Organometallics 2011, 30, 273–283 273
DOI: 10.1021/om101004z
Ruthenium- and Osmium-Arene Complexes of 2-Substituted
Indolo[3,2-c]quinolines: Synthesis, Structure, Spectroscopic Properties,
and Antiproliferative Activity
€
Lukas K. Filak, Gerhard Muhlgassner, Felix Bacher, Alexander Roller, Markus Galanski,
Michael A. Jakupec, Bernhard K. Keppler, and Vladimir B. Arion*
€
Institute of Inorganic Chemistry, University of Vienna, Wahringer Strasse 42, A-1090 Vienna, Austria
Received October 22, 2010
The synthesis of new modified indolo[3,2-c]quinoline ligands L1-L8 with metal-binding sites
is reported. By coordination to ruthenium- and osmium-arene moieties 16 complexes of the type
[(η6-p-cymene)M(L)Cl]Cl (1a,b-8a,b), where M is RuII or OsII and L is L1-L8, have been prepared.
All compounds were comprehensively characterized by elemental analysis, electrospray ionization
mass spectrometry, IR, UV-vis, and NMR spectroscopy, thermogravimetric analysis, and single-
crystal X-ray diffraction (2a, 4a, 4b, 5a, 7a, and 7b). The complexes were tested for antiproliferative
activity in vitro in three human cancer cell lines, namely, CH1 (ovarian carcinoma), SW480 (colon
adenocarcinoma), and A549 (non-small-cell lung cancer), yielding IC50 values in the submicromolar
or low micromolar range.
Introduction
Screen Database.12 Experiments with enzyme assays con-
firmed the assumption, and a larger series of paullones was
evaluated for their biological activity.13-15
Triggered by the success of flavopiridol, the first cyclin-
dependent kinase (cdk) inhibitor under clinical investiga-
tion,1 efforts have been focused on the development of
targeted ruthenium complexes,2-9 among them some with
kinase-inhibitory properties.10,11 Indolo[3,2-d ]benzaze-
pines, also referred to as paullones, were identified as puta-
tive cdk inhibitors by analysis of the National Cancer
Institute (NCI) Human Tumor Cell Line Anti-Cancer Drug
In order to overcome limitations of confined water solu-
bility and bioavailability of these organic compounds, they
were complexed with metal ions. As the paullone backbone
itself is not suitable for coordination to metals, except for
binding via lactam (or thiolactam) groups yielding thermo-
dynamically nonstable four-membered metallocycles, metal-
binding sites had to be created at the periphery of the molecule
scaffold. By complexation of paullones with gallium(III),16,17
ruthenium(II),18-20 osmium(II),19,20 and copper(II),21 their
physicochemical and biological properties could be altered
markedly. Structure-activity relationship studies have shown
*To whom correspondence should be addressed. E-mail: vladimir.
arion@univie.ac.at. Tel: þ43 1 4277 52615. Fax: þ43 1 4277 52630
(V.B.A.).
(1) Christian, B. A.; Grever, M. A.; Byrd, J. C.; Lin, T. S. Clin.
Lymphoma Myeloma 2009, 9 (Suppl. 3), 179.
(2) Ang, W. H.; Dyson, P. J. Eur. J. Inorg. Chem. 2006, 4003.
(12) Zaharevitz, D. W.; Gussio, R.; Leost, M.; Senderowicz, A. M.;
Lahusen, T.; Kunick, C.; Sausville, E. A. Cancer Res. 1999, 59, 2566.
(13) Schultz, C.; Link, A.; Leost, M.; Zaharevitz, D. W.; Gussio, R.;
Sausville, E. A.; Meijer, L.; Kunick, C. J. Med. Chem. 1999, 42, 2909.
(14) Kunick, C.; Zeng, Z.; Gussio, R.; Zaharevitz, D.; Leost, M.;
€
(3) Meggers, E.; Atilla-Gokcumen, G. E.; Grundler, K.; Corazon
Frias, C.; Prokop, A. Dalton Trans. 2009, 10882.
(4) Ratanaphan, A.; Temboot, P.; Dyson, P. J. Chem. Biodiversity
2010, 7, 1290.
(5) Grguric-Sipka, S.; Stepanenko, I. N.; Lazic, J. M.; Bartel, C.;
Jakupec, M. A.; Arion, V. B.; Keppler, B. K. Dalton Trans. 2009, 3334.
ꢀꢁ
(6) Casini, A.; Karotki, A.; Gabbiani, C.; Rugi, F.; Vasak, M.;
€
Totzke, F.; Schachtele, C.; Kubbutat, M. H. G.; Meijer, L.; Lemcke, T.
ChemBioChem 2005, 6, 541.
(15) Becker, A.; Kohfeld, S.; Lader, A.; Preu, L.; Pies, T.; Wieking,
K.; Ferandin, Y.; Knockaert, M.; Meijer, L.; Kunick, C. Eur. J. Med.
Chem. 2010, 45, 335.
Messori, L.; Dyson, P. J. Metallomics 2009, 1, 434.
(7) Renfrew, A. K.; Phillips, A. D.; Egger, A. E.; Hartinger, C. G.;
Bosquain, S. S.; Nazarov, A. A.; Keppler, B. K.; Gonsalvi, L.; Peruzzini,
M.; Dyson, P. J. Organometallics 2009, 28, 1165.
(16) Dobrov, A.; Arion, V. B.; Kandler, N.; Ginzinger, W.; Jakupec,
ꢁ
M. A.; Rufinska, A.; G. v. Keyserlingk, N.; Galanski, M.; Kowol, C.;
(8) Mendoza-Ferri, M. G.; Hartinger, C. G.; Mendoza, M. A.;
Groessl, M.; Egger, A. E.; Eichinger, R. E.; Mangrum, J. B.; Farrell,
N. P.; Maruszak, M.; Bednarski, P. J.; Klein, F.; Jakupec, M. A.;
Nazarov, A. A.; Severin, K.; Keppler, B. K. J. Med. Chem. 2009, 52, 916.
(9) Kandioller, W.; Hartinger, C. G.; Nazarov, A. A.; Bartel, C.;
Skocic, M.; Jakupec, M. A.; Arion, V. B.; Keppler, B. K. Chem.;Eur. J.
2009, 15, 12283.
(10) Anand, R.; Maksimoska, J.; Pagano, N.; Wong, E. Y.; Gimotty,
P. A.; Diamond, S. L.; Meggers, E.; Marmorstein, R. J. Med. Chem.
2009, 52, 1602.
Keppler, B. K. Inorg. Chem. 2006, 45, 1945.
(17) Ginzinger, W.; Arion, V. B.; Giester, G.; Galanski, M.; Keppler,
B. K. Cent. Eur. J. Chem. 2008, 6, 340.
(18) Schmid, W. F.; Zorbas-Seifried, S.; John, R. O.; Arion, V. B.;
Jakupec, M. A.; Roller, A.; Galanski, M.; Chiorescu, I.; Zorbas, H.;
Keppler, B. K. Inorg. Chem. 2007, 46, 3645.
(19) Schmid, W. F.; John, R. O.; Arion, V. B.; Jakupec, M. A.;
Keppler, B. K. Organometallics 2007, 26, 6643.
€
(20) Schmid, W. F.; John, R. O.; Muhlgassner, G.; Heffeter, P.;
Jakupec, M. A.; Galanski, M.; Berger, W.; Arion, V. B.; Keppler,
€
(11) Filak, L. K.; Muhlgassner, G.; Jakupec, M. A.; Heffeter, P.;
B. K. J. Med. Chem. 2007, 50, 6343.
(21) Primik, M. F.; Muhlgassner, G.; Jakupec, M. A.; Zava, O.;
€
Berger, W.; Arion, V. B.; Keppler, B. K. J. Biol. Inorg. Chem. 2010, 15,
903.
Dyson, P. J.; Arion, V. B.; Keppler, B. K. Inorg. Chem. 2010, 49, 302.
r
2010 American Chemical Society
Published on Web 12/27/2010
pubs.acs.org/Organometallics

274 Organometallics, Vol. 30, No. 2, 2011
Filak et al.
Chart 1. Indolo[3,2-d]benzazepine (left) and Indolo[3,2-
c]quinoline (right) Backbones with Atom-Numbering Schemes
indolo[3,2-c]quinolines 1a,b-8a,b (Scheme 1, Chart 2), of
which six were characterized by X-ray diffraction, their spec-
troscopic properties (NMR, UV-vis, FT-IR), thermal beha-
vior, and ESI mass spectra. The cytotoxic activity of these
metal complexes assayed in vitro in three human cancer cell
lines, CH1 (ovarian carcinoma), SW480 (colon adeno-
carcinoma), and A549 (non-small-cell lung carcinoma), is also
reported.
that an intact lactam unit is favorable for cdk inhibition.13,22,23
In vitro cytotoxicity of ruthenium and osmium complexes was,
however, found to be higher if complexation occurred via the
modified lactam group and not through a chelator group at
position 9 of the paullone backbone.20
Experimental Section
