Mendeleev Commun., 2014, 24, 222–223
1
13
12
11
10
9
8
7
6
5
d/ppm
Figure 2 1H NMR spectrum of salicylaldehyde-d1.
Zn(OAc)2·2H2O
Ni(NO3)2·6H2O
1
3
5
7
13
12
11
10
9
8
7
6
5
d/ppm
O
H
Figure 4 The 1H NMR spectra of the H/D exchange of salicylaldehyde in
the presence of 1, Zn(OAc)2·2H2O or Ni(NO3)2·6H2O.
9
OD
11
13
Innovation in Chemistry (PERCH-CIC). We are grateful to Miss
Tan Geok Kheng and Hong Yimian (National University of
Singapore) for the solution of the crystal structure.
210
170
130
90
50
10
d/ppm
Online Supplementary Materials
Supplementary data associated with this article can be found
in the online version at doi:10.1016/j.mencom.2014.06.011.
Figure 3 The HSQC spectrum and proposed structure of salicylalde-
hyde-d1.
After 5.5 h, the hydroxyl proton peak completely disappears and
other peaks remain unchanged (Figure 2). From HSQC spectrum,
all positions of C and H are the same as those of salicylaldehyde
except no proton at hydroxyl group (Figure 3). The peak assign-
ment indicated in the spectrum tentatively suggests the structure
of salicylaldehyde-d1. To confirm the H/D exchange reaction of
the salicylaldehyde, the organic product was analyzed by GC-MS
(Figure S3). The product ion of m/z 123 at a retention time of
22.20 min produces fragment ions with m/z 121 and 65. They
resulted from the loss of a deuterium atom from the ion at m/z 123
and the formation of the [M–C5H5]+ ion, respectively. Since the
molecular weight of salicylaldehyde is 122, only one active H in
its structure was exchanged for a deuterium atom. The similar
reaction was also performed using DMSO. The product ion
mass spectrum of m/z 122 at a retention time of 20.92 min
shows fragment ions at m/z 121 and 65 (Figure S4). However, the
molecular ion of m/z 123 was found in this reaction. The intensity
of this ion in DMSO-d6 is higher than that in DMSO. The mole-
cular weight of salicylaldehyde-d1 causes a slow mobility of the
substance and results in an increase of the retention time.20 The
GC-MS analysis and 1H NMR spectroscopy confirmed the H/D
exchange reaction. Ni(NO3)2·6H2O or Zn(OAc)2·2H2O was tested
as a catalyst under identical conditions (Figure 4). The hydroxyl
proton immediately manifests itself as a broad peak at 10.67 ppm
in the presence of Zn(OAc)2·2H2O and this peak remained
unchanged after 6 h. When using Ni(NO3)2·6H2O as a catalyst,
there is no reaction after 6 h. Thus, the heterometallic ion pair
compound is an efficient catalyst in the H/D exchange of salicyl-
aldehyde. Zn(OAc)2·2H2O can also catalyze the H/D exchange
reaction, however, the reaction is not complete within 6 h. The
Lewis acidity of the zinc salt may be the source for promoting
the catalytic activity. Other alcohol substrates, namely, tert-butanol,
diphenylmethanol and phenylethanol were tested under analogous
conditions with complex 1 as a catalyst, but no reaction was
observed within 6 h.
References
1 S. P. Neo, Z.-Y. Zhou, T. C. W. Mak and T. S. A. Hor, Inorg. Chem.,
1995, 34, 520.
2 P. Teo and T. S. A. Hor, Coord. Chem. Rev., 2011, 255, 273.
3 S. Q. Bai, A. M. Yong, J. J. Hu, D. J. Young, X. Zhang, Y. Zong, J. Xu,
J. -L. Zuo and T. S. A. Hor, Cryst. Eng. Comm., 2012, 14, 961.
4 O. V. Nesterova, S. R. Petrusenko, V. N. Kokozay, B. W. Skelton, J. K.
Bjernemose and P. R. Raithby, Inorg. Chim. Acta, 2005, 358, 2725.
5 S. R. Breeze and S. Wang, Inorg. Chem., 1993, 32, 5981.
6 J.-S. Hu, C.-L. Zhu, X.-M. Song and J. He, Mendeleev Commun., 2012,
22, 220.
7 L. Li, D. Liao, Z. Jiang and S. Yan, Polyhedron, 2000, 19, 1575.
8 S. Saha, D. Biswas, P. P. Chakrabarty,A. D. Jana,A. K. Boudalis, S. K. Seth
and T. Kar, Polyhedron, 2010, 29, 3342.
9 O. V. Nesterova, A. V. Lipetskaya, S. R. Petrusenko, V. N. Kokozay, B. W.
Skelton and J. Jezierska, Polyhedron, 2005, 24, 1425.
10 S. Nakashima, A. Yamamoto, Y. Asada, N. Koga and T. Okuda, Inorg.
Chim. Acta, 2005, 358, 257.
11 D. Bose, S. H. Rahaman, R. Ghosh, G. Mostafa, J. Ribas, C.-H. Hung
and B. K. Ghosh, Polyhedron, 2006, 25, 645.
12 Z. Mahendrasinh, S. Ankita, S. B. Kumar, A. Escuer and E. Suresh, Inorg.
Chim. Acta., 2011, 375, 333.
13 A. Escuer, M. Font-Bardía, E. Peñalba, X. Solans and R. Vicente, Inorg.
Chim. Acta, 1999, 286, 189.
14 Z.-H. Ni, L.-F. Zhang, V. Tangoulis, W. Wernsdorfer, A.-L. Cui, O. Sato
and H.-Z. Kou, Inorg. Chem., 2007, 46, 6029.
15 K.-L. Cheung, S.-K.Yip and V. W.-W.Yam, J. Organomet. Chem., 2004,
689, 4451.
16 P.-G. Lassahn, V. Lozan, G. A. Timco, P. Christian, C. Janiak and R. E. P.
Winpenny, J. Catal., 2004, 222, 260.
17 R. Srivastava, D. Srinivas and P. Ratnasamy, J. Catal., 2006, 241, 34.
18 C. Balzarek, T. J. R. Weakley and D. R. Tyler, J. Am. Chem. Soc., 2000,
122, 9427.
19 X. Ribas, R. Xifra, T. Parella, A. Poater, M. Solà and A. Llobet, Angew.
Chem. Int. Ed., 2006, 45, 2941.
20 D. A. Oyugi, F. O. Ayorinde, A. Gugssa, A. Allen, E. B. Izevbigie, B. Eribo
and W. A. Anderson, J. Biosci. Tech., 2011, 2, 287.
This work was supported by Khon Kaen University under
Incubation Researcher Project and the Center of Excellence for
Received: 12th August 2013; Com. 13/4177
