Synthesis and comparative evaluation of novel cationic amphiphile C12-Man-Q as an efficient DNA delivery agent in vitro

Article abstract of DOI:10.3390/molecules23071540

New amphiphilic 1,4-DHP derivative C12-Man-Q with remoted cationic moieties at positions 2 and 6 was synthesised to study DNA delivery activity. The results were compared with data obtained for cationic 1,4-DHP derivative D19, which is known to be the mos

Full text of DOI:10.3390/molecules23071540

molecules
Article
Synthesis and Comparative Evaluation of Novel
Cationic Amphiphile C12-Man-Q as an Efficient DNA
Delivery Agent In Vitro
Gunita Apsite 1, Irena Timofejeva 1, Aleksandra Vezane 1, Brigita Vigante 2, Martins Rucins 2,
Arkadij Sobolev 2, Mara Plotniece 2,3, Karlis Pajuste 2, Tatjana Kozlovska 1 and Aiva Plotniece 2,
*
1
Latvian Biomedical Research and Study Centre, Ratsupites iela 1, LV-1067 Riga, Latvia;
gunita.apsite@gmail.com (G.A.); irena@biomed.lu.lv (I.T.);
Aleksandra.Vezane@biomed.lu.lv (A.V.); tatyana@biomed.lu.lv (T.K.)
Latvian Institute of Organic Synthesis, Aizkraukles iela 21, LV-1006 Riga, Latvia; vigante@osi.lv (B.V.);
2
rucins@osi.lv (M.R.); arkady@osi.lv (A.S.); marapl67@hotmail.com (M.P.); kpajuste@osi.lv (K.P.)
3
R¯ıga Stradinš University, Dzirciema iela 16, LV-1007 Riga, Latvia
,
*
Correspondence: aiva@osi.lv; Tel.: +371-6701-4852
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 28 May 2018; Accepted: 21 June 2018; Published: 26 June 2018
Abstract: New amphiphilic 1,4-DHP derivative C12-Man-Q with remoted cationic moieties at
positions 2 and 6 was synthesised to study DNA delivery activity. The results were compared
with data obtained for cationic 1,4-DHP derivative D19, which is known to be the most efficient
one among the previously tested 1,4-DHP amphiphiles. We analysed the effects of C12-Man-Q
concentration, complexation media, and complex/cell contact time on the gene delivery effectiveness
and cell viability. Transmission electron microscopy data confirms that lipoplexes formed by the
compound C12-Man-Q were quite uniform, vesicular-like structures with sizes of about 50 nm,
and lipoplexes produced by compound D19 were of irregular shapes, varied in size in the range
of 25–80 nm. Additionally, confocal microscopy results revealed that both amphiphiles effectively
delivered green fluorescent protein expression plasmid into BHK-21 cells and produced a fluorescent
signal with satisfactory efficiency, although compound C12-Man-Q was more cytotoxic to the BHK-21
cells with an increase of concentration. It can be concluded that optimal conditions for C12-Man-Q
lipoplexes delivery in BHK-21 cells were the serum free media without 0.15 M NaCl, at an N/P ratio
of 0.9. Compound D19 showed higher transfection efficiency to transfect BHK-21 and Cos-7 cell
lines, when transfecting active proliferating cells. Although D19 was not able to transfect all studied
cell lines we propose that it could be cell type specific. The compound C12-Man-Q showed modest
delivery activity in all used cell lines, and higher activity was obtained in the case of H2-35 and B16
cells. The transfection efficiency in cell lines MCF-7, HeLa, and Huh-7 appears to be comparable to
the reference compound D19 and minimal in the HepG2 cell line.
Keywords: cationic amphiphiles; 1,4-dihydropyridines; lipoplexes; DNA transfection; gene
delivery; cytotoxicity
1. Introduction
Gene therapy has become the research focus for many laboratories in pharmacy, medicine,
biochemistry, and chemical engineering worldwide [
controlling elements are used as pharmacological agents to cure diseases by replacing damaged genes
with a proper one [ ]. Initially, gene therapy was viewed as an approach for treating hereditary
1,2]. In gene therapy DNA, RNA, or gene activity
3–6
diseases, but its potential role in the treatment of acquired diseases, such as cancer, is now widely
recognised [7–9].
Molecules 2018, 23, 1540; doi:10.3390/molecules23071540
www.mdpi.com/journal/molecules

Molecules 2018, 23, 1540
2 of 18
The success of gene therapy is largely dependent on the development of a vector or vehicle that
can selectively and efficiently deliver a gene to target cells with minimal toxicity [10 12]. The two
–
main types of vectors that are used in gene therapy are based on viral and nonviral gene delivery
systems. Though viral systems usually give high transfection efficiency, safety concerns from potential
mutation, recombination, oncogenic effect, and high cost, however, greatly limit their therapeutic
applications [13,14]. Compared to viral vectors, nonviral gene delivery systems are known to possess
a low preexisting immunogenicity. Additional advantages of nonviral vectors are their higher loading
capacity and facile preparation methods [15]. Consequently, the development of novel nontoxic
cationic structures with high gene transfection efficiencies is of great importance [16].
Synthetic cationic lipids are widely used components of nonviral gene carriers and the factors
regulating their transfection efficiency are subject of considerable interest [17]. Synthetic cationic
lipids are currently the most extensively used nonviral carriers due to their ability to form complexes
with the nucleic acids [18]. The structure of the lipid molecule, for example, the functional nature
hydrophobic domain and the charged headgroup, has a significant impact on the particle integrity
and morphology and, hence, on transgene efficiency and cytotoxicity [19]. Each lipid has different
structural aspects, such as headgroup size and hydrocarbon tail length. These aspects confer distinct
characteristics to the lipid/DNA complex, which, in turn, affect association with, and uptake into,
the cell [20]. The molecular architecture of the cationic lipid determines its transfection efficiency [21].
Positively-charged amphiphilic 1,4-dihydropyridine (1,4-DHP) derivatives were studied earlier
as membranotropic compounds [22] and proposed as a promising tool for DNA delivery [23,24].
Previously, multiple cationic 1,4-dihydropyridine amphiphiles capable of transfecting plasmid DNA
(pDNA) into different cell lines in vitro were developed. After these studies we have concluded
that two cationic moieties at positions 2 and 6, together with dodecyloxycarbonyl substituents at
positions 3 and 5 of the 1,4-DHP molecule, were optimal for these kinds of synthetic lipid-like
compounds [23,24]. The obtained data confirmed that, at charge ratio 2, the transfection efficiency of
1,4-DHP amphiphile D19 was about five times better than that reported for the commercially available
cationic lipid of DOTAP (N-(1-(2,3-dioleoyloxy)propyl)-N,N,N-trimethyl ammonium methylsulfate).
The compound was also 45 times more effective than PEI 25 (polyethyleneimine of 25 kDa) [24].
Recently, the influence of the amphiphile core on the efficacy of pDNA delivery has been revealed
within studies of structure-activity relationships performed by our research group. During these
studies the activity of the corresponding cationic pyridines as close structural analogues, and possible
metabolites of promising 1,4-DHP delivery systems, were examined. The obtained data showed
that pyridine derivatives having dodecyloxycarbonyl substituents at positions 3 and 5, and cationic
moieties at positions 2 and 6, possessed lower pDNA transfection activity than the corresponding
1,4-DHP amphiphiles [25].
In this study two promising cationic compounds on 1,4-DHP core were studied. Compound
C12-Man-Q was synthesised for testing of the influence of remoted cationic moieties at positions 2
and 6 of the 1,4-DHP molecule on DNA delivery activity. The design of compound C12-Man-Q was
based on the exchange of aromatic pyridinium moieties of derivative D19 to aliphatic ammonium
moieties. The results were compared with data obtained for cationic 1,4-DHP derivative D19, which is
known to be the most efficient one among the 1,4-DHP derivatives tested previously [23–25]. In this
work we analysed the effects of C12-Man-Q concentration, complexation media, and complex/cell
contact time on the gene delivery effectiveness and cell viability on various cell lines.
2. Result and Discussion
2.1. Synthesis of Cationic 1,4-Dihydropyridine Derivatives D19 and C12-Man-Q
0
The reference compound 1,1 -[(3,5-didodecyloxycarbonyl-4-phenyl-1,4-dihydropyridine-2,6-diyl)d
imethylen]-bispyridinium dibromide (D19) was synthesised according to the already-reported
0
method [23], path A (Scheme 1). The target 1,4-DHP derivative N,N -{[3,5-bis(dodecyloxycarbonyl)-4-p

Molecules 2018, 23, 1540
3 of 18
henyl-1,4-dihydropyridine-2,6-diyl]diethylene}bis N,N-dimethyloctyl ammonium dibromide
C12-Man-Q) was designed to remain in two cationic moieties at positions 2 and 6 and
(
dodecyloxycarbonyl substituents at positions 3 and 5 of the 1,4-DHP molecule which were
defined as optimal for these kinds of synthetic lipid-like compounds as delivery systems according
to our previous studies [23,24]. In this case, remoted 1,4-DHP cycle cationic aromatic headgroups
were exchanged with aliphatic headgroups at positions 2 and 6 providing compound C12-Man-Q
.
Studies of the differences in activities of D-19 and C12-Man-Q are important steps in establishing
the structure-activity relationships and elaboration of more active and selective cationic 1,4-DHP
derivatives in the future. The desired cationic 1,4-DHP derivative C12-Man-Q was synthesised in the
two-stage procedure according to path B (Scheme 1).
Scheme 1. Strategies for the synthesis of cationic 1,4-DHP derivatives D19 and C12-Man-Q. Reaction
conditions: (a) NBS, MeOH, r.t., 20 h; (b) pyridine, dry acetone, r.t. 48 h [26]; (
c) paraformaldehyde,
dimethylamine hydrochloride, EtOH, conc.HCl, reflux, 24 h; and (d) 1-bromooctane, nitromethane,
DMF, reflux, 48 h.

Molecules 2018, 23, 1540
4 of 18
2,6-Bis(2-(N,N-dimethylamino)ethyl) 1,4-dihydropyridine derivative
3
was obtained in 68% yield
in the Mannich reaction, analogous with the method reported in the literature [27]. In our case product
purification was performed by flash chromatography. It can be assumed that the Mannich reaction
occurred with a lower yield due to the presence of didodecyloxycarbonyl substituents at the positions
3 and 5 of 1,4-DHP cycle, compared to the previously-described methoxycarbonyl moieties [27],
which were less sterically hindered. Further quaternisation of 1,4-DHP
3 with 1-bromooctane with
continuous refluxing in a mixture of nitromethane and DMF led to the target aliphatic moieties
containing dicationic 1,4-DHP derivative C12-Man-Q in 50% yield.
The structures of the newly-synthesised compounds
3 and C12-Man-Q were established and
confirmed by 1H-NMR, 13C-NMR, MS, and elemental analysis data. Details of the syntheses and full
physico-chemical characterisation for the newly-synthesised compounds are given in the Experimental
section. The purities of the studied compounds were at least 95% according to high-performance liquid
chromatography (HPLC) data [28].
2.2. Choice of Plasmid DNA
Plasmid DNA (pDNA), as a DNA vector for transferring different genes of interest, has been
widely used as gene delivery systems in vitro [29]. Plasmid vectors were classified into different
classes in accordance to specificity of existing replication origin, selection markers and promoter
sequences [30]. In this study, two plasmid vectors with relatively similar sizes (4079 bp and 4731 bp)
and the same, strong constitutive cytomegalovirus (CMV) promoter [31] for transcriptional control of
two different reporter genes’ expression were used. Plasmid pRL-CMV (Promega, Madison, WI, USA)
was used for delivery of the wild-type Renilla luciferase gene, thus allowing the evaluation of the
transfection efficiency quantitatively. Plasmid pEGFP-C1 (Clontech) encoded for a red-shifted variant
of wild-type GFP [32–34], which has been optimised for brighter fluorescence and higher expression
in mammalian cells, was used to assess transfection efficiency visually with fluorescent microscopy.
Interpretation of the results is based on the assumption, that although absolute gene expression values
vary with the plasmid construct, the relative expression levels for various transfection reagents are
related directly to the reagent and not to the plasmid [35,36].
2.3. Evaluation of Complexation Ability
Formation of complexes (lipoplexes) between lipids and DNA is defined as the electrostatic
interaction between anionic-charged DNA and the cationic-charged gene delivery vehicle. The first
step in the gene delivery process is evaluation of the complexation ability of the carrier molecule with
the pDNA, followed by pDNA condensation and formation of the carrier/pDNA complex. The N/P
ratio refers to ionic balance in cationic amphiphiles/DNA transfection lipoplexes and indicates the
ratio between nitrogen (N) from the synthetic lipid and phosphate (P) residues from the DNA. In most
cases, in order to achieve higher transfection efficiency, it is crucial for the transfection complex to stay
positively charged so that it could interact with cell plasmatic membrane on the same electrostatic
forces basis [37–39]. Therefore, the relative pDNA binding affinities of the synthesised 1,4-DHP
amphiphiles D19 and C12-Man-Q were evaluated using a standard electrophoresis gel shift assay for
the assessment of pDNA (pEGFP-C1) complexation at various N/P ratios. Increasing the amounts
of the compounds C12-Man-Q or D19 were mixed with a constant amount (1 µg) of plasmid DNA
(pEGFP-C1) and analysed by agarose (0.9%, w/v) gel electrophoresis. The assay is based on the
ability of free negatively-charged pDNA to migrate into the gel upon application of an electrical
field, whereas complexed pDNA lacks this property. The formation of the D19/DNA complexes as
evaluated in serum-free cell growth medium while C12-Man-Q/DNA complexes were evaluated both
in serum free cell growth medium and in the same medium supplemented with NaCl (0.15 M) at
various amphiphile/DNA (N/P) ratios. NaCl is an important component of most biological fluids,
including serum. Even-Chen et al. demonstrated that for cationic lipid compositions, the addition
of NaCl prevented lipoplex formation and induced partial dissociation between lipids and DNA of

Molecules 2018, 23, 1540
5 of 18
the preformed lipoplexes [40]. NaCl additive in transfection media was also used in our previous
studies for development of 1,4-DHP amphiphiles as pDNA delivery agents and evaluated 1,4-DHP
amphiphile D19 as a perspective delivery system [23,24].
The binding affinities of the studied 1,4-DHP amphiphiles D19 and C12-Man-Q are represented
in Figure 1. The efficiency of pDNA complexation increased, along with growing the amphiphile/DNA
complexes’ N/P ratio. The ability to complex the pDNA was approved by evident disappearance
of supercoiled and linear forms of the pDNA for both compounds. For compound D19 almost
all pDNA has been bound at N/P ratio of 2, which is in a good agreement with our previous
data [23
,24]. The effectiveness of 1,4-DHP derivative C12-Man-Q in lipoplex formation was influenced
by complexation media and decreased up to 20% in the presence of 0.15 M NaCl (Figure 1B). It was
confirmed that media significantly affected the complexation ability of compound C12-Man-Q
which was in agreement with other group conclusions, that transfection medium properties (ionic
strength, counterion species, and pH) were very important and affected cell surface and lipoplex
electrostatics [40].
,
Figure 1. pDNA (pEGFP-C1) and cationic amphiphiles affinity test obtained by gel electrophoresis
assay at various N/P (0.25–3) ratios. Supercoiled (sc) and linear (l) forms of plasmid DNA indicated
by arrows. (
A
) pDNA retardation assay: (
a
) for C12-Man-Q/pDNA complexes without NaCl; (
b) for
C12-Man-Q/pDNA complexes with 0.15 M NaCl; (c) for D19/pDNA complexes with NaCl; and (B)
quantification of the pDNA binding shift by densitometry (the percentage of the bonded supercoiled
DNA was assessed by the density of bands on agarose gel using the open-access image processing
program ImageJ) [41].
Among factors regulating the activity of transfection complexes, the size of the lipoplexes has
been reported to be a major determinant of transfection efficiency [42–44]. The morphology and
size of the lipoplexes formed by 1,4-DHP amphiphiles C12-Man-Q and D19 were analysed by the
transmission electron microscopy (TEM) technique. As seen in TEM images (Figure 2), lipoplexes
formed by the compound C12-Man-Q (Figure 2A) were quite uniform, about 50 nm in size and
resembled vesicular-like structures. In turn, lipoplexes produced by compound D19 (Figure 2B) were
of irregular shapes and these complexes varied in their size in the range 25–80 nm.

Molecules 2018, 23, 1540
6 of 18
Figure 2. Transmission electron microscopy (TEM) images of lipoplexes formed by cationic lipid and
pDNA (pEGFP-C1) at optimised N/P ratio. ( ) lipoplexes formed by amphiphile C12-Man-Q (N/P
) lipoplexes formed by amphiphile D19 (N/P ratio of 2). Scale bars represent
A
ratio of 0.9); and (
100 nm.
B
Obtained data about lipoplex sizes for compound D19 coincide well with previous results,
confirming that compound D19 and its structural analogues having different alkyl chains at
3,5-positions of 1,4-DHP and pCMV-βGal plasmid containing the β-galactosidase cDNA driven
by the CMV promoter formed lipoplexes with diameters in the range below 150 nm [23].
2.4. Cytotoxicoty Evaluation of 1,4-DHP/DNA Complexes
The cytotoxic effect of the lipoplexes formed by 1,4-DHP amphiphiles/DNA towards mammalian
cells was evaluated using colorimetric 3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyltetrazolium bromide
(MTT) assay [45]. The cells were treated with 1,4-DHP amphiphile/DNA complexes at various N/P
ratios. Obtained data for the viability of BHK-21 cells are presented in Figure 3.
Figure 3. Viability of BHK-21 cells (%) 24 h post transfection determined by MTT assay.
(A) C12-Man-Q/DNA complexes; (B) D19/DNA complexes. DNA-pEGFP-C1. For each value
of the N/P ratio three independent repeats were performed.
As shown in Figure 3, linear coherence between the used amount of 1,4-DHP amphiphiles and
the viability of BHK-21 cells is evident for both compounds. An increase of the N/P ratio means
decreasing cell viability. In general, lipoplexes formed by compound C12-Man-Q are more toxic to
cells, and the toxicity is increased when NaCl (0.15M) is used as an additive of lipoplex formation
medium (Figure 3A). Thus, lipoplexes of compound C12-Man-Q showed only 50% cell viability,
when the lowest N/P ratio of 1 was used. Cell viability results were improved when the transfection
complexes were prepared in medium without the addition of NaCl, giving 50% cell viability at an
N/P ratio of 2. In turn, lipoplexes formed by compound D19 (Figure 3B) showed minimal toxic

Molecules 2018, 23, 1540
7 of 18
effect on BHK-21 cells. Moreover, compound D19, evidently, does not affect cell division and, as a
result, cell viability values 24 h post transfection are even higher (above 100%) than that of control,
non-transfected cells.
It should be noted that evaluation of Cos-7 cell morphology after treatment with
C12-Man-Q/DNA (pEGFP-C1) lipoplexes (Figure 4A) does not reveal any signs of toxicity caused
by the used transfection reagent. Therefore, we could assume that different cell types might have
different responses to treatment by C12-Man-Q/DNA lipoplexes, thus proving that the optimal
transfection reagent for each cell line needs to be determined empirically. Synthesis of new series of
cationic amphiphiles differing in cationic substituents may lead to the development of new prospective
transfection reagents in the future.
Figure 4. Cos-7 cell morphology evaluated by fluorescent microscopy 24 h post transfection
with 1,4-DHP/DNA (pEGFP-C1) lipoplexes. (A) C12-Man-Q/DNA lipoplexes; and (B) D19/DNA
lipoplexes. Scale bars represent 100 µm.
2.5. Evaluation of Transfection Activity
To evaluate the efficiency of the compounds C12-Man-Q and D19 to deliver plasmid DNA into
mammalian cells, first, we performed a transient transfection of BHK-21 cell line. The expression vector
pRL-CMV was used to evaluate the transfection efficiency of the new transfection agent C12-Man-Q
at various N/P ratios. Increasing amounts of C12-Man-Q were mixed with 1 µg of pDNA to achieve
N/P ratios varying from 0.25 to 3.0, and transfection activity of the lipoplexes was assessed by the
luciferin-luciferase reaction test (Renilla luciferase assay system) [46]. Obtained data for transfection
activity of 1,4-DHP amphiphiles in BHK-21 cells are presented in Figure 5. According to the obtained
data lipoplexes formed by C12-Man-Q/DNA in media with NaCl additive demonstrated moderate,
yet steady, transfection efficiency beginning from an N/P ratio of 0.5 with no significant drop of the
activity along with the increase of N/P ratios up to 3.0 (Figure 5A, curve 2), and in media without NaCl
additive, maximal transfection efficiency at an N/P ratio of 0.9, gradually decreasing to an N/P ratio
of 3 (Figure 5A, curve 1). By the obtained data C12-Man-Q can be characterised as rather inefficient
in transfection of BHK-21 cells and, in this case, with completely different action compared with the
reference compound D19. Obtained data confirmed that the compound D19 showed dose-dependent
incensement of transfection activity at an N/P ratio of 2.4; after that, the activity slowly decreased
(Figure 5B). The maximum delivery activity of compound D19 exceeded the transfection activity of
C12-Man-Q by almost eight times in BHK-21 cells.
It was also noted earlier that the properties of the transfection medium (ionic strength, counter
ion species, and pH) are very important, because of the effect on cell surfaces and lipoplex
electrostatics [40,47], which confirms the NaCl additive’s influence on C12-Man-Q delivery efficiency.
A promising nonviral transfection gene delivery vehicle should have high transfection activity,
but also low cytotoxicity, as cellular damage is an important event accompanying transfection [48,49].
Furthermore, it has long been recognised that different transfection reagents cause different levels of
cytotoxicity in different cell lines [50].

Molecules 2018, 23, 1540
8 of 18
Figure 5. Transfection efficiency achieved using 1,4-DHP amphiphiles determined by luciferase enzyme
activity 24 h post transfection. ( ) Compound C12-Man-Q (1-without NaCl; 2-with NaCl additive);
and (B) compound D19. For each value of the N/P ratio three independent repeats were performed.
A
The influence of 1,4-DHP/DNA lipoplexes on BHK-21 cell morphology changes (24 h after
transfection) were evaluated by confocal fluorescent microscopy. The obtained data are presented at
Figure 6.
Figure 6. BHK-21 morphology changes (24 h after transfection) under the influence of lipoplexes of
C12-Man-Q
(
A
) and D19
(
B
) analysed by confocal fluorescent microscopy. Blue (DAPI)—nucleus of
m.
the cell, green EGFP expression in transfected cells transfection complex. Scale bars represent 100
µ
Confocal microscopy results revealed that both amphiphiles C12-Man-Q and D19 delivered a
green fluorescent protein expression plasmid into BHK-21 cells and produced a fluorescent EGFP signal
with satisfactory efficiency. However, for the new compound C12-Man-Q cytotoxicity of the preformed
transfection complexes (Figure 6A), revealed as distinct morphological changes (cell shrinkage) in
transfected BHK-21 cells, was one of the most important factors that negatively influenced 1,4-DHP
derivative C12-Man-Q transfection potential. Oppositely, the reference compound D19, as a part of the
transfection complex, did not affect the transfected cell morphology, as evidenced by the predominantly
uniform cytoplasmic distribution of EGFP fluorescence in cells (Figure 6B).
Simultaneously, we evaluated the influence of ionic strength of the complexation medium and
optimised the contact time between the lipoplex and the cell surface on cytotoxicity and transfection
efficiency of C12-Man-Q lipoplexes. Initially, the influence of ionic strength on BHK-21 cell morphology

Molecules 2018, 23, 1540
9 of 18
after transfection by C12-Man-Q/pEGFP-C1 lipoplexes were evaluated in the serum free media with
and without 0.15 NaCl additive [23]. The obtained data are presented in Figure 7.
Figure 7. Influence of the ionic strength of the lipoplex formation medium on BHK-21 cell morphology
changes 24 h after transfection by C12-Man-Q/pEGFP-C1 lipoplexes. (A) lipoplexes prepared in
medium containing 0.15 M NaCl; and ( ) lipoplexes prepared in medium without the addition of NaCl.
B
Green cells represent transfected cells, which express pEGFP. Scale bars represent 100 µm.
Comparison of the morphology of BHK-21 cells (Figure 7) transfected by C12-Man-Q/pEGFP-C1
lipoplexes showed the effect of NaCl on cell proliferation. The density of cells in the Figure 7A is
about 50% compared to Figure 7B, where the cell density is almost 100%. The NaCl effects on the cells
are seen at Figure 7. This effect has resulted in reduced cell viability and also led to the conclusion
that increments of ionic strength of complexation medium are the reason for the enhanced toxicity of
C12-Man-Q for BHK-21 cell (Figures 5 and 6).
The results revealed that C12-Man-Q lipoplexes transfection efficiency on BHK-21 cells could be
improved by decreasing the ionic strength of the lipoplex formation medium. As a result transfection
efficiency was increased up to three times, when NaCl was removed from the C12-Man-Q/DNA
complex formation medium (Figure 5A, curve 1). Thus, for an efficient BHK-21 cell transfection
the optimal complexation medium for compound C12-Man-Q was a serum-free medium without
NaCl and the highest transfection activity was achieved when the N/P ratio was 0.9; afterwards,
the transfection activity slowly decreased. These conditions were used for the following evaluation of
transfection efficiency for compound C12-Man-Q.
The optimal contact time between lipoplexes and transfecting cells is a rather complex parameter
and depends on several factors that influence lipoplex size and stability [51]. Contact time of
transfection complexes with cells ranges from 1 h to continuous exposure until the time of analysis [35].
In order to decrease the toxic impact of C12-Man-Q-formed lipoplexes on BHK-21 cells, the optimal
contact time of lipoplexes and cells was established. We performed correlation analysis to determine
whether the reduction of the contact time in half would cause a significant effect on transfection
efficiency. The obtained results are presented in Figure 8.
After analysis of the obtained data, it was concluded that there was no significant impact of
reducing the incubation time on transfection efficiency (Figure 8B). At the same time the significant
improvement of cell viability was observed (Figure 7). Thus, it could be concluded that complexation
time for lipoplexes prepared with compound C12-Man-Q can be reduced twice without any loss in
transfection efficiency, but with a minimisation to lipoplex cytotoxicity.
Optimisation of the key parameters of the transfection protocol allows us to maximize transfection
efficiency of the BHK-21 cells by C12-Man-Q-formed lipoplexes up to three times (Figure 9).

Molecules 2018, 23, 1540
10 of 18
Figure 8. Optimisation of the C12-Man-Q/pDNA (pRL-CMV) lipoplexes/cell contact time on BHK-21
cells; N/P ratio of 0.9; sample prepared without additional NaCl. ( ) The impact of the lipoplexes/cell
contact time on the cell viability, determined 24 h post transfection by MTT test; and ( ) the impact of
lipoplexes/cell contact time on transfection efficiency determined by luciferase enzyme activity.
A
B
Figure 9. Influence of transfection parameters (lipoplex formation medium and lipoplex/cell contact
time) on transfection efficiency of C12-Man-Q in BHK-21 cells in comparison to the reference compound
D19. (
100 m): (
transfection by C12-Man-Q after optimisation of the key parameters of the transfection protocol;
) transfection by the reference compound D19; (II): quantification of the influence of transfection
I
): evaluation of EGFP production in cells by fluorescent microscopy (scale bars represent
µ
A
) transfection by C12-Man-Q lipoplexes performed under standard conditions; (
B)
(
C
parameters was assessed by amount of fluorescent cells using the open-access image processing
program ImageJ.
Optimisation of the key parameters of the transfection protocol demonstrate that the 1,4-DHP
derivative C12-Man-Q also works as gene delivery agent though still inferior to the reference

Molecules 2018, 23, 1540
11 of 18
compound D19. Obtained information regarding structure-activity relationships will be helpful
for future design of DNA delivery agents on the base 1,4-DHP amphiphiles.
2.6. Cell Line-Dependent Differences in Transfection Efficiency of the New Amphiphilic 1,4-DHP Derivative
C12-Man-Q
Since transfection efficiency can significantly contrast among different cell lines, it is an absolute
perquisite to evaluate new nonviral gene delivery vehicle transfection efficiency in various cell lines.
In general, it was underlined that, in many cases, transfection efficiency mediated by nonviral vectors
is affected strongly by the cell type [52].
Thus, in addition to previously analysed BHK-21 and Cos7 cell lines, for evaluation of transfection
ability of the new potential gene delivery agent C12-Man-Q, cancer cell lines H2-35, B16 (both of
mouse origin), and MCF-7, HeLa, Huh-7, and HepG2 (of human origin) were chosen (Figures 10
and 11). The compound possessed moderate transfection efficiency, but was active in all cell lines used,
showing promising potential for in vivo applications. Results were compared with data obtained for
derivative D19 which is the most efficient among the previously studied 1,4-DHP derivatives [23–25].
Figure 10. Assessment of transfection efficiency of the C12-Man-Q lipoplexes in cancer cell lines by
fluorescent microscopy: B16 and H2-35 (both of mouse origin), and MCF-7 and HepG2 (human origin).
Scale bars reflect 100 µm.
Figure 11. The comparison of the transfection efficiency of the studied amphiphilic 1,4-DHP derivatives
C12-Man-Q and D19 in B16, H2-35, Cos-7, MCF-7, HeLa, Huh-7, and HepG2 cell lines. Image analysing
program ImageJ was used to count fluorescent cells in the field of view.
We used the open-access image analysing program ImageJ to count fluorescent cells in the field of
view (Figure 11). Compound D19 showed greater transfection efficiency to transfect cell lines BHK-21
(Figure 9); Cos-7 (Figure 11), but did not succeed in transfecting HepG2 and B16 cell lines.

Molecules 2018, 23, 1540
12 of 18
The compound C12-Man-Q showed rather high delivery activity in the case of H2-35 and
B16 cells, while towards other cell lines this compound displayed only modest activity (Figure 11).
The transfection efficiency in cell lines MCF-7, HeLa, and Huh-7 was found to be comparable to the
reference compound D19, while for the HepG2 cell line almost no activity was observed. In general,
there should be careful optimisation for every type of cell line because of differences in their metabolic
states, lipoplex uptake, and cell trafficking machineries.
3. Materials and Methods
3.1. General
All reagents were purchased from Acros Organics (Geel, Belgium) or Alfa Aesar (Lancashire, UK)
and used without purification. TLC was performed on Silica gel 60 F254 aluminium sheets 20
×
20 cm
(Merck KGaA, Darmstadt, Germany). 1H-NMR spectra were recorded with a Varian Mercury BB
(400 MHz) spectrometer and 13C-NMR spectra were recorded with a Varian Mercury BB (100.56 MHz)
spectrometer (Agilent, Santa Clara, CA, USA). The coupling constants are expressed in Hertz (Hz).
The chemical shifts of the hydrogen and carbon atoms are presented in parts per million (ppm) and
referred to the residual signals of the non-deuterated CDCl3 (d: 7.25) or partially-deuterated DMSO-d6
(d: 2.50) solvent for 1H-NMR spectra and CDCl3 (d: 77.0) or DMSO-d6 (d: 39.5) solvent for 13C-NMR,
respectively. Multiplicities are abbreviated as s = singlet; m = multiplet; br = broad. Mass spectral data
were determined on a Waters Acquity UPLC system (Waters, Milford, MA, USA) connected to a Waters
SQ Detector-2 operating in the ESI positive ion mode on a Waters Acquity UPLC® BEH C18 column
(1.7
µm, 2.1
×
50 mm) using a gradient elution with acetonitrile (0.01% trifluoroacetic acid) in water
(0.01% trifluoroacetic acid) at a flow rate of 0.5 mL/min. LC-MS data were recorded with a Waters
MassLynx 4.1 chromatography data system. Melting points (m.p.) of the synthesised compounds were
determined on an OptiMelt (SRS Stanford Research Systems, Sunnyvale, CA, USA). Elemental analyses
were determined on an Elemental Combustion System ECS 4010 (Costech Instruments, Pioltello, Italy).
Cell culture BHK-21 (baby hamster kidney fibroblast), Cos-7 (African green monkey kidney
fibroblast-like), HeLa (human cervix epithelial cells), HepG2 (human liver epithelial), H2-35 (mouse
liver hepatocytes), B16 (mouse melanoma), MCF-7 (human mammary gland adenocarcinoma), and
Huh-7 (human hepato cellular carcinoma) cell lines were used in this study. Cells were cultured
according to manufacturer’s (American Type Culture Collection (ATCC), Rockville, MD, USA and
Japanese Collection of Research Bioresources Cell Bank (JCRB), Osaka, Japan) provided guidelines at
37 ◦C and 5% CO2.
Plasmids/pEGFP-C1 (4731 bp) (Clontech, Takara, Tokyo, Japan) was used for most studies
(microscopy, complex formation assays). pRL-CMV (4079 bp) (Promega, Fitchburg, WI, USA) was used
for transfection efficiency quantification by luciferase reporter assay. Both plasmids were transformed
in Escherichia coli DH5
were purified by a QIAGEN the EndoFree Plasmid Purification kit (Hilden, Germany). The purified
plasmid DNA were dissolved in distilled water and stored at
20 ◦C. The purity and concentration
α
and amplified in E. coli grown in LB media at 37 ◦C for 16–18 h. Plasmids
−
of plasmid DNA were confirmed by a NanoDrop1000 spectrophotometer (Thermo Fischer Scientific
(Waltham, MA, USA), and plasmids DNA were identified by agarose gel electrophoresis.
3.2. Synthesis of compounds 1, 2 and D19 (Scheme 1)
Compounds
1
,
2
and D19. The 3,5-bis(dodecyloxycarbonyl)-2,6-dimethyl-4-phenyl-1,4-dihydropyrid
) and
ine ( ); 2,6-di(bromomethyl)-3,5-bis(dodecyloxycarbonyl)-4-phenyl-1,4-dihydropyridine (
1
2
1,10-[(3,5-didodecyloxycarbonyl-4-phenyl-1,4-dihydropyridine-2,6-diyl)dimethylen]-bispyridinium
dibromide (D19) were synthesised according to the previously-reported methods [23]. Briefly,
the elaborated synthesis of the cationic derivative D19 involves three sequential steps. The first step
was a synthesis of the starting 1,4-DHP derivative
the second involved the bromination of the methyl groups 2,6-dimethyl-1,4-DHP derivative
1
in a two-component Hantzsch-type cyclisation;
with
1

Molecules 2018, 23, 1540
13 of 18
N-bromosuccinimide (NBS); and the third step was the nucleophilic substitution of bromine of
1
compound
2
with pyridine yielding the target compound D19. H- and 13C-NMR spectra data of
compounds 1, 2, and D19 were identical to those reported in the literature [26].
Didodecyl 2,6-bis-(2-(N,N-dimethylamino)ethyl)-4-phenyl-1,4-dihydropyridine-3,5-dicarboxylate (
3). A mixture
of didodecyl 3,5-bis(dodecyloxycarbonyl)-2,6-dimethyl-4-phenyl-1,4-dihydropyridine (
1, 1.22 g,
2.00 mmol), paraformaldehyde (0.40 g, 0.01 eq, 0.02 mol), dimethylamine hydrochloride (0.98 g,
12.0 mmol), a conc. HCl (0.150 mL) and ethanol (10 mL) was refluxed for 24 h. The solvent was
removed by evaporation in vacuo, after which water (5 mL) was added. The pH of the resulting
mixture was adjusted to approx. 8 with an aqueous solution of sodium carbonate and extracted
with chloroform (6
×
30 mL). The organic layer was washed with brine and dried over MgSO4.
After removal of the solvent, the oily residue was obtained and purified by flash chromatography
(eluent: chloroform:acetone:methanol:Et3N = 9:4:2:0.02) yielding 0.75 g (68%) of light yellow foam. TLC:
Rf: 0.2 (CHCl3/MeOH/Et3N = 1:1:0.01). 1H-NMR (CDCl3):
δ
0.86–0.90 (m, 6H), 1.23–1.34 (m, 36H);
1.55–1.60 (m, 4H), 2.33 (s, 12H), 2.52–2.66 (m, 4H), 2.90–3.09 (m, 4H), 3.98–4.02 (m, 4H), 4.98 (s, 1H),
7.08–7.12 (m, 1H), 7.16–7.20 (m, 2H), 7.26–7.27 (m, 2H), 10.13 (s, 1H) ppm. 13C-NMR (CDCl3):
14.1,
δ
18.4, 22.7, 26.1, 27.8, 28.7, 29.3, 29.4, 29.5, 29.6, 29.7, 31.9, 37.0, 39.4, 44.7, 63.8, 69.2, 102.8, 125.9, 127.7,
127.8, 148.2, 148.3, 167.7 ppm. MS (+ESI) m/z (relative intensity); 725 ([M + H]+, 60). Anal. calcd. for
C45H77N3O4: C, 74.64; H, 10.72; N, 5.80; Found: C, 74.49; H, 10.55; N, 5.91.
N,N0-{[3,5-Bis(dodecyloxycarbonyl)-4-phenyl-1,4-dihydropyridine-2,6-diyl]diethylene}bis N,N-dimethyoctyl
ammonium dibromide (C12-Man-Q). A mixture of compound
3 (290 mg, 0.4 mmol, 1 eq) and
1-bromooctane (232 mg, 1.2 mmol, 3 eq) in nitromethane (3 mL) and DMF (0.5 mL) was refluxed
under argon for 48 h. The solvents were removed in vacuo and the residue was triturated with a small
amount of dry acetone. After cooling the precipitate was filtered off and crystallised from dry acetone
yielding compound C12-Man-Q as a light yellow powder (222 mg, 50%), mp 180–183 ◦C. 1H-NMR
(CDCl3):
δ 0.79–0.84 (m, 12H), 1.21–1.30 (m, 56H), 1.53 (br s, 4H), 1.60–1.87 (m, 8H), 3.22–3.38 (m,
2H)overlap, 3.36 (s, 12H)overlap, 3.48–3.56 (m, 2H), 3.65–3.73 (m, 2H), 3.85–3.97 (m, 4H), 4.24–4.35 (m,
2H), 4.74 (s, 1H), 7.04–7.08 (m, 1H), 7.12–7.15 (m, 2H), 7.20–7.26 (m, 2H)overlap with CDCl3, 10.02 (s,
1H) ppm. 13C-NMR (CDCl3):
δ 14.0, 14.1, 22.5, 22.6, 29.3, 29.6, 29.7, 31.9, 39.2, 51.3, 51.8, 61.6, 64.1, 64.7,
105.4, 126.4, 127.9, 128.0, 143.6, 147.2, 166.9 ppm. MS (+ESI) m/z (relative intensity); 950 ([M-2Br + H]+
10). Anal. calcd. for C61H111Br2N3O4: C, 65.98; H, 10.08; N, 3.78; Found: C, 65.71; H, 10.15; N, 3.72.
3.3. Calculation of Nitrogen to Phosphorus (N/P) Ratio
The N/P ratio is a measure of the ionic balance of the amphiphile/DNA complexes. The positive
charge (N) of amphiphile originates from the nitrogens of 1,4-DHP amphiphiles C12-Man-Q or D19
The negative charge (P) in the plasmid DNA backbone arises from the phosphate group of the
deoxyribose nucleotides. The average molecular weight of the nucleotides is assumed to be 330 g/mol.
.
Example of N/P ratio calculation: Complexation of 1
µg of plasmid DNA with C12-Man-Q at
N/P ratio 1, how much 0.5 mM of C12-Man-Q (VC12ManQneeded ) is needed?
N
P
1 × 10−6
=
= 3 × 10−9M = 3 nmol
= 1 × 3 = 3 µL
330
N = P × 1 = 3 × 1 = 3
VC12ManQ
needed
3.4. Preparation of Amphiphile/pDNA Complexes (Lipoplexes)
The amphiphile/pDNA complexes were prepared using various amounts of cationic lipid and
constant amount of pDNA, ensuring different N/P ratios. Firstly, cationic lipid and pDNA were
diluted separately in various transfection media: (a) medium without any supplements; and (b)

Molecules 2018, 23, 1540
14 of 18
medium without any supplements, with additional 0.15 M NaCl solution; we also compared the
complexes’ efficiency made in those media, just with reduced volume. Secondly, after a 5-min long
incubation time, diluted pDNA was added by droplets to diluted cationic reagent solution and the
whole mixture was then incubated at room temperature for 15 min.
Agarose gel retardation assay. The cationic amphiphile/pDNA complexes were prepared by adding
1 µg of DNA to different concentrations of 1,4-DHP derivatives to obtain different N/P charge
ratios. After gentle swirling, the mixtures were allowed to stand at room temperature for 10 min
prior to analysis. The lipoplexes were prepared in media containing additional 0.15 M NaCl (for
compounds D19 and C12-Man-Q) or in media without any additional supplements (for C12-Man-Q).
After incubation time, gel running buffer with bromophenol blue was added to the complexes and they
were loaded on 0.9% agarose gel in TAE buffer, pH 8. Voltage of 65 V was applied for 2.5 h. Following
EtBr staining DNA bands were visualised in an UV transilluminator and photographed (BioSpectrum
Imaging system, Upland, CA, USA).
3.5. In Vitro Transfection Experiment
Cells were seeded onto 24-well plates prior the experiment day with antibiotic-free media so that,
at the time of transfection, cells reached 70–80% confluency. The final lipoplexes volume was 200
or 100 L (in case the dilution volume was reduced) and the DNA were used at a concentration of
g/well. Before adding lipoplex solutions, old cell culture medium was removed and cells were
µL
µ
1
µ
washed once with serum-free medium, and the above 200 or 100 µL lipoplexes were added to each
well. Plates were incubated for 1.5 to 3 h at 37 ◦C in a humidified atmosphere containing 5% CO2.
At the end of the incubation period, into each well fresh medium containing 10% FBS was added.
Plates were further incubated for a period of 24 h before evaluating the expression of the reporter gene.
3.5.1. Cytotoxicity Assay
Cytotoxicity of lipoplexes towards used cells was determined using an MTT (3-(4,5-dimethylthiazo
l-2-yl)-2,5-diphenyltetrazolium bromide) reduction assay. Twenty-four hours post transfection, culture
medium was removed and cells were washed once with PBS. Then 270
µL of medium without
phenol red and 30 L of MTT solution (MTT powder was diluted into medium without phenol red
µ
in proportion—15 mg powder into 3 mL of medium) was added to each well. The plate was then
◦
incubated for 2 h at 37 C in a humidified atmosphere containing 5% CO2. After incubation time
300
µL of MTT solvent (10% Triton X-100, 0.1 N HCl anhydrous isopropanol, 125 mL) was added
to each well, and cells were suspended in order to promote dissolution of formed formazan crystals.
The absorbance was measured using an FL
VT, USA) at wavelengths of 570 and 690 nm.
×
800 fluorescence microplate reader (Biotek, Vernusky,
3.5.2. Assessment of Transfection’s Efficiency
For fluorescent microscopy assays, cells were transfected by complexes containing pEGFP-C1.
Twenty-four hours after the transfection, the microscope images were obtained at magnifications of
100
×
and 400 , recorded with Leica DC 150 camera system (Meyer Instruments Inc., Houston, TX,
×
USA) and processed with the open access image processing and analysing program ImageJ.
For luciferase assays, cells were transfected with complexes containing pRL-CMV. For a typical
assay in a 24-well plate, 24 h post transfection old medium was removed from the wells and the
cells were washed once with PBS. In accordance with the Renilla luciferase assay system (Promega,
USA) manufacturer, 100 µL of luciferase lysis buffer was then added to each well, and the cells
were lysed for 15 min at room temperature. The cell lysate was transferred to Eppendorf tubes and
◦
centrifuged (11,000 rpm for 10 min at 8 C). For the assay, 20
µL of this supernatant, and 50
µL
of luciferase assay substrate (Promega, USA), were used. The luciferase activity was measured in
a luminometer Thermo Luminoskan Ascent Reader (Thermo Fischer Scientific, USA) in standard
kinetic-luminiscence mode. The integration time of the measurement was 10 s, and a delay of 2 s

Molecules 2018, 23, 1540
15 of 18
was given before each measurement. Comparisons of transfection efficiency of various transfection
complexes was made based on data for luciferase expressed as relative light units (RLU), normalised
for 10,000 cells. All the experiments were done in triplicate, and the results presented are the average
of those independent experiments.
3.5.3. Sample Preparation for Confocal Laser Scanning Microscopy
BHK-21 cells were plated onto glass chamber slides for cytochemistry. After 24 h growing cells
were transfected with pEGFP-C1 using novel cationic compounds C12-Man-Q and D19. At 3–24 h
post transfection the cells were washed with PBS and fixed with 3.7% formaldehyde (Sigma-Aldrich,
USA) for 15 min at +37 ◦C. Cell nuclei were counterstained with DAPI (c = 4
µg/mL) (Sigma-Aldrich,
USA) for 7 min. ProLong® Antifade Kit (P7481) (Molecular Probes/Invitrogen, Eugene, OR, USA) was
used for cell mounting. Studies were performed by a Leica DM 6000 B microscope (Leica Microsystems
CMS GmbH, Wetzlar, Germany) with a Leica TCS SP2 SE AOBS® laser scanning confocal system (Leica
Microsystems CMS GmbH, Wetzlar, Germany).
3.5.4. Sample Preparation for Transmission Electron Microscopy Studies
Samples were prepared as described above (see: Preparation of Liposome/pDNA Complexes
(Lipoplexes)), however, DNA and cationic lipids were diluted into the water. The concentration
of cationic lipid for electron microscopy was 0.5
µg/µL and, therefore, we calculated the exact
amount of pDNA and the volume of cationic lipid. One drop of the sample was adsorbed to a
formvar carbon-coated copper grid and negatively stained with 1% aqueous solution of uranyl acetate.
The grids were examined with a JEM-1230 TEM (Jeol, Tokyo, Japan) at 100 kV.
3.6. Statistical Analysis
Data statistical analysis was performed using the open source programming language and
software environment for statistical computing and graphics program R [53]. Two sample t-test,
regression analysis, as well as analysis of covariance (ANCOVA), were performed. Statistical
significance was set at p < 0.05.
4. Conclusions
We tested and compared two novel cationic compounds, D19 and C12-Man-Q, on a 1,4-DHP core
as nonviral liposome-based transfection agents. A new amphiphilic 1,4-DHP derivative, C12-Man-Q
,
was synthesised with more remoted cationic moieties at positions 2 and 6 than for the parent compound
D19. Additionally, instead of aromatic pyridinium moieties, aliphatic ammonium moieties were
introduced into the C12-Man-Q molecule as cationic headgroups. The results were compared with
data obtained for cationic 1,4-DHP derivative D19, which is known to be the most efficient one among
the previously tested 1,4-DHP amphiphiles. In this study we evaluated the effects of C12-Man-Q
concentration, complexation media, and complex contact time on the gene delivery effectiveness and
cell viability.
Obtained data confirmed that both cationic 1,4-DHP derivatives have the ability to bind pDNA,
though their performance of transfecting cells differ significantly. To increase transfection efficiency
and reduce toxic cell effects of compound C12-Man-Q we found the optimal transfection complex
preparation medium (without any supplements) and reduced the transfection complex/cell contact
time to 1.5 h. We also explored an optimal N/P ratio of 0.9 for this compound, when transfection
efficiency was quite good, and cell viability after transfection was also within the acceptable range.
We evaluated the transfection activity of lipoplexes formed by 1,4-DHP derivatives D19 and
C12-Man-Q with pDNA in various cell lines: BHK-21, Cos7, H2-35, B16, MCF-7, HeLa, Huh-7, and
HepG2. The most significant property of compound C12-Man-Q is its moderate, but still steady,
ability to transfect many cell lines, with higher effectiveness in the case of H2-35 and B16 cell lines.
The experimental results showed that compound C12-Man-Q effectively delivered plasmid DNA

Molecules 2018, 23, 1540
16 of 18
into many eukaryotic cell lines, while compound D19 was defined as cell type specific and possesses
higher transfection efficiency in the case of BHK-21 and Cos-7 cell lines.
Author Contributions: B.V. and T.K. conceived and designed the experiments; G.A. I.T., A.V., B.V., M.R., M.P., and
A.S. performed the experiments; K.P., M.P., A.V., G.A., and A.P. analysed the data; I.T., K.P., and A.S. contributed
reagents/materials/analysis tools; and A.P., G.A., and T.K. wrote the paper.
Funding: This research was funded by the National Research programme “Biomedicine for Public
Health” (BIOMEDICINE) (2014–2017): Project: No 3 “Development of novel anticancer drugs and
immunotherapeutic approaches”.
Acknowledgments: We are indebted to Dr.habil. V.Ose for transmission electron microscopy analysis.
Conflicts of Interest: The authors declare no conflict of interest.
References and Note
1.
2.
Wirth, T.; Parker, N.; Ylä-Herttuala, S. History of gene therapy. Gene 2013, 525, 162–169. [CrossRef] [PubMed]
Foldvari, M.; Chen, D.W.; Nafissi, N.; Calderon, D.; Narsineni, L.; Rafiee, A. Non-viral gene therapy: Gains
and challenges of non-invasive administration methods. J. Control. Release 2016, 240, 165–190. [CrossRef]
[PubMed]
3.
4.
5.
6.
7.
Keeler, A.M.; ElMallah, M.K.; Flotte, T.R. Gene Therapy 2017: Progress and Future Directions.
Clin. Transl. Sci. 2017, 10, 242–248. [CrossRef] [PubMed]
Cox, D.B.T.; Platt, R.J.; Zhang, F. Therapeutic genome editing: Prospects and challenges. Nat. Med. 2015, 21,
121. [CrossRef] [PubMed]
Khan, S.; Ullah, M.W.; Siddique, R.; Nabi, G.; Manan, S.; Yousaf, M.; Hou, H. Role of Recombinant DNA
Technology to Improve Life. Int. J. Genom. 2016, 2016, 14. [CrossRef] [PubMed]
Scholz, C.; Wagner, E. Therapeutic plasmid DNA versus siRNA delivery: Common and different tasks for
synthetic carriers. J. Control. Release 2012, 161, 554–565. [CrossRef] [PubMed]
Wang, K.; Kievit, F.M.; Zhang, M. Nanoparticles for cancer gene therapy: Recent advances, challenges, and
strategies. Pharmacol. Res. 2016, 114, 56–66. [CrossRef] [PubMed]
8.
9.
El-Aneed, A. Current strategies in cancer gene therapy. Eur. J. Pharmacol. 2004, 498, 1–8. [CrossRef] [PubMed]
Morille, M.; Passirani, C.; Vonarbourg, A.; Clavreul, A.; Benoit, J.-P. Progress in developing cationic vectors
for non-viral systemic gene therapy against cancer. Biomaterials 2008, 29, 3477–3496. [CrossRef] [PubMed]
10. Li, S.; Huang, L. Nonviral gene therapy: Promises and challenges. Gene Ther. 2000, 7, 31–34. [CrossRef]
[PubMed]
11. Lv, H.; Zhang, S.; Wang, B.; Cui, S.; Yan, J. Toxicity of cationic lipids and cationic polymers in gene delivery.
J. Control. Release 2006, 114, 100–109. [CrossRef] [PubMed]
12. Knudsen, K.B.; Northeved, H.; Kumar Ek, P.; Permin, A.; Gjetting, T.; Andresen, T.L.; Larsen, S.;
Wegener, K.M.; Lykkesfeldt, J.; Jantzen, K.; et al. In vivo toxicity of cationic micelles and liposomes.
Nanomedicine 2015, 11, 467–477. [CrossRef] [PubMed]
13. Anson, D.S. The use of retroviral vectors for gene therapy-what are the risks? A review of retroviral
pathogenesis and its relevance to retroviral vector-mediated gene delivery. Genet. Vaccines Ther. 2004, 2, 9–10.
[CrossRef] [PubMed]
14. Wu, T.-L.; Ertl, H.C.J. Immune barriers to successful gene therapy. Trends Mol. Med. 2009, 15, 32–39.
[CrossRef] [PubMed]
15. Keles, E.; Song, Y.; Du, D.; Dong, W.-J.; Lin, Y. Recent progress in nanomaterials for gene delivery applications.
Biomater. Sci. 2016, 4, 1291–1309. [CrossRef] [PubMed]
16. Zhou, Z.; Liu, X.; Zhu, D.; Wang, Y.; Zhang, Z.; Zhou, X.; Qiu, N.; Chen, X.; Shen, Y. Nonviral cancer gene
therapy: Delivery cascade and vector nanoproperty integration. Adv. Drug Deliv. Rev. 2017, 115, 115–154.
[CrossRef] [PubMed]
17. Prakash, K.P.; Arabinda, C. Cationic liposomes as non-viral carriers of gene medicines: Resolved issues,
open questions, and future promises. Med. Res. Rev. 2007, 27, 696–722. [CrossRef]
18. Koynova, R.; Tenchov, B. Enhancing nucleic acid delivery, insights from the cationic phospholipid carriers.
Curr. Pharm. Biotechnol. 2014, 15, 806–813. [CrossRef] [PubMed]

Molecules 2018, 23, 1540
17 of 18
19. Parvizi, P.; Jubeli, E.; Raju, L.; Khalique, N.A.; Almeer, A.; Allam, H.; Manaa, M.A.; Larsen, H.; Nicholson, D.;
Pungente, M.D.; et al. Aspects of nonviral gene therapy: Correlation of molecular parameters with lipoplex
structure and transfection efficacy in pyridinium-based cationic lipids. Int. J. Pharm. 2014, 461, 145–156.
[CrossRef] [PubMed]
20. Ibraheem, D.; Elaissari, A.; Fessi, H. Gene therapy and DNA delivery systems. Int. J. Pharm. 2014, 459, 70–83.
[CrossRef] [PubMed]
21. Hiwale, A.A.; Voshavar, C.; Dharmalingam, P.; Dhayani, A.; Mukthavaram, R.; Nadella, R.; Sunnapu, O.;
Gandhi, S.; Naidu, V.G.M.; Chaudhuri, A.; et al. Scaling the effect of hydrophobic chain length on gene
transfer properties of di-alkyl, di-hydroxy ethylammonium chloride based cationic amphiphiles. RSC Adv.
2017, 7, 25398–25405. [CrossRef]
22. Tirzite, D.; Koronova, J.; Plotniece, A. Influence of some quaternised 1,4-dihydropyridine derivatives on
liposomes and erythrocyte membranes. Biochem. Mol. Biol. Int. 1998, 45, 849–856. [PubMed]
23. Hyvonen, Z.; Plotniece, A.; Reine, I.; Chekavichus, B.; Duburs, G.; Urtti, A. Novel cationic amphiphilic
1,4-dihydropyridine derivatives for DNA delivery. Biochim. Biophys. Acta Biomembr. 2000, 1509, 451–466.
[CrossRef]
24. Pajuste, K.; Hyvonen, Z.; Petrichenko, O.; Kaldre, D.; Rucins, M.; Cekavicus, B.; Ose, V.; Skrivele, B.;
Gosteva, M.; Morin-Picardat, E.; et al. Gene delivery agents possessing antiradical activity: Self-assembling
cationic amphiphilic 1,4-dihydropyridine derivatives. New J. Chem. 2013, 37, 3062–3075. [CrossRef]
25. Petrichenko, O.; Rucins, M.; Vezane, A.; Timofejeva, I.; Sobolev, A.; Cekavicus, B.; Pajuste, K.; Plotniece, M.;
Gosteva, M.; Kozlovska, T.; et al. Studies of the physicochemical and structural properties of self-assembling
cationic pyridine derivatives as gene delivery agents. Chem. Phys. Lipids 2015, 191, 25–37. [CrossRef]
[PubMed]
26. Pajuste, K.; Plotniece, A.; Kore, K.; Intenberga, L.; Cekavicus, B.; Kaldre, D.; Duburs, G.; Sobolev, A. Use of
pyridinium ionic liquids as catalysts for the synthesis of 3,5-bis(dodecyloxycarbonyl)-1,4-dihydropyridine
derivative. Cent. Eur. J. Chem. 2011, 9, 143–148. [CrossRef]
27. Aritomi, J.; Ueda, S.; Nishimura, H. Mannich Reaction of Dihydropyridine Derivatives. I. Reactions with
Secondary Amines. Chem. Pharm. Bull. 1980, 28, 3163–3171. [CrossRef]
28. Both compounds were analysed by HPLC on a Zorbax CN (5
µ
m,4.6
×
250 mm, Agilent, Santa Clara, CA,
USA) column using a mobile phase of acetonitrile/0.05 M phosphate buffer, pH 2 (80:20 by volume) at a
flow rate of 1.5 mL/min with detection at UV 210 nm. Under the conditions analysed, the retention times of
D-19 and C12-Man-Q were 5.5 and 3.3 min, respectively.
29. Hardee, C.L.; Arévalo-Soliz, L.M.; Hornstein, B.D.; Zechiedrich, L. Advances in non-viral DNA vectors for
gene therapy. Genes 2017, 8. [CrossRef] [PubMed]
30. Wang, Z.; Jin, L.; Yuan, Z.; We˛grzyn, G.; We˛grzyn, A. Classification of plasmid vectors using replication
origin, selection marker and promoter as criteria. Plasmid 2009, 61, 47–51. [CrossRef] [PubMed]
31. Román, R.; Miret, J.; Scalia, F.; Casablancas, A.; Lecina, M.; Cairó, J.J. Enhancing heterologous protein
expression and secretion in HEK293 cells by means of combination of CMV promoter and IFNα2 signal
peptide. J. Biotechnol. 2016, 239, 57–60. [CrossRef] [PubMed]
32. Prasher, D.C.; Eckenrode, V.K.; Ward, W.W.; Prendergast, F.G.; Cormier, M.J. Primary structure of the
Aequorea victoria green-fluorescent protein. Gene 1992, 111, 229–233. [CrossRef]
33. Chalfie, M.; Tu, Y.; Euskirchen, G.; Ward, W.W.; Prasher, D.C. Green fluorescent protein as a marker for gene
expression. Science 1994, 263, 802–805. [CrossRef] [PubMed]
34. Inouye, S.; Tsuji, F.I. Evidence for redox forms of the Aequorea green fluorescent protein. FEBS Lett. 1994
351, 211–214. [CrossRef]
,
35. Van Gaal, E.V.B.; van Eijk, R.; Oosting, R.S.; Kok, R.J.; Hennink, W.E.; Crommelin, D.J.A.; Mastrobattista, E.
How to screen non-viral gene delivery systems in vitro? J. Control. Release 2011, 154, 218–232. [CrossRef]
[PubMed]
36. Van Gaal, E.V.B.; Oosting, R.S.; van Eijk, R.; Bakowska, M.; Feyen, D.; Kok, R.J.; Hennink, W.E.;
Crommelin, D.J.A.; Mastrobattista, E. DNA Nuclear Targeting Sequences for Non-Viral Gene Delivery.
Pharm. Res. 2011, 28, 1707–1722. [CrossRef] [PubMed]
37. Hofland, H.E.; Shephard, L.; Sullivan, S.M. Formation of stable cationic lipid/DNA complexes for gene
transfer. Proc. Natl. Acad. Sci. USA 1996, 93, 7305–7309. [CrossRef] [PubMed]

Molecules 2018, 23, 1540
18 of 18
38. Doyle, S.R.; Chan, C.K. Differential intracellular distribution of DNA complexed with polyethylenimine
(PEI) and PEI-polyarginine PTD influences exogenous gene expression within live COS-7 cells.
Genet. Vaccines Ther. 2007, 5, 11. [CrossRef] [PubMed]
39. De los Milagros Bassani Molinas, M.; Beer, C.; Hesse, F.; Wirth, M.; Wagner, R. Optimizing the transient
transfection process of HEK-293 suspension cells for protein production by nucleotide ratio monitoring.
Cytotechnology 2014, 66, 493–514. [CrossRef] [PubMed]
40. Even-Chen, S.; Cohen, R.; Barenholz, Y. Factors affecting DNA binding and stability of association to cationic
liposomes. Chem. Phys. Lipids 2012, 165, 414–423. [CrossRef] [PubMed]
41. Schneider, C.A.; Rasband, W.S.; Eliceiri, K.W. NIH Image to ImageJ: 25 years of image analysis. Nat. Methods
2012, 9, 671. [CrossRef] [PubMed]
42. Ross, P.C.; Hui, S.W. Lipoplex size is a major determinant of in vitro lipofection efficiency. Gene Ther. 1999, 6,
651. [CrossRef] [PubMed]
˙
43. Rak, M.; Ochałek, A.; Bielecka, E.; Latasiewicz, J.; Gawarecka, K.; Sroka, J.; Czyz, J.; Piwowarczyk, K.;
Masnyk, M.; Chmielewski, M.; et al. Efficient and non-toxic gene delivery by anionic lipoplexes based on
polyprenyl ammonium salts and their effects on cell physiology. J. Gene Med. 2016, 18, 331–342. [CrossRef]
[PubMed]
44. Oskuee, R.K.; Mahmoudi, A.; Gholami, L.; Rahmatkhah, A.; Malaekeh-Nikouei, B. Cationic Liposomes
Modified with Polyallylamine as a Gene Carrier: Preparation, Characterization and Transfection Efficiency
Evaluation. Adv. Pharm. Bull. 2016, 6, 515–520. [CrossRef] [PubMed]
45. Tolosa, L.; Donato, M.T.; Gómez-Lechón, M.J. General Cytotoxicity Assessment by Means of the MTT Assay.
In Protocols in In Vitro Hepatocyte Research; Vinken, M., Rogiers, V., Eds.; Springer: New York, NY, USA, 2015;
pp. 333–348.
46. Smale, S.T. Luciferase Assay. Cold Spring Harbor Protoc. 2010, 2010, 2010. [CrossRef] [PubMed]
47. Meidan, V.M.; Cohen, J.S.; Amariglio, N.; Hirsch-Lerner, D.; Barenholz, Y. Interaction of oligonucleotides with
cationic lipids: The relationship between electrostatics, hydration and state of aggregation1. Biochim. Biophys.
Acta Biomembr. 2000, 1464, 251–261. [CrossRef]
48. Zuhorn, I.S.; Hoekstra, D. On the Mechanism of Cationic Amphiphile-mediated Transfection. To Fuse or not
to Fuse: Is that the Question? J. Membr. Biol. 2002, 189, 167–179. [CrossRef] [PubMed]
49. Hoekstra, D.; Rejman, J.; Wasungu, L.; Shi, F.; Zuhorn, I. Gene delivery by cationic lipids: In and out of an
endosome. Biochem. Soc. Trans. 2007, 35, 68–71. [CrossRef] [PubMed]
50. Jacobsen, L.B.; Calvin, S.A.; Lobenhofer, E.K. Transcriptional effects of transfection: The potential for
misinterpretation of gene expression data generated from transiently transfected cells. BioTechniques 2009
47, 617–624. [CrossRef] [PubMed]
,
51. Ma, B.; Zhang, S.; Jiang, H.; Zhao, B.; Lv, H. Lipoplex morphologies and their influences on transfection
efficiency in gene delivery. J. Control. Release 2007, 123, 184–194. [CrossRef] [PubMed]
52. Sakaguchi, N.; Kojima, C.; Harada, A.; Koiwai, K.; Kono, K. The correlation between fusion capability and
transfection activity in hybrid complexes of lipoplexes and pH-sensitive liposomes. Biomaterials 2008, 29,
4029–4036. [CrossRef] [PubMed]
53. R Core Team. R: A Language and Environment for Statistical Computing; R Foundation for Statistical Computing:
Vienna, Austria, 2013; Available online: http://www.R-project.org/ (accessed on 30 April 2018).
Sample Availability: Samples of the compounds D19 and C12-Man-Q are available from the authors.
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
