M. Faure et al. / Journal of Organometallic Chemistry 621 (2001) 103–108
107
with nitrogen prior to use. The NMR spectra were
recorded on a Varian Gemini 200 BB instrument; the
treatment of the spectra was performed using a SUN
Varian station. The IR spectra were recorded on a
Perkin–Elmer FT-IR 1720 X spectrometer (4000–
400 cm−1) as KBr pellets. Micro-analytical data were
obtained from the Service de Microchimie, Universite´
de Gene`ve. Electron mass spectra were obtained in
positive-ion mode with an LCQ Finnigan mass spec-
trometer using acetone as the mobile phase. The organic
phase containing products and substrate was analysed
by gas chromatography (GC) on a DANI 86.10 HT gas
chromatograph using a CHROMPACK Carbowax
WCOT fused silica column. The starting cation [(h6-
C6Me6)2(h6-C6H6)Ru3(m2-H)3(m3-O)]+ (2) [7] was syn-
twice-distilled water. To this solution, placed in a 100 ml
stainless steel autoclave, 1.225 ml of ethylbenzene were
added. After purging four times with hydrogen, the
autoclave was pressurised with hydrogen (60 bar) and
held at room temperature under vigorous stirring of the
reaction mixture (900 rpm). After 2 h the pressure was
released. The two-phase system was separated by
decanting. The yellow aqueous phase was evaporated
to dryness; the residue was dissolved in acetone, and
crystallisation at −20°C gave [(h6-C6Me6)2(h6-
C6H6)Ru3(m2-H)2(m2-OH)(m3-O)][BF4] (cation 3). Yield
7 mg (8.27×10−3 mmol, 43%). Anal. Found: C, 42.86;
H, 5.70. Calc. for C30H45B1F4O2Ru3·H2O: C, 42.61; H,
5.60%. IR(cm−1): 3413 (w), w(OꢀH); 3011 (w),
w(CꢀHar); 2930 (s), 2853 (m), w(CꢀH); 1438 (m), 1385
(m), w(C=C); 1084 (br, vs), w(BF4).
thesised
from
(h6-C6Me6)2Ru2Cl4
[12]
and
(h6-C6H6)2Ru2Cl4 [13] according to published methods.
3.3. X-ray structure determination of complex 3
3.2. Synthesis of
An orange crystal of [(h6-C6Me6)2(h6-C6H6)Ru3(m2-
H)2(m2-OH)(m3-O)][BF4] (cation 3) was mounted on a
Stoe imaging plate diffractometer system (Stoe & Cie,
1995) equipped with a one-circle goniometer and a
graphite monochromator. Data collection was per-
formed at −120°C using Mo–Ka radiation (u=
[(p6-C6Me6)2(p6-C6H6)Ru3(v2-H)2(v2-OH)(v3-O)]+ (3)
[(h6-C6Me6)2(h6-C6H6)Ru3(m2-H)3(m3-O)][BF4] (cation
2) (16 mg, 1.93×10−2 mmol) was dissolved in 5 ml of
,
0.710 73 A). 200 exposures (3 min per exposure) were
obtained at an image plate distance of 70 mm with
0BB200° and with the crystal oscillating through 1°
in . The resolution range was Dmin–Dmax 12.45–
Table 5
Crystallographic and selected experimental data for 3
Compound
[(h6-C6H6)(h6-C6Me6)2Ru3(m2-H)2-
,
0.81 A. The structure was solved by Patterson methods
(m2-OH)(m3-O)][BF4]·H2O
using SHELXS-97 [14]. Refinement was done by full-ma-
trix least squares on F2 with SHELXL-97 [15]. The
compound crystallises in the tetragonal system (cen-
trosymmetric space group I4/m) with half a molecule of
3 as well as half a water molecule and half of an
extremely disordered BF−4 anion per asymmetric unit.
The BꢀF distances in the distorted BF−4 anion were
constrained to their theoretical values [16]. The hydro-
gen atoms attached to the water molecule were derived
from Fourier difference maps and constrained to their
theoretical values [16]. The positions of the hydride
H1ꢀRu and the hydroxide H atom were also found as
electron density peaks and refined while the remaining
hydrogen atoms of the organic ligand were included in
calculated positions and treated as riding atoms using
SHELXL-97 default parameters. All non-hydrogen atoms
(except F3, F3a, F4, F4a and F4b atoms, which were
isotropically refined) were refined with anisotropic dis-
placement parameters. Selected bond lengths and bond
angles are listed in Table 1. Crystallographic details for
compound 3 are summarised in Table 5. The figure was
Empirical formula
Crystal colour
C30H47B1F4O3Ru3 (cation 3)
Orange
Block
Crystal shape
Crystal size (mm3)
0.30×0.20×0.15
845.70
Tetragonal
I4/m
18.2490(9)
18.2490(9)
20.2191(10)
90
90
90
6733.6(6)
8
1.668
1.379
3392
1.65–26.05
153(2)
26 603
3355
Mr (g mol−1
)
Crystal system
Space group
,
a (A)
,
b (A)
,
c (A)
h (°)
i (°)
k (°)
3
,
V (A )
Z
Dc (g cm−3
)
v (Mo–Ka) (mm−1
F(000)
)
q scan-range (°)
T (K)
Reflections measured
Independent reflections
Reflections observed [I\2|(I)] 2580
Final R indices [I\2|(I)]a
R indices (all data)a
Goodness of fit
R1=0.0501, wR2=0.1467
R1= 0.0643, wR2=0.1551
1.030
drawn with PLATON/PLUTON [17].
Maximum D/|
0.001
+1.539, −2.789
3.4. Catalytic runs
Residual density: maximum,
minimum Dz (e−
A
)
−3
,
In a typical experiment, a solution of 0.01 mmol of
a R1=S ꢀꢀFoꢀ−ꢀFcꢀꢀ/S ꢀFoꢀ, wR2=[S w(Fo2−F2c)2/S (wFo4)]1/2
.
[(h6-C6Me6)2(h6-C6H6)Ru3(m2-H)2(m2-OH)(m3-O)][BF4]
