Synthesis and reductive elimination of arylPd(II)
trifluoromethyl complexes: a remarkable
concentration effect on chemoselectivity†
Cite this: Phys.Chem.Chem.Phys.,
2016, 18, 32664
Received 17th October 2016,
Accepted 15th November 2016
Song-Lin Zhang* and Zhu-Qin Deng
DOI: 10.1039/c6cp07093k
www.rsc.org/pccp
Reductive elimination from Pd(II) aryl trifluoromethyl complexes is a such as Ar–Ar, Ar–F and P–F coupling products are often
challenging and elusive step which is accompanied by a number of observed.4–6 Furthermore, the origins of the byproducts are still
kinetically more favorable side reactions giving rising to a complex elusive and convincing experimental evidence has been scarcely
mixture. We report herein the synthesis and isolation of several disclosed to fully elucidate the kinetics and mechanisms. It is
arylPd(II) trifluoromethyl complexes (2a–c) and study their electronic only in very recent years that limited success has been achieved
structures, photophysical properties and reductive elimination by Buchwald, Grushin and Shoenebeck et al.5 In their reports,
reactivities. A remarkable concentration effect on chemoselectivity the key point for success is the search for an efficient ancillary
is observed for thermal decomposition of (Xantphos)Pd(II)(Ar)(CF3) ligand due to its unique steric and/or electronic properties to
(2c) that favors the formation of Ar–CF3 at lower concentrations, promote the desired Ar–CF3 reductive elimination.
but gives increasingly more Ar–Ar homocoupling product to a
As part of our continuous efforts on trifluoromethylation
dominant extent as the concentration of 2c increases. This is solid reactions, we recently prepared a few key Pd and Cu trifluoro-
evidence for the involvement of an intermolecular Ar/CF3 ligand methyl intermediates and investigated their reactivity properties
exchange/Ar–Ar reductive elimination mechanism that has been in combination with DFT computational studies.7–9 The results
proposed based on DFT computational studies. The interplay between of our DFT study on the rationalization of the difficulties of
theory and experiment provides valuable insights into the mechanism reductive elimination from ArPd(II) CF3 complexes containing an
and kinetics of the key elementary reaction of reductive elimination at ordinary bisphosphine ligand proposed that bimolecular Ph/CF3
Pd(II), and may thus prompt the design of more efficient Pd-mediated ligand exchange and subsequent Ph–Ph reductive elimination
nucleophilic trifluoromethylation reactions.
might be a significant kinetically favorable side pathway for
(ethylenediphosphine)Pd(II)(Ph)(CF3) model complex.10 Furthermore,
Transition metal-mediated trifluoromethylation reactions are a for (Xantphos)Pd(II)(para-CF3-Ph)(CF3) complex, the biomolecular
useful tool for preparing fluorinated compounds widely used in ligand exchange is even exergonic by 4.4 kcal molꢀ1, giving
pharmaceuticals, agrochemicals and organic materials.1 Particularly, (Xantphos)Pd(II)(Ar)2 and (Xantphos)Pd(II)(CF3)2 (Scheme 1).
Pd- and Cu-promoted aromatic trifluoromethylation reactions have Reductive elimination from (Xantphos)Pd(II)(Ar)2 requires only
occupied a dominant position.2,3 It has been generally accepted that a low activation barrier of 8.0 kcal molꢀ1, that is largely lower
reductive elimination from arylPd(II) trifluoromethyl complexes than the activation barrier of 23.2 kcal molꢀ1 required for direct
is a key product-releasing elementary step of the catalytic cycle Ar–CF3 reductive elimination (Scheme 1).11 This would give rise
for Pd-mediated nucleophilic aromatic trifluoromethylation to the decreased formation of the desired Ar–CF3 cross-coupling
reactions. However, reductive elimination of Ar–CF3 from product and the appearance of a significant bisaryl byproduct.
arylPd(II) trifluoromethyl complexes with most ancillary ligands
Inspired by these results, we hypothesized that high concen-
is known to be kinetically unfavorable and several byproducts tration of ArPd(II) CF3 complexes should, in principle, accelerate
bimolecular ligand exchange as a result of statistically greater
probability of intermolecular collision. This should accordingly
promote the formation of bisaryl and simultaneously diminish
the formation of Ar–CF3. Herein, we present, for the first time,
solid experimental evidence proving this hypothesis by the
amazing observation that the concentration dictates the chemo-
selectivity of Ar–CF3 cross-coupling versus Ar–Ar homocoupling.
The Key Laboratory of Food Colloids and Biotechnology, Ministry of Education,
School of Chemical and Material Engineering, Jiangnan University, Wuxi 214122,
Jiangsu Province, China. E-mail: slzhang@jiangnan.edu.cn; Fax: +86-510-85917763;
Tel: +86-510-85917763
† Electronic supplementary information (ESI) available: Experimental details,
spectroscopic characterization data, X-ray crystallographic study, general procedure for
thermal decomposition of 2c and DFT computational details. CCDC 1446596. For ESI
and crystallographic data in CIF or other electronic format see DOI: 10.1039/c6cp07093k It should be emphasized that the concentration effect on the
32664 | Phys. Chem. Chem. Phys., 2016, 18, 32664--32667
This journal is ©the Owner Societies 2016

View Article Online
Communication
PCCP
respectively. Furthermore, there are fine splittings of the two 19F
signals in 2b–c due to the presence of P–F coupling between the
bisphosphine P atoms and metal-bound CF3. Similarly, this P–F
coupling is also reflected in the 31P NMR spectroscopy for 2b–c,
leading to fine splitting of the 31P signals (for more details on NMR
spectroscopic data, please refer to the ESI†).
The crystal structure of complex 2c can further be obtained
by X-ray crystallographic diffraction analysis.13 As shown by
Fig. 1, complex 2c clearly shows a square planar geometry with
cis-orientation of the CF3 and Ar ligands (Fig. 1) and is in good
agreement with 19F and 31P NMR spectroscopy. The Pd–CF3 and
Pd–Ar bond lengths are 2.066(6) and 2.030(6) Å. The CF3–Pd–Ar
bond angle is only 80.7(3) degrees, which should be attributed
to the large bite angle of Xantphos that forces the approach of
Ar and CF3 ligands.
Scheme 1 Direct reductive elimination versus bimolecular Ar/CF3
exchange/Ar–Ar homocoupling for arylPd(II) trifluoromethyl complexes.
Values in parentheses are relative free energies in toluene in kcal molꢀ1
.
To further understand the electronic structure of complexes
2a–c, UV-vis absorption spectra of 2a–c were determined
(Fig. 2). Complexes 2a–c all exhibit dominant maximum
absorption at ca. 228 nm in the UV region that are attributed
to p–p* transitions of the ancillary ligands. Notably, 2a has two
additional minor yet significant lower-energy absorption bands
at 302 and 314 nm, which are almost negligible for 2b and 2c.
This suggests significant metal-to-ligand charge transfer for 2a
product chemoselectivity for the reductive elimination of aryl
Pd(II) CF3 complexes has never been reported. The interplay
between theory and experiment rationalizes the origins of the
Ar–Ar side products and more importantly adds another important
mechanistic aspect—namely, concentration effect of the substrate
in addition to the ancillary ligand effect—for improving Ar–CF3
reductive elimination from Pd(II). The valuable and convincing
insights into the mechanism and kinetics of the key elementary
reaction of reductive elimination at Pd(II) may thus prompt the
design of more efficient Pd-mediated nucleophilic trifluoro-
methylation reactions.
Complexes 1a–c with the corresponding ligand of bpy, BINAP
and Xantphos were prepared by oxidative addition of para-
trifluoromethylphenyl iodide with Pd(dba)2 in toluene or THF
(Scheme 2).12 Treatment of 1a–c with CF3SiMe3 as the CF3
source in the presence of AgF at room temperature produced
the desired ArPd(II) CF3 complexes 2a–c. After workup and
recrystallization, 2a–c were obtained in isolated yields of 69%,
72% and 67%, respectively (for more details on synthesis and
purification, please refer to the ESI†).
Complexes 1a–c and 2a–c were fully characterized by 1H, 19F,
31P NMR spectroscopy. For instance, 19F NMR spectra of 1a–c
show only one resonance at ca. ꢀ62 ppm, attributed to the
1
atromatic CF3. H NMR spectra are consistent with coordinating
Fig. 1 ORTEP drawing of complex 2c with thermal ellipsoids at 50%
probability. All the hydrogen atoms and solvent molecules are omitted
for clarity. Disorders of fluorine atoms are removed for clarity for the
aromatic CF3 substituent.
bpy, BINAP and Xantphos which are substantially low-field shifted
in the aromatic region compared to the free ligands. For 2a–c,
there are consistently two 19F resonances at ca. ꢀ21 and ꢀ62 ppm,
corresponding to the metal-bound CF3 and aromatic CF3 ligands,
Fig. 2 UV-vis absorption spectra of complexes 2a–c at a concentration
Scheme 2 Synthesis and reactivity of (L)Pd(II)(Ar)(CF3) complexes 2a–c.
of 10ꢀ5 M in CH2Cl2.
