Synthesis and modification of poly(ethyl 2-(imidazol-1-yl)acrylate) (PEImA)

Article abstract of DOI:10.1016/j.polymer.2017.08.058

We present the synthesis and characterization of poly(ethyl 2-(imidazol-1-yl)acrylate) (PEImA) using free radical polymerization in various solvents with and without acids as additive. In addition, PEImA was also prepared using anionic polymerization with

Full text of DOI:10.1016/j.polymer.2017.08.058

Accepted Manuscript
Synthesis and modification of Poly(ethyl 2-(imidazol-1-yl)acrylate) (PEImA)
C. Rössel, M. Billing, H. Görls, G. Festag, M. Grube, P. Bellstedt, I. Nischang, F.H.
Schacher
PII:
S0032-3861(17)30845-5
10.1016/j.polymer.2017.08.058
JPOL 19960
DOI:
Reference:
To appear in: Polymer
Received Date: 8 June 2017
Revised Date: 25 August 2017
Accepted Date: 26 August 2017
Please cite this article as: Rössel C, Billing M, Görls H, Festag G, Grube M, Bellstedt P, Nischang I,
Schacher FH, Synthesis and modification of Poly(ethyl 2-(imidazol-1-yl)acrylate) (PEImA), Polymer
(2017), doi: 10.1016/j.polymer.2017.08.058.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT
Synthesis and Modification of Poly(ethyl 2-
(
imidazol-1-yl)acrylate) (PEImA)
1
,2
1,2
3
1,2
1,2
1,3
1,2
C. Rössel , M. Billing , H. Görls , G. Festag ,M. Grube , P. Bellstedt , I. Nischang , F. H.
1
,2,
Schacher *
1
Laboratory of Organic and Macromolecular Chemistry, Friedrich Schiller University Jena,
Humboldtstr. 10, D-07743 Jena, Germany; felix.schacher@uni-jena.de
2
Jena Center for Soft Matter (JCSM), Friedrich Schiller University Jena, Philosophenweg 7, D-07743
Jena, Germany
3
Laboratory of Inorganic and Analytical Chemistry, Friedrich Schiller University Jena, Humboldtstr. 8,
D-07743 Jena, Germany
th
Dedicated to Prof. Axel H. E. Müller on the occasion of his 70 birthday

ACCEPTED MANUSCRIPT
Abstract
We present the synthesis and characterization of poly(ethyl 2-(imidazol-1-yl)acrylate) (PEImA) using
free radical polymerization in various solvents with and without acids as additive. In addition, PEImA
was also prepared using anionic polymerization with KOtBu as initiator in DMF and in THF at different
1
M:I ratios. The resulting polymers of moderate dispersity were characterized by H-NMR, solid state
1
3
C-NMR, and size exclusion chromatography (SEC) both in water and DMAc. PEImA is an interesting
highly substituted polymer as it can be modified by methylation to poly(ethyl 2-(methyl imidazolium-
-yl iodide)acrylate) PEMeImA, via ester cleavage into the polyzwitterion poly(2-(imidazol-1-yl)acrylic
1
acid) (PImAA), and – finally - to poly(2-(methyl imidazolium-1-yl)acrylic acid) (PMeImAA) if both
modification steps are carried out. We also investigated structure and solubility of these different
polyelectrolytes using potentiometric titration in aqueous media.
Table of contents graphic:

ACCEPTED MANUSCRIPT
Introduction
Polyelectrolytes are macromolecules containing ionizable groups along the polymer backbone or
[
1,2]
within the side chain.
Depending on the nature of the functional group, such material can be
further subdivided into weak or strong polycations or polyanions. In contrary to strong
polyelectrolytes which are completely ionized over the full range of commonly accessible pH values,
[
3]
the charge density of weak polyelectrolytes depends on the solution pH. Typical examples are
[
4]
[5]
poly(methacrylic acid) (PMAA) , poly(2-(dimethylamino)ethyl methacrylate) (PDMAEMA) ,
[
6]
[7]
poly(ethylenimine) (PEI) and poly(vinylimidazole) (PVIm) . There are many possible applications of
polyelectrolytes such as oil recovery, mineral processing, as stabilizers in emulsion polymerizations
and as flocculation or coagulation agents and this explains the constant and broad interest in both
[
8,9]
the synthesis as well as modification of such materials.
In addition, especially cationic
polyelectrolytes are of interest as potential non-viral gene transfection agents due to their ability to
[
10]
reversibly bind and release DNA or RNA.
If both cationic and anionic charges are present within a macromolecule, such materials are termed
polyampholytes and these examples are of interest for sewage treatment, metals binders (e.g. Ni, Cu
or Cd), water purification, paper reinforcement, as antifouling coatings or in cosmetic
[
11,12]
formulations.
If both charges are located within the same monomer unit, polyzwitterions as
subclass of polyampholytes are formed and can further be subdivided into poly(sulfobetaine)s,
poly(phosphobetaine)s and poly(carboxybetaine)s – depending on the nature of the negatively
charged group. Especially in the latter case, the overall ratio of positive and negative charges can
[
11,13]
further be adjusted by variation of the pH value.
One further example for a polyzwitterion with
tunable charge is poly(dehydroalanine) (PDha), which exhibits varying charge and rather high charge
[
12,14]
density depending on the pH of the surrounding solution.
Another interesting functionality for
the construction of polyampholytes or polyzwitterions is the imidazole moiety. In most cases,
imidazole-based polyzwitterions feature a betaine structure with the imidazole moiety being turned
[
15,16,17]
into a permanently charged group by alkylation.
One possible application field for these
polymers is as poly(ionic liquid)s, like other polyimidazoles as electrolytes in fuel cells and batteries,
[
18,19]
as solid ionic conductors, or in the field of gas separation.
In contrast to low molar mass ionic
liquids, the polymeric examples often exhibit enhanced mechanical stability and durability, but at the
[
20]
cost of higher melting points. These properties in turn can be influenced by variation of the
[
21]
corresponding counterions and the moiety used for alkylation.
Possible starting materials for the preparation of polyampholytic materials based on imidazole are
shown in Scheme 1, with urocanic acid as example for a natural product, which is enzymatically
prepared from histidine on human skin and acts as sunscreen to protect DNA from UV induced
[
22]
damage.
Hence, urocanic acid was already of interest for cosmetic applications via
[
23]
copolymerization with acrylic acid. However, only a few β-substituted acrylates have so far been
[24]
successfully polymerized using radical techniques.
An isomer of urocanic acid, 2-(imidazol-1-
yl)acrylic acid, was synthesized by Yavari et al. both as methyl (MeImA) and ethyl ester (EImA,
[
25]
Scheme 1). In that regard, the free radical copolymerization of MeImA with acrylonitrile has been
described by Batchelor et al. as low molecular weight plasticizers in poly(acrylonitrile) fibers to
[
26]
prepare carbon fibers.

ACCEPTED MANUSCRIPT
Scheme 1: Monomers of potential interest for radical polymerization based on urocanic acid.
Herein, we present the preparation and modification of poly(ethyl 2-(imidazol-1yl)acrylate) (PEImA),
both using conventional free radical polymerization and anionic techniques. The resulting PEImA is a
weak polyelectrolyte and can be converted into a strong polycation by alkylation of the imidazole
group. Furthermore, the cleavage of the ester moiety results in the formation of a polyzwitterion,
where the charge density depends on the pH of the solution. The resulting materials are
characterized by size exclusion chromatography (SEC, SEC-MALLS), solution and solid state nuclear
magnetic resonance spectroscopy (NMR), and thermogravimetric analysis (TGA). Additionally, we use
potentiometric titration to access the pH-dependant charge density of different modifications of
PEImA.

ACCEPTED MANUSCRIPT
Results and Discussion
Herein, we report on the synthesis and polymerization of EImA, both using free radical and anionic
polymerization techniques. Our main motivation is that the resulting PEImA can be multiply
functionalized: it can either be converted into a poly(ionic liquid) using alkylation of the imidazole
moiety or turned into a polyampholyte/polyzwitterion via hydrolysis of the ester moiety. At first, the
described synthesis of EImA from Yavari et al. was optimized for a larger scale by adding the
[
25]
triphenylphosphine solution at -30 °C (Scheme 2).
N
O
O
PPh3
DCM, -30 °C to RT, 22 h
N
N
NH
O
O
Scheme 2: Optimized synthesis of ethyl 2-(imidazol-1-yl)acrylate (EImA).
g
N
O
b
f
N
h
i
O
a
e
H
H c
d
1
13
Figure 1: H-NMR spectrum (A) and C-NMR spectrum (B) of ethyl 2-(imidazol-1-yl)acrylate (EImA) in CD Cl .
2
2
After purification of the crude product EImA was yielded as yellowish oil, which crystallized at -25 °C
overnight. The crystals were analyzed by solution NMR spectroscopy (Figure 1), which showed all
expected signals, and X-ray analysis (Figure 2) to verify both the structure and purity. The molecular
structure exhibits a conjugation between the carbonyl group and the double bond as expected, but
the imidazole ring is out of plane with a torsion angle C5C4N2C1 of 37.0(3)°. Therefore, the imidazole
group acts only as electron donating group and does not influence the double bond by conjugation.
This means that the monomer can be regarded as an activated acrylate with the carbonyl as electron
withdrawing and the imidazole moiety as electron donating group.
Figure 2: Molecular structure and numbering scheme (A) and crystal structure (B) of ethyl 2-(imidazol-1-yl)acrylate (EImA).
The ellipsoids represent a probability of 50%.

ACCEPTED MANUSCRIPT
At first, PEImA was synthesized via free radical polymerization at 65 °C in various solvents with and
without the addition of different acids. In the literature, the homopolymerization of vinylimidazoles
and imidazole containing acrylates has been reported either after protonation or alkylation of the
[
27,28,29,30]
imidazole group.
N-vinylimidazole and quarternized vinylimidazole in aqueous solution depending on the pH value.
Santanakrishnan and Hutchinson studied the polymerization of
[
31]
They reported a degradative addition of radicals to the imidazole group and on the possibility to
suppress this side reaction by protonation. Only few examples of imidazole containing monomers
have been reported so far where the polymerization was carried out without protonation or
quaternization like in case of 2-[(1-imidazolyl)formyloxy]ethyl methacrylate and 2-(1-imidazolyl)ethyl
[
32,33]
methacrylate.
Furthermore, it was reported that a direct copolymerization of such monomers
and MeImA with acrylonitrile was possible due to the formation of a charge transfer complex
[
26,27,34]
between the nitrile and imidazole group.
Scheme 3: Free radical polymerization of ethyl 2-(imidazol-1-yl)acrylate (EImA).
Based on these facts, EImA was polymerized with 0.5 mol% AIBN and 5 equivalents of acetic acid in
various solvents like water, methanol, hexafluoroisopropanol, 2,2,2-trifluoroethanol or
2
-methoxyethanol, which so far afforded only oligomers in low yields between 20% and 40%. The
polymerizations were repeated with 1.1 equivalents of concentrated hydrochloric acid instead of
acetic acid and also oligomers were observed, but the overall yield increased up to 99% (Table 1).
Additionally, EImA was polymerized without the addition of acid and an increase in molar mass to a
-
1
range of 2,000 - 13,000 g∙mol and with moderate dispersities of approximately 1.5 according to SEC
in water was observed (Figure 3, Table 1).
Figure 3: SEC elugrams (water with 0.1 M NaCl and 0.3% TFA, P2VP calibration, * system peak) of PEImA prepared by free
radical polymerization in DMSO and DMF with added acids and without.

ACCEPTED MANUSCRIPT
Table 1: Free radical polymerization of EImA in different solvents with 0.5 mol% AIBN.
-
1 a)
a)
-1 b)
b)
Entry
Solvent
DMSO
DMSO
DMSO
DMF
DMF
DMF
Anisole
Benzol
MeCN
THF
Additive
Yield [%]
50
M [g∙mol ]
PDI
M [g∙mol ]
PDI
n
n
1
2
3
4
5
6
7
8
9
-
13,300
2,700
1,000
10,000
2,700
2,100
11,500
13,400
8,600
1.45
1.53
1.52
1,54
1.39
1.37
1.65
1.59
1.48
1.49
30,200
1.45
-
HOAc
Conc. HCl
22
99
52
38
99
44
40
29
-
-
-
-
20,600
-
1.45
-
HOAc
Conc. HCl
-
-
-
-
-
-
23,800
29,400
17,000
16,500
1.53
1.51
1.42
1.56
1
0
42
8,700
a)
b)
Determined by SEC (Water, 0.1 M NaCl, 0.3% TFA). P2VP calibration. Determined by SEC (DMAc + 0.21% LiCl). PMMA
calibration.
The combination of an increased overall polymer yield and decreasing molar mass for PEImA
obtained using free radical polymerization in the presence of HCl in comparison to HOAc or without
any acid suggests transfer (e.g. to monomer) occurring as side reaction. Besides an increased molar
mass without protonation of EImA, the solubility of PEImA is improved in organic solvents like DMAc,
DMF, DCM and chloroform. The free radical polymerization of EImA was therefore repeated without
any acid in various solvents and the resulting materials were further analyzed by SEC in DMAc with
0
.21% LiCl using PMMA calibration (Table 1, Figure S1). Here, approximately the doubled molar
masses with similar dispersities was detected in comparison to SEC data acquired in water.
Moreover, we also investigated the anionic polymerization of EImA using KOtBu (0.1 M in THF) as
initiator in THF and DMF at 50 °C (Scheme 4). In comparison to N-vinylimidazole, anionic
polymerization so far is not described in the literature, probably due to the acidity of the proton at
the 2 position of the imidazole ring. A proton exchange study with deuterium oxide via NMR
spectroscopy of N-vinylimidazole at 40 °C was reported by Green et al. and a half-life time of
[
35]
approximately 2.6 hours was reported.
Scheme 4: Anionic polymerization of ethyl 2-(imidazol-1-yl)acrylate (EImA).
We carried out a comparable proton exchange experiment with EImA in D O at the polymerization
2
1
temperature of 50 °C by H-NMR spectroscopy. In our case, an even faster exchange rate was
observed (Figure 4) and after approximately 2 hours the deuteration is completed according to NMR,
which might turn anionic polymerization attempts problematic. On the other hand, 1-tritylimidazole-
4
-ethylene oxide could be successfully polymerized via anionic ring-opening polymerization initiated
with KOtBu by Ramirez et al. which indicates that KOtBu as base is probably not strong enough to
[
36]
deprotonate the imidazole group.

ACCEPTED MANUSCRIPT
1
Figure 4: Proton exchange of EImA in D O at 50 °C monitored via H-NMR.
2
At first, anionic polymerization was attempted at 50 °C for 24 hours in bulk, and in DMF or THF as
solvent with a 0.1 M KOtBu solution as initiator in THF (Figure 5). Here, the bulk polymerization
afforded the polymer with the highest molar mass and a rather broad molar mass distribution.
However, performing the anionic polymerization in DMF and THF afforded PEImA of lower dispersity.
In DMF, we observe an improved solubility of PEImA if compared to THF, which seems to affect the
degree of polymerization, leading to a distinctly higher molar mass (Table 2). Possibly caused by the
more polar solvent DMF, a faster polymerization with less control is observed, leading to a
moderately broad dispersity of 1.4-1.7. In comparison, anionic polymerization of EImA in THF results
in a dispersity of approx. 1.3.
Figure 5: SEC elugrams (water with 0.1 M NaCl and 0.3% TFA, P2VP calibration, * system peak) of PEImA prepared by
anionic polymerization with [M]:[I]=100 in different solvents (A) and different [M]:[I] ratios as well as different reaction
times in THF (B).
In order to access the possibility to control the molar mass of the resulting PEImA using anionic
polymerization we carried out different reactions at varying M:I ratios and a reduced polymerization
time of 2 hours (Figure 5, Table 2). As can be seen, increasing molar masses are obtained for M:I
-
1
-1
-1
ratios of 50:1 (3,700 g∙mol ), 100:1 (5,000 g∙mol ), and 200:1 (5,800 g∙mol ) at moderate dispersities

ACCEPTED MANUSCRIPT
down to 1.28 (according to SEC in water). We are aware that this does not exclude that side reactions
are occurring, but at least indicates a certain level of control. In addition, the fact that a comparable
-
1
reaction after 24 hours afforded an increased molar mass of 7,000 g∙mol at a dispersity of 1.28 (M:I
was 100:1) further supports this observation.
Table 2: Anionic polymerization of EImA with KOtBu at 50 °C.
-
1 a)
a)
-1 b)
b)
Entry
Solvent
THF
THF
THF
THF
DMF
-
[M]:[I] Time [h] M [g∙mol ]
PDI
M [g∙mol ]
PDI
Yield [%]
n
n
1
1
1
1
1
1
1
2
3
4
5
6
50
2
2
3,700
5,000
5,800
7,000
17,800
22,300
1.76
1.28
1.29
1.28
1.71
3.74
5,400
8,000
2.00
1.42
1.44
1.32
1.42
2.23
13
31
38
30
10
53
100
200
100
100
100
2
9,600 g
13,000
43,500
47,100
24
24
4
a)
b)
Determined by SEC (Water, 0.1 M NaCl, 0.3% TFA). P2VP calibration. Determined by SEC (DMAc + 0.21% LiCl). PMMA
calibration.
In comparison with the anionic polymerization in THF, PEImA prepared by free radical polymerization
1
reaches a higher molar masses but with broader dispersities. The H-NMR spectra and solid state
13
C-NMR spectra of both, radically or anionically synthesized PEImA are mostly identical (Figure S2),
although no fine splitting for the imidazole protons occurs in case of PEImA prepared by free radical
polymerization. To determine the absolute molar mass of suitable samples of PEImA, we additionally
carried out SEC-MALLS measurements in water containing 0.1 M NaCl and 0.3 % TFA (Table 3, Table
S1, Figure S3).
Table 3: Comparison of molar masses of PEImA obtained by SEC and SEC-MALLS.
-
1 a)
a)
-1 b)
b)
-1 c)
-1 c)
M [g∙mol ]
w
Entry
M [g∙mol ]
PDI
M [g∙mol ]
PDI
M [g∙mol ]
n
n
n
4
10,000
7,000
1,54
1.28
20,600
13,000
1.45
1.32
34,400
16,900
36,300
17,800
1
4
a)
b)
Determined by SEC (Water, 0.1 M NaCl, 0.3% TFA), P2VP calibration. Determined by SEC (DMAc + 0.21% LiCl), PMMA
c)
calibration. Determined by SEC-MALLS (Water, 0.1 M NaCl, 0.3% TFA).
These data show that both aqueous SEC and SEC in DMAc with the respective calibration
underestimate molar masses of PEIma as distinctly higher values are obtained using SEC-MALLS for
both samples investigated.
We were further interested in the modification of PEImA by either alkylation of the imidazole moiety
or hydrolysis of the ethyl ester. By this, the material will be changed from a weak polyelectrolyte into
a polyzwitterion poly(2-(imidazol-1-yl)acrylic acid) (PImAA) or poly(2-(3-methylimidazolium-1-
yl)acrylic acid) (PMeImAA) or a poly(ionic liquid) poly(ethyl 2-(3-methylimidazolium-1-yl
iodide)acrylate) (PEMeImA) (Scheme 5) and the corresponding materials might be of interest as
carrier material for catalysts, water purification, or as pH-responsive materials in future
[
37]
applications.

ACCEPTED MANUSCRIPT
Scheme 5: Conversion of PEImA into strong polyelectrolyte and polyzwitterion.
The transformation of PEImA into a polyzwitterion and strong polycation was carried out by either
cleavage of the ester moiety with lithium hydroxide and alkylation with methyl iodide starting from
anionically polymerized PEImA (for details see Table 4). In case of the alkylation, methyl iodide can
[
28]
easily be exchanged by other alkyl halides similar to poly(ionic liquids) based on PVIm.
The
conversion of PEImA into poly(ethyl 2-(3-methylimidazolium-1-yl iodide)acrylate) (PEMeImA) with
methyl iodide succeeded with a degree of alkylation over 90%. A new signal at 4.37 ppm appears in
1
the H-NMR spectrum with nearly the same intensity as the methyl group of the ester moiety at
1
3
1
.64 ppm and the solid state C-NMR shows the signal of the introduced methyl group at 33.87 ppm
(
Figure 6, B and C). However, the SEC in water showed a decrease in apparent molar mass for PEImA
if compared to the used PEImA (Table 4, Figure 7). Additionally, PEMeImA was converted into the
polyzwitterion poly(2-(3-methylimidazolium-1-yl)acrylic acid) (PMeImAA) via hydrolysis of the ethyl
ester. PMeImAA was purified by dialysis against water and a small decrease of the molar mass was
observed by SEC in water. One explanation could be that methylation (if compared to protonation)
results in a slightly less hydrophilic polycation and, thus, a slightly reduced hydrodynamic volume in
solution. In addition, changes in the apparent hydrodynamic volume might also originate from the
presence of iodide and tri-iodide counterions. Additionally, PEMeImA was converted into the
polyzwitterion poly(2-(3-methylimidazolium-1-yl)acrylic acid) (PMeImAA) via hydrolysis of the ethyl
ester. PMeImAA was purified by dialysis against water and a small decrease of the molar mass was
1
observed by the SEC in water. The integration of the H-NMR spectrum confirms that about 94% of
the ester moiety were successfully cleaved, which can be seen by the disappearance of the CH3-
13
group of the ethyl ester at 1.37 ppm and in the solid state C-NMR spectrum at 8-9 ppm.

ACCEPTED MANUSCRIPT
1
13
Figure 6: Structure (A), H-NMR spectra (B) and solid state C-NMR spectra (C) of PEImA, PEMeImA and PMeImAA.
As an alternative pathway, first the ester moiety of PEImA was hydrolyzed with lithium hydroxide to
afford poly(2-(imidazol-1-yl)acrylic acid) (PImAA) as polyzwitterion with a tunable charge and,
depending on the pH value, a polyanion, polyzwitterion, or polycation could result. Based on
1
calculations by H-NMR spectroscopy of PImAA (Figure 8) approximately 5% of the ethyl ester remain
and a shift of the distribution to higher elution volumes and apparent lower molar masses is visible in
SEC in water (Figure 7).

ACCEPTED MANUSCRIPT
Figure 7: SEC elugram (water with 0.1 M NaCl and 0.3% TFA, P2VP
calibration, * system peak) of PEImA and its modifications.
1)
2)
Prepared by ester cleavage. Prepared by methylation.
Table 4: Modification of PEImA via ester cleavage and methylation.
-
1 a)
a)
Polymer
PEImA
PImAA
PEMeImA
PMeImAA
PMeImAA
M [g∙mol ]
PDI
n
6,500
4,900
5,100
4,800
6,800
1.40
1.31
1.46
1.57
1.45
1
)
2)
a)
1)
2)
Determined by SEC (Water, 0.1 M NaCl, 0.3% TFA). P2VP calibration. Prepared by ester cleavage. Prepared by
methylation.
Afterwards, alkylation of PImAA using methyl iodide was used to prepare PMeImAA following the
second pathway. Therefore, PImAA was dissolved in methanol/water (v/v 1/1) under Ar atmosphere
and methyl iodide was added. The biphasic mixture was heated up to 65 °C and merged to a single-
1
phase reaction mixture. The degree of alkylation of 83% was determined by H-NMR integration of
-
1
the introduced methyl group at 4.07 ppm and the molar mass increased from 4,900 g∙mol to
-
1
6
,800 g∙mol according to SEC in water.

ACCEPTED MANUSCRIPT
1
13
Figure 8: Structure (A), H-NMR spectra (B) and solid state C-NMR spectra (C) of PEImA, PImAA and PMeImAA.
After successful modification of PEImA, we also investigated the resulting polyelectrolytes and
polyzwitterions using potentiometric titration in aqueous solution. Whereas PImAA and PMeImAA
were titrated with 0.1 M HCl starting at high pH. Both PEImA and EImA were titrated with 0.1 M
NaOH starting under acidic conditions to prevent ester hydrolysis occurring already during the
measurement (Table 5). The monomer EImA features a pK value of 9.13, which is higher if compared
a
to other N-substituted imidazole compounds with a pK of 6.9 to 7.5, presumably due to the
a
[
38]
presence of the electron withdrawing carbonyl functionality.
An increased basicity was also
observed for PEImA and the modified polymers (Table 5, Figure 9, S4-S8). For PImAA the pK value of
a
the carboxylic acid is difficult to specify, due to partial precipitation and, hence, a heterogeneous
mixture from pH 6.8 to 2.2. PImAA was completely redissolved at pH of 2.2, but the carboxylic acid
has presumably a pK value between 4 and 5 similar to PMeImAA. For both PMeImAA a pK of
a
a
approximately 9.3 was determined, which in our opinion results from the 10-17% of non-alkylated
imidazole groups present in the material.

ACCEPTED MANUSCRIPT
Figure 9: Titration curve of PEImA (5 g/L in 0.1 M HCl) with 0.1 M
NaOH (black) and the first derivative (red).
Table 5: Determined pKa values for EImA, PEImA and the modified polymers.
Polymer
EImA
PEImA
pK 1
pK 2
a
a
9.13
9.17
-
-
PImAA
PMeImAA
PMeImAA
10.78
-
1
)
)
a)
9.38
5.10
4.24
2
a)
9.23
a)
1)
2)
Presumably due to non-alkylated imidazole groups. Prepared by ester cleavage. Prepared by methylation.
The thermogravimetric analysis of PEImA and its derivatives shows the release of water and in case
of PEMeImA probably methanol up to temperatures of 120 °C (Figure S9). The decomposition of
PEImA starts around 150 °C and the mass loss over 80% at 800 °C indicates the degradation of both
the ethyl ester and the imidazole ring. Furthermore, PEMeImA seems to decompose at lower
temperatures and PImAA seems to feature significantly increased thermal stability as degradation
starts around 250 °C.

ACCEPTED MANUSCRIPT
Conclusion
We describe the homopolymerization of PEImA via free radical and anionic techniques as well as the
modification into permanently charge polyelectrolytes or polyzwitterions through either alkylation of
the imidazole ring or hydrolysis of the ester moiety. The materials were characterized by SEC, SEC-
MALLS (for selected examples), NMR spectroscopy, titration, and TGA. Whereas anionic
polymerization of EImA seems to produce polymers of lower dispersity, higher molar masses so far
can be reached using free radical polymerization in various solvents. We think that the resulting
materials, especially the polyzwitterions PImAA or PMeImAA are interesting candidates as materials
with tunable charge and charge density and further studies regarding the pH- and salinity-dependent
solubility will follow. In addition, such materials might be of interest in the context of protein-
repellant coatings (for nanoparticles) or as potential biocompatible polymers. Also, imidazole-based
polymeric materials can act as carrier system for metal catalysts and, in our case, both the imidazole
[
39]
and the carboxylic acid can act as ligands.

ACCEPTED MANUSCRIPT
Experimental Section
Ethyl propiolate (99%), triphenyl phosphine (ReagentPlus®, 99%), 2,2′-azobis(2-methylpropionitril)
AIBN) recrystallized in methanol and iodomethane (99%) were purchased from Sigma Aldrich.
(
Potassium tert-butoxide (Fluorochem Ltd., 99%), imidazole (AppliChem GmbH, 99%), DMF (Acros
Organics, 99.8%, Extra Dry, AcroSeal®) and lithium hydroxide monohydrate (Acros Organics, extra
pure, 56% LiOH) were used without further purification. Tetrahydrofuran (VWR International,
®
HiPerSolv CHROMANORM for HPLC) was dried by refluxing over sodium with benzophenone and
stored under Ar. All deuterated solvents were obtained from Deutero GmbH (Kastellaun, Germany).
For dialysis, a regenerated cellulose membrane (Spectrum, Inc., Spectra/Por® 6 pre-wetted dialysis
tubing) with a nominal molecular weight cut-off of 1 kDa was used.
Size-exclusion chromatography (SEC)
SEC measurements in DMAc were performed on an Agilent (Santa Clara, CA, USA) system equipped
with G1310A pump, a G1362A refractive index detector, and both a PSS GRAM 30 Å and a PSS GRAM
1
000 Å column in series (PSS Polymer Standards Service, Mainz, Germany). N,N-Dimethylacetamide
-
1
-1
with 2.1 g∙L of lithium chloride was applied as eluent at 1 mL∙min flow rate and the column oven
-
1
was set to 40 °C. The system was calibrated with PMMA (505-981,000 g∙mol ) standards.
SEC measurements in water were performed on a Jasco (Groß-Umstadt, Germany) system equipped
with a PU-980 pump and a RI-930 refractive index detector. Water with 0.3% trifluoroacetic acid and
-
1
0
3
.1 M sodium chloride was used as solvent at a flow rate of 1 mL∙min on an PSS SUPREMA-MAX
-
1
00 Å column at 30 °C. The system was calibrated with P2VP (1,300-81,900 g∙mol ) standards
(
Polymer Source, Dorval, Quebec, Canada).
Size-exclusion chromatography with multi-angle light scattering (SEC-MALLS)
SEC measurements (PSS, NOVEMA Max column) were performed on an adapted AF2000 MT System
from Postnova Analytics GmbH (Landsberg, Germany), equipped with a tip pump used to control the
mobile phase flow rate (PN1130), an autosampler (PN5300), and a column oven unit (PN4020). The
column was coupled to a multi-angle laser light scattering (MALLS) detector (PN3621) equipped with
a 532 nm laser. A mobile phase of 0.1 M NaCl + 0.3% TFA was used as sample and run solvent. The
oven temperature was set to T=25 °C and the injection volume was 50 μL. The polymer was dissolved
-
1
in the running mobile phase at a concentration of 2.5 mg mL . A refractive index (RI) detector was
used as a concentration sensitive detector and the elutions further detailed via MALLS. Values for the
recovery were found close to 100%. Example elugrams are shown in Figure S3 with the weight-
average molar mass trace against elution time shown in blue.
Values of the refractive index increment dn/dc, necessary to estimate appropriate values of the
molar mass, were determined with an Optilab rEX system (Wyatt, Germany) by manual delivery of six
known concentrations of the polymer in respective mobile phases used in SEC-MALLS experiments
via a plastic syringe at a temperature of T = 25 °C. The dn/dc was calculated by the slope of the plot
-
1
from the refractive index against the concentration. Values for the dn/dc of 0.1557±0.0003 mL g for
-
1
entry 14 of Table 3 and 0.1594±0.0008 mL g for entry 4 of Table 3 were determined.
Nuclear magnetic resonance spectroscopy (NMR)
1
13
H-NMR and C-NMR spectra of the monomer were recorded in CD Cl on a Bruker Fourier
2
2
spectrometer equipped with a direct observe probehead operating at a proton frequency of

ACCEPTED MANUSCRIPT
3
00 MHz. Sample temperature was set to 298 K. Chemical shifts are given in parts per million (ppm,
[δ]) and were referenced by using the residual signal of the deuterated solvent.
1
H-NMR spectra of the polymers were recorded in d -DMSO or D O on a Bruker Avance III
6
2
spectrometer equipped with a direct observe probehead operating at a proton frequency of
00 MHz. Sample temperature was set to 333 K. Chemical shifts are given in parts per million (ppm,
δ]) and were referenced by using the residual signal of the deuterated solvent.
4
[
Solid state NMR
13
Proton decoupled C solid-state magic angle spinning (ssMAS) NMR spectra were acquired utilizing
cross polarization with a contact time of 2 ms and a spinning frequency of 15 kHz. All data were
collected on a Bruker Avance III HD 400 MHz spectrometer equipped with a 4 mm dual channel
probe. Sample temperature was set to 300 K. The carbon chemical shifts were referenced externally,
setting the high-frequency (methylene) signal of adamantane to 38.5 ppm.
Thermogravimetric analysis (TGA)
TGA measurements were carried out from 30 °C up to 800 °C under nitrogen atmosphere with a
-
1
heating range of 10 K∙min on a Perkin Elmer TGA8000 device.
Crystal Structure Determination
The intensity data were collected on a Nonius KappaCCD diffractometer, using graphite-
monochromated Mo-K radiation. Data were corrected for Lorentz and polarization effects;
α
[
40][41][42]
absorption was taken into account on a semi-empirical basis using multiple-scans.
[
43]
he structure was solved by direct methods (SHELX ) and refined by full-matrix least squares
2
[43]
techniques against Fo (SHELXL-97 ). All hydrogen atoms were located by difference Fourier
[
44]
synthesis and refined isotropically. MERCURY was used for structure representations.
Supporting Information Available: Crystallographic data deposited at the Cambridge Crystallographic
Data Centre under CCDC-1554466 for EImA contain the supplementary crystallographic data
excluding structure factors; this data can be obtained free of charge via
www.ccdc.cam.ac.uk/conts/retrieving.html (or from the Cambridge Crystallographic Data Centre, 12,
Union Road, Cambridge CB2 1EZ, UK; fax: (+44) 1223-336-033; or deposit@ccdc.cam.ac.uk).
Potentiometric titration
The Titrations were done with a titrator TitroLine® 7000 with WA 20 exchangeable unit and magnetic
stirrer TM 235 equipped ScienceLine pH combination electrodes with temperature sensor A162 from
-
1
SI Analytics GmbH (Mainz, Germany). Therefore, a 5 g∙L solution of PImAA or PMeImAA was
prepared with 0.1 M NaOH and titrated against 0.1 M HCl by automatic dynamic pH titration method.
Additionally, EImA and PEImA were dissolved in 0.1 M HCl and titrated with 0.1 M NaOH using the
same method.
Lyophilisation
An Alpha 1-2 LDplus from Martin Christ Gefriertrocknungsanlagen GmbH (Osterode am Harz,
Germany) were used for freeze-drying of aqueous solutions.
Centrifugation
The precipitated polymer was centrifuged with a Thermo Scientific Heraeus Megafuge 8 Centrifuge at
8
,000 rpm for 5 minutes.
Synthesis of ethyl 2-(imidazol-1-yl)acrylate (EImA)

ACCEPTED MANUSCRIPT
To a solution of imidazole (10.093 g; 148.25 mmol) in DCM (350 mL) ethyl propiolate (15 mL;
1
1
48.01 mmol) was added at -15 °C and cooled to -30 °C. A solution of triphenylphosphine (38.701 g;
47.55 mmol) in DCM (80 mL) was added dropwise and the reaction mixture was allowed to warm
up to room temperature over 2 hours. After 20 hours the mixture was concentrated and purified by
column chromatography (DCM, followed by EtOAc) to afford 18.706 g ethyl 2-(imidazol-1-yl)acrylate
(
1
75%) as yellow oil, which crystallized at -25 °C.
H-NMR (300 MHz, CD Cl , 25 °C): δ = 1.34 (t, J=7.1, -CH -CH ), 4.32 (q, J=7.1, -CH -CH ), 5.83 (d, J=1.1,
2
2
2
3
2
3
-
C=CH ), 6.26 (d, J=1.1, -C=CH ), 7.04 (dd, J=1.4, 1.0 Hz, -N-CH=CH-), 7.15 (t, J=1.4, -N-CH=CH-), 7.70
2
2
(
1
t, J=1.1 Hz, -N=CH-N-) ppm.
3
C-NMR (75 MHz, CD Cl , 25 °C): δ = 14.42 (-CH -CH ), 62.87 (-CH -CH ), 119.26 (-C=CH ), 120.03 (-N-
2
2
2
3
2
3
2
CH=CH-), 129.70 (-N-CH=CH-), 135.11 (-C=CH ), 137.66 (-N=CH-N-), 162.78 (-C=O) ppm.
2
-
1
Crystal Data for EImA: C H N O , Mr = 166.18 g∙mol , colourless prism, size 0.088 x 0.080 x
8
10
2
2
3
0
1
.064 mm , monoclinic, space group P 2 /c, a = 6.4082(7), b = 20.135(3), c = 6.8450(8) Å, β =
1
3
-3
-1
10.585(7)°, V = 826.83(18) Å , T= -140 °C, Z = 4, ρ
= 1.335 g∙cm , µ (Mo-K ) = 0.98 cm , multi-
α
calcd.
scan, transmin: 0.4553, transmax: 0.7456, F(000) = 352, 8634 reflections in h(-8/7), k(-24/25), l(-8/8),
measured in the range 3.34° ≤ Θ ≤ 26.36°, completeness Θmax = 99.9%, 1691 independent reflections,
2
R = 0.1018, 1263 reflections with F > 4σ(F ), 149 parameters, 0 restraints, R1 = 0.0617, wR
=
int
o
o
obs
obs
2
0
.1222, R1 = 0.0939, wR = 0.1368, GOOF = 1.176, largest difference peak and hole: 0.248 / -0.286
all all
-
3
e Å .
General procedure for free radical polymerization of EImA
To a flask charged with EImA under Ar atmosphere were added solvent (1.75 M EImA) and AIBN
(
0.5 mol%). The mixture was degassed by three cycles of freeze-pump-thaw and heated up to 65 °C
for 48 hours. The polymer was precipitated in EtOAc (45 mL), centrifuged and dried under vacuum.
1
H-NMR (400 MHz, d -DMSO, 60 °C): δ = 0.7-1.5 (-CH -CH ), 1.6-3.1 (back bone), 3.5-4.4 (-CH -CH ),
6
2
3
2
3
6
.4-7.9 (Imidazole group) ppm.
13
Solid state C-NMR: δ = 5-12 (-CH -CH ), 30-54 (back bone), 54-77 (-CH -CH , back bone), 109-141
2
3
2
3
(
Imidazole group), 159-172 (-C=O) ppm.
General procedure for the anionic polymerization of EImA
A microwave vial was charged with EImA under Ar atmosphere was introduced into a glove box and
dry solvent was added. The monomer solution was added to a second microwave vial with solvent
and KOtBu (0.1 M in THF) and stirred for 24 hours. Methanol was added to the reaction mixture and
the polymer was precipitated in EtOAc, centrifuged and dried under vacuum.
1
H-NMR (400 MHz, d -DMSO, 60 °C): δ = 0.7-1.4 (-CH -CH ), 1.5-3.0 (back bone), 3.1-4.0 (-CH -CH ),
6
2
3
2
3
6
.4-7.9 (Imidazole group) ppm.
13
Solid state C-NMR: δ = 5-13 (-CH -CH ), 29-54 (back bone), 54-65 (-CH -CH , back bone), 107-140
2
3
2
3
(
Imidazole group), 157-171 (-C=O) ppm.
Synthesis of PEMeImA
In a microwave vial PEImA (299.5 mg) was dissolved in methanol (5 mL) and purged with Ar for
minutes. Methyl iodide (0.56 mL; 9.0 mmol; 5 eq. per monomer unit) was added to the polymer
solution and stirred at room temperature for 48 hours. The polymer was precipitated in EtOAc
5
(
1
175 mL), centrifuged and dried under vacuum to afford 456.4 mg PEMeImA as yellowish solid.
H-NMR (400 MHz, D O, 60 °C): δ = 1.2-2.1 (-CH -CH ), 3.2-4.8 (back bone, -CH -CH , -N-CH ), 7.0-10.1
2
2
3
2
3
3
(
Imidazole group) ppm.

ACCEPTED MANUSCRIPT
1
3
Solid state C-NMR: δ = 5-15 (-CH -CH ), 26-54 (-N-CH , back bone), 54-69 (-CH -CH , back bone),
2
3
3
2
3
1
10-140 (Imidazole group), 156-169 (-C=O) ppm.
Synthesis of PImAA
In a microwave vial PEImA (101.7 mg) was dissolved in methanol (2 mL) and a solution of lithium
hydroxide monohydrate (162.3 mg; 3.87 mmol; 5 eq. per monomer unit) in water (2 mL) was added.
The reaction mixture was heated up to 65 °C for 48 hours and dialyzed against water. The aqueous
solution of the polymer was freeze-dried and afforded 75.7 mg PImAA as white solid.
1
H-NMR (400 MHz, D O, 60 °C): δ = 2.5-3.5 (back bone), 6.5-8.5 (Imidazole group) ppm.
2
13
Solid state C-NMR: δ = 22-54 (backbone), 55-77 (back bone), 108-142 (Imidazole group), 152-181
-C=O) ppm.
(
Synthesis of PMeImAA
Preparation by ester cleavage of PEMeImA
In a microwave vial PEMeImA (250.5 mg) was dissolved in methanol (2.5 mL) and a solution of lithium
hydroxide monohydrate (178.8 mg; 4.26 mmol; 5 eq. per monomer unit) in water (2.5 mL) was
added. The reaction mixture was heated up to 65 °C for 48 hours and dialyzed against water. The
aqueous solution of the polymer was freeze-dried and afforded 142.2 mg PMeImAA as yellowish
solid.
1
H-NMR (400 MHz, D O, 60 °C): δ = 2.6-3.6 (back bone), 3.7-4.3 (-N-CH ), 6.8-9.6 (Imidazole group)
2
3
ppm.
13
Solid state C-NMR: δ = 27-35 (-N-CH ), 35-57 (back bone), 58-72 (back bone), 106-142 (Imidazole
3
group), 157-176 (-C=O) ppm.
Preparation by methylation of PImAA
In a microwave vial PImAA (97.6 mg) was dissolved in methanol (2 mL) and water (2 mL). The solution
was purged with Ar for 5 minutes and methyl iodide (0.25 mL; 4.02 mmol; 5 eq per monomer unit).
The biphasic mixture was heated up to 65 °C for 24 hours and the yellow solution was dialyzed
against water, 50% methanol and water again. After freeze-drying 83.4 mg PMeImAA was yielded as
white solid.
1
H-NMR (400 MHz, D O, 60 °C): δ = 2.4-3.8 (back bone), 3.8-4.4 (-N-CH ), 6.7-9.8 (Imidazole group)
2
3
ppm.
13
Solid state C-NMR: δ = 28-36 ((-N-CH ), 36-56 (back bone), 57-71 (backbone), 107-141 (Imidazole
3
group), 157-172 (-C=O) ppm.

ACCEPTED MANUSCRIPT
Acknowledgements
We would like to acknowledge the NMR-platform at the Friedrich-Schiller-University Jena for support
in NMR spectroscopy and Steffen Weidner (Federal Ministry for Economic Affairs and Energy, BAM)
and Jan Steinkönig (Karlsruhe Institute of Technology, KIT) for attempted MALDI-MS or ESI-MS
measurements of PEIMA or the corresponding oligomers. Further support of this study was obtained
from the Thüringer Ministerium für Wirtschaft, Wissenschaft und Digitale Gesellschaft (TMWWDG,
ProExzellenz II, NanoPolar) for funding the Solution Characterization Group (SCG) at the Jena Center
for Soft Matter (JCSM). We are further grateful to Moritz von der Lühe for TGA analysis.
References
[
[
[
[
[
[
[
[
[
[
[
[
1] A. V. Dobrynin, M. Rubinstein, Prog. Polym. Sci. 2005, 30, 1049–1118.
2] A. D. Jenkins, P. Kratochvíl, R. F. T. Stepto, U. W. Suter, Pure Appl. Chem. 1996, 2287–2311.
3] D. V. Pergushov, Axel H. E. Müller, F. H. Schacher, Chem. Soc. Rev. 2012, 41, 6888–6901.
4] X. Yang, L. Chen, B. Huang, F. Bai, X. Yang, Polymer 2009, 50, 3556–3563.
5] M. Billing, T. Rudolph, E. Täuscher, R. Beckert, F. Schacher, Polymers 2015, 7, 2478–2493.
6] P. C. Griffiths, A. Paul, P. Stilbs, E. Petterson, Macromolecules 2005, 38, 3539–3542.
7] P. M. Henrichs, L. R. Whitlock, A. R. Sochor, J. S. Tan, Macromolecules 1980, 13, 1375–1381.
8] D. A. Mortimer, Polym. Int. 1991, 25, 29–41.
9] D. Avci, N. Mol, L. Dagasan, Polym. Bull. 2002, 48, 353–359.
10] K. Kim, W. C. Chen, Y. Heo, Y. Wang, Prog. Polym. Sci. 2016, 60, 18–50.
11] A. B. Lowe, C. L. McCormick, Chem. Rev. 2002, 102, 4177–4190.
12] U. Günther, L. V. Sigolaeva, D. V. Pergushov, F. H. Schacher, Macromol. Chem. Phys. 2013, 407,
2
202–2212.
[
[
[
[
[
[
[
13] A. Laschewsky, Polymers 2014, 6, 1544–1601.
14] M. Billing, G. Festag, P. Bellstedt, F. H. Schacher, Polym. Chem. 2017, 8, 936–945.
15] S. Soll, P. Zhang, Q. Zhao, Y. Wang, J. Yuan, Polym. Chem. 2013, 4, 5048.
16] V. A. Vasantha, S. Jana, A. Parthiban, J. G. Vancso, Chem. Commun. 2014, 50, 46–48.
17] X. He, S. Qiang, Z. Liu, M. Wang, W. Yang, RSC Adv. 2015, 5, 101055–101062.
18] O. Green, S. Grubjesic, S. Lee, M. A. Firestone, Polym. Rev. 2009, 49, 339–360.
19] D. Cordella, A. Kermagoret, A. Debuigne, C. Jérôme, D. Mecerreyes, M. Isik, D. Taton, C.
Detrembleur, Macromolecules 2015, 48, 5230–5243.
[20] J. Yuan, M. Antonietti, Polymer 2011, 52, 1469–1482.
[21] M. M. Obadia, S. Fagour, Y. S. Vygodskii, F. Vidal, A. Serghei, A. S. Shaplov, E. Drockenmuller, J.
Polym. Sci. Part A: Polym. Chem. 2016, 54, 2191–2199.
[
[
[
[
[
22] N. K. Gibbs, M. Norval, J. Invest. Dermatol. 2011, 131, 14–17.
23] C. Schade, EP2851375 A1, 2015.
24] B. Yamada, S. Kobatake, Prog. Polym. Sci. 1994, 19, 1089–1131.
25] I. Yavari, H. Norouzi-Arasi, Phosphorus, Sulfur Silicon Relat. Elem. 2002, 177, 87–92.
26] B. L. Batchelor, S. F. Mahmood, M. Jung, H. Shin, O. V. Kulikov, W. Voit, B. M. Novak, D. J. Yang,
Carbon 2016, 98, 681–688.
[27] M. H. Allen, S. T. Hemp, A. E. Smith, T. E. Long, Macromolecules 2012, 45, 3669–3676.

ACCEPTED MANUSCRIPT
[
[
[
[
[
[
[
[
28] S. Soll, Q. Zhao, J. Weber, J. Yuan, Chem. Mater. 2013, 25, 3003–3010.
29] M. Rikkou-Kalourkoti, P. A. Panteli, C. S. Patrickios, Polym. Chem. 2014, 5, 4339.
30] M. R. Simmons, C. S. Patrickios, Macromolecules 1998, 31, 9075–9077.
31] S. Santanakrishnan, R. A. Hutchinson, Macromol. Chem. Phys. 2013, 214, 1140–1146.
32] E. Ranucci, G. Spagnoli, P. Ferruti, Macromol. Rapid Commun. 1999, 20, 1–6.
33] C. S. Patrickios, M. R. Simmons, Colloids Surf., A 2000, 167, 61–72.
34] N. Pekel, Rzaev, Zakir M. O., O. Güven, Macromol. Chem. Phys. 2004, 205, 1088–1095.
35] M. D. Green, M. H. Allen, J. M. Dennis, Cruz, David Salas-de la, R. Gao, K. I. Winey, T. E. Long, Eur.
Polym. J. 2011, 47, 486–496.
[
[
[
[
[
[
36] S. M. Ramirez, J. M. Layman, P. Bissel, T. E. Long, Macromolecules 2009, 42, 8010–8012.
37] M. Billing, F. H. Schacher, Macromolecules 2016, 49, 3696–3705.
38] B. Lenarcik, P. Ojczenasz, J. Heterocycl. Chem. 2002, 39, 287–290.
39] S. M. Sarkar, Y. Uozumi, Yamada, Yoichi M A, Angew. Chem. Int. Ed. 2011, 50, 9437–9441.
40] COLLECT, Data collection software, Nonius B.V., The Netherlands, 1998.
41] Z. Otwinowski, W. Minor, Processing of X-Ray Diffraction Data Collected in Oscillation Mode, ed.
C. W. Carter, R. M. Sweet, Academic Press, San Diego, USA, 1st edn, vol. 276, pp. 307–326, 1997.
42] SADABS 2.10, Bruker-AXS inc., Madison, WI, USA, 2002.
[
[
[
43] G. M. Sheldrick, Acta Crystallogr., Sect. A: Found. Crystallogr. 2008, 64, 112–122.
44] C. F. Macrae, P. R. Edgington, P. McCabe, E. Pidcock, G. P. Shields, R. Taylor, M. Towler, J. van de
Streek, J. Appl. Crystallogr. 2006, 39, 453–457.

ACCEPTED MANUSCRIPT
Highlights:
-
-
-
We report on the synthesis of Poly(ethyl 2-(imidazol-1-yl)acrylate) (PEImA)
PEImA can be prepared using either free radical or anionic polymerization
PEImA can further be transformed into different polyampholytes or polyzwitterions
