Induced Wide Nematic Phase by Seven-Ring
Supramolecular H-Bonded Systems: Experimental
and Computational Evaluation
Latifah Abdullah Alshabanah 1, Laila A. Al-Mutabagani 1, Hoda A. Ahmed 2,3,
*
and
Mohamed Hagar 3,4,
*
1
Chemistry Department, College of Science, Princess Nourah bint Abdulrahman University, Riyadh 11671,
Saudi Arabia; Laalsabanah@pnu.eud.sa (L.A.A.); Laalmutbagani@pnu.edu.sa (L.A.A.-M.)
Department of Chemistry, Faculty of Science, Cairo University, Cairo 12613, Egypt
Chemistry Department, College of Sciences, Yanbu, Taibah University, Yanbu 30799, Saudi Arabia
Chemistry Department, Faculty of Science, Alexandria University, Alexandria 21321, Egypt
Correspondence: ahoda@sci.cu.edu.eg (H.A.A.); mhagar@taibahu.edu.sa (M.H.)
2
3
4
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editors: Giuseppe Cirillo and Derek McPhee
Received: 23 March 2020; Accepted: 3 April 2020; Published: 7 April 2020
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: New seven-ring systems of dipyridine derivative liquid crystalline 2:1 supramolecular
H-bonded complexes were formed between 4-n-alkoxyphenylazo benzoic acids and
4-(2-(pyridin-4-yl)diazenyl)phenyl nicotinate. Mesomorphic behaviors of the prepared complexes
were investigated using a combination of differential scanning calorimetry (DSC) and polarizing optical
microscopy (POM). Fermi bands attributed to the presence of intermolecular H-bond interactions
were confirmed by FT–IR spectroscopy. All prepared complexes possessed an enantiotropic nematic
phase with a broad temperature nematogenic range. Phases were confirmed by miscibility with a
standard nematic (N) compound. A comparison was constructed to investigate the influence of the
incorporation of the azophenyl moiety on the mesomeric behavior of corresponding five-membered
complexes. It was found that the present complexes observed induced a wide nematic phase with
relatively higher temperature ranges than the five aromatic systems. Density functional theory (DFT)
suggested the nonlinear geometry of the formed complex. The results of the DFT explained the
nematic mesophase formation. Moreover, the π–π stacking of the aromatic moiety in the phenylazo
acid plays an effective role in the mesomorphic thermal stability. The energy difference between
the frontier molecular orbitals, HOMO (highest occupied) and LUMO (lowest occupied), and the
molecular electrostatic potential (MEP) of the prepared complexes were estimated by DFT calculations.
The results were used to illustrate the observed nematic phase for all H-bonded supramolecular
complexes. Finally, photophysical studies were discussed which were carried out by UV spectroscopy
connected to a hot stage.
Keywords: supramolecular H-bonding complexes; dinitrogen H-boning complexes; nematic stability;
DFT calculations; photophysical
1. Introduction
In the last few years, interesting studies of heterocyclic liquid crystal compounds comprising
azopyridene moieties have been prepared and their mesomorphic properties were characterized [1–11].
The incorporation of heterocyclic rings with electronegative hetero-atoms (N, O or S) will enhance
and impact powerful polar induction [12]. The conjugation of heterocyclic mesogens offered organic
photonics applications powers of heterocyclic mesogens offered organic photonics applications [13].
In fact, the ability of trans-cis-isomerization upon thermal and photoirradiation of azopyridene
Molecules 2020, 25, 1694; doi:10.3390/molecules25071694
www.mdpi.com/journal/molecules

Molecules 2020, 25, 1694
2 of 16
liquid crystals (LCs) makes them good candidates due to their photo-responsiveness [14
,15], making
it interesting to study such properties. Recently, azopyridene has been used in the formation of
nanofiber supramolecular self-assembling and hydrogen/halogen-bonding LCs with photo-induced
transition phenomena [16
(SMLCs) through intermolecular hydrogen-bonding interactions are also concerns of our area of
interest [ 21 26]. The use of heterocyclic rings (dipyridine) with different nitrogen atom orientations
widely improves many characteristics of SMLCs complexes [27 28]. Changes in the structural and
–20]. Designing of photosensitive supramolecular liquid crystal materials
6
,
–
,
molecular characteristics may impact mesomorphic properties essential for technical use. A combination
of rigid (aromatic) and flexible segments (alkyl chains) are essential in designing anisotropic LCs
architectures with better phase transitions. Recently, the construction of materials according to
previous computational predictions has received high attention from many researchers [1,29–38]. The
mutual influence of many optical parameters requires stimulated information regarding the energies
of molecular orbitals as well as the molecular geometries of designed compounds. Very recently,
our research group [4,10,22,39–47] focused on the computational parameters of new synthesized
supramolecular liquid crystal (SMLC) systems by illustrating the behavior of the supramolecular
H-bonded complexes of carboxylic acids and pyridine derivatives experimentally and theoretically.
The molecular shape and alkoxy chain length (as terminals) play an important role in the formation,
thermal stability, type, mesomorphic range, as well as estimated geometrical and thermal parameters
of liquid crystalline architectures. The molecules tend to be oriented in a parallel arrangement as
the length of the terminal substituent increases [48]. In addition, the terminal chain length plays an
important role in influencing the heliconical and twist–bend nematic phases [49,50].
Based on the above context, the aim of the present study is to design new seven-ring architectures
of 2:1 supramolecular H-bonded (SMHB) complexes based on dipyridine and phenyl nicotinate as
base moieties (B), and 4-n-alkoxyphenylazobenzoic acids as H-donor moieties (In). The purpose of this
study is to investigate their mesomorphic and optical properties as well as their geometrical parameters.
Moreover, we studied theoretical (DFT) calculations to understand the experimental variables that
could be affected by the possible orientation of dinitrogen atoms for the predicted conformers which
impacts the degree of the intermolecular interaction between the SMHBCs. Further, a comparison
is established between the present seven-membered systems and previous five aromatic ring SMHB
complexes (IIn/B, Scheme 1) to investigate the effect of incorporation of an additional phenylazo group
on estimated experimental and theoretical parameters.
O
N
OCnH2n+1
N
H2n+1CnO
H O
O
O
N
N
N
N
N
O
H
N
O
In/B
O
OCnH2n+1
H O
O
O
N
H2n+1CnO
N
N
O
H
N
O
IIn/B
Scheme 1. 2:1 Supramolecular hydrogen bonded complexes In/B and IIn/B.

Molecules 2020, 25, 1694
3 of 16
2. Experimental
The dinitrogen base
Supplementary Data.
B
was synthesized according to the procedure mentioned in the
Preparation of 2:1 SMHB Complexes
Supramolecular In/B complexes were prepared from 2:1 molar ratios of alkoxyphenylazobezoic
acids (In) with different chain lengths from n = 6 to n = 12 and a dinitrogen base (
B), respectively. The
solid mixture was melted together in dry watch glass at
≈
270 ◦C with stirring to form an intimate
blend and then allowed to cool to room temperature (Scheme 2). The formation of supramolecular
complexes (In/B) was proved by DSC investigation as well as FT–IR spectroscopy.
Scheme 2. Preparation of 2:1 supramolecular H-bonded complexes (In/B).
3. Results and Discussion
3.1. FT–IR Characterizations of 2:1 SMHB Complexes
The mixing of an acid and a base affords four possible kinds of products: (a) a mixture of
non-ionized acids and bases; (b) the H-bonding supramolecular complexes; (c) pure organic ionic
salts; and (d) salts in association with H-bonded supramolecular complexes [51]. However, these
mixtures could be confirmed with the FT–IR spectroscopy. The pure ionic salts could be confirmed by
the presence of the C=O stretching vibration lower than 1700 cm−1. On the other hand, the H-bonded
formation increases the C=O stretch vibration more than that of the free acid. Finally, the case such
mixing could be proven by the presence of two absorption peaks, one higher than 1700 cm−1 and the
other lower. In the present study, the absence of the lower stretching frequency <1700 cm–1 is evidence
of the presence of H-bonded supramolecular complexes as the only product [52,53].
The formation of the dinitrogen compound and the azo acid was confirmed by FT–IR spectral
data measurements for the individual components as well as to their supramolecular complexes. The
FT–IR spectrum of I10, B and their complex I10/B (as representative examples) are given in Figure 1.
The signal at 1681 cm−1 was assigned to the dimeric C=O group of the azo acid. The dimeric H-bond
between the azo acids is replaced with that between the azo acid (I10). The nitrogen of dipyridine
(
B
) could be confirmed by the FT–IR measurements. An important piece of evidence concerning the
H-bonded supramolecular complexes formation is the C=O, OH stretching vibration. It has been
reported [38 54 59] that the presence of three Fermi resonance vibration bands of the H-bonded OH
groups -, - and -types provides evidence for the supramolecular complex formation. The -type
Fermi band of complex I10/B is overlapped with that of the C–H vibrational peaks at 2921 to 2855
cm−1. Moreover, the peak at 2452 (I10/B) and could be assigned to
-type of the in-plane bending
vibration of the O–H. On the other hand, 1901 cm−1 is corresponding to the
-type Fermi band due to
,
B
–
A
C
A
B
C
the interaction between the overtone of the torsional effect and the fundamental stretching vibration of
the OH.

Molecules 2020, 25, 1694
4 of 16
Figure 1. FT–IR spectra of B, I10 and their supramolecular I10/B complex.
3.2. Mesomorphic Study of 2:1 SMHBLC Complexes
Interestingly, mesomorphic and optical behaviors of the seven-ring 2:1 supramolecular H-bonded
systems (In/B) were analyzed. Details of the transition temperatures and their associated enthalpy, as
well as the normalized entropy of the mesophase transition for all investigated SMHB In/B complexes,
as derived from DSC measurements, are summarized in Table 1. Transition temperatures of the
investigated complexes are represented graphically in Figure 2 in order to evaluate the effect of terminal
alkoxy chain lengths of acid components on the mesophase behavior. During heating and cooling
scans, all SMLHB complexes showed only enantiotropic nematic phase. The POM measurements
revealed textures which confirmed the thread/schlieren texture of the nematic mesophase (Figure 3).
In order to confirm that the N phase is the only mesophase exhibited by all complexes, miscibility
studies were constructed between the present complexes and the standard nematic 4-hexyloxy benzoic
acid, resulting in only an enantiotropic N phase. Representative DSC thermograms on the second
heating/cooling cycles of supramolecular I12/B complexes are shown in Figure 4.
Table 1. Phase transition temperatures (◦C), enthalpy of transitions (kJ/mol) and normalized transition
entropy of supramolecular In/B complexes.
System
TCr-N
∆HCr-N TN-I
∆HN-I
∆S/R
I6/B
I8/B
I10/B
I12/B
168.5
153.1
163.8
169.2
47.65
57.38
61.49
64.08
241.2
237.4
234.0
230.1
4.8
1.12
1.28
1.44
2.05
5.43
6.08
8.57
Abbreviations:
TN-I: Nematic to isotropic liquid transition. ∆HN-I: Nematic to isotropic liquid phase transition.
∆S/R: Normalized entropy transition.

Molecules 2020, 25, 1694
5 of 16
Figure 2. Graphical DSC transitions of the 2:1 supramolecular complex series, In/B.
Figure 3. DSC thermograms on the second heating/cooling cycles of the 2:1 supramolecular H-bonded
(SMHB) complex I12/B at a rate of 10 ◦C/min.

Molecules 2020, 25, 1694
6 of 16
Figure 4. Nematic polarizing optical microscopy (POM) textures on heating for 2:1 supramolecular
complexes (a) I12/B at 218.0 ◦C, (b) I12/B at 225.0 ◦C (c) and I8/B at 180.0 ◦C phases.
The evaluated data of Table 1 and Figure 2 revealed that enantiotropic nematic mesophase was
only observed for all investigated 2:1 mixtures and their thermal stabilities declined by increasing
the terminal alkoxy chain length of the alkoxyphenylazobezoic acid component from n = 6 to 12.
Additionally, the melting point transitions have irregular trends. It should be mentioned that the
thermal and optical result of dipyridine derivative
B is nonmonomorphic and converted directly
from solid crystal to isotropic liquid at 148.1 ◦C. Meanwhile, the pure alkoxyphenylazobezoic acid
derivatives In exhibit a smectic C phase (SmC) with relatively high transition temperatures and nematic
phase (N) with a very narrow range [60]. Despite that the dipyridine compound
B did not exhibit any
phases, all prepared 2:1 supramolecular In/B complexes observed an induced wide nematic phase
with relatively higher value temperature ranges for the complex I8/B (~84.3 ◦C) and lower values for
I12/B (~60.9 ◦C). In addition, the nematic transition stability decreases with the increment of the chain
attached to the acid complement (n); thus, the length and the core of the H-donor molecule is found to
be more dominant on the stability of the observed N phase. It can be concluded that the increment
of the molecular anisotropy in the SMHB complexes promotes the broadening of nematic phases
that agree with the previous work [22] which revealed that the increase of the mesogenic part length
enhances the stability of nematic phases. The nematic range (
I8/B I6/B I10/B I12/B. Supramolecular complex I8/B has the highest broad mesomorphic range.
The descending trend in the N thermal stability with terminal chain length can be concluded to the
dilution of the rigid mesogenic core [61 62]. This could be due to the higher van der Waals attractions
∆TN = TN-Tcr) is decreased in the order
>
>
>
n
,
between the longer alkoxy chain length leading to the intertwining and facilitates terminal interaction
and alkyl group aggregation which are important effects for the nematic phase enhancement.
The normalized entropy, driven form DSC, of transitions (∆S/R) were calculated for the present
supramolecular In/B complexes and the results are tabulated in Table 1. The results indicate an
increment of the entropy change with the terminal alkoxy chain length (Figure 5) that reflects the
decrease in the biaxiality of the mesogenic part, resulting in an increase in conformational entropy [55].
Moreover, the variation in the entropy change with alkoxy chain length may be attributed to the change

Molecules 2020, 25, 1694
7 of 16
of molecular interactions between molecules, which are affected by the dipole moment, polarizability,
rigidity, aspect ratio (length/breadth ratio) and geometrical shape of molecules. These factors may
contribute to the conformational, orientational and translational entropies of the molecule in different
amounts. The increase of ∆S/R values when increasing the number of carbons in the alkoxy chain
is probably due to the disappearance of the long orientational order and increase of the number of
conformational distributions at the mesophase transitions.
Figure 5. Normalized entropy changes with the alkoxy chain length of SMHB In/B complexes.
In order to investigate the effect of the incorporation of an extra phenylazo group part to the acid
moiety on the mesomorphic behavior, a comparison was constructed between the mesophase stability
(TC) of the present investigated seven-ring In/B complexes with the data reported of the previously
prepared five-ring SMHB complexes IIn/B [63] (Figure 6). As can be seen from Figure 4, the addition
of the extra phenylazo group into IIn/B resulted in a significant increase in the Tc nematic values. The
nematic stability (TN) values were found to increase in the range of 97.9, 93.4, 90.3 and 89.4 ◦C for
alkoxy acid chains n = 6, 8, 10 and 12, respectively. These increments are attributed to the increase of
polarizability of the whole seven-aromatic-ring molecules as well as the increase of rigidity and the
aspect ratio, which, in turn, lead to an increase of intermolecular interactions between molecules.
In/B
240
200
160
120
IIn/B
6
8
10
12
Alkoxy chain length (n)
Figure 6. Comparison between the present SMHB In/B complexes (
nematic stability.
•
) and five-ring IIn/B system (
#
) in

Molecules 2020, 25, 1694
8 of 16
3.3. DFT Calculations
3.3.1. Molecular Geometries
All DFT calculations were carried out using the DFT/B3LYP method at the basis set 6-31G (d,p)
for all In/B complexes. Since imaginary frequencies are absent, this could provide evidence for the
geometrical stability of all H-bonded complexes. Figure 7 shows the geometrical structure of the
bonded complexes of the base B with the azo acid In of n = 12 carbon atoms in the alkoxy chain.
Figure 7. The calculated geometry of B, I12 and I12/B.
As shown from Figure 7, although both base B, as well as the acid I12, are completely linear,
the geometry of the formed complex is not completely linear. The formed complex has two parts.
The first is linear, derived from the azopyridene moiety of the dinitrogen compound, and the other
non-linear part is that of the nicotinate ester. The length of the complex derived from azo acid I12 is
77.20 Å and its height is 15.01 Å to form a molecule with area 1158.57 Å2. The length of the linear part
is 18.89 Å and that of the non-linear one is 54.28 Å. On the other hand, the angle of the non-linear
part is 144◦. The unsymmetrical geometry of the formed complex could be an explanation of the
nematic mesophase formation. This geometry cannot permit the lateral interaction of the molecule
to enhance the smectic mesophase; however, it leaves the terminal aggregation of the alkoxy groups
to be predominated to enhance the nematic mesophase. The presence of the aromatic part of these
supramolecular complexes could explain the high thermal stability and mesophase range, Tc = 230.1
and
were affected by the length of the observed mesophase, and this could be another evidence of the
effect of the stacking of the aromatic moiety on the azo acid that can increase the stability of the
∆T
N = 60.9 ◦C, respectively. On the other hand, neither the mesophase range nor their stability
π–π
enhanced mesophase [64–67].
3.3.2. Effect of the H-Bonding and π–π Stacking on the Mesophase Behavior
The investigation of the impact of the H-bonding interactions on the mesophase stability and
mesophase range can be achieved by a comparison of the mesomorphic behavior of the H-bonded I12/B
complex with the individual azo acid I12. It has been reported [60] that the azo acid I12 has smectic
C and narrow nematic range (only
≈
6 ◦C), however, the formation of the H-bonded complex I12/B
induced the nematic range to be 60.9 ◦C. The induction of the wide nematic range could be attributed
to the higher degree of the terminal aggregation of the alkoxy chains of the H-bonded complex with
respect to the free acid. Moreover, the presence of the three aromatic rings of the dinitrogen compound
B
can also increase the range by extra parallel interactions of the aromatic rings of the H-bonded

Molecules 2020, 25, 1694
9 of 16
complex. Furthermore, the linear and planar geometry of the free azo acid I12 enhances the smectic C
mesophase with a very narrow range of the nematic phase due to the high degree of lateral interaction
which facilitates close packing of the molecules to grow the more ordered smectic mesophase. However,
the less linear geometry of the formed supramolecular I12/B complex decreases the chance of the
lateral interaction with higher terminal aggregation forces to enhance the nematic mesophase of more
random textures.
The effect of the number of the aromatic rings that impacts the degree of the backing of the
molecules is also studied with the previously reported supramolecular H-bonded complex of the
same dinitrogen base
aromatic rings instead of five rings of the alkoxybenzoic acid complexes. The higher number of the
aromatic rings helps the strong stacking of the molecules to increase the mesophase stability of the
B with dodecyloxybenzoic acid [68]. Our present compounds have seven
π–π
seven aromatic rings H-bonded complexes than that of the five aromatic rings of alkoxybenzoic acid
complexes. The dodecyloxybenzoic acid H-bonded interactions of II12/B showed nematic stability
140.7 ◦C with respect to 230.1 ◦C of the azo acid I12. This data could be explained in terms of the higher
degree of π–π stacking of the I12/B H-bonded complexes due to the incorporation of the phenylazo
group than that of the five-ring II12/B system.
3.3.3. Thermal Parameters
Values of thermal parameters were calculated with the same method at the same set for the 2:1
supramolecular H-bonded complexes I6/B, I8/B, I10/B and I12/B. All evaluated data are summarized in
Table 2. The calculated data of Table 2 illustrate that the increment of the chain length highly affects the
estimated stability of the supramolecular complexes, whereas the chain length increases the predicted
energy deceases. The increment of alkoxy chain length has a negative effect on the predicted total
energy and positive effect on the nematic mesophase stability of prepared H-bonded In/B complexes.
Table 2. Thermal Parameters (Hartree/Particle) of I6/B, I8/B, I10/B, I12/B and II8/B.
Parameter
I6/B
I8/B
I10/B
I12/B
II8/B
Ecorr
ZPVE
Etot
H
1.025964
1.140069
1.254160
1.368322
0.959290
−3168.161489 −3325.295728 −3482.429991 −3639.564172 −2644.501692
−3168.093627 −3325.222380 −3482.351174 −3639.479910 −2644.441531
−3168.092683 −3325.221436 −3482.350230 −3639.478966 −2644.440586
−3168.288686 −3325.431743 −3482.573992 −3639.716414 −2644.616210
G
Abbreviations: Ecorr: Thermal correction to energy; ZPVE: Sum of electronic and zero-point energies; Etot: Sum of
electronic and thermal energies; H: Sum of electronic and thermal enthalpies; G: Sum of electronic and thermal
free energies.
3.3.4. Frontier Molecular Orbitals, Dipole Moment and Polarizability
Figures 8 and 9 show that the estimated plots for frontier molecular orbitals HOMO (highest
occupied) and LUMO (lowest unoccupied) of In/B and II8/B. From these figures, it is clear that
the electron densities are mainly localized on the phenylazo acid (In) for HOMO while it shifted
to the dinitrogen base in the case of LUMO. The energy difference between the frontier molecular
orbitals (∆E) could be used in the prediction of the capability of electrons to transfer from HOMO
to LUMO by any electron excitation process. The global softness (S) = 1/∆E is the parameter that
predicts the polarizability as well as the sensitivity of the compounds for the photoelectric effects.
The higher global softness of the compounds enhanced their photoelectric sensitivity as well as their
polarizability. As shown from Table 3 and Figure 9, there is no significant effect of the length of the
alkoxy chain on softness. However, the number of the aromatic ring has a high impact on the softness,
and the supramolecular H-bonded complexes derived from the alkoxyphenylazobezoic In
/B acids are
softer than that of the alkoxybenzoic IIn acids. The extra conjugation of the seven aromatic ring
/
B
supramolecular In/B complexes has higher polarizability than the five-ring complexes IIn/B. Moreover,
the lower energy difference of IIn/B increases its polarizability to 949.74 of the complexes derived from

Molecules 2020, 25, 1694
10 of 16
octyloxyphenylazo acid (I8/B) instead of 661.95 for the octyloxybenzoic acid-based complex, II8/B. On
the other hand, the length of the alkoxy chain of the acid component highly impacts the polarizability.
Figure 8. The estimated plots for frontier molecular orbitals of I8/B and II8/B.
Figure 9. The estimated plots for frontier molecular orbitals of supramolecular In/B complexes.
Table 3. FMO Energies a.u., Polarizability,
and II8/B.
α, and Dipole Moment µ (Debye) of I6/B, I8/B, I10/B, I12/B
Parameter
I6/B
I8/B
I10/B
I12/B
II8/B
ELUMO
EHOMO
∆EHOMO-LUMO
1/∆E
−0.12678
−0.22048
0.0937
10.67236
1.7921
−0.12686
−0.22039
0.09353
10.69176
1.7962
−0.12703
−0.22028
0.09325
10.72386
1.7948
−0.12704
−0.22028
0.09324
10.72501
1.7348
−0.12450
−0.22693
0.10243
9.762765
2.6037
µ Total
Polarizability α
901.07
949.74
997.65
1045.29
661.95
As we recently reported [63], the magnitude of the dipole moment affects the type of mesophase
and its behavior. As shown in Table 3 the dipole moment of prepared complexes has an insignificant
,
effect on the calculated dipole moment, and this could be illustrated in terms of the similar of the
electronic nature of the alkoxy chains even for longer C-chains. However, the alkoxybenzoic acid IIn/B
complexes are higher than that of the alkoxyphenylazobezoic acid In/B complexes. The higher dipole
moment increases the lateral interaction with respect to the terminal one, and this could be a good
explanation on the wide range nematic mesophase formation for the SMLC In/B complexes and with
respect to their corresponding IIn/B.

Molecules 2020, 25, 1694
11 of 16
3.3.5. Molecular Electrostatic Potential (MEP)
The charge distribution map for In/B was calculated with the same method on the same basis sets
according to the molecular electrostatic potential (MEP; Figure 10). The negatively charged atomic sites
(the red region) were estimated to be localized on carboxylate moiety of the alkoxyphenylazobezoic
acid, while the moiety of the dinitrogen base as well as the alkyl chain was predicted to show the least
negatively charged atomic sites (blue regions). As shown from Figure 10, the orientation of the charges
is not affected by the length of the alkoxy chain, and consequently, this could be an illustration for the
similarity of the mesophase behavior regardless of the chain length. The increment of the alkoxy chain
length of In/B affects neither the orientation nor the amount of the charge distribution map, and this
could illustrate the observed nematic phase for all H-bonded supramolecular complexes due to more
end-to-end aggregation of the terminal alkoxy chains.
Figure 10. Molecular electrostatic potential (MEP) of I6/B, I8/B, I10/B and I12/B.
3.4. Photophysical Behavior
The photophysical investigation of the I12/B complex as an example of a supramolecular H-bonded
mixture was carried out by measuring UV–vis spectra. A solution of C = 1.8
10−6 mol/L in DMF was
·
used to record spectrophotometric absorption spectra bands at a temperature range of 298–398 K. All
photoisomerization absorption bands’ results are graphically represented in Figure 11. As shown in
Figure 11, the SMHB I12/B complex has maximum absorption bands at ~361 nm and ~514 nm with a
small shoulder at ~460 nm. The absorbance slightly increases with the temperature range. The highly
delocalized electronic systems and
linking parts with high molar absorption coefficient (
π
–
π
* transitions, due to the presence of conjugated dinitrogen
= 10.4
105 L mol−1cm−1), were recognized to
ε
·
the maximum absorption in the present H-bonding interactions. Moreover, the absorption and the
intensity of the peak in the absorption spectrum are depending on the molecule which absorbs the
light of a given wavelength. The absorption spectra of the complex showed maxima bands at 361 nm
which attributed to the electronic transition from the highest occupied molecular orbitals (HOMO) to
lowest unoccupied molecular orbital (LUMO) π–π transition [69–71].

Molecules 2020, 25, 1694
12 of 16
Figure 11. UV absorption spectrum of SMHB complex I12/B in DMF with a heating range from 25 to
100 ◦C.
4. Conclusions
Herein, we have reported the synthesis of new supramolecular H-bonded complexes of seven
aromatic rings dipyridine-based derivative. Mesomorphic and optical characterizations were carried
out by DSC, POM and UV spectroscopy. Interestingly, the orientations of dinitrogen atoms in the
base moiety play an important role in the observation of enantiotropic nematic mesophase with broad
nematogenic stability range for all mixtures. All these findings illustrate the purposes of the selection
of azo linkers and explain how they could possess excellent characteristics to be of great potential
and as valuable candidates for developing new applicable nematogenic architectures. Theoretical
calculations provided information to understand the experimental results in terms of the relationships
of the thermal and geometrical parameters. It was found that the π–π stacking of the aromatic moiety
in the phenylazo acid plays an effective role in the wide mesomorphic thermal stability. Moreover,
the DFT results explained how the aspect ratio of the complexes under investigation enhanced the
mesophase ranges compared with our previously reported H-bonded complexes of the same dinitrogen
base with short alkoxy chain arms. Further, the photophysical studies revealed for all complexes
involves isomerization.
Supplementary Materials:
The following are available online.
Scheme S1:
Preparation of
4-(2-(pyridin-4-yl)diazenyl)phenyl nicotinate (I), Table S1: Phase transition temperatures (◦C), enthalpy of
transitions (kJ/mol), and transition entropy of supramolecular complex IIn/B.
Author Contributions: Data curation, L.A.A.-M., H.A.A. and M.H.; formal analysis, L.A.A.-M., L.A.A., and
M.H.; funding acquisition, L.A.A.-M., L.A.A., and H.A.A.; methodology, L.A.A.-M., L.A.A., H.A.A., and M.H.;
project administration, M.H.; resources, L.A.A. and H.A.A.; software, M.H.; writing—original draft, H.A.A. and
M.H.; writing—review and editing, H.A.A., M.H. All authors have read and agreed to the published version of
the manuscript.
Funding: This research was funded by the Deanship of Scientific Research at Princess Nourah bint Abdulrahman
University through the Fast-Track Research Funding Program.
Conflicts of Interest: The authors declare no conflicts of interest.

Molecules 2020, 25, 1694
13 of 16
References
1.
Hagar, M.; Ahmed, H.; Alhaddad, O. DFT calculations and mesophase study of coumarin esters and its
azoesters. Crystals 2018, 8, 359. [CrossRef]
2.
Hagar, M.; Ahmed, H.; Alhaddad, O. Experimental and theoretical approaches of molecular geometry and
mesophase behaviour relationship of laterally substituted azopyridines. Liq. Cryst. 2019, 46, 1440–1451.
[CrossRef]
3.
4.
5.
6.
7.
8.
9.
Naoum, M.M.; Fahmi, A.A.; Alaasar, M.A.; Salem, R.A. Supramolecular liquid crystals in binary and ternary
systems. Thermochim. Acta 2011, 517, 63–73. [CrossRef]
Ahmed, H.A.; Hagar, M.; Alhaddad, O.A. Phase behavior and DFT calculations of laterally methyl
supramolecular hydrogen-bonding complexes. Crystals 2019, 9, 133. [CrossRef]
Hagar, M.; Ahmed, H.; Saad, G. New calamitic thermotropic liquid crystals of 2-hydroxypyridine ester
mesogenic core: Mesophase behaviour and DFT calculations. Liq. Cryst. 2020, 47, 114–124. [CrossRef]
Ahmed, H.; Hagar, M.; Alhaddad, O. New chair shaped supramolecular complexes-based aryl nicotinate
derivative; mesomorphic properties and DFT molecular geometry. RSC Adv. 2019, 9, 16366–16374. [CrossRef]
Ong, L.-K.; Ha, S.-T.; Yeap, G.-Y.; Lin, H.-C. Heterocyclic pyridine-based liquid crystals: Synthesis and
mesomorphic properties. Liq. Cryst. 2018, 45, 1574–1584. [CrossRef]
Foo, K.-L.; Ha, S.-T.; Yeap, G.; Lee, S. Mesomorphic behaviors of a series of heterocyclic
thiophene-imine-ester-based liquid crystals. Phase Transit. 2018, 91, 509–520. [CrossRef]
Foo, K.-L.; Ha, S.-T.; Yeap, G.-Y.; Lin, H.-C. Mesomorphic behaviors of a series of heterocyclic
benzothiazole-imine-ester-based liquid crystals. Phase Transit. 2019, 92, 87–99. [CrossRef]
10. Nafee, S.S.; Ahmed, H.; Hagar, M. Theoretical, experimental and optical study of new thiophene-based
liquid crystals and their positional isomers. Liq. Cryst. 2020, 1–12. [CrossRef]
11. Du, S.; Zhang, M.; Chen, P.; Dang, J.; Gao, A.; Du, W.; Chen, X.; An, Z. Improved mesomorphic behaviour
and large birefringence of fluorinated liquid crystals containing ethynyl and 1-methyl-1h-benzimidazole
moieties. Liq. Cryst. 2020. [CrossRef]
12. Ghosh, T.; Lehmann, M. Recent advances in heterocycle-based metal-free calamitics. J. Mater. Chem. C 2017
,
5, 12308–12337. [CrossRef]
13. Zhang, X.-B.; Tang, B.-C.; Zhang, P.; Li, M.; Tian, W.-J. Synthesis and characterization of 1,3,4-oxadiazole
derivatives containing alkoxy chains with different lengths. J. Mol. Struct. 2007, 846, 55–64. [CrossRef]
14. Chen, Y.; Yu, H.; Quan, M.; Zhang, L.; Yang, H.; Lu, Y. Photothermal effect of azopyridine compounds and
their applications. RSC Adv. 2015, 5, 4675–4680. [CrossRef]
15. Garcia-Amorós, J.; Reig, M.; Cuadrado, A.; Ortega, M.; Nonell, S.; Velasco, D. A photoswitchable bis-azo
derivative with a high temporal resolution. Chem. Commun. 2014, 50, 11462–11464. [CrossRef]
16. Zhou, W.; Yu, H. Different morphologies of self-assembled nanofibers fabricated with amphiphilic
low-molecular-weight azopyridinium salts. RSC Adv. 2013, 3, 22155–22159. [CrossRef]
17. Zhou, W.; Kobayashi, T.; Zhu, H.; Yu, H. Electrically conductive hybrid nanofibers constructed with two
amphiphilic salt components. Chem. Commun. 2011, 47, 12768–12770. [CrossRef]
18. Zhang, H.; Hao, R.; Jackson, J.K.; Chiao, M.; Yu, H. Janus ultrathin film from multi-level self-assembly at
air–water interfaces. Chem. Commun. 2014, 50, 14843–14846. [CrossRef]
19. Mamiya, J.-I.; Yoshitake, A.; Kondo, M.; Yu, Y.; Ikeda, T. Is chemical crosslinking necessary for the
photoinduced bending of polymer films? J. Mater. Chem. 2008, 18, 63–65. [CrossRef]
20. Aoki, K.I.; Nakagawa, M.; Ichimura, K. Self-assembly of amphoteric azopyridine carboxylic acids: Organized
structures and macroscopic organized morphology influenced by heat, pH change, and light. J. Am. Chem.
Soc. 2000, 122, 10997–11004. [CrossRef]
21. Alaasar, M.; Tschierske, C.; Prehm, M. Hydrogen-bonded supramolecular complexes formed between
isophthalic acid and pyridine-based derivatives. Liq. Cryst. 2011, 38, 925–934. [CrossRef]
22. Ahmed, H.; Naoum, M. Mesophase behaviour of azobenzene-based angular supramolecular
hydrogen-bonded liquid crystals. Liq. Cryst. 2016, 43, 222–234. [CrossRef]
23. Naoum, M.M.; Fahmi, A.A.; Refaie, A.A.; Alaasar, M.A. Novel hydrogen-bonded angular supramolecular
liquid crystals. Liq. Cryst. 2012, 39, 47–61. [CrossRef]

Molecules 2020, 25, 1694
14 of 16
24. Naoum, M.; Fahmi, A.; Alaasar, M. Supramolecular hydrogen-bonded liquid crystals formed from
4-(4’-pyridylazophenyl)-4”-alkoxy benzoates and 4-substituted benzoic acids. Mol. Cryst. Liq. Cryst.
2008, 487, 74–91. [CrossRef]
25. Naoum, M.; Fahmi, A.; Alaasar, M. Supramolecular liquid crystals induced by hydrogen-bonding
interactions between non-mesomorphic compounds. I. 4-(4’-pyridylazophenyl)-4”-substituted benzoates
and 4-substituted benzoic acids. Mol. Cryst. Liq. Cryst. 2009, 506, 22–33. [CrossRef]
26. Naoum, M.M.; Fahmi, A.G.A.; Almllal, W.A. Supramolecular liquid crystals induced by hydrogen-bonding
interactions between non-mesomorphic compounds. II. effect of lateral substitution. Mol. Cryst. Liq. Cryst.
2010, 518, 109–128. [CrossRef]
27. Carli, J.T.; Lindberg, C.D.; Heltne, M.D.; Bornowski, E.C.; John, E.A.; Wiegel, K.N. Supramolecular main-chain
liquid crystalline polymers with competitive hydrogen bonding: Inclusion of structurally analogous hydrogen
bond acceptors and the effects on liquid crystallinity. Mol. Cryst. Liq. Cryst. 2017, 656, 83–88. [CrossRef]
28. Mallia, V.A.; George, M.; Das, S. Photochemical phase transition in hydrogen-bonded liquid crystals. Chem.
Mater. 1999, 11, 207–208. [CrossRef]
29. Chen, K.-Y. Crystal structure, hydrogen-bonding properties, and DFT studies of 2-((2-(2-hydroxyphenyl)
benzo [D] thiazol-6-Yl) methylene) malononitrile. Mol. Cryst. Liq. Cryst. 2015, 623, 285–296. [CrossRef]
30. Shoji, M.; Tanaka, F. Theoretical study of hydrogen-bonded supramolecular liquid crystals. Macromolecules
2002, 35, 7460–7472. [CrossRef]
31. Sundaram, S.; Jayaprakasam, R.; Dhandapani, M.; Senthil, T.; Vijayakumar, V. Theoretical (DFT) and
experimental studies on multiple hydrogen bonded liquid crystals comprising between aliphatic and
aromatic acids. J. Mol. Liq. 2017, 243, 14–21. [CrossRef]
32. Hagar, M.; Soliman, S.M.; Ibid, F.; El Sayed, H. Quinazolin-4-Yl-sulfanylacetyl-hydrazone derivatives;
synthesis, molecular structure and electronic properties. J. Mol. Struct. 2013, 1049, 177–188. [CrossRef]
33. Soliman, S.M.; Hagar, M.; Ibid, F.; El Sayed, H. Experimental and theoretical spectroscopic studies, homo–lumo,
nbo analyses and thione–thiol tautomerism of a new hybrid of 1,3,4-oxadiazole-thione with quinazolin-4-one.
Spectrochim. Acta Part A Mol. Biomol. Spectrosc. 2015, 145, 270–279. [CrossRef] [PubMed]
34. Hagar, M.; Soliman, S.M.; Ibid, F.; El Sayed, H. Synthesis, molecular structure and spectroscopic studies of
some new quinazolin-4 (3h)-one derivatives: An account on the N-versus S-alkylation. J. Mol. Struct. 2016,
1108, 667–679. [CrossRef]
35. Aboelnaga, A.; Hagar, M.; Soliman, S.M. Ultrasonic synthesis, molecular structure and mechanistic study of
1, 3-dipolar cycloaddition reaction of 1-alkynylpyridinium-3-olate and acetylene derivatives. Molecules 2016
,
21, 848. [CrossRef] [PubMed]
36. Ahmed, H.A.; Hagar, M.; El-Sayed, T.H.; Alnoman, R.B. Schiff base/ester liquid crystals with different lateral
substituents: Mesophase behaviour and DFT calculations. Liq. Cryst. 2019, 46, 1–11. [CrossRef]
37. Paterson, D.A.; Gao, M.; Kim, Y.-K.; Jamali, A.; Finley, K.L.; Robles-Hernández, B.; Diez-Berart, S.; Salud, J.;
De La Fuente, M.R.; Timimi, B.A. Understanding the twist-bend nematic phase: The characterisation of
1-(4-cyanobiphenyl-4’-yloxy)-6-(4-cyanobiphenyl-4’-yl) hexane (Cb6ocb) and comparison with Cb7cb. Soft
Matter 2016, 12, 6827–6840. [CrossRef]
38. Martinez-Felipe, A.; Cook, A.G.; Abberley, J.P.; Walker, R.; Storey, J.M.; Imrie, C.T. An FT-IR spectroscopic
study of the role of hydrogen bonding in the formation of liquid crystallinity for mixtures containing
bipyridines and 4-pentoxybenzoic acid. RSC Adv. 2016, 6, 108164–108179. [CrossRef]
39. Ahmed, H.; Hagar, M.; Alaasar, M.; Naoum, M. Wide nematic phases induced by hydrogen-bonding. Liq.
Cryst. 2019, 46, 550–559. [CrossRef]
40. Ahmed, H.; Hagar, M.; Aljuhani, A. Mesophase behavior of new linear supramolecular hydrogen-bonding
complexes. RSC Adv. 2018, 8, 34937–34946. [CrossRef]
41. Alnoman, R.B.; Ahmed, H.A.; Hagar, M.; Al-Ola, A.; Khulood, A.; Alrefay, B.S.; Haddad, B.A.; Albalawi, R.F.;
Aljuhani, R.H.; Aloqebi, L.D. Induced phases of new H-bonded supramolecular liquid crystal complexes;
mesomorphic and geometrical estimation. Molecules 2020, 25, 1549. [CrossRef]
42. Nafee, S.S.; Hagar, M.; Ahmed, H.A.; Alhaddad, O.; El-Shishtawy, R.M.; Raffah, B.M. New two rings schiff
base liquid crystals; ball mill synthesis, mesomorphic, hammett and DFT studies. J. Mol. Liq. 2020, 299,
112161. [CrossRef]

Molecules 2020, 25, 1694
15 of 16
43. Ahmed, N.H.; Saad, G.R.; Ahmed, H.A.; Hagar, M. New wide-stability four-ring azo/ester/schiff base liquid
crystals: Synthesis, mesomorphic, photophysical, and DFT approaches. RSC Adv. 2020, 10, 9643–9656.
[CrossRef]
44. Alnoman, R.; Ahmed, H.A.; Hagar, M.; Abu Al-Ola, K.; Alrefay, B.; Haddad, B.; AlBalawi, R.; Aljuhani, R.;
Aloqebi, L.; AlSenani, S. Induced Phases of New H-bonded Supramolecular Liquid Crystal Complexes;
Mesomorphic and Geometrical Estimation. Molecules 2020, 25, 1549. [CrossRef] [PubMed]
45. Al-Mutabagani, L.A.; Alshabanah, L.A.; Ahmed, H.A.; Hagar, M.; Al-Ola, K.A.A. New symmetrical U-and
wavy-shaped supramolecular H-bonded systems; geometrical and mesomorphic approaches. Molecules
2020, 25, 1420. [CrossRef] [PubMed]
46. Alhaddad, O.A.; Ahmed, H.A.; Hagar, M.; Saad, G.R.; Al-Ola, A.; Khulood, A.; Naoum, M.M. Thermal and
photophysical studies of binary mixtures of liquid crystal with different geometrical mesogens. Crystals
2020, 10, 223. [CrossRef]
47. Ahmed, H.; Hagar, M.; Alhaddad, O. Mesomorphic and geometrical orientation study of the relative position
of fluorine atom in some thermotropic liquid crystal systems. Liq. Cryst. 2020, 47, 404–413. [CrossRef]
48. Dave, J.S.; Menon, M. Azomesogens with a heterocyclic moiety. Bull. Mater. Sci. 2000, 23, 237–238. [CrossRef]
49. Abberley, J.P.; Killah, R.; Walker, R.; Storey, J.M.; Imrie, C.T.; Salamon´czyk, M.; Zhu, C.; Gorecka, E.;
Pociecha, D. Heliconical smectic phases formed by achiral molecules. Nat. Commun. 2018, 9, 228. [CrossRef]
50. Paterson, D.A.; Crawford, C.A.; Pociecha, D.; Walker, R.; Storey, J.M.; Gorecka, E.; Imrie, C.T. The role of
a terminal chain in promoting the twist-bend nematic phase: The synthesis and characterisation of the
1-(4-cyanobiphenyl-4’-yl)-6-(4-alkyloxyanilinebenzylidene-4’-oxy) hexanes. Liq. Cryst. 2018, 45, 2341–2351.
[CrossRef]
51. Stoimenovski, J.; Dean, P.M.; Izgorodina, E.I.; Macfarlane, D.R. Protic pharmaceutical ionic liquids and solids:
Aspects of protonics. Faraday Discuss. 2012, 154, 335–352. [CrossRef] [PubMed]
52. Pibiri, I.; Pace, A.; Buscemi, S.; Causin, V.; Rastrelli, F.; Saielli, G. Oxadiazolyl-pyridines and
perfluoroalkyl-carboxylic acids as building blocks for protic ionic liquids: Crossing the thin line between
ionic and hydrogen bonded materials. Phys. Chem. Chem. Phys. 2012, 14, 14306–14314. [CrossRef] [PubMed]
53. Dega-Szafran, Z.; Dulewicz, E. Infrared and 1 H nuclear magnetic resonance studies of hydrogen bonds in
some pyridine trifluoroacetates and their deuteriated analogues in dichloromethane. J. Chem. Soc. Perkin
Trans. 2 1983, 3, 345–351. [CrossRef]
54. Cleland, W.; Kreevoy, M.M. Low-barrier hydrogen bonds and enzymic catalysis. Science 1994, 264, 1887–1890.
[CrossRef] [PubMed]
55. Lizu, M.; Lutfor, M.; Surugau, N.; How, S.; Arshad, S.E. Synthesis and characterization of ethyl cellulose–based
liquid crystals containing azobenzene chromophores. Mol. Cryst. Liq. Cryst. 2010, 528, 64–73. [CrossRef]
56. Martínez-Felipe, A.; Imrie, C.T. The role of hydrogen bonding in the phase behaviour of supramolecular
liquid crystal dimers. J. Mol. Struct. 2015, 1100, 429–437. [CrossRef]
57. Ghanem, A.; Noel, C. FTIR investigation of two alkyl-p-terphenyl-4,4”-dicarboxylates in their crystalline,
smectic and isotropic phases. Mol. Cryst. Liq. Cryst. 1987, 150, 447–472. [CrossRef]
58. Paterson, D.A.; Martínez-Felipe, A.; Jansze, S.M.; Tm Marcelis, A.; Md Storey, J.; Imrie, C.T. New insights
into the liquid crystal behaviour of hydrogen-bonded mixtures provided by temperature-dependent FTIR
spectroscopy. Liq. Cryst. 2015, 42, 928–939. [CrossRef]
59. Walker, R.; Pociecha, D.; Abberley, J.; Martinez-Felipe, A.; Paterson, D.; Forsyth, E.; Lawrence, G.;
Henderson, P.; Storey, J.; Gorecka, E. Spontaneous chirality through mixing achiral components: A twist-bend
nematic phase driven by hydrogen-bonding between unlike components. Chem. Commun. 2018, 54,
3383–3386. [CrossRef]
60. Ahmed, H.; Naoum, M.; Saad, G. Mesophase behaviour of 1: 1 mixtures of 4-n-alkoxyphenylazo benzoic
acids bearing terminal alkoxy groups of different chain lengths. Liq. Cryst. 2016, 43, 1259–1267. [CrossRef]
61. Imrie, C.; Taylor, L. The preparation and properties of low molar mass liquid crystals possessing lateral alkyl
chains. Liq. Cryst. 1989, 6, 1–10. [CrossRef]
62. Imrie, C.T. Non-symmetric liquid crystal dimers: How to make molecules intercalate. Liq. Cryst. 2006, 33,
1449–1485. [CrossRef]
63. Nafee, S.S.; Ahmed, H.A.; Hagar, M. New architectures of supramolecular H-bonded liquid crystal complexes
based on dipyridine derivatives. Liq. Cryst. 2020, 1–14. [CrossRef]

Molecules 2020, 25, 1694
16 of 16
64. Liu, Y.; Zhan, G.; Zhong, X.; Yu, Y.; Gan, W. Effect of Pi–Pi stacking on the self-assembly of azomethine-type
rod–coil liquid crystals. Liq. Cryst. 2011, 38, 995–1006. [CrossRef]
65. Zang, L.; Che, Y.; Moore, J.S. One-dimensional self-assembly of planar
Π-conjugated molecules: Adaptable
building blocks for organic nanodevices. Acc. Chem. Res. 2008, 41, 1596–1608. [CrossRef]
66. Scherf, U.; Adamczyk, S.; Gutacker, A.; Koenen, N. All-conjugated, rod-rod block copolymers-generation
and self-assembly properties. Macromol. Rapid Commun. 2009, 30, 1059–1065. [CrossRef]
67. He, G.; Li, Y.; Liu, J.; Yang, Y. Enhanced electroluminescence using polystyrene as a matrix. Appl. Phys. Lett.
2002, 80, 4247–4249. [CrossRef]
68. Naoum, M.M.; Fahmi, A.A.; Mohammady, S.Z.; Abaza, A.H. Effect of lateral substitution
on supramolecular liquid crystal associates induced by hydrogen-bonding interactions between
4-(4’-pyridylazo-3-methylphenyl)-4”-alkoxy benzoates and 4-substituted benzoic acids. Liq. Cryst. 2010, 37,
475–486. [CrossRef]
69. Zhang, X.; Feng, H.; Yan, M.; Guo, H.; Yang, F. The novel rufigallol-based liquid crystals with cholesterol
units: Synthesis, mesomorphic and photophysical properties. Liq. Cryst. 2019, 46, 787–796. [CrossRef]
70. Lin, L.; Qin, W.; Cheng, B.; Guo, H.; Yang, F. The influence of multiple alkyl chains on mesomorphic and
photophysical properties of diphenylacrylonitrile liquid crystals. Liq. Cryst. 2019. [CrossRef]
71. Yang, M.; Liu, Z.; Li, X.; Yuan, Y.; Zhang, H. Influence of flexible spacer length on self-organization behaviors
and photophysical properties of hemiphasmidic liquid crystalline polymers containing cyanostilbene. Eur.
Polym. J. 2020, 123, 109459. [CrossRef]
Sample Availability: Samples of the compounds I6-12/B are available from the authors.
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
