Novel, yellow-emitting anthracene/fluorene oligomers:
synthesis and characterization
*
Zujin Zhao, Shuqiang Yu, Lei Xu, Hongbo Wang and Ping Lu
Department of Chemistry, Zhejiang University, Hangzhou 310027, PR China
Received 5 February 2007; revised 24 May 2007; accepted 25 May 2007
Available online 2 June 2007
Abstract—A novel series of highly soluble and strongly yellow fluorescent with well-controlled, alternative anthracene, and fluorene units
were successfully synthesized by a Pd/Cu-catalyzed Sonogashira coupling reaction and characterized. Their thermal stabilities, electrochem-
ical behaviors, and photophysical properties were investigated. These oligomers might be used as models to study structure–property relation-
ship for their corresponding polymers and applied in optoelectronics devices as materials themselves.
Ó 2007 Elsevier Ltd. All rights reserved.
1. Introduction
Both fluorene and anthracene are well-known blue fluoro-
phores and their derivatives have been widely used as
emitting materials or else. Though random poly(fluorene-
co-anthracene)s have been reported,11 to the best of our
knowledge, few oligomers or polymers based on well-
controlled alternative fluorene and anthracene structures
are reported. Therefore, in this paper, we would like to report
the synthesis and characterization of a series of monodis-
perse, ethynylene-linked oligomers with well-defined, alter-
native fluorene and anthracene structures. These oligomers
could be used as models to study structure–property relation-
ship for their corresponding polymers or be applied in opto-
electronic devices as materials themselves.
Conjugated oligomers have triggered intense investigations
from both academic and industrial laboratories1 due to their
promising applications, such as light-emitting diodes
(OLEDs),2 solar cells,3 field-effect transistors (FETs),4 and
models5 to understand the structure–property relationships
of their analogous polydisperse polymers. In contrast to
polymers, monodisperse conjugated oligomers are charac-
terized by a well-defined and uniform molecular structure
as well as superior chemical purity, which would offer im-
proved stability and sharper emission bands.6 Development
of synthetic methodology makes it possible to design a vari-
ety of soluble monodisperse oligomers, which permit color
and charge injection tunable through the conjugation length
control, as well as the introduction of functional groups to
the parent p-conjugated system.7 For example, palladium-
catalyzed cross-coupling reaction of terminal alkynes with
arylhalides (the Sonogashira reaction) provides an efficient
and versatile tool to extend p–p conjugation in organic
compounds, affording simplified molecular structures com-
pared with their alkene analogues due to the lack of Z/E
isomerism of the double bonds.8 And many ethynylene-
linked oligomers of special properties have been designed
and synthesized.9 To these ethynylene-extended arenes and
heteroarenes, it has been proved to be of the function as
nanoscale ‘molecular wires’, with the extent of intramolec-
ular conjugation dependent upon the topology of the p-
system and the molecular length.10
2. Results and discussion
A Pd/Cu-catalyzed Sonogashira coupling reaction was used
as a key reaction to build ethylnylene-linked molecules.
Synthetic approach of necessary intermediates are outlined
in Scheme 1. Our strategy to the target molecules started
from 9-iodo-anthracene (1) and 9,10-diiodo-anthracene
(4). Pd/Cu-catalyzed coupling of 1 and 3-methyl-1-butyn-
3-ol provided 2, which was followed by a base-promoted de-
protection to afford 9-ethynyl-anthracene (3) in 85% total
yield. Similar procedures were performed from 4 to obtain
9,10-diethynyl-anthracene (6) in 64% total yield. Treatment
of 3 with 3 equiv of 2,7-diiodo-9,9-diheptyl-9H-fluorene
(7)12 in the presence of CuI, Pd(PPh3)2Cl2, Ph3P, and NEt3
afforded intermediate 8 in 84% yield after separation by col-
umn chromatography. Compound 8 was then converted to 10
in 78% total yield after cross-coupling and deprotection pro-
cedure. Compound 10 reacted with 3 equiv of 4 in the pres-
ence of Pd/Cu catalyst to afford 11 in 66% yield. Analogous
* Corresponding author. Tel.: +86 571 879 52543; e-mail: pinglu@zju.
edu.cn
0040–4020/$ - see front matter Ó 2007 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tet.2007.05.095

7810
Z. Zhao et al. / Tetrahedron 63 (2007) 7809–7815
a
b
a
b
I
OH
I
I
HO
OH
OH
1
3
5
2
4
6
a
b
c
I
I
I
+
C7H15
C7H15
C7H15 C7H15
10
C7H15
C7H15
C7H15
C7H15
3
7
8
9
a
4
b
I
OH
c
C7H15 C7H15
13
C7H15
C7H15
C7H15
11
C7H15
12
7
c
I
C7H15
C7H15
C7H15
C7H15
14
Scheme 1. (a) 3-Methyl-1-butyn-3-ol, CuI, Pd(PPh3)2Cl2, Ph3P, NEt3, N2, reflux; (b) KOH, 2-propanol, reflux; and (c) CuI, Pd(PPh3)2Cl2, Ph3P, NEt3, N2, reflux.
procedures were performed step by step to get intermediate
14 from 11 in 28% total yield.
all of these synthesized compounds exhibited excellent sol-
ubility in common organic solvents, such as CH2Cl2, CHCl3,
THF, and toluene. This is helpful for easier preparation and
purification in the synthetic procedure leading to the suffi-
ciently long rod length as well as easier fabrication in the
procedures of optoelectronic device preparation.
In order to facilitate the synthesis of longer oligomers, we
tried to gain compound 18, which could serve as a core of
oligomers with longer molecular length after a bicoupling
with monoiodide (Scheme 2). Coupling of 9,10-diiodo-
anthracene (4) with an equal amount of 3-methyl-1-butyn-
3-ol yielded compound 15 in 72% yield, which was followed
by a further coupling with 1613 giving compound 17 in 65%
yield. Compound 18 was produced by the final base-
promoted deprotection of 17, which was indicated by thin
layer chromatography. However, it was hard to be isolated
because it was unstable when exposed to air in solid states.
It was destroyed quickly when we run column chromato-
graphy. In fact, we found that compounds 6 and 13 were
also unstable, especially for compound 6.
Thermal properties of these oligomers were examined
through differential scanning calorimetric (DSC) and ther-
mogravimetric analysis (TGA) in N2 at a heating rate of
10 ꢀC/min, and these results are listed in Table 1. The de-
composition temperatures (Tds) of these oligomers were in
the range of 386–426 ꢀC, with 5% loss of initial weight,
while their melting points were not detected. And the glass
transition temperatures (Tgs) of oligomer DAF, TADF,
TATF, and PATF were 101, 115, 119, and 122 ꢀC, respec-
tively, which gradually increased as the main chain length
increased.
The final couplings of anthracene/fluorene oligomers are il-
lustrated in Scheme 3. DAF and TATF were obtained in 89,
and 78% yields by treating 16 with 2 equiv of 1 and 11, re-
spectively, in the presence of CuI, Pd(PPh3)2Cl2, Ph3P, and
NEt3. TADF and PATF were obtained in 55 and 38% yields
by treating newly prepared 6 with 2 equiv of 8 and 14, re-
spectively, under the same conditions. Moreover, an addi-
tional oligomer TATFC was synthesized (48% yield) by
coupling intermediate 14 with 3,6-diethynyl-9-p-tolyl-9H-
carbazole (19)14 under the same conditions. The existence
of 3,6-substituted carbazole core introduced a V shape to
the molecule. All the final oligomers were characterized
by NMR and element analysis. However, their mass spectra
could not be detected by MALDI-TOF mass spectroscopy.
All of the oligomers as well as intermediates were solid.
Due to the presence of the flexible n-heptyl substituents,
Electrochemical properties of oligomers were analyzed by
cyclic voltammetry (CV) in the CH2Cl2 in the presence of
0.1 M Bu4NPF6 as supporting electrolyte. The results are
listed in Table 1. Oligomers exhibited irreversible oxidation
peaks that shift positively from 1.22 to 1.69 V with the incre-
ment of the oligomer length. On the basis of the onset poten-
tial for the oxidation and the band gap determined from the
optical absorption threshold, the HOMO and LUMO energy
levels of oligomers were calculated in the range of ꢁ5.43 to
ꢁ5.61 eV and ꢁ2.76 to ꢁ3.29 eV (Table 1), respectively,
with a steady increment as the anthracene unit accumulated.
The photophysical properties of oligomers were examined
by UV–vis and photoluminescence (PL) spectroscopy in di-
lute CH2Cl2 solutions and the results are listed in Table 1.
16
a
b
C7H15
C7H15
I
I
I
OH
HO
OH
a
C7H15 C7H15
18
C7H15
C7H15
15
4
17
Scheme 2. (a) 3-Methyl-1-butyn-3-ol, CuI, Pd(PPh3)2Cl2, Ph3P, NEt3, N2, reflux and (b) KOH, 2-propanol, reflux.

Z. Zhao et al. / Tetrahedron 63 (2007) 7809–7815
7811
1
c
DAF
C7H15
C7H15
C7H15
C7H15
C7H15 C7H15
C7H15
C7H15
C7H15
16
8
c
TADF
C7H15
C7H15
6
11
c
TATF
C7H15
C7H15
16
C7H15
C7H15
C7H15
C7H15
14
c
PATF
C7H15
C7H15
C7H15
C7H15
C7H15
C7H15
C7H15
6
N
19
C7H15
C7H15
C7H15
C7H15
14
c
C7H15
C7H15
C7H15
C7H15
N
TATFC
Scheme 3. (c) CuI, Pd(PPh3)2Cl2, Ph3P, NEt3, N2, reflux.
