.12 (s, 0.4H), 5.43 (s, 0.6H), 4.30–4.09 (m, 2H), 2.12
(s, 1.8H), 2.08 (s, 1.2H), 1.37–1.15 (m, 3H) ppm. HRMS (NSI): m/z [M + H]+ calcd. for C20H21O3:
309.1485; found: 309.1487.
Ethyl 1-hydroxy-3-methyl-4-phenyl-2-naphthoate (7). β-Keto ester 6 (0.065 mmol, 20 mg) and FeCl3
(0.071 mmol, 11 mg) were dissolved in dry CH2Cl2 (3 mL) under argon at −60 °C and stirred for 5 min.
Phenylselenenyl chloride (0.139 mmol, 43 mg) was added to the reaction mixture and stirred while the
flask warmed to room temperature; the reaction was then left stirring for 5 h. The mixture was then
poured in cold water, extracted with CH2Cl2 and washed with water. The combined organic layers were

Molecules 2015, 20
10871
dried with MgSO4, filtered and concentrated under vacuum. The crude product was purified by preparative
TLC (toluene:hexane, 3:2) to give the pure product 7 as a colorless solid in 96% yield (0.062 mmol,
1
19 mg). H-NMR (400 MHz, CDCl3): δ = 12.59 (s, 1H, OH), 8.46–8.42 (m, 1H), 7.51–7.40 (m, 5H),
13
7.23–7.16 (m, 3H), 4.49 (q, J = 7.1 Hz, 2H), 2.35 (s, 3H), 1.44 (t, J = 7.1 Hz, 3H) ppm. C-NMR
(75 MHz, CDCl3): δ = 172.9, 161.3, 140.3, 136.0, 132.3, 131.3, 131.0, 129.5, 128.6, 127.1, 126.3,
124.9, 123.9, 123.5, 107.1, 61.9, 21.5, 14.4 ppm. HRMS (NSI): m/z [M + H]+ calcd. for C20H19O3:
307.1329; found: 307.1332.
4. Conclusions
We have demonstrated the successful carbocyclization of a new stilbene derivative using electrophilic
selenium reagents in the presence of Lewis acid, to afford the corresponding tetrasubstituted naphthalene
derivative in excellent yields. The desired product is obtained through a 6-endo cyclization, phenylselenium
elimination and a 1,2-rearrangement of the phenyl moiety. Although there was the chemical possibility
for an alternative rearrangement, the phenyl migration was the only migration observed. The reaction
proceeded under very mild reaction conditions and with complete selectivity for the 6-endo cyclization.
Acknowledgments
Support from the School of Chemistry, Cardiff University is gratefully acknowledged. We thank the
EPSRC National Mass Spectrometry Facility, Swansea, for mass spectrometric data and B. Kariuki,
Cardiff University, for the X-ray analysis of 7.
Conflicts of Interest
The authors declare no conflict of interest.
References and Notes
1. Freudendahl, D.M.; Shahzad, S.A.; Wirth, T. Recent Advances in Organoselenium Chemistry.
Eur. J. Org. Chem. 2009, 2009, 1649–1664.
2. Wirth, T.; (Ed.) Organoselenium Chemistry: Novel Developments in Synthesis, Catalysis and
Biochemistry; Wiley VCH: Weinheim, Germany, 2011.
3. Shahzad, S.A.; Wirth, T. Fast Synthesis of Benzofluorenes by Selenium-Mediated
Carbocyclizations. Angew. Chem. Int. Ed. 2009, 48, 2588–2591.
4. Shahzad, S.A; Vivant, C.; Wirth, T. Selenium-Mediated Synthesis of Biaryls through Rearrangement.
Org. Lett. 2010, 12, 1364–1367.
5. Jiang, H.; Cheng, Y.; Zhang, Y.; Yu, S. De Novo Synthesis of Polysubstituted Naphthols and
Furans Using Photoredox Neutral Coupling of Alkynes with 2-Bromo-1,3-dicarbonyl Compounds.
Org. Lett. 2013, 15, 4884–4887.
6. Singh, F.V.; Rehbein, J.; Wirth, T. Facile Oxidative Rearrangements Using Hypervalent Iodine
Reagents. ChemistryOpen 2012, 1, 245–250.
7. Gaussian 03, version B.04; Gaussian, Inc.: Wallingford, CT, USA, 2004.

Molecules 2015, 20
10872
8. Boye, A.C.; Meyer, D.; Ingison, C.K.; French, A.N.; Wirth, T. Novel Lactonization with Phenonium
Ion Participation Induced by Hypervalent Iodine Reagents. Org. Lett. 2003, 5, 2157–2159.
9. CCDC-1400036 (7) contains the supplementary crystallographic data for this paper. These data can be
obtained free of charge via www.ccdc.cam.ac.uk/conts/retrieving.html (or from the CCDC, 12 Union
Road, Cambridge CB2 1EZ, UK; fax: +44 1223 336033; or e-mail: deposit@ccdc.cam.ac.uk).
10. Mitra, P.; Shome, B.; De, S.R.; Sarkar, A.; Mal, D. Stereoselective synthesis of hydroxy stilbenoids and
styrenes by atom-efficient olefination with thiophthalides. Org. Biomol. Chem. 2012, 10, 2742–2752.
11. Bunescu, A.; Wang, Q.; Zhu, J. Copper-Mediated/Catalyzed Oxyalkylation of Alkenes with
Alkylnitriles. Chem. Eur. J. 2014, 20, 14633–14636.
Sample Availability: Not available.
© 2015 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/4.0/).
