Angewandte
Communications
Chemie
Heterocycles
Highly Site Selective Formal [5+2] and [4+2] Annulations of
Isoxazoles with Heterosubstituted Alkynes by Platinum Catalysis:
Rapid Access to Functionalized 1,3-Oxazepines and
2,5-Dihydropyridines
Wen-Bo Shen+, Xin-Yu Xiao+, Qing Sun, Bo Zhou, Xin-Qi Zhu, Juan-Zhu Yan, Xin Lu,* and
Long-Wu Ye*
À
Abstract: Platinum-catalyzed formal [5+2] and [4+2] annu-
lations of isoxazoles with heterosubstituted alkynes enabled the
atom-economical synthesis of valuable 1,3-oxazepines and 2,5-
dihydropyridines, respectively. Importantly, this Pt catalysis
not only led to unique reactivity dramatically divergent from
that observed under Au catalysis, but also proceeded via
unprecedented a-imino platinum carbene intermediates.
indoles through the gold-catalyzed C H annulation of
anthranils with ynamides by a similar strategy (Scheme 1b).[9]
Notably, nonpolarized alkynes also underwent this trans-
formation when MsOH (10 mol%) was used as an additive.
This chemistry has also been aptly exploited in the synthesis
of 3-aminopyrroles through the rhodium-catalyzed formal
[3+2] annulation of 1,2,3-triazoles with isoxazoles by Tang
and co-workers.[10]
C
atalytic transformations involving metal carbenes are
Herein, we report an unprecedented platinum-catalyzed
formal [5+2] annulation between ynamides and isoxazoles
through pathway presumably involving an a-imino Pt carbene
(Scheme 1c), in sharp contrast to the above-reported [3+2]
annulations. This Pt catalysis led to the unexpected formation
of various polysubstituted 1,3-oxazepines, which are struc-
tural motifs commonly found in natural products and
bioactive molecules.[11] This chemistry could also be extended
to the site-selective synthesis of 2,5-dihydropyridines through
among the most important aspects of homogeneous transi-
tion-metal catalysis. Recently, the generation of metal car-
benes directly from readily available alkynes has attracted
much attention, and various synthetic methods have been
developed.[1] However, the generation of Pt carbenes has
been explored relatively seldom as compared with the related
Au carbenes,[1] and most studies have focused on vinyl Pt
carbenes.[2] To the best of our knowledge, the generation of a-
oxo or a-imino Pt carbenes has been unsucessful to date.[3,4]
Hence, access to novel Pt carbenes is highly desirable, not
only for the enrichment of platinum chemistry, but also
because it may result in a selectivity switch for the con-
struction of diverse intricate scaffolds.[5]
a
platinum-catalyzed formal [4+2] annulation between
alkynyl ethers and isoxazoles. Furthermore, our proposed
mechanistic rationale for this novel cascade reaction is
strongly supported by theoretical calculations.
Considering that the formation of a bulky a-imino metal
carbene intermediate may increase the chance of 1,7-cycliza-
tion, ynamide 1a and fully substituted isoxazole 2a were
chosen as model substrates for our initial study. Typical gold
catalysts, such as [IPrAuNTf2] and [Ph3PAuNTf2], only
afforded the 1,5-cyclization product 3aa, as in our previously
reported study (Table 1, entries 1–3).[8b] However, the desired
1,7-cyclization product was produced in 30% yield with
[BrettPhosAuNTf2] as the catalyst, and importantly, no
formation of 3aa was observed (entry 5). Interesting, the
structure of this cyclized product was assigned by X-ray
diffraction[12] as 1,3-oxazepine 3a rather than the expected
1,4-oxazepine. Compounds 3a and 3aa could not be con-
verted into one another under the relevant reaction con-
ditions.[13] Product 3a was formed exclusively with Pt
catalysts, but with low efficiency even when the catalyst
loading was increased to 10 mol% (entries 7–9). Gratifyingly,
further studies revealed that the efficiency of the above PtCl2-
catalyzed reaction was substantially improved in toluene
under a CO (1 atm) atmosphere,[14] under which conditions 3a
was formed in 86% yield (Table 1, entry 11). Brønsted acids
and other (non-noble) metals did not catalyze this reaction.[13]
We explored the scope of the reaction under the
optimized reaction conditions. Ynamides with different N-
protecting groups were first investigated, and it was found
During the course of our recent studies on transition-
metal-catalyzed tandem reactions based on ynamides,[6,7] we
disclosed a novel and atom-economical route to the gener-
ation of a-imino Au carbenes through a gold-catalyzed formal
[3+2] annulation between ynamides and isoxazoles, thus
providing ready access to various 2-aminopyrroles (Sche-
me 1a).[8] Very recently, Hashmi and co-workers reported an
elegant protocol for the synthesis of unprotected 7-acyl
[*] W.-B. Shen,[+] X.-Y. Xiao,[+] Q. Sun, B. Zhou, X.-Q. Zhu, J.-Z. Yan,
Prof. Dr. X. Lu, Prof. Dr. L.-W. Ye
Collaborative Innovation Center of Chemistry for Energy Materials
State Key Laboratory of Physical Chemistry of Solid Surfaces
Key Laboratory for Chemical Biology of Fujian Province
College of Chemistry and Chemical Engineering, Xiamen University
Xiamen 361005 (China)
E-mail: xinlu@xmu.edu.cn
Prof. Dr. L.-W. Ye
State Key Laboratory of Organometallic Chemistry, Shanghai
Institute of Organic Chemistry, Chinese Academy of Sciences
Shanghai 200032 (China)
[+] These authors contributed equally.
Supporting information for this article can be found under:
Angew. Chem. Int. Ed. 2016, 55, 1 – 6
ꢀ 2016 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1
These are not the final page numbers!
