Ultrasound-assisted surfactant/ionic liquid aqueous two-phase system extraction prior to high performance liquid chromatography for the determination of tetracyclines in milk and honey samples

Article abstract of DOI:10.3906/kim-1611-51

In this work, an ultrasonic-assisted surfactant/ionic liquid aqueous two-phase system (ATPS) extraction method was developed to extract six tetracycline antibiotics from food samples before their chromatographic determination using high performance liquid chromatography. The ATPS was formed with 1-allyl-3-methyl-imidazolium bromide, Triton X-100, and dipotassium hydrogen phosphate. The parameters including type and amount of surfactant, ionic liquid and salt, pH of sample solution, and sonication time were optimized. Under the optimized conditions, linear calibration curves of the six tetracyclines were obtained in the range of 10–500 μg L^?1 with > r² = 0.990 (n = 9). The proposed green analytical extraction method was applied to the analysis of tetracycline antibiotics in milk and honey samples with recovery of 50%–110% and 68%–117%, respectively.

Full text of DOI:10.3906/kim-1611-51

Turk J Chem
Turkish Journal of Chemistry
(2017) 41: 955 – 966
¨
http://journals.tubitak.gov.tr/chem/
˙
c
⃝ TUBITAK
doi:10.3906/kim-1611-51
Research Article
Ultrasound-assisted surfactant/ionic liquid aqueous two-phase system extraction
prior to high performance liquid chromatography for the determination of
tetracyclines in milk and honey samples
Hayriye Mine ANTEP, Ta¸skın MUMCU, Kamil BOSTANCI,
∗
˙
Serap SEYHAN BOZKURT , Melek MERDIVAN
˙
Department of Chemistry, Faculty of Science, Dokuz Eylu¨l University, Izmir, Turkey
Received: 22.11.2016
•
Accepted/Published Online: 22.06.2017
•
Final Version: 20.12.2017
Abstract: In this work, an ultrasonic-assisted surfactant/ionic liquid aqueous two-phase system (ATPS) extraction
method was developed to extract six tetracycline antibiotics from food samples before their chromatographic determina-
tion using high performance liquid chromatography. The ATPS was formed with 1-allyl-3-methyl-imidazolium bromide,
Triton X-100, and dipotassium hydrogen phosphate. The parameters including type and amount of surfactant, ionic
liquid and salt, pH of sample solution, and sonication time were optimized. Under the optimized conditions, linear
calibration curves of the six tetracyclines were obtained in the range of 10–500 µg L−1 with > r2 = 0.990 (n = 9). The
proposed green analytical extraction method was applied to the analysis of tetracycline antibiotics in milk and honey
samples with recovery of 50%–110% and 68%–117%, respectively.
Key words: Aqueous two-phase system, tetracycline, HPLC, ionic liquid, surfactant
1. Introduction
Drugs in veterinary medicine have been used for preventing animal diseases, changing behaviors, accelerating
growth, feed utilization, and increasing yield. Honey and cow’s milk are directly consumed natural products.
These are important foods for humans, especially for babies. The residues of agricultural drugs, antibiotics,
negatively affect honeybees and cows. At the same time, these antibiotics, such as sulfonamides, quinolones,
penicillins, and tetracylines, can be a risk factor for human health because of their accumulation in animal
products like honey and milk.1−3
The regulations for drugs used in animal raising and controlling of antibiotic residues in animal food
products have been legislated by the European Union.4 The maximum residue limits (MRLs) for veterinary
products in food has been established by European Commission Regulation. The recommended MRL in milk
is 100 µg L−1 by the European Committee. However, no MRL is given for honey.5
Tetracycline antibiotics have been successfully analyzed by reversed-phase high performance liquid chro-
matography (HPLC) with diode array (DAD), fluorescence, and mass spectrometer detector.6−8 Before chro-
matographic analysis, separation and preconcentration of tetracyclines in food samples have been accomplished
by different extraction techniques like liquid–liquid extraction9 and solid-phase extraction.10 Besides the advan-
tages of these techniques, use of organic solvent and long analysis time are their basic disadvantages. In recent
∗Correspondence: serap.seyhan@deu.edu.tr
955

ANTEP et al./Turk J Chem
years, the aqueous two-phase system, a novel extraction method, has been used for extraction of metal ions11−13
such as Cu(II), Au(III), cadmium(II), and zinc(II), and biomolecules14−16 such as proteins, antibiotics, and
enzymes because of its short analysis time and fast phase separation, and because it is more environmentally
friendly and economical. ATPS is generally formed by combination of two different polymers, one polymer
with inorganic salt or ionic liquid with inorganic salt at high concentration. Nowadays, a new ATPS extraction
method is performed using surfactant with ionic liquid.17−21 The ionic liquid-based ATPS extraction sys-
tems such as ionic liquid/sodium carbonate,22 1-octyl-3-methylimidazolium bromide/sodium dodecyl sulfate,15
1-methyl-3-octylimidazolium tetrafluoroborate/sodium dihydrogen phosphate,23 1-butyl-3-methylimidazolium
tetrafluoroborate/ammonium sulfate,24 1-butyl-3-methylimidazolium tetrafluoroborate/sodium dihydrogen phos-
phate,25 and 1-butyl-3-methylimidazolium halide ([Bmim] X (X = Cl, Br))/di potassium hydrogen phosphate26
were used for the separation and preconcentration of tetracylines before their analysis.
In this work, an ultrasonic-assisted surfactant/ionic liquid based aqueous two-phase system is proposed
for the determination of six tetracyclines by HPLC-DAD in milk and honey samples. Target tetracycline
compounds were tetracycline (TC), oxytetracycline (OTC), chlorotetracycline (CTC), doxytetracycline (DC),
minocycline (MITC), and metacycline (MTC). The effect of some parameters such as type and amount of
surfactant, ionic liquid and salt, pH of sample solution and sonication time were studied.
2. Results and discussion
2.1. Characterization of ionic liquids
The structures of synthesized ionic liquids was characterized with FTIR and 1 H NMR spectra. In the FTIR
spectra, the peaks of wave numbers of 3100–3050 cm−1 and 2850–2950 cm−1 were the aromatic =C–H
stretching vibrations and aliphatic symmetric and asymmetric –C–H stretching vibrations. Peaks at wave
numbers 1450–1460 cm−1 and 1560–1570 cm−1 were due to C=C and C=N stretching vibrations. The
aliphatic –C–H bending vibrations and aliphatic –C–C stretching vibrations were at wave numbers 1280–1330
cm−1 and 1050–1168 cm−1 , respectively. The peaks at wave numbers 719–847 cm−1 were due to aromatic
=C–H out-of-plane bending vibrations.
1 H NMR spectra were reported as ppm (δ) with internal standard (TMS). The D2 O and CDCl3 were
used as solvent. The results of analysis are given for the synthesized ionic liquids as follows:
AMIM-BF4 ; 1 H NMR (D2 O, ppm): 8.92 (s, 1H, NCH N) 7.67 (d, 2H, NCH2 CHCH2), 6.20 (m, 1H,
NCH2 CH CH2), 5.61 (m, 2 × CH, NCH CH N), 4.99 (d, 2H, NCH2 CHCH2), 4.11 (s, 3H, NCH3)
BMIM-BF14; H NMR (D2 O ppm): 8.81 (s, 1H, NCH N), 7.54 (d, 1H, NCH CHN), 4.27 (t, 2H, NCH2 CH2),
3.99 (s, 3H, NCH3), 1.91 (m, 2H, NCH2 CH2 CH2 CH3), 1.36 (h, 2H, NCH2 CH2 CH2 CH3), 0.96 (t, 3H,
CH2 CH3)
1
BeMIM-Br;
H NMR (CDCl3 ppm): 9.75 (s, 1H, NCH N), 7.33 (d, 1H, NCH CHN), 7.24 (d, 1H,
NCHCH N), 7.14 (d, 2H, –ArH), 6.92 (m, 3H, –ArH), 3.62 (s, 3H, NCH3)
BeMIM-BF4 ; 1 H NMR (CDCl3 ppm): 9.26 (s, 1H, NCH N), 7.24–7.52 (m, 2H, NCH CH N; 2H, ArH),
7.02–6.99 (m, 3H, –ArH), 3.61 (s, 3H, –NCH3)
2.2. Optimization of extraction parameters
In order to get high extraction efficiency, type and amount of surfactant, ionic liquid and salt, pH of sample
solution, and sonication time as experimental parameters were optimized.
956

ANTEP et al./Turk J Chem
2.2.1. Type of surfactant
Presence of surfactant in ATPS is useful for better phase separation because of getting dense aqueous solution.27
In this proposed method, sodium dodecyl sulfate (SDS) as anionic, cetyl trimethylammonium bromide (CTAB)
as cationic, and Triton X-100 as nonionic surfactant were used to investigate their effects on the extraction
efficiency of tetracyclines. To a polyethylene test tube, ionic liquids (AMIM-Br, BMIM-Br, BeMIM-Br, AMIM-
BF4 , BMIM-BF4 , BeMIM-BF4) whose final concentration was 0.12 mol L−1 , 1 g of K2 HPO4 , and 1 mL of 5%
(w/v) each surfactant were added. Finally, the test solution (adjusted to pH 5 with acetate buffer) having 100
µg L−1 (initial concentration) of each tetracycline was diluted to 10 mL with deionized water. After sonication
of the last mixture for 5 min, it was centrifuged. Some white particles were formed at the bottom or suspended
in solution when SDS and CTAB were used as surfactant. With Triton X-100, the ionic liquid rich upper phase
and inorganic salt rich bottom phase were obtained. Therefore, Triton X-100 was selected as surfactant for
further studies.
2.2.2. Type of ionic liquid
Ionic liquids having different cation and anion groups can affect the phase behavior of solution.28 For this
manner, two different hydrophilic anion groups like bromide and tetrafluoroborate and imidazolium cation group
having three different organic group like butyl, allyl, and benzyl were studied to investigate the extraction
efficiency of six tetracycline compounds using Triton X-100 concentration. The six tetracycline compounds
were extracted using all ionic liquids studied except MITC in BeMIM-BF4 and MITC and CTC in BeMIM-Br.
Therefore, AMIM-Br, AMIM-BF4 , BMIM-Br, and BMIM-BF4 ionic liquids were used for other optimization
parameters.
2.2.3. Amount of surfactant
To get the optimum amount of surfactant, the concentration of Triton X-100 in the final solution was studied
from 0.25% (w/v) to 1.5% (w/v) for ionic liquids containing alkyl groups as butyl- and allyl-. The phase
separation was not obtained when the concentration of Triton X-100 was 0.25% (w/v). As seen in Figure 1, the
extraction yield increased up to 1% (w/v) and afterward decreased gradually by increasing to 1.5 (w/v). For
further studies, the concentration of Triton X-100 in the final solution was selected as 1% (w/v).
Figure 1. The optimization of amount of Triton X-100 for extraction of tetracyclines (concentration and volume of
sample: 100 µg L−1 , 4 mL; pH: 5; concentration of ionic liquid: 0.12 mol L−1 ; type and amount of salt: K2 HPO4 , 1
g; sonication time: 5 min).
957

ANTEP et al./Turk J Chem
2.2.4. pH of the system
The extraction degree of analyte can be affected by the pH of sample solution.29 Tetracyclines have different
dissociation constants, pKa1 = 3.3, pKa2 = 7.5, and pKa3 = 9. The influence of pH on the extraction
of tetracyclines from the sample solution was tested in the pH range of 3 to 9. The peak areas of the six
tetracycline compounds were high at pH 3 and pH 5 (Figure 2). The tetracyclines are in the protonated or
zwitterion ion form at pH 3 and pH 5, respectively. At higher pH values, it could be concluded that the
extraction of these compounds was low. The interaction between tetracyclines and ionic liquid could be defined
as a hydrophobic and π–π interaction between aromatic rings of tetracycline compounds and imidazolium ring,
especially containing allyl groups, and also possible electrostatic interactions between ionic groups’ presence in
the aqueous media in the ATPS method. Afterwards, pH of test solutions was adjusted to 3 because of slightly
higher peak areas of tetracyclines.
Figure 2. The optimization of pH for extraction of tetracyclines (concentration and volume of sample: 100 µg L−1
,
4 mL; concentration of ionic liquid: 0.12 mol L−1 ; type and amount of surfactant: Triton X-100, 1% (w/v); type and
amount of salt: K2 HPO4 , 1 g; sonication time: 5 min).
2.2.5. Amount of ionic liquid
The concentration of ionic liquid directly affects the formation of phase separation in ATPS.30 For this purpose,
a series of test solutions having final ionic liquid concentration from 0.06 to 0.18 mol L−1 were prepared. When
ATPS was applied to these solutions, it was observed that the higher extraction efficiency was achieved with
0.09 mol L−1 BMIM-Br or AMIM-Br and 0.06 mol L−1 BMIM-BF4 or AMIM-BF4 (Figure 3). Therefore,
further studies were carried out with these concentrations of ionic liquids.
2.2.6. Type and amount of salt
The optimization of salt is important parameter in the transition of the target analyte to organic phase.31 To
optimize the type, extraction was carried out with 1 g of K2 HPO4 , KH2 PO4 , (NH4)2 SO4 , and K2 SO4 . The
highest preconcentration was obtained with K2 HPO4 .
The amount of K2 HPO4 was changed from 0.5 to 1.5 g under the same experimental conditions in test
solutions to achieve effective extraction. The highest extraction efficiency was obtained with 1 g of K2 HPO4 .
Thus, the further studies were carried out with 1 g of K2 HPO4.
958

ANTEP et al./Turk J Chem
Figure 3. The optimization of amount of ionic liquid for extraction of tetracyclines (concentration and volume of
sample: 100 µg L−1 , 4 mL; pH: 3; type and amount of surfactant: Triton X-100, 1% (w/v); type and amount of salt:
K2 HPO4 , 1 g; sonication time: 5 min).
2.2.7. Sonication time
To determine the best extraction time for the highest yields of tetracyclines by ATPS, the sonication time was
investigated. For this, the method was carried out for 30, 60, 120, and 180 s. The extraction yield was increased
when the sonication time was 60 s for all tetracyclines in the four ionic liquids studied (Figure 4). Thus, 60 s
was selected as the optimum sonication time for maximum extraction efficiency.
Figure 4. The optimization of sonication time for extraction of tetracyclines (concentration and volume of sample: 100
µg L−1 , 4 mL; pH: 3; concentration of ionic liquid: 0.09 mol L−1 AMIM-Br, BMIM-Br, 0.06 mol L−1 AMIM-BF4 ,
BMIM-BF4 ; type and amount of surfactant: Triton X-100, 1% (w/v); type and amount of salt: K2 HPO4 , 1 g).
2.2.8. Analytical performance
According to the obtained optimization data (Figure 4, 60 s) the best results were obtained with AMIM-Br for
MITC, OTC, CTC, and MTC antibiotics. Thus, the evaluation of the developed method was carried out by this
ionic liquid. The linearity, precision, and limit of detection (LOD) were investigated as analytical parameters
under optimized conditions. The precision of ATPS was defined as relative standard deviation percentage (RSD
959

ANTEP et al./Turk J Chem
%) and determined by measuring the interday and intraday for 100 µg L−1 and 25 µg L−1 , respectively. The
calibration curves showed a linear peak area in the concentration of 10–500, 20–500, and 40–500 µg L−1 for
MITC, CTC, MTC, DC and TC and OTC, respectively, and the satisfactory coefficient of determination (R2)
ranging from 0.990 to 0.998 were obtained. LOD was calculated by ten blank measurements as a signal to noise
ratio of 3 and all the results are given in Table 1.
Table 1. The analytical parameters of the developed method for extraction of tetracycline compounds.
Linear
range
LOD
RSD %
RSD %
Tetracycline
R2
(3 × S/N) (interday, n = 5) (interday, n = 5)
(µg L−1
10–500
40–500
20–500
25–500
10–500
10–500
)
(µg L−1
)
(25 µg L−1
2.62
2.01*
2.46
0.75
)
(100 µg L−1
6.62
1.16
6.49
5.77
)
MITC
OTC
TC
CTC
MTC
0.996 2.60
0.997 11.98
0.998 1.37
0.997 7.72
0.992 3.24
0.990 3.19
1.27
4.28
0.29
9.97
DC
*for 50 µg L−1
2.2.9. Application of the ATPS method to real samples
The developed ionic liquid-based ATPS method was applied to milk and honey samples with AMIM-Br under
optimal conditions. MITC, OTC, TC, CTC, MTC, and DC tetracyclines were not observed in the milk samples.
The observed tetracycline residues in the honey samples were under maximum residue limits of tetracyclines.
Recovery was calculated by spiking tetracycline standard mixture at 50 µg L−1 and 100 µg L−1 concentrations
in final solution to the milk and honey samples. It was observed that the recoveries of tetracyclines were
50%–110% and 68%–117% milk and honey samples, respectively (Table 2). The chromatograms of spiked
and nonspiked real samples are given in Figures 5a–5c and Figures 6a–6c. The recoveries indicated that the
developed ionic liquid-based ATPS method was successfully applicable to milk and honey samples.
2.2.10. Comparison of the developed method with the other ionic liquid-based ATPS methods
The performance of the developed method was evaluated with the other extraction methods for tetracyclines.
As shown in Table 3, the developed method for separation and preconcentration of tetracyclines before their
analysis offered a short analysis time and a wide linear range. Moreover, the method had small LOD values, in
comparison with other extraction methods for tetracyclines.
3. Conclusions
In this study, a new ionic liquid-based aqueous two-phase system was developed for the separation and pre-
concentration of tetracyclines from an analytical matrix before their HPLC determination. For this purpose,
imidazolium-based ionic liquids containing butyl, allyl, and benzyl as alkyl groups and bromide and tetrafluo-
roborate as anion groups were used. The parameters such as type and amount of surfactant, ionic liquid and
salt, pH of sample solution, and sonication time were optimized with all ionic liquids. The highest extraction
efficiency was obtained with AMIM-Br at the optimum conditions for MITC, OTC, CTC, and MTC antibiotics.
Thus, the analytical performance and application of this method to real samples was carried out with this ionic
liquid. For accuracy of this method, 50 µg L−1 and 100 µg L−1 standard tetracycline mixture were added to
milk and honey samples and the recovery was ≥50% and 68%, respectively.
960

ANTEP et al./Turk J Chem
961

ANTEP et al./Turk J Chem
Figure 5. HPLC chromatograms of honey sample spiked with 100 µg L−1 ((70 µg kg−1) tetracycline standard (a);
honey sample spiked with 50 µg L−1 (35 µg kg−1) tetracycline standard (b); unspiked honey sample (c) after ATPS
method, (retention time (min): MITC: 5.4, OTC: 6.1, TC: 7.2, CTC: 13.4, MTC: 14.4, DC: 15.6.
The developed method was simple, had good repeatability, was rapid, and was applicable to food products.
It might also be applicable to other antibiotic groups after optimization of the proposed ATPS method.
4. Experimental
4.1. Chemicals
The standards of OTC, TC, CTC, MITC, MTC, and DC (purity 97%–99.7%) were obtained from Sigma-
Aldrich and Fluka. The ionic liquids [1-butyl-3-methyl imidazolium bromide (BMIM-Br) and 1-allyl-3-methyl
imidazolium bromide (AMIM-Br)] were purchased from Sigma-Aldrich. 1-Methylimidazole, benzyl bromide,
ammonium tetrafluoroborate, formic acid, trifluoroacetic acid (TFA), trichloroacetic acid (TCA), citric acid,
sodium citrate, toluene, dichloromethane, HPLC grade acetonitrile (ACN), and methanol were purchased from
Sigma-Aldrich, Alfa Easer, or Merck. All other chemicals used were of analytical grade. Deionized water was
obtained with a Milli-Q water purification system. Deuterium oxide (D2 O) and deuterated chloroform (CDCl3)
were used for 1 H NMR spectra and chemical shift values were recorded as ppm.
The individual stock solution of each tetracycline compound (1000 µg L−1) was prepared by methanol
and stored in a refrigerator at –18 ◦ C. The mixed stock solution containing six tetracyclines was prepared from
962

ANTEP et al./Turk J Chem
Figure 6. HPLC chromatograms of milk sample spiked with 100 µg L−1 (96 µg kg−1) tetracycline standard (a); milk
sample spiked with 50 µg L−1 (48 µg kg−1) tetracycline standard (b); unspiked milk sample (c) after ATPS method,
retention time (min): MITC: 5.4, OTC: 6.1, TC: 7.2, CTC: 12.8, MTC: 13.2, DC: 14.4.
individual stock solution by diluting with methanol and stored at 4 ◦ C in dark conditions. The mixed working
solutions were prepared daily.
Ionic liquids [1-benzyl-3-methyl imidazolium bromide (BeMIM-Br), 1-butyl-3-methyl imidazolium tetraflu-
oroborate (BMIM-BF4), 1-allyl-3-methyl imidazolium tetrafluoroborate (AMIM-BF4), 1-benzyl-3-methyl im-
idazolium tetrafluoroborate (BeMIM-BF4)] were prepared according to the literature.36 For the synthesis of
BeMIM-Br, N-methyl imidazole and benzyl bromide were refluxed at 70 ◦ C for 10 h. Then the BeMIM-Br
963

ANTEP et al./Turk J Chem
Table 3. Comparison of the proposed method with other extraction method for tetracyclines
Extr. t!me
(m!n)
L!near range LOD
(µg L-1)
Sp!ked recovery
(%)
Method
Ref.
15
(µg L-1)
Ion!c l!qu!d-based
ATPS
20.1–303.6
(µg kg-1)
5.8–8.2
(µg kg-1)
85.5–109.6 (honey)
1
Ion!c l!qu!d-based
DLLME
60.8–95.3
(egg)
0.5
4
5–1000
30–600
2–12
32
Ultrasound-ass!sted
DLLME
85.7–96.4
(egg)
6.4–11.1
33
62.6–96.3
(r!ver water)
58.9–94.5
(f!shpond water)
55.1–86.1
(hog leachate)
77.5–93
(m!lk)
74–90.2
(egg)
76.4–92.3
(pork)
Ion!c l!qu!d-based
DLLME
5
0.1–200
0.031–0.079
34
35
20–40
(ng g–1)
SPE
100–1000
10–500
68–117
(honey)
50–110
(m!lk)
Ion!c l!qu!d-based
ATPS
"!s
work
1
1.37–5.98
SPE: solid phase extraction
DLLME: dispersive liquid–liquid microextraction
collected in the lower phase was taken and washed with ethyl ether solution. The AMIM-BF4 , BMIM-BF4 ,
and BeMIM-BF4 were also synthesized by mixing ammonium tetrafluoroborate and AMIM-Br, BMIM-Br, or
BeMIM-Br, respectively, in dichloromethane at room temperature for 24 h.
4.2. Instruments
A Buchi rotary evaporator for synthesis of ionic liquids, Selecta 2001 pH meter for pH adjustment of aqueous
solutions, Nuve ultrasonic bath and JP Selecta Ivymen system Cy-500 ultrasonic homogenizer system (500 W,
20 kHz) for sonication, and Spectrum 100 model Fourier transform infrared spectrometer with attenuated total
reflectance (ATR) probe for characterization of ionic liquids were used. The spectra were obtained with the
sum of 25 scans in the range of wave number from 4000 to 400 cm−1 . The 1 H NMR spectra of the synthesized
˙
ionic liquids were obtained at Ege University, Science Technology Research and Application Center in Izmir,
Turkey.
The HPLC-DAD measurements were carried out by a Dionex Ultimate 3000 at 270 nm. Data acquisi-
tions were performed by software. Chromatographic separation of tetracyclines was achieved using a Thermo
Syncronics C18 (150 mm × 4.6 mm, 3 µm) analytical column. The mobile phase was composed of ACN (A)
and TFA (pH 3, B). The injection volume was 10 µL. The flow rate was 1 mL min−1 with a linear gradient at
the following conditions: 0 min: 20% A; 0–15 min: 30% A; 15–17 min: 20% A.32
4.3. Aqueous two-phase system
The sample solution or test solution having mixed tetracycline standards as 4 mL from solution adjusted to
pH 3 with citrate buffer was put into a 15-mL centrifuge tube. Then 0.098 g of 1-allyl-3-methyl-imidazolium
964

ANTEP et al./Turk J Chem
bromide of final concentration 0.09 mol L−1 , 1 mL of 5% (w/v) Triton X-100 solution, and 1 g of dipotassium
hydrogen phosphate (K2 HPO4) were added to tube. This mixture was sonicated at 37% amplitude at room
temperature for 1 min. Then the phase separation was achieved by centrifuging at 5000 rpm for 5 min. Next,
200 µL of the upper phase was transferred to a vial using a microsyringe and diluted with 100 µL of ACN.
The resulting solution was filtered with a 0.45-µm PTFE filter membrane and subjected to HPLC analysis.
4.4. Sample preparation
˙
Milk and honey samples were purchased from a local market in Izmir, Turkey. First, 10 g of milk sample (blank
or fortified sample) was put in a 15-mL centrifuge tube and vortexed for 1 min. After 1 h in the refrigerator, 1
mL of 15% (w/v) TCA was added and the final mixture was centrifuged at 5000 rpm for 10 min to precipitate the
protein part of the milk. The supernatant part was filtered using a 0.45-µm PTFE filter membrane, transferred
to another tube, and kept in the refrigerator at 4 ◦ C up to analysis.37
First, 1 g of honey sample (blank or fortified sample) was diluted with 5 mL of deionized water and
homogenized for 1 h by stirring with a stirring bar. After that, this sample mixture was filtered using a
0.45-µm PTFE filter membrane and kept in the refrigerator at 4 ◦ C until analysis.38
Acknowledgments
¨
The authors are grateful to the Scientific and Technological Research Council of Turkey (TUBITAK) (No:
˙
115Z083) for its financial support.
References
1. Lv, Y. K.; Jia, C. L.; Zhang, J. Q.; Li, P.; Sun, H. W. J. Liq. Chromatogr. R. T. 2013, 36, 249-260.
2. Bozkurt, S. S.; Erdogan D.; Antep, M.; Tuzmen, N.; Merdivan, M. J. Liq. Chromatogr. R. T. 2016, 39, 21-29.
3. Hernandez-Arteseros, J. A.; Barbosa, J.; Compano, R.; Prat, M. D. J. Chromagr. A 2002, 945, 1-24.
4. Commission Regulation (EU) No. 37/2010 of 22 December 2009, L.15 1-72.
5. European commission decision 2002/657/EC, Official Journal of European Communities 2002, 221, 8-36.
¨
6. S¸enyuva, H.; Ozden, T.; Sarıca, D. Y. Turk. J. Chem. 2000, 24, 395-400.
7. Du, F. Y.; Zheng, X.; Sun, L.; Qin, Q.; Guo, L.; Ruan, G. H. J. Sep. Sci. 2015, 38, 3774-3780.
8. Nebot, C.; Guarddon, M.; Seco, F.; Iglesias, A.; Miranda, J. M.; Franco, C. M.; Cepeda, A. Food Control 2014,
46, 495-501.
9. Mookantsa, S. O. S.; Dube, S.; Nindi, M. M. Talanta 2016, 148, 321-328.
10. Feng, M. X.; Wang, G. N.; Yang, K.; Liu, H. Z.; Wang, J. P. Food Control 2016, 69, 171-176.
11. Khayati, G.; Gilani¨o H. G.; Safari Keyvani, Z. Sep. Sci. Technol. 2016, 51, 601-608.
12. Zheng, Y.; Tong, Y.; Wang, S. B., Zhang, H.; Yang, Y. Sep. Purif. Technol. 2015, 154, 123-127.
13. Bulgariu, L.; Bulgariu, D. Sep. Purif. Technol. 2013, 118, 209-216.
14. Li, N.; Wang, Y. Z.; Xu, K. J.; Huang, Y. H.; Wen, Q.; Ding, X. Q. Talanta 2016, 152, 23-32.
15. Yang, X.; Zhang, S. H.; Yu, W.; Liu, Z. L.; Lei, L.; Li, N.; Zhang, H. Q.; Yu, Y. Talanta 2014, 124, 1-6.
16. Ketnawa, S.; Martinez-Alvarez, O.; Benjakul, S.; Rawdkuen, S. J. Food Biochem. 2015, 39, 429-438.
17. Santos, P. L.; Santos, L. N. S.; Ventura, S. P. M.; de Souza, R. L.; Coutinho, J. A. P.; Soares, C. M. F.; Lima, A.S.
Chem. Eng. Res. Des. 2016, 112, 103-112.
965

ANTEP et al./Turk J Chem
18. Zhu, J.; Z. M. Chem. Res. Chinese U. 2016, 32, 630-633.
19. Li, Y. L.; Xu, Z. Y.; Luo, Q. X.; Lu, X. J.; Hu, J. Thermochim Acta 2016, 632, 72-78.
20. Vicente, F. A.; Lario, L. D.; Pessoa, A.; Ventura, S. P. M. Process. Biochem. 2016, 51, 528-534.
21. Shu, Y.; Gao, M. C.; Wang, X. Y.; Song, R. S.; Lu, J.; Chen, X. W. Talanta 2016, 149, 6-12.
22. Marques, C. F. C.; Mourao, T.; Neves, C. M. S. S.; Lima, A. S.; Boal-Palheiros, I.; Coutinho, J. A. P.; Freire, M.
G. Biotechnol. Prog. 2013, 29, 645-654.
23. Soto, A., Arce, A., Khoshkbarchi, M. K. Sep. Purif. Technol. 2005, 44, 242-246.
24. Wang, Y.; Xu, X. H.; Han, J.; Yan, Y. S. Desalination 2011, 266, 114-118.
25. Ma, C. H.; Wang, L.; Yan, Y. S.; Che, G. B.; Yin, Y. S.; Wang, R. Z.; Li, D. Y. Chem. Res. Chin. Univ. 2009,
25, 832-835.
26. Pang, J.; Han, C.; Chao, Y.; Jing, L.; Ji, H.; Zhu, W.; Chang, Y.; Li, H. Sep. Sci. Technol. 2015, 50, 1993-1998.
27. Ritter, E.; Racheva, R.; Storm, S.; Muller S.; Ingram, T.; Smirnova, I. J. Chem. Eng. Data 2016, 61, 1496-1501.
28. Ant Bursalı, E.; Seyhan Bozkurt, S.; Yurdako¸c, M. Turk. J. Chem. 2016, 40, 364-372.
29. Zhang, Y. Q.; Sun, T. C.; Hou, Q. X.; Guo, Q.; Lu, T. Q.; Guo, Y. C.; Yan, C. H. Sep. Purif. Technol. 2016, 169,
151-157.
30. Wang, X. Z.; Li, X. W.; Li, L. J.; Li, M.; Wu, Q.; Liu, Y.; Yang, J.; Jin, Y. R. Anal. Method. 2016, 8, 6566-6572.
31. Wang, Y.; Hu, X. W.; Han, J.; Ni, L.; Tang, X.; Hu, Y. T.; Chen, T. Food Chem. 2016, 194, 257-264.
32. Song, J.; Zhang, Z. H.; Zhang, Y. Q.; Feng, C.; Wang, G. N.; Wang, J.P. Anal. Method. 2014, 6, 6459-6466.
33. Rodriguez, M. P.; Pezza, H. R.; Pezza, L. Anal. Bioanal. Chem. 2016, 408, 6201-6211.
34. Hou, D.; Guan, Y.; Di, X. Chromatographia 2011, 73, 1057-1064.
35. Feng, M. X.; Wang, G. N.; Yang, K.; Liu, H. Z.; Wang, J. P. Food Control 2016, 69, 171-176.
36. Ozdemir, S.; Varlikli, C.; Oner, I.; Ocakoglu, K.; Icli, S. Dyes Pigments 2010, 86, 206-216.
37. Han, J.; Wang, Y.; Yu, C. L; Yan, Y. S.; Xie, X. Q. Anal. Bioanal. Chem. 2011, 399, 1295-1304.
38. Chen, H.; Chen, H.; Ying, J.; Huang, J.; Liao, L. Anal. Chim. Acta 2009, 632, 80-85.
966
