tial emission also in the UV region. We believe that female Luer to female 10–32 adapters in conjunction with
1
0–32 fingertight fittings for 1/16 inch OD tubing (Up-
the failure of LED with a-terpinene could be ascribed
to their limited emission range that probably affects
the sensitized production of singlet oxygen, although
church). Proton nuclear magnetic resonance analysis
1
(
H NMR) was carried out on a Bruker AC 250F tuned at
50 MHz. According to the specification sheet available in
2
its lower lifetime in toluene, with respect to D O,
2
the internet (www.cnmic.com) for the white LED used
model. ML50W13H-BED) the emission spectrum is in the
cannot be ruled out. We are currently purchasing a
suitable equipment for an accurate control and meter-
ing of light sources to extend this promising photooxi-
dation study also to other functional substrates.
(
range 440–630 nm with two broad peaks at 480 and 580 nm.
The power supply for the LED-based light source was a
HAMEG instrument (model HM7042-S, Elpav Instruments,
The results reported in this paper were achieved Padua).
with a simple set-up in which the solid photosensitizer
was confined into suitably-designed chambers within
Fabrication of the Reactor Head with Integrated
Female Ports
the MR that was equipped with original female ports
for a quick and easy press-fit connection. The design
principles reported in this work should be applicable The structure of an integrated female port is depicted sche-
matically in Figure 1a. For its construction, access holes
to the inclusion of other supported molecular struc-
were drilled on two identical glass-slides using the corre-
tures, such as catalysts, scavengers or bead-based che-
sponding mask as a reference. One of the two glass-slides
mosensors, in the microfluidic network. As a final
was placed in horizontal position and flanged tubes were in-
remark, we believe that safety issues should make a
serted, flange up, into each of the access holes. Spacers were
microreactor a system to be considered for photo-
glued at the corners of the glass plate using a small amount
chemical oxygenations even if efficiency questions
would be in favour of a batch reactor
of thiolene resin (UV lamp exposition time of about a
minute). Next, the flanged holes were plugged with stoppers
and the adhesive was poured over the glass plate. A second
glass plate was aligned using the stopper tubes as a guide
and carefully layered on the thiolene resin avoiding air bub-
bles formation. The device was allowed to pre-cure beneath
the UV-lamp for two minutes. After removing the stopper
tubes with a tweezer, the reactor head was allowed to post
cure for 20 min. Finally, the device was thermally cured at
Experimental Section
Materials and General Methods
Chemical reagents were purchased from Aldrich and used
as received. The silica supported, fullerene-based sensitizer
5
08C for 12 h to complete the thiolene cross-linking and
[10c]
make the device impervious to organic solvents. The de-
tailed layout of the reactor head construction is reported in
the Supporting Information associated to this paper.
was prepared according to a published procedure.
Optical
adhesive NOA81 was obtained from Norland Products Inc.
A Spectroline SB-100P flood lamp (Spectronics, optimized
for 365 nm) was used for pre- and post-curing the optical ad-
hesive. The lamp was housed inside a home-made dark-box
that allowed us to place the device 60 and 10 cm away from
the lamp during pre-cure (to achieve a degree of beam colli-
mation) and post-cure, respectively. The fluidic path was
generated by using a computer drawing package (Canvas
ver. 9) and printed out in duplicate on transparency film
Fabrication of the Microstructured Reactor
The head described previously served as the bottom layer
for the construction of the photochemical MR. To this pur-
pose, the access holes of the reactor head were plugged with
stopper tubes to prevent contamination with the adhesive.
Using the mask as a reference, pieces of paper filters (about
2ꢄ5ꢄ0.3 mm) were placed in the appropriate locations (F1,
F2, and F3 in Figure 2) and glued to the glass using small
amounts of thiolene adhesive (curing time 1 min). The same
kind of paper filter was also used as spacer and glued to the
corners of the bottom layer. The adhesive was poured over
the glass plate then a second glass plate was carefully lay-
ered on the thiolene resin. The mask was placed on the top
and the assembly and pre-cured for 45 s beneath the UV
lamp at a distance of 60 cm. After removing the stoppers,
the channels were emptied by connecting the device to a
water aspirator, then extensively washed with methanol al-
ternated to short washings with acetone. The device was
dried with a flow of nitrogen. Post curing was carried out by
placing the microreactor under the UV lamp for 20 min at a
distance of 10 cm from the bulb, followed by thermal curing
at 508C for 12 h to attain mechanical stability and to
become impervious to organic solvents. The chambers of the
MR, filled with the sensitizer (vide infra), were connected in
series through small bridges of PTFE tubing. The light
(
KarnaK cod. 2676) using a 1200 dpi laser printer (Epson
EPL-6200). The two masks were aligned on top of each
other and taped together. Access holes (inlets and outlets)
were drilled on glass plates (25ꢄ75ꢄ1 mm or 50ꢄ100ꢄ
1
mm) using a diamond wheel point (Dremel item n. 7103,
bit diameter 2.0 mm, mounted in a variable speed multipro
rotary tool fixed to a 220–01 work station drill press). PTFE
tubings (OD=1/8 inch, ID=1/16 inch, Supelco, item no.
58699) were flanged with a flanging tool (female ports).
PTFE tubing (OD=1/16 inch, ID=1/32 inch, Supelco, item
no. 58701) were used for connecting the MR to sample res-
ervoirs and pumps. During the construction of the reactors,
in some cases it was necessary to prevent the adhesive to
enter into the flanged tubes. In such cases, small pieces of
the connection tubes were filled with optical glue, cured be-
neath the UV lamp, and used as stoppers.
Liquids and gas were delivered to the MR by syringe
pumps (KD-Scientific, Mod. KDS200 and KDS100)
equipped with 5-mL gas-tight Hamilton syringes. The con-
nection between tubing and syringes was realized with
