Enantioselective synthesis, crystal structure, and photophysical properties of a 1,1′-bitriphenylene-based sila[7]helicene

Article abstract of DOI:10.1002/ejoc.201403565

A 1,1′-bitriphenylene-based sila[7]helicene was synthesized with a high ee value by enantioselective double [2+2+2] cycloaddition of a biaryl-linked tetrayne with a silicon-linked bis(propargylic alcohol) as a key step. This sila[7]helicene exhibited a high tolerance toward racemization, which could be explained by the X-ray crystal structure analysis. With respect to the photophysical properties, this sila[7]helicene exhibited a relatively high fluorescence quantum yield and circularly polarized luminescence activity.

Full text of DOI:10.1002/ejoc.201403565

SHORT COMMUNICATION
DOI: 10.1002/ejoc.201403565
Enantioselective Synthesis, Crystal Structure, and Photophysical Properties of
a 1,1Ј-Bitriphenylene-Based Sila[7]helicene
Koichi Murayama,[a] Yasuaki Oike,[a] Seiichi Furumi,[b] Masayuki Takeuchi,[c]
Keiichi Noguchi,[d] and Ken Tanaka*[a,e,f]
Keywords: Luminescence / Helicenes / Triphenylenes / Cycloaddition / Rhodium
A 1,1Ј-bitriphenylene-based sila[7]helicene was synthesized
with a high ee value by enantioselective double [2+2+2]
cycloaddition of a biaryl-linked tetrayne with a silicon-linked
bis(propargylic alcohol) as a key step. This sila[7]helicene
exhibited a high tolerance toward racemization, which could
be explained by the X-ray crystal structure analysis. With
respect to the photophysical properties, this sila[7]helicene
exhibited a relatively high fluorescence quantum yield and
circularly polarized luminescence activity.
would afford an 1,1Ј-bitriphenylene-based sila[7]helicene
(Scheme 1). Recently, Nozaki, Nakano, and co-workers
reported the synthesis of an enantiopure 3,3Ј-biphen-
anthrene-based sila[7]helicene[12] by the platinum-catalyzed
intramolecular double hydroarylation followed by resolu-
tion with chiral HPLC,[4] while the enantioselective synthe-
sis of the sila[7]helicene has not been achieved. In this pa-
per, we disclose the enantioselective synthesis, crystal struc-
ture, and photophysical properties of the 1,1Ј-bitripheny-
lene-based sila[7]helicene.
Introduction
Silafluorene derivatives have attracted much attention in
materials chemistry because of their use for organic electro-
luminescent compounds.[1] There have been several reports
on the transition-metal-catalyzed synthesis of sila-
fluorenes.[2–4] For example, several research groups have re-
ported the intra- and intermolecular cross-coupling reac-
tions to produce silafluorenes.[2] Murakami and co-workers
reported a conceptually different strategy, the iridium-cata-
lyzed [2+2+2] cycloaddition of silicon-linked diynes with
monoynes, for the synthesis of silafluorenes.[3] On the other
hand, our research group reported the enantioselective syn-
thesis of 1,1Ј-bitriphenylene-based carbo- and phospha[7]-
helicenes by the rhodium-catalyzed double [2+2+2] cyclo-
addition of a biaryl-linked tetrayne with carbonyl- or
phosphorus-linked diynes (Scheme 1).[5–11] We anticipated
that the rhodium-catalyzed double [2+2+2] cycloaddition
of the biaryl-linked tetrayne with a silicon-linked diyne
[a] Department of Applied Chemistry, Faculty of Engineering,
Tokyo University of Agriculture and Technology
Koganei, Tokyo184-8588, Japan
[b] Department of Applied Chemistry, Faculty of Science,
Tokyo University of Science
Scheme 1. Enantioselective synthesis of 1,1Ј-bitriphenylene-based
[7]helicenes by rhodium-catalyzed [2+2+2] cycloadditions.
1-3 Kagurazaka, Shinjuku, Tokyo 162-8601, Japan
[c] Organic Materials Group, National Institute for Materials
Science
Results and Discussion
1-2-1 Sengen, Tsukuba, Ibaraki 305-0047, Japan
[d] Instrumentation Analysis Center, Tokyo University of
Agriculture and Technology
Our research group previously reported that a silyl-sub-
stituted propargylic alcohol is a highly reactive substrate in
the rhodium-catalyzed [2+2+2] cycloaddition with a biaryl-
linked diyne (Scheme 2).[13]
Koganei, Tokyo184-8588, Japan
[e] Department of Applied Chemistry, Graduate School of Science
and Engineering,
Tokyo Institute of Technology
Thus, silicon-linked bis(propargylic alcohol)
2 was
Ookayama, Meguro-ku, Tokyo 152-8550, Japan
E-mail: ktanaka@apc.titech.ac.jp
selected as a cycloaddition partner of the biaryl-linked
tetrayne 3. Diyne 2 was readily prepared in two steps
through the silylation of protected propargylic alcohol 1
followed by deprotection (Scheme 3). Various cationic
rhodium(I)/axially chiral biaryl bisphosphine complexes
http://www.tuat.ac.jp/~tanaka-k/
[f] ACT-C, Japan Science and Technology Agency (JST),
4-1-8 Honcho, Kawaguchi, Saitama 332-0012, Japan
Supporting information for this article is available on the
WWW under http://dx.doi.org/10.1002/ejoc.201403565.
Eur. J. Org. Chem. 2015, 1409–1414
© 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
1409

K. Tanaka et al.
SHORT COMMUNICATION
based carbo[7]helicene,[5] but significantly smaller than that
(2980°) of the 3,3-biphenanthrene-based sila[7]helicene.[4]
For comparison, the rhodium-catalyzed double [2+2+2]
cycloaddition of biaryl-linked diyne 6 with 2 was examined
(Scheme 5). Interestingly, not the corresponding C–Si bond
cleavage product 8 but the double [2+2+2] cycloaddition
product 7 was obtained in good yields. Therefore, steric
strain of sila[7]helicene 5 might facilitate C–Si bond
cleavage.
In order to confirm the formation of (+)-4 from (+)-5,
the reaction of (+)-5 with the cationic rhodium(I)-
BArF4/(S)-segphos complex was examined. Indeed, (+)-4
was generated in good yield without racemization at room
temperature (Scheme 6).
We previously reported that the racemization of a carb-
onyl-linked 1,1Ј-bitriphenylene proceeds in (CH2Cl)2 solu-
tion at 80 °C.[5] The thermal stability of 1,1Ј-bitriphenylene-
based sila[7]helicene 5 toward racemization was examined,
which revealed that no racemization was observed in
(CH2Cl)2 solution at 80 °C for 24 hours. This observation
is consistent with the recent report by Nozaki, Nakano, and
co-workers, which discloses the extraordinarily high
tolerance of the phenanthrene-based sila[7]helicene toward
racemization.[4]
Scheme 2. Rhodium-catalyzed [2+2+2] cycloaddition of a biaryl-
linked diyne with a silyl-substituted propargylic alcohol.
were screened for the reaction of tetrayne 3[5] and diyne 2
at room temperature for 16 hours, which revealed that the
use of a cationic rhodium(I)-BArF4/(S)-segphos complex
shows the highest catalytic activity, while not the desired
sila[7]helicene but biaryl (+)-4 was obtained with a high ee
value (Scheme 3).
It is well known that transition-metal complexes react
with aryl[2-(hydroxymethyl)phenyl]dimethylsilanes to form
[1,2]oxasilole derivatives through transmetallation of in situ
generated tetraorganosilicon intermediates.[14] In order to
minimize the formation of the undesired biaryl (+)-4, the
same reaction was conducted for 1 hour to give the desired
1,1Ј-bitriphenylene-based sila[7]helicene (+)-5 in 18% yield
The X-ray crystal structure of enantiopure (+)-5 is shown
with 85% ee (Scheme 4) along with (+)-4 in ca. 10% yield. in Figure 1. The angle between two formal C=C double
–
The use of the BF4 counteranion improves the enantio- bonds of the annelated cyclopentadiene fragment is 48.1°,
selectivity, but the product yield decreases (Scheme 4). The which is larger than that for the carbonyl-linked 1,1Ј-bitri-
optical rotation value (1378°) of 5, which is calculated as phenylene (37.2°)[5] and close to that of the 3,3-biphen-
100% ee, was close to that (1087°) of the 1,1-bitriphenylene- anthrene-based sila[7]helicene (53°).[4] This feature accounts
Scheme 3. Enantioselective synthesis of 1,1Ј-bitriphenylene-based biaryl 4 by rhodium-catalyzed [2+2+2] cycloaddition.
1410
www.eurjoc.org
© 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Eur. J. Org. Chem. 2015, 1409–1414

1,1Ј-Bitriphenylene-Based Sila[7]helicene
Scheme 4. Enantioselective synthesis of 1,1Ј-bitriphenylene-based sila[7]helicene (+)-5 by rhodium-catalyzed [2+2+2] cycloaddition.
Scheme 5. Rhodium-catalyzed [2+2+2] cycloaddition of biaryl-linked diyne 6 with silicon-linked bis(propargylic alcohol) 2.
Scheme 6. Rhodium-mediated formation of (+)-4 from (+)-5.
for the higher tolerance of 5 towards racemization. On the
other hand, the sum of the five dihedral angles [C15–C16–
C17–C18, C16–C17–C18–C19, C17–C18–C19–C36, C18–
Figure 1. X-ray crystal structure analysis of enantiopure (+)-5 with
C19–C36–C35, and C19–C36–C35–C34] is 119.1°, which is
ellipsoids at 30% probability.
significantly larger than those for the carbonyl-linked 1,1Ј-
bitriphenylene (90.7°)[5] and the 3,3-biphenanthrene-based
sila[7]helicene (99.5°).[4] Therefore, triphenylene-based
Absorption and emission spectra of 5 are shown in Fig-
sila[7]helicene 5 is more distorted than the carbonyl-linked ure 2. The absorption maximum of 5 is 269 nm, which is
1,1Ј-bitriphenylene and 3,3-biphenanthrene-based sila[7]- longer than that for the 3,3-biphenanthrene-based sila[7]-
helicene. The absolute configuration of (+)-5 was deter- helicene (ca. 260 nm)[4] presumably because of the more ex-
mined to be P by the anomalous dispersion method.[15]
tended delocalization of the π-electrons over triphenylene
Eur. J. Org. Chem. 2015, 1409–1414
© 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.eurjoc.org
1411

K. Tanaka et al.
SHORT COMMUNICATION
than phenanthrene. Compound 5 exhibits a strong blue alcohol) as a key step. The thus obtained 1,1Ј-bitriphen-
luminescence with λmax = 482 nm, which is also longer than ylene-based sila[7]helicene exhibits a high tolerance toward
that for the 3,3-biphenanthrene-based sila[7]helicene racemization, which could be explained by the X-ray crystal
(450 nm).[4] The fluorescence quantum yield of 5 in CHCl3 structure analysis. With respect to the photophysical prop-
is relatively high (15%) for helicene derivatives,[16] although erties, this sila[7]helicene exhibits a relatively high fluores-
those of the 3,3-biphenanthrene-based sila[7]helicene cence quantum yield and circularly polarized luminescence
(23%)[4] and the 1,1-bitriphenylene-based carbo[7]helicene activity.
(32%)[5] are higher.
Experimental Section
Typical Procedure: (Scheme 4). Under an atmosphere of argon,
[Rh(cod)2]BArF (11.8 mg, 0.010 mmol) and (S)-segphos (6.1 mg,
4
0. 010 mmol) were dissolved in CH2Cl2, and the mixture was stirred
at room temperature for 10 min. H2 was introduced to the resulting
solution in a Schlenk tube. After the mixture was stirred at room
temperature for 1 h, it was concentrated to dryness. To
a
(CH2Cl)2 (1.0 mL) solution of the residue and (8.4 mg,
2
0.0500 mmol) was added a (CH2Cl)2 (1.0 mL) solution of 3
(20.1 mg, 0.0500 mmol). The mixture was stirred at room tempera-
ture for 1 h. The resulting solution was concentrated and purified
by a preparative TLC (hexane/ethyl acetate/CH2Cl2/CH3OH =
100:60:60:3) to give (+)-5 (5.1 mg, 0.0091 mmol, 18% yield, 85%
ee).
Supporting Information (see footnote on the first page of this arti-
Figure 2. UV/Vis (blue line) and fluorescence (red line) spectra of
cle): Experimental procedures, characterization data, and copies of
5 at 7.8ϫ10–6 m in CHCl3 at 25 °C.
1
the H NMR and 13C NMR spectra are presented.
The corresponding circular dichroism (CD) spectra of
(+)-5 (91% ee) and (–)-5 (91% ee) in CHCl3 is shown in
Figure 3. It was found that these enantiomers show strong
Cotton effects, which are mirror images. Thus, we at-
tempted to measure circularly polarized luminescence
(CPL) of (+)-5, as shown in Figure 3.[17] The value is glum
= –0.016 at 482 nm, which is larger than that for the 3,3-
biphenanthrene-based sila[7]helicene (glum = –0.0035 at
470 nm)[4] but smaller than that for the 1,1-bitriphenylene-
based carbo[7]helicene (glum = –0.030 at 428 nm).[5,18]
Acknowledgments
This work was supported partly by ACT-C from Japan Science
and Technology Agency (JST, Japan). We thank Nanotechnology
Platform Project of MEXT, Japan. We also thank Mr. Yuta
Miyauchi (TUAT) for his valuable assistance, Takasago Inter-
national Corporation for the gift of Segphos, and Umicore for
generous support in supplying the rhodium complex.
[1] For a review, see: a) J. Chen, Y. Cao, Macromol. Rapid Com-
mun. 2007, 28, 1714. For examples, see: b) J. J. McDowell, F.
Maier-Flaig, T. J. A. Wolf, A.-N. Unterreiner, U. Lemmer, G.
Ozin, ACS Appl. Mater. Interfaces 2014, 6, 83; c) J. J. McDow-
ell, I. Schick, A. Price, D. Faulkner, G. Ozin, Macromolecules
2013, 46, 6794; d) E. Pusztai, H. Albright, Y. Cai, R. Hu, R.
West, B. Z. Tang, I. A. Guzei, Organometallics 2013, 32, 6871;
e) E. Pusztai, I. S. Toulokhonova, N. Temple, H. Albright, U. I.
Zakai, S. Guo, I. A. Guzei, R. Hu, R. West, Organometallics
2013, 32, 2529; f) M. Shimizu, K. Mochida, M. Katoh, T. Hi-
yama, Sci. China Chem. 2011, 54, 1937; g) C. W. Keyworth,
K. L. Chan, J. G. Labram, T. D. Anthopoulos, S. E. Watkins,
M. McKiernan, A. J. P. White, A. B. Holmes, C. K. Williams,
J. Mater. Chem. 2011, 21, 11800; h) L. Li, C. Xu, S. Li, Tetrahe-
dron Lett. 2010, 51, 622; i) Y.-Q. Mo, X.-Y. Deng, X. Jiang,
Q.-H. Cui, J. Polym. Sci. Polym. Chem. 2009, 47, 3286; j) E.
Wang, C. Li, W. Zhuang, J. Peng, Y. Cao, J. Mater. Chem.
2008, 18, 797; k) E. Wang, C. Li, J. Peng, Y. Cao, J. Polym.
Sci. Polym. Chem. 2007, 45, 4941; l) K. L. Chan, S. E. Watkins,
C. S. K. Mak, M. J. McKiernan, C. R. Towns, S. I. Pascu, A. B.
Holmes, Chem. Commun. 2005, 5766; m) Y.-Q. Q. Mo, R.-Y.
Tian, W. Shi, Y. Cao, Chem. Commun. 2005, 4925; n) K. L.
Chan, M. J. McKiernan, C. R. Towns, A. B. Holmes, J. Am.
Chem. Soc. 2005, 127, 7662.
Figure 3. CD and CPL spectra of (+)-5 (blue) and (–)-5 (red) in
CHCl3 at 25 °C.
Conclusions
We have achieved the first enantioselective synthesis of a
sila[7]helicene through the double [2+2+2] cycloaddition of
a biaryl-linked tetrayne with a silicon-linked bis(propargylic
[2] For examples, see: a) M. Shimizu, K. Mochida, T. Hiyama,
Angew. Chem. Int. Ed. 2008, 47, 9760; Angew. Chem. 2008, 120,
1412
www.eurjoc.org
© 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Eur. J. Org. Chem. 2015, 1409–1414

1,1Ј-Bitriphenylene-Based Sila[7]helicene
9906; b) M. Tobisu, M. Onoe, Y. Kita, N. Chatani, J. Am.
Chem. Soc. 2009, 131, 7506; c) Y. Yabusaki, N. Oshima, H.
Kondo, T. Kusamoto, Y. Yamanoi, H. Nishihara, Chem. Eur.
J. 2010, 16, 5581; d) T. Ureshino, T. Yoshida, Y. Kuninobu, K.
Takai, J. Am. Chem. Soc. 2010, 132, 14324; e) Y. Liang, S.
Zhang, Z. Xi, J. Am. Chem. Soc. 2011, 133, 9204; f) R. Shin-
tani, H. Otomo, K. Ota, T. Hayashi, J. Am. Chem. Soc. 2012,
134, 7305; g) Y. Kuninobu, K. Yamauchi, N. Tamura, T. Seiki,
K. Takai, Angew. Chem. Int. Ed. 2013, 52, 1520; Angew. Chem.
2013, 125, 1560; see also ref. 1e.
T. Matsuda, S. Kadowaki, T. Goya, M. Murakami, Org. Lett.
2007, 9, 133.
H. Oyama, K. Nakano, T. Harada, R. Kuroda, M. Naito, K.
Nobusawa, K. Nozaki, Org. Lett. 2013, 15, 2104.
M. J. Webber, A. Martínez, C. De Fusco, B. List, Angew. Chem.
Int. Ed. 2014, 53, 5202; Angew. Chem. 2014, 126, 5303; c) M. C.
Carreño, Á. Enríquez, S. García-Cerrada, M. J. Sanz-Cuesta,
A. Urbano, F. Maseras, A. Nonell-Canals, Chem. Eur. J. 2008,
14, 603; d) A. Latorre, A. Urbano, M. C. Carreño, Chem. Com-
mun. 2009, 6652; e) A. Latorre, A. Urbano, M. C. Carreño,
Chem. Commun. 2011, 47, 8103; f) A. Grandbois, S. K. Collins,
Chem. Eur. J. 2008, 14, 9323; g) J. Caeiro, D. Peña, A. Cobas,
D. Pérez, E. Guitián, Adv. Synth. Catal. 2006, 348, 2466; h) M.
Miyasaka, A. Rajca, M. Pink, S. Rajca, J. Am. Chem. Soc.
2005, 127, 13806; i) M. C. Carreño, M. González-López, A.
Urbano, Chem. Commun. 2005, 611; j) A. Rajca, M. Miyasaka,
M. Pink, H. Wang, S. Rajca, J. Am. Chem. Soc. 2004, 126,
15211; k) M. Carreño, C. S. García-Cerrada, A. Urbano,
Chem. Eur. J. 2003, 9, 4118.
For reviews on helicene synthesis see: a) N. M. Saleh, C. Shen,
J. Crassous, Chem. Sci. 2014, 5, 3680; b) N. Hoffmann, J. Pho-
tochem. Photobiol. C: Photochem. Rev. 2014, 19, 1; c) A. Ur-
bano, M. C. Carreno, Org. Biomol. Chem. 2013, 11, 699; d) M.
Gingras, G. Félix, R. Peresutti, Chem. Soc. Rev. 2013, 42, 1007;
e) M. Gingras, Chem. Soc. Rev. 2013, 42, 968; f) Z. Peng, N.
Takenaka, Chem. Rec. 2013, 13, 28; g) Y. Shen, C.-F. Chen,
Chem. Rev. 2012, 112, 1463; h) R. Amemiya, M. Yamaguchi,
Chem. Rec. 2008, 8, 116; i) A. Rajca, M. Miyasaka, in Func-
tional Organic Materials: Syntheses, Strategies, and Applica-
tions (Eds.: T. J. J. Müller, U. H. F. Bunz), Wiley-VCH,
Weinheim, 2007, p. 543; j) A. Urbano, Angew. Chem. Int. Ed.
2003, 42, 3986; Angew. Chem. 2003, 115, 4116; k) C. Schmuck,
Angew. Chem. Int. Ed. 2003, 42, 2448; Angew. Chem. 2003, 115,
2552; see also chapter 10 of ref. 9a and ref. 9c.
Several 3,3Ј-biphenanthrene-based hetero[7]helicenes have been
reported. For oxa- and aza[7]helicenes, see: a) K. Nakano, Y.
Hidehira, K. Takahashi, T. Hiyama, K. Nozaki, Angew. Chem.
Int. Ed. 2005, 44, 7136; Angew. Chem. 2005, 117, 7298; b) S. D.
Dreher, D. J. Weix, T. J. Katz, J. Org. Chem. 1999, 64, 3671.
For thia[7]helicenes, see: c) S. Cossu, O. De Lucchi, D. Fabbri,
G. Valle, Tetrahedron 1997, 53, 6073; d) A. Dore, D. Fabbri, S.
Gladiali, G. Valle, Tetrahedron: Asymmetry 1995, 6, 779; e) G.
Gottarelli, G. Proni, G. P. Spada, D. Fabbri, S. Gladiali, C.
Rosini, J. Org. Chem. 1996, 61, 2013. See also ref. 12b. For
oxa[9]helicenes, see: f) M. Salim, T. Kimura, M. Karikomi,
Heterocycles 2013, 87, 547; g) M. Salim, H. Ubukata, T. Ki-
mura, M. Karikomi, Tetrahedron Lett. 2011, 52, 6591; h) M.
Salim, A. Akutsu, T. Kimura, M. Minabe, M. Karikomi, Tetra-
hedron Lett. 2011, 52, 4518. For phospha[7]helicenes, see: i) K.
Nakano, H. Oyama, Y. Nishimura, S. Nakasako, K. Nozaki,
Angew. Chem. Int. Ed. 2012, 51, 695; Angew. Chem. 2012, 124,
719.
K. Murayama, Y. Sawada, K. Noguchi, K. Tanaka, J. Org.
Chem. 2013, 78, 6202.
Y. Nakao, A. K. Sahoo, H. Imanaka, A. Yafa, T. Hiyama, Pure
Appl. Chem. 2006, 78, 435.
CCDC-1037274 [(+)-5] contains the supplementary crystallo-
graphic data for this paper. These data can be obtained free of
charge from The Cambridge Crystallographic Data Centre via
www.ccdc.cam.ac.uk/data_request/cif.
For example, the fluorescent quantum yield of hexahelicene is
0.041. See: M. Montalti, A. Credi, L. Prodi, M. T. Gandolfi,
in Handbook of Photochemistry, 3rd ed., Taylar & Francis,
Boca Raton, 2006.
The degree of CPL is given by the luminescence dissymmetry
ratio, which is defined as glum = 2(IL – IR)/(IL + IR), where IL
and IR are the luminescence intensities of left and right circu-
larly polarized light, respectively.
For recent examples on CPL-active single organic molecules,
see: a) T. Amako, K. Nakabayashi, T. Mori, Y. Inoue, M. Fu-
jiki, Y. Imai, Chem. Commun. 2014, 50, 12836; b) Y. Morisaki,
K. Inoshita, Y. Chujo, Chem. Eur. J. 2014, 20, 8386; c) Y. Mori-
saki, M. Gon, T. Sasamori, N. Tokitoh, Y. Chujo, J. Am. Chem.
Soc. 2014, 136, 3350; d) H. Maeda, W. Hane, Y. Bando, Y.
[3]
[4]
[5]
[6]
Y. Sawada, S. Furumi, A. Takai, M. Takeuchi, K. Noguchi, K.
Tanaka, J. Am. Chem. Soc. 2012, 134, 4080.
[11]
For other examples on enantioselective helicene synthesis by
the RhI-catalyzed [2+2+2] cycloaddition, see: a) K. Tanaka, A.
Kamisawa, T. Suda, K. Noguchi, M. Hirano, J. Am. Chem.
Soc. 2007, 129, 12078; b) K. Tanaka, N. Fukawa, T. Suda, K.
Noguchi, Angew. Chem. Int. Ed. 2009, 48, 5470; Angew. Chem.
2009, 121, 5578; c) N. Fukawa, T. Osaka, K. Noguchi, K.
Tanaka, Org. Lett. 2010, 12, 1324; d) M. R. Crittall, N. W. G.
Fairhurst, D. R. Carbery, Chem. Commun. 2012, 48, 11181; e)
Y. Kimura, N. Fukawa, Y. Miyauchi, K. Noguchi, K. Tanaka,
Angew. Chem. Int. Ed. 2014, 53, 8480; Angew. Chem. 2014, 126,
8620.
[7]
The enantio- or diastereoselective helicene syntheses by the
[2+2+2] cycloaddition with Ni0, CoI, and IrI complexes have
been reported. For Ni0, see: a) I. G. Stará, I. Starý, A.
[12]
ˇ
ˇ
Kollárovicˇ, F. Teplý, S. Vyskocˇil, D. Saman, Tetrahedron Lett.
1999, 40, 1993; b) F. Teplý, I. G. Stará, I. Starý, A. Kollárovicˇ,
ˇ
ˇ
D. Saman, S. Vyskocˇil, P. Fiedler, J. Org. Chem. 2003, 68, 5193;
c) I. G. Stará, Z. Alexandrová, F. Teplý, P. Sehnal, I. Starý, D.
Saman, M. Budesínský, J. Cvacka, Org. Lett. 2005, 7, 2547; d)
A. Jancˇarˇík, J. Rybácˇek, K. Cocq, J. V. Chocholousˇová, J. Va-
cek, R. Pohl, L. Bednárová, P. Fiedler, I. Cisarˇová, I. G. Stará,
I. Starý, Angew. Chem. Int. Ed. 2013, 52, 9970; Angew. Chem.
2013, 125, 10154; e) B. Heller, M. Hapke, C. Fischer, A. And-
ronova, I. Starý, I. G. Stará, J. Organomet. Chem. 2013, 723,
98. For Co , see: f) P. Sehnal, I. G. Stará, D. Saman, M. Tichý,
I
ˇ
J. Mísˇek, J. Cvacˇka, L. Rulísˇek, J. Chocholousˇová, J. Vacek, G.
Goryl, M. Szymonski, I. Císarˇová, I. Starý, Proc. Natl. Acad.
Sci. USA 2009, 106, 13169; see also ref. 7e. For IrI, see: g) T.
Shibata, T. Uchiyama, Y. Yoshinami, S. Takayasu, K. Ta-
chikawa, K. Endo, Chem. Commun. 2012, 48, 1311.
The helicene syntheses by transition-metal-mediated double
[2+2+2] cycloaddition, see: a) S. Han, A. D. Bond, R. L. Disch,
D. Holmes, J. M. Schulman, S. J. Teat, K. P. C. Vollhardt, G. D.
Whitener, Angew. Chem. Int. Ed. 2002, 41, 3223; Angew. Chem.
2002, 114, 3357; b) S. Han, D. R. Anderson, A. D. Bond, H. V.
Chu, R. L. Disch, D. Holmes, J. M. Schulman, S. J. Teat,
[8]
[13]
[14]
[15]
K. P. C. Vollhardt, G. D. Whitener, Angew. Chem. Int. Ed.
ˇ
2002, 41, 3227; Angew. Chem. 2002, 114, 3361; c) M. Cízková,
ˇ
ˇ
D. Saman, D. Koval, V. Kasˇicˇka, B. Klepetárˇová, I. Císarˇová,
F. Teplý, Eur. J. Org. Chem. 2014, 5681; see also ref. 6e and ref.
7f.
[16]
[17]
[18]
[9]
For selected reviews that focus on transition-metal-catalyzed
enantioselective [2+2+2] cycloaddition of alkynes, see: a) Tran-
sition-Metal-Mediated Aromatic Ring Construction (Ed.: K.
Tanaka), Wiley, Hoboken, 2013, ch. 8–10; b) Y. Shibata, K.
Tanaka, Synthesis 2012, 44, 323; c) I. G. Stará, I. Starý, in Sci-
ence of Synthesis (Eds.: J. S. Siegel, Y. Tobe), Thieme, Stuttgart,
2010, vol. 45b, p. 885; d) K. Tanaka, Chem. Asian J. 2009, 4,
508; e) T. Shibata, K. Tsuchikama, Org. Biomol. Chem. 2008,
6, 1317; f) B. Heller, M. Hapke, Chem. Soc. Rev. 2007, 36, 1085;
g) K. Tanaka, Synlett 2007, 1977.
[10]
For recent examples on enantioselective helicene synthesis see:
a) K. Nakamura, S. Furumi, M. Takeuchi, T. Shibuya, K.
Tanaka, J. Am. Chem. Soc. 2014, 136, 5555; b) L. Kötzner,
Eur. J. Org. Chem. 2015, 1409–1414
© 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.eurjoc.org
1413

K. Tanaka et al.
SHORT COMMUNICATION
Terashima, Y. Haketa, H. Shibaguchi, T. Kawai, M. Naito, K.
Takaishi, M. Uchiyama, A. Muranaka, Chem. Eur. J. 2013, 19,
16263; e) K. Goto, R. Yamaguchi, S. Hiroto, H. Ueno, T. Ka-
wai, H. Shinokubo, Angew. Chem. Int. Ed. 2012, 51, 10333;
Angew. Chem. 2012, 124, 10479; f) J. Kumar, T. Nakashima,
H. Tsumatori, M. Mori, M. Naito, T. Kawai, Chem. Eur. J.
2013, 19, 14090; g) H. Maeda, Y. Bando, K. Shimomura, I.
Yamada, M. Naito, K. Nobusawa, H. Tsumatori, T. Kawai, J.
Am. Chem. Soc. 2011, 133, 9266; h) T. Kaseyama, S. Furumi,
X. Zhang, K. Tanaka, M. Takeuchi, Angew. Chem. Int. Ed.
2011, 50, 3684; Angew. Chem. 2011, 123, 3768; i) H. Tsumatori,
T. Nakashima, T. Kawai, Org. Lett. 2010, 12, 2362; see also
ref. 10a.
Received: December 3, 2014
Published Online: January 22, 2015
1414
www.eurjoc.org
© 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Eur. J. Org. Chem. 2015, 1409–1414
