Indoline Dyes with Benzothiazole Unit for Dye-sensitized Solar Cells
Tamotsu Horiuchi,*1 Tohru Yashiro,1 Ryo Kawamura,2 Satoshi Uchida,3 and Hiroshi Segawa4
1System Device Development Department, Ricoh Institute of Future Technology, Ricoh Company Limited,
16-1 Shinei-cho, Tsuzuki-ku, Yokohama, Kanagawa 224-0035
2Research & Development Group, intellim Corporation, 3-4-5 Umeda, Kita-ku, Osaka 530-0001
3Komaba Organization for Educational Excellence College of Arts and Science (KOMEX), The University of Tokyo,
3-8-1 Komaba, Meguro-ku, Tokyo 153-8902
4Research Center for Advanced Science, The University of Tokyo, 4-6-1 Komaba, Meguro-ku, Tokyo 153-8904
(E-mail: tamotsu.horiuchi@nts.ricoh.co.jp)
We report a new series of indoline dyes with a donor-
aromatic-acceptor (D-π-A) structure. D-π-A metal-free organic
dyes with indoline-benzothiazole-rhodanine units were synthe-
sized and their photovoltaic performances were evaluated. The
photoelectric conversion efficiency (©) of the indoline-benzo-
thiazole-rhodanine dye is 3.7%, while that of the indoline-
thiophene-rhodanine dye is 0.9% under the same conditions.
The incident photon-to-current conversion efficiencies (IPCEs)
of these dyes are 60% and 25%, respectively, at 500 nm. To
understand their electronic structures, the geometries of the dyes
were optimized by density functional theory (DFT) calculations
at the 6-31G(d) level using a B3LYP exchange-correlation
functional. As a result, the localized highest occupied molecular
orbital (HOMO) and the lowest unoccupied molecular orbital
(LUMO) of the indoline-benzothiazole-rhodanine dye were
obtained and were compared with those of the indoline-
thiophene-rhodanine dye.
derivative should be introduced between the donor and acceptor
units.11-13 The development of the NKX-2195 dye, with a
rhodanine ring as the acceptor and a coumarin ring as the donor,
has been reported.14 This dye has oxidation potential values
(EOX) minus the 0-0 energy (E0-0) that are more negative than
approximately ¹0.7 V vs. NHE, and show high incident photon-
to-current conversion efficiencies (IPCEs). For EOX = ¹0.63 V,
the IPCE value of NKX-2195 at -max was 40%. In donor-
aromatic-acceptor (D-π-A)-type dyes with a rhodanine ring, the
absorption band of LMc with a 4-methine chain as the π unit
was red-shifted compared to that of Mc with a 2-methine chain
as the π unit, and the absorption thresholds in ethanol solution
were 700 and 570 nm, respectively.15 However, the photoelectric
conversion efficiency (©) and short-circuit photocurrent density
¹2
(JSC) of the LMc were very low (©: 0.4%, JSC: 2.62 mA cm
)
compared to those of the Mc (©: 4.5%, JSC: 11.4 mA cm¹2).16
The low excitation energy, occurrence of cis-trans isomer-
ization, and disorder of the alignment of chromophores in the
J-like aggregate were used to explain these observations.
Molecular design of the dyes is thus necessary to prevent
cis-trans isomerization and to obtain good energy matching to
TiO2 and I2. We examined π units that would be effective for
D-π-A type dyes with a rhodanine ring as the acceptor, and
found that the benzothiazole ring has a molecular structure that
would not allow cis-trans isomerization. Here, we report on a
new type of organic dye, based on indoline with a benzothiazole
unit.
Keywords: Dye-sensitized solar cell (DSSC)
Metal-free organic dye Indoline
|
|
Dye-sensitized solar cells have attracted considerable
attention as inexpensive next-generation power-generating de-
vices.1-3 These are the only solar cells capable of combining
colorful designs, transparency, and flexibility. By exploiting
these advantages, even from the standpoint of photovoltaic
devices, the use of dye-sensitized solar cells will become
widespread, and an industry that can actively support future
energy levels will grow. However, the conversion efficiency
and durability of dye-sensitized solar cells need to be further
improved to suit more practical applications and to establish
the industry. Thus, continuous development of new materials is
essential. In particular, the refinement of dyes plays a crucial
role in fulfilling this task. These dyes are classified into two
groups: “metal complex dyes,” such as ruthenium complexes,
and “metal-free organic dyes,” which do not contain metal
ions. Metal-free dyes have unique features like high molecular
absorption coefficients, vivid colors, and a wide variety of
molecular designs. In particular, good photovoltaic performance
has been reported for dyes containing indoline as the donor
unit.4-6 Perovskite solar cells have attracted considerable
attention in recent years due to their excellent photovoltaic
performances.7-10 Although the energy conversion efficiencies
of dye-sensitized solar cells are lower than perovskite solar cells,
it has little load for environment.
The chemical structure of the indoline dyes (BT-1 and BT-2)
are shown in Figure 1. T-1 and T-2, both of which have a
thiophene unit, were synthesized for reference. Details of the
conditions and route for the synthesis of BT-2, T-1, and T-2 are
presented in the Supporting Information. Only the synthesis of
BT-1 is described below.
Et
S
N
O
S
BT-2
S
BT-1
S
S
N
COOH
CN
N
N
N
N
COOH
O
Et
N
S
O
T-2
T-1
S
CN
COOH
S
COOH
N
N
N
S
S
O
It has recently been shown that to fabricate sensitized dyes
with large wavelengths, an aromatic ring such as the thiophene
Figure 1. Chemical structure of indoline dyes.
