Linear-shaped thermally activated delayed fluorescence emitter using 1,5-naphthyridine as an electron acceptor for efficient light extraction

Article abstract of DOI:10.1016/j.orgel.2019.105600

In this study, we developed a donor-π-acceptor-π-donor-type thermally activated delayed fluorescence (TADF) emitter (NyDPAc) using 1,5-naphthyridine as a core moiety. NyDPAc exhibited a high horizontal dipole ratio and thus a high external quantum efficiency (20.9%) even at a relatively low photoluminescence quantum yield (57%). 1,5-naphthyridine as an electron acceptor represents a promising core moiety for efficient TADF materials.

Full text of DOI:10.1016/j.orgel.2019.105600

Organic Electronics xxx (xxxx) xxx
Contents lists available at ScienceDirect
Organic Electronics
journal homepage: http://www.elsevier.com/locate/orgel
Linear-shaped thermally activated delayed fluorescence emitter using
1,5-naphthyridine as an electron acceptor for efficient light extraction
,
,*
Youngnam Leea, Seung-Je Woob, Jang-Joo Kimb **, Jong-In Honga
a Department of Chemistry, Seoul National University, Seoul, 08826, Republic of Korea
b Department of Materials Science and Engineering, Seoul National University, Seoul, 08826, Republic of Korea
A R T I C L E I N F O
A B S T R A C T
Keywords:
In this study, we developed a donor-π-acceptor-π-donor-type thermally activated delayed fluorescence (TADF)
Organic light emitting diode
Thermally activated delayed fluorescence
Light out coupling efficiency
Emitting dipole orientation
Naphthyridine
emitter (NyDPAc) using 1,5-naphthyridine as a core moiety. NyDPAc exhibited a high horizontal dipole ratio
and thus a high external quantum efficiency (20.9%) even at a relatively low photoluminescence quantum yield
(57%). 1,5-naphthyridine as an electron acceptor represents a promising core moiety for efficient TADF
materials.
1. Introduction
efficient TADF materials based on combinations of electron donors and
acceptors, OLED device efficiencies containing these emitters with near-
Organic light-emitting diodes (OLEDs) have attracted considerable
attention as a future display technology. Phosphorescence emitters can
attain 100% of the internal quantum efficiency (IQE) due to the strong
spin-orbit coupling of heavy metals [1,2], as compared to conventional
fluorescence emitters that yield only 25% of the IQE [3,4]. However,
because iridium and platinum used in phosphorescence emitters are
rare-earth elements and expensive, considerable effort has been devoted
to developing pure organic emitters which can reach 100% of the IQE.
Recently, thermally activated delayed fluorescence (TADF) materials
have received a great deal of attention as alternative OLED emitters
unity PLQYs are insufficient due to low light out-coupling efficiencies
[15–17]. Efficiency of TADF materials can be enhanced by employing
linear-shaped fluorescent molecules with a horizontal orientation. There
have been some reports about TADF emitters exhibiting a high hori-
zontal dipole ratio using triscarbazole, tri-spiral electron donor,
spiro-linked double electron donors and acceptors, and others [18–22].
However, to the best of our knowledge, 1,5-naphthyridine has not been
used as a core moiety for linear-shaped TADF molecules showing
excellent high horizontal dipole ratios.
1,5-naphthyridine has been known for its applications in pharma-
ceutical communities [23–25]. However, applications to OLEDs as an
electron acceptor remain largely unexplored. In this study, we designed
a linear-shaped TADF emitter (NyDPAc) by connecting 1,5-naphthyli-
dine as an electron acceptor and dimethylacridine as an electron
donor through a phenylene bridge (Fig. 1a). NyDPAc showed TADF
emission due to the orbital separation between the electron donor and
acceptor. Furthermore, the rod-like structure of NyDPAc induced hori-
zontal deposition during thermal evaporation, resulting in maximized
light out-coupling efficiency. Thus, the NyDPAc-based OLED device
showed a high EQE of 20.9% despite a relatively low PLQY (57%). This
is the first case of utilizing 1,5-naphthyridine as a linear acceptor for
achieving high TADF OLED efficiency.
[5–10]. TADF emitters require a small singlet-triplet energy gap (ΔEST
)
and have shown a maximum photoluminescence quantum yield (PLQY)
of 100% when triplet (T1) excitons are fully converted to singlet (S1)
excitons through reverse intersystem crossing (RISC). For high efficiency
OLEDs, both the IQE and external quantum efficiency (EQE) should be
considered, where the EQE is related to light out-coupling [11]. Even
when the IQE of TADF materials reaches 100%, the theoretical
maximum EQE is only 20% for isotropic materials due to limited light
out-coupling efficiencies [12,13]. Therefore, designing emitters which
can fully extract electroluminescence through the glass substrate is
necessary. These materials tend to be highly linear or planar, the dipoles
of which are aligned horizontally when thermally deposited [14].
In general, TADF materials can be designed by reducing the ΔEST
through distortion of electron donors and acceptors. Despite many
* Corresponding author.
** Corresponding author.
E-mail addresses: jjkim@snu.ac.kr (J.-J. Kim), jihong@snu.ac.kr (J.-I. Hong).
https://doi.org/10.1016/j.orgel.2019.105600
Received 10 September 2019; Received in revised form 23 November 2019; Accepted 17 December 2019
Available online 18 December 2019
1566-1199/© 2019 Published by Elsevier B.V.
Please cite this article as: Youngnam Lee, Organic Electronics, https://doi.org/10.1016/j.orgel.2019.105600

Y. Lee et al.
Organic Electronics xxx (xxxx) xxx
Table 1
Calculated data of NyDPAc.
HOMO
[eV]
LUMO
Egap
S1 [eV]
T1 [eV]
ΔEST
[eV]
[eV]
[eV]
NyDPAc
4.90 eV
2.22 eV
2.68 eV
2.286
eV
2.282
eV
0.004
eV
Fig. 1. (a) Design strategy (b) optimized geometry: HOMO (blue), LUMO
(Red). (For interpretation of the references to color in this figure legend, the
reader is referred to the Web version of this article.)
2. Experimental
Scheme 1. Synthetic routes for NyDPAc. i) m-NO2PhSO3Na, glycerol, H2SO4,
H2O, 150 �C; ii) mCPBA, CH2Cl2/MeOH, rt; iii) POCl3, 110 �C, 20 min; iv) CuI,
trans-1,2-cyclohexanediamine, sodium tert-butoxide, 1,4-dioxane, 100 �C; v) n-
BuLi, trimethyl borate, THF, À 78 �C → rt; vi) Pd(PPh3)4, K2CO3, 1,4-dioxane/
H2O, 100 �C.
2.1. Quantum chemical calculations
All quantum chemical calculations were performed using the
Gaussian ’09 program package. Gas-phase geometry optimizations for
the lowest excited singlet and triplet states were carried out using den-
sity functional theory (DFT) and time-dependent density functional
theory (TD-DFT) calculations at the B3LYP/6-31G(d) level.
2.4. Device fabrication and measurements
The patterned indium-tin-oxide (ITO, 150 nm) substrates were
washed with water and isopropyl alcohol, followed by 10 min UV-ozone
treatment. Organic layers, LiF, and Al were thermally evaporated at a
deposition rate of 1–2 Å sÀ 1 for organic layers, 0.1 Å sÀ 1 for LiF, and 3–5
Å sÀ 1 for the Al electrode. OLED properties were measured using a
Keithley source meter 2400 and a PR-650 spectrascan colorimeter.
2.2. Photophysical property analysis
UV–visible spectra were recorded on a Jasco V-730 spectrophotom-
eter. Fluorescence and phosphorescence spectra were recorded on a
Jasco FP-8300 spectrophotometer. Absolute quantum efficiency was
obtained with a PTI QuantaMaster 40 spectrofluorometer using a 3.2 in.
integrating sphere at room temperature. Transient photoluminescence
(PL) was measured with a streak camera (Hamamatsu Photonics, Japan)
using a nitrogen laser (337 nm; Usho Optical Systems, Japan) as the
excitation source. For angle-dependent PL (ADPL) measurements, p-
polarized light emitted from PL samples was measured by attaching the
film substrate to a half-cylinder lens with index-matching oil and
changing the angle between the sample and the detector from À 90� to
90� using a motorized rotational stage.
2.5. Synthesis and characterization
Commercially available reagents and solvents were used without
further purification unless otherwise noted. 1H and 13C NMR spectra
were recorded using an Agilent 400-MR DD2 400 MHz or Varian/Oxford
As-500 500 MHz in CDCl3. 1H NMR chemical shifts in CDCl3 were
referenced to CHCl3 (7.27 ppm). 13C NMR chemical shifts in CDCl3 were
reported relative to CHCl3 (77.23 ppm). Mass spectra were recorded on a
matrix-assisted laser desorption ionization time-of-flight (MALDI-TOF)
Microflex instrument from Bruker. High-resolution mass spectrometric
(HRMS) data (JEOL, JMS-700) with fast atom bombardment (FAB)
positive mode were received directly from the National Center for Inter-
University Research Facilities (NCIRF). Elemental analyses were carried
out using Thermo Scientific FlashEA 1112.
2.3. Electrochemical and thermal analysis
Cyclic voltammetry (CV) experiments were conducted in DMF so-
lution (1.00 mM) with 0.1 M tetra-n-butylammonium perchlorate
(TBAP) as the supporting electrolyte. A glassy carbon electrode was
employed as the working electrode and referenced to an Ag reference
electrode. All potential values were calibrated against the ferrocene/
ferrocenium (Fc/Fcþ) redox couple. The onset potential was determined
from the intersection of two tangents drawn at the rising and back-
ground current of the cyclic voltammogram. Differential scanning
calorimetry (DSC) and thermogravimetric analysis (TGA) were per-
formed with a TA instrument DSC Q10 and Q50 thermogravimetric
3. Results and discussion
3.1. Theoretical calculations
DFT and TD-DFT calculations of NyDPAc were performed to show an
optimized molecular structure and the highest occupied molecular
orbital (HOMO)/lowest unoccupied molecular orbital (LUMO) of
ground states and energies of excited states at the B3LYP/6-31G(d) level.
The calculated data are summarized in Table 1. DFT calculations of
NyDPAc revealed a linear shape as the optimized geometry (Fig. 1b),
where dimethylacridine and a phenylene bridge were distorted with a
analyzer in a nitrogen atmosphere at a heating rate of 10 �C minÀ 1
.
2

Y. Lee et al.
Organic Electronics xxx (xxxx) xxx
Table 2
Physical and photophysical data of NyDPAc.
λPLa/b [nm]
ESa/b [eV]
ETa/b [eV]
ΔESTa/b [eV]
PLQYb [%]
57
τFb [ns]
τTADF [μs]
HOMOc [eV]
5.30
HOMOc [eV]
2.87
θlld [%]
Tge/Tdf [oC]
144/414
b
NyDPAc
486/510
2.81/2.80
2.51/2.51
0.30/0.29
12
451
92
a
Measured using toluene solution (10À 5 M).
b
c
d
e
f
Measured using 10 wt% NyDPAc doped in DPEPO film.
Estimated from the onset potentials (oxEonset and redEonset [eV] against Fc/Fcþ redox couple) in CV experiments.
The horizontal emitting dipole ratio.
The glass transition temperature.
The temperature at 5% weight loss.
Fig. 2. (a) Absorption and PL spectra of NyDPAc in solution (concentration: 10À 5 M). (b) Fluorescence and phosphorescence spectra of NyDPAc in toluene and 10 wt
% NyDPAc doped in DPEPO film. (c) Transient PL decay curve using 10-wt% NyDPAc doped in DPEPO film. (d) Angle-dependent PL intensity.
dihedral angle of 89� because of steric hindrance. The HOMO was
localized on the dimethylacridine moiety, whereas the LUMO was
localized on the linear core of 1,5-naphthyridine and two phenylene
linkers. The energies of singlet (2.286 eV) and triplet (2.282 eV) excited
states were estimated using TD-DFT calculations, resulting in a small
ΔEST of 0.004 eV.
POCl3 to furnish 2,6-dichloro-1,5-naphthyridine (2). 2,6-Bis(4-(9,9-
dimethylacridin-yl)phenyl)-1,5-naphthyridine (NyDPAc) was obtained
through Suzuki-Miyaura coupling between 2 and (4-(9,9-dimethylacri-
din-10(9H)-yl)phenyl) boronic acid (3). NyDPAc was further purified by
train sublimation under reduced pressure (<10À 4 Torr). Details of their
syntheses and purification are provided in the Supporting Information.
3.2. Synthesis
3.3. Photophysical properties
The synthetic procedure is depicted in Scheme 1. First, 3-aminopyr-
idine was heated with sulfuric acid, glycerol, and 3-nitrobenzene sul-
fonate to produce 1,5-naphthyridine through a Skraup reaction. The
resulting 1,5-naphthyridine was oxidized with mCPBA to yield 1,5-
naphthyridine-1,5-dioxide (1), which was then chlorinated using
We investigated the photophysical properties using ultra-
violet–visible (UV–vis), photoluminescence (PL), and transient PL
spectroscopy. The photophysical properties of NyDPAc are summarized
in Table 2. In the UV–vis spectra, charge transfer (CT) absorption
occurred at 350 nm, which represents the charge transfer from
3

Y. Lee et al.
Organic Electronics xxx (xxxx) xxx
Fig. 3. (a) Energy level diagram for the OLED device, (b) current density-voltage-luminance (J-V-L) curves, (c) EL spectra at 5 V, (d) external quantum efficiency-
current density (ηEQE-J) curve.
dimethylacridine to naphthyridine. As
a result, solvatochromism
Table 3
appeared as the polarity of the solvent increased from toluene to tetra-
hydrofuran (THF) and methylene chloride (MC). The CT emissions were
observed at 486 nm in toluene, 548 nm in THF, and 558 nm in MC
(Fig. 2a). Thin-film PL measurements were conducted using bis[2-
(diphenylphosphino)phenyl] ether oxide (DPEPO) as a host with a high
T1 energy (T1 ¼ 3.0 eV) [26]. The 10 wt% doped film exhibited CT
emission at 510 nm and an absolute PLQY of 57%.
Device data of NyDPAc in a DPEPO host matrix.
a
e
Doping
Turn on
voltage
[V]
EQEmax
[%]
CEb
[cd
AÀ 1
PEc
CIE
λmax
concentration
[lm
Coordinates
[nm]
]
WÀ 1
]
d(x, y)
10%
20%
30%
3.6
3.6
3.6
20.9
18.7
12.6
47.9
46.1
29.8
41.8
40.2
26.0
0.28, 0.53
0.30, 0.55
0.32, 0.55
516
524
528
The time-gated PL spectra were acquired at a low temperature (77 K)
to investigate the characteristics of triplet excited states (Fig. 2b). Both
solution and film phosphorescence spectra were characterized by the
mixing of 3CT and 3LE states [27], compared to the spectrum of the
acceptor moiety (Fig. S1), whereas the fluorescence has a 1CT character.
ΔEST was estimated to be approximately 0.30 eV based on the onset of
spectra. To confirm the TADF characteristics, a transient PL decay pro-
file of NyDPAc in the doped films was obtained (Fig. 2c). Decay curves
showed prompt and delayed components with lifetimes of 12 ns and 451
a
External quantum efficiency.
Current efficiency.
b
c
d
e
Power efficiency.
CIE 1931 Coordinates.
Maximum wavelength at 5V.
3.4. Electrochemical and thermal properties
The HOMO and LUMO levels of NyDPAc measured by cyclic vol-
tammetry were 5.30 and 2.87 eV, respectively (Fig. S2). Therefore,
DPEPO (HOMO ¼ 6.1 eV, LUMO ¼ 2.0 eV) can serve as a suitable host
material for NyDPAc. Differential Scanning calorimetry (DSC) and
thermal gravimetric analysis (TGA) showed extremely high thermal
stability with a glass transition temperature (Tg) of 144 �C and a
decomposition temperature (Td) of 414 �C at 5% weight loss (Fig. S3).
μ
s, respectively. NyDPAc clearly showed TADF emission despite large
ΔEST. This was due to appropriate interactions between 1CT, 3LE, and
3CT for RISC according to the El-Sayed rule [28]. In fact, several studies
on successful TADF emitters have been conducted using large ΔEST
[29–32]. The kinetic constants of NyDPAc were calculated according to
the Adachi’s method (Table S1) [33–35].
4

Y. Lee et al.
Organic Electronics xxx (xxxx) xxx
3.5. Device properties
References
[1] M.A. Baldo, D.F. O’Brien, Y. You, A. Shoustikov, S. Sibley, M.E. Thompson, et al.,
Highly efficient phosphorescent emission from organic electroluminescent devices,
Nature 395 (6698) (1998) 151–154.
The OLED device structure was as follows (Fig. 3a): indium tin oxide
(ITO, 150 nm)/N,N0-di(1-naphthyl)-N,N0-diphenyl-(1,10-biphenyl)-4,40-
diamine (NPB, 40 nm)/1,3-bis(N-carbazolyl)benzene (mCP, 10 nm)/
DPEPO:NyDPAc (20 nm, x wt%)/DPEPO (10 nm)/2,20,2"-(1,3,5-benzi-
netriyl)-tris(1-phenyl-1-H-benzimidazole(TPBi, 40 nm)/LiF (1 nm)/Al
(100 nm). The device data are summarized in Table 3. The device
showed an emission peak of 516 nm, an EQEmax of 20.9%, a current
[2] C. Adachi, M.A. Baldo, M.E. Thompson, S.R. Forrest, Nearly 100% internal
phosphorescence efficiency in an organic light-emitting device, J. Appl. Phys. 90
(10) (2001) 5048–5051.
[3] L.J. Rothberg, A.J. Lovinger, Status of and prospects for organic
electroluminescence, J. Mater. Res. 11 (12) (1996) 3174–3187.
[4] R.H. Friend, R.W. Gymer, A.B. Holmes, J.H. Burroughes, R.N. Marks, C. Taliani, et
al., Electroluminescence in conjugated polymers, Nature 397 (6715) (1999)
121–128.
efficiency (CE) of 47.9 cd AÀ 1, a power efficiency (PE) of 41.8 lm WÀ 1
,
and CIE coordinates of (0.28, 0.53) at 10% doped NyDPAc. As the
concentration of dopant increased, we observed decreased EQEs and
emission spectral shifts, which are presumably due to the interactions
between emitter molecules [36]. The long TADF lifetime of NyDPAc
[5] H. Uoyama, K. Goushi, K. Shizu, H. Nomura, C. Adachi, Highly efficient organic
light-emitting diodes from delayed fluorescence, Nature 492 (2012) 234.
[6] Y.-Z. Shi, K. Wang, X. Li, G.-L. Dai, W. Liu, K. Ke, et al., Intermolecular charge-
transfer transition emitter showing thermally activated delayed fluorescence for
efficient non-doped OLEDs, Angew. Chem. Int. Ed. 57 (30) (2018) 9480–9484.
[7] H. Mieno, R. Kabe, M.D. Allendorf, C. Adachi, Thermally activated delayed
fluorescence of a Zr-based metal–organic framework, Chem. Commun. 54 (6)
(2018) 631–634.
(451 μs, Table 2) resulted in large device efficiency roll-off (Fig. 3d) [37,
38]. Interestingly, the calculated EQE was 11.4% based on the PLQY of
57% and light out-coupling efficiency of 20%. However, the obtained
EQE of 20.9% was much higher than the calculated value.
[8] Y. Xiang, Z.-L. Zhu, D. Xie, S. Gong, K. Wu, G. Xie, et al., Revealing the new
potential of an indandione unit for constructing efficient yellow thermally
activated delayed fluorescence emitters with short emissive lifetimes, J. Mater.
Chem. C 6 (26) (2018) 7111–7118.
To obtain greater insight into the unexpected high EQE, the angle-
dependent PL of p-polarized light was measured using a 30-nm-thick
film of 10 wt% NyDPAc in DPEPO to investigate the emitting dipole
orientation (EDO) (Fig. 2d). The EDO ratio was obtained by fitting the
measured curves to the classical dipole optical simulation. NyDPAc
showed 92% of the horizontal EDO ratio (Θll), indicating that NyDPAc
had a fairly good horizontal orientation in the layer of DPEPO. Based on
the PLQY and Θll of NyDPAc, the theoretical maximum EQE was
calculated through optical simulation, assuming that the thickness of the
ITO was 150 nm and ΦRISC ¼ 1. Calculations showed that the EQE could
reach 20.6%, which is nearly identical to our experimental results. EDO
and simulation verified that NyDPAc was well arranged in the hori-
zontal orientation. Thus, the increased EQE clearly originated from the
high horizontal orientation.
[9] C. Li, C. Duan, C. Han, H. Xu, Secondary acceptor optimization for full-exciton
radiation: toward sky-blue thermally activated delayed fluorescence diodes with
external quantum efficiency of �30%, Adv. Mater. 30 (50) (2018) 1804228.
[10] S.-J. Woo, Y. Kim, Y.-H. Kim, S.-K. Kwon, J.-J. Kim, A spiro-
silafluorene–phenazasiline donor-based efficient blue thermally activated delayed
fluorescence emitter and its host-dependent device characteristics, J. Mater. Chem.
C 7 (14) (2019) 4191–4198.
[11] W. Brütting, J. Frischeisen, T.D. Schmidt, B.J. Scholz, C. Mayr, Device efficiency of
organic light-emitting diodes: progress by improved light outcoupling, Phys. Status
Solidi A 210 (1) (2013) 44–65.
[12] A. Endo, K. Sato, K. Yoshimura, T. Kai, A. Kawada, H. Miyazaki, et al., Efficient up-
conversion of triplet excitons into a singlet state and its application for organic
light emitting diodes, Appl. Phys. Lett. 98 (8) (2011), 083302.
[13] A. Senes, S.C.J. Meskers, H. Greiner, K. Suzuki, H. Kaji, C. Adachi, et al., Increasing
the horizontal orientation of transition dipole moments in solution processed small
molecular emitters, J. Mater. Chem. C 5 (26) (2017) 6555–6562.
[14] D. Yokoyama, Molecular orientation in small-molecule organic light-emitting
diodes, J. Mater. Chem. 21 (48) (2011) 19187–19202.
4. Conclusion
[15] Y.J. Cho, B.D. Chin, S.K. Jeon, J.Y. Lee, 20% external quantum efficiency in
solution-processed blue thermally activated delayed fluorescent devices, Adv.
Funct. Mater. 25 (43) (2015) 6786–6792.
In conclusion, the TADF emitter NyDPAc containing 1,5-naphthyri-
dine as an electron acceptor showed TADF emission and high horizontal
dipole orientation. The distinct 1CT and 3LE emission of NyDPAc
resulted in RISC for TADF, thus improving the EQE. The high horizontal
EDO ratio of NyDPAc further increased the EQE by enhancing the light
out-coupling efficiency. Device data (10 wt% doped) showed a high EQE
of 20.9%, a CE of 47.9 Cd AÀ 1, and a PE of 41.8 lm WÀ 1. Our study
suggests that using 1,5-naphthyridine as a core moiety is an effective
means of developing efficient TADF emitters. Further modified design
based on the 1,5-naphthyridine structure is currently underway in our
laboratory.
[16] Y. Wada, K. Shizu, S. Kubo, K. Suzuki, H. Tanaka, C. Adachi, et al., Highly efficient
electroluminescence from a solution-processable thermally activated delayed
fluorescence emitter, Appl. Phys. Lett. 107 (18) (2015) 183303.
[17] M. Kim, S.K. Jeon, S.-H. Hwang, S.-S. Lee, E. Yu, J.Y. Lee, Correlation of molecular
structure with photophysical properties and device performances of thermally
activated delayed fluorescent emitters, J. Phys. Chem. C 120 (5) (2016)
2485–2493.
[18] S.Y. Byeon, J. Kim, D.R. Lee, S.H. Han, S.R. Forrest, J.Y. Lee, Nearly 100%
horizontal dipole orientation and upconversion efficiency in blue thermally
activated delayed fluorescent emitters, Advanced Optical Materials 6 (15) (2018)
1701340.
[19] W. Li, B. Li, X. Cai, L. Gan, Z. Xu, W. Li, et al., Tri-spiral donor for high efficiency
and versatile blue thermally activated delayed fluorescence materials, Angew.
Chem. Int. Ed. 58 (33) (2019) 11301–11305.
[20] X. Zeng, K.-C. Pan, W.-K. Lee, S. Gong, F. Ni, X. Xiao, et al., High-efficiency pure
blue thermally activated delayed fluorescence emitters with a preferentially
horizontal emitting dipole orientation via a spiro-linked double D–A molecular
architecture, J. Mater. Chem. C 7 (35) (2019) 10851–10859.
Declaration of competing interest
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
[21] T. Komino, H. Tanaka, C. Adachi, Selectively controlled orientational order in
linear-shaped thermally activated delayed fluorescent dopants, Chem. Mater. 26
(12) (2014) 3665–3671.
[22] D.H. Kim, K. Inada, L. Zhao, T. Komino, N. Matsumoto, J.C. Ribierre, et al., Organic
light emitting diodes with horizontally oriented thermally activated delayed
fluorescence emitters, J. Mater. Chem. C 5 (5) (2017) 1216–1223.
[23] G. Roma, M. Di Braccio, G. Grossi, F. Mattioli, M. Ghia, 1,8-Naphthyridines IV. 9-
substituted N,N-dialkyl-5-(alkylamino or cycloalkylamino) [1,2,4]triazolo[4,3-a]
[1, 8]naphthyridine-6-carboxamides, new compounds with anti-aggressive and
potent anti-inflammatory activities, Eur. J. Med. Chem. 35 (11) (2000) 1021–1035.
[24] D.J. Hazuda, N.J. Anthony, R.P. Gomez, S.M. Jolly, J.S. Wai, L. Zhuang, et al.,
A naphthyridine carboxamide provides evidence for discordant resistance between
mechanistically identical inhibitors of HIV-1 integrase, Proc. Natl. Acad. Sci. U. S.
A. 101 (31) (2004) 11233–11238.
Acknowledgement
This work was supported by the NRF grant (No.
2018R1A2B2001293) funded by the MSIP.
Appendix A. Supplementary data
[25] K.M. Peese, C.W. Allard, T. Connolly, B.L. Johnson, C. Li, M. Patel, et al., 5,6,7,8-
Tetrahydro-1,6-naphthyridine derivatives as potent HIV-1-Integrase-Allosteric-Site
inhibitors, J. Med. Chem. 62 (3) (2019) 1348–1361.
Supplementary data to this article can be found online at https://doi.
org/10.1016/j.orgel.2019.105600.
[26] C. Han, Y. Zhao, H. Xu, J. Chen, Z. Deng, D. Ma, et al., A simple phosphine–oxide
host with a multi-insulating structure: high triplet energy level for efficient blue
electrophosphorescence, Chem. Eur J. 17 (21) (2011) 5800–5803.
5

Y. Lee et al.
Organic Electronics xxx (xxxx) xxx
[27] T. Hosokai, H. Matsuzaki, H. Nakanotani, K. Tokumaru, T. Tsutsui, A. Furube, et
al., Evidence and mechanism of efficient thermally activated delayed fluorescence
promoted by delocalized excited states, Science Advances 3 (5) (2017), e1603282.
[33] Q. Zhang, H. Kuwabara, W.J. Potscavage, S. Huang, Y. Hatae, T. Shibata, et al.,
Anthraquinone-based intramolecular charge-transfer compounds: computational
molecular design, thermally activated delayed fluorescence, and highly efficient
red electroluminescence, J. Am. Chem. Soc. 136 (52) (2014) 18070–18081.
[34] Q. Zhang, B. Li, S. Huang, H. Nomura, H. Tanaka, C. Adachi, Efficient blue organic
light-emitting diodes employing thermally activated delayed fluorescence, Nat.
Photonics 8 (2014) 326.
�
[28] P.K. Samanta, D. Kim, V. Coropceanu, J.-L. Bredas, Up-Conversion intersystem
crossing rates in organic emitters for thermally activated delayed fluorescence:
impact of the nature of singlet vs triplet excited states, J. Am. Chem. Soc. 139 (11)
(2017) 4042–4051.
[29] T. Takahashi, K. Shizu, T. Yasuda, K. Togashi, C. Adachi, Donor–acceptor-
structured 1,4-diazatriphenylene derivatives exhibiting thermally activated
delayed fluorescence: design and synthesis, photophysical properties and OLED
characteristics, Sci. Technol. Adv. Mater. 15 (3) (2014), 034202.
[30] X. Cai, X. Li, G. Xie, Z. He, K. Gao, K. Liu, et al., “Rate-limited effect” of reverse
intersystem crossing process: the key for tuning thermally activated delayed
fluorescence lifetime and efficiency roll-off of organic light emitting diodes, Chem.
Sci. 7 (7) (2016) 4264–4275.
[35] S. Oda, B. Kawakami, R. Kawasumi, R. Okita, T. Hatakeyama, Multiple resonance
effect-induced sky-blue thermally activated delayed fluorescence with a narrow
emission band, Org. Lett. 21 (23) (2019) 9311–9314.
[36] H.S. Kim, S.-R. Park, M.C. Suh, Concentration quenching behavior of thermally
activated delayed fluorescence in a solid film, J. Phys. Chem. C 121 (26) (2017)
13986–13997.
[37] K. Masui, H. Nakanotani, C. Adachi, Analysis of exciton annihilation in high-
efficiency sky-blue organic light-emitting diodes with thermally activated delayed
fluorescence, Org. Electron. 14 (11) (2013) 2721–2726.
[31] P. Data, P. Pander, M. Okazaki, Y. Takeda, S. Minakata, A.P. Monkman, Dibenzo[a,
j]phenazine-Cored donor–acceptor–donor compounds as green-to-red/NIR
thermally activated delayed fluorescence organic light emitters, Angew. Chem. Int.
Ed. 55 (19) (2016) 5739–5744.
[38] Z. Yang, Z. Mao, Z. Xie, Y. Zhang, S. Liu, J. Zhao, et al., Recent advances in organic
thermally activated delayed fluorescence materials, Chem. Soc. Rev. 46 (3) (2017)
915–1016.
[32] S.G. Yoo, W. Song, J.Y. Lee, Molecular engineering of donor moiety of
donor–acceptor structure for management of photophysical properties and device
performances, Dyes Pigments 128 (2016) 201–208.
6
