Sotolon Enantiomers in White Wines
J. Agric. Food Chem., Vol. 56, No. 5, 2008 1607
750 rpm). The resulting organic phases were mixed and dried over
anhydrous sodium sulfate. The organic extract was then concentrated
to 0.5 mL under a nitrogen stream (100 mL/min). Two microliters of
the extract was injected into a gas chromatograph (GC) with a mass
spectrometer (MS) detector.
Table 1. Impact of Injector Temperature on the Racemization of Sotolon
in GC-MS
injector
(R)-enantiomeric excess (%)
(R - S)/(R + S)
temp (°C)
Racemization Studies in Wine Model Solution. Samples (500 µL)
were extracted twice with 200 µL of ethyl acetate (vortex 2, 2 min).
Organic phases were mixed and dried over anhydrous sodium sulfate.
Two microliters of the extract was injected into a GC with an MS
detector.
150
180
190
200
210
230
99
98
97
92
79
65
Gas Chromatography-Mass Spectrometry (GC-MS) Conditions.
A Star 3400CX gas chromatograph (Varian) fitted to a Saturn 2000
electronic ion trap mass spectrometer from Varian was used to analyze
the wine extracts. The precolumn was a fused silica column coated
with polar phase (BP20; 2 m × 0.25 mm i.d. internal diameter; 0.25
µm film thickness) (SGE, France) followed by a 30 m × 0.25 mm i.d.
fused silica column coated with a 0.25 µm film of a solution of 20%
ꢀ-cyclodextrin in (35% phenyl)-methylpolysiloxane (HPchiral) from
J&W (France). The carrier gas was He (Linde gas, Bordeaux), 5.3 grade,
with a flow rate of 1 mL/min. A Varian 1078 temperature-program-
mable injector was used to inject the 2 µL sample. The injector was
initially set at 180 °C for 0.3 min, and then the temperature was raised
to 230 at 180 °C/min for 30 min. Oven temperature was initially set at
50 °C for 0.1 min, raised to 110 at 1 °C/min, held at that temperature
for 20 min, then raised to 210 at 3 °C/min, and held at that temperature
for a further 20 min.
Odor Thresholds. The sotolon enantiomer perception thresholds
were determined using the method described by Boidron (9). The
sensory panel consisted of 60 persons from 20 to 40 years old, who
received weekly training sessions. Tests were performed at a controlled
room temperature of 20 °C, in individual booths, using covered AFNOR
glasses containing about 40 mL of liquid. Olfactory thresholds were
measured using ranking tests, with five series of triangular tests,
presented with increasing sotoloncontent. The perception threshold
corresponded to the minimum concentration recognized by 50% of the
tasters. The neutral white wine used to determine olfactory thresholds
was previously extracted and analyzed and then supplemented with
sotolon.
Racemization of (R)-Sotolon. A 40 mL sample of a model wine
solution was supplemented with (R)-sotolon (100 mg/L) [enantiomeric
excess (ee) ) 99.5%] and divided among four 10 mL flasks. To study
the influence of the model wine solution’s pH on the racemization of
(R)-sotolon, NaOH was added to obtain pH values of 3.0 and 3.5 (WTW
720 pH-meter; VWR, France). Samples (in duplicate) were kept in the
dark, at room temperature (20 °C). Every 15 days in the first month,
then once per month, an aliquot of each sample (500 µL) was extracted
with ethyl acetate and injected into the GC-MS. The sotolon extraction
procedure and chromatographic conditions were as described above.
The transfer line and manifold were maintained at 210 and 80 °C,
respectively. Trap temperature was maintained at 170 °C. Axial
modulation was 3.5 V. Injection (2 µL) was in splitless mode (closure
time ) 0.75 min). For the sotolon detection segment, 55-80 min after
the beginning of the GC run (Tr ) 55–80 min), current intensity was
20 µamp and the offset multiplier for the voltage value was at 100 V.
The mass spectra were acquired in electron impact mode (ionization
energy ) 70 eV), limiting the mass range between 81 and 130 (SIS
mode). Ion 83 was used to quantify sotolon, and ion 128 confirmed its
presence.
RESULTS AND DISCUSSION
Impact of Temperature Injection by GC on Racemization
of the Sotolon Enantiomer in White Wine Extract. Many
optically active compounds are racemized simply by heating
them (17). For example, Marriot (18) demonstrated partial
racemization of linalool during the distillation (T ) 100 °C) of
a lavender extract. The thermodegradation of sotolon is one of
the known properties applied in this GC-MS on-column assay
mode (13, 19). In a previous work, sotolon degradation was
shown to occur in the gas chromatograph injector at tempera-
tures above 180 °C (20), suggesting that it could be linked with
the racemization phenomenon. However, to our knowledge,
examples of partial or total racemization of volatile compounds
in the chromatograph injector have not been widely reported.
We determined the optimum injector temperature, under our
assay conditions. A model dry white wine solution supplemented
with 10 µg/L sotolon was extracted, as previously described.
The organic extract obtained was analyzed repeatedly by GC-
MS, varying the injector temperature from 150 to 230 °C. The
results obtained are shown in Table 1. Partial racemization was
observed at high temperature (230 °C), with a decrease in the
enantiomeric excess (ee) value from 99 to 65%. Therefore, lower
temperatures (180 °C) would be more appropriate for studying
the distribution of sotolon enantiomers in wine.
Racemization studies were carried out with a GC HP-5890 (Agilent,
France) coupled to MS HP-5972, fitted with the capillary column
previously described. The operating parameters were as follows:
isothermal injection temperature, 180 °C; transfer line temperature, 230
°C. The GC temperature program was the same as for Varian GC.
Impact of Injection Temperature on Sotolon Racemization. A
model solution (12% vol EtOH; 5 g/L tartaric acid, pH 3.5) supple-
mented with (R)-sotolon (10 µg/L) was extracted, as previously
described. The resulting organic extract was analyzed by GC-MS
(Varian), varying the injector temperature from 150 to 230 °C. Injection
was repeated three times at each temperature. The programmable
injector temperature settings and chromatographic conditions were as
described above.
Separation of (R)-Sotolon and (S)-Sotolon from a Commercial
Racemic Mixture. HPLC Separation. HPLC was performed on a
Merck L-7100 pump connected to a Merck variable-wavelength UV
detector. The preparative column was a Chiralpak AS-H model (250
× 20, 5 µm). The eluent consisted of 10% isopropanol in n-heptane
with a flow rate of 20 mL/min at a constant temperature of 25 °C.
When the two compounds were collected after HPLC purification, 50
mg of each sotolon enantiomer was obtained.
Purity Control. The purity of each enantiomer was assessed by HPLC
fitted with a Chiralpak AS-H 5 µm (250 × 4.6 mm). Detection
wavelength was 250 nm. Enantiomeric excesses were 99.5 and 98.5%
for the first and second eluting peaks, respectively.
Distribution of the Sotolon Enantiomers in Dry White
Wine. The optical isomers of sotolon in the dry white wines
Chiral Identity. The absolute configuration of sotolon was elucidated
by measuring the specific rotation values of this optically active
furanone. For the first eluting peak: [R]D20 ) -10.2° (c 0.45; CHCl3)
and for the second eluting peak: [R]D20 ) +14.4° (c 0.5; CHCl3). These
values are close to those obtained by Guichard (16) for the optical
were separated by chiral GC analysis on a ꢀ-cyclodextrin phase
with a polar precolumn. Each enantiomer had previously been
injected separately to identify its retention time (Figure 1). The
commercial dry white wines were tasted by a panel of well-
trained jury prior to analysis. All of the wines were systemati-
cally found to be strongly oxidized with odors reminiscent of
honey.
20
rotation of (R) and (S)-sotolon: [R]D ) -19.3 (c 1.15; CHCl3) and
20
[R]D ) +16.5° (c 1.2; CHCl3), respectively.
Optical Rotation. Optical rotation was determined on a Perkin-
Elmer 341 polarimeter using a 1 dm cell.
