769 cm-1; MS: m/z: 321 (M+), 320, 305 (100); Found: M+ 321.1013, C20H11N5 requires M+
321.1014.
5H-Quinoxalino[2',3':4,5]pyrrolo[3,2,1-de]acridine (9a), yellow solid (Method 1, reaction
time: 15 min., 51 mg, yield 80%; Method 2, reaction time: 6 h, 38 mg, yield 60%): mp 288-289
°C (dec.); 1H-NMR (CDCl3): 4.55 (s, 2H), 7.20 (t, J=7.5 Hz, 1H, H-8), 7.35 (d, J=6.9 Hz, 1H, H-
9), 7.42 (t, J=6.9 Hz, 1H, H-13 or H-12), 7.48 (d, J=6.9 Hz, 1H, H-14), 7.49 (t, J=6.9 Hz, 1H, H-
13 or H-12), 7.72 (t, J=7.5 Hz, 1H, H-4 or H-3), 7.81 (t, J=7.8 Hz, 1H, H-4 or H-3), 8.25 (d,
13
J=8.1 Hz, 2H, H-5, H-2), 8.30 (d, J=8.4 Hz, 1H, H-11), 9.53 (d, J=8.4 Hz, 1H, H-7); C-NMR
(CDCl3): 29.42, 117.54, 118.29, 119.62, 120.20, 122.70, 123.38, 124.27, 126.71, 127,71, 128,35,
128.97, 129.11, 129.20, 129.63, 135.27, 138.88, 140.04; FT-IR (KBr): 3057, 1581, 1510, 1470,
1463, 1240, 745 cm-1; MS: m/z: 307 (M+), 306 (100). Found: M+ 307.1110, C21H13N3 requires
M+ 307.1109.
1-Methyl-5H-quinoxalino[2',3':4,5]pyrrolo[3,2,1-de]acridine (9b), purple solid (Method 1,
reaction time: 10 min., 47 mg, yield 70%; Method 2, reaction time: 6 h, 33 mg, yield 50%): mp
219-220 °(.dec)C ; 1H-NMR (CDCl3): 2.24 (s, 3H, CH3), 4.01 (d, J=17.7 Hz, 1H, CH2), 4.20 (d,
J= 17.7 Hz, 1H, CH2), 7.21-7.56 (m, 7H), 7.95 (dd, J1=6.9 Hz, J2=2.4 Hz, H-2 or H-5), 8.33 (d,
J=8.1 Hz, 1H), 8.57 (dd, J1=6 Hz, J2=2.4 Hz,1H); 13C-NMR (CDCl3): 21.11, 32.90, 114.29,
115.16, 119.78, 122.78, 124.78, 125.49, 125.56, 125.82, 126.68, 126.78, 129.56, 130.79, 130.99,
131.72, 131.93, 143.97; FT-IR (KBr): 3049, 2913, 1600, 1582, 1405, 1241, 817, 746 cm-1; MS:
m/z: 321 (M+), 320, 305(100); Found: M+ 321.1268, C22H15N3 requires M+ 321.1266.
12-Methyl-5H-quinoxalino[2',3':4,5]pyrrolo[3,2,1-de]acridine (9c) and 11-Methyl-5H-
quinoxalino[2',3':4,5]pyrrolo[3,2,1-de]acridine (9d) obtained in a ratio of 1:1 (the isomers
could not be separated); yellow solid (Method 1, reaction time: 10 min., 57 mg, yield 85%;
1
Method 2, reaction time: 6 h : 49 mg, yield 73%): mp 189-190 ° ;(.dec)C H-NMR (CDCl3):
2.65 (s, 0.5x3H, CH3), 2.66 (s, 0.5 x3H, CH3), 4.50 (s, 2H), 7.1 4-7.46 (m, 4H), 7.16 (t, J=7.5,
1H, H-8 ), 7.55 (dd, J1=8.4 Hz, J2=1.2 Hz, 1H, H-14 or H-11), 7.62 (dd, J1=8.4 Hz, J2=1.8 Hz,
1H, H-14 or H-11), 8.01 (s, 0.5x1H), 8.05 (s, 0.5x1H), 8.11 (d, J=8.4 Hz, 1H), 8.15 (d, J=8.4 Hz,
1H), 8.20 (d, J=8.4 Hz,1H, H-3), 9.46 (d, J=4.2 Hz, 1H, H-7), 9.49 (d, J=4.2 Hz, 1H, H-7); 13C-
NMR (CDCl3): 29.40, 29.69, 117.40, 117.47, 118.37, 119.49, 119.92, 120.05, 122.61, 122.67,
123.19, 123.24, 124.08, 124.12, 127.38, 127.63, 127.83, 128.11, 128.26, 128.64, 128.70, 128.83,
128.95, 129.56, 131.18, 135.307, 136.85, 137.23, 138.28, 138.84, 139.45; FT-IR (KBr): 3060,
2921, 2852, 1582, 1467, 1405, 1177, 1116, 746 cm-1; MS: m/z: 321 (M+), 320, 285 (100). Found:
M+ 321.1265, C22H15N3 requires M+ 321.1266.
1,12-Dimethyl-5H-quinoxalino[2',3':4,5]pyrrolo[3,2,1-de]acridine (9e) and 1,11-dimethyl-
5H-quinoxalino[2',3':4,5]pyrrolo[3,2,1-de]acridine (9f) obtained in a ratio of 1:3 or 3:1 (by
integration of the methyl signals) (the isomers could not be separated), yellow solid (Method 1,
reaction time: 5 min., 56 mg, yield 80%; Method 2, , reaction time: 5 h , 49 mg, yield 70%): mp
1
251-252 °(.dec)C ; H-NMR (CDCl3): 2.23 (s, 3H for one isomer), 2.24 (s, 3H for one isomer),
2.61 (s, 3H for one isomer) 2.65 (s, 3H for one isomer), 4.00 (d, J=17.4 Hz, 1H, CH2), 4.20 (d,
J=17.4 Hz,1H, CH2), 7.72 (d, Jm=0.9 Hz, H-2 or H-5), 7.81 ( d, J=8.4 Hz, H-7(7b)), 8.31 (d,
