molecules
Article
Isolation, Structure Determination, and Synthesis of
Cyclic Tetraglutamic Acids from Box Jellyfish Species
Alatina alata and Chironex yamaguchii
Justin Reinicke 1,2, Ryuju Kitatani 3, Shadi Sedghi Masoud 4, Kelly Kawabata Galbraith 1,5
Wesley Yoshida 6, Ayako Igarashi 3, Kazuo Nagasawa 4 , Gideon Berger 1,*,
,
Angel Yanagihara 7,
* *
, Hiroshi Nagai 3,* and F. David Horgen 1,
1
Department of Natural Sciences, Hawaii Pacific University, Kaneohe, HI 96744, USA;
reinicke@hawaii.edu (J.R.); kgalbraith2468@gmail.com (K.K.G.)
Daniel K. Inouye College of Pharmacy, University of Hawaii at Hilo, Hilo, HI 96720, USA
Department of Marine Sciences, Tokyo University of Marine Science and Technology, Tokyo 108-8477, Japan;
ryujukitatani@gmail.com (R.K.); igarashi.b.ayako.t@gmail.com (A.I.)
Department of Biotechnology and Life Science, Tokyo University of Agriculture and Technology, Tokyo
184-8588, Japan; shadi@m2.tuat.ac.jp (S.S.M.); knaga@cc.tuat.ac.jp (K.N.)
German Center for Neurodegenerative Diseases (DZNE), Sigmund-Freud-Str. 27, 53127 Bonn, Germany
Department of Chemistry, University of Hawaii at Manoa, Honolulu, HI 98622, USA; wyoshida@hawaii.edu
Békésy Laboratory of Neurobiology, Pacific Biosciences Research Center, School of Ocean and Earth Science
2
3
4
5
6
7
and Technology, and Department of Tropical Medicine, John A. Burns School of Medicine, University of
Hawaii at Manoa, Honolulu, HI 96822, USA
*
Correspondence: gberger@hpu.edu (G.B.); ayanagih@hawaii.edu (A.Y.); nagai@kaiyodai.ac.jp (H.N.);
dhorgen@hpu.edu (F.D.H.); Tel.: +1-808-236-3551 (G.B.); +1-808- 956-8328 (A.Y.); +81-3-5463-0454 (H.N.);
+1-808-236-5864 (F.D.H.)
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editor: Ryuichi Sakai
Received: 21 January 2020; Accepted: 10 February 2020; Published: 17 February 2020
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: Cubozoan nematocyst venoms contain known cytolytic and hemolytic proteins, but small
molecule components have not been previously reported from cubozoan venom. We screened
nematocyst extracts of Alatina alata and Chironex yamaguchii by LC-MS for the presence of small
molecule metabolites. Three isomeric compounds, cnidarins 4A (
from venom extracts and characterized by NMR and MS, which revealed their planar structure
as cyclic -linked tetraglutamic acids. The full configurational assignments were established by
syntheses of all six possible stereoisomers, comparison of spectral data and optical rotations, and
stereochemical analysis of derivatized degradation products. Compounds were subsequently
detected by LC-MS in tissues of eight other cnidarian species. The most abundant of these compounds,
cnidarin 4A ( ), showed no mammalian cell toxicity or hemolytic activity, which may suggest a role
1), 4B (2), and 4C (3), were isolated
γ
1–3
1
for these cyclic tetraglutamates in nematocyst discharge.
Keywords: cubozoa; cnidarian; cnidarin; cyclicpeptide; polyglutamic acid; venom
1. Introduction
Background
Jellyfish, sea anemones, hydrozoans, and corals comprise the phylum Cnidaria. The phylum
is defined by the presence of stinging cells, cnidocytes, which contain a singular large subcellular
collagen-walled organelle, the cnidae, capable of rapid discharge of a hollow eversible tubule. Penetrant
cnidae are called nematocysts, which store venom that is injected into prey upon discharge through
the tubule. Both physical and chemical stimuli trigger nematocyst discharge.
Molecules 2020, 25, 883; doi:10.3390/molecules25040883
www.mdpi.com/journal/molecules

Molecules 2020, 25, 883
2 of 21
Cnidarians in the class Cubozoa, or box jellyfish, include about 50 described species [
1] that can
cause harm and even death to humans upon envenomation. For example, Chironex fleckeri has caused
more than 67 cardiac/respiratory related human fatalities [ ]. In general, envenomation symptoms
2–5
from cubozoans range from immediate localized pain and swelling, to deferred systemic responses,
such as Irukandji syndrome, which is characterized by delayed symptoms including nausea, vomiting,
headaches, muscle pain, pulmonary edema, hypertension and cardiac failure [6–9]. Chironex yamaguchii,
known as the Habu-kurage in Japan, is closely related to Chironex fleckeri [10] and also has confirmed
human fatalities associated with its sting. However, the majority of C. yamaguchii stings are not fatal [11].
The Hawaiian Box Jellyfish, Alatina alata [1,12] causes stings that are typically characterized by localized
pain and welts [ 13]. However, there have also been cases of systemic Irukandji sequelae associated
9,
with Alatina alata stings. Yoshimoto and Yanagihara retrospectively identified symptoms consistent
with systemic Irukandji symptoms in 5% of patients [14]. The mechanisms of venom induced Irukandji
systemic symptoms are not clearly understood but have been found to involve induction of “cytokine
storm” and “catecholamine surge” events comparable to sepsis [7–9].
The major reported toxins isolated from cubozoan venom are proteins that demonstrate hemolytic
and cytolytic activity [15
revealed a more complex composition of venom protein families [20
cardiovascular collapse appears to be the common biological outcome, but the mechanisms of toxicity
may be complex and vary among cubozoa species [ 19 23 28]. Controversy exists as to whether
cytolytic proteins, porins, may be solely responsible for cardiovascular collapse and systemic effects
observed in humans [ 19 23 27 29]. Further complicating analysis of the published literature is the
–
19], and some are allergenic [11]. Recent proteomic approaches have
–
22]. For species lethal to humans,
3
, , –
3, , – ,
vast differences in reported specific activity of “venom” and the methodologies by which “venom”
is prepared.
Some groups of cnidarians, especially members of Anthozoa (corals and anemones), are rich
sources of bioactive secondary metabolites that putatively serve in defense and communication, and
have potential societal benefits such as potential as therapeutic drugs [30]. However, few small
molecules have been reported from scyphozoans (true jellyfish), and none from cubozoans [31]. At the
same time, there is evidence for small molecules in some cnidarian venoms. Lindquist reported
tridentatols, alkylthio tyramine derivatives, from the hydroid Tridentata marginata [32]. This suggests
the potential of small molecules in other cnidarian venom, including box jellyfish venom.
In this study, Hawaiian box jellyfish, Alatina alata, and Japanese box jellyfish, Chironex yamaguchi
(Habu-kurage), were selected as model species to expand the known chemical space of venom
constituents by screening for small molecules. Venom extracts from both A. alata and C. yamaguchi
yielded cnidarin 4A (
and stereoisomers cnidarins 4B (
C. yamaguchii (Figure 1). The structures of
synthesis, and analysis of chemical degradation products. Cnidarins 4A (
products, while cnidarin 4C ( ) has been synthesized previously but is reported here for the first time
1
), 2.1,5.4-anhydro(
γ
-d-glutamyl-
), (dlll and llll analogs, respectively) were isolated from
were determined by spectroscopic analyses, chemical
) and 4B ( ) are novel natural
γ-d-glutamyl-γ-l-glutamyl- l-glutamic acid),
2) and 4C (
3
1–3
1
2
3
from nature. To our knowledge, these are the first small molecules isolated and fully characterized
from Cubozoa.

Molecules 2020, 25, 883
3 of 21
Figure 1. Structure of naturally occurring cyclic tetra-γ-glutamic acids 1–3 and synthetic analogues 4–6.
2. Results
2.1. Alatina alata Venom
Alatina alata specimens were collected on Waikiki Beach (Oahu, Hawaii). After gentle removal
of nematocysts from excised tentacles, nematocysts were disrupted and venom was collected from
supernatant after centrifugation (details provided in Sections 4.2.1 and 4.3.1). LC-MS screening of the
venom extracts (Figure S1, Rt 18.6 min) consistently showed a constituent demonstrating a protonated
+
molecular ion at m/z 517.1765, which supported a molecular formula of C20H28N4O12 (C20H29N4O12
requires m/z 517.1783, ∆ −1.8 mmu) and indicating 9 degrees of unsaturation. The peak was collected
by analytical LC guided by MS, and the 1H-NMR of the resulting enriched sample of cnidarin 4A (
1)
showed signals consistent with the presence of glutamic acid residues, while the molecular formula
matched a tetraglutamate with one additional degree of unsaturation. A detailed NMR study (HSQC,
HMBC, NOESY, and 1-D TOCSY) confirmed the presence of glutamic acid residues, while NOESY
correlations between NH and
The data suggested cnidarin 4A (1) was a cyclic γ-linked tetraglutamate.
Following further purification of cnidarin 4A ( ) (Figure S2, Rt 9.4 min), the configuration of
the glutamic acid residues in was determined by the advanced Marfey’s analysis following acid
hydrolysis. The resulting derivatized glutamate residues were quantitated by both UV and MS/MS,
γ-protons (and lack of NH to α-protons) was evidence of all γ-linkages.
1
1
and showing that cnidarin 4A (
and Figures S4 and S5).
1) contains a 1:1 ratio of d-glutamic acid:l-glutamic acid (see Table S1
Taken together, the data suggested that the isolated compound was a cyclic tetrapeptide of
glutamic acids with a 1:1 ratio of d/l and all -linked. Only two possible cyclic tetra- -glutamates
γ
γ
meet this criteria, having a configuration sequence of either ddll or dldl. In order to determine the
structure and obtain additional amounts of the scarce natural product for biological testing, both
compounds, 2.1,5.4-anhydro(
) and 2.1,5.4-anhydro( -d-glutamyl-
), were synthesized. The syntheses were performed similar to methods described by Munekata
and coworkers [33] and Hollosi and Kajtar [34] who coincidently synthesized the cyclic tetrapeptide
with -linkage containing all l-glutamic acid residues, designated below as cnidarin 4C ( ). For the
ddll-cyclotetra- -glutamic acid, cnidarin 4A ( ), Boc-d-glutamic acid 1-benzyl ester ( ) was converted
γ
-d-glutamyl-
γ
-d-glutamyl-γ-l-glutamyl-l-glutamic acid) (cnidarin 4A,
1
γ
γ
-l-glutamyl-
γ
-d-glutamyl-l-glutamic acid) (iso-cnidarin 4A,
4
γ
3
γ
1
5
to the N-hydroxysuccinimide (NHS) ester and then coupled with d-glutamic acid 1-benzyl ester in
dichloromethane with triethylamine, to provide protected dipeptide 6 (Scheme 1).

Molecules 2020, 25, 883
4 of 21
Scheme 1. Preparation synthetic cnidarin 4A (1).
This process of NHS acyl activation, followed by coupling, was repeated two more times, using the
protected l-glutamate, with comparable yields, to give the linear tetrapeptide 8. Trifluoroacetic
acid (TFA) was used to remove the tert-butoxycarbonyl (Boc) protecting group, providing the
free ammonium trifluoroacetate, primed for cyclization. Macrocyclization was achieved using
a carbodiimide to yield 9 in adequate yield. Benzyl deprotection of the alpha carboxylic acids
was accomplished using standard catalytic hydrogenation conditions to provide crude cnidarin
4A (
-d-glutamyl-
overall yield). The synthesis of the dldl-cyclotetra-
performed via the same approach (see Supplemental Information).
1H-NMR of the venom isolate cnidarin 4A (
) showed evidence of 2 sets of glutamate signals that
matched that of synthetic product 2.1,5.4-anhydro( -d-glutamyl- -d-glutamyl- -l-glutamyl-l-glutamic
acid) (cnidarin 4A, ), but differed significantly from iso-cnidarin 4A ( ) (Figure 2). To confirm, the
tetramethyl esters of isolated and synthesized were prepared by Fischer esterification in methanol,
catalyzed by Amberlyst-15. The 13C-NMR spectra of both resulting tetramethyl esters showed the
1
). The crude product was purified by reverse phase HPLC to provide 2.1,5.4-anhydro
-d-glutamyl- -l-glutamyl-l-glutamic acid), cnidarin 4A ( ), in nine steps (18.5%
-glutamate isomer, iso-cnidarin 4A ( ), was
(γ
γ
γ
1
γ
4
1
γ
γ
γ
1
4
1
1
expected 12 carbons signals with nearly identical chemical shifts (Table 1). Thus, 1 was unambiguously
identified as the all γ-linked cyclic tetraglutamate with a ddll configuration.

Molecules 2020, 25, 883
5 of 21
Figure 2. 1H-NMR of cnidarin 4A (
(300 MHz; 1 in D2O/100 mM deuterated formic acid and 4 in D2O).
1) vs. synthetic samples of cnidarin 4A (1) and iso-cnidarin 4A (4)
Table 1. 13C-NMR of tetramethyl esters of 1 isolated from A. alata venom and synthesized.
δC
Isolated 1 Tetramethyl Ester
Synthetic 1 Tetramethyl Ester
25.83
26.63
30.73
31.42
50.09
51.38
51.94
51.98
170.69
172.19
172.56
172.82
25.81
26.61
30.69
31.38
50.07
51.36
51.91
51.96
170.65
172.17
172.55
172.81
2.2. Chironex Yamaguchii Venom
The venom of Chironex yamaguchii was similarly screened for secondary metabolites. Cnidarin 4A
(
1
) and two additional isomers were isolated from nematocyst extracts. The peptides were isolated
guided by LC-MS monitoring [M + H]+ m/z 517 (or [M
−
H]− m/z 515), as cnidarin 4A (
1
), cnidarin
4B (
2), and cnidarin 4C (
3
), in order of HPLC elution (Figure 3). As in Alatina alata, cnidarin 4A (1)
was the major cyclic tetraglutamate. Cnidarins 4B (
2
) and 4C (3) also have a molecular formula of
C20H28N4O12 (cnidarin 4B (
2
): [M + H]+ at m/z 517.1780, ∆ −0.3 mmu; cnidarin 4C (
3
): [M + H]+ at m/z
517.1775 ∆ −0.8 mmu).

Molecules 2020, 25, 883
6 of 21
Figure 3. Reversed phased HPLC chromatogram of Chironex yamaguchii nematocyst extracts using
Develosil C30 column. Cnidarin 4A (1), 4B (2), and 4C (3) peaks are indicated. Detection is by UV.
The 1H-NMR spectra of cnidarins 4A (
structure elucidation of cnidarin 4B ( ) and 4C (
the possible stereoisomers (1–6) that were synthesized in this study.
The high degree of symmetry in the llll-cyclotetra- -glutamic acid (
synthetic strategy (Scheme 2). l-Glutamic acid 5-benzyl ester 10 was reacted with Boc-l-glutamic acid
11) to give protected ll-glutamylglutamic acid (12). The ll-glutamylglutamic acid derivatives 13 and
14 were synthesized from 12 by deprotection of the benzyl group and selective deprotection of the Boc,
respectively. Compound 13 was reacted with 14 to give the protected linear llll-tetra- -glutamic acid
15. Deprotection of Boc and the benzyl group was followed by macrocyclization using MNBA/DMAP.
Finally, TFA was used to remove the tert-butyl protecting group, providing cnidarin 4C ( ) in nine steps
(18.5% overall yield/LLS). The dddd-configured enantiomer, ent-cnidarin 4C ( ), was similarly prepared.
1), 4B (2), and 4C (3) showed close similarity. The complete
2
3
) was accomplished by the comparison with all six of
γ
3) lent itself to a second
(
γ
3
6
Scheme 2. Preparation cnidarin 4C (3).

Molecules 2020, 25, 883
7 of 21
1
The H and 13C-NMR spectra of authentic cnidarian 4C (
3) were identical with those of the
synthesized llll- and dddd-configured cyclotetra-γ-glutamic acids (3 and 6, respectively). The optical
rotation of these compounds was small and difficult to compare with the natural product given its
scarcity. Therefore, the Marfey analysis was used to determine the configuration of glutamic acid
residues in cnidarin 4C (
detected indicating that cnidarin 4C (3) is the llll-configured cyclic tetra-γ-glutamic acid.
In order to elucidate the absolute structure of cnidarin 4B ( ), the synthesis of the remaining 2
stereoisomers, the lddd- and dlll-configured enantiomers ( and , respectively), was performed
3). Following hydrolysis of the natural product, only l-glutamic acid was
2
2
5
using the same approach as for synthesis of the llll- and dddd-enantiomeric pair,
3 and 6 (see
1
Supplemental Information Section S1). The H and 13C-NMR spectra of authentic cnidarin 4B (
2
)
matched with those of the synthesized lddd- and dlll-configured cyclotetra-
natural cnidarin 4B ( ) and the synthesized dlll isomer showed dextrorotatory optical rotation
[cnidarin 4B (
), [α]2D4 + 30◦ (c 0.009, CH3OH); synthesized dlll isomer, [α]D24 + 7.5◦ (c 0.022, CH3OH)],
while synthesized lddd-configured ent-cnidarin 4B (
) showed levorotatory optical rotation, [α]2D4 17◦
) was assigned as the dlll-configured
γ-glutamic acids. Both
2
2
5
−
(c 0.022, CH3OH). Consequently, the structure of cnidarin 4B (
2
cyclotetra-γ-glutamic acid.
The 1H and 13C-NMR assignments for compounds 1–3 are shown in Tables 2–4, respectively.
Table 2. 1H-NMR (800 MHz) and 13C-NMR (200 MHz) for cnidarin 4A (1) in CD3OD.
Position
Glu-1 a
COOH
α
13C-NMR (ppm)
1H-NMR (ppm)
Mult.
J (Hz)
177.4
54.5
-
4.37
dd
2.4, 6.6
Hα 1.89
Hβ 2.35
m
m
β
28.7
γ
33.8
2H 2.41
m
C=O
Glu-2 a
COOH
α
174.8
177.8
55.3
-
4.27
dd
2.4, 6.6
Hα 2.01
Hβ 2.13
m
m
β
29.6
Hα 2.31
Hβ 2.38
m
m
γ
33.0
C=O
175.4
a
The positions of Glu-1 and Glu-2 were not determined.
2.3. Tissue Distribution of Cnidarins
To determine whether cnidarin 4A (1) and related isomers, occurred in the nematocyst only or also
in adjacent tissues, Alatina alata tentacle extract, free of nematocysts, was analyzed by LC-MS. Neither
cnidarin 4A (
) nor its isomers were detected by LC-MS (Figure S7), indicating that the cnidarin 40s
only occur in the nematocysts. LC-MS quantification of cnidarin 4A ( ) in Alatina alata venom showed
a concentration in extracted nematocyst venom of 5.7 µg/mL (±0.2, 4% CV).
1
1

Molecules 2020, 25, 883
8 of 21
Table 3. 1H-NMR (800 MHz) and 13C-NMR (200 MHz) for cnidarin 4B (2) in CD3OD.
Position
13C-NMR (ppm)
1H-NMR (ppm)
Mult.
J (Hz)
Glu-1 a
COOH
α
176.42 b
54.15
-
4.37
m
Hα 1.94
Hβ 2.35
m
m
β
γ
28.71
Hα 1.94
Hβ 2.35
m
m
33.8
C=O
Glu-2 a
COOH
α
174.8
176.43 b
54.38
-
4.34
m
Hα 2.02
Hβ 2.22
m
m
β
γ
28.27
Hα 2.36
Hβ 2.46
m
m
32.87
175.3
C=O
Glu-3 a
COOH
α
176.65 c
54.8
-
4.32
m
Hα 2.06
Hβ 2.16
m
m
β
γ
29.11
Hα 2.36
Hα 2.41
m
m
33.71
C=O
Glu-4a
COOH
α
175.07
176.66 c
54.38
-
4.33
m
Hα 2.02
Hβ 2.16
m
m
β
28.81
γ
33.81
2H 2.41
m
C=O
175.24
a
b,c
The positions of Glu-1, Glu-2, Glu-3, and Glu-4 were not determined.
Signals assigned may be interchanged.
Table 4. 1H-NMR (800 MHz) and 13C-NMR (200 MHz) for cnidarin 4C (3) in CD3OD.
Position
COOH
α
13C-NMR (ppm)
1H-NMR (ppm)
Mult.
J (Hz)
175.6
53.3
-
4.41
dd
1.4, 6.5
Hα 1.99
Hβ 2.31
m
m
β
28.2
γ
32.8
2H 2.41
m
C=O
175.0

Molecules 2020, 25, 883
9 of 21
2.4. Marine Animals Screened for Cnidarin 4A-C (1–3)
Seventeen marine animal species, including species from Cnidaria, Ctenophora, Annelida,
Mollusca, Echinodermata, Arthropoda, and Chordata, were screened for cnidarin 4A–C ( ) by
LC-MS. Compounds were detected in whole bodies or tentacles of all 9 cnidarians examined
1–3
1–3
(including C. yamaguchii). However, none were detected in the 8 non-cnidarian species. These results
suggest cnidarins 4A–C (1–3) are specific to cnidarians.
2.5. Cytotoxicity and Hemolytic Activity
The cytotoxicity of cnidarin 4A (
embryonic kidney) cells. The compounds showed no significant toxicity at concentrations as high as
100 M (Figure S9). This data suggests that cnidarin 4A ( ) and iso-cnidarin 4A ( ) are not directly toxic
to human cells. The ability of cnidarin 4A ( ) to lyse red blood cells was also measured at concentrations
1) and iso-cnidarin 4A (4) was evaluated in HEK-293 (human
µ
1
4
1
as high as 121 µM, but compound 1 had no effect on cell lysis.
3. Discussion
In this study, we isolated and identified three cyclotetra-γ-glutamic acids, cnidarins 4A–C
(
1
–
3
), from cubozoan nematocyst venom and determined that the compounds are distributed across
numerous cnidarian taxa, while absent from animals in six other phyla. Structural analyses indicated
that compounds have all -linkage, and and contain D-glutamic acid residues. The full structural
assignments were made by spectral, optical rotation, and degradation/configurational analyses in
comparison with synthetic isomers . Compounds represent the first fully characterized small
molecules reported from A. alata and C. yamaguchii. In fact, to our knowledge, are the first
1–
3
γ
1
2
1–6
1–3
1–3
characterized small molecules reported from the class Cubozoa. Interestingly, ctenophores were
formerly grouped with cnidarians in the phylum Coelenterata, but increasing awareness of their
differences resulted in their placement in a separate phylum. In this study, cnidarin 4A–C (1–3) were
not detected in the Ctenophora Bolinopsis mikado but were detected in all cnidarian species tested,
providing chemotaxonomic evidence that supports the re-classification of ctenophores separate from
the cnidarians.
Although new in nature, the synthesis of compound
3
has been described previously [33
,34] and
was reported to be non-toxic in rats [33]. Cnidarins 4A–C (
1–
3
) are closely related to poly- -glutamates
γ
(consisting of 10–50 glutamic acid residues) that have been reported as a major component of
nematocysts in cnidarians [35 36] and are biosynthesized in nematocysts [37]. The resulting osmotic
pressure of the polyanions contributes to the driving force behind the discharge of nematocysts [35 38 39].
Interestingly, poly- -glutamates are produced rarely by eukaryotes, and almost exclusively by
Gram-positive bacteria (especially Bacillus species). Poly- -glutamates are non-toxic, non-immunogenic,
,
,
,
γ
γ
and even edible, with numerous commercial applications including as food additives, drug carriers,
cryoprotectants, and wastewater flocculants.
This investigation did not elucidate a biological role for compounds
cyclotetraglutamic acids and , however, are not toxic to human cells in culture, and compound
showed no ability to cause hemolysis of red blood cells. The lack of cytotoxicity and hemolytic activity
observed from compound does not preclude a role in the bioactivity of the venom. However, it is
quite possible that compounds contribute to the nematocyst discharge and the lack of biological
effects in our assays is consistent with such a role. Clearly, the wide distribution in Cnidaria suggest
compounds play some important role in nematocyst function or venom toxicity. Further studies
will be required to determine the functional role of the cnidarin 40s.
1
–
3.
Synthetic
1
4
1
1
1–3
1–3

Molecules 2020, 25, 883
10 of 21
4. Materials and Methods
4.1. General Experimantal Procedures
LC-MS and MS were performed using either (a) an Agilent MSD-TOF time of flight (TOF) analyzer,
(b) a Bruker micrOTOF QII mass spectrometer, or (c) a Thermo Finnigan LCQ Deca XP Max ion trap
mass spectrometer with evaporative light scattering (ELSD, Sedex 75, Sedere, Alfortville, France) and
photo diode array (PDA, Surveyor, Thermo Finnigan, San Jose, CA, USA) detectors, or (d) a JEOL
JMS-T100LC spectrometer.
HPLC analyses and separations were performed using either a SHIMADZU HPLC system
equipped with a SPD-M10A diode array detector or an Agilent 1100 binary preparative system
equipped with a fraction collector (FC) and multi-wavelength UV detector.
NMR experiments were performed on either (a) a Varian Unity INOVA 500 spectrometer using 3
mm tubes or a Protasis capillary probe, (b) a Varian Mercury Plus 300 MHz spectrometer using 3 and
5 mm tubes, (c) Bruker AVANCE III 800 MHz and 600 MHz spectrometers, or (d) JEOL AL300 and
ECX 400 instruments. The spectra are referenced internally according to the residual solvent signals of
CDCl3 (δH 7.26 ppm; δC 77.0 ppm), D2O (δH 4.79 ppm; 1,4-dioxane was added as internal standard for
13C-NMR, δC 67.2 ppm), CD3OD (δH 4.87 ppm), and d6-DMSO (methyl carbons δC 39.51 ppm).
Optical rotations were measured on a JASCO P-2100 or P-2200 polarimeters. Infrared spectra
were obtained with the use of NaCl and AgCl plates on a Perkin Elmer Spectrum RX I FT-IR. Flash
chromatography was carried out on silica gel (Silicycle, SiliaFlash P60, 230 400 mesh, or Kanto
−
silica gel 60 spherical, particle size 0.040–0.100 mm). Silica thin layer chromatography (TLC) plates
(Sigma-Aldrich, St. Louis, MO, USA) were used to visualize reaction products, either under a UV lamp
(254 nm) or with para -anisaldehyde stain.
Starting materials H-Glu-OtBu
(Watanabe Chem. Ind., Ltd., Hiroshima, Japan).
·
HCl and H-d-Glu-OtBu HCl were obtained commercially
·
4.2. Species Sample Collection
4.2.1. Alatina alata
Specimens were collected at Waikiki Beach (Oahu, HI, USA) 8–10 days after the full moon from
2007–2011. Organisms were collected immediately after beaching using metal tongs, and tentacles
were immediately excised from the animals, transferred in to 1 M trisodium citrate solution (1 volume
tentacle:4 volumes 1 M trisodium citrate) and transported to the lab. Specimens were identified by A.Y.
4.2.2. Chironex yamaguchii
Specimens were collected at Irijima, Urasoe, Okinawa in August from 2006–2015. The samples
were identified by Professor S. Kubota, Faculty of Science, Kyoto University. Tentacles were excised
from the samples at the site immediately after collection, kept in the cold seawater and stored at
30 ◦C
−
until treatment. The voucher specimens for identification were deposited at the Okinawa Prefectural
Institute of Health and Environment.
4.3. Venom Extraction and Preparation
4.3.1. Alatina alata
The buffered tentacles solution was gently rocked at 4 ◦C for 3–6 weeks to separate the nematocyst
from tentacle tissue with a 90% nematocyst recovery. Sieved (0.5-mm mesh) nematocyst solutions were
centrifuged at 400
citrate at 1:20 (vol:vol) and washed twice at 250
ice-cold deionized water to a slurry and transferred to a pre-chilled French Press 20 K pressure cell
(SLM-AMINCO Cat# FA078) and subjected to 12,000 psi for 10–15 min. The lysate (total venom) was
×
g for 20 min. Undischarged nematocyst pellets were resuspended in chilled 1 M
g for 20 min, then gently diluted 1:0.5 (vol:vol) with
×

Molecules 2020, 25, 883
11 of 21
expelled at 30 drops/min and recycled 2–4 times to achieve 90% nematocyst rupture, then centrifuged at
12,000
g at 4 ◦C for 5 min to remove structural capsule wall and tubule debris. The viscous upper layer,
lysate (venom) was removed, leaving the solid debris pellet, aliquoted, snap frozen in N2(l) and stored
at
80 ◦C. Protein concentrations were determined using a Bradford protein assay (Bio-Rad Protein
×
−
Assay). Size-exclusion chromatography (SEC) was performed using a BioSilect 125-5 column (BioRad
125-0060 with BioRad 125-0072, Hercules, CA, USA) equilibrated with sodium phosphate buffer
(50 mM Na2HPO4, 50 mM NaH2PO4, 150 mM NaCl, pH 6.8) at a rate of 0.5 mL/min using an AKTA
Purifier high-pressure liquid chromatography (HPLC) system (GE Biosciences). Protein-free fractions
(mw < 2000) of the extract were screened by LC-MS for small molecule components (Section 4.4.1).
Prior to analysis of tentacles, tentacles were examined microscopically and found to be devoid of
nematocysts after incubation for weeks in 1 M citrate at 4 ◦C, allowing nematocyst sloughing. Tentacles
were then freeze dried for solvent extraction and analysis by LC-MS to check for the presence of
cnidarins 4A–C (1–3).
4.3.2. Chironex yamaguchii
The tissue of the entire tentacles was used to isolate the nematocysts from C. yamaguchii.
The tentacles used for experiments were excised from frozen tentacles. A string of tentacle was
shaken vigorously for 5 min in 20 mL 1 M NaCl solution to isolate the nematocyst. NaCl solutions
containing nematocyst (nematocyst suspension) were weakly centrifuged (100 rpm) and the isolated
nematocysts were obtained as the pellet. The tentacles that were separated from nematocysts were
used as the nematocyst free tentacles. The isolated nematocysts and nematocyst free tentacles were
sonicated in distilled water. After centrifugation (12,000
and analyzed by LC-MS.
×
g, 30 min), each supernatant was removed
4.4. Isolation of Compounds
4.4.1. Isolation of Cnidarin 4A (1) from Alatina alata
Venom extract SEC fractions from Alatina alata were fractionated in multiple batches using HPLC
(Waters Atlantis dC18, 10 250 mm, 10 m particle size; mobile phase A: water/formic acid (1000:1);
×
µ
mobile phase B: acetonitrile/formic acid (1000:1); gradient typically: 0% B, 0–12 min, 0–50% B, 12–30 min,
50–100% B, 30–35 min, 100% B, 35–40 min). A single chromatographic peak (Rt 18.6 min, 0.2 mg)
containing cnidarin 4A (
1
) as the major component along with 2 isomers was analysed by LC-MS and
+
NMR. The crude cnidarin 4A (1
) sample showed a [M + H]+ peak at m/z 517.1765 (C20H29N4O12
requires 517.1783, ∆ −1.8 mmu), consistent with the molecular formula C20H28N4O12, which requires
9 degrees of unsaturation (Figure S6). Capillary 1H-NMR (500 MHz, Protasis CapNMR, D2O/H2O)
conducted on the initial HPLC runs showed signals consistent with a polyglutamic acid (Figure S3).
Further 1H-NMR experiments (500 MHz, 3 mm probe, D2O/H2O: gHSQC (JCH = 140 Hz, relaxation
delay 0.8 s); gHMBC (JCH = 140 Hz, nJCH = 7 Hz, relaxation delay 0.8 s); gTOCSY (relaxation delay
1 s, spinlock mixing time 20–80 ms); gNOESY (relaxation delay 1 s, cross-relaxation delay 500 ms)
confirmed signals consistent with a polyglutamic acid, while NOESY experiments showed cross peaks
only between NH protons and
while the degrees of unsaturation required a cyclic structure.
Cnidarin 4A ( ) was further purified and separated from isomers by diluting venom 1:9 with 1%
formic acid in water prior to injection and adjusting the initial mobile phase to 2.5% B (versus 0% B)
The diluted solution was filtered through a 0.45 m filter and fractionated by semi-preparative HPLC
(Waters Atlantis dC18, 10 250 mm, 10 m particles size, mobile phase A: water/formic acid (1000:1);
γ-hydrogens indicating all γ-linkages between glutamic acid residues,
1
µ
×
µ
mobile phase B: acetonitrile/formic acid (1000:1); gradient: 2.5% B, 0–7 min, 2.5–40% B, 7–24 min,
40–100% B, 24–30 min, 100% B 30–35 min). Compound 1 eluted at collected at 12–16 min.
Analyses of fractions were carried out by low resolution LC-MS using a Waters Atlantis dC18
(3
×
250 mm, 5 µm particle size) column (mobile phase A: water/formic acid (1000:1); mobile phase

Molecules 2020, 25, 883
12 of 21
B: acetonitrile/formic acid (1000:1); gradient: 2.5% B, 0–7 min, 2.5–100% B, 7–27 min, 100% B, 27–35).
Compound 1 was isolated as a white solid with a mass of 6.6 mg.
4.4.2. Cnidarin 4A, 4B, and 4C (1–3) Isolation from Chironex Yamaguchii
Isolated nematocysts were extracted with distilled water by sonication with USP-400A (Shimadzu,
Kyoto, Japan). The extract was centrifuged (12,000
by HPLC (SCL-10A VP, LC-10ADVP, DGU-12A, Shimadzu, Kyoto, Japan) using a reversed phase
column (Develosil C30, 10 250 mm, Nomura Chemical, Aichi, Japan) at a flow rate of 2 mL/min (mobile
×
g, 30 min) and the supernatant was further purified
×
phase A: aqueous 50 mM HCOOH, 2 mM HCOONH4; mobile phase B: 5% water/95% acetonitrile
with 50 mM HCOOH, 2 mM HCOONH4; gradient: 0–45 min, 0% B, 45–65 min, 0–5% B, 65–130 min,
5% B). Detection was by diode array, SPD-M10A VP (Shimadzu, Kyoto, Japan). The eluted peaks
were collected and subject to LC-MS (positive mode). Three m/z 517 compounds were isolated and
designated cnidarins 4A (1), 4B (2), and 4C (3) in order of elution (Figure 3).
4.5. Compound Characterization from Alatina alata
4.5.1. Accurate Mass Determination and Routine LC-MS Analyses
Accurate mass measurements of crude cnidarin 4A, compound 1, synthetic 1 and 2 and the synthetic
intermediates were collected by LC-MS-TOF. Analyses of all samples and synthetic intermediates were
performed by a low-resolution LC-MS system configured for fractionation using a 9:1 splitter with the
low flow going to the ELSD and the high flow going to the PDA and MS detectors. A Waters Atlantis
dC18 (3
0.1% formic acid).
×
250 mm, 5 µm) column was used typically with a gradient of water and acetonitrile (with
4.5.2. NMR of Crude Cnidarin 4A (1)
Initial NMR was performed on crude cnidarin 4A (1) due to the scarcity of sample. Capillary
NMR (Protasis NMRCap) was conducted with a mixture of D2O/H2O, as solvent to slow the exchange
of NH protons. These experiments showed the presence of glutamate signals. Larger quantities
of crude cnidarin 4A (1) were accumulated and analyzed in a 3 mm tube for 2D NMR [D2O/H2O:
gHSQC (JCH = 140 Hz, relaxation delay 0.8 s); gHMBC (JCH = 140 Hz, nJCH = 7 Hz, relaxation delay
0.8 s); gTOCSY (relaxation delay 1 s, spinlock mixing time 20–80 ms); gNOESY (relaxation delay 1 s,
cross-relaxation delay 500 ms)].
4.5.3. Preparation of Methyl Esters of Cnidarin 4A (1)
Fischer esterification was performed on isolated and synthesized compound
synthetic (2.1 mg) and isolated (2.9 mg) were dried and reconstituted in methanol (5 mL), and
Amberlyst 15 Ion Exchange Resin (0.4 mg and 0.6 mg, respectively) was added to the solution. Reactions
were filtered through celite (rinsing 5 with methanol) and then a 0.45 m PTFE filter. The solvent
1. Samples of
1
1
×
µ
of the combined washings was then removed in vacuo. This material was further purified by flash
chromatography on silica gel (20% methanol in dichloromethane). The resulting methyl esters of
isolated and synthetic compound 1 were subject to 13C-NMR (Table 1).
4.5.4. Configurational Analysis of Compound 1 Using the Advanced Marfey’s Method
The configuration of glutamic acid residues was determined for crude and isolated cnidarin 4A
(1) by the advanced Marfey’s analysis. Residual amounts of the crude cnidarin 4A (1) and 22 µg of
l-glutamic acid, separately, were hydrolyzed in 6 M HCl (0.2 mL, 110 ◦C, 18 h), dried under a stream of
N2(g), and repeatedly reconstituted with water and redried under N2(g). The respective hydrolysates
were reconstituted in methanol/water 1:9 and eluted from a C18 SPE column (100 mg/mL). Solvent was
evaporated under a stream of N2(g). The hydrolysates were reconstituted in 40
µL of water and 40 µL
of 1 M NaHCO3 solution, followed by the addition of 40 L of l-FDLA in acetone (1% w/v solution).
µ

Molecules 2020, 25, 883
13 of 21
The mixture was heated for 3 min at 80 ◦C, and then acidified with 80
µL of 6 M HCl and diluted with
250
The samples were analyzed by LC-MS method below.
The configuration of cnidarin 4A ( ) was assessed again once isolated. A portion (100
compound and two 50 g portions of l-glutamic acid were separately hydrolyzed in 6 M HCl (0.2 mL,
µL of acetonitrile. l-Glutamic acid standard was also reacted with dl-FDLA in the same manner.
1
µg) of
1
µ
110 ◦C, 18 h), dried under a stream of N2(g), and repeatedly reconstituted with water and redried
under N2(g). The separate dried hydrolysates were reconstituted in methanol/water 1:9 and eluted
from a C18 SPE column (100 mg/mL). Solvent was evaporated under a stream of N2(g). The dried
hydrolysates were reconstituted in 40
addition of 50
L of l-FDLA in acetone (2% w/v solution). The mixture was heated for 3 min at 80 ◦C,
and then acidified with 100
standard was also reacted with dl-FDLA.
The Marfey products for the crude and pure cnidarin 4A (
µL of water and 50 µL of 1 M NaHCO3 solution, followed by the
µ
µL of 2 M HCl and diluted with 250
µL of acetonitrile. l-glutamic acid
1
) hydrolysates were analyzed in
comparison with standard derivatives by LC-MS on a Phenomenex Luna C18(2) (2.0
×
250 mm, 3 µm
particle size) column (mobile phase A: water/formic acid (1000:1); mobile phase B: acetonitrile/formic
acid (1000:1); gradient: 0–80% B, 0–30 min, 80% B, 30–35 min). Extracted ion chromatograms for
corresponding derivative ions (protonated glutamic acid-FDLA monomer and dimer ions, m/z 442 and
883, respectively) were plotted and retention times compared to standards.
4.5.5. Quantitation of Compound 1 in Alatina alata Nematocyst and Tentacles
Compound
250 mm, 5
acetonitrile/formic acid (1000:1); gradient: 2.5% B, 0–7 min, 2.5–100% B, 7–27 min, 100% B, 27–35 min),
using synthetic as a standard. The standard was dissolved in 0.5% aqueous formic acid and diluted
1
in Alatina alata venom was quantified by LC-MS on a Waters Atlantis dC18
(3
×
µm particle size) column (mobile phase A: water/formic acid (1000:1); mobile phase B:
1
in a semi-log fashion. Venom samples were prepared by diluting crude venom 1:1 with 1% aqueous
formic acid to make a final concentration of 0.5% formic acid. Injection volumes were controlled by
overfilling a 9.2 µL injection loop. MS/MS data was collected by fragmenting the protonated molecular
ion m/z 517 and integrating the resulting MS/MS total ion chromatogram peaks were integrated using
the automated selection of area under the curve in the instrument software (Qual Browser, Thermo
Finnigan) with visual checked for consistency. Data for serial dilutions of the standard were collected
in triplicates, and a concentration curve (Figure S8) was prepared by plotting ion counts vs. mass of
the injected standard. A best-fit line was determined by linear regression. The venom sample was run
in triplicate, and the compound
based on the concentration curve.
Tentacle extraction, without nematocysts, was performed with 1.4 mg of freeze-dried tentacle
material that was ground and suspended in 500 L of water, which was then diluted to 1000 L using
1 peak (9.5 min) was integrated and concentrations were calculated
µ
µ
1% formic acid. Samples (10 µL) were analyzed by LC-MS method above.
1
4.5.6. H-NMR of Compound 1 and Synthetic 1
To confirm the absolute configuration of compound 1 as the all γ-linked cyclotetraglutamic acid
with a configuration of ddll, 1H-NMR spectral data for compound
was compared with that of the
synthetic ddll (synthetic ) and dldl (synthetic ) isomers (Figure 2). A deuterated solution buffered
1
1
4
with 100 mM of deuterated formic acid (pH 2.45) was used to dissolve synthetic
ensure comparable ionization states.
1 and natural 1 to

Molecules 2020, 25, 883
14 of 21
4.6. Compound Characterization from Chironex yamaguchii
Marfey Analysis of Authentic Cnidarin 4C (3) and Synthesized llll- and dddd-cyclic
tetra-γ-Glutamic Acids
For each sample, including cnidarin 4C (
3
), synthesized llll- or dddd-cyclic tetra-
γ
-glutamic
acids ( and , respectively), 200 µ
3
6
g of each was hydrolyzed by heating in a sealed vial at 120 ◦C for 22
h in 6 M HCl. The hydrolysate was dried with centrifugation in vacuo. A small portion of the acid
hydrolysate was added to a 1% 1-fluoro-2,4-bis(nitrophenyl)-5-l-alanine amide (FDAA) solution in
Me2O (10 µL) and 1 M NaHCO3 (20 µL). The sample was incubated for 60 min at 36 ◦C. The reaction
mixture was neutralized with 1 M HCl (20
dried with centrifugation in vacuo. The residue was dissolved in 50
analyzed by reversed phase HPLC (column: Cosmosil 5C18-AR-II 4.6
mobile phase: A, aqueous 0.04% trifluoroacetic acid; B, acetonitrile with 0.04% trifluoroacetic acid;
gradient: 0–60 min, 10–50% B).
µ
L) after cooling to room temperature. The mixture was
L DMSO. The sample was
15 mm; flow rate: 1.2 mL/min;
µ
×
4.7. Screening of Cnidarin 4A, 4B, and 4C (1–3) in Marine Invertebrates
4.7.1. Marine Species Screened for Cnidarins 4A–C (1–3)
Nine Cnidaria, one Ctenophora, one Annelida, one Mollusca, two Echinodermata, one Arthropoda,
and one Chordata (17 marine animals in total) were screened for cnidarin 4A–C (1–3) by LC-MS.
Cnidaria Cubozoa:
Chironex yamaguchii was collected at Urasoe, Okinawa in August from 2006–2015.
Carybdea brevipedalia was collected at Misaki, Kanagawa in September 2010.
Cnidaria Hydrozoa:
Physalia physalis was collected at Banda, Chiba in August 2009.
Millepora tenera was collected at Aka Island, Okinawa in August 2005.
Cnidaria Scyphozoa:
Aurelia coerulea was collected at Tokyo-bay, Tokyo in June 2012.
Chrysaora pacifica was collected at Tokyo-bay, Tokyo in April 2012.
Nemopilema nomurai was collected at Sea of Japan, Niigata in September 2009.
Cnidaria Anthozoa:
Phyllodiscus semoni was collected at Itoman, Okinawa in August 2000.
Actineria villosa was collected at Itoman, Okinawa in August 2000.
Ctenophora Tentaculata:
Bolinopsis mikado was collected at Yokohama port, Kanagawa in September 2012.
Echinodermata Asteroidea:
Certonardoa semiregularis was collected at Zushi, Kanagawa in June 2012.
Echinodermata Echinoidea:
Heliocidaris crassispina was collected at Hayama, Kanagawa in June 2012.
Echinometra mathaei was purchased from an aquarium shop in 2012.
Annelida Polychaeta:
Perinereis nuntia was purchased from a fishing equipment store in 2012.
Mollusca Bivalvia:
Mytilus galloprovincialis was purchased from the Tsukiji fish market in 2012.
Arthropoda Malacostraca:
Marsupenaeus japonicas was purchased from the Tsukiji fish market in 2012.
Chordata Actinopterygii:
Trachurus japonicus was purchased from the Tsukiji fish market in 2012.
Whole bodies of all the samples (except N. nomurai) were immediately frozen after collection or
purchasing and kept at
30 ◦C in the laboratory until analyzed. For N. nomurai, only the tentacles
−

Molecules 2020, 25, 883
15 of 21
were collected and frozen. C. yamaguchii and C. brevipedalia were identified by Dr. Shin Kubota, Kyoto
University. P. physalis, A. coerulea, C. pacifica and N. nomurai were identified by Dr. Haruto Ishii, Tokyo
University of Marine Science and Technology. P. semoni and A. villosa were identified by Dr. Hiro’omi
Uchida, Kushimoto Marine Park. M. tenera was identified by Dr. Yuri Latypov, Russian Academy of
Science. For C. yamaguchii, the voucher specimens were deposited at the Okinawa Prefectural Institute
of Health and Environment. For N. nomurai, the voucher specimens were deposited at Japan Sea
National Fisheries Research Institute. For C. brevipedalia, P. physalis, A. coerulea, C. pacifica, P. semoni,
A. villosa and M. tenera, the voucher specimens were deposited at the laboratory of aquatic ecochemistry,
Tokyo University of Marine Science and Technology.
4.7.2. Screening Procedure
Each sample (100 g) was homogenized in EtOH (200 mL) and filtered. Filtrate was evaporated and
condensed, then liquid-liquid partition was performed between EtOAc and H2O. The H2O layer was
evaporated and partition between CHCl3 and H2O. The resulting H2O layer was evaporated to dryness
and re-dissolved with 20 mL of H2O and eluted from a solid phase extraction cartridge (Sep-Pak
C18 Plus Long Cartridge) that was equilibrated with H2O. The cartridge was washed with 15 mL of
H2O. These non-retained fractions were combined and evaporated to dryness before re-dissolving
in a small volume of H2O and analyzing by LC-MS. The internal standard was the penta-peptide
Lys-Glu-Glu-Glu-Glu, commercially synthesized by JBioS (Saitama, Japan). For sample where cnidarin
4A (1) was not be detected, authentic cnidarin 4B (2) was added to the extract and reanalyzed to
confirm the ionization of cnidarin 4B (2) in the sample solution.
4.8. Synthesis of Targeted Cyclic Tetraglutamic Acids
4.8.1. ddll Cyclic Tetra-γ-Glutamic Acid (Cnidarin 4A, 1) Synthesis (See Scheme 1)
(R)-5-(Benzyloxy)-4-((R)-5-(benzyloxy)-4-((tert-butoxycarbonyl)amino)-5-oxopentanamido)
-5-oxopentanoic acid (6)
Boc-d-glutamic acid 1-benzyl ester (
1-benzyl ester and triethylamine in a solution of dichloromethane. Following work-up, EDCI (0.271 g,
1.42 mmol) was added to a solution of (0.382 g, 1.13 mmol) and N-hydroxysucinimide (0.182 g,
5) was prepared by adding Boc anhydride to d-glutamic acid
5
1.58 mmol) in dichloromethane (5.7 mL) at room temperature. The reaction was monitored by TLC and
after 18 h was diluted with dichloromethane (75 mL) and washed 3 times with saturated KH2PO4. The
combined aqueous layers were back extracted with dichloromethane and the combined organic layers
were washed with saturated NaCl, dried over mgSO4, and concentrated, providing the crude NHS ester
(0.532 g, quant) as a white powder, deemed suitable for use in the subsequent reaction. To a solution of
the crude NHS ester and triethylamine (0.221 mL, 0.160g, 1.59 mmol) in dichloromethane (11 mL) at
room temperature, 1-benzyl d-glutamate (0.309 g, 1.30 mmol) was added. The reaction was monitored
by TLC and after 21 h, diluted with dichloromethane (75 mL) and washed 3 times with saturated
KH2PO4. The combined aqueous layers were back extracted with dichloromethane and the combined
organic layers were washed with saturated NaCl, dried over mgSO4 and concentrated. The crude
product was purified by flash chromatography on silica gel, (5% methanol/95% dichloromethane with
0.5% acetic acid acid) to provide
Rf = 0.31 (5% methanol/95% dichloromethane with 0.5% acetic acid); 1H-NMR (300 MHz, CD3OD)
7.39–7.31 (m, 10H), 5.18 (s, 2H), 5.17 (d, J = 3.0, 2H), 4.48 (dd, J = 6.0,9.0, 1H), 4.17 (dd, J = 3.0,9.0, 1H),
2.40–2.32 (m, 4H), 2.21–2.09 (m, 2H), 2.01–1.86 (m, 2H), 1.44 (s, 9H); 13C-NMR (75 MHz, CD3OD)
6
(0.559 g, 95% (two step yield)) as a white powder: mp 104–106 ◦C;
δ
δ
174.9, 173.7, 172.4, 171.7, 156.8, 136.0, 136.0, 128.3, 128.3, 128.1, 128.0, 128.0, 79.5, 66.9, 66.8, 53.7, 52.2,
31.8, 30.0, 27.7, 27.3, 26.6; IR 3333 (br), 2976 (m), 1738 (m), 1520 (m), 1455 (s) cm−1; TOF-MS m/z 579.2308
[M + Na]+ (C29H36N2O9Na+ requires 579.2319, ∆ −1.1 mmu). See Figures S10 and S11 for 1H and
13C-NMR spectra.

Molecules 2020, 25, 883
16 of 21
(6R,11R,16S)-6,11,16-Tris((benzyloxy)carbonyl)-2,2-dimethyl-4,9,14-trioxo-3-oxa-5,10,15
-triazanonadecan-19-oic acid (7)
To a solution of (0.575 g, 1.03 mmol) and N-hydroxysucinimide (0.166 g, 1.45 mmol) in
dichloromethane (10 mL) at room temperature was added EDCI (0.247 g, 1.29 mmol). The reaction was
monitored by TLC and after 19 h was diluted with dichloromethane (90 mL) and washed 3 with
6
×
saturated KH2PO4. The combined aqueous layers were back extracted with dichloromethane and
the combined organic layers were washed with saturated NaCl, dried over mgSO4 and concentrated,
providing the crude NHS ester (0.614 g, quant) as a white foam, deemed suitable for use in the
subsequent reaction. To a solution of the crude NHS ester (all the material from the previous reaction)
and triethylamine (0.201 mL, 0.146 g, 1.45 mmol) in dichloromethane (10 mL) at room temperature,
1-benzyl l-glutamate (0.282 g, 1.19 mmol) was added. The reaction was monitored by TLC and after 19
h was diluted with dichloromethane (90 mL) and washed 3
×
with saturated KH2PO4. The combined
aqueous layers were back extracted with dichloromethane and the combined organic layers were
washed with saturated NaCl, dried over mgSO4 and concentrated. The crude product was purified
by flash chromatography on silica gel (4% methanol/96% dichloromethane with 0.5% acetic acid) to
provide
with 0.5% acetic acid); 1H-NMR (300 MHz, CD3OD)
(m, 2H), 4.21 (dd, J = 6.0,12.0, 1H), 2.42–2.31 (m, 6H), 2.27–2.09 (m, 3H), 2.01–1.85 (m, 3H), 1.46 (s, 9H);
13C-NMR (75 MHz, CD3OD)
174.7, 173.6, 173.5, 172.4, 171.7, 171.6, 136.0, 136.0, 128.4, 128.3, 128.1,
7
(0.5570 g, 71% (two step yield)) as a white foam: Rf = 0.47 (10% methanol in dichloromethane
δ
7.43–7.29 (m, 15H), 5.24–5.13 (m, 6H), 4.53–4.45
δ
128.0, 128.0, 79.6, 66.9, 66.8, 53.4, 52.3, 31.7, 31.7, 30.0, 27.7, 27.2, 26.5; IR 3321 (br), 3041 (m), 2953 (m),
2356 (s), 1737 (s), 1654 (s), 1529 (s) cm−1; TOF-MS m/z 798.3221 [M + Na]+ (C41H49N3O12Na+ requires
798.3214, ∆ +0.7 mmu). See Figures S12 and S13 for 1H and 13C-NMR spectra.
(6S,11S,16R,21R)-6,11,16,21-Tetrakis((benzyloxy)carbonyl)-2,2-dimethyl-4,9,14,19-tetraoxo-3-oxa
-5,10,15,20-tetraazatetracosan-24-oic acid (8)
To a solution of
dichloromethane (7.0 mL) at room temperature, EDCI (0.101 g, 0.526 mmol) was added. The reaction
was monitored by TLC and after 15 h was diluted with dichloromethane (100 mL) and washed 3 with
7 (0.545 g, 0.70 mmol) and N-hydroxysucinimide (0.056 g, 0.491 mmol) in
×
saturated KH2PO4. The combined aqueous layers were back extracted with dichloromethane and
the combined organic layers were washed with saturated NaCl, dried over mgSO4 and concentrated,
providing the crude NHS ester (0.711 g, quant) as a light brown foam deemed suitable for use in
the subsequent reaction. To a solution of the crude NHS ester and triethylamine (0.136 mL, 0.099 g,
0.981 mmol) in dichloromethane (7.0 mL), 1-benzyl l-glutamate (0.191 g, 0.806 mmol) was added at room
temperature. The reaction was monitored by TLC and after 14 h was diluted with dichloromethane
(100 mL) and washed 3
×
with saturated KH2PO4. The combined aqueous layers were back extracted
with dichloromethane and the combined organic layers were washed with saturated NaCl, dried
over mgSO4 and concentrated. The crude product was purified by flash chromatography on silica
gel (4–8% methanol/96–92% dichloromethane with 0.5% acetic acid) to provide
step yield)) as a light brown foam: Rf = 0.29 (5% methanol/95% dichloromethane with 0.5% acetic
acid); 1H-NMR (300 MHz, CD3OD)
7.39–7.28 (m, 20H), 5.18–5.13 (m, 8H), 4.50–4.37 (m, 3H), 4.18
(dd, J = 6.0,9.0, 1H), 2.41–2.27 (m, 8H), 2.23–2.07 (m, 4H), 1.99–1.82 (m, 4H), 1.43 (s, 9H); 13C-NMR (75
MHz, CD3OD) 174.8, 173.6, 173.50, 173.5, 172.4, 171.7, 171.6, 136.0, 136.0, 128.4, 128.35, 128.1, 128.0,
8 (0.619 g, 89% (two
δ
δ
128.0, 128.0, 79.6, 66.9, 66.8, 53.5, 52.4, 52.3, 31.8, 31.7, 30.0, 27.2, 27.0, 26.5; IR 3300 (br), 3046 (m), 2958
(m), 2341 (m), 1732 (m), 1724 (m), 1648 (s) cm−1; TOF-MS m/z 1017.4117 [M + Na]+ (C53H62N4O15Na+
requires 1017.4109, ∆ +0.8 mmu). See Figures S14 and S15 for 1H and 13C-NMR spectra.
Tetrabenzyl(2S,7S,12R,17R)-5,10,15,20-tetraoxo-1,6,11,16-tetraazacycloicosane-2,7,12,17
-tetracarboxylate (9)
◦
To a solution of
8
(0.373 g, 0.375 mmol) in dichloromethane (25 mL) at 0 C, a pre-cooled 1:1
solution of trifluoroacetic acid and dichloromethane (25 mL) were added portionwise; 5 mL was added
at a time every 5 min (5 ) for a total of 25 mL. The reaction was monitored by TLC by conducting “mini
workups” (drying under N2(g) and reconstituting with dichloromethane, 3 in total). After 1 h the
×
×

Molecules 2020, 25, 883
17 of 21
solvent was removed by rotary-evaporation and the crude reconstituted in dichloromethane followed
again by evaporation (3 in total) to provide the free ammonium trifluoroacetate as a brown foam.
×
To a solution of the crude product, all material from previous reaction, and triethylamine (0.157 mL,
0.114 g, 1.12 mmol) in dichloromethane (375 mL) at room temperature, EDCI (0.216 g, 1.12 mmol)
was added. The reaction was monitored by TLC and after 9 h was diluted with dichloromethane
(100 mL) and washed 3
×
with saturated KH2PO4. The combined aqueous layers were back extracted
with dichloromethane and the combined organic layers were washed with saturated NaCl, dried
over mgSO4 and concentrated. The crude product was purified by recrystallization according to the
following procedure. The crude sample was dissolved in warm dichloromethane, filtered through
cotton in a glass funnel followed by the addition of a small volume of hexane. The solution was placed
in a fume hood overnight and then in a freezer for 4 days providing small crystals. The suspension
was centrifuged, and the supernatant removed followed by 2 hexane-wash/centrifugation cycles to
provide
CDCl3)
(m, 2H), 4.40–4.31 (m, 2H), 2.50–1.98 (m, 16H); 13C-NMR (75 MHz, CDCl3)
9
δ
(123.5 mg, 37% two step yield) as a white powder: mp 244 - 246 ◦C; 1H-NMR (300 MHz,
7.38–7.27 (m, 20H), 7.095 (d, J=3.0, 2H), 6.94 (d, J=6.0, 2H), 5.17 (qd, J = 6.0,13.5, 8H), 4.60–4.49
173.6, 173.3 171.6, 171.4,
δ
135.8, 135.7, 128.8, 128.6, 128.5, 128.2, 128.0, 67.4, 67.2, 54.0, 53.9, 32.1, 31.2, 25.3, 24.3; IR 3290 (br), 3051
(m), 2932 (m), 1732 (s), 1638 (m), 1534 (s) cm−1; TOF-MS m/z 899.3425 [M + Na]+ (C48H52N4O12Na+
requires 899.3479, ∆ −0.54 mmu). See Figures S16 and S17 for 1H and 13C-NMR spectra.
2.1,5.4-Anhydro(γ-d-glutamyl-γ-d-glutamyl-γ-l-glutamyl-l-glutamic acid), cnidarin 4A (1)
Above a solution of
temperature, hydrogen gas was maintained at ambient pressure for 24 h. The reaction was then
filtered through a PTFE filter followed by ethanol washing (5 1 mL), methanol washing (5 1 mL)
then water (2 1.5 mL). The crude product was purified by HPLC using a Waters Atlantis dC18
(10 250 mm, 10 m particle size) column (mobile phase A: water/formic acid (1000:1); mobile phase B:
acetonitrile/formic acid (1000:1); gradient: 2.5% B, 0–7 min, 2.5–100% B, 7–27 min, 100% B, 27–35 min)
to provide cnidarin 4A,
(9.7 mg, 79%) as a white solid: decomp 279–285 ◦C; 1H-NMR (500 MHz,
D2O) 4.33 (dd, J=5.0,12.0, 2H), 4.255 (dd, J=5.0,10.0, 2H), 2.47–2.30 (m, 10H), 2.15–2.05 (m, 2H),
2.03–1.94 (m, 2H), 1.93–1.84 (m, 2H); 13C-NMR (125 MHz, D2O)
178.4, 178.2, 177.9, 177.5, 55.4, 54.3,
9 (20.2 mg, 0.023 mmol) and 10% Pd/C (~2 mg) in ethanol (20 mL) at room
×
×
×
×
µ
1
δ
δ
34.5, 33.8, 29.0, 28.6; IR 3286 (br), 2560 (br), 1724 (m), 1538 (m), 1415 (br) cm−1; TOF-MS m/z 539.1578
[M + Na]+ (C20H28N4O12Na+ requires 539.1601, ∆ −2.3 mmu). See Figures S18 and S19 for 1H and
13C-NMR spectra.
4.8.2. llll Cyclic Tetraglutamic Acid (Cnidarin 4C, 3) Synthesis (See Scheme 2)
5-Benzyl 1-(tert-butyl)((S)-5-(tert-butoxy)-4-((tert-butoxycarbonyl)amino)-5-oxopentanoyl)
-l-glutamate (12)
To a solution of 10 (1.09 g, 3.61 mmol) in dichloromethane (15 mL), DMAP (220 mg, 1.8 mmol),
EDCI (1.38 g, 7.22 mmol) and 11 (1.06 g, 3.06 mmol) were added, and the reaction mixture was stirred at
room temperature for 2 h. H2O was added to the reaction mixture and the organic layer was extracted
with dichloromethane. The extracts were dried over mgSO4, filtered, and concentrated in vacuo. The
residue was purified by column chromatography to give 12 (1.64 g, 2.83 mmol) in 78% yield.
5-Benzyl 1-(tert-butyl) ((S)-4-amino-5-(tert-butoxy)-5-oxopentanoyl)-l-glutamate (13)
To a solution of 12 (0.9 g, 1.55 mmol) in CH3CN/H2O (50:1), BiCl3 was added portionwise (977 mg,
3.1 mmol), to selectively deprotect the Boc group [40], NaHCO3 was added and the reaction mixture
was filtered through Celite pad and and filtrates were concentrated in vacuo to give 13 (660 mg,
1.38 mmol) in 88% yield.
(S)-5-(tert-Butoxy)-4-((S)-5-(tert-butoxy)-4-((tert-butoxycarbonyl)amino)-5-oxopentanamido)
-5-oxopentanoic acid (14)
Again, to the solution of 12 (0.7 g, 1.2 mmol), Pd/C (70 mg) was added and the reaction mixture
was stirred at room temperature under hydrogen gas at ambient pressure. After 20 min, the reaction

Molecules 2020, 25, 883
18 of 21
mixture was filtered through a Celite pad, and filtrates were concentrated in vacuo to give 14 (550 g,
1.12 mmol) in 93% yield.
23-Benzyl 11,16,21,6-tetra-tert-butyl (6R,11R,16R,21R)-2,2-dimethyl-4,9,14,19-tetraoxo-3-oxa-5,10,
15,20-tetraazatricosane-6,11,16,21,23-pentacarboxylate (15)
To a solution of 14 (660 mg, 1.38 mmol) in dichloromethane (15 mL), EDCI (528 mg, 2.76 mmol),
DMAP (84.3 mg, 0.69 mmol), and the amine 13 (673 mg, 1.38 mmol) were added, and the mixture was
stirred at room temperature for 2 h. To the reaction mixture was added H2O, and the organic layer
was extracted by dichloromethane. The extracts were dried over mgSO4, filtered, and concentrated in
vacuo. The residue was purified by column chromatography to give 15 (1.0 g, 1.05 mmol) in 79% yield.
2.1,5.4-Anhydro(γ-l-glutamyl-γ-l-glutamyl-γ-l-glutamyl-l-glutamic acid), cnidarin 4C (3)
To a solution of 15 (1.0 g, 1.05 mmol) in CH3CN-H2O (50:1), BiCl3 was added portionwise (662 mg,
2.1 mmol) to selectively deprotect the Boc group.1 NaHCO3 was added and the reaction mixture was
filtered through a Celite pad, and filtrates were concentrated in vacuo. The concentrates further were
purified by column chromatography to give the linear llll-tetraglutamic acid (420 mg, 0.49 mmol) in
46% yield. [
1H), 5.10 (s, 2H), 4.46–4.43 (m, 3H), 3.71 (m, 1H), 2.53–2.39 (m, 4H), 2.35–2.25 (m, 4H), 2.24–2.11 (m,
4H), 2.02–1.76 (m, 4H), 1.48–1.42 (m, 36H); 13C-NMR (100 MHz, CDCl3)
172.6, 172.5, 172.2, 172.0,
α] δ 7.32 (s, 5H), 7.07 (s, 1H), 7.05 (s,
25 +7.34◦ (c 1.88, CHCl3); 1H-NMR (400 MHz, CDCl3)
D
δ
171.2, 171.0, 135.7, 128.4, 128.1, 82.1, 66.3, 53.7, 52.2, 52.0, 32.2, 31.8, 30.3, 28.8, 28.5, 28.3, 27.8, 27.4 ppm;
HRMS (ESI, [M + Na]+) m/z 871.4697 (calcd for C43H68N4O13Na+ 871.4680,
∆ +1.7 mmu). See Figures
S30 and S31 for 1H and 13C-NMR spectra.
To the linear llll-glutamic acid (126 mg, 0.14 mmol) in THF, Pd/C (12 mg) was added and
hydrogen gas was maintained at ambient pressure to remove the benzyl group. The reaction mixture
was filtrate through Celite pad and concentrated in vacuo. The concentrates (166 mg, 0.21 mmol) were
subjected to macrocylization in the presence of 2-methyl-6-nitrobenzoic anhydride (MNBA, 108 mg,
0.315 mmol), DMAP (2.56 g, 0.021 mmol) and Et3N (175 mL, 1.26 mmol) to give the cyclic llll-glutamic
acid and finally the Boc group deprotected by TFA to give
3
(48.6 mg, 0.094 mmol) in 67% yield in three
4.44–4.28 (m, 4H), 2.55–2.32 (m,
175.7, 175.6, 175.5, 175.4, 53.6,
25
steps. [
α
]
−
28.4 (c 0.83, methanol); 1H-NMR (400 MHz, D2O)
δ
D
8H), 2.28, 2.14 (m, 4H), 2.05–1.87 (m, 4H); 13C-NMR (100 MHz, D2O)
δ
52.5, 52.3, 31.7, 26.6 ppm; HRMS (ESI, [M + Na]+) m/z 539.1589 (calcd for C20H28N4O12Na+ 539.1601,
∆ −1.2 mmu). See Figures S32 and S33 for 1H and 13C-NMR spectra.
4.9. Bioassays
4.9.1. Cytotoxicity Assay
Sample preparation: Cnidarin 4A (
1
) (2.1,5.4-anhydro(
γ
-d-glutamyl-
γ
-d-glutamyl-
γ-l-glutamyl-l
-glutamate) and iso-cnidarin 4A ( ) (2.1,5.4-anhydro(
4
γ-d-glutamyl-γ-l-glutamyl-γ-d-glutamyl-l-glutamate)
(MW 516) samples were dissolved in 5% bovine serum (FBS) (Mediatech) supplemented Dulbecco’s
Modified Eagle Medium (DMEM) (Sigma Aldrich) media, with vortexing and sonicating to allow
complete solvation, and sterile filtered. Doxorubicin dissolved in 5% FBS supplemented DMEM media
was used as a toxicity standard. Compounds were half-log serial diluted.
Cell culture: HEK-293 cells were cultured in DMEM supplemented with 10% FBS and 1%
penicillin-streptomycin (Mediatech) and maintained at 37 ◦C, 90% humidity, and 5% CO2 atmosphere.
Bioassay: Cells were plated in a 96-well plate at 10,000 cells/well in DMEM supplemented with
5% FBS and 1% penicillin-streptomycin. Cells were incubated for 24 h prior to compound addition to
allow cells to grow to confluency. Next 100
µ
L of (2 ) compound or control was added to the wells,
×
and plates were incubated (37 ◦C, 90% humidity, and 5% CO2) for 48 h. Cells were then fixed with
50% cold trichloroacetic acid (TCA), added directly to the wells, and allowed to sit for 1 h at 4 ◦C.
Plates were washed with tap water to remove media and TCA, and dried. 0.4% sulforhodamine B
in 1% acetic acid was added to each well and allowed to sit for 30 min at room temperature. Plates
were then washed 5–6 times with 1% acetic acid and dried. Dye was solubilized with 10 mM Tris base

Molecules 2020, 25, 883
19 of 21
(pH = 10.5) and allowed to sit for 30 min until dye was completely solubilized. Plates were then read
for absorbance on the Flexstation 3 (Molecular Devices) at 500 nm and a background wavelength of
690 nm.
Background absorbance was subtracted from all experiment wells. Growth inhibition/lethality was
calculated using four parameters: (1) Tz: absorbance measurement of cells fixed at “time zero”, the same
time test compounds were added to other wells, and represented 0% growth. (2) Tc: absorbance
measurement of control cells grown in media only, represented 100% growth. (3) No Cells: absorbance
measurement of background control (wells with no cells), and represented 100% lethality. (4) Ti:
absorbance measurement of cells grown in test compound. Percent growth inhibition was calculated
([(Ti
−
Tz)/(Tc
−
Tz)]
×
100) if absorbance of test compound (Ti) is greater than absorbance of cells fixed
and showed not notable reduction of cell growth or survival at any
at time = 0 (Tz). Compounds
1
2
concentration tested (see Figure S9).
4.9.2. Hemolysis Assay
A 6% red blood cell (RBC) solution in 140 mM NaCl was prepared from human whole blood.
Compound was dissolved in 140 mM NaCl at 2 concentrations, 98 and 484 M, and a 10% TritonX-100
(Fisher Scientific) solution was prepared in 110 mM NaCl. In a 96-well plate, 100 L of the RBC solution
was combined with 100 L of vehicle (140 mM NaCl) or diluted stock solutions of compound or
TritonX-100 (in 140 mM NaCl) to give final compound concentrations of 24 and 121 M and a 1%
TritonX-100 concentration. Each condition was tested in triplicate. The plate was incubated at 37 ◦C
for 1 h before adding 70 L 140 mM NaCl and centrifuging at 750
g for 10 min at 4 ◦C (Marathon
2100R Centrifuge, Fisher Scientific). A 100 L aliquot of each supernatant was then transferred to a flat
1
µ
µ
µ
1
1
µ
µ
×
µ
bottom 96-well plate, and the absorbance was read at 405 nm on an Ultramark EX Microplate Imaging
System (Bio-Rad) to quantitate the hemoglobin concentration as a measure of the extent of hemolysis.
The hemoglobin concentration was calculated from its molar absorptivity and the data was normalized
to the signal for 1% TritonX-100 (positive control). Student t-test showed compound
1 caused no
significant hemolysis compared to negative control (saline) at either concentration. See Table S2.
5. Conclusions
Three new cyclic
from venom extracts of the jellyfish Alatina alata and Chironex yamaguchii. The full configurational
assignments were confirmed by syntheses. The most abundant of these compounds, cnidarin 4A ( ),
γ-linked tetraglutamic acids, cnidarins 4A (1), 4B (2), and 4C (3), were isolated
1
showed no mammalian cell toxicity or hemolytic activity. These compounds were detected in all nine
Cnidarians tested, but not in the other nine non-Cnidarians species examined (one Ctenophora, one
Annelida, one Mollusca, two Echinodermata, one Arthropoda, and one Chordata). Although a limited
number of invertebrate species were screened, the current results may be an indication that these
compounds are specific to Cnidaria. In light of the fact that no hemolytic or toxic effects were detected
for the most abundant of the peptides, the role of cnidarins 4A (
1), 4B (2), and 4C (3) in the Cnidarians’
nematocyst is an intriguing research topic that needs to be resolved.
Supplementary Materials: The following are available online at http://www.mdpi.com/1420-3049/25/4/883/s1:
Methods and results for synthesis of compounds and , chromatography and chemical analyses of compound
cell toxicity assays of compounds 1 and 4, and NMR spectra of synthetic intermediates for compounds 1–4.
2
4
1,
Author Contributions: J.R., G.B., H.N., K.N., A.Y., and F.D.H conceived and designed the experiments; J.R.,
K.K.G., R.K., S.S.M., W.Y., A.I., and A.Y. performed the experiments; J.R., K.K.G., G.B., K.N., H.N., A.Y., and F.D.H
analyzed the data; J.R., G.B., A.Y, H.N., K.N., and F.D.H. prepared the manuscript. All authors have read and
agreed to the published version of the manuscript.
Funding: This work was supported by the Hawaii Community Foundation (F.D.H. and A.Y.), the National
Institute of General Medical Sciences, National Institutes of Health (P20GM 103466, F.D.H. and G.B.), the Japan
Society for the Promotion of Science (JSPS) Grant in-Aid for Scientific Research Grant Number (16K01911 and
19K06220 to H.N.).
Acknowledgments: We thank Davey Cagle and Hannah Tsunemoto for technical assistance.

Molecules 2020, 25, 883
20 of 21
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Bentlage, B.; Cartwright, P.; Yanagihara, A.A.; Lewis, C.; Richards, G.S.; Collins, A.G. Evolution of box
jellyfish (Cnidaria: Cubozoa), a group of highly toxic invertebrates. Proc. R. Soc. B Biol. Sci. 2009, 277,
493–501. [CrossRef] [PubMed]
2.
3.
Fenner, P.J.; Harrison, S.L. Irukandji and Chironex fleckeri jellyfish envenomation in tropical Australia.
Wilderness Environ. Med. 2000, 11, 233–240. [CrossRef]
Ramasamy, S.; Isbister, G.K.; Seymour, J.E.; Hodgson, W.C. The in vivo cardiovascular effects of box jellyfish
Chironex fleckeri venom in rats: Efficacy of pre-treatment with antivenom, verapamil and magnesium sulphate.
Toxicon 2004, 43, 685–690. [CrossRef] [PubMed]
4.
5.
Currie, B.J. Marine antivenoms. J. Toxicol. Clin. Toxicol. 2003, 41, 301–308. [CrossRef] [PubMed]
Brinkman, D.; Burnell, J. Identification, cloning and sequencing of two major venom proteins from the box
jellyfish, Chironex fleckeri. Toxicon 2007, 50, 850–860. [CrossRef]
6.
7.
8.
9.
Tibballs, J. Australian venomous jellyfish, envenomation syndromes, toxins and therapy. Toxicon Off. J. Int.
Soc. Toxinol. 2006, 48, 830–859. [CrossRef]
Carrette, T.J.; Underwood, A.H.; Seymour, J.E. Irukandji syndrome: A widely misunderstood and poorly
researched tropical marine envenoming. Diving Hyperb. Med. 2012, 42, 214–223.
Tibballs, J.; Li, R.; Tibballs, H.A.; Gershwin, L.-A.; Winkel, K.D. Australian carybdeid jellyfish causing
“Irukandji syndrome”. Toxicon 2012, 59, 617–625. [CrossRef]
Yanagihara, A.A.; Wilcox, C.; Smith, J.; Surrett, G.W. Cubozoan Envenomations: Clinical Features,
Pathophysiology and Management. In The Cnidaria, Past, Present and Future; Springer: Berlin/Heidelberg,
Germany, 2016; pp. 637–652. ISBN 978-3-319-31303-0.
10. Lewis Ames, C.; Bentlage, B. Clarifying the identity of the Japanese Habu-Kurage, Chironex yamaguchii, sp.
nov. (Cnidaria: Cubozoa: Chirodropida). Zootaxa 2009, 2030, 59–65. [CrossRef]
11. Horiike, T.; Nagai, H.; Kitani, S. Identification of allergens in the box jellyfish Chironex yamaguchii that cause
sting dermatitis. Int. Arch. Allergy Immunol. 2015, 167, 73–82. [CrossRef]
12. Lewis, C.; Bentlage, B.; Yanagihara, A.; Gillan, W.; Blerk, J.V.; Keil, D.P.; Bely, A.E.; Collins, A.G. Redescription
of Alatina alata (Reynaud, 1830) (Cnidaria: Cubozoa) from Bonaire, Dutch Caribbean. Zootaxa 2013, 3737,
473–487. [CrossRef] [PubMed]
13. Nagai, H.; Takuwa, K.; Nakao, M.; Sakamoto, B.; Crow, G.L.; Nakajima, T. Isolation and characterization
of a novel protein toxin from the Hawaiian box jellyfish (sea wasp) Carybdea alata. Biochem. Biophys. Res.
Commun. 2000, 275, 589–594. [CrossRef]
14. Yoshimoto, C.M.; Yanagihara, A.A. Cnidarian (coelenterate) envenomations in Hawai’i improve following
heat application. Trans. R. Soc. Trop. Med. Hyg. 2002, 96, 300–303. [CrossRef]
15. Anderluh, G.; Sepcˇic´, K.; Turk, T.; Macˇek, P. Cytolytic proteins from cnidarians-an overview. Acta Chim. Slov.
2011, 58, 724–729. [PubMed]
16. Mariottini, G.L.; Pane, L. Cytotoxic and cytolytic cnidarian venoms. A review on health implications and
possible therapeutic applications. Toxins 2013, 6, 108–151. [CrossRef] [PubMed]
17. Brinkman, D.L.; Burnell, J.N. Biochemical and molecular characterisation of cubozoan protein toxins. Toxicon
2009, 54, 1162–1173. [CrossRef] [PubMed]
18. Chung, J.J.; Ratnapala, L.A.; Cooke, I.M.; Yanagihara, A.A. Partial purification and characterization of a
hemolysin (CAH1) from Hawaiian box jellyfish (Carybdea alata) venom. Toxicon 2001, 39, 981–990. [CrossRef]
19. Yanagihara, A.A.; Shohet, R.V. Cubozoan venom-induced cardiovascular collapse is caused by hyperkalemia
and prevented by zinc gluconate in mice. PLoS ONE 2012, 7, e51368. [CrossRef]
20. Brinkman, D.L.; Jia, X.; Potriquet, J.; Kumar, D.; Dash, D.; Kvaskoff, D.; Mulvenna, J. Transcriptome and
venom proteome of the box jellyfish Chironex fleckeri. BMC Genom. 2015, 16, 407. [CrossRef]
21. Jouiaei, M.; Casewell, N.; Yanagihara, A.; Nouwens, A.; Cribb, B.; Whitehead, D.; Jackson, T.; Ali, S.;
Wagstaff, S.; Koludarov, I.; et al. Firing the sting: Chemically induced discharge of cnidae reveals novel
proteins and peptides from box jellyfish (Chironex fleckeri) venom. Toxins 2015, 7, 936–950. [CrossRef]

Molecules 2020, 25, 883
21 of 21
22. Jaimes-Becerra, A.; Chung, R.; Morandini, A.C.; Weston, A.J.; Padilla, G.; Gacesa, R.; Ward, M.; Long, P.F.;
Marques, A.C. Comparative proteomics reveals recruitment patterns of some protein families in the venoms
of Cnidaria. Toxicon 2017, 137, 19–26. [CrossRef] [PubMed]
23. Fenner, P.J.; Hadok, J.C. Fatal envenomation by jellyfish causing Irukandji syndrome. Med. J. Aust. 2002, 177,
362–363. [CrossRef] [PubMed]
24. Winkel, K.D.; Tibballs, J.; Molenaar, P.; Lambert, G.; Coles, P.; Ross-Smith, M.; Wiltshire, C.; Fenner, P.J.;
Gershwin, L.-A.; Hawdon, G.M. Cardiovascular actions of the venom from the Irukandji (Carukia Barnesi)
jellyfish: Effects in human, rat and guinea-pig tissues in vitro and in pigs in vitro. Clin. Exp. Pharmacol. Physiol.
2005, 32, 777–788. [CrossRef] [PubMed]
25. Nagai, H. Recent progress in jellyfish toxin study. J. Health Sci. 2003, 49, 337–340. [CrossRef]
26. Ramasamy, S.; Isbister, G.K.; Seymour, J.E.; Hodgson, W.C. Pharmacologically distinct cardiovascular effects
of box jellyfish (Chironex fleckeri) venom and a tentacle-only extract in rats. Toxicol. Lett. 2005, 155, 219–226.
[CrossRef]
27. Bailey, P.M.; Little, M.; Jelinek, G.A.; Wilce, J.A. Jellyfish envenoming syndromes: Unknown toxic mechanisms
and unproven therapies. Med. J. Aust. 2003, 178, 34–37. [CrossRef]
28. Lau, M.-T.; Manion, J.; Littleboy, J.B.; Oyston, L.; Khuong, T.M.; Wang, Q.-P.; Nguyen, D.T.; Hesselson, D.;
Seymour, J.E.; Neely, G.G. Molecular dissection of box jellyfish venom cytotoxicity highlights an effective
venom antidote. Nat. Commun. 2019, 10, 1655. [CrossRef]
29. Little, M.; Pereira, P.; Carrette, T.; Seymour, J. Jellyfish responsible for Irukandji syndrome. QJM 2006, 99,
425–427. [CrossRef]
30. Rocha, J.; Peixe, L.; Gomes, N.; Calado, R. Cnidarians as a source of new marine bioactive compounds—An
overview of the last decade and future steps for bioprospecting. Mar. Drugs 2011, 9, 1860–1886. [CrossRef]
31. Dictionary of Natural Products; CRC Press: Boca Raton, FL, USA, 2019.
32. Lindquist, N. Tridentatols D H, nematocyst metabolites and precursors of the activated chemical defense in
−
the marine hydroid Tridentata marginata (Kirchenpauer 1864). J. Nat. Prod. 2002, 65, 681–684. [CrossRef]
33. Munekata, E.; Ishiyama, H.; Osakada, F.; Izumi, K. Synthetic cyclopeptides with some neuroactive properties.
Pept. Chem. 1980, 181–186.
34. Hollosi, M.; Katar, M. Synthesis of cyclo-γ-oligoglutamic acid derivatives. Acta Chim. Acad. Sci. Hung. 1972,
73, 247–254.
35. Weber, J. Poly(gamma-glutamic acid)s are the major constituents of nematocysts in Hydra (Hydrozoa,
Cnidaria). J. Biol. Chem. 1990, 265, 9664–9669. [PubMed]
36. Weber, J. A novel kind of polyanions as principal components of cnidarian nematocysts. Comp. Biochem.
Physiol. A Physiol. 1991, 98, 285–291. [CrossRef]
37. Szczepanek, S.; Cikala, M.; David, C.N. Poly-gamma-glutamate synthesis during formation of nematocyst
capsules in Hydra. J. Cell Sci. 2002, 115, 745–751.
38. Berking, S.; Herrmann, K. Formation and discharge of nematocysts is controlled by a proton gradient across
the cyst membrane. Helgol. Mar. Res. 2006, 60, 180–188. [CrossRef]
39. Park, S.; Piriatinskiy, G.; Zeevi, D.; Ben-David, J.; Yossifon, G.; Shavit, U.; Lotan, T. The nematocyst’s sting is
driven by the tubule moving front. J. R. Ssoc. Interface 2017, 14, 20160917. [CrossRef]
40. Navath, R.S.; Pabbisetty, K.B.; Hu, L. Chemoselective deprotection of N-Boc group in amino acids and
peptides by bismuth(III) trichloride. Tetrahedron Lett. 2006, 47, 389–393. [CrossRef]
Sample Availability: Samples of the compounds are not available from the authors.
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
