Activity analysis and preliminary inducer screening of the chicken DAZL gene promoter

Article abstract of DOI:10.3390/ijms16036595

This study was aimed at identifying the active control area of chicken DAZL gene core promoter, to screen optimum inducers of the DAZL gene, thus to enhance the differentiation of embryonic stem cells into spermatogonial stem cells. Fragments of chicken DAZL gene promoter were cloned into fluorescent reporter plasmids and transfected into DF-1 cells. Then Dual-Luciferase Reporter Assay System was used to identify the activity of the DAZL gene under different inducers. Our studies showed that the DAZL core promoter region for the Suqin yellow chicken was 383 to 39 bp. The dual-luciferase reporter showed that all-trans retinoic acid (ATRA), a retinoic acid receptor alpha agonist (tamibarotene/Am80), or estradiol (E₂) could significantly enhance DAZL transcription. The in vitro inductive culture of chicken ESCs demonstrated that, with ATRA treatment, DAZL transcription peaked at 6 days and then decreased slowly; whereas, DAZL transcription was continuous and peaked at 10 days with Am80 treatment. E E₂ treatment significantly increased DAZL expression after 8 days. All three treatments were associated with the appearance of male germ cell (MGC)-like cells on day 10. These results provide the optimum inducer screening of the DAZL gene and lay the foundation for further screening of compounds that can induce the differentiation of ESCs into MGCs in vitro.

Full text of DOI:10.3390/ijms16036595

Int. J. Mol. Sci. 2015, 16, 6595-6605; doi:10.3390/ijms16036595
OPEN ACCESS
International Journal of
Molecular Sciences
ISSN 1422-0067
www.mdpi.com/journal/ijms
Article
Activity Analysis and Preliminary Inducer Screening of the
Chicken DAZL Gene Promoter
Lei Zhang †, Rui Zhu †, Qisheng Zuo, Dong Li, Chao Lian, Beibei Tang, Tianrong Xiao,
Yani Zhang * and Bichun Li *
College of Animal Science and Technology, Yangzhou University, Yangzhou 225009, Jiangsu, China;
E-Mails: leizhang17@sina.com (L.Z.); rzhu1988@163.com (R.Z.); zqs081901427@gmail.com (Q.Z.);
lidongyzu@hotmail.com (D.L.); lcyzdx@hotmail.com (C.L.); tangbeibei125@163.com (B.T.);
xtryzdx2013@hotmail.com (T.X.)
†
These authors contributed equally to this work.
* Authors to whom correspondence should be addressed;
E-Mails: yubcli@yzu.edu.cn (B.L.); ynzhang@yzu.edu.cn (Y.Z.);
Tel.: +86-514-8797-7207 (B.L.); +86-514-8799-7194 (Y.Z.).
Academic Editor: Gregor Drummen
Received: 24 November 2014 / Accepted: 5 March 2015 / Published: 23 March 2015
Abstract: This study was aimed at identifying the active control area of chicken DAZL gene
core promoter, to screen optimum inducers of the DAZL gene, thus to enhance the
differentiation of embryonic stem cells into spermatogonial stem cells. Fragments of chicken
DAZL gene promoter were cloned into fluorescent reporter plasmids and transfected into
DF-1 cells. Then Dual-Luciferase® Reporter Assay System was used to identify the activity
of the DAZL gene under different inducers. Our studies showed that the DAZL core promoter
region for the Suqin yellow chicken was −383 to −39 bp. The dual-luciferase® reporter
showed that all-trans retinoic acid (ATRA), a retinoic acid receptor alpha agonist
(tamibarotene/Am80), or estradiol (E2) could significantly enhance DAZL transcription. The
in vitro inductive culture of chicken ESCs demonstrated that, with ATRA treatment, DAZL
transcription peaked at 6 days and then decreased slowly; whereas, DAZL transcription was
continuous and peaked at 10 days with Am80 treatment. E2 treatment significantly increased
DAZL expression after 8 days. All three treatments were associated with the appearance
of male germ cell (MGC)-like cells on day 10. These results provide the optimum inducer

Int. J. Mol. Sci. 2015, 16
6596
screening of the DAZL gene and lay the foundation for further screening of compounds that
can induce the differentiation of ESCs into MGCs in vitro.
Keywords: DAZL gene; core promoter; gene inducer screening; male germ cells
1. Introduction
The autosomal DAZL gene is an important member of the Deleted in Azoospermia (DAZ) family
(including DAZ, DAZL and BOULE), which encode RNA-binding proteins of the RNA recognition motif
(RRM) type and are involved in translation of polysomal mRNA [1]. DAZL, which contains the
conserved RRM repeat motif structural domain DAZ, was first discovered in the Drosophila testis [2].
Mouse Dazl expression starts during the early stage of germ cell development, persists into meiosis, and
is expressed both in the adult testis and ovaries [3,4]. The RNA-binding protein encoded by Dazl is
required for the completion of spermatocyte meiosis in the mouse [5]. Houston et al. [6] found that
Xenopus DAZL was critically involved in primordial germ cell (PGC) development. Vogel et al. [7]
determined that Xenopus DAZL could only substitute for the murine homologue with respect to the early
functions in the establishment of the germ cells. Reynolds et al. [8] found that in Dazl knockout mice,
meiotic prophase was arrested at the zygotene stage. Together these results indicate that DAZL has a
conserved role in germ cell development, regulation of germ cell differentiation, and is one of the
important regulatory factors in the process of gamete formation.
Currently, many research groups are focused on germ cell gene regulation and inductive
differentiation of PGCs from embryonic stem cells (ESCs) in vitro. Yu [9] induced mouse ESCs to
differentiate into sperm-like cells and oocyte-like cells by overexpression of Dazl. Haston [10] had
shown that Dazl plays an important role in the process of differentiation from to germ cell in vitro.
Using overexpression of Dazl Kee et al. [11] found that PGC formation could be promoted. Thus far,
there have been a number of reports on mouse, human, and Drosophila DAZL and identification of
a large number of inducers of its expression; however, the reports on the chicken ortholog are not
comprehensive enough. Our team has been committed for decades to studying the inductive
differentiation of chicken male germ cells (MGCs) in vitro. Unfortunately, the induction efficiency is
low. To improve the induction efficiency, selecting the optimum inducers for chicken DAZL gene
expression is crucial.
Chicken, as a classic model anima of developmental biology, displays a unique process of embryonic
development. As an experimental model system, chickens provide sufficient material for the study of
embryonic germ cells and have more permissive rules than mammalian models. The 5' flanking region
of the DAZL gene promoter was cloned upstream of a fluorescent reporter and transfected into DF-1
cells. The Dual-Luciferase® Reporter Assay System allowed quantification of the activity of the chicken
DAZL promoter fragments and identification of the gene’s core promoter. The level of DAZL gene
promoter activity was detected under different inducer treatments. Candidate optimal inducers were
screened for their functional capacity in vitro to induce chicken ESCs to differentiate into MGCs, to
provide the optimum inducer screening of the DAZL gene, and to lay the foundation for in vitro screening
for inducers of ESC to MGC differentiation in the chicken.

Int. J. Mol. Sci. 2015, 16
6597
2. Results and Discussion
2.1. The Qualitative Analysis of DAZL Gene Promoter Activity
To test whether the fragment of −932 to −39 bp has promoter activity, pDAZL-EGFP, pEGFP-N1,
and pLinker-EGFP plasmids were transfected into DF-1 cells (Figure 1A). The cells transfected
with pDAZL-EGFP vector could express green fluorescent protein (GFP), but its fluorescence intensity
was weaker than positive control plasmid pEGFP-N1, and pLinker-EGFP transfected cells had no
GFP expression.
Four recombinant plasmids: pGL-P1 (−932 to −39 bp), pGL-P2 (−647 to −39 bp), pGL-P3 (−383 to
−39 bp), and pGL-P4 (−186 to −39 bp) were used to transfect DF-1 cells with pRL-SV40. pGL-basic and
pRL-SV40 were used to transfect DF-1 cells as the negative control group. After 48 h of transfection,
the activity of the four promoter segments was detected and different segments of the Suqin yellow
chicken DAZL promoter had varying expression (Figure 1B). There was almost no promoter activity in
the −186 to −36 bp fragment. The promoter activity in the −383 to −39 bp was the highest.
Figure 1. (A) The green fluorescent protein (GFP) detection of promoter activity of the
chicken Deleted in Azoospermia (DAZL) long promoter fragment in DF-1 cells transfected
with positive control pDAZL-EGFP, pEGFP-N1, and negative control pLinker-EGFP
(40× magnification); (B) The activity of different promoter regions of the chicken DAZL
gene in DF-1 cells; (C) The effect of different inducers on the activity of the chicken DAZL
core gene promoter in mouse DF-1 cells. * represents p < 0.05, ** represents p < 0.01.
2.2. The Influence of Different Inducers on Chicken DAZL Gene Promoter Activity
According to the above result, pGL3/334 GC-1 cells had the highest DAZL transcriptional activity.
pGL3/334 DF-1 cells were treated with RA (10−5 mol/L), ATRA (10−5 mol/L), Am80 (10−6 mol/L),
BMP4 (40 ng/mL), FSH (0.1 IU/mL), E2 (1 μg/mL), testosterone (15 ng/mL), or testicular extract.

Int. J. Mol. Sci. 2015, 16
6598
After 48 h of induction, treatment with BMP4 or testicular extracts had no obvious effect on the activity
of the DAZL gene promoter. RA, FSH, and testosterone increased the activity but not significantly.
ATRA, Am80, and E2 significantly increased the activity of the DAZL gene promoter (Figure 1C).
2.3. In Vitro Induction Validation
Based on their induction of DAZL transcription ATRA, Am80, and E2 were screened as the optimal
inducers of the DAZL gene. Morphological changes were induced in chicken ESCs in vitro by ATRA,
AM80, and E2. qRT-PCR and immunohistochemistry were used to detect the kinetics of DAZL gene
expression during differentiation. The results showed that cell morphology gradually changed under a
different culture system (Figure 2). Under basic medium, control cells grew slowly. A few cell colonies
appeared at 2 days, and the cells differentiated at 6 days. With ATRA or Am80 treatment, embryonic
bodies gradually formed and increased at 2 days, began to collapse at 6 days, and MGC-like cells were
observed at 10 days. With E2 treatment, embryonic bodies gradually formed and enlarged at 2 days, began
to collapse at 6 days, MGC-like cells were observed at 8 days, and the number increased at 10 days.
Figure 2. Differentiation of chicken embryonic stem cells (ESCs) induced by different
DAZL inducers. (A) chicken ESCs with DMEM; (B) chicken ESCs with 10−5 mol/L l-trans
retinoic acid (ATRA) induction; (C) chicken ESCs with 10−6 mol/L Am800 induction;
(D) chicken ESCs with 1 μg/mL E2 induction. Arrows represent spermatogonial stem
cell-like (SSC-like) cells. (400× magnification).
qRT-PCR results showed that, compared with the control group, DAZL gene expression achieved
the highest level at 6 days of ATRA treatment, and then showed a trend of slow decline. DAZL gene
showed continuous expression after Am80 treatment, achieving the highest level at 10 days. DAZL gene
expression was significantly increased at 8 days of E2 treatment (Figure 3). Immunohistochemistry also

Int. J. Mol. Sci. 2015, 16
6599
showed that with ATRA, Am80, or E2 treatment, the cells expressed DAZL protein (green), which was
absent in the control cells (Figure 4).
Figure 3. DAZL mRNA expression under ATRA, Am80, and E2 induction compared with
control chicken ESCs. The results are presented as a mean ± SEM of three duplicate runs.
Error bars in charts represent the corresponding standard deviations.
Figure 4. Immunohistochemical detection of DAZL protein expression in chicken ESCs
treated with various inducers of germ cell differentiation. (A) chicken ESCs with DMEM;
(B) chicken ESCs with 10−5 mol/L ATRA induction; (C) chicken ESCs with 10−6 mol/L
Am80 induction; (D) chicken ESCs with 1 μg/mL E2 induction. (400× magnification).

Int. J. Mol. Sci. 2015, 16
6600
3. Experimental Section
3.1. Materials and Reagents
Procedures involving animals and their care conformed to the U.S. National Institute of Health
guidelines (NIH Pub. No. 85-23, revised 1996) and were approved by the laboratory-animal management
and experimental-animal ethics committee of Yanzhou University.
Fertilized eggs of Suqin yellow chickens (Gallus gallus domesticus) were purchased from the Chinese
Academy of Agricultural Sciences Experimental Poultry Farm (Yangzhou, China). ESCs were collected
from stage X embryos as described previously [12].
The pEGFP-N1 vector is maintained by our laboratory. E. coli DH5α competent cells, gel extraction
kits, and miniprep kits were purchased from Tiangen Biotech (Beijing, China). DL5000 DNA Marker
Prime, STAR Max DNA Polymerase, T4 DNA ligase, and restriction endonucleases were purchased
from Takara (Shiga, Japan). Expression vectors pGL3.0-Basic, pRL-SV40, and the dual-luciferase assay
kit, Dual-Luciferase Reporter Assay System, were purchased from Promega Corporation (Madison, WI,
USA). LipofectamineTM2000 was purchased from Invitrogen Life Technologies (Carlsbad, CA, USA).
Retinoic acid (RA), all-trans retinoic acid (ATRA), tamibarotene (Am80), estrogen (E2), and testosterone
were purchased from SIGMA-Aldrich (St. Louis, MO, USA). Mouse bone morphogenetic protein 4
(BMP4) and follicle stimulating hormone (FSH) were purchased from ProSpec-Tany TechnoGene Ltd.
(Rehovot, Israel). The mouse spermatogonial cell line (GC-1) and the chicken embryo fibroblast cell
line (DF-1) were purchased from ATCC (Manassas, VA, USA). The remaining reagents were imported
or domestic analytical grade. Primer synthesis and sequencing were conducted by Invitrogen.
3.2. Extraction of Genomic DNA
Genomic DNA was extracted from chicken peripheral blood samples using a Puregene DNA isolation
kit (Gentra, Minneapolis, MN, USA) according to the manufacturer’s instructions.
3.3. Genomic Clone
Four fragments of the chicken DAZL gene promoter were amplified by polymerase chain reaction
(PCR), forward primers (positions relative to the transcription start site, corresponding to the genomic
positions chr2:34953772-34954681 for the longest amplicon) were: pEGFP-P0 (−932 to −39 bp):
5'-CGCATTAATTATGCACTCCAGTTGATCAGTTTAA-3', pGL-P1 (−932 to −39 bp): 5'-GGGGT
ACCTATGCACTCCAGTTGATCAGTTTAA-3', pGL-P2 (−647 to −39 bp): 5'-GGGTACCCCAGCCT
GCTCCAGAGTATCCA-3', pGL-P3 (−383 to −39 bp): 5'-GGGGTACCCACACATCGCCCTTCGTC
TT-3', pGL-P4 (−186 to −39 bp): 5'-GGGGTACCAAGAACTGCCTCTTTCGCAC-3', and common
reverse primer: 5'-CCCTCGAGCAAACGAGGCCTTCAAGACAA-3'.
The PCR consisted of 35 cycles of gene amplification as follows: 98 °C for 10 s followed by 35 cycles
composed of a denaturation step at 95 °C for 30 s, 56–62 °C for 30 s, and an elongation step at 72 °C
for 40 s. The PCR products were resolved by electrophoresis on 1% agarose gels, and the appropriate
band was excised and purified for the subsequent steps of cloning or sequence determination. Sequence

Int. J. Mol. Sci. 2015, 16
6601
analysis was performed with an automatic sequencer (ABI 377, Applied Biosystems/PE/Life
Technologies, Grand Island, NY, USA).
3.4. Vector Construction
The DAZL gene 5' flanking area −932 to −39 bp was inserted into the pEGFP-N1 vector between AseI
and XhoI restriction enzyme cutting sites and named pDAZL-EGFP. A negative control carrier was also
built as pLinker-EGFP. Four fragments of the DAZL gene promoter region cloned previously were
inserted into the dual-luciferase reporter gene carrier pGL3-Basic. All vectors were verified by AseI and
XhoI restriction enzyme digestion and sequence analysis.
3.5. Qualitative Analysis of DAZL Gene Promoter
DF-1/GC-1 cells were inoculated into 12 wells, approximately 5 × 105 cells per well. According
the manufacturer’s instructions for LipofectamineTM2000, pEGFP-N1/893 was used for transfection
of DF-1/GC-1 cells, and a positive (pEGFP-N1 transfected cells) and negative control group
(pEGFP-N1-CMV transfected cells) were created. The results for each group represent three replications.
After 48 h of transfection, fluorescence was observed under a Nikon Eclipse microscopy (Nikon,
Tokyo, Japan).
3.6. Cell Transfection
DF-1/GC-1 cells were inoculated into 24 wells, approximately 2.5 × 105 cells per well. According to
the manufacturer’s instructions for LipofectamineTM2000, all recombinant plasmids and a reference
plasmid pRL-SV40 (35:1) were transfected into DF-1/GC-1 cells. DF-1/GC-1 cells transfected with
pGL3-basic and pRL-SV40 were selected as a negative group. The results from each group represent
three replications. After 48 h, the Dual-Luciferase® Reporter Assay was performed.
After 6 h of transfection, cells were treated with RA (10−5 mol/L), ATRA (10−5 mol/L), Am80
(10−6 mol/L), BMP4 (40 ng/mL), FSH (0.1 IU/mL), E2 (1 μg/mL), testosterone (15 ng/mL), or testicular
extract. The negative group was treated with the same volume of phosphate-buffered saline. After
treatment for 48 h, cells were collected. The results of each group represent three replications.
3.7. Dual-Luciferase Activity Detection
Cells were collected in 70 μL PBS and the suspension was transferred to a 96-well plate.
A Dual-Luciferase® Reporter Assay was performed to detect the activity of the DAZL gene promoter
constructs. The relative luciferase activity representing the promoter activity is reported as the ratio of
firefly luciferase value/renilla luciferase.
3.8. In Vitro Induction Experiment
Chicken ESCs were inoculated into 24 wells, approximately 2 × 105 cells per well. ATRA (10−5 mol/L),
Am80 (10−6 mol/L), and E2 (1 μg/mL) were used to induce chicken ESC differentiation in vitro. The
cells were collected every two days after inducer treatment. The results of each group consisted of
three replications.

Int. J. Mol. Sci. 2015, 16
6602
3.9. Quantitative Real-Time Reverse Transcriptase PCR (qRT-PCR)
Total RNA was extracted using the RNeasy kit (Qiagen, Suzhou, China). Reverse transcription into
cDNA was performed by Reverse Transcription System (Qiagen) to serve as a template for qRT-PCR.
qRT-PCR of the cDNA was performed according to the instructions provided in the fluorescence
quantitative PCR kit (Qiagen), using SYBR as the fluorescent reagent and 7500 System fluorescence
quantitative instrument (Applied Biosystems, Foster City, CA, USA). Each group had three replications.
The data were analyzed in Microsoft Excel using the 2−ΔΔ t relative quantitative method.
C
4. Discussion
DAZL is one of the DAZ family members encoding an RNA-binding protein, which is also an
indispensable control factor during the animal gametogenesis process. To explore the role of the DAZL
gene in the specific regulatory mechanism of male reproductive cells, different lengths of the chicken
DAZL gene promoter attached to a fluorescent reporter were constructed, and were transfected into
DF-1. A Dual-Luciferase® Reporter Assay was performed, showing that the pGL-P3 promoter has the
highest activity of the DAZL gene promoter fragments in DF-1 cells. This indicates that there are
important regulatory elements in the −382 to −39 bp region of the chicken DAZL gene promoter.
Zhuo et al. [13] found that with ectopic expression of the Dazl gene, both motile-tailed sperm and
oocytes could be induced from mouse ESCs. Several other groups [14–17] also verified that Dazl was a
master gene controlling germ cell differentiation. However, DAZL gene research is not comprehensive
in chickens, and there is doubt whether specific inducers of the mouse Dazl gene could be used for
directional induction by the chicken ortholog in vitro. To evaluate the conservation of DAZL gene
function, combining previous research results [18–20], RA, ATRA, Am80, BMP4, FSH, E2,
testosterone, and testicular extracts evaluated for induction of pGL3/334 GC-1 cells.
BMP4 is a multifunctional cytokine, which can induce ESCs to differentiate into MGCs in vitro.
Shi et al. [20] found that the expression of Dazl, Stra8, Integrin α6, and c-kit was enhanced with every
2 days of BMP4 treatment in chicken. In our study, BMP4 treatment did not enhance the activity of the
core chicken DAZL gene promoter. Considering the short treatment time of BMP4 in our study (48 h),
the lack of an effect might be because BMP4 does not directly affect the chicken DAZL gene, but
indirectly causes the expression of DAZL mRNA through interaction with multiple genes. Neither
testosterone nor testicular extract had an effect on the chicken DAZL gene promoter, which is consistent
with the results by Sun and colleagues [12]. Pan et al. [19] found that E2 and FSH could induce mouse
ESCs to differentiate into MGCs with high-level expression of mouse Dazl mRNA on day 7. Our study
is consistent with their earlier findings. Additionally E2 had a more significant effect than FSH in our
hands. Retinoic acids, including ATRA and RA, are fat-soluble small molecule metabolites of vitamin
A. RA plays an important role in biological development and normal physiological conditions. The
compound can mediate cell differentiation, proliferation, apoptosis, and regulate immune function.
Kerkis and colleagues found that, 10−5 mol/L of RA could induce mouse ESCs to differentiate into
MGCs positive for Dazl gene expression. The single factor induction by ATRA and RA in our study
showed that both can enhance the expression of the chicken DAZL gene. Am80 is a new synthetic retinoic

Int. J. Mol. Sci. 2015, 16
6603
acid analogue and specific receptor agonist of RARα. Am80 has a higher induced efficiency than ATRA
or RA.
Combining with the prediction of regulatory elements binding sites of chicken DAZL gene (Figure S3),
a RAR-beta (RARβ) binding site presented in the gene’s core promotor region. This indicated that ATRA
and RA could probably promoting chicken DAZL gene transcription by directly binding this interval.
The absence of ER (estrogen receptor) and RARalpha (RARα) binding site indicating that E2 or Am80
might play its role through other bound transcription factors or by signaling. We also found two AR
(androgen receptor) binding sites in this region, ATRA, Am80 or E2 could also directly binding this
interval to paly the role in chicken DAZL gene transcriptional regulation. We are investigating further
about the specific molecular mechanism of chicken DAZL gene inducer.
To further validate whether the inducers we screened from chicken DF-1 cells could be applied to
other species, we also used mouse GC-1 cells for the same test (Figure S1). The results showed that
ATRA, Am80, and E2 could also significantly increased the activity of the DAZL gene promoter in
GC-1 cells (Figure S2C). ATRA, Am80, and E2 can significantly enhance the activity of the chicken
DAZL gene promoter and expression of the encoded DAZL protein. The formation of MGC-like cells
was also observed during the induction, indicating that these factors can regulate the minimal chicken
DAZL promoter similar to its mammalian counterparts.
5. Conclusions
In this paper, we identified the core promoter region of the DAZL gene for the Suqin yellow chicken,
and compared the induction efficiency of different inducers. ATRA, Am80, and E2 were screened as
optimal inducers of the chicken DAZL gene, and in vitro induction validation was performed. This study
provides a starting point to design the optimal culture system to induce chicken ESCs to differentiate
into MGCs in vitro, in part, by significantly raising DAZL gene expression.
Supplementary Materials
Supplementary materials can be found at http://www.mdpi.com/1422-0067/16/03/6595/s1.
Acknowledgments
The author thanks the Poultry Institute of the Chinese Academy of Agricultural Sciences
Experimental Poultry Farm for providing the experimental materials.
Author Contributions
Bichun Li conceived and designed the experiments; Lei Zhang, Rui Zhu, Qisheng Zuo and Dong Li
performed the experiments; Lei Zhang analyzed the data; Lei Zhang and Rui Zhu wrote the paper; and
Lei Zhang, Chao Lian, Beibei Tang, Tianrong Xiao and Yani Zhang edited it; Lei Zhang and Rui Zhu
worked as the same in this study.
Conflicts of Interest
The authors declare no conflict of interest.

Int. J. Mol. Sci. 2015, 16
6604
References
1. Xu, E.Y.; Moore, F.L.; Pera, R.A.R. A gene family required for human germ cell development
evolved from an ancient meiotic gene conserved in metazoans. Proc. Natl. Acad. Sci. USA 2001,
98, 7414–7419.
2. Eberhart, C.G.; Maines, J.Z.; Wasserman, S.A. Meiotic cell cycle requirement for a fly homologue
of human Deleted in Azoospermia. Nature 1996, 381, 783–785
3. Ruggiu, M.; Cooke, H.J. In vivo and in vitro analysis of homodimerization activity of the mouse
Dazl1 protein. Gene 2000, 252, 119–126.
4. Yen, P.H. Putative biological functions of the DAZ family. Int. J. Androl. 2004, 27, 125–129.
5. Lin, Y.M.; Chen, C.W.; Sun, H.S.; Tsai, S.J.; Hsu, C.C.; Teng, Y.N.; Lin, J.S.; Kuo, P.L. Expression
patterns and transcript concentrations of the autosomal DAZL gene in testes of azoospermic men.
Mol. Hum. Reprod. 2001, 7, 1015–1022.
6. Houston, D.W.; King, M.L. A critical role for Xdazl, a germ plasm-localized RNA, in the
differentiation of primordial germ cells in Xenopus. Development 2000, 127, 447–456.
7. Vogel, T.; Speed, R.M.; Ross, A.; Cooke, H.J. Partial rescue of the Dazl knockout mouse by the
human DAZL gene. Mol. Hum. Reprod. 2002, 8, 797–804.
8. Nicola, R.; Brian, C.; Victoria, B.; Nicola, K.G.; Howard, J.C. Translation of the synaptonemal complex
component Sycp3 is enhanced in vivo by the germ cell specific regulator Dazl. RNA 2007, 13, 974–981.
9. Yu, Z.; Ji, P.; Cao, J.; Zhu, S.; Li, Y.; Zheng, L.; Chen, X.; Feng, L. Dazl promotes germ cell
differentiation from embryonic stem cells. J. Mol. Cell Biol. 2010, 2, 170.
10. Haston, K.M.; Tung, J.Y.; Pera, R.A.R. Dazl functions in maintenance of pluripotency and genetic
and epigenetic programs of differentiation in mouse primordial germ cells in vivo and in vitro.
PLoS One 2009, 4, e5654.
11. Kehkooi, K.; Vanessa, T.A.; Martha, F.; Ha, N.N.; Renee, A.R.P. Human DAZL, DAZ and BOULE
genes modulate primordial germ-cell and haploid gamete formation. Nature 2009, 462, 222–225.
12. Sun, M. Study on Male Germ Cell Derived from Chicken Embryonic Stem Cell and the Generation
of Transgenic Chicken. Ph.D. Dissertation, Yangzhou University, Yangzhou, China, 2012.
13. Tung, J.Y.; Rosen, M.P.; Nelson, L.M.; Turek, P.J.; Witte, J.S.; Cramer, D.W.; Cedars, M.I.;
Reijo-Pera, R.A. Novel missense mutations of the Deleted-in-AZoospermia-Like (DAZL) gene in
infertile women and men. Reprod. Biol. Endocrinol. 2006, 4, 40.
14. Zhang, Q.B.; Li, Q.F.; Li, J.H.; Li, X.F; Liu, Z.S.; Pan, Z.X.; Song, D.W.; Xie, Z. The cow b-DAZL
spermatogenesis related new gene cloning and bioinformatics analysis and expression study.
Prog. Natl. Sci. 2008, 18, 493–504.
15. Linher, K.; Cheung, Q.; Baker, P.; Bedecarrats, G.; Shiota, K.; Li, J. An epigenetic mechanism
regulates germ cell-specific expression of the porcine Deleted in Azoospermia-Like (DAZL) gene.
Differentiation 2009, 77, 335–349.
16. Wang, H.; Zhang, L.; Hou, M.; Wang, C.-F.; Wang, L.-L.; Sun, T.; He, H.-B.; Zhong, J.-F. Cloning
and activity analysis of bovine natural resistance associated macrophage protein 1 (Nramp1) Gene
Promoter. Sci. Agric. Sin. 2011, 44, 1022–1028.

Int. J. Mol. Sci. 2015, 16
6605
17. Teng, Y.N.; Chang, Y.P.; Tseng, J.T.; Kuo, P.H.; Lee, I.W.; Lee, M.S.; Kuo, P.L. A single-nucleotide
polymorphism of the DAZL gene promoter confers susceptibility to spermatogenic failure in the
Taiwanese Han. Hum. Reprod. 2012, 27, 2857–2865.
18. Lin, Y.; Gill, M.E.; Koubova, J.; Page, D.C. Germ cell-intrinsic and-extrinsic factors govern meiotic
initiation in mouse embryos. Science 2008, 322, 1685–1687.
19. Pan, S. Study on Mouse Embryonic Stem Cells Differentiate into Male Germ Cells. Ph.D.
Dissertation, Northwest Agriculture & Forestry University, Yangling, China, 2010.
20. Shi Q.; Zhang, Z.; Li, P.; Zheng, M.-M.; Wang, D.; Huang, X.-M.; Zhang. Y.-N.; Li, B.-C. Study on
differentiation of chicken embryonic stem cells to male germ cells by BMP4. Acta Vet. Zootech. Sin.
2013, 44, 1749–1757.
© 2015 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/4.0/).

Supplementary Information
Figure S1. The primer design scheme for deletional analysis of the chicken DAZL gene
promoter region.
Figure S2. (A) The GFP detection of promoter activity of the chicken DAZL long
promoter fragment in GC-1 cells transfected with positive control pDAZL-EGFP,
pEGFP-N1, and negative control pLinker-EGFP (40× magnification); (B) The activity
of different promoter regions of the chicken DAZL gene in GC-1 cells; (C) The effect
of different inducers on the activity of the chicken DAZL core gene promoter in mouse
GC-1 cells. * represents p < 0.05, ** represents p < 0.01.

S2
Figure S3. Prediction of regulatory elements binding sites at −383~−36 bp of chicken DAZL gene.

Copyright of International Journal of Molecular Sciences is the property of MDPI Publishing
and its content may not be copied or emailed to multiple sites or posted to a listserv without
the copyright holder's express written permission. However, users may print, download, or
email articles for individual use.
