Fishing and Hunting”—Selective Immobilization of

a Recombinant Phenylalanine Ammonia-Lyase from

Fermentation Media

Evelin Sánta-Bell , Zsófia Molnár , Andrea Varga , Flóra Nagy , Gábor Hornyánszky ¹^,⁵,

1

1,2,3

4

1

4

1,5,6,

1,4,5,

Csaba Paizs , Diána Balogh-Weiser

* and László Poppe

*

1

Department of Organic Chemistry and Technology, Budapest University of Technology and Economics,

111 Budapest, Hungary

Fermentia Microbiological Ltd., 1405 Budapest, Hungary

1

2

3

Institute of Enzymology, Research Center for Natural Sciences, Hungarian Academy of Science,

1117 Budapest, Hungary

4

Biocatalysis and Biotransformation Research Centre, Faculty of Chemistry and Chemical Engineering,

Babeş-Bolyai University of Cluj-Napoca, 400028 Cluj-Napoca, Romania

SynBiocat Ltd., 1172 Budapest, Hungary

Department of Physical Chemistry and Materials Science, Budapest University of Technology and

Economics, 1111 Budapest, Hungary

5

6

*

Correspondence: dweiser@mail.bme.hu (D.B.W.); poppe@mail.bme.hu (L.P.)

Received: 27 September 2019; Accepted: 13 November 2019; Published: 15 November 2019

Abstract: This article overviews the numerous immobilization methods available for various

biocatalysts such as whole-cells, cell fragments, lysates or enzymes which do not require

preliminary enzyme purification and introduces an advanced approach avoiding the costly and

time consuming downstream processes required by immobilization of purified enzyme-based

biocatalysts (such as enzyme purification by chromatographic methods and dialysis). Our approach

is based on silica shell coated magnetic nanoparticles as solid carriers decorated with mixed

functions having either coordinative binding ability (a metal ion complexed by a chelator anchored

to the surface) or covalent bond-forming ability (an epoxide attached to the surface via a proper

linker) enabling a single operation enrichment and immobilization of a recombinant phenylalanine

ammonia-lyase from parsley fused to a polyhistidine affinity tag.

Keywords: IMAC; selective enzyme immobilization; phenylalanine ammonia-lyase; magnetic

nanoparticles

1

. Introduction

1

.1. Importance of Biocatalysts

The use of enzyme-based biocatalysts for biotransformations is getting more and more common

both in research and in industrial processes [1,2]. This phenomenon is understandable considering

the need of enantiomerically pure compounds in modern drug manufacturing and the pursuit of

environmental protection. Biocatalysts allow to accomplish stereo-, regio- or enantioselective

reactions under mild conditions in an easy and environmentally friendly way. Biocatalysts often

provide reaction pathways at ambient temperature, without using strong bases, acids, expensive

metal-containing catalyst or difficult to regenerate, harmful solvents. Beyond the advantageous

properties of proteins as biocatalysts, knowledge on their structure and mechanism of action is also

very important because several drugs and pesticides target various proteins in living organisms.

Molecules 2019, 24, 4146; doi:10.3390/molecules24224146

www.mdpi.com/journal/molecules

Molecules 2019, 24, 4146

2 of 23

1

.1.1. Whole Cells and Isolated Enzymes as Biocatalysts

In the food industry, microorganisms have already been used without knowing their

mechanism. Yeasts have been catalyzing the fermentation processes of wine, yoghurt or leavened

bread production since thousands of years. Nowadays, we are using whole cells or their enzymes

more consciously for many purposes in research and industry as well [2–4].

In the pharmaceutical and fine chemicals industries, the whole cells and enzymes have an

important role as biocatalyst in selective biotransformations resulting in simpler building blocks [4–

9

] and more complex compounds like alkaloids [10] or steroids [11–14]. It is a common feature of the

chiral active pharmaceutical ingredients that just one of the enantiomers has the desired effect. Due

to their homochiral nature, enzyme-based biocatalysts are capable of providing the desired

enantiomer through kinetic resolution, dynamic kinetic resolution or enantiotope selective

biotransformations. The advantage of the last two methods is that the undesirable enantiomer of a

racemate can be utilized via a racemization step or it is not even forming in the biotransformation.

During the preceding decades, several valuable biotransformations have been implemented:

resolution processes via hydroxyl or amine functional groups [15–22], oxidations [23–25] and

reductions [26–29] in one step or in cascade reactions [30–32], production of amines with

transaminases [30,32–34], imine reductases [28,35] or amine dehydrogenase [34,36] and amino acid

formations [37–39]. Most of these reactions have industrial importance not only in pharmaceutical

field [3,40] but in food [41–45] and fine chemical industries [46–48] or in modern analytics and

diagnostic technologies as well [43,49–53]. Furthermore, biocatalysis has gained more and more

importance in fuel industry regarding biodiesel production with lipases [54,55], in polymer industry

to mediate biocatalyzed polymerizations [56–58] or in environmental processes to degrade various

polymers or biopolymers by hydrolysis [59–61].

1

.1.2. Biocatalyst Production by Fermentation, Recombinant Techniques

The developments in molecular genetics, directed evolution, structure determination and

bioinformatics have led to an enormous increase in knowledge, experience and new possibilities in

fermentation techniques, protein structure manipulation and enzyme mechanism determination.

Thanks to modern biotechnology, the production of a novel recombinant protein in an appropriate

host system is a routine process in a well-equipped laboratory [62].

Nature provides a large number of enzymes to implement a great variety of reactions [63]. In

addition to the natural properties and functions of wild type enzymes, their activity, substrate scope,

and stability can be evolved further with protein engineering methods. Modification of the amino

acid sequence randomly or consciously, based on the researcher experiences or bioinformatics-based

information is a frequent method to improve the efficiency of biocatalysts. For the efficient

production of proteins mostly bacterial or yeast recombinant hosts are used [63]. The DNA sequence

coding the protein is delivered to the producing cells as part of a vector (e.g., plasmid, phage or

artificial chromosome). Beyond the mandatory sections which are essential for the protein expression,

vectors can contain other components like antibiotic resistance gene sequences and tag-coding

sections. Antibiotic resistance allows the selective survival of the vector containing cells, whereas

different tags are useful in the purification of the protein [64–66]. Recombinant protein expression

should be induced, in this way higher protein amounts can be obtained even if the resulting protein

is toxic for the cell. In case of bacterial expressions, usually the lac operon and isopropyl β-D-1-

thiogalactopyranoside (IPTG, being a molecular mimic of the lactose metabolite, allolactose) as

inducer of the gene regulation system are used [66]. During the upstream process even hundred-liter

fermenter size can be achieved step by step starting from a small colony.

Molecules 2019, 24, 4146

3 of 23

1

.1.3. Downstream Processes for Enzyme Production

After the cell culture has reached the desired state, the cells are harvested by centrifugation. The

easier case of enzyme production is when the target enzyme is secreted, thus it can be separated from

the sedimented cells [67]. Even in this case, a number of purification steps are needed to obtain pure

enzyme. It is more complicated in the case of intracellular enzymes when after the cell disruption the

enzyme has to be isolated from the cell debris and many other proteins.

Usually, the protein products are expressed intracellularly in the host cells, where they can be

occasionally accumulated in inclusion bodies. In order to gain the desired protein, the host cells have

to be disrupted by using mechanical methods like high pressure homogenization, bead mills or

ultrasonication, or other physical, enzymatic or chemical methods disintegrating the cell wall [68–

7

0]. After cell disruption, the protein containing supernatant can be separated from the cell debris by

centrifugation. The costliest part of the protein purification is the process resulting in the target

enzyme which requires separation from a complex protein mixture containing the own proteins of

the host cells as well. When the target enzyme is thermostable, heat shock is a cheap and easy way to

get rid of the non-thermostable proteins [54].

To date, a lot of different techniques have been developed for protein separation: e.g., size-

exclusion, hydrophobic and affinity chromatography or fractional precipitation [71]. When

recombinant protein production is applied, the use of affinity techniques is very common because

affinity tags are easy to fuse to the protein by using a suitable vector. Due to the selective interaction

between the tag and the affinity function of the chromatographic stationary phase, a high degree of

purification can be achieved in a single operation [64]. After taking advantage of the affinity tag, it

can be eliminated easily with a chosen site-specific protease if the protein of interest is expressed with

the proper protease cleavage site [72]. To find the most suitable tag, the size and nature of the tag, the

costs and circumstances of the binding, elution and tag removal should be considered. In many cases,

enzymes have only limited stability in the elution buffer, therefore the enzyme isolated after removal

of the impurities should be dialyzed against a suitable buffer, followed by concentration and storage

for further using.

The purification and polishing steps often require sophisticated apparatus and chromatographic

stationary phases. The waste-water generated during the dialysis or stationary phase regeneration

steps can also increase the environmental load of the purification process. Therefore, it is highly

beneficial if the purification process can be simplified on the way to get the final biocatalyst.

1

.2. Improved Immobilization Techniques for Biocatalysts: Methods, Pros and Cons

There are several shortcut possibilities from the cell or enzyme production until reaching the

final functional form of the biocatalyst (Figure 1). Choosing the right technique of immobilization

depends on the desired use of the biocatalyst, considering the activity, selectivity, stability and

economic points of view.

The first strategy, when the whole cells are to be immobilized, is applicable for strains isolated

from nature or for microbial whole cells hosting expressed wild type or mutant enzymes. In this case,

the only step of the downstream processing is harvesting the whole cells after fermentation usually

by centrifugation. It is a relatively simple and inexpensive method, which is advantageous if the

enzyme is sensitive to environmental effects and/or unstable in extracellular media. Importantly, the

whole cells contain usually the cofactors and further enzymes aiding cofactor regeneration, but if

there is no substrate for the regeneration of the cofactor, feeding the appropriate cofactors in small

concentrations may be necessary for effective long-term operation [32]. Whole-cell immobilization is

required when the target enzyme is a cell surface display protein. In this case, it is advantageous that

the substrate does not have to diffuse into the cell, because the enzyme is located on the outer surface

of the cell [73,74]. However, a disadvantage of the immobilized whole-cell biocatalysts that they are

multienzyme systems in which undesired side reactions can occur catalyzed by the other enzymes

present in addition to the desired enzyme. In this case, the target enzyme should be separated from

the further disturbing enzymes.

Molecules 2019, 24, 4146

4 of 23

Figure 1. Possible shortcuts of the downstream process during immobilized biocatalyst production.

The next possibility is immobilization of the cell lysate containing proteins and enzymes

separated from the cell debris with centrifugation after cell lysis. Typically, similar immobilization

techniques can be used for this protein mixture which are also applicable for a purified enzyme.

Immobilization at this phase of downstream process is advantageous for proteins which would not

tolerate further purification steps such as chromatography, dialysis or concentration. Another case

when the immobilization can take place after the lysis is when the high concentration of the target

enzyme allows to omit further purification.

If a partially purified or a homogenous enzyme is needed, further purification steps have to be

accomplished. The numbers and type of these depends on the enzyme. If the enzyme is thermostable

some of the host proteins can be removed with heat shock [54] and centrifugation. Recombinant

production of proteins allows fusing various affinity tags to the target enzyme and using the most

efficient affinity chromatographic methods during the downstream processes. For example, strep-

tags, S-tag, calmodulin-binding peptide, cellulose- or chitin-binding domains are used in

combination with an appropriate chromatographic stationary phase with an immobilized ligand with

high affinity and selectivity towards the tag. Affinity chromatography usually ensure a very selective

binding and high purity in one chromatographic step [64,75]. One of the most often used tags

nowadays is the His-tag comprising of an oligopeptide sequence of several histidines. The His-tag is

Molecules 2019, 24, 4146

5 of 23

suitable for metal ion affinity chromatography due to the strong chelating ability towards various

metal ions. The following subchapters go into more details of the above-mentioned immobilization

techniques enabling shortcuts from the fermentation to a homogenous form of the target enzyme.

1

.2.1. Whole-Cell Immobilization Strategies

To immobilize whole cells, entrapment techniques are widely used [76,77]. In this method the

cells are retained within a polymer matrix, like capsules, nanofibers or sol-gel matrices, in a way

enabling substrate access to and product egress from the cells.

Alginate is a very popular biopolymer for cell entrapment [78]. It is an affordable raw material

and easily forms alginate gel matrices in the presence of calcium or other multivalent metal ions.

Agar, agarose, chitosan, carrageenans are also suitable polysaccharides for whole-cell immobilization

[76,79]. Carrageenans also form gel when added to a solution of calcium salt. By the aid of solvent

evaporation, changing pH or using cross-linkers, membranes, films or gels can be formed from chitin,

chitosan or gelatin [80]. Other organic and inorganic polymers are also used for the immobilization

of cells. The application of poly(vinyl-alcohol) (PVA), acrylic polymers, [76] or polyurethane foams

[81] as entrapment matrices also resulted in easy-to-store biocatalysts. Organosilane-based sol-gel

matrices offer a general and gentle way for cell entrapment as well [82–84]. Depending on the sol

formation method and the type of the silica precursor, the sol-gel formation may take place in

aqueous or organic media catalyzed by acids or bases [32,83,85,86]. The addition of solid silica

particles to this sol-gel system could approve the catalyst diffusion properties or mechanical stability

[32].

Besides the formation of gels, hydrogels or membranes, some polymers like PVA, polyethylene

oxide (PEO), polyvinyl pyrrolidone (PVP), polycaprolactone (PCL) or polylactic acid (PLA) proved

to be suitable for cell-entrapment in electrospun nanofibers [87–90]. Selection of the suitable polymer

requires considerations based on the solvent tolerance of the cells and the conditions of the designed

biotransformations. There are fully water-soluble polymers, like PVA or PEO, but in many cases

organic solvents are needed to mediate the electrospinning process. An important aspect of matrix

selection for electrospun fiber cell entrapment is that the formed nanofiber should not dissolve in the

medium of the biotransformation.

Immobilization of whole cells on solid supports is less common. Adsorption is based on

secondary interactions, such as ionic interactions [91]. To diminish cell leakage, adsorption as first

step can be combined with other immobilization techniques like encapsulation, coatings or covalent

cross-linking after flocculation [92,93]. In this case the adsorbents and the flocculants have great

impact on the produced biocatalyst. The addition of solid support, such as diatomite, bentonite, silica

microspheres, could increase mechanical and chemical stability and the biocatalytic activity

compared to the cross-linked or entrapped cells without solid support [32,92]. For cross-linking and

covalent immobilization onto solid surfaces, glutaraldehyde is widely used [92,94]. It is getting

popular to combine these methods and merge the advantageous properties of the different systems

creating new hybrid matrices for whole cell or enzyme immobilization [95,96].

1

.2.2. Strategies for Immobilization of Cell-Free Forms of Enzymes

Immobilized forms of enzymes have several advantages over their native forms. Usually,

immobilized biocatalysts are easy to recycle and the immobilization often improves resistance of the

enzyme against environmental impacts (temperature, pH, ionic strength, organic solvents, etc.) [97].

The methods of enzyme immobilization can be categorized in several ways. In one of the, the

immobilization protocols can be categorized into two main types, the physical and the chemical

immobilizations, based on whether the enzyme was chemically modified or not. In case of physical

immobilization, the enzyme structure is not modified chemically. Two subclasses may be

distinguished within this type. First, when the enzyme is entrapped (encapsulated) in a polymer

matrix. This can be achieved for example by sol-gel or polysaccharide based gels or by

electrospinning, similarly, as already mentioned at the whole cell immobilization methods in Section

1

.2.1. [18,98–101]. The second subclass of non-chemical immobilization methods is based on

Molecules 2019, 24, 4146

6 of 23

secondary interactions between the enzyme and a solid support. These secondary interactions can be

adsorption based on π-π interactions, hydrogen or ionic bonds, or a stronger affinity-based

interaction [102,103]. The later method is suitable for orienting the protein during the immobilization,

by positioning the tags in an adequate position within the protein sequence of the functional enzyme.

Because these methods avoid chemical modification of the enzyme, it is considered that this kind of

immobilization keeps the active form of enzyme with higher probability than the methods based on

chemical protein modifications. Methods based on physical interactions are useful when covalent

immobilization leads to enzyme inactivation (e.g., by reaction of a lysine in the active center or near

to it). In case of the entrapped enzymes, the negligible leakage from properly selected polymer

matrixes and the enhanced heat and solvent tolerance are advantageous, but the hindrance of

substrate and product diffusion can be much higher than with other types of immobilizations. On the

other hand, the adsorbed enzyme biocatalysts have more beneficial diffusion properties, but in this

case, a serious disadvantage can be the desorption of the enzyme from the surface which can cause a

decrease in the activity and the reusability of the biocatalyst.

The chemical immobilization techniques usually mean immobilizations are based on covalent

bond formation. Covalent bonding may happen between the enzyme and some kind of carrier or

between several enzyme molecules (Cross-Linked Enzyme Aggregates – CLEAs) [45,104]. Serious

disadvantages of the CLEAs method are the high enzyme amount required, the usually weak

chemical and mechanical resistance of the resulted biocatalyst and the hindered diffusion due to the

formed tight nanopores.

Multipoint covalent immobilization onto a solid support leads to stable biocatalysts where the

structural, diffusional and mechanical properties can be influenced with the well-chosen support.

Abundantly, glutaraldehyde is applied for the formation of covalent bonds [105]. Besides the often

used glutaraldehyde, epoxy functioned supports have been used for a long time [106], and activated

carboxyl, amino, hydroxyl or thiol groups are also suitable for covalent immobilization [21,104,107–

1

09]. The two-step method of the covalent immobilization can be enhanced with heterofunctional

epoxy supports [109–112]. Different functional groups beside the epoxy functions like thiol [113,114],

amino- or carboxylic groups [109,111], hydrophobic functions [103,115] and iminodiacetic acid

complexed metal ions [116–120] can help the enzyme adsorption and thus the covalent

immobilization. Also the pH during the immobilization has a great impact on the formation of stabile

multipoint covalent attachment between the enzyme and the support [114,120]. Nowadays, a great

variety of supports are used: macroporous polymers [107,109], silica particles in different size and

shape [21], magnetic nanoparticles [121] and several type of nanofibers [122] or nanotubes [123] are

just some of the most popular ones. Also modification of the surface with inert groups besides the

reactive functions has an effect on the biocatalytic activity [103,109].

1.3. Immobilization Methods of Isolated Enzymes Simplifying the Downstream Process

From the economic and environmental point of view it is advantageous if the costly and time-

consuming enzyme purification processes can be eliminated fully or partially in the course of the

biocatalyst production. As already demonstrated, there are well-known methods enabling selective

immobilization [124]. However, these selective methods are usually based on affinity interaction

between the enzyme and the surface and not on covalent immobilization.

1

.3.1. Embedding as Purification Free Process

The immobilization methods based on embedding and presented in Section 1.2.1 – like sol-gel,

alginate or chitosan systems or electrospun nanofibers – are suitable for efficient and usually low

cell/protein loss immobilization of whole cells or cell lysate without further protein purification.

Molecules 2019, 24, 4146

7 of 23

1

.3.2. Affinity-Based Methods

In the late 1970s, Porath and coworkers discovered that proteins containing histidine and

cysteine on their surface can coordinate to transition metal ions via the imidazole and thiol groups of

2+

these amino acids [125]. They created an agarose gel with iminodiacetic acid complexed to Zn and

Cu²⁺ions. This metal ion-charged agarose gel was used successfully to separate human serum

proteins. Inspired by this discovery, Hochuli and coworkers used this system for purification of poly-

histidine-tagged proteins [126]. Due to the quite rare occurrence of multiple consecutive histidine

sequence in Nature, it is a great opportunity to tag proteins and purify them in an easy way. With

the aid of modern molecular biology methods and enzyme engineering, it is now very simple to

attach six or ten histidines to a recombinant protein enabling coordination of the tagged protein to

transition metal ions. The immobilized metal affinity chromatography (IMAC) as a protein

purification process became one of the most often used affinity-based methods for purification of

recombinant proteins. One of the most popular commercial purification resin is still based on agarose

charged with Ni²⁺ion chelated with nitrilotriacetic acid (NiNTA), which is similar to that used by

Porath in 1983 [127]. Despite the popularity of IMAC, during the last four decades a number of further

affinity tags, chelating agents and supports were created for the purification of enzymes and other

proteins, like antibodies as well (Table 1) [64–66].

Table 1. Affinity tags for protein purification (protein binding).

Tag Name

Poly Arg-tag [128]

Poly His-tag [126]

FLAG [129]

Strep-tag II [130]

Length

5–6 arginine

6–10 histidine

8 amino acids

Binding Matrix

Cation-exchange resin

Immobilized metal-coated support

Anti-FLAG MAbs

Modified streptavidin

Calmodulin

Calmodulin-binding peptide [131]

Cellulose-binding domains [132]

SBP [133]

Chitin-binding domain [134]

Si-Tag (L2, Zbasic2 proteins) [135,136]

Glutathione S-transferase [137]

HaloTag [138]

26 amino acids

27–129 amino acids

38 amino acids

51 amino acids

58 and 273 amino acids

211 amino acids

237 amino acids

396 amino acids

Cellulose

Streptavidin

Chitin

Silica surface

Glutathione

HaloTag ligands

Cross-linked amylose

Maltose-binding protein [139]

However, IMAC (and the other listed methods) are applicable not only for protein purification

but are also useful for selective and oriented enzyme immobilization [140]. This process, when

applied without elution of the bound protein from the support, enables selective immobilization of

the biocatalyst in one-step. Because the immobilization in such case is based on reversible interaction

between the fixed metal ion and the protein, in case of enzyme inactivation the exhausted enzyme

can be eluted from the surface and the support can be recharged with fresh enzyme in a new

immobilization cycle. This is advantageous in case of expensive or hard-to-prepare supports.

Although the use of this complex formation for enzyme immobilization is a very straightforward

and rapid way to obtain biocatalysts, but sometimes the conditions of the target biotransformation

require more stable immobilization. If enzyme leakage occurs during the application (e.g., a chelating

agent is present in the reaction, or the pH or ion concentration do not favor the enzyme-metal

complex stability) an immobilization method resulting in more durable binding is needed. A good

strategy may be to stabilize the complexed enzyme after binding to the IMAC support by other

methods. As a further step after IMAC support binding, embedding methods can be considered (such

as electrospinning or sol-gel entrapment of the enzyme on the support in an appropriate matrix).

Alternatively, covalent bonds can be created after the complexation if there are further reactive

functions on the support. Such strategy was applied in a modified, selective CLEA method for the

immobilization of His-tagged acid phosphatases [141]. Smart silica nanoparticles with amino

functions and metal chelating groups were created enabling selective immobilization of acid

phosphatases in a process starting with rapid affinity binding of the target phosphatases followed by

cross-linking the enzyme-nanoparticles system with bisepoxides as cross-linkers. The created acid

Molecules 2019, 24, 4146

8 of 23

phosphatase biocatalysts showed excellent activity and long-term operation stability compared with

the enzyme immobilized by other methods.

In case of conventional covalent immobilization, usually the use of purified enzymes is required

because the often used aldehyde- or epoxy-group based binding functions on the support cannot

distinguish the amino groups of different proteins. Since the costliest part of the enzyme production

is the purification, it is desirable to develop single process methods for simultaneous enrichment and

immobilization. Thus it is advantageous to combine the two methods within one process or on one

support. When a covalently immobilized biocatalyst is needed in a single operation process without

breaking off the procedure between the purification and stabilization steps, the chelating and

covalent binding functions must be present in the same time on the support. A selective and stabile

process can be achieved by these strategies if a first rapid complexation is followed by a slower

covalent binding step [120].

Mateo and coworkers immobilized different enzymes on multifunctional epoxy supports, also

2+

on iminodiacetic acid (IDA) and Cu modified Eupergit C [109,116]. Later they optimized the epoxy

and IDA-metal ion ratio with different reaction times of the Eupergit C and used the modified

support for the immobilization of His-tagged glutaryl acylase [120]. It was found that only a small

surface metal ion concentration was enough to exert the selective effect. Most of the target proteins

2+

adsorbed on the surface when the Co concentration was 5 µmol/mL with IDA – epoxy ratio 1 to 7

on the support and the binding of the other proteins was negligible. In this way it was possible to

gain immobilized biocatalyst from the crude cell lysate with almost the same biocatalytic activity as

from the purified enzyme solution.

There are further examples from the last twenty years for using similar bifunctional supports for

one step purification and immobilization [117–120]. Penicilline G acylase was immobilized on

2+

epichlorohydrin, iminodiacetic acid and Cu functionalized cellulose membrane [117]. The amount

of metal chelating groups was controlled by using different amounts of IDA during the surface

modification. In this case, the optimal ratio of epoxy and metal chelating groups were close to 1:1 in

the preparations providing the most stable and reusable biocatalyst.

Also magnetic nanoparticles with an epoxy – IDA combination in 13:2 ratio were used for

selective immobilization of His-tagged benzaldehyde lyase (BAL) [118]. After the elution of the non-

covalently attached proteins with imidazole buffer, a covalently immobilized biocatalyst was

obtained directly from the crude cell lysate. The BAL-MNPs biocatalyst was used successfully in the

condensation reaction of benzaldehyde to benzoin.

Alcohol dehydrogenase from Haloferax volcanii was immobilized on commercially available

epoxy support, Sepabeads EC-EP/S, after modification approximately 5% of epoxy groups with IDA

2

+

2+

[

119]. Three transition metal ions – Co , Ni , Zn – and Ca were tested in the immobilization

2+

process. The best efficiency was earned with Ni modified support.

In all of these examples an epoxy support was partially modified with IDA as a metal chelating

agent. In all instances, the mixed epoxy-chelate function supports were more effective than the epoxy

supports. Creating the chelating functions directly on an epoxy support is quick and easy, but the

fine tuning of the surface is more complicated due to the restricted variability of the required multi-

linker modifications. In our work, a similar immobilization technique was used, but fine-tunable

surface modification of the carrier system was developed. Both the epoxide moieties and the

complexing agent were formed simultaneously during a single surface modification step of an amine

functionalized support. This allowed us to vary the properties of the final selective support by

choosing and combining different agents of variable chemical structures, lengths and the hydrophilic-

hydrophobic properties to form the two functions for chelation and covalent binding. All of these

properties have an impact on the immobilization of the enzyme and on its final biocatalytic behavior.

Phenylalanine ammonia-lyase (PAL) from various organisms has a great impact in the

production of several unnatural amino acids [142,143], and also get a lot of attention as a possible

enzyme substitution treatment for patients suffering from phenylketonuria [144]. Therefore,

immobilization of a phenylalanine ammonia-lyase has been selected as the target of the present study.

Based on these preliminary considerations, our aim was to prepare mixed epoxy-chelate

Molecules 2019, 24, 4146

9 of 23

functionalized magnetic nanoparticles with ethylenediaminetetraacetic acid related chelating

function and test them as selective support in a single-step immobilization of PAL.

2

. Results and Discussion

In this work we studied the advantages of the epoxy-chelate bifunctional supports in the

immobilization of phenylalanine ammonia-lyase from Petroselinum crispum (PcPAL) expressed in

recombinant E. coli even from crude cell lysate (Figure 2). Magnetic nanoparticles were selected as

support because of their easy separability, high surface area and simple surface modification [145].

Silica shell-coated magnetic nanoparticles were etched with aminopropyl functions and further

modified with mixtures of ethylenediaminetetraacetic dianhydride (EDa) and various multiepoxide

compounds in different ratio. With this strategy it was possible to test different multiepoxides to form

the covalent binding function and also the ratio of chelating and covalent binding sites could be

modulated.

Figure 2. Surface modification of magnetic nanoparticles and immobilization of phenylalanine

ammonia-lyase from Petroselinum crispum (PcPAL) onto mixed epoxy-chelate magnetic nanoparticles

from cell lysate.

Our previous experiences with the IMAC purification of PcPAL indicated that the strongest and

most selective binding could be achieved by cobalt(II) ion charged supports [unpublished data].

Therefore, no further metal ion tests were performed in this study, and cobalt(II) was used solely as

a chelating metal ion. The formed PcPAL biocatalysts were tested in ammonia eliminating reaction

from L-phenylalanine [146].

Molecules 2019, 24, 4146

10 of 23

2

.1. Optimizing the Epoxy-Chelate Ratio

First, to determine the proper amount of multiepoxide and ethylenediaminetetraacetic

dianhydride (EDa) as admixture in the amine-modification reaction, the amount of the amino groups

at the surface of aminopropyl-etched MNPs had to be measured. The amino group content on the

surface of the MNPs was quantified by ninhydrin colorimetric assay [147] (see Supplementary

−

1

materials Section 2.4) and was found to be 360 ± 18 µmol × g .

Because the dianhydride was the more reactive component in the surface modification reaction,

being also sensitive to hydrolysis, the surface amine-modification reactions were carried out in dry

dimethylformamide. In the first series of experiments, neopentylglycol diglycidyl ether (NPDGE)

was used as a bisepoxide agent. In addition to the pure chelating and pure epoxy MNPs supports,

nine further MNPs supports prepared with different ratio of NPDGE and EDa. The functionalization

mixtures were investigated for the immobilization of PcPAL leading to biocatalysts with different

immobilization yields and biocatalytic activities (Figure 3). After the overnight shaking with the cell

lysate containing PcPAL, the samples were washed with imidazole solution (500 mM) in order to

elute the weakly complexed His-tagged enzymes and other histidine contained proteins.

Figure 3. Effect of the bisepoxide to ethylenediaminetetraacetic dianhydride ratio in surface

functionalization on the activity of the immobilized PcPAL biocatalyst. Lysate: crude protein mixture

without immobilization; EDa: only EDa modified support; NPDGE: only NPDGE modified support;

numbers: quantity of NPDGE to one unit of EDa during the surface modification. Colored bars:

specific biocatalytic activity (U

B

), colored dots: activity yield (Y

A

); for the non-immobilized cell-lysate

U

B

= U . The measurements were performed in three replicates; the standard deviation of activity

E

yield values was always below 5%. Experiments were performed as described in Section 3.5.

It is clearly shown that for the most effective immobilization the presence of both the complexing

and the covalent binding groups were required (Figure 3). In the absence of epoxy groups, the

enzymes attached to the surface due to the affinity tag chelation and further ionic interactions, and

as expected, the PcPAL-binding MNPs had reasonable biocatalytic activity. Because the expression

level of PcPAL was quite low in our present case, the cell lysate contained high amounts of other

proteins besides the target enzyme. Therefore, it is not surprising that the epoxy-containing MNPs

without the ability to distinguish between the proteins gave only a poor specific PcPAL activity. The

best specific activity could be achieved when the EDa and NPDGE were used in 1:10 ratio in the

amine-modification reaction mixture. When the ratio of metal chelating groups to NPDGE decreased

below 1:10, the specific biocatalytic activity was reduced due to limited capacity to select the target

enzyme from the protein mixture during the immobilization. With MNPs of the best ratio, 33× better

specific activity of the immobilized PcPAL biocatalyst could be achieved as with MNPs containing

solely epoxy functions on the surface.

Molecules 2019, 24, 4146

11 of 23

2

.2. Comparison of the Biocatalytic Activity of Simple Epoxy – and Mixed Epoxide/EDa Functionalized

MNPs

To demonstrate the enhanced effectivity of this immobilization method, PcPAL immobilization with

the optimized mixed epoxide/chelator functionalized MNPs was compared to the epoxy-

functionalized MNPs from purified PcPAL solution and from a crude lysate after PcPAL expression

(Table 2).

Table 2. Comparison of PcPAL immobilization from crude lysate or from pure enzyme solution using

(µmol × min⁻¹× g )]

−1

epoxy and optimized mixed epoxy-chelate MNPs as support [U

B

PcPAL Solution PcPAL-MNPs-NPDGE PcPAL-MNPs-NPDGE/EDa-10

Crude lysate

Purified PcPAL

0.4 ± 0.1

14.2 ± 0.5

13.7 ± 0.6

14.1 ± 0.6

Immobilization of PcPAL from crude lysate with the surface optimized support resulted in almost

as high activity as immobilization from the purified enzyme on the optimized mixed epoxy-chelate MNPs

or on the epoxy functionalized MNPs. It means that by using the optimized mixed epoxy-chelate MNPs

for immobilization of PcPAL the protein purification process could be skipped by a single process

operation leading to the same specific activity as achievable with simple supports only from purified

enzyme solution.

In our present case, PcPAL exhibited a low level of expression in E. coli, usually resulting in 3–5%

active enzyme content in the total proteins of the cell lysate. The 33 times better specific activity of PcPAL

immobilized on mixed MNPs-epoxy-chelate as compared to MNPs-epoxy clearly indicated the benefits

of this selective enzyme immobilization method when enzymes are produced at low expression levels.

However, to provide guidance in which cases this method is worth using, we investigated the

immobilization of PcPAL with the optimal epoxy-chelate MNPs compared to the epoxy only MNPs as

support for immobilizations from protein mixtures of six different target protein contents. For accurate

modeling, known amounts of purified enzyme in lysis buffer were added to cell lysate to mimic mixtures

representing different expression levels. In the final mixtures the concentration of the target enzyme was

set to the same value and immobilizations were performed with the MNPs-NPDGE/EDa-10 and the

MNPs-NPDGE supports (Table 3).

(µmol × min⁻¹× g )]

−1

Table 3. Comparison of the efficiency of PcPAL immobilization [U

B

with epoxy and optimized epoxy-chelate supports from protein mixtures of different

target enzyme content.

Target Protein

Concentration

5

PcPAL-MNPs-

NPDGE/EDa-10

NPDGE/EDa−10_/_U

NPDGE

UB

B

NPDGE

0.5

1.0

3.3

8.3

11.9

12.4

12.3

12.6

13.2

13.4

13.6

24.1

13.2

4.0

1.6

1.2

1

2

5

7

9

0

5

0

5

0

1.1

The results clearly indicated the benefits of the optimized MNPs-NPDGE/EDa-10 for selective

single operation immobilization of PcPAL not just in expression levels below 10 m/m % target enzyme

content (>13-fold enhancement in specific activity compared to the non-selective MNPs support) but

even in case of 50 m/m % target protein concentration (1.6-fold enhancement).

2

.3. Effect of the Nature of Multiepoxide Agents on the MNPs for the Immobilization of PcPAL

Another advantage of the post modification of amine functionalized magnetic nanoparticles is

the variability of the applicable multiepoxides. Because the amino MNPs do not contain the epoxy

groups inherently, they have to be created together with the complexing functions. In this study, ten

Molecules 2019, 24, 4146

12 of 23

multiepoxides were used for the surface functionalization of MNPs with aminopropyl functions at

the best epoxy-EDa ratio of 10:1 (Figure 4).

After surface activation with the ten different multiepoxides and EDa in 10:1 ratio, the resulted

epoxy-chelate MNPs were tested as supports in the selective immobilization of PcPAL (Figure 4).

There was no significant difference between specific biocatalytic activities of seven bisepoxides and

−

1

two trisepoxides (U

(

B

10 to 14 U × g ), but the mixture formed from the bulkiest trisepoxide

−

1

THPMTGE) resulted in a significantly higher specific activity (24.7 U × g ). However, the relative

residual enzyme activity compared to the native enzyme activity was significantly lower with the

MNPs-THPMTGE/EDa-10 based biocatalyst than with the MNPs-NPDGE/EDa-10 support. It was

observed that epoxides with a shorter and substituted alkyl chain (GDGE/NPDGE/GTGE/TMPTGE)

or epoxides with aromatic rings (BADGE/THPMTGE) as covalent linkers resulted higher specific

biocatalytic activities and activity yields that obtained with epoxides containing longer mobile chains

or aliphatic ring (PDGE/BDGE/CDGE/HDGE).

Figure 4. Effect of the nature of multiepoxide linkers on the activity and immobilization efficiency of

PcPAL biocatalysts. Bars: specific biocatalytic activity (U

B

), dots: activity yield (Y

A

); for the non-

immobilized cell-lysate U = U . The measurements were performed in three replicates; the standard

B

E

deviation of activity yield values was always below 5%. Experiments were performed as described in

Section 3.5.

2

.4. Operational Stability of the Immobilized PcPAL Biocatalysts

Besides of the better mechanical and chemical properties, one of the biggest benefits of using

immobilized biocatalysts is the reusability. Two immobilized PcPAL biocatalysts were chosen for

repeated batch tests (the immobilization leading to the PcPAL-MNPs-NPDGE/EDa-10 and the

PcPAL-MNPs-THPMTGE/EDa-10 was scaled up thirty-fold). The selectivity of these two supports

Molecules 2019, 24, 4146

13 of 23

for the target protein PcPAL were investigated by SDS-PAGE. The covalently attached protein

composition was estimated by SDS PAGE analysis of the adsorbed protein onto the MNPs surface

after a 1 h immobilization time with the cell lysate (Figure S3). Based on the SDS-PAGE analysis, most

of the adsorbed proteins were the target enzyme PcPAL indicating that the bifunctional epoxy-chelate

supports had an excellent selectivity for the His-tagged enzyme.

The biocatalysts were tested by five repetitive cycles in the ammonia elimination of racemic

phenylalanine (D,L-PHE) in a traditional buffer system (TRIS, 100 mM, pH 8.8). The conversions and

enantiomeric excess values achieved by the immobilized biocatalyst are presented in Table 4.

Although the activity of both biocatalysts decreased cycle-by-cycle, after five batch reaction the

catalysts retained 90% of their initial activities.

Table 4. Conversions and enantiomeric excess values of the operational stability tests of immobilized

PcPAL biocatalysts in the ammonia elimination reaction of D,L-phenylalanine. All the measurements

were performed in triplicate, and the standard deviations were below 5%. For experimental

conditions see Supplementary materials Section 3.4.

PcPAL-MNPs-NPDGE/EDa-10

PcPAL-MNPs-THPMTGE/EDa-10

Reaction Cycle

c [%]

eeD

-PHE [%]

c [%]

eeD

-PHE [%]

1

2

3

4

5

49

48

45

43

82

78

71

67

52

51

48

47

93

92

91

43

64

47

89

The reusability of these biocatalysts were tested also under more demanding conditions in the

opposite reaction direction to catalyze ammonia addition onto trans-cinnamic acid (trans-CA)

producing

diminished during the recycling even of the negative effect of the long-term presence of high

ammonia concentration [123]. Both biocatalysts produced -phenylalanine at high conversion rate

L-phenylalanine. The activity of the PcPAL-MNPs-THPMTGE/EDa-10 was barely

L

with an excellent enantiomeric excess even after five repeated batch reactions (Table 5).

Table 5. Conversions and enantiomeric excess values of the operational stability tests of immobilized

PcPAL biocatalysts in the ammonia addition onto trans-cinnamic acid. All the measurements were

performed in triplicate, and the standard deviations were below 5%. For experimental conditions see

Supplementary materials Section 3.5.

PcPAL-MNPs-NPDGE/EDa-10

PcPAL-MNPs-THPMTGE/EDa-10

Reaction cycle

c [%]

85

ee

L

-PHE [%]

»99

c [%]

86

eeL

-PHE [%]

»99

1

2

3

4

5

86

»99

87

»99

85

»99

86

»99

82

»99

86

»99

70

»99

83

»99

3

. Materials and Methods

3

.1. Materials and Analysis

The magnetic nanoparticles coated with aminopropyl functional groups–MagnAmineAP–were

kindly donated by SynBiocat Ltd. (Budapest, Hungary). Bisepoxides 1,4-butanediol diglycidyl ether

BDGE), neopentylglycol diglycidyl ether (NPDGE), 1,6-hexanediol diglycidyl ether (HDGE), 1,4-

(

Molecules 2019, 24, 4146

14 of 23

cyclohexanedimethanol diglycidyl ether (CHDGE), polyoxypropyleneglycol diglycidyl ether

PEDGE), trimethylolpropan triglycidyl ether (TMPTGE) and glycerol triglycidyl ether (GTGE) were

the products of Ipox Chemicals Ltd. (Budapest, Hungary). Glycerol diglycidyl ether (GDGE),

Bisphenol diglycidyl ether (BADGE), tris(4-hydroxyphenyl)methane triglycidyl ether

THPMTGE), ethylenediaminetetraacetic acid (EDTA), potassium chloride, sodium chloride,

(

A

(

tris(hydroxymethyl)aminomethane (TRIS), cobalt(II) acetate tetrahydrate and dialysis tubing

cellulose membrane with a 14 kDa cut off were purchased from Sigma-Aldrich (Saint Louis, MO,

USA). Imidazole, 4-(2-hydroxyethyl)-1-piperazineethanesulfonic acid (HEPES), Bradford reagent, L-

phenylalanine (L-Phe) and trans-cinnamic acid were purchased from Alfa Aesar Europe (Karlsruhe,

Germany). Pyridine, acetic anhydride and all solvents were purchased from Merck KGaA

(Darmstadt, Germany). The technical grade solvents were dried and/or freshly distilled prior to use

and dimethylformamide was dried over 4 Å molecular sieves. The UV-VIS measurements were

carried out in a Genesys 2 type spectrophotometer (Thermo Fisher Scientific Inc., Waltham, MA,

USA).

3

.2. Expression and Purification of PcPAL

Expression of recombinant phenylalanine ammonia-lyase from parsley (PcPAL) carrying an N-

TM

terminal His10-tag in E. coli Rosetta host was carried out at Fermentia Ltd. according to the method

described by Dima et al. [146]. To determine the target PcPAL concentration, a small amount of cell

lysate was purified on Ni-Sepharose according to the protocols of the manufacturer. For complete

recovery of the target protein elution was performed with 500 mM imidazole (in 50 mM HEPES, 30

mM KCl, pH 7.5). The eluted PcPAL was dialyzed against lysis buffer (50 mM TRIS, 150 mM NaCl,

pH 7.5) and the dialyzed PcPAL solution was stored at −20 °C. The total protein concentration in the

−1

cell lysate was 25.6 ± 2.01 g × mL containing the target PcPAL in 0.99 ± 0.13 g × mL concentration

determined by Bradford method (for the measurement description see Supplementary materials

Section 2.3.).

3.3. Surface Treatment of Aminopropylsilane-Coated Magnetic Nanoparticles with EDa and Multiepoxides

at Different Ratios

In a dried 4 mL screw cap glass vial was sonicated a mixture of MNPs (50.0 mg; 18 µmol amine

−1

function), PEG 400 (25.0 mg of polyethylene glycol with an average molecular weight of 400 g × mol )

in N,N-dimethylformamide (DMF, 750 µL) for 10 min. Then variable amounts of a multiepoxide

solution (100 µmol × mL⁻¹in DMF), EDa solution (40 µmol × mL in DMF) and N-ethyl-N,N-

−1

diisopropylamine (DiPEA) solution (60 µmol × mL in DMF, 2 equivalents to the EDa) were added

to the suspension. The total amounts of EDa and the multiepoxide were two equivalents related to

the amino group content of MNPs (36 µmol) but in different molar ratios (EDa-multiepoxide: 1–0; 1–

1

2

; 1–5; 1–10; 1–25; 1–50; 1–75; 1–100; 1–150; 1–200; 0–1). The total reaction volume was filled up to

800 µL by addition of the required amount of DMF. The reaction mixture was shaken at 600 rpm for

4 h at 60 °C, then 50 µL distilled water was added to the mixture which was shaken for further 1 h

at 60 °C. Than the surface-treated MNPs were separated with a neodymium magnet from the reaction

medium and were washed with acetonitrile (2 × 1.0 mL) and 2-propanol (1.0 mL), dried in a VDL 23

vacuum drying chamber (Binder GmbH, Tuttlingen, Germany) at room temperature overnight.

Ethylenediaminetetraacetic dianhydride was synthesize by us (see Supplementary materials Section

3

.1.).

3.4. Metal Ion Complexation of the Surface-Treated MNPs and Immobilization of PcPAL

The metal ion complexation of the surface-treated MNPs and immobilization of phenylalanine

ammonia-lyase on them were performed in 4 mL screw cap glass vials. The bifunctional metal

chelate-epoxy MNPs (5 mg) in distilled water (500 µL) were sonicated for 10 min. After addition of

cobalt(II) acetate solution (100 mM, 500 µL), the resulted mixture was shaken for 30 min, followed by

Molecules 2019, 24, 4146

15 of 23

separation of metal-charged bifunctional MNPs which were washed with distilled water (3× 1 mL)

and lysis buffer (1 mL, 50 mM TRIS, 150 mM NaCl, pH 7.5).

The crude cell lysate or the purified enzyme solution was defrosted and centrifuged (3500 rpm,

2

min, 15 °C). The supernatant protein solution (1 mL) was added to the actual metal-charged

bifunctional MNPs samples. The resulted suspensions were shaken for 20 h at room temperature.

After the first stage of immobilization, the proteins adsorbed nonspecifically were removed by

washing first with low salt buffer (1 mL, 30 mM KCl, 50 mM HEPES, pH 7.5), and then with high salt

buffer (1 mL, 300 mM KCl, 50 mM HEPES, pH 7.5) solutions. Next, the non-covalently bonded His-

tagged proteins were removed from the cobalt(II)-charged MNPs by washing with an imidazole

solution (1 mL, 500 mM in low salt buffer). Finally, the immobilized PcPAL biocatalysts were washed

with TRIS buffer (3× 1 mL, 100 mM, pH 8.8) and were tested directly in the ammonia elimination

reaction. In the case of two selected surface modified supports (MNPs-NPDGE/EDTA DA-10 and

MNPs-THPMTGE/EDTA DA-10),

a scale-up of the immobilization was performed (see

Supplementary materials Section 3.2.).

3

.5. Activity of the Immobilized PcPAL Biocatalysts in the Ammonia Elimination of L-Phenylalanine

In 4 mL screw cap glass vial L-phenylalanine solution (2 mL, 10 mM L-PHE in 100 mM TRIS, pH

.8) was added to the PcPAL-MNPs biocatalyst (5 mg) and the resulted suspension was shaken at 600

8

rpm, 30 °C. After 30 min and 60 min samples (50 µL, each) were taken and diluted to 1 mL with

distillated water and the absorbance of the samples was measured at 290 nm.

Conversion of L-phenylalanine to trans-cinnamic acid was determined from the measured

concentration of cinnamic acid at 290 nm by using the Lambert-Beer equation. To characterize the

productivity of the PcPAL-MNPs biocatalysts, the specific biocatalytic activity was calculated using

the equation U

time and m [g] is the mass of the applied biocatalyst; in case of the cell lysate m

from the total protein concentration). The specific enzyme activity was calculated using the equation

= U /m (where m [g] is the mass of the PcPAL in the applied biocatalyst; in case of the cell lysatem

g] was calculated from the determined PcPAL concentration of the lysate). Activity yield was

calculated using the equation Y = 100 × U (cat)/U (lys) (where U (cat) is the U of the biocatalyst and

(lys) is the U of the cell lysate). To determine m , the activity of the crude cell lysate was measured

B

= nP

/(t × m

B

) (where n

P

[µmol] is the amount of the product, t [min] is the reaction

B

[g] was calculated

UE

B

E

[

A

E

U

E

before and after the immobilization process as well as the imidazole elution fractions during the

washing steps (for representing activity measurement see the Supplementary materials, Section 3.3.).

4

. Conclusions

In this study an effective immobilization strategy that does not require preliminary protein

purification steps has been developed by the creation of optimized compositions of mixed epoxy-

chelate functionalized magnetic nanoparticles. Our results with the selective immobilization of

parsley phenylalanine ammonia-lyase fused to a poly-histidine tag proved that this method is

especially useful for the immobilization of a target enzyme from a crude lysate without the need of

purification even if the enzyme is expressed at a low level. We believe, that our flexible method

enabling the variation and fine-tuning of the covalent linker offers a good opportunity for effective

and selective one-step purification and immobilization of further sensitive, or hard-to-purify

enzymes decorated with a proper metal binding affinity tag.

Supplementary materials: The following are available online at www.mdpi.com/xxx/s1, Figure S1.

Representative HPLC chromatogram from the separation of D,L-phenylalanine and trans-cinnamic acid; Figure

S2. Representative HPLC chromatogram from the separation of D- and L-phenylalanine; Figure S3. Monitoring

the selective immobilization of PcPAL (78 kDa, green framed) onto cobalt contained bifunctional magnetic

nanoparticles by SDS-PAGE; Figure S4. Monitoring the selective immobilization of PcPAL onto cobalt contained

bifunctional magnetic nanoparticles; Table S1. Estimation of immobilized target protein quantity based on the

activity values were measured during the immobilization process.

Molecules 2019, 24, 4146

16 of 23

Author Contributions: E.S.-B., D.B.-W. and L.P. conceived and designed the experiments; Z.M. and A.V. carried

out the fermentation and purification of phenylalanine ammonia lyase, E.S.-B. and F.N. performed the

immobilization experiments and activity measurements; A.V. carried out the HPLC measurements, E.S.-B., D.B.-

W. G.H., C.P. and L.P. analyzed the data and wrote the article.

Funding: This work was supported NKFI (Budapest, Hungary; SNN-125637) and by the Higher Education

Excellence Program of the Ministry of Human Capacities (Budapest, Hungary) in the frame of Biotechnology

research area of Budapest University of Technology and Economics (BME FIKP-BIO). CP and LP thank the COST

Action SysBiocat (CM 1303) and project NEMSyB, ID P37_273, Cod MySMIS 103413 [funded by National

Authority for Scientific Research and Innovation (ANCSI, Bucharest, Romania) and European Regional

Development Fund, Competitiveness Operational Program 2014-2020 (POC), Priority axis 1, Action 1.1] for

support.

Acknowledgments: This work was supported by National Talent Program of Ministry of Human Capacities

(NTP-NFTÖ-18-B-0379).

Conflicts of Interest: SynBiocat Ltd. has interest in commercialization of supports for enzyme immobilization

and immobilized biocatalysts. Besides that, the authors declare no conflict of interest. The funders had no role

in the design of the study; in the collection, analyses, or interpretation of data; in the writing of the manuscript,

or in the decision to publish the results.

References

1.

2.

3.

Woodley, J.M. Accelerating the implementation of biocatalysis in industry. Appl. Microbiol. Biotechnol. 2019,

03, 4733–4739; doi:10.1007/s00253-019-09796-x.

Chapman, J.; Ismail, A.E.; Dinu, C.Z. Industrial Applications of Enzymes: Recent Advances, Techniques,

and Outlooks. Catalysts 2018, 8, 238; doi:10.3390/catal8060238.

Devine, P.N.; Howard, R.M.; Kumar, R.; Thompson, M.P.; Truppo, M.D.; Turner, N.J. Extending the

application of biocatalysis to meet the challenges of drug development. Nat. Rev. Chem. 2018, 2, 409–421;

doi:10.1038/s41570-018-0055-1.

1

4

5

6

7

8

9

1

.

Choi, J.-M.; Han, S.-S.; Kim, H.-S. Industrial applications of enzyme biocatalysis: Current status and future

aspects. Biotechnol. Adv. 2015, 33, 1443–1454; doi:10.1016/j.biotechadv.2015.02.014.

Ghanem, A. Trends in lipase-catalyzed asymmetric access to enantiomerically pure/enriched compounds.

Tetrahedron 2007, 63, 1721–1754; doi:10.1016/j.tet.2006.09.110.

de Miranda, A.S.; Miranda, L.S.M.; de Souza, R.O.M.A. Lipases: Valuable catalysts for dynamic kinetic

resolutions. Biotechnol. Adv. 2015, 33, 372–393; doi:10.1016/j.biotechadv.2015.02.015.

Zhang, X.-Y.; Xu, Z.-H.; Zong, M.-H.; Wang, C.-F.; Li, N. Selective Synthesis of Furfuryl Alcohol from

Biomass-Derived Furfural Using Immobilized Yeast Cells. Catalysts 2019, 9, 70; doi:10.3390/catal9010070.

Martín-Matute, B.; Bäckvall, J.-E. Dynamic kinetic resolution catalyzed by enzymes and metals. Curr. Opin.

Chem. Biol. 2007, 11, 226–232; doi:10.1016/j.cbpa.2007.01.724.

Zhu, S.; Zheng, G. Dynamic kinetic resolution of Vince lactam catalyzed by γ-lactamases: A mini-review.

J. Ind. Microbiol. Biotechnol. 2018, 45, 1017–1031; doi:10.1007/s10295-018-2093-6.

0. Tian, W.; Sun, C.; Zheng, M.; Harmer, J.R.; Yu, M.; Zhang, Y.; Peng, H.; Zhu, D.; Deng, Z.; Chen, S.-L.; et al.

Efficient biosynthesis of heterodimeric C3-aryl pyrroloindoline alkaloids. Nat. Commun. 2018, 9, 4428;

doi:10.1038/s41467-018-06528-z.

1

1. Venkataraman, H.; te Poele, E.M.; Rosłoniec, K.Z.; Vermeulen, N.; Commandeur, J.N.M.; van der Geize, R.;

Dijkhuizen, L. Biosynthesis of a steroid metabolite by an engineered Rhodococcus erythropolis strain

expressing a mutant cytochrome P450 BM3 enzyme. Appl. Microbiol. Biotechnol. 2015, 99, 4713–4721;

doi:10.1007/s00253-014-6281-7.

1

2. Putkaradze, N.; Kiss, F.M.; Schmitz, D.; Zapp, J.; Hutter, M.C.; Bernhardt, R. Biotransformation of

prednisone and dexamethasone by cytochrome P450 based systems – Identification of new potential drug

candidates. J. Biotechnol. 2017, 242, 101–110; doi:10.1016/j.jbiotec.2016.12.011.

3. Xiong, S.; Wang, Y.; Yao, M.; Liu, H.; Zhou, X.; Xiao, W.; Yuan, Y. Cell foundry with high product specificity

and catalytic activity for 21-deoxycortisol biotransformation. Microb. Cell Fact. 2017, 16, 105;

doi:10.1186/s12934-017-0720-y.

4. Morlock, L.K.; Grobe, S.; Balke, K.; Mauersberger, S.; Böttcher, D.; Bornscheuer, U.T. Protein Engineering

of the Progesterone Hydroxylating P450-Monooxygenase CYP17A1 Alters Its Regioselectivity.

ChemBioChem 2018, 19, 1954–1958; doi:10.1002/cbic.201800371.

Molecules 2019, 24, 4146

17 of 23

1

5. Lee, J.H.; Han, K.; Kim, M.-J.; Park, J. Chemoenzymatic Dynamic Kinetic Resolution of Alcohols and

Amines. European J. Org. Chem. 2010, 2010, 999–1015; doi:10.1002/ejoc.200900935.

6. Kim, Y.; Park, J.; Kim, M.-J. Dynamic Kinetic Resolution of Amines and Amino Acids by Enzyme-Metal

Cocatalysis. ChemCatChem 2011, 3, 271–277; doi:10.1002/cctc.201000330.

7. Kourist, R.; Bornscheuer, U.T. Biocatalytic synthesis of optically active tertiary alcohols. Appl. Microbiol.

Biotechnol. 2011, 91, 505–517; doi:10.1007/s00253-011-3418-9.

8. Weiser, D.; Nagy, F.; Bánóczi, G.; Oláh, M.; Farkas, A.; Szilágyi, A.; László, K.; Gellért, Á.; Marosi, G.;

Kemény, S.; et al. Immobilization engineering – How to design advanced sol–gel systems for biocatalysis?

Green Chem. 2017, 19, 3927–3937; doi:10.1039/C7GC00896A.

1

2

9. Farkas, E.; Oláh, M.; Földi, A.; Kóti, J.; Éles, J.; Nagy, J.; Gal, C.A.; Paizs, C.; Hornyánszky, G.; Poppe, L.

Chemoenzymatic Dynamic Kinetic Resolution of Amines in Fully Continuous-Flow Mode. Org. Lett. 2018,

20, 8052–8056; doi:10.1021/acs.orglett.8b03676.

0. Xing, X.; Jia, J.-Q.; Zhang, J.-F.; Zhou, Z.-W.; Li, J.; Wang, N.; Yu, X.-Q. CALB Immobilized onto Magnetic

Nanoparticles for Efficient Kinetic Resolution of Racemic Secondary Alcohols: Long-Term Stability and

Reusability. Molecules 2019, 24, 490; doi:10.3390/molecules24030490.

1. Oláh, M.; Suba, S.; Boros, Z.; Kovács, P.; Gosselin, M.; Gaudreault, C.; Hornyánszky, G. Lipase B from

Candida antarctica Immobilized on Epoxy-functionalized Hollow Silica Microspheres: Efficient Biocatalysts

for Enantiomer Selective Acylation of Alcohols and Amines. Period. Polytech. Chem. Eng. 2018, 62, 519–532;

doi:10.3311/PPch.12517.

2

2. Moustafa, G.A.I.; Kasama, K.; Higashio, K.; Akai, S. Base-promoted lipase-catalyzed kinetic resolution of

atropisomeric 1,1′-biaryl-2,2′-diols. RSC Adv. 2019, 9, 1165–1175; doi:10.1039/C8RA09070J.

3. Riva, S. Laccases: Blue enzymes for green chemistry. Trends Biotechnol. 2006, 24, 219–226;

doi:10.1016/j.tibtech.2006.03.006.

4. Sokic-Lazic, D.; Arechederra, R.L.; Treu, B.L.; Minteer, S.D. Oxidation of Biofuels: Fuel Diversity and

Effectiveness of Fuel Oxidation through Multiple Enzyme Cascades. Electroanalysis 2010, 22, 757–764;

doi:10.1002/elan.200980010.

2

5. Mitsou, E.; Xenakis, A.; Zoumpanioti, M. Oxidation Catalysis by Enzymes in Microemulsions. Catalysts

2

017, 7, 52; doi:10.3390/catal7020052.

6. Hollmann, F.; Arends, I.W.C.E.; Holtmann, D. Enzymatic reductions for the chemist. Green Chem. 2011, 13,

285–2313; doi:10.1039/c1gc15424a.

2

7. Durchschein, K.; Hall, M.; Faber, K. Unusual reactions mediated by FMN-dependent ene- and nitro-

reductases. Green Chem. 2013, 15, 1764–1772; doi:10.1039/c3gc40588e.

8. Schrittwieser, J.H.; Velikogne, S.; Kroutil, W. Biocatalytic Imine Reduction and Reductive Amination of

Ketones. Adv. Synth. Catal. 2015, 357, 1655–1685; doi:10.1002/adsc.201500213.

9. Bódai, V.; Nagy-Győr, L.; Örkényi, R.; Molnár, Z.; Kohári, S.; Erdélyi, B.; Nagymáté, Z.; Romsics, C.; Paizs,

C.; Poppe, L.; et al. Wickerhamomyces subpelliculosus as whole-cell biocatalyst for stereoselective bioreduction

of ketones. J. Mol. Catal. B Enzym. 2016, 134, 206–214; doi:10.1016/j.molcatb.2016.11.003.

0. Fuchs, M.; Farnberger, J.E.; Kroutil, W. The Industrial Age of Biocatalytic Transamination. European J. Org.

Chem. 2015, 2015, 6965–6982; doi:10.1002/ejoc.201500852.

3

1. Liu, J.; Wu, S.; Li, Z. Recent advances in enzymatic oxidation of alcohols. Curr. Opin. Chem. Biol. 2018, 43,

77–86; doi:10.1016/j.cbpa.2017.12.001.

2. Nagy-Győr, L.; Abaházi, E.; Bódai, V.; Sátorhelyi, P.; Erdélyi, B.; Balogh-Weiser, D.; Paizs, C.; Hornyánszky,

G.; Poppe, L. Co-immobilized Whole Cells with ω-Transaminase and Ketoreductase Activities for

Continuous-Flow Cascade Reactions. ChemBioChem 2018, 19, 1845–1848; doi:10.1002/cbic.201800286.

3. Guo, F.; Berglund, P. Transaminase biocatalysis: Optimization and application. Green Chem. 2017, 19, 333–

3

360; doi:10.1039/C6GC02328B.

4. D. Patil, M.; Grogan, G.; Bommarius, A.; Yun, H. Recent Advances in ω-Transaminase-Mediated

Biocatalysis for the Enantioselective Synthesis of Chiral Amines. Catalysts 2018, 8, 254;

doi:10.3390/catal8070254.

35. Lenz, M.; Borlinghaus, N.; Weinmann, L.; Nestl, B.M. Recent advances in imine reductase-catalyzed

reactions. World J. Microbiol. Biotechnol. 2017, 33, 199; doi:10.1007/s11274-017-2365-8.

36. Liu, J.; Li, Z. Enhancing cofactor recycling in the bioconversion of racemic alcohols to chiral amines with

alcohol dehydrogenase and amine dehydrogenase by coupling cells and cell-free system. Biotechnol. Bioeng.

2019, 116, 536–542; doi:10.1002/bit.26896.

Molecules 2019, 24, 4146

18 of 23

3

7. Varga, A.; Bánóczi, G.; Nagy, B.; Bencze, L.C.; Toşa, M.I.; Gellért, Á.; Irimie, F.D.; Rétey, J.; Poppe, L.; Paizs,

C. Influence of the aromatic moiety in α- and β-arylalanines on their biotransformation with phenylalanine

,3-aminomutase from Pantoea agglomerans. RSC Adv. 2016, 6, 56412–56420; doi:10.1039/C6RA02964G.

8. Xue, Y.-P.; Cao, C.-H.; Zheng, Y.-G. Enzymatic asymmetric synthesis of chiral amino acids. Chem. Soc. Rev.

018, 47, 1516–1561; doi:10.1039/C7CS00253J.

2

3

4

2

9. Gao, X.; Ma, Q.; Zhu, H. Distribution, industrial applications, and enzymatic synthesis of D -amino acids.

Appl. Microbiol. Biotechnol. 2015, 99, 3341–3349; doi:10.1007/s00253-015-6507-3.

0. Rosenthal, K.; Lütz, S. Recent developments and challenges of biocatalytic processes in the pharmaceutical

industry. Curr. Opin. Green Sustain. Chem. 2018, 11, 58–64; doi:10.1016/j.cogsc.2018.03.015.

1. Kristinsson, H.G.; Rasco, B.A. Fish Protein Hydrolysates: Production, Biochemical, and Functional

Properties. Crit. Rev. Food Sci. Nutr. 2000, 40, 43–81; doi:10.1080/10408690091189266.

2. Leroy, F.; De Vuyst, L. Lactic acid bacteria as functional starter cultures for the food fermentation industry.

Trends Food Sci. Technol. 2004, 15, 67–78; doi:10.1016/j.tifs.2003.09.004.

3. Amine, A.; Mohammadi, H.; Bourais, I.; Palleschi, G. Enzyme inhibition-based biosensors for food safety

and environmental monitoring. Biosens. Bioelectron. 2006, 21, 1405–1423; doi:10.1016/j.bios.2005.07.012.

4. Czinkóczky, R.; Németh, Á. Investigations into Enzymatic Bioconversion to Form Rebaudioside A from

Stevioside. Period. Polytech. Chem. Eng. 2018, 62, 396–402; doi:10.3311/PPch.12673.

5. Araya, E.; Urrutia, P.; Romero, O.; Illanes, A.; Wilson, L. Design of combined crosslinked enzyme

aggregates (combi-CLEAs) of β-galactosidase and glucose isomerase for the one-pot production of fructose

syrup from lactose. Food Chem. 2019, 288, 102–107; doi:10.1016/j.foodchem.2019.02.024.

6. Straathof, A.J..; Panke, S.; Schmid, A. The production of fine chemicals by biotransformations. Curr. Opin.

Biotechnol. 2002, 13, 548–556; doi:10.1016/S0958-1669(02)00360-9.

4

7. Panke, S.; Held, M.; Wubbolts, M. Trends and innovations in industrial biocatalysis for the production of

fine chemicals. Curr. Opin. Biotechnol. 2004, 15, 272–279; doi:10.1016/j.copbio.2004.06.011.

8. Thompson, M.P.; Peñafiel, I.; Cosgrove, S.C.; Turner, N.J. Biocatalysis Using Immobilized Enzymes in

Continuous Flow for the Synthesis of Fine Chemicals. Org. Process Res. Dev. 2019, 23, 9–18;

doi:10.1021/acs.oprd.8b00305.

4

5

9. Lee, L.J.; Yang, S.; Lai, S.; Bai, Y.; Huang, W.; Juang, Y. Microfluidic Enzyme-Linked Immunosorbent Assay

Technology. In Advances in Clinical Chemistry; 2006; Vol. 42, pp. 255–295 ISBN 0120103427.

0. Haun, J.B.; Yoon, T.-J.; Lee, H.; Weissleder, R. Magnetic nanoparticle biosensors. Wiley Interdiscip. Rev.

Nanomedicine Nanobiotechnology 2010, 2, 291–304; doi:10.1002/wnan.84.

1. de la Rica, R.; Aili, D.; Stevens, M.M. Enzyme-responsive nanoparticles for drug release and diagnostics.

Adv. Drug Deliv. Rev. 2012, 64, 967–978; doi:10.1016/j.addr.2012.01.002.

2. El Harrad, L.; Bourais, I.; Mohammadi, H.; Amine, A. Recent Advances in Electrochemical Biosensors

Based on Enzyme Inhibition for Clinical and Pharmaceutical Applications. Sensors 2018, 18, 164;

doi:10.3390/s18010164.

53. Nguyen, H.H.; Lee, S.H.; Lee, U.J.; Fermin, C.D.; Kim, M. Immobilized Enzymes in Biosensor Applications.

Materials (Basel). 2019, 12, 121; doi:10.3390/ma12010121.

5

4. Dror, A.; Kanteev, M.; Kagan, I.; Gihaz, S.; Shahar, A.; Fishman, A. Structural insights into methanol-stable

variants of lipase T6 from Geobacillus stearothermophilus. Appl. Microbiol. Biotechnol. 2015, 99, 9449–9461;

doi:10.1007/s00253-015-6700-4.

5

5. Gihaz, S.; Weiser, D.; Dror, A.; Sátorhelyi, P.; Jerabek-Willemsen, M.; Poppe, L.; Fishman, A. Creating an

Efficient Methanol-Stable Biocatalyst by Protein and Immobilization Engineering Steps towards Efficient

Biosynthesis of Biodiesel. ChemSusChem 2016, 9, 3161–3170; doi:10.1002/cssc.201601158.

6. Douka, A.; Vouyiouka, S.; Papaspyridi, L.-M.; Papaspyrides, C.D. A review on enzymatic polymerization

to produce polycondensation polymers: The case of aliphatic polyesters, polyamides and polyesteramides.

Prog. Polym. Sci. 2018, 79, 1–25; doi:10.1016/j.progpolymsci.2017.10.001.

5

7. Su, J.; Wang, C.; Noro, J.; Cavaco-Paulo, A.; Silva, C.; Fu, J. Polymers from Bamboo Extracts Produced by

Laccase. Polymers (Basel). 2018, 10, 1141; doi:10.3390/polym10101141.

8. Jiang, Y.; Loos, K. Enzymatic Synthesis of Biobased Polyesters and Polyamides. Polymers (Basel). 2016, 8,

243; doi:10.3390/polym8070243.

9. Rokhati, N.; Susanto, H.; Haryani, K.; Pramudono, B. Enhanced Enzymatic Hydrolysis of Chitosan by

Surfactant Addition. Period. Polytech. Chem. Eng. 2017, 62, 286–291; doi:10.3311/PPch.11142.

Molecules 2019, 24, 4146

19 of 23

60. Gong, J.; Kong, T.; Li, Y.; Li, Q.; Li, Z.; Zhang, J. Biodegradation of Microplastic Derived from Poly(ethylene

terephthalate) with Bacterial Whole-Cell Biocatalysts. Polymers (Basel). 2018, 10, 1326;

doi:10.3390/polym10121326.

6

1. Blackwell, C.; Haernvall, K.; Guebitz, G.; Groombridge, M.; Gonzales, D.; Khosravi, E. Enzymatic

Degradation of Star Poly(ε-Caprolactone) with Different Central Units. Polymers (Basel). 2018, 10, 1266;

doi:10.3390/polym10111266.

th

62. Poppe, L.; Vértessy, B.G. The Fourth Wave of Biocatalysis Emerges–The 13 International Symposium on

Biocatalysis and Biotransformations. ChemBioChem 2018, 19, 284–287; doi:10.1002/cbic.201700687.

3. Amid, A.; Hassan, N.; Jamaluddin, M.J.A.; Othman, M.E.F.; Belgasem, F.F. Ben; Salleh, H.M.; Yusof, F.;

Ismail, N.A.; Azmi, A.S.; Sulaiman, S.; et al. Recombinant Enzymes - From Basic Science to Commercialization;

Amid, A., Ed.; Springer International Publishing: Heilderberg, 2015; ISBN 978-3-319-12396-7.

4. Young, C.L.; Britton, Z.T.; Robinson, A.S. Recombinant protein expression and purification: A

comprehensive review of affinity tags and microbial applications. Biotechnol. J. 2012, 7, 620–634;

doi:10.1002/biot.201100155.

6

5. Terpe, K. Overview of tag protein fusions: From molecular and biochemical fundamentals to commercial

systems. Appl. Microbiol. Biotechnol. 2003, 60, 523–533; doi:10.1007/s00253-002-1158-6.

6. Rosano, G.L.; Ceccarelli, E.A. Recombinant protein expression in Escherichia coli: Advances and challenges.

Front. Microbiol. 2014, 5, 1–17; doi:10.3389/fmicb.2014.00172.

7. Vahidi, A.K.; Yang, Y.; Ngo, T.P.N.; Li, Z. Simple and Efficient Immobilization of Extracellular His-Tagged

Enzyme Directly from Cell Culture Supernatant As Active and Recyclable Nanobiocatalyst: High-

Performance Production of Biodiesel from Waste Grease. ACS Catal. 2015, 5, 3157–3161;

doi:10.1021/acscatal.5b00550.

68. Peternel, Š. Bacterial cell disruption: A crucial step in protein production. N. Biotechnol. 2013, 30, 250–254;

doi:10.1016/j.nbt.2011.09.005.

6

9. Liu, D.; Ding, L.; Sun, J.; Boussetta, N.; Vorobiev, E. Yeast cell disruption strategies for recovery of

intracellular bio-active compounds—A review. Innov. Food Sci. Emerg. Technol. 2016, 36, 181–192;

doi:10.1016/j.ifset.2016.06.017.

7

0. Shehadul Islam, M.; Aryasomayajula, A.; Selvaganapathy, P.R. A Review on Macroscale and Microscale

Cell Lysis Methods. Micromachines 2017, 8, 83; doi:10.3390/mi8030083.

1. Hatti-Kaul, R.; Mattiasson, B. Isolation and purification of proteins; Hatti-Kaul, R., Mattiasson, B., Eds.; Marcel

Dekker, Inc.: New York, 2012; ISBN 0824707265.

2. Waugh, D.S. An overview of enzymatic reagents for the removal of affinity tags. Protein Expr. Purif. 2011,

80, 283–293; doi:10.1016/j.pep.2011.08.005.

3. Kranen, E.; Detzel, C.; Weber, T.; Jose, J. Autodisplay for the co-expression of lipase and foldase on the

surface of E. coli: Washing with designer bugs. Microb. Cell Fact. 2014, 13, 19; doi:10.1186/1475-2859-13-19.

4. Li, X.; Jin, X.; Lu, X.; Chu, F.; Shen, J.; Ma, Y.; Liu, M.; Zhu, J. Construction and characterization of a

thermostable whole-cell chitinolytic enzyme using yeast surface display. World J. Microbiol. Biotechnol. 2014,

30, 2577–2585; doi:10.1007/s11274-014-1681-5.

7

5. Saraswat, M.; Musante, L.; Ravidá, A.; Shortt, B.; Byrne, B.; Holthofer, H. Preparative Purification of

Recombinant Proteins: Current Status and Future Trends. Biomed Res. Int. 2013, 2013, 1–18;

doi:10.1155/2013/312709.

7

8

6. Stolarzewicz, I.; Białecka-Florjańczyk, E.; Majewska, E.; Krzyczkowska, J. Immobilization of Yeast on

Polymeric Supports. Chem. Biochem. Eng. Q. 2011, 25, 135–144.

7. Kisukuri, C.M.; Andrade, L.H. Production of chiral compounds using immobilized cells as a source of

biocatalysts. Org. Biomol. Chem. 2015, 13, 10086–10107; doi:10.1039/C5OB01677K.

8. Melvik, J.E.; Dornish, M. Alginate as a Carrier for Cell Immobilisation. In Fundamentals of Cell Immobilisation

Biotechnology; Nedović, V., Willaert, R., Eds.; Springer: Dordrecht, 2004; pp. 33–51 ISBN 978-94-017-1638-3.

9. Michelini, E.; Roda, A. Staying alive: New perspectives on cell immobilization for biosensing purposes.

Anal. Bioanal. Chem. 2012, 402, 1785–1797; doi:10.1007/s00216-011-5364-x.

0. Krajewska, B. Application of chitin- and chitosan-based materials for enzyme immobilizations: A review.

Enzyme Microb. Technol. 2004, 35, 126–139; doi:10.1016/j.enzmictec.2003.12.013.

1. Carballeira, J.D.; Quezada, M.A.; Hoyos, P.; Simeó, Y.; Hernaiz, M.J.; Alcantara, A.R.; Sinisterra, J.V.

Microbial cells as catalysts for stereoselective red–ox reactions. Biotechnol. Adv. 2009, 27, 686–714;

doi:10.1016/j.biotechadv.2009.05.001.

Molecules 2019, 24, 4146

20 of 23

8

2. Zajkoska, P.; Rebroš, M.; Rosenberg, M. Biocatalysis with immobilized Escherichia coli. Appl. Microbiol.

Biotechnol. 2013, 97, 1441–1455; doi:10.1007/s00253-012-4651-6.

3. Desimone, M.F.; Alvarez, G.S.; Foglia, M.L.; Diaz, L.E. Development of Sol-Gel Hybrid Materials for Whole

Cell Immobilization. Recent Pat. Biotechnol. 2009, 3, 55–60; doi:10.2174/187220809787172605.

4. Desimone, M.F.; De Marzi, M.C.; Copello, G.J.; Fernández, M.M.; Malchiodi, E.L.; Diaz, L.E. Efficient

preservation in a silicon oxide matrix of Escherichia coli, producer of recombinant proteins. Appl. Microbiol.

Biotechnol. 2005, 68, 747–752; doi:10.1007/s00253-005-1912-7.

85. Silva, C.R.; Airoldi, C. Acid and Base Catalysts in the Hybrid Silica Sol–Gel Process. J. Colloid Interface Sci.

1997, 195, 381–387; doi:10.1006/jcis.1997.5159.

8

6. Kato, K.; Nakamura, H.; Nakanishi, K. Asymmetric bioreduction of acetophenones by Baker’s yeast and its

cell-free extract encapsulated in sol–gel silica materials. Appl. Surf. Sci. 2014, 293, 312–317;

doi:10.1016/j.apsusc.2013.12.160.

8

7. Klein, S.; Kuhn, J.; Avrahami, R.; Tarre, S.; Beliavski, M.; Green, M.; Zussman, E. Encapsulation of Bacterial

Cells in Electrospun Microtubes. Biomacromolecules 2009, 10, 1751–1756; doi:10.1021/bm900168v.

8. Salalha, W.; Kuhn, J.; Dror, Y.; Zussman, E. Encapsulation of bacteria and viruses in electrospun nanofibres.

Nanotechnology 2006, 17, 4675–4681; doi:10.1088/0957-4484/17/18/025.

9. Gensheimer, M.; Becker, M.; Brandis-Heep, A.; Wendorff, J.H.; Thauer, R.K.; Greiner, A. Novel Biohybrid

Materials by Electrospinning: Nanofibers of Poly(ethylene oxide) and Living Bacteria. Adv. Mater. 2007, 19,

2480–2482; doi:10.1002/adma.200602936.

9

0. Zussman, E. Encapsulation of cells within electrospun fibers. Polym. Adv. Technol. 2011, 22, 366–371;

doi:10.1002/pat.1812.

1. Brosel-Oliu, S.; Mergel, O.; Uria, N.; Abramova, N.; van Rijn, P.; Bratov, A. 3D impedimetric sensors as a

tool for monitoring bacterial response to antibiotics. Lab Chip 2019, 19, 1436–1447; doi:10.1039/C8LC01220B.

2. Jin, L.-Q.; Yang, B.; Xu, W.; Chen, X.-X.; Jia, D.-X.; Liu, Z.-Q.; Zheng, Y.-G. Immobilization of recombinant

Escherichia coli whole cells harboring xylose reductase and glucose dehydrogenase for xylitol production

from xylose mother liquor. Bioresour. Technol. 2019, 285, 121344; doi:10.1016/j.biortech.2019.121344.

3. Qiu, S.; Wang, Y.-J.; Yu, H.; Cheng, F.; Zheng, Y.-G. t-Butyl 6-cyano-(3R,5R)-dihydroxyhexanoate synthesis

via asymmetric reduction by immobilized cells of carbonyl reductase and glucose dehydrogenase co-

expression E. coli. Process Biochem. 2019, 80, 43–51; doi:10.1016/j.procbio.2019.02.019.

9

4. Stojkovič, G.; Žnidaršič-Plazl, P. Continuous synthesis of L-malic acid using whole-cell microreactor.

Process Biochem. 2012, 47, 1102–1107; doi:10.1016/j.procbio.2012.03.023.

5. Zehnder, T.; Sarker, B.; Boccaccini, A.R.; Detsch, R. Evaluation of an alginate–gelatine crosslinked hydrogel

for bioplotting. Biofabrication 2015, 7, 25001; doi:10.1088/1758-5090/7/2/025001.

6. Thakur, A.; Panesar, P.S.; Saini, M.S. Parametric Optimization of Lactic Acid Production by Immobilized

Lactobacillus casei Using Box-Behnken Design. Period. Polytech. Chem. Eng. 2018, 62, 274–285;

doi:10.3311/PPch.11403.

97. Mateo, C.; Palomo, J.M.; Fernandez-Lorente, G.; Guisan, J.M.; Fernandez-Lafuente, R. Improvement of

enzyme activity, stability and selectivity via immobilization techniques. Enzyme Microb. Technol. 2007, 40,

1451–1463; doi:10.1016/j.enzmictec.2007.01.018.

98. Taqieddin, E.; Amiji, M. Enzyme immobilization in novel alginate–chitosan core-shell microcapsules.

Biomaterials 2004, 25, 1937–1945; doi:10.1016/j.biomaterials.2003.08.034.

99. Sóti, P.L.; Weiser, D.; Vigh, T.; Nagy, Z.K.; Poppe, L.; Marosi, G. Electrospun polylactic acid and polyvinyl

alcohol fibers as efficient and stable nanomaterials for immobilization of lipases. Bioprocess Biosyst. Eng.

2016, 39, 449–459; doi:10.1007/s00449-015-1528-y.

100. Krisch, E.; Balogh-Weiser, D.; Klimko, J.; Gyarmati, B.; Laszlo, K.; Poppe, L.; Szilagyi, A. Composite beads

of silica gel, alginate and poly(aspartic acid) for the immobilization of a lipase enzyme. Express Polym. Lett.

2019, 13, 512–523; doi:10.3144/expresspolymlett.2019.43.

1

01. Teepoo, S.; Dawan, P.; Barnthip, N. Electrospun Chitosan-Gelatin Biopolymer Composite Nanofibers for

Horseradish Peroxidase Immobilization in a Hydrogen Peroxide Biosensor. Biosensors 2017, 7, 47;

doi:10.3390/bios7040047.

102. Jesionowski, T.; Zdarta, J.; Krajewska, B. Enzyme immobilization by adsorption: A review. Adsorption 2014,

20, 801–821; doi:10.1007/s10450-014-9623-y.

103. Boros, Z.; Weiser, D.; Márkus, M.; Abaháziová, E.; Magyar, Á.; Tomin, A.; Koczka, B.; Kovács, P.; Poppe, L.

Hydrophobic adsorption and covalent immobilization of Candida antarctica lipase B on mixed-function-

Molecules 2019, 24, 4146

21 of 23

grafted silica gel supports for continuous-flow biotransformations. Process Biochem. 2013, 48, 1039–1047;

doi:10.1016/j.procbio.2013.05.002.

1

04. Weiser, D.; Varga, A.; Kovács, K.; Nagy, F.; Szilágyi, A.; Vértessy, B.G.; Paizs, C.; Poppe, L. Bisepoxide

Cross-Linked Enzyme Aggregates-New Immobilized Biocatalysts for Selective Biotransformations.

ChemCatChem 2014, 6, 1463–1469; doi:10.1002/cctc.201300806.

1

05. Vazquez-Ortega, P.G.; Alcaraz-Fructuoso, M.T.; Rojas-Contreras, J.A.; López-Miranda, J.; Fernandez-

Lafuente, R. Stabilization of dimeric β-glucosidase from Aspergillus niger via glutaraldehyde

immobilization under different conditions. Enzyme Microb. Technol. 2018, 110, 38–45;

doi:10.1016/j.enzmictec.2017.12.007.

1

06. Turková, J.; Bláha, K.; Malaníková, M.; Vančurová, D.; Švec, F.; Kálal, J. Methacrylate gels with epoxide

groups as supports for immobilization of enzymes in pH range 3-12. Biochim. Biophys. Acta 1978, 524, 162–

169; doi:10.1016/0005-2744(78)90114-6.

07. Abaházi, E.; Lestál, D.; Boros, Z.; Poppe, L. Tailoring the Spacer Arm for Covalent Immobilization of

Candida antarctica Lipase B—Thermal Stabilization by Bisepoxide-Activated Aminoalkyl Resins in

Continuous-Flow Reactors. Molecules 2016, 21, 767; doi:10.3390/molecules21060767.

08. Guisan, J.M.; López-Gallego, F.; Betancor, L.; Mateo, C.; Grazu, V.; Fernandez-Lorente, G.; Rocha-Martin,

rd

J.; Bolivar, J.M.; Ovsejevi, K.; Manta, C.; et al. Immobilization of Enzymes and Cells, 3 Ed. (Methods in Molecular

Biology, Vol. 1051); Guisan, J.M., Ed.; Humana Press: Totowa, NJ, 2013; ISBN 978-1-62703-549-1.

09. Mateo, C.; Fernández-Lorente, G.; Abian, O.; Fernández-Lafuente, R.; Guisán, J.M. Multifunctional Epoxy

Supports: A New Tool to Improve the Covalent Immobilization of Proteins. The Promotion of Physical

Adsorptions of Proteins on the Supports before Their Covalent Linkage. Biomacromolecules 2000, 1, 739–745;

doi:10.1021/bm000071q.

1

10. Mateo, C.; Bolivar, J.M.; Godoy, C.A.; Rocha-Martin, J.; Pessela, B.C.; Curiel, J.A.; Muñoz, R.; Guisan, J.M.;

Fernández-Lorente, G. Improvement of Enzyme Properties with a Two-Step Immobilizaton Process on

Novel Heterofunctional Supports. Biomacromolecules 2010, 11, 3112–3117; doi:10.1021/bm100916r.

11. Mateo, C.; Grazu, V.; Palomo, J.M.; Lopez-Gallego, F.; Fernandez-Lafuente, R.; Guisan, J.M. Immobilization

of enzymes on heterofunctional epoxy supports. Nat. Protoc. 2007, 2, 1022–1033; doi:10.1038/nprot.2007.133.

12. Barbosa, O.; Torres, R.; Ortiz, C.; Berenguer-Murcia, Á.; Rodrigues, R.C.; Fernandez-Lafuente, R.

Heterofunctional Supports in Enzyme Immobilization: From Traditional Immobilization Protocols to

1

Opportunities

in

Tuning

Enzyme

Properties.

Biomacromolecules

2013,

14,

2433–2462;

doi:10.1021/bm400762h.

1

13. Grazú, V.; Abian, O.; Mateo, C.; Batista-Viera, F.; Fernández-Lafuente, R.; Guisán, J.M. Novel bifunctional

epoxy/thiol-reactive support to immobilize thiol containing proteins by the epoxy chemistry.

Biomacromolecules 2003, 4, 1495–1501; doi:10.1021/bm034262f.

14. Grazú, V.; Abian, O.; Mateo, C.; Batista-Viera, F.; Fernández-Lafuente, R.; Guisán, J.M. Stabilization of

enzymes by multipoint immobilization of thiolated proteins on new epoxy-thiol supports. Biotechnol.

Bioeng. 2005, 90, 597–605; doi:10.1002/bit.20452.

15. Manoel, E.A.; dos Santos, J.C.S.; Freire, D.M.G.; Rueda, N.; Fernandez-Lafuente, R. Immobilization of

lipases on hydrophobic supports involves the open form of the enzyme. Enzyme Microb. Technol. 2015, 71,

53–57; doi:10.1016/j.enzmictec.2015.02.001.

16. Barbosa, O.; Ortiz, C.; Torres, R.; Fernandez-Lafuente, R. Effect of the immobilization protocol on the

properties of lipase B from Candida antarctica in organic media: Enantiospecific production of atenolol

acetate. J. Mol. Catal. B Enzym. 2011, 71, 124–132; doi:10.1016/j.molcatb.2011.04.008.

17. Chen, C.-I.; Chen, C.-W.; Huang, C.-W.; Liu, Y.-C. Simultaneous purification and immobilization of

penicillin

G

acylase using bifunctional membrane. J. Memb. Sci. 2007, 298, 24–29;

doi:10.1016/j.memsci.2007.03.054.

18. Tural, B.; Tural, S.; Ertaş, E.; Yalınkılıç, İ.; Demir, A.S. Purification and covalent immobilization of

benzaldehyde lyase with heterofunctional chelate-epoxy modified magnetic nanoparticles and its

carboligation reactivity. J. Mol. Catal. B Enzym. 2013, 95, 41–47; doi:10.1016/j.molcatb.2013.05.023.

19. Alsafadi, D.; Paradisi, F. Covalent Immobilization of Alcohol Dehydrogenase (ADH2) from Haloferax

volcanii: How to Maximize Activity and Optimize Performance of Halophilic Enzymes. Mol. Biotechnol.

2014, 56, 240–247; doi:10.1007/s12033-013-9701-5.

Molecules 2019, 24, 4146

22 of 23

120. Mateo, C.; Fernández-Lorente, G.; Cortés, E.; Garcia, J.L.; Fernández-Lafuente, R.; Guisan, J.M. One-step

purification, covalent immobilization, and additional stabilization of poly-His-tagged proteins using novel

heterofunctional chelate-epoxy supports. Biotechnol. Bioeng. 2001, 76, 269–276; doi:10.1002/bit.10019.

21. Weiser, D.; Bencze, L.C.; Bánóczi, G.; Ender, F.; Kiss, R.; Kókai, E.; Szilágyi, A.; Vértessy, B.G.; Farkas, Ö.;

Paizs, C.; et al. Phenylalanine Ammonia-Lyase-Catalyzed Deamination of an Acyclic Amino Acid: Enzyme

Mechanistic Studies Aided by a Novel Microreactor Filled with Magnetic Nanoparticles. ChemBioChem

1

2015, 16, 2283–2288; doi:10.1002/cbic.201500444.

1

22. Sathishkumar, P.; Kamala-Kannan, S.; Cho, M.; Kim, J.S.; Hadibarata, T.; Salim, M.R.; Oh, B.-T. Laccase

immobilization on cellulose nanofiber: The catalytic efficiency and recyclic application for simulated dye

effluent treatment. J. Mol. Catal. B Enzym. 2014, 100, 111–120; doi:10.1016/j.molcatb.2013.12.008.

23. Bartha-Vári, J.H.; Bencze, L.C.; Bell, E.; Poppe, L.; Katona, G.; Irimie, F.-D.; Paizs, C.; Toșa, M.I. Aminated

Single-walled Carbon Nanotubes as Carrier for Covalent Immobilization of Phenylalanine Ammonia-lyase.

Period. Polytech. Chem. Eng. 2017, 61, 59–66; doi:10.3311/PPch.10417.

24. Barbosa, O.; Ortiz, C.; Berenguer-Murcia, Á.; Torres, R.; Rodrigues, R.C.; Fernandez-Lafuente, R. Strategies

for the one-step immobilization–purification of enzymes as industrial biocatalysts. Biotechnol. Adv. 2015,

33, 435–456; doi:10.1016/j.biotechadv.2015.03.006.

125. Porath, J.; Carlsson, J.; Olsson, I.; Belfrage, G. Metal chelate affinity chromatography, a new approach to

protein fractionation. Nature 1975, 258, 598–599; doi:10.1038/258598a0.

126. Hochuli, E.; Döbeli, H.; Schacher, A. New metal chelate adsorbent selective for proteins and peptides

cotaining neighbouring histidine residues. J. Chromatogr. A 1987, 411, 177–184; doi:10.1016/S0021-

9673(00)93969-4.

1

27. Porath, J.; Olin, B. Immobilized Metal Ion Affinity Adsorption and Immobilized Metal Ion Affinity

Chromatography of Biomaterials. Serum Protein Affinities for Gel-Immobilized Iron and Nickel Ions.

Biochemistry 1983, 22, 1621–1630; doi:10.1021/bi00276a015.

128. Sassenfeld, H.M.; Brewer, S.J. A polypeptide fusion designed for the purification of recombinant proteins.

Bio/Technology 1984, 2, 76–81; doi:10.1038/nbt0184-76.

1

29. Hopp, T.P.; Prickett, K.S.; Price, V.L.; Libby, R.T.; March, C.J.; Cerretti, D.P.; Urdal, D.L.; Conlon, P.J. A

short polypeptide marker sequence useful for recombinant protein identification and purification.

Bio/Technology 1988, 6, 1204–1210; doi:10.1038/nbt1088-1204.

1

30. Korndorfer, I.P.; Skerra, A. Improved affinity of engineered streptavidin for the Strep-tag II peptide is due

to a fixed open conformation of the lid-like loop at the binding site. Protein Sci. 2002, 11, 883–893;

doi:10.1110/ps.4150102.

31. Stofko-Hahn, R.E.; Carr, D.W.; Scott, J.D. A single step purification for recombinant proteins

Characterization of a microtubule associated protein (MAP 2) fragment which associates with the type II

cAMP-dependent protein kinase. FEBS Lett. 1992, 302, 274–278; doi:10.1016/0014-5793(92)80458-S.

32. Tomme, P.; Boraston, A.; McLean, B.; Kormos, J.; Creagh, A.L.; Sturch, K.; Gilkes, N.R.; Haynes, C.A.;

Warren, R.A.J.; Kilburn, D.G. Characterization and affinity applications of cellulose-binding domains. J.

Chromatogr. B Biomed. Sci. Appl. 1998, 715, 283–296; doi:10.1016/S0378-4347(98)00053-X.

33. Keefe, A.D.; Wilson, D.S.; Seelig, B.; Szostak, J.W. One-Step Purification of Recombinant Proteins Using a

Nanomolar-Affinity Streptavidin-Binding Peptide, the SBP-Tag. Protein Expr. Purif. 2001, 23, 440–446;

doi:10.1006/prep.2001.1515.

34. Watanabe, T.; Ito, Y.; Yamada, T.; Hashimoto, M.; Sekine, S.; Tanaka, H. The roles of the C-terminal domain

and type III domains of chitinase A1 from Bacillus circulans WL-12 in chitin degradation. J. Bacteriol. 1994,

176, 4465–4472; doi:10.1128/jb.176.15.4465-4472.1994.

35. Ikeda, T.; Ninomiya, K. ichi; Hirota, R.; Kuroda, A. Single-step affinity purification of recombinant proteins

using the silica-binding Si-tag as

doi:10.1016/j.pep.2009.12.009.

a fusion partner. Protein Expr. Purif. 2010, 71, 91–95;

36. Bolivar, J.M.; Nidetzky, B. Positively charged mini-protein Z basic2 as a highly efficient silica binding

module: Opportunities for enzyme immobilization on unmodified silica supports. Langmuir 2012, 28,

10040–10049; doi:10.1021/la3012348.

37. Smith, D.B.; Johnson, K.S. Single-step purification of polypeptides expressed in Escherichia coli as fusions

with glutathione S-transferase. Gene 1988, 67, 31–40; doi:10.1016/0378-1119(88)90005-4.

Molecules 2019, 24, 4146

23 of 23

1

38. Los, G.V.; Encell, L.P.; McDougall, M.G.; Hartzell, D.D.; Karassina, N.; Zimprich, C.; Wood, M.G.; Learish,

R.; Ohana, R.F.; Urh, M.; et al. HaloTag: A Novel Protein Labeling Technology for Cell Imaging and Protein

Analysis. ACS Chem. Biol. 2008, 3, 373–382; doi:10.1021/cb800025k.

1

39. Duplay, P.; Hofnung, M. Two regions of mature periplasmic maltose-binding protein of Escherichia coli

involved in secretion. J. Bacteriol. 1988, 170, 4445–4450; doi:10.1128/jb.170.10.4445-4450.1988.

40. Hernandez, K.; Fernandez-Lafuente, R. Control of protein immobilization: Coupling immobilization and

site-directed mutagenesis to improve biocatalyst or biosensor performance. Enzyme Microb. Technol. 2011,

4

8, 107–122; doi:10.1016/j.enzmictec.2010.10.003.

41. Nagy, F.; Tasnádi, G.; Balogh-Weiser, D.; Bell, E.; Hall, M.; Faber, K.; Poppe, L. Smart Nanoparticles for

Selective Immobilization of Acid Phosphatases. ChemCatChem 2018, 10, 3490–3499;

doi:10.1002/cctc.201800405.

1

42. Paizs, C.; Katona, A.; Rétey, J. The Interaction of Heteroaryl-Acrylates and Alanines with Phenylalanine

Ammonia-Lyase from Parsley. Chem. - A Eur. J. 2006, 12, 2739–2744; doi:10.1002/chem.200501034.

43. Gloge, A.; Zoń, J.; Kövári, Á.; Poppe, L.; Rétey, J. Phenylalanine Ammonia-Lyase: The Use of Its Broad

Substrate Specificity for Mechanistic Investigations and Biocatalysis—Synthesis of L-Arylalanines. Chem.

Eur. J. 2000, 6, 3386–3390; doi:10.1002/1521-3765(20000915)6:18<3386::AID-CHEM3386>3.0.CO;2-5.

44. Hydery, T.; Coppenrath, V.A. A Comprehensive Review of Pegvaliase, an Enzyme Substitution Therapy

for the Treatment of Phenylketonuria. Drug Target Insights 2019, 13, 1–8; doi:10.1177/1177392819857089.

45. Fields, C.; Li, P.; O’Mahony, J.J.; Lee, G.U. Advances in affinity ligand-functionalized nanomaterials for

biomagnetic separation. Biotechnol. Bioeng. 2016, 113, 11–25; doi:10.1002/bit.25665.

46. Dima, N.A.; Filip, A.; Bencze, L.C.; Oláh, M.; Sátorhelyi, P.; Vértessy, B.G.; Poppe, L.; Paizs, C. Expression

and purification of recombinant phenylalanine ammonia-lyase from Petroselinum crispum. Stud. Univ.

Babes-Bolyai Chem. 2016, 61, 21–34.

1

47. Lu, H.-T. Synthesis and characterization of amino-functionalized silica nanoparticles. Colloid J. 2013, 75,

3

11–318; doi:10.1134/S1061933X13030125.

©

2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access

article distributed under the terms and conditions of the Creative Commons Attribution

(

CC BY) license (http://creativecommons.org/licenses/by/4.0/).

Article Doi

"Fishing and hunting"-selective immobilization of a recombinant phenylalanine ammonia-lyase from fermentation media

DOI: 10.3390/molecules24224146

Source and publish data:

Authors:

Article abstract of DOI:10.3390/molecules24224146

Full text of DOI:10.3390/molecules24224146

Products guided by the article

R&D Labs maybe for 140-10-3

Relevant to this article

Hot Product
